Nuvico CF-ST1N User manual

580
TVL
*Lens not included.

2
Disclaimer
• While every effort has been made to ensure that the information contained in this guide
is accurate and complete, no liability can be accepted for any errors or omissions.
• NUVICO reserves the right to change the specications of the hardware and software
described herein at any time without prior notice.
• No part of this guide may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language in any form, by any means, without prior written
permission of NUVICO.
• NUVICO makes no warranties for damages resulting from corrupted or lost data due to
a mistaken operation or malfunction of the cameras, peripheral devices, or unapproved/
unsupported devices.

3
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE
VENTILATION GRILLS OR OPENINGS ON THE EQUIPMENT.
Warning and Caution
The lightning ash with arrowhead symbol, within an equilateral triangle, is intended to
alert the user to the presence of uninsulated “dangerous voltage” within the product’s
enclosure that may be of sufcient magnitude to constitute a risk of electric shock to
persons.
CAUTION!
WARNING!
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instruction in the literature
accompanying the product.

4
FCC Compliance Statement
CE Compliance Statement
FCC INFORMATION : THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY
WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE
FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION
AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT.THIS EQUIPMENT GENERATES, USES,AND CAN RADIATE
RADIO FREQUENCY ENERGY AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH
THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL INTERFERENCE TO RADIO
COMMUNICATIONS. OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS
LIKELY TO CAUSE HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE
REQUIRED TO CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
CAUTION : CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY
RESPONSIBLE FOR COMPLIANCE COULD VOID THE USER’S AUTHORITY TO OPERATE
THE EQUIPMENT.
THIS CLASS A DIGITAL EQUIPMENT COMPLIES WITH CANADIAN ICES-003.
CET APPAREIL NUMÉRIQUE DE LA CLASSE A EST CONFORME À LA NORME NMB-003
DU CANADA.
WARNING : THIS IS A CLASS A PRODUCT. IN A DOMESTIC ENVIRONMENT THIS
PRODUCT MAY CAUSE RADIO INTERFERENCE IN WHICH CASE THE USER MAY BE
REQUIRED TO TAKE ADEQUATE MEASURES

5
Important Safeguards
• Read these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this equipment near water.
• Clean only with dry cloth.
• Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or other
equipment (including ampliers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding type plug has two blades
and a third grounding prong. The wide blade or the third prong is provided for your safety.
If the provided plug does not t into your outlet, consult an electrician for replacement of
the obsolete outlet.
• Protect the power cord from being walked on or pinched, particularly at plugs, conve-
nience receptacles, and the point where they exit from the equipment.
• Only use attachments/accessories specied by the manufacturer.
• Unplug this equipment during lightning storms or when unused for long periods of time.
• Refer all servicing to qualied service personnel. Servicing is required when the equip-
ment has been damaged in any way, such as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the equipment, the equipment has been
exposed to rain or moisture, does not operate normally, or has been dropped.
• CAUTION - THIS MANUAL IS FOR USE BY QUALIFIED SERVICE PERSONNEL ONLY.
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT PERFORM ANY SERVICING OTHER
THAN THAT CONTAINED IN THE OPERATING INSTRUCTIONS UNLESS YOU ARE QUALIFIED
TO DO SO.
• Use Certied/Listed Class 2 power supply transformer only.

6
Table of Contents
.....................................................................................................
......................................................................................
...........................................................................
...........................................................................
..................................................................................
..........................................................................................
............................................................
.....................................................................................
.....................................................................................
....................................................................
...................................................................................
.......................................................................
.................................................
................................................................
.............................................................................
........................................................................................
........................................................................................
................................................
........................................................................................
..................................................................................
...........................................
.....................................................................
............................................................................................
.......................................................................................
2
3
4
4
5
6
8
9
11
12
13
14
15
16
16
16
17
17
17
17
17
18
18
19
Disclaimer
Warning and Caution
FCC Compliance Statement
CE Compliance Statement
Important Safeguards
Table of Contents
Introduction / Content Verication
Parts & Descriptions
Camera Dimensions
Installing the DC Auto Iris Lens
Power Requirement
Camera OSD Setup Controls
OSD Menu Control & Navigation
OSD MENU CONTROLS (On-Screen-Display)
OSD Menu Terms & Settings
1. AE SETUP (Automatic Exposure)
1.1 MODE (ELC, ALC)
1.2 CONTROL
1.3 SHUTTER
1.4 AGC MODE (Automatic Gain Control)
1.5 MAX AGC
1.6 BRIGHTNESS
1.7 MAX FIELDS - DSS (Digital Slow Shutter)
2. WB SETUP (White Balance)
2.1 MODE
2.2 CONTROL

7
Table of Contents (Continued)
...................................................................................................
................................................................................................
.......................................................
...............................................................................................
...............................................................................................
......................................
...................................................................................................
...........................................................
........................................................
...........................................................
......................................................................................
........................................................................................
.........................................................................................
...........................................................................
..................................................................
...................................................................
OSD Menu Terms & Settings (Continued)
2.3 RED
2.4 BLUE
3. BLC SETUP (Back Light Compensation)
3.1 MODE
3.2 LEVEL
3.3 BMB Mode Menu (Brightlight Masking Block)
4. SPECIAL
4.1 MD SETUP (Motion Detection)
4.2 PZM SET (Private Zone Masking)
4.3 DNR (Digital Noise Reduction)
4.4 SHARPNESS
4.5 LANGUAGE
4.6 EDIT TITLE
4.7 FACTORY DEFAULT
Technical Specications | NTSC
Technical Specications | PAL
19
19
20
20
20
21
22
23
24
24
24
24
24
25
26
27

8
Introduction
Thank you for purchasing our S.I.E.™ 2 Fixed Camera.
Our Fixed Cameras are all equipped with high resolution 1/3” Interline transfer CCD
Imager for enhanced low light sensitivity. Combined with our 2nd generation ‘Super Image
Enhancer II’ - ‘SIE II’ module, viewing in the dark is radically amplied. A user-friendly, on-
screen display (OSD) menu make it easy to setup and program functions.
ABOUT THIS MANUAL
Content Verication
Before installing the camera, please make sure that all of the following items are included
in the box.
1. Fixed Camera
2. Installation Manual
3. C-Mount Lens Adaptor
4. Auto Iris Lens Plug
5. L-Wrench

9
Parts & Descriptions
Front
1. Sensor Protective Cap
Be sure to cap the lens mount when the lens is not mounted.
Pull out the cap to mount the lens.
2. CS-Mount Lens Adaptor
Used to mount a CS-mount lens.
3. C-Mount Lens Adaptor
Used to mount a C-mount lens.
4. Back Focus Set Screw
If needed adjustment of back focus, loosen the set screws using L-wrench to turn
CS-mount lens adaptor and tighten the set screw after adjustment.
5. Tripod Mount Hole
Use to install the camera on the mount.
The tripod must be equipped with the 1/4”-20UNC(20 Thread) screw.
Bottom

10
Back
6. Video Output Connector
BNC connector for composite video out.
7. OSD Menu Set up Key
Control the OSD menu.
8. Power Indicator
9. Auto Iris Lens Connector
Connect auto iris lens plug.
10. Power Input Terminal
Connect 24VAC or 12VDC power source.
Parts & Descriptions

11
Dimensions Unit: mm
Camera Dimensions
See the diagrams below for the exact dimensions of the Fixed Camera.

12
Installation
Installing DC Auto Iris Lens
Using DC Auto Iris lens, connect the Iris lens plug to the camera as shown below.
1. Strip approximately 8mm for outer shield and 2mm for inner shield of lens cable for soldering.
2. Remove the cover from the Iris lens plug and solder the lens cable to the plug pin following the
table below.
3. Connect the lens plug to the auto Iris lens connector on the rear of the camera.
IMPORTANT: This camera is designed to work with DC Auto Iris Lens only. Use of any other lens
type is not recommended.
Pin 2
Pin 4
Pin 1
Pin 3
Pin No.
1
2
3
4
DC Auto Iris Lens
Damp-
Damp+
Drive+
Drive-

13
Installation
Power Requirement
- 12VDC/24VAC 500mA regulated power supply.
- The camera is reverse - polarity protected.
Note: Do not use power sources other than specied.

14
Camera OSD Setup Controls
Please use the directional keys located at the back of the camera to make the desired
changes in the OSD menu.
Enter Key
Right Key
Up Key
Down Key
Left Key
Directional Navigation Keys

15
OSD Menu Controls & Navigation
Enter Key - Used to access MAIN SETUP menu mode.
Up / Down Key - Used to scroll through the desired sub-menu selection and to move the
cursor up or down during the OSD menu.
Left / Right Key - Used to adjust the desired menu selection, and to move the cursor left or
right during the OSD menu. Also used to conrm the setting changes.
To enter the main menu, press and hold the ENTER Key down for 2 or more seconds until
the OSD menu appears on the screen.
To enter the sub-menu from the Main menu, press the Left / Right key at the selected line.
While in the OSD menu, scroll up/down the available options by using the corresponding
navigational keys.
To go to the up-menu from the sub- menu, press the Left / Right Key at the RETURN line.
Once all of the desired changes have been made, move the cursor over to the SAVE AND
EXIT line to save and exit. Choosing EXIT will lose all changes and revert back to its previ-
ously saved conguration.
OSD MENU CONTROLS (On-Screen-Display)
Entering and Navigating the Main Menu
Entering and Navigating the Sub-Menu
Go to the Up-Menu from the Sub-Menu
Exiting the OSD Menu

16
1. AE MODE (Automatic Exposure)
The AE MODE is used to control the video output levels under different intensities
in the lighting. The factory default is ‘ALC.’
1.1 MODE (ELC, ALC)
• ALC (Automatic Level Control): Select the ALC mode and the camera will
continuously monitor changes in the lighting intensity and automatically adjust the Iris to
the most optimal level.
• ELC (Electric Level Control): The ELC mode is not recommended for this camea. ELC
mode will automatically adjust the brightness level by shifting its shutter speed.
OSD Menu Terms & Settings
1.2 CONTROL - Lens Control Mode (AUTO, MANUAL)
• In the case of ALC Mode: DC Iris lens only.
• In the case of ELC Mode: Choose between AUTO or MANUAL. In the AUTO setting, the
shutter and AGC will automatically selected. In the MANUAL setting, shutter and AGC can
be selected manually according to user preference.
ELC ModeALC Mode

17
1.3 SHUTTER (AUTO, 1/60 a... a1/100,000)
• In the case of ALC Mode: The SHUTTER speed can be selected manually according to
user preference. The shutter speed of 1/60(NTSC), or 1/50(PAL) seconds are recommended.
• In the case of ELC Mode: The shutter is automatically controlled and cannot be changed.
1.4 AGC MODE - Automatic Gain Control (AUTO, FIXED)
• In the case of ALC Mode: Choose between AUTO or FIXED. In the AUTO setting, the AGC
will be automatically controlled. The FIXED setting assumes the MAX AGC value.
• In the case of ELC Mode: Same as ALC Mode.
1.5 MAX AGC (OFF, 8dB a... a36dB)
• In the case of ALC Mode: The AGC will compensate the gain levels automatically up to
the pre-determined maximum. The MAX AGC limit can be set as low as 8dB, or as high as
36dB(MAX). The factory default limit is 22dB.
• In the case of ELC Mode: Same as ALC Mode.
1.6 BRIGHTNESS (0 ~ 100)
• In the case of ALC Mode: The BRIGHTNESS can be adjusted by opening and closing of
the Iris aperture. User may ne-tune the screen to their preferred brightness. The brightness
ranges from 0~100 - 0 being the darkest, and 100 being the brightest.
• In the case of ELC Mode: Same as ALC Mode.
1.7 MAX FIELDS (DSS) - Digital Slow Shutter (OFF, 1FLD a... a512FLD)
• In the case of ALC Mode: In the absence of adequate lighting, DSS allows the ability to
capture usable images without the use of additional illumination. The MAX FLD limit can be
set as low as 1FLD, or as high as 512FLD(MAX). The factory default limit is OFF.
• In the case of ELC Mode: Same as ALC Mode.
Note: Increasing the MAX FIELDS will also increase the presence of noise.
OSD Menu Terms & Settings

18
OSD Menu Terms & Settings
The WB SETUP is used to control the white balance under different illumination sources.
Adjust this setting to calibrate the camera for correct color rendering.
The factory default of ‘AWC AUTO’ is strongly recommended.
2. WB SETUP (White Balance)
2.1 MODE (AWC, ATW, INDOOR, OUTDOOR, MWB)
• AWC (Automatic White Balance Control): Choose between the LOCK
mode, AUTO Mode, or the CRLS mode. AUTO mode monitors the color changes and
automatically adjusts the red and blue values to compensate for the color shifting.
LOCK mode locks in the previous color setting and adjusts accordingly. CRLS mode is
used to prevent color-rolling commonly associated with uorescent lighting.
• ATW (Automatic Tracking White Balance): Select the ATW mode if the color
temperature of the light source is between 2,500°K~8,000°K (i.e. Fluorescent Light,
Sodium Vapor Lamps)
• INDOOR: Fixed at 3200°K
• OUTDOOR: Fixed at 5400°K
• MWB: (Manual White Balance) Select the MWB mode to adjust the RED or BLUE
color values manually.

19
OSD Menu Terms & Settings
• This eld displays the current CONTROL status of the WB mode. In the AWC LOCK
mode, the user may control the white balance after pointing the camera to the desired
location. Press Right Key will convert the eld from ‘LOCK’ to ‘PUSH.’ Once the desired
color balance is obtained, press Left Key to lock in the current white balance setting.
2.2 CONTROL - WB Mode Control (LOCK, AUTO, CRLS, 3200°K, 5400°K, R/BCONT)
2.3 RED (0 ~ 255)
2.4 BLUE (0 ~ 255)
• This eld displays the current RED value of the WB mode. RED value can only be
altered in the MWB and ATW mode. The red value ranges from 0~255.
• This eld displays the current BLUE value of the WB mode. BLUE value can only be
altered in the MWB and ATW mode. The blue value ranges from 0~255

20
OSD Menu Terms & Settings
The BLC SETUP is used to control the various Back Light Compensation modes available
in the Fixed camera. BLC can assist in compensating for exposure problem associated
with very bright backgrounds causing subjects to bloom or silhouette. The factory default
is ‘OFF.’
• OFF: The BLC is off.
• BLC (Back Light Compensation): The BLC divides the frame and calculates each
zone according to its exposure level to counterbalance excessive background light to
distinguish the subject in the foreground.
• SBLC (Super Back Light Compensation): Choose the SBLC to correct overexposure
problem traditional BLC cannot compensate.
• BMB (Brightlight Masking Block): The BMB masks out excessively bright areas
within the frame and compensates the rest of the frame accordingly.
• OFF: The BLC is off.
• BLC: The BLC level can be adjusted from 0~100.
• SBLC: The SBLC level can be adjusted from 0~20.
• BMB: The BMB sensitivity can be adjusted from 0~20.
3. BLC SETUP (Back Light Compensation)
3.1 MODE (OFF, BLC, SBLC, BMB)
3.2 LEVEL (Varies)
