Failure to properly installation or use of the equipment may risk to damage the unit or severe personal injury.
The unit cannot be repaired by the end user and must be returned to the manufacturer or his authorized representative.
Any unauthorized modification must be avoided.
INSTALLATION
D5011 series are repeater power supply hart compatible housed in a plastic enclosure suitable for installation on T35 DIN-
Rail according to EN50022, with or without Power Bus or on customized Termination Board.
D5011 unit can be mounted with any orientation over the entire ambient temperature range.
Electrical connection of conductors up to 2.5 mm² are accommodated by polarized plug-in removable screw terminal blocks
which can be plugged in/out into a powered unit without suffering or causing any damage (for Zone 2 installations check
the area to be nonhazardous before servicing).
The wiring cables have to be proportionate in base to the current and the length of the cable.
Intrinsically Safe conductors must be identified and segregated from non I.S. and wired in accordance to the relevant
national/international installation standards (e.g. EN/IEC60079-14 Electrical apparatus for explosive gas atmospheres -
Part 14: Electrical installations in hazardous areas (other than mines)), make sure that conductors are well isolated from
each other and do not produce any unintentional connection.
The enclosure provides, according to EN60529, an IP20 minimum degree of mechanical protection (or similar to NEMA
Standard 250 type 1) for indoor installation, outdoor installation requires an additional enclosure with higher degree of
protection (i.e. IP54 to IP65 or NEMA type 12-13) consistent with the effective operating environment of the specific
installation.
Units must be protected against dirt, dust, extreme mechanical (e.g. vibration, impact and shock) and thermal stress, and
casual contacts. If enclosure needs to be cleaned use only a cloth lightly moistened by a mixture of detergent in water.
Electrostatic Hazard: to avoid electrostatic hazard, the enclosure of D5011 must be cleaned only with a damp or
antistatic cloth.
Any penetration of cleaning liquid must be avoided to prevent damage to the unit.
Any unauthorized card modification must be avoided.
According to EN61010, D5011 unit must be connected to SELV or SELV-E supplies.
For the complete instruction manual ISM0124, datasheet and certifications please refer to our website www.gmintsrl.com.
D5014
SAFETY DESCRIPTION
ATEX: II 3(1)G Ex nA [ia Ga] IIC T4 Gc, II (1)D [Ex ia Da] IIIC, I (M1) [Ex ia Ma] I
IECEx: Ex nA [ia Ga] IIC T4 Gc, [Ex ia Da] IIIC, [Ex ia Ma] I, associated apparatus and non-sparking electrical equipment.
Uo/Voc = 25.9 V, Io/Isc = 92 mA, Po/Po = 594 mW at terminals 7-8, 9-10.
Uo/Voc = 1.1 V, Io/Isc = 56 mA, Po/Po = 16 mW at terminals 8-11, 10-12.
Ui/Vmax = 30 V, Ii/Imax = 128 mA, Ci/Ci = 0 nF, Li/Li = 0 mH, at terminals 8-11, 10-12.
Um = 250 Vrms, -40 °C ≤Ta ≤70 °C.
Approvals:
BVS 10 ATEX E 113 X conforms to EN60079-0, EN60079-11, EN60079-15.
IECEx BVS 10.0072X conforms to IEC60079-0, IEC60079-11, IEC60079-15.
PARAMETERS TABLE
In the system safety analysis, always check the Hazardous Area/Hazardous Locations devices to conform with the related
system documentation, if the device is Intrinsically Safe check its suitability for the Hazardous Area/Hazardous Locations
and gas group encountered and that its maximum allowable voltage, current, power (Ui/Vmax, Ii/Imax, Pi/Pi) are not
exceeded by the safety parameters (Uo/Voc, Io/Isc, Po/Po) of the D5014 series Associated Apparatus connected to it. Also
consider the maximum operating temperature of the field device, check that added connecting cable and field device
capacitance and inductance do not exceed the limits (Co/Ca, Lo/La, Lo/Ro) given in the Associated Apparatus parameters
for the effective gas group. See parameters indicated in the table below:
Terminals Associated Apparatus Parameters must
be
Haz. Area/Haz. Locations
Device Parameters
Ch1, Ch2 7-8, 9-10 Uo / Voc = 25.9 V ≤Ui / Vmax
Ch1, Ch2 8-11, 10-12 Uo / Voc = 1.1 V
Ch1, Ch2 7-8, 9-10 Io / Isc = 92 mA ≤Ii / Imax
Ch1, Ch2 8-11, 10-12 Io / Isc = 56 mA
Ch1, Ch2 7-8, 9-10 Po / Po = 594 mW ≤Pi / Pi
Ch1, Ch2 8-11, 10-12 Po / Po = 16 mW
