GMW 5201 User manual

GMW
USER’S MANUAL
MODEL: 5201
MODEL: 5201-MRD-MPS
PROJECTED FIELD ELECTROMAGNET
MOTORIZED ROTATING DRIVE
Date Sold:____________
PROPRIETARY
THIS DOCUMENT CONTAINS CONFIDENTIAL INFORMATION PROPRIETARY TO GMW ASSOCIATES. IT MUST
NOT BE REPRODUCED OR DISCLOSED TO OTHERS OR USED IN ANY WAY EXCECPT FOR THE INSTALLATION,
OPERATION OR MAINTENANCE OF GMW ASSOCIATES PRODUCTS.
File No:M5201a Projected Field Electromagnet.doc Revision Date: April 10, 2003
_____________________________________________________________________________________
GMW
955 Industrial Road, San Carlos, CA 94070 Tel: [phone] Fax: [phone]
Email: [email protected] Web site: http://www.gmw.com

TABLE OF CONTENTS
SPECIFICATIONS Section 1
5201 Electromagnet Specifications
5201 Motorized Rotational Drive Specifications
WARNINGS [ Refer to this section before operation of ElectromagnetSystem] Section 2
INSTALLATION Section 3
Mounting Position
Electrical Connections
Electrical Interlocks
Water Cooling
Software
OPERATION Section 4
Software Description
Magnet System Software Operation
Electromagnet Operation
Motorized Rotating Drive Operation
Automatic Operation of Electromagnet System and Motorized Rotating Drive.
Logging of Electromagnet System, and Motorized Rotating Drive Parameters.
MAINTANENCE Section 5
Electromagnet
Motorized Rotational Drive
EXCITATION CURVES Section 6
Field versus Current
TEST DATA Section 7
Field Uniformity
DRAWINGS Section 8
Drawing 11901960 Electromagnet/Motorized Rotation Drive General Assembly
Drawing 11901860 Electromagnet General Assembly
Drawing 11901950 Electromagnet Electrical Assembly
Drawing 13900420 Electromagnet Electrical Wiring.
Drawing 13900430 Electrical Wiring Kepco Programming Plug
Drawing 11901910 Electromagnet Terminal Block Assembly
Drawing 11902050 Motorized Rotation Drive General Assembly [no motor drive fitted]
Drawing 11902060 Motorized Rotation Drive General Assembly [with motor drive fitted]
Drawing 11902070 Motor Drive General Assembly
Drawing 13900350 Motorized Rotation Drive Electrical Wiring
Drawing 11902080 Service Panel Assembly
Drawing 11902090 Spool Assembly
Drawing 11902100 Belt Tensioner Assembly
Drawing 11902110 Stop Block Assembly
Drawing 11902120 Worm Mount Assembly
SOFTWARE REVISION LIST Section 9

Section 1
SPECIFICATIONS
Model: 5201 Electromagnet Specifications
Field: (at max current) Bx.= ±0.3T (3000G)
(X,Y,Z= 0, 0, 4mm)
Projected Field Region (for Bx)X = ± 2mm
Y = ± 5mm
Z = 0 to 12mm
Coil:
coil resistance (20°C) 0.85 Ohm
max resistance (hot)* 1.02 Ohm
max power 20A/20V (400W)
Self Inductance:
Cooling:0.5 Litre/min 1.0 bar [14 psid]
Thermal Interlock:Open circuit above 75° C (167°F)
Dimensions:Drawing 11901860
70.0 mm W x 60.0 mm D x 120 mm H
2.8 inch W x 2.4 inch D x 4.7 inch H
Weight:4kg (9lb)
*CAUTION -The value of maximum coil resistance given should not be exceeded.
At this resistance the coils are at maximum safe temperature for continuous operation.
1-1

SPECIFICATIONS
Table 1. Model 5201-MRD Specifications
Rotation Angle:[from zero point] +/-200 deg max
Rotation Repeatability:+/-0.2 deg max
Rotation Accuracy:+/-0.5 deg max
Mechanical Stops:approx. +/-210 deg max
Limit Switches:approx.+/-200 deg max
Homing Switch:0.0deg
Drive System:
Gear type Worm/Worm Gear
Mechanical reduction 100:1
Stepper Motor:
Motor type VS13B-SFRIO
Motor torque 0.5Nm (73 oz.in)
Motor frame size 17
Stepper Motor Controller:
Model Compumotor Zeta 6104
AC Power 115V AC only
Rotation Axis Scaling:approx. 6944 steps/deg
Dimensions: Drawing 11901960
200 mm W x 200 mm D x 193 mm H
7.9 inch W x 7.9 inch D x 7.6 inch H
Weight: 4 kg (9 lb)
1-2

Section 2
WARNINGS
REFER TO WARNINGS BELOW BEFORE OPERATING ELECTROMAGNET SYSTEM
ELECTROMAGNET
1. Safety
In operation the magnet fringing field in the vicinity of the pole gap is in excess of 0.5mT (5G). This can cause
malfunctioning of sensitive electronic and magnetic components. We recommend that warning signs are posted
indicating that a magnetic field may be present.
2. Ferromagnetic Objects
During operation the magnet exerts magnetic attraction towards ferromagnetic objects in the near vicinity of its
pole gap. Keep ferromagnetic items clear!
3. Arcing
This magnet stores energy in its field during operation. Do not disconnect any current lead while under load or
the magnetic field energy will be discharged across the interruption causing arcing and possible damage to
electronic circuits.
4. Coil Hot Resistance
Do not exceed the maximum coil hot resistance given in the specifications or coil overheating and possible
damage may occur.
5. Watches, Credit Cards, and Magnetic Disks
Do not move magnetically sensitive items into the close vicinity of the magnet pole. Even some anti-magnetic
watches can be damaged when placed in close proximity to the pole gaps during operation. Credit cards, and
magnetic disks are affected by magnetic fields as low as 0.5mT (5G). Depending on the previous operating
field and the pole gap, the remanent field in the gap can be in excess of 0.5mT (5G) with the magnet power
supply off or disconnected.
---------------------------------------------------------------------------------------------------------
MOTORIZED ROTATIONAL DRIVE
1. Hand Operation
Do not rotate the Motorized Rotating Drive platen by hand. For hand operation the Motor Drive assembly
must be removed. See maintance section for instruction on how to remove the Motor Drive assembly.
2. Obstructions
Keep foreign objects and tools clear of the Motorized Rotation Drive. Ensure the Electromagnet and
Motorized Rotation Drive do not contact obstructions during rotation.
2-1

Section 3
INSTALLATION
HARDWARE
Mounting Position (Refer to drawing 11902050)
The magnet system can be mounting in any orientation,including being completely inverted. The motorized
rotating drive can be adjusted for height and also leveled by following the procedure below.
1. Loosen setscrew [item 19]
2. Screw –in/out foot assembly to adjust height and level as required
3. Retighen setcrew [item 19]
Four M5 mounting holes are provided on the bottom of the Motorized Rotating Drive for inverted mounting or
securing to test fixture etc.
Electrical Connections
The magnet system comes with integrated wiring for the magnet,and motorized rotating drive. Never connect
or remove cables from the magnet system with the AC power energized otherwise damage to the magnet
power supply or MRD stepper motor controller may occur. Follow instruction below for making electrical
connections.
Power Supply (Refer to drawing 11901950 & 13900420)
1. Plug in the magnet cable plug into the back of Kepco BOP power supply.
2. Secure the connecting plug with the two securing thumbscrews.
3. Connect the three sleeved wires to the output connector block on the rear of the Kepco BOP power
supply as detailed below.
•Black Wire with RED sleeve to Output
•Black Wire with BLUE sleeve to Common
•Green wire to Ground
4. Connect GPIB ribbon cable to edge connector on GPIB board.
5. Connect GPIB adaptor into the back of Kepco BOP power supply.
6. Secure GPIB adaptor with the two adaptor securing thumbscrews.
7. Connect GPIB cable to adaptor and secure with GPIB connector thumbscrews.
8. Connect the other end of the GPIB cable to the host computer.
9. Secure GPIB cable with the two GPIB connector securing thumbscrews.
10. Connect Kepco power supply to AC power source with cord set provided.
Motorized Rotating Drive (Refer to drawing 13900350)
1. Plug in the black 9 way plug on the MRD cable into the Motor connector on the Zeta 6104 controller.
2. Plug in the black 4 way plug on the MRD cable into the Limits connector on the Zeta 6104 controller.
3. Plug in the black 4 way plug on the serial communication cable into the Com 1 connector on the Zeta
6104 controller. Connect other end to host computer.
4. Connect Zeta 6104 controller to 115V AC power source with cord set provided.
3-1

Section 3
INSTALLATION
HARDWARE
Electrical Interlocks
The Model 5201 has two temperature switches, Selco part no 802L-075. They are located on the pole/coil
assembly heatsinks and wired in series. The temperature switches are normally closed, opening when the coil
heatsink temperature exceeds 75°C +/5°C.
Water Cooling (Refer to drawing 11901960)
The Model 5201 can be operated to an average coil temperature of 70° C. Assuming an ambient laboratory
temperature of 20°C and a temperature coefficient of resistively for copper of 0.0039/°C, the hot resistance of
the coil should not exceed 20% more than the ambient temperature "cold" resistance. The coil thermostat will
open when either pole/coil heatsink temperature exceeds approximately 75° C. If either temperature switch
opens then the Magnet power supply circuit breaker will trip to the off position. Clean, cool (16°C -20°C)
water at 0.5 l/min at 1.0 bar (14 psid) should be used to cool the 5201 magnet.
The cooling copper tubes are electrically isolated from the coils to avoid electrochemical corrosion. A 50
micron filter should be placed before the input to the magnet to trap particulates and avoid blockage of the
cooling circuits.
Water Cooling Connections
The magnet system has two water cooling connections provided on the rear of the motorized rotating drive.
Two barbed “push on” hose couplings are provided to suit 6 mm (1/4”) ID rubber hose.
•Water Inlet: Connect to a clean water source fitted with a suitable metering valve
(to control water flow).
•Water Outlet: Connect to drain.
Inlet Water Metering Valve Kit.
Metering Valve (brass) SWAGELOCK Cat No: B-4MG2 (1 required)
Hex Coupling (brass) 1/4” NPT female SWAGELOCK Cat No: B-4-HGC (2 required)
Hose Connectors (brass) 1/4” NPT to1/4”Hose SWAGELOCK Cat No:SB-PB4-PM4
(2 required)
Hose Push On (black) 1/4” ID SWAGELOCK: Cat No: PB-4-BK (as required)
3-2

Section 3
INSTALLATION
SOFTWARE
Software Requirements
•An IBM PC 486/Pentium or compatible.
•8Mb RAM memory.
•SVGA monitor running 1024 x 768 pixels. [Note1]
•CD Rom Drive.
•GPIB Board [National Instruments compatible].
•Windows 95/98/ME/XP Operating System software.
•LabVIEW for Windows 95/98/ME/XP.Ver 6.0 or higher.
Motorized Rotating Drive software can also be supplied as an executable file and run directly from the
Windows Operating System. In this case LabVIEW for Windows V6.0 is not required. [Note 2]
Software Installation
The Motorized Rotating Drive LabVIEW driver and support files are all located in a directory called 5201
Magnet Control.
To install the driver follow the directions given below.
1. Insert CD rom into computer CD ROM drive
2. Copy the complete 5201 Magnet Control directory to the host computers hard drive.
3. Locate the Default.dat file in the Data directory.
4. Right mouse click on the file properties
5. Uncheck the Read Only attribute.
Before running the 5201 Magnet Control software set the Com Port control to match the Com Port being
used on the control computer. [Com 1 is the default.] The 5201 Magnet power supply is set to GPIB address
2 and is not changeable from the Setup Panel.
Note:
1. Using screen resolutions other than 1024 x 768 means all items on the LabVIEW front panels will have to
be resized by the end user.
2. The executable program file cannot be altered by the end user. Consult GMW if the 5201 Magnet
Control software is required as a executable file.
3-3

Section 4
OPERATION
SOFTWARE DESCRIPTION
MAIN CONTROL PANEL
Panel Control:. Makes either Setup or Automatic control panels visible.
Control Mode:. Selects either Manual or Automatic control mode of operation.
Key Focus Control:. When Key Focus is turned on the selected control is controlled by the Up an Down
arrows on the computer keyboard. A set value can also be directly entered from the
numeral keypad. By default the lowest significant digit is controlled and rolls over to
the next highest digit. Roll over occurs between the lowest to the most significant digit.
System Shutdown: Sets zero current on the magnet power supply, and stop rotation on the Motorized
Rotating Drive. Finally this LabVIEW application stops running, and a System
Shutdown message is displayed.
MAGNET FIELD CONTROL
Setpoint Control: Selects either a current setpoint in Amps or field input in Tesla.
Setpoint Mode Control: Selects either current control or field control of the magnet system..
Excitation File Control: Makes sub panel visible for the creating and loading of open loop characterization files.
Magnet Voltage Indicator: Display voltage from the magnet power supply.
Magnet Current Indicator: Display current from the magnet power supply.
Loaded Excitation File: Displays the current loaded excitation file.
MAGNET ROTATION CONTROL PANEL
Home CW Control: Makes the motorized rotating Drive rotate in a clockwise direction until it finds the
homing position at 0.0 deg and resets the current position counter to 0.0 deg.
Home CCW Control: Makes the motorized rotating Drive rotate in a counterclockwise direction until it finds
the homing position at 0.0 deg and resets the current position counter to 0.0 deg.
Counter Reset Control: Resets the current position counter to 0.0 deg.
Velocity Control: Sets the velocity of the stepper motor.
Set Position Control: Sets the MRD platen to the desired position.
Immediate Control: Starts the MRD in motion as soon as set position input value is entered.
Go Control: If immediate control is turned off, no motion occurs on the MRD until the Go button is pressed.
Start Motion CCW Control: Starts the motorized rotating drive rotating in a counterclockwise direction until
a soft limit is reached, or the Stop Motionbutton in pushed.
Start Motion CW Control: Starts the motorized rotating drive rotating in a clockwise direction until a soft
limit is reached, or the Stop Motionbutton in pushed.
Stop Motion Control: Stops the motorized rotating drive rotating at any time.
Emergency Stop Control: Stops the motorized rotating drive rotating INSTANTLY.
FOR EMERGENCY USE ONLY.
4-1

Section 4
OPERATION
SOFTWARE DESCRIPTION
MAGNET ROTATION CONTROL PANEL (Continued)
CCW Limit Control: Stops the motorized rotation drive from rotating in thecounterclockwise direction when
the current position counter equals the CCW limit setting.[A red indicator shows when
limit is reached.]
CW Limit Control: Stops the motorized rotation drive from rotating in theclockwise direction when the
current position counter equals the CW limit setting. [A red indicator shows when limit
is reached.]
Current Position Indicator: Shows the motorized rotation drive current position on a digital display. Units
are in degrees from the initialized zero position, [normally 0.0 deg.]
Ramp Indicator: Shows velocity ramp up and down as set position is approached.
SETUP PANEL (Visible only when selected with the Panel Control)
Com Port Control: Selects the computer serial port to use to communicate with the stepper motor controller.
[Set to Com 1 as default.]
Motor Controls: Sets the acceleration, start of speed ramp down, ramp rate and axis scaling of the stepper
motor. Ramp feature can be turn On or Off by the Ramp control switch
Home Motion Controls: Sets the acceleration, deceleration and velocity of the stepper motor when homing
to the 0.0 deg position.
Soft Limits Range: Sets the maximum, minimum and increment on the soft limits scale. Soft Limit feature can
be turned On or Off by the Soft Limits control switch.
Velocity Chart Indicator: Shows the current acceleration, deceleration and velocity of the stepper motor.
Reset Controller on Start Up: Sends a Reset command to the stepper motor controller. This command is
only sent once when the program starts.
AUTOMATIC CONTROL/LOGGING PANEL (Visible only when selected with the Panel Control).
Date Indicator:Shows the data from the computers clock.
Time Indicator:Shows time from the computers clock.
Step in Progress: Shows the current row of data being used for automatic control.
Automatic Control: Turns On and Off the automatic operation from the table setting control.
Logging Control: Turns On and Off logging of system data to log file.
Table Settings Control: The table setting control has five columns of data. Step is the row of Data in use.
Current or Field settings are sent to the magnet power supply. Rotation settings
are sent to the Motorized Rotating Drive. Time in seconds is the interval between
steps.
Step Control: Single steps the table control through steps 1,2,3,4 etc.
Zero Control: Returns the table control to step 1.
4-2
