Go Power GP-MPPT-PRO-40-60-R User manual

GP-MPPT-PRO-40-60-R
Solar Charge Controller Remote
Quick Start Guide
Find tech tips, manuals and support at gpelectric.com
No.
Descripon
1Communication Fault Indicator
6
7
Escape Button
OK Button
2 Communication Connection Indicator
3LCD Screen
4Up Button
5
Down Button
Main Menu
40/60 Solar Controller Remote GP-MPPT-PRO-40-60-R
4 5 6 7
1
3
2
To set battery type, view historical data, and use other functions,
refer to the user manual for at gpelectric.com/MPPT-PRO.
Icon State Description Comments
Steady on Nighttime
Related to
charging
Steady on Daytime
Steady on
A dynamic arrow indicates charging is
in process, while a static one indicates
otherwise.
"0 to 100%"
Current battery capacity
Related to
battery
"0%" in slow
flashing
Battery over-discharged
"100%" in
quick flashing
Battery over-voltage
Steady on
A bulb shown as left and a dynamic
arrow indicate the load is switched on.
Related to
load
Steady on
A bulb shown as left and a static arrow
indicate the load is switched off.
Quick flashing Overload or short-circuit protection
Icon Descre

Item
QTY
LCD Display Unit -
-

Expansion Bolts
Data Cable (2m) 6 cores, RJ12 at both ends

panel

wall
User Manual
KA3 * 12_Black Countersunk
Machine Screws
KA4 * 25mm Tapping Screws
1
4
1
1
4
4
REMARKS
Installation Usage of Navigation Keys
The GP-MPPT-PRO-40-60-R installation on a controller case or panel.
The GP-MPPT-PRO-40-60-R installation on a Wall.
See user manual for complete instructions at gpelectric.com
Packing List
ITEM
External dimensions: 115.82×115.82mm
Installation dimensions: 96mm or 103.82x103.82mm
Installation hole diameter: ￠3.5 (mm)
External dimensions: 118.5×118.5x48mm
Installation dimensions: 50x50mm or 70x70mm
Installation hole diameter: ￠5 (mm)
The product design features 4 keys which, from left to right, are:
" ", " ", " ", " "
They equal to ("Up", "Down", "ESC", "OK")
KEY
OPERATION
DESCRIPTION
Tap, press
and hold
1) When browsing a menu , tap the key for a page up,
2) In parameter seng, tap the key to increase the value by a minimum unit;
3) Press and hold the key for quick page -up movement or value increasing.
Tap, press
and hold
1) When browsing a menu , tap the key for a page down;
2) In parameter seng, tap the key to decrease the value by a minimum unit;
3) Press and hold the key for quick page-down movement or value decreasing.
Tap
1) When browsing a menu, tap the key to return to the previous level, unl the
main menu is reached;
2) In the seng mode, a tap on this key can cancel the data modicaon in
process and exit the seng mode.
Press and
hold
In any menu, press and hold the key to immediately skip to the "error code
page for convenient checkup.
Tap
1) In a menu which contains submenus, tap the key to enter into a submenu;
2) In a menu with seable or adjustable parameters, tap the key to enter into
or conrm parameter seng.
Press and
hold
If "manual mode" is selected as the load mode, a press-and-hold on the key
to switch on/ othe load.
If it's not in the manual mode, a press-and-hold will cause the display to skip
to the load mode seng interface as a reminder.
(Note: if no load is connected to the controller, this function and related load parameters will
become inoperative.)
