Gobo ECO Spot LED A10 User manual

ECO Spot LED A10 User Manual
Copyright © 2015 Globus New Media LLC Page 1
Thank you for choosing an ECO Spot™ Gobo projector.
Please read this manual before installing or operating this fixture,
follow the safety precautions listed below and observe all warnings.
Package Contents
Projector with integrated Projection Lens
Test Gobo mounted
Spare Gobo Retaining Ring
User Manual
Safety Information
Follow all local building and electrical codes and apply both, overload and
ground-fault protection.
Handling Instructions
Warranty
One Year from Date of Purchase. Keep your receipt for reference and contact your dealer
in case of warranty issues.
ECO Spot™ LED A10
User Manual
Place your fixture at a suitable place with good air flow.
Keep flammable materials away from the fixture.
Minimum distance to flammable material = 1ft (0.3m).
Do not look directly into the lamp; it can result in eye damage.
Disconnect the fixture from AC power before handling it.
Do not use the fixture if the power cable or power plug is in any way damaged,
defective or wet, or if they show signs of overheating.
Light fixtures should be installed and maintained only by qualified personnel
with experience in lighting equipment and general electrical experience.
Before the initial start-up, please unpack and carefully check for damage
caused during transportation.
When suspending the fixture above ground level, verify that the structure can
hold at least 10 times the weight of all installed devices.
Verify that all external covers and rigging hardware are securely fastened and
use an approved means of secondary attachment such as a safety cable.

ECO Spot LED A10 User Manual
Page 2 Copyright © 2015 Globus New Media LLC
Focusing
Mounting Bases
Gobo Placement (see illustrations below)
The Projector uses D-Size gobos
, (see Specifications for Gobo Dimensions). See the
illustration below
Power up the projector.
Focus the projection by twisting the lens in the front of the Lens Barrel in and
out until the image is well focused. When used for the first time, the lens will
often need to be twisted outwards many rotations to reach the focusing point.
To adjust the rotational gobo position, twist the complete Lens Barrel. You may
have to re-adjust the focus.
The projector is available with different mounting bases:
Rectangular Wall Base that can be used to place the projector onto a desk,
attach to a wall or ceiling.
Track Base for Halo and compatible systems.
Round Wall Base (special order)
These bases are order options and cannot be interchanged in the field.
If the projector is on, turn it off.
Even though this is a LED projector, the gobo can get hot, please wait a few
minutes for the gobo to cool down if the projector was on.
Unscrew the Lens Barrel.
The gobo sits inside the Lens Barrel. Push the two pins of the gobo retaining
ring together and pull out the retaining ring. Carefullyremove the old gobo
and replace it with the new gobo.
If you have a glass gobo, place the more reflective side towards the light bulb.
Replace the retaining ring and make sure it evenly pushes the gobo all the way
back.
Replace the Lens Barrel but don’t screw it in tightly.
Turn on the projector and adjust the rotational gobo position by twisting the
Lens Barrel.
Focus the image by twisting the front lens in or out.

ECO Spot LED A10 User Manual
Copyright © 2015 Globus New Media LLC Page 3
Lens Barrel
Unscrew the Barrel
to access the Gobo
Projection Lens,
twist to focus.
The Gobo sits
inside here.
Gobo Retaining
Ring
Projector Base

ECO Spot LED A10 User Manual
Page 4 Copyright © 2018 Globus New Media LLC
Line Voltage
110- 240/277V, 50 - 60Hz, 14W
Ambient Operating Temperature
-13 to 104°F (-25 to 40°C)
Dimensions / Weight
Fixture Body: 9” x 3” (23 cm x 7.6 cm)
Weight 13lbs (6kg)
Gobo Dimensions D-Size
Metal or Glass Gobos and Dichroic filters
The projector takes D-Size gobos:
Outer Diameter (OD):53mm
Image Diameter (ID):2 mm
Max Thickness:4mm
Larger ID up to 38mm is possible for
pattern projection and some loss in
focusing quality, for optimal focus stay
within 24mm image size. An adapter for
the smaller E-Size gobosis available.
LED Lamp
Lens Options
The projector comes with a standard
projection lens.
Medium-Narrow f=70mm 28º
Other lenses available as build options on
request.
Extremely high light density for
ultra-efficient projection.
Power: 10W
Bulb life 50,000h
Color Temperature 6,000k, +/-
500k
Rated Luminous flux: 850lm
Effective luminous flux: 580lm
