Goddess RHODOS 2 User manual

RHODOS 2 / RHODOS 2 ION
/ RHODOS 2 CE ION
NÁVOD K POUŽITÍ / NÁVOD NA POUŽITIE
INSTRUCTION MANUAL
Rohová infra
sauna
Rohová infra
sauna
Corner infra
sauna

EN - 30
EN
Thank you for choosing our infrared sauna!
INDEX
Important safety guides ......................................................................................................... 31
Introduction ............................................................................................................................ 32
Benets, Highlights ................................................................................................................ 32
Installation requirements ....................................................................................................... 33
Installation procedure ............................................................................................................ 33
Operation ............................................................................................................................... 39
Warnings ............................................................................................................................... 40
Trouble Shooting ................................................................................................................... 40
Clear and Maintenance ......................................................................................................... 42
Transportation ....................................................................................................................... 42
Packing List ........................................................................................................................... 42

EN
EN - 31
IMPORTANT SAFETY GUIDES
READ AND FOLLOW ALL INSTRUCTIONS
a) A receptacle shall not be installed inside the heated room.
b) The door of the heated room do not include any locking or latching system, malfunction
of which could cause entrapment inside the heated room.
c) Keep the intended ventilation open when use the dry-bath bathing room.
d) CAUTION – Hyperthermia occurs when the internal temperature of the body reaches a level
several degrees above the normal body temperature of 98.6°F (37°C). The symptoms of
hyperthermia include an increase in the internal temperature of the body, dizziness, lethargy,
drowsiness, and fainting. The effects of hyperthermia include:
a) Failure to perceive heat;
b) Failure to recognize the need to exit the room;
c) Unawareness of impending hazard;
d) Fetal damage in pregnant women;
e) Physical inability to exit the room; and
f ) Unconsciousness.
e) WARNING – The use of alcohol, drugs, or medication is capable of greatly increasing
the risk of fatal hyperthermia.
f) WARNING – reduce the risk of electrocution and burns, do not operate unless guard
is in place.
g) CAUTION – excessive exposure can be harmful to health.
Persons with poor health should consult their physicians before using sauna.
h) CAUTION – reduce the rick of re, do not place combustible material on heater at any time.
i) CAUTION – don´t take water not the other liquids into the sauna room, in order to prevent
the injury from the electric current.
j) WARNING – reduce the risk of overheating:
a) exit immediately if uncomfortable, dizzy, or sleepy, staying too long
in a heated area is capable of causing overheating.
b) supervise children at all times.
c) check with a doctor before use if pregnant, in poor health, or under medical care.
d) breathing heated air in conjunction with consumption of alcohol, drugs, or medication is
capable of causing unconsciousness.
k) WARNING – reduce the risk of electrocution, disconnect the supply connect before
servicing.
Save these Instructions

EN - 32
EN
INTRODUCTION
We welcome you to the most affordable infrared sauna in the nation! We also congratulate you
on your new path to better health! Thousands of users enjoy the benets of infrared saunas
every day. Infrared saunas help you burn calories, reduce toxins, relieve pain and even clear
complexions. Now you can enjoy the great benets of far-infrared heat within the privacy of your
own home.
We strive to deliver superior ttness products at an affordable price.
Our list of clients grows daily and we believe that your success is our success.
Our staff is ready to provide you with excellent customer service
HEALTH & BEAUTY BENEFITS
Relieve pain:
The far-infrared rays of a sauna accelerate the blood circulation and supply more oxygen to
the body. Increased blood circulation diminishes inammation, relieves pain, and speeds up
recovery. Infrared saunas have also been used to treat bursitis, rheumatism, arthritis,
and hemorrhoids. Increased blood circulation not only alleviates internal ailments, but also skin
conditions such as psoriasis, eczema and scars. Good circulation is essential for smooth
and rm skin.
Burn calories & fat:
The far-infrared rays of the sauna eliminate extra salt and subcutaneous fat. Burn up to 600
calories in one half hour session versus a half hour of jogging which burns 300 calories,
and a half hour of cycling burns 225 calories.
Relax your body and mind:
Use the built-in CD player to listen to your favorite music to relax and reduce stress. Infrared
saunas also improve; often cure insomnia, and other stress related disorders (CD is the optional
part).
Reduce toxins and improve complexions:
Sweating in a lower temperature environment activates the sweat glands and expels toxins from
the skin
HIGHLIGHTS
a) High quality craftsmanship
b) Automatic thermostat for constant temperature
c) Timer and buzzer: buzzer sounds 5 minutes before the end of session
d) Digital sensor and thermometer
e) Infrared heating pipes
f) FM radio and AUX input for connecting MP3 player / mobile phone
(stereo connection cable included)
g) Ionizer - by a large number of negatively charged ions (anions) refreshes the air, cleans it
from smoke, dust, pollen from flowers and other debris, kills bacteria and viruses.
(only for model with Ionizer: RHODOS 2 ION / RHODOS 2 CE ION)

EN
EN - 33
INSTALLATION
INSTALLATION REQUIREMENTS
a) Do not plug any other appliances into the outlet with your our infrared sauna. (The outlet
must be secured by curent balance protection)
b) Install the sauna on a completely level floor.
c) Do not spray the exterior with water. If the floor is damp, install a floor separator to keep the
sauna high & dry.
d) Do not store flammable objects or chemical substances near the sauna.
INSTALLATION PROCEDURE
SAUNA ROOM:
1) Structure of Infrared Sauna. See FIG-1 (illustrative picture - differs as per the model NO.)
1) front board
2) door
3) bottom board
4) protect screen
5) heater
6) sitting baffle
7) bench
8) inlet of air
9) right side board
10) temperature controller
11) temperature use
12) right back side board
13) internal top board
14) external top board
15) outlet of air
16) light
17) electric control box
18) lampshade
19) screw 001
20) left back side board
21) heater
22) protect screen
23) screw 002
24) left side board
25) screw 003
26) DIGITAL PANEL
27) window panel
28) door knob

EN - 34
EN
2) One unit is packed into 3 cartons. See FIG-2
OBR-2 3 cartons OBR-2.1 C/No.
Check the C/NO. on all cartons if they are the same. If not, please notify the store/website
youpurchased your Infrared Sauna. 2-persons corner sauna, 3-persons corner sauna are
packed in 3cartons, for example: C/NO: 002 1OF 3, C/NO: 002 2 OF 3
and C/NO: 002 3 OF 3 are for one unit;. See FIG-2.1.
3) Make sure all parts are present before installing the unit. See packing list below.
4) Installation procedure
Place the bottom board in the desired location of your sauna, and make sure which side is
the front and which side is the back. See FIG-3.
FIG-3 Placing bottom oor
5) Align the right back side board with bottom board’s corresponding battens; make sure they
are in line. Assemble the left back side board and right back side board by using the
latching. See FIG-4, 5.
FIG-4 Assembling right back-side board FIG-5 Assembling left back-side board

EN
EN - 35
6) The latch has a guide tab that must be placed in the guide slot for alignment. Pick up the
back panel (hold it upright to the oor panel) and place the tab in the slot, do not latch at this
time. When the back wall and the front wall/side wall are set together on the oor panel,
close and latch it. See FIG-6.
FIG-6 Latching
7) Align the right side board with bottom board’s corresponding battens, make sure right side
board ts ush into right back-side board. Latch it. Do the same way when assemble the left
side board. See FIG-7.
8) Hold the long sitting bafe with heater along the left back side board, and the right side
board’s corresponding slot then place it vertically into these slots. Note: Please make sure
this board is in the slot; otherwise the sitting board will become unstable. See FIG-8.
FIG-7 Assembling the left and right side boards FIG-8 Assembling long sitting bafe
9) Hold the short sitting bafe along the left and right sideboard, and the short sitting bafe’s
corresponding slot then place it vertically into these slots. Notes: Do make sure this board is
in the slot; otherwise the sitting board will become unstable. See FIG-9.
10) Connect the electrical wire in the left and right back board with corresponding wire in the
sitting bafe. Note: Please make sure they are tightly connected; otherwise the heater will
not work. See FIG-10.
FIG-9 Assembling short sitting bafe FIG-10 connecting the wire

EN - 36
EN
11) Put the sitting board horizontally on corresponding battens of the right back side board.
See FIG-11
FIG-11 Assembling sitting board FIG-12 locked bench
12) Use screws to x the bench onto back-side and sitting panel. See FIG-12.
13) Align the front board with bottom board’s corresponding battens, and then latch it with the
left and right boards respectively. Note: Take caution of the glass door to avoid damage.
See FIG-13.
14) Put all of the wires outside to leave enough space for setting up the top board. See FIG-14.
Open the door, raise the top board high enough to see if it ts with the surrounding boards,
and then put down.
FIG-13 Assembling front board FIG-14 Assembling the inner top board
15) During the course of putting down the internal top board, make sure all the wires (mentioned
above) and connecting plugs are slipped through the corresponding holes of the top board.
All these wires will be led into connecting with the controller on the internal top board.
See FIG-15.
FIG-15 put through the wire FIG-16 linker on the outer top board
16) All the infrared heaters are pre-assembled. See FIG-16. Connect all the wires and
connectors to the corresponding outlets on the top board. Please be sure that all the plugs
are connected tightly.

EN
EN - 37
17) After that, put down the power plugs of the speakers, temperature sensor, control panel
through the hole near the fan on the top board. See FIG 17.
FIG-17 Leading the wires of heaters onto the board through the corresponding hole
18) Install the ionizer
(Note: Insert the ionizer to the prepared frame from the top side and connect the power
connector). See FIG-18.
FIG-18 Install the ionizer
19) Making sure all steps are nished correctly, plug in the power and try using the sauna at rst
to make sure it will work properly. Then put the external top board. Over the internal top
board, and take out the power plug through the corresponding hole in the external top
board. See FIG-19.
FIG-19 Slip the power plug through FIG-20 Fix the external
external top board board with screws
20) Take the screws afxed on the external top board, then set up the board using the cross
screwdriver. See FIG-20.
Installation Completed.

EN - 38
EN
OPERATION
1) Precautions
a) Check all the circuitry and the plug meet all requirements.
b) Set the temperature and time to a comfortable level, normally, 60 minutes at
50 - 65ºC (122ºF - 140 ºF)
Note: If ambient temperature is lower than 18.3ºC (65ºF), please set the temperature at
about 122ºF (50ºC); and if ambient temperature is higher than 18.3ºC (65ºF), please set
the temperature at about 65ºC (140ºF).
c) Drink a cup of water before the sauna session.
d) After 2 hours of continuous use, shut the sauna down for one hour.
e) To avoid burns, do not touch the heating element.
2) Operation
a) See electrical label on the unit, and plug the sauna into a proper wall outlet
(220 - 240 V). Do not share the outlet with any other appliances. Switch on the main
switch at the ceiling of the sauna room and then activate the sauna through the ON/OFF
switch on the control panel. Sauna should be unplugged when not in use.
b) Press the “temperature“ button to increase or decrease the temperature. If the “heat“ light
is on, the temperature setting will increase one degree every time the “+“ button
is pushed. If pressed for three seconds, the setting will increase quickly.
Decrease the temperature in the same manner by pressing the “-“ button.
After the sauna reaches the desired temperature, the “heat“ light turns off.
c) Press the “light“ button to turn the light on and off.
d) If the sauna is too stuffy, open the vent in the ceiling or open the front door.
e) After your sauna session, turn off, and unplug the power cable.
f ) To set the time press the “function“ button until the “time” button blinks.
Press the “+“ and “-“ buttons to set the timer from 5 to 60 minutes. If pressed for three
seconds, the timer will increase quickly. When the display reads “05“, the timer will
buzzes then the machine will shut off automatically after 5 minutes. To extend the sauna
session, reset the timer again.
g) The Fahrenheit and Centigrade display can be switched: press the temperature
button “+“ and “-“ at the meantime, then press the button of “light“ to switch
h) If you want to activate (or deactivate) the ionizer, you can do it any time during
the sauna process by switching the ON (OFF) button on the ionizer.

EN
EN - 39
3) Music playback
1) Plug in the socket for the sauna and Press Music button to start ,Temperature display
shows AU means AUX function,shows XXX XO means radio,When it is in radio mode.
Control panel will display frequency from (86.00-108.00).
2) Press TEMP/FM button to change the frequency. Press it for 1.5 seconds ,
it will decrease or increase automatically until received radio; Press it more than
2 seconds ,It can search radio cyclically after listening the beep .It will stop one second
when received radio ,at the same time you can press any “frequency” button or “voice”
button to stop searching radio.
3) Press TIME/VOL button to decrease or increase voice .Control panel will display “UL”,
you can change.
The voice from “00”to“15”, “00” indicates mute and “15” indicates maximum.
4) The voice and radio can be storage automatically .It can recover previous radio and voice
next time.
5) Control panel will display temperature and time if there is no operation for 15 seconds
(when sauna is working) .
6) It can change to Music operation by pressing “ Music ” button when it under sauna room
working mode ,and the “Music” button will twinkle.
7) Press “Music” button to AUX .Plug into AUX input and you will receive signal from AUX.
Please turn off the AUX input when not in use.
8) Press “Music” button long time, The temperature display can change from“n1” and “n2”.
“n1”: Adjust frequency with 100 KHz ; “n2”: Adjust frequency with 50 KHz .

EN - 40
EN
WARNINGS
1) Safety precautions
a) To avoid re, do not dry clothes or leave any towels in the sauna.
b) To prevent burns or electric shocks, do not touch or use metal tools on the net cover
of the far infrared heater elements.
c) While in the sauna, do not touch the light bulb. If the bulb needs to be changed, switch it off
and wait until the sauna is shut off and the bulb is cool
d) Do not spray water on the far-infrared lm. This activity may result in electric shock
or damage to the heater elements.
e) Do not use the infrared sauna if you have any of the following conditions:
1) Open wounds
2) Eye diseases
3) Sever sunburns
4) Elderly & weak people, especially those suffering from a disease, pregnant women
and infants are prohibited. Children over the age of 6 years may use the sauna under
the supervision of adults.
5) If suffering from a disease directly related to temperature, seek the advice of a doctor before
using.
F) Do not place pets in the sauna.
G) Do not use the sauna if you are under the effects of alcohol.
H) Do not take water or the other liquids into the sauna room.
TROUBLE SHOOTING:
Problem Possible reason Countermeasure
Indicator light for power
supply not working
The connector is not connec-
ted properly
Check the connector or replace
a new one
No power supply input
chick the circuitry (especially
weather there is power supply
input)
Indicator light is broken replace the circuitry panel
Indicator light for function
is not working
The heating indicator light is
broken Replace the relevant control panel
The circuit board or compo-
nents are broken Replace the circuit board
The temperature sensor is
broken
Check the connect is loosen
and replace it
Infrared Heater not hea-
ting up
The heater is broken Replace with a new one
Of the same specications
The wire junction or the hea-
ter’s wire is loosen Check and make them tight
The temperature sensor is
broken
Check junction of the temperature
sensor is loosen and replace it
The circuit board of the relay
is not work Replace the circuit board

EN
EN - 41
Odor from the sauna The circuit‘s problems
1) There is eyewinker around,
remove it
2) Some heater’s temperature
over high,cut off the power
supply,replace it
3) Parts on the circurity is broken
Light bulb is not working
Light bulb is burned out Replace the light bulb
Light bulb wiring is loosen Replace the lamp holder
Problems with electrical
control panel Repair or replace it
Sauna is not power up
Power cord is unplug Plug back power cord to outlet
Outlet has no power Check outlet or circuit breaker
Power supply or circuit panel
is broken
Replace the power supply or rela-
ted circuitry board
The temperature display
show „EP
The connector of
temperature sensor is loose
or sensor damaged
Tighten the connector of tempe-
rature sensor or change to a new
temperature sensor
The temperature display
show „H“
The temperature inside
the sauna room is too high
Turn off the unit, and contact
the manufacture.
Speaker does not work
The speaker is broken Replace with a new one of
the same specications
The speaker wire is loosen Reconnect the speaker wire
The connecting cable from
the MP3 player / phone
is broken or loose.
Check or replace the cable.

EN - 42
EN
USER MAINTENANCE INSTRUCTIONS
CLEAR AND MAINTENANCE
Cleaning
Clean the faceplate with a wet towel, or clean with a small amount of hand-soap mixed
with warm water if necessary. Clean the sauna room with a wet cotton towel, dry with a clean
dry towel.
Do no use benzene, alcohol, or strong cleaning chemicals on sauna.
NOTE: Any chemical that can damage wood material will damage the sauna
and the protection layer that is on the wood.
Suggest: do not leave the sauna on for more than 2 hours at a time.
(For giving heaters longer lifetime.)
TRANSPORTATION AND STORAGE
1) Avoid exposure to rain, snow or strong collisions during transport.
2) Do not store in damp environments.
PACKING LIST
1X Infrared sauna room with oor
6X Heating element
4X Light
2X Speakers (optional part)
1X Bag of screws and bolts
1X Instruction manual
1x Ionizer (only for model with Ionizer: RHODOS 2 ION / RHODOS 2 CE ION)

EN
EN - 43
We reserve the right to change technical specifications.
WARNING: Do not use this product near water, in wet areas to avoid re or injury
of electric current. Always turn off the product when you don’t use it or before
a revision. There aren’t any parts in this appliance which are reparable by consumer.
Always appeal to a qualied authorized service. The product is under a dangerous
tention.
Old electrical appliances, used batteries and accumulators disposal
This symbol appearing on the product, on the product accessories or on the
product packing means that the product must not be disposed as household
waste. When the product/ battery durability is over, please, deliver the product
or battery (if it is enclosed) to the respective collection point, where the electrical
appliances or batteries will be recycled. The places, where the used electrical
appliances are collected, exist in the European Union and in other European
countries as well. By proper disposal of the product you can prevent possible
negative impact on environment and human health, which might otherwise occur as
a consequence of improper manipulation with the product or battery/ accumulator. Recycling
of materials contributes to protection of natural resources. Therefore, please, do not throw
the old electrical appliances and batteries/ accumulators in the household waste. Information,
where it is possible to leave the old electrical appliances for free, is provided at your local
authority, at the store where you have bought the product. Information, where you can leave
the batteries and accumulators for free, is provided to you at the store, at your local authority.
