Godox Ami User manual

说 明 手 册
Instruction Manual
地址/Add: 深圳市宝安区福永镇福洲大道西新和村华发工业园A4栋
Building A4, Xinhe Huafa Industrial Zone, Fuzhou RD West, Fuyong
Town, Baoan District, Shenzhen 518103, China
电话/Tel: [phone](8062) 传真/Fax: [phone]
邮箱/E-mail: [email protected]
深圳市神牛摄影器材有限公司
GODOX Photo Equipment Co., Ltd.
705-AMI000-00 Made in China 
Smartphone Flash

Before using this product
Please read this user manual carefully in order to ensure your safety and the proper
operation of this product. Keep for future reference.
Thank you for purchasing a GODOX product.
Godox Ami smartphone flash is light and portable with built-in lithium battery.
The Ami flash offers:
• Operation with phone APP: With built-in Bluetooth 4.0 Module, which enables Ami
to connect the smartphone through Bluetooth, thus setting flashes or LED
video lights’ parameters on the APP interface.
• Lightweight and portable: Built-in lithium battery with no carriage burden.
• Stable color temperature: 6000±200K over the entire power range.
如果遇到问题，请参阅此故障排除指南。
闪光曝光不足或过度
• 照片中存在反光强烈的物体(玻璃窗户等)。
手指不要遮挡感光部位。•
Ami感光部分要正对被拍物体。•
感光部位脏，拿棉签清洁干净。•
由于APP相机部分的最大快门比较低，在室外强光下使用容易过曝。•
• 闪光灯在工作时，如发现异常，应立即关掉电源，查明原因。
• 灯体应避免震动，平时注意表面除尘。
• 灯体稍有发热为正常现象，无特别需要时，勿连续引闪。
• 闪光灯的所有维修概由本厂指定可供原厂配件之维修部负责。
• 1年保修，消耗品如灯管等，不在1年保修范围。
• 经发现，擅自检修此闪光灯的，将取消闪光灯之一年保修期，维修需要收取相关费用。
• 如果本品出现故障或者被水淋湿，在专业人员维修后方可继续使用。
• 如有技术更改，恕不另行通知。
维护保养
- 14 -
- 13 -
故障排除指南 Foreword

Always keep this product dry. Do not use in rain or in damp conditions.
This product contains high-voltage electronic parts. Touching the high-voltage
circuit inside it may result in electric shock. Do not disassemble. Should repairs
become necessary, this product must be sent to an authorized maintenance
center.
Stop using this product if it breaks open due to extrusion, falling or strong hit.
Otherwise, electric shock may occur if you touch the electronic parts inside it.
Do not leave or store the flash unit if the ambient temperature reads over 50°C
(e.g. in automobile).
Do not fire the flash directly into the eyes (especially those of babies) within short
distances. Otherwise visual impairment may occur. When taking pictures for
babies, keep the flash unit at least 1 meter (3.3 feet) away from them. Using
bounce flash to reduce light intensity is also recommended.
Do not use the flash unit in the presence of flammable gases, chemicals and
other similar materials. In certain circumstances, these materials may be
sensitive to the strong light emitting from this flash unit and fire or
electromagnetic interference may result.
Please disconnect the charger after getting fully charged.
Conventions used in this Manual
• This manual is based on the assumption that both the camera and camera
flash’s power switches are powered on.
• Reference page numbers are indicated by “p.**”.
• The following alert symbols are used in this manual:
The Caution symbol indicates a warning to prevent shooting problem.
The Note symbol gives supplemental information.
- 16 -- 15 -
Warning

(1) Flash (2) Clip (3) Paster*2 (4)Type-C USB Cord
Included Accessories
- 18 -
Contents
14
15
18
19
19
20
21
23
24
25
26
26
Foreword
Warning
Name of Parts
Body
Included Accessories
Battery
Power Management
Flash Mode
A Mode: Auto Flash
Ami Connects with Smartphone
APP Instruction
Protection Function
Technical Data
Troubleshooting
Maintenance
- 17 -
Flash
Unit
Optical
Sensor
Magnetic Surface
Reset
Power Switch
Battery Level Indicator
Type-C USB Port
Status Lamp of Phone
Bluetooth Connection/
Flash Ready Indicator
Blue light is blinking:
Bluetooth is disconnected.
Blue light is off:
Bluetooth is connected.
Red light is lit:
the recycle is finished.
Red light is blinking:
it is recycling.
Body Name of Parts

● Features
1. This flash unit uses non-detachable built-in Li-ion polymer battery which has long
runtime.
2. It is reliably safe. The inner circuit is against overcharge, overdischarge,
overcurrent, and short circuit.
3. Take only 1 hour to fully charge the battery by charging through the micro USB port.
● Battery Level Indication
Power Management
*Long press the < > Power Switch for 2 seconds to control the on/off of the flash
unit. Turn off if the flash unit will not be used for an extended period. The flash unit
will enter sleep mode after a certain period (approx. 30 minutes) of idle use.
Note: Short press the ON/OFF button < > can test the flash.
Battery Level Indication
on the OLED display
Blue light
Purple light
Red light
Red light blinks
Meaning
Full battery
Medium battery
Low battery
The battery level is going to be used out immediately.
And the flash will auto power off in 1 minute.
Note: Please recharge the battery as soon as possible
(within 10 days). Then, the flash can be used or be
placed for long period.
This flash has one flash modes: Auto (auto flash: A). The camera and the Ami will
work together to calculate the correct exposure for the subject and the background.
A: Auto Flash Exposure Compensation Setting
Set the flash exposure compensation amount on
the camera interface of the smartphone APP
between±2 steps.
- 20 -- 19 -
+
-
Normal
3 s
10 s
0.0
ISO 160
Battery Flash Mode

- 21 - - 22 -
1. Press the < > Button to turn on the
Ami flash.
2. Search “Godox Ami” in iPhone’s APP
Store and download the APP. Or install
the APP by scanning the QR Code with
your smartphone.
3. Open the APP and choose < >.
Bluetooth
4. Search Bluetooth of devices.
5. Approach the Ami flashes to the
smartphone find the Bluetooths
whose name begins with "Ami"
and choose the one which has
the strongest signal to connect.
6. Back to the APP’s Camera interface after
being successfully matched.
7. When successfully matched, Ami’s
Bluetooth indicator is off while the red
recycle indicator is lighten.
BluetoothCamera
Pending connection device
Other device
Search
12 :0 0
BluetoothCamera
Ami-4C60
Ami-4C60
Ami-4C08
Other device
Clear
12 :0 0
ISO 160
Flash Connects with Smartphone

+
-
Normal
3 s
10 s
0.0
ISO 160
(1)(2)
(3)
(4)
(5)
(6)(7)(8)
1. Open the operation interface of APP.
2. APP
(1) Bluetooth link icon: click to enter the
Bluetooth link interface and choose the
corresponding Bluetooth ID to link Ami flash.
For example, Ami-xxxx (x:0--9,A--F).
When there are several Ami flashes in the
same occasion, approach the Ami flashes
to the smartphone and choose the one which
has the strongest signal to connect.
(2) Shooting button.
(3) Picture view.
(4) ISO: ISO ranges from 25 to 640
(5) Flash exposure compensation: -2 to +2
(6) Front/back camera lens switching icon:
click to switch
(7) Delay setting icon: Normal,
3s and 10s for choice
(8) Flash icon: yellow for reclycling while
orange for flash is ready.
1. Low Battery Protection
• When the battery level is too low, the flash cannot be used and the battery level
indication is blinking.
2. Short Circuit, Overcurrent and Overvoltage Protections
• With built-in hardware to protect circuit. Auto power off will occur when running
into short circuit, overcurrent and overvoltage.
3. Over-Temperature Protection:
• Over-temperature protection: when the intervals between the two flashes is within
10 seconds, the over-temperature protection will be activated after firing 40 times
in full power with approx. two-meter distance. When over-temperature protection
occurs, the blue lamp, not the battery level indicator, will blinks in 1 second's cycle
until the over-temperature protection is relieved. Now if continues to fire flashes,
the recycle time will be longer (max. 8s). And the over-temperature protection will
be relieved if stops firing for 3 minutes. The over-temperature protection will be
activated when the temperature of flash’s internal component is over 80°C and be
relieved below 60°C.
• The over-temperature protection will be activated when firing in full power for 40
times with approx. two-meter shooting distance.
- 24 -- 23 -
APP Instruction Protection Function

Technical Data
Model
Guide No. (1/1 power output)
Flash power
Flash color temperature
Power source
Full power flashes
Whole shutdown current
Recycle time
Battery level indication
Whole sleep current
Dimensions
W x H x D
Net Weight
Wireless Frequency Range
Max. Transmitting Power
Ami
Fn=5.3 (ISO100)
darkroom, 1m
5W
6000K±200K
Lithium Battery (3.8V/610mAh)
500
10UA
3s
√
20mA

60x46x17mm
60g
2402.0MHz-2480.0MHz(Bluetooth wireless)
5dbm (Bluetooth wireless)
If there is a problem, refer to this Troubleshooting Guide.
The flash exposure is underexposed or overexposed.
• There was a highly reflective object (e.g. glass window) in the picture.
• Do not cover the light sensitive part.
• The light sensitive part shall be placed towards the photographed object.
• Clean the dirty places of light sensitive part with cotton swabs.
• As the max. shutter of APP’s camera part is relatively low, overexpose is easy to
be occurred in outdoor light.
Troubleshooting
- Shut down the device immediately should abnormal operation be detected.
- Avoid sudden impacts and the product should be dedusted regularly.
- It is normal for the flash tube to be warm when in use. Avoid continuous flashes if
unnecessary.
- Maintenance of the flash must be performed by our authorized maintenance
department which can provide original accessories.
- This product, except consumables e.g. flash tube, is supported with a one-year
warranty.
- Unauthorized service will void the warranty.
- If the product had failures or was wetted, do not use it until it is repaired by
professionals.
- Changes made to the specifications or designs may not be reflected in this manual.
Maintenance
- 26 -
- 25 -

“ This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help."
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
FCC statement
- 28 -- 27 -
FCC Caution:
Changes or modifications not expressly approved by the part responsible for
compliance could void the user's authority to operate the equipment.
RSS statement:
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas
produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.This equipment complies with Industry Canada radiation exposure
limits set forth for an uncontrolled environment. Cet équipement est conforme à
l'exposition aux rayonnements Industry Canada limites établies pour un
environnement non contrôlé.
