Goji G10WMAG19 User manual

SMARTPHONE
WIRELESS
CAR CHARGER
Instruction Manual
G10WMAG19

Contents
Safety Warnings.............................................................................................. 3
Unpacking....................................................................................................... 4
Product Overview........................................................................................... 5
First Time Setup .............................................................................................. 5
Charging Your Digital Devices....................................................................... 6
Troubleshooting ............................................................................................. 7
Specications.................................................................................................. 7

Safety Warnings
• Do not drop, tamper, disassemble or attempt to repair the unit by yourself.
• Do not immerse it in water or expose it to wet conditions.
• Do not expose it to re or any heat source.
• Do not dispose the unit in your household waste.
• Before charging, please refer to the user’s manual of your specic device
for the manufacture’s required charging amperage and determine the
appropriate charging cable for your device.
• Only use with products designed to be powered via a USB socket.
• Do not use with a damaged USB charging cable as it can cause overheating
and damage to your device.
• For IT equipment use only.
While in use
• Unwind the cable to its full length.
• Never wrap the cable around the unit, or coil it together or leave it tangled.
Doing so may result to product damage and related hazards.
• Make sure that the charger is used between 0 - 35 °C.

4
Thank you for purchasing your new product.
We recommend that you spend some time reading this instruction
manual in order that you fully understand all the operational
features it oers. You will also nd some hints and tips to help you
resolve any issues.
Read all the safety instructions carefully before use and keep this
instruction manual for future reference.
Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose
of it please do so according to local regulations.
The following items are included:
Charging pad
USB cable
Metal plate x 2 Sticker x 2 (spare)
Air vent holder
Car charger
Template card x 19
Dashboard holder
Instruction manual
Instruction
Manual

5
Product Overview
Qi sensor
Dashboard holder
Bolt
USB input
socket
Charging
indicator
First Time Setup
Loosen the bolt. Then insert the air vent holder or dashboard holder into
the bolt. Fasten the bolt to complete the installation.

6
Charging Your Digital Devices
1. Connect the charging pad and the car charger with the USB charging
cable.
2. Plug the car charger to the cigarette lighter socket.
This product only supports mobile device with Qi feature.
3. Attach the metal plate on
a mobile device, choose an
appropriate template card to
align the position.
4. Place the mobile device onto the
charging pad, it will start charging.
Status Charging indicator
Charging Fade in green slowly
Fully
charged
Light up in green
Standby Light will turn off
Error Flash in red
Metal plate
Template card
Mobile device

7
Troubleshooting
If any functional abnormality is encountered, unplug the unit from the
mains socket and reconnect it again. Remove any device from the unit and
replace it again.
Specications
Charging Pad
Input 5V 2A, 9V 1.67A
Output 10W (max.)
Charging Distance 6 mm (max.)
Frequency Band(s) 108 – 150.5 KHz
Max. Radio Frequency Power
Transmitted
0 dBuA/m @10m distance
Dimension (L x W x H) 98.5 x 65.5 x 28 mm
Net Weight 88 g
Car Charger
Input 12V - 24V
Output 5V 3A, 9V 2A, 12V 1.5A
Dimension (L x W x H) 67 x 29 x 28 mm
Net Weight 20 g
Features and specications are subject to change without prior notice.

IB-G10WMAG19-190520V2
DSG Retail Ltd. (co. no. 504877)
1 Portal Way, London, W3 6RS, UK
EU Representative
DSG Retail Ireland Ltd (259460)
3rd Floor Oce Suite
Omni Park SC, Santry, Dublin 9, Republic of Ireland
