GOLDENSEA UV UV-BOX User manual

UV-BOX
USER MANUAL
KEEP THIS MANUAL FOR FUTURE NEEDS

www.goldenseauv.com
1
Thank you for purchasing a GOLDENSEA UV product. You have acquired a
powerful and versatile device. We are confident that you will be satisfied with
our excellent products and service. For your own safety, please read this user
manual carefully before installing and operating the device.
Contents
1. Operation 3
2. Notes 3
3. Warnings 3
4. Product Overview 5
5. Dimensional Drawings 5
6. Troubleshooting Tips 5
7. Features 6
8. Cleaning and Maintenance 6
9. Service 6

www.goldenseauv.com
2
Voltage Input: AC 220-240V~, 50/60Hz; Power: 7W; Product Size: 250x160x70mm
This device is for household use, disinfect small items such as mobile phones, headsets,
masks, office supplies, cosmetic tools, baby supplies, etc.. It shall only be used by adults
who are capable of operating this device by following this user manual, and keep children,
pets and plants away from the device before operating.
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed
including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
a) This equipment is designed for use with germicidal UV radiation sources and UV
radiation can pose a risk of personal injury. Overexposure can result in damage to eyes and
bare skin. To reduce the risk of overexposure, the operator must wear protective clothing
and UV glasses when operating, and make sure the disinfection area is safeguarded during
the entire disinfection process.
b) Maintenance and servicing of this UV generating equipment shall be performed by
professional person. Service personnel must wear appropriate Personal Protective
Equipment (PPE) if the equipment will be in operation during the maintenance or servicing
work. Contact the equipment manufacturer for PPE recommendations and guidance.
c) When replacing lamps, replace them only with the lamps for which the equipment is
marked and intended.
d) The use of accessory not recommended by the manufacturer may cause an unsafe
condition.
e) Do not use this equipment for other than intended use.
f) Keep the device away from children and pets.
g) It should be stored well to avoid accidental damage to the sterilizer and personal injury
after the sterilization is finished.

www.goldenseauv.com
3
1. Operation
1) Open the lid of the box, place your items inside, then
close the lid.
2) Plug-in to power on.
3) Select time setting <5 mins>, <15 mins> or <30
mins> by the Time Setting button < >, the
corresponding indicator light turns on.
4) Press the Start button, audible alarm starts beeping
regularly for 5 seconds. The UV lamp will turn on
after the 5 seconds delay when disinfection time is
set.
5) Once the disinfection process ends, an audible alarm
sounds and the indicator light turns off.
6) Open the lid of the box to ventilate.
* If the lid of the box is opened during disinfection process by misuse, the UV lamp will
automatically turn off to prevent potential injury to the operator. Once the lid is closed
again, the disinfection process will continue.
2. Notes
1. The surface of the lamp should be kept clean.
2. The lamp is fragile. Please handle it with care.
3. According to the latest guideline on the diagnosis and treatment released by the
National Health Commission, the virus is sensitive to ultraviolet (UV) light and heat, so
UV radiation is a quick and effective way of disinfecting against germs and viruses.
3. Warnings
The UV-C wavelength is 253.7nm.
CAUTION: TO REDUCE THE RISK OF FIRE
USE ONLY _ TUV 4W FAM/10X25BOX _
LAMPS
ATTENTION – RISQUE D’INCENDIE
UTILISER UNIQUEMENT LES LAMPES
_ TUV 4W FAM/10X25BOX
Suitable for damp locations
CONVIENT AUX EMPLACEMENTS HUMIDES

www.goldenseauv.com
4
WARNING – RISK OF PERSONAL INJURY
Avertissement – RISQUE DE BLESSURES
CORPORELLES
THIS EQUIPMENT IS DESIGNED FOR
USE WITH GERMICIDAL LAMPS OR UV
SOURCES AND MUST BE INSTALLED
AND USED IN COMPLIANCE WITH
COMPETENT TECHNICAL DIRECTIONS
TO PREVENT THE USER'S EYE AND
BARE SKIN FROM EXPOSURE TO
HARMFUL UV OR OPTICAL RADIATION.
PEOPLE, PETS AND PLANT SHOULD
LEAVE THE AREAS WHEN USING THE
DISINFECTION LIGHT.
CET ÉQUIPEMENT EST CONÇU POUR ÊTRE
UTILISÉ AVEC DES LAMPES GERMICIDALES OU
DES SOURCES UV ET DOIT ÊTRE INSTALLÉ ET
UTILISÉ EN CONFORMITÉ AVEC LES DIRECTIVES
TECHNIQUES COMPÉTENTES POUR EMPÊCHER
L’ŒIL DE L’UTILISATEUR ET LA PEAU NUE DE
L’EXPOSITION À DES RAYONS UV OU OPTIQUE
NOCIFS. LES PERSONNES, LES ANIMAUX DE
COMPAGNIE ET LES PLANTES DEVRAIENT
QUITTER LES ZONES LORS DE L’UTILISATION DE
LA LUMIÈRE DE DÉSINFECTION.
EYE DAMAGE MAY RESULT FROM
DIRECTLY VIEWING THE LIGHT
PRODUCED BY THE LAMP IN THIS
EQUIPMENT. ALWAYS TURN OFF LAMP
BEFORE SERVICING.
LES DOMMAGES OCULAIRES PEUVENT
RÉSULTER DE L’OBSERVATION DIRECTE DE LA
LUMIÈRE PRODUITE PAR LA LAMPE DANS CET
ÉQUIPEMENT. ÉTEIGNEZ TOUJOURS LA LAMPE
AVANT L’ENTRETIEN.
WARNING-POSSIBLE RISK OF INJURY TO EYES AND SKIN
• Hazardous optical radiation may be emitted from the light source. Do
not stare at operating lamp.May be harmful to the eyes.
• UV may be emitted from the light source. Eye or skin irritation may
result from exposure. Use appropriate shielding.
• IR may be emitted from the light source. Do not stare at operating lamp.
Avertissement：risque possible de blessures aux yeux et à la peau
• Un rayonnement optique dangereux peut être émis par la source
lumineuse. Ne pas regarder directement la lampe en fonctionnement.
Peut être très nocif pour les yeux.
• Des ultra-violets (UV) peuvent être émis par la source lumineuse. Une
irritation des yeux ou de la peau peut résulter de l'exposition. Toujours
utiliser des protections appropriées.
• Des infra-rouges (IR) peuvent être émis par la source lumineuse. Ne
pas regarder fixement la lampe en fonctionnement.
UV-C RISK GROUP 3
WARNING: UV-C emitted from this
product.
Avoid eye and skin exposure to
unshielded product.
Follow installation instructions and
user manual.
GROUPE DE RISQUE UV-C 3
AVERTISSEMENT UV-C émis par ce
produit.
Évitez l’exposition des yeux et de la peau
au produit non fumé.
Suivez les instructions d’installation et le
manuel d’utilisation.
SAVE THESE INSTRUCTIONS

www.goldenseauv.com
5
4. Product Overview
5. Dimensional Drawings
!
6. Troubleshooting Tips
8.1 What to do if the device doesn’t work?
1. Ensure the device is plugged into a working wall socket.
2. Ensure the plug is wired correctly and terminal well-connected.
3. If you still have issues with the device, please contact your local dealer or our customer
service for assistance.
8.2 How often should the UV tube be replaced?
1. The UV tube is the core of the product, it should be replaced after 6000 hours of use to
maintain the germicidal efficacy.
1） Power Cable
2） 5 mins - Indicator
3） 15 mins - Indicator
4） 30 mins - Indicator
5） Power Indicator
6） Start Button
7） Time Setting Button

www.goldenseauv.com
6
2. The UV tube is defected if it flashes, please contact your local dealer or our customer
service to order a new UV tube. For replacing the UV tube, please refer to the
instructions in this user manual.
3. After use for a period of time, it is normal to find some black spots on both sides of the
UV tube.
7. Features
Light Source
• Lamp: TUV 4W FAM/10X25BOX (PHILIPS) or
HNS 4W G5(G4T5/OF)PURITEC UV-C Germicidal Low Pressure Lamp (OSRAM)
• Extremely long Life: up to 6,000 H
Features
• Delayed start (5 seconds delayed start)
• Audio alarm
• Visual indicator lights
• 3 disinfection time settings
• UVC wavelength: 253.7nm
Product Type
Household Ultraviolet disinfection light
Weight
Net weight: 0.65 kg
8. Cleaning and Maintenance
1. To ensure the device remains in good condition and does not fail prematurely, regular
maintenance, cleaning and checks are required.
2. For cleaning of the device, please use a lint-free cloth.
3. To avoid damage to the device, never use detergent or solvents.
4. Never spray insecticide towards the device, it can discolor or damaged.
5. Should you need any spare parts, please order genuine parts from your local dealer.
9. Service
For all service needs, please contact your local authorized dealer or GOLDENSEA
customer service. Our contact details are:
Email: [e-mail]
Tel : [phone]
Address: No.109 Haiyong Road, Shiji Town, Panyu Zone, Guangzhou, China. 511450
Errors and omissions for all information given in this user manual are expected.
All information is subject to change without prior notice.
