GOLDENSEA UV UVS4 User manual

DISINFECTION LAMPS

WHAT IS UV AND UVC?
Ultraviolet light is a form of radiation and an invisible part of the electromagnetic spectrum. It has
a wavelength between 100nm-380nm. UVC with a wavelength of 200nm-280nm has proved to
be the most effective disinfectant wavelength in the UV Spectrum. As we all know UV Light is also
found in sunlight.
GOLDENSEA UV uses the ultraviolet spectral wavelength 253.7nm.
This belongs to the short-wave UVC spectrum and is an efficient and
better choice for disinfection!
HOW DOES UVC KILL BACTERIA AND VIRUS?
UVC (in particular253.7nm) destroys the molecular structure of DNA (deoxyribonucleic acid) and
RNA (ribonucleic acid) of microbial (bacteria and virus) cells, causing the death of growth cells
and/or regenerative cells, thus achieving the effect of disinfection
WARNING
Ultraviolet light can cause damage to eyes and skin.
All personnel, animals and plants must leave/ be moved from the site during use.

WHY GOLDENSEA UV?
Viruses, bacteria and mold are ubiquitous and potential health threats. Compared with familiar
disinfection methods using liquid and powder based disinfectants, ultraviolet disinfection lamps
can be widely used, are extremely efficient and most convenient to operate.
-Goldensea UV disinfection lamps are environmental friendly
-The UV-C disinfection is a physical process – no chemicals used, no environmetal footprint left
-Goldensea UV installations are very affordable to install and operate
-The UV-C disinfection results are related to the UV dose - easy to measure and prove
-Goldensea UV disinfection systems are optimized for both mobile application and installations
-The UV-C disinfection adds to your cleaning protocol and significantly mitigates the risk of any
new infections
WHERE TO APPLY GOLDENSEAUV
HOTELS
GYMS
SCHOOLS
THEATERS
FACTORIES
RESTAURANTS
CLINICS
CONSUMERS

WHO IS GOLDEN SEA?
GOLDENSEA UV is manufactured by industry leading hi-tech lighting design and manufacturer
Golden Sea Professional. Our large team of experts ensures quality, safety and performance are of
the highest level. All GOLDENSEA UV’s products are CE, ETL and FCC compliant and listed.
GOLDENSEA UV – SAFETY BY DESIGN
MOTION SENSOR
Lamp automatically shuts
down if motion is detected
AUTO FALL PROTECTION
If the unit senses a larger than 45
degree tilt, power will
automatically turn off to lamp
FLEXIBILITY OF USE
AND INSTALLATION
VISUAL INDICATORS
Red and Green LEDs will light up
solid or flashing to provide a visual
indication of the product’s state
REMOTE CONTROL
THROUGH THE WALL
IMPORTANT ACCESSORIES
INCLUDED
(PROTECTION GLASSES,
WARNING SIGNS)
AUDIO ALARM
A built in alarm will provide audible
tones to alert users to the different
important events and states the
product is in
LONGLIFE, HIGH QUALITY
QUARTZ GLASS TUBE
Allows full transmission of
ultraviolet light
COMPREHENSIVE CUSTOMER SERVICE
TRAININGS AVAILABLE
DELAYED START
Audio and Visual indicators during
delayed start to allow operator to
leave the disinfection area prior to
lamp on
NO OZONE
Safe and harmless – Leave no residue
Note: Only when used in
accordance with manufacturer
instructions
SMART UV LIGHT CALCULATOR AND
FURTHERS RESOURCES AVAILABLE
ONLINE: WWW.GOLDENSEAUV.EU

_ 6
UVS4 UVP36 UV-BOX
Product description 4W desktop ultraviolet disinfection lamp 36W household ultraviolet disinfection lamp 4W portable UV sterilizer
discription on
marketing material GSUV DESKTOP ULTRAVIOLET DISINFECTION LAMP GSUV PORTABLE ULTRAVIOLET DISINFECTION BOX
Product type Small size ultraviolet disinfection lamp for household Portable Ultraviolet disinfection products for household Ultraviolet disinfection box for household items
Applications Small area disinfection: car, closet, shoe cabinet,
washing machine, suitcase, refrigerator, cabinet,
bathroom, etc
Disenfection of smaller rooms (up to 40sqm): kitchen,
bedroom, study, living room, office and other places
disinfection
Disinfection of small items: mobile phones, headsets,
masks, office supplies, cosmetic tools, baby supplies,
etc.
Features 30 seconds delay to lamp on, touch key and remote control, remote control through the wall, motion sensor, buzzer
alarm, 3 options of disinfection time, falling power-off design
Button start,aroma volatilizes, large capacity, multi-
purpose, 3 options of disinfection time
Disinfection duration/
Disinfection area 15 mins/0.55m², 30 mins/1m², 60 mins/2m² 15 mins/5m²,30 mins/10m²,60 mins/20m² 5 mins/0.2m², 10 mins/0.4m², 15 mins/0.6m²
Disinfection height
range No 0-4m 0-0.038m
IP Rating IP20
SOFTWARE
Child safety lock Yes No
Software upgrade No
Lamp on delay 30 seconds
Motion detection Lamp automatically doused once detecting motion Lamp turns off automatically when opening the lid
Alarm Buzzer Buzzer for 30 seconds at startup Buzzer for 5 seconds at startup
Tilt protection Luminaire immediately turns off when tilted at 45 degrees or more No
Disinfection timing
options 3 options
CONTROL
Remote control Yes No
Switch/panel type Touch keys Button
Control Touch key & remote control Mechanical button
ELECTRICAL
PSU Electronic ballast
Power consumption 5W (Measured) 45W (Measured) 5W(Measured)
Voltage 120V/60HZ, 220-240V /50HZ
Power factor >0.45
Current Max 30mA Max 400mA Max 30mA
Battery operation No
CONSUMER PRODUCTS

_ 7
UVS4 UVP36 UV-BOX
DIMENSIONS & WEIGHT
Product dimensions Ø95 x H232 mm Ø165 x H453.75 mm 250 x 160 x 70.3 mm
Inner dimension N/A N/A 215 x 105 x 38 mm
Packing dimensions
(Carton) N/A N/A N/A
Net weight 0.38 KG 0.8 KG 0.63 KG
Gross Weight (Carton) N/A N/A N/A
Dimensional drawing
OTHERS
Tube material -
Housing Material Anti-UV,ABS material
Compliance CE ETL FCC
Mounting Desktop
Accessory No
Power cord 1.8 m
Instructions for use 1. Press the touch key to start up
2. Leave the area immediately after the disinfection time is selected. The disinfection will start automatically after 30
seconds. The disinfection times available are 15 minutes, 30 minutes and 60 minutes
3. Please remove the power cord after disinfection to avoid accidentally touching the switch again
Remote control:
1. Press the power switch button
2. Select the desired disinfection time
3. Press the power switch again and the disinfection will start after a 30 second delay
1.Open the top cover and insert the items that need to be
disinfected. Close the top cover.
2. Press and hold the touch key to turn on the device,
press the disinfection key to operate, and press and
hold the disinfection key to turn off the device after
disinfection.
3. After the selected set time finish, it turns off the
infection automatically.
Cautions 1. Ultraviolet disinfection lamp products emitting UVC at 253.7nm must only be used in an environment with no living
things present (humans, animals, plants). Ultraviolet light may cause skin redness, itching, peeling, and eye conjunctive
damage caused by electro-optical ophthalmitis. Never look directly at the lamp without suitable eye protection when
it is powered on and emitting light. It is essential that all people and pets leave the room before the lamp is turned on
and only re-enter the room after the lamp has been turned off/ has finished its disinfection cycle.
2. Ultraviolet has a degrading effect on many materials including plastics, paper and cloth. Exposure to irradiation over
long periods of time may cause the surface of the irradiated objects to change color and or become more brittle. Never
use ultraviolet sterilization lamp products emitting direct irradiation on expensive clothing, ornaments, calligraphy,
painting and other valuables.
3. The surface of the lamp tube should be kept clean when using the UV disinfection lamp. It is recommended to clean
the lamp tube regularly when not in use (usually every 2 weeks). When cleaning, please use a soft clean cotton cloth
with a small amount of alcohol to wipe the lamp tube surface, remove the dust and oil.
4. A side effect of disinfection can be an abnormal smell, similar to that of the sun drying wet bedding, we recommend
that spaces are well ventilated for 10-15 minutes following disinfection.
5. UV lamps should be properly protected after disinfection and placed out of reach of children, in a safe place.
6. Impact and strong vibration may cause the lamp tube to break. Should the lamp tube break, immediately turn off the
power supply and dispose of the lamp, wearing protective gloves and according to your local toxic and harmful garbage
rules. Should a lamp break, immediately open the windows for 10-15 minutes of ventilation.
7. Never disinfect areas with inflammable or explosive items as you may otherwise cause burning or explosion.
8. If the lamp tube needs to be replaced, replace only with the original brand of lamp tube and complete the operation
according to the procedures in the user manual.
1. The disinfection function will not start until the upper
cover is closed, and the cover should not be opened
during disinfection.
2. Valuables are not recommended to be put into the
disinfection box, the surface of which will have the risk
of fading.
3. Inflammable and explosive articles are not allowed to
be put into the disinfection box.
CONSUMER PRODUCTS

_ 8
UVL72 UVL150 UVL220
Product description 2- tube ultraviolet disinfection light (72W) 4- tube ultraviolet disinfection light (144W) 6- tube ultraviolet disinfection light (216W)
Description on
marketing material GSUV ULTRAVIOLET DISINFECTION LAMP FOR COMMERCIAL ENVIRONMENTS
Product type Industrial Ultraviolet disinfection light
Applications Disinfection of small to medium size rooms
(up to 80 sqm): classroom, hotel, office, factory, public
washroom etc.
Disinfection of medium size rooms (up to 160 sqm):
hotel, office, classroom and other medium - sized places
Disinfection of medium to large size rooms: hotel, office,
classroom, workshop and other medium to large - sized
places
Features 2 mins delay to light up, mechanical switch,
touch key and remote control, remote control through
the wall, motion sensor, buzzer alarm, 3 options of
disinfection time
2 mins delay to light up, mechanical switch and remote control, remote control through the wall, motion sensor,
buzzer alarm, 3 options of disinfection time
Disinfection duration/
Disinfection area 30 mins/20m², 60 mins/40m², 120 mins/80m² 30 mins/40m², 60 mins/80m², 120 mins/160m² 30 mins/60m², 60 mins/120m², 120 mins/240m²
Disinfection height
range 0-4m
IP Rating IP20
SOFTWARE
Child safety lock No
Software upgrade No
Lamp on delay 2 mins delay to boot up
Motion detection Lamp immediately doused once detecting motion
Alarm Buzzer Buzzer for 2 mins at startup
Tilt protection No
Disinfection timing
options 3 options
CONTROL
Remote control Yes
Switch/panel type Mechanical switch and touch key
Control Mechanical switch, key switch and remote control
ELECTRICAL
PSU Electronic ballast
Power consumption 90W (estimated) 180W (estimated) 270W (estimated)
Voltage 100V-240V, 50-60HZ
Power factor >0.9
Current MAX 1A MAX 2A MAX 3A
Battery operation No
INDUSTRIAL PRODUCTS

_ 9
UVL72 UVL150 UVL220
DIMENSIONS & WEIGHT
Product dimensions 479 x 76 x 200mm 479.3 x 76 x 400mm TBA
Inner dimension N/A N/A N/A
Packing dimensions
(Carton) N/A N/A N/A
Net weight 2.65 KG 3.8 KG TBA
Gross Weight (Carton) N/A N/A N/A
Dimensional drawing
OTHERS
Tube material -
Housing Material Aluminium alloy
Compliance CE ETL FCC
Mounting Surface mount or Wall mount
Accessory Reflector
Power cord 1.8m
Instructions for use Usage:
1. Set the mechanical switch to the ON position, then press the key to start the luminaire
2. Leave the area immediately after the disinfection time is selected. The disinfection will start automatically after 2 minutes. The disinfection times available are 30 minutes, 60
minutes and 120 minutes
3. Please turn off the mechanical switch after disinfection to avoid accidentally activating the luminaire again
Remote control:
1. Set the mechanical switch to the ON position, then press the button on the remote control to start the luminaire
2. Choose a disinfection time and the disinfection will begin after a 2 minute delay
Cautions 1. Ultraviolet disinfection lamp products emitting UV-C at 253.7nm must only be used in an environment with no living things present (humans, animals, plants)
Ultraviolet light may cause skin redness, itching, peeling, and eye conjunctive damage caused by electro-optical ophthalmitis. Never look directly at the lamp without suitable eye
protection when it is powered on and emitting light. It is essential that all people and pets leave the room before the lamp is turned on and only re-enter the room after the lamp
has been turned off/ has finished its disinfection cycle
2. Ultraviolet has a degrading effect on many materials including plastics, paper and cloth. Exposure to irradiation over long periods of time may cause the surface of the irradiated
objects to change color and or become more brittle. Never use ultraviolet sterilization lamp products emitting direct irradiation on expensive clothing, ornaments, calligraphy,
painting and other valuables
3. The surface of the lamp tube should be kept clean when using the UV disinfection lamp. It is recommended to clean the lamp tube regularly when not in use (usually every 2
weeks). When cleaning, please use a soft clean cotton cloth with a small amount of alcohol to wipe the lamp tube surface, remove the dust and oil
4. A side effect of disinfection can be an abnormal smell, similar to that of the sun drying wet bedding, we recommend that spaces are well ventilated for 10-15 minutes following
disinfection
5.UV lamps should be properly protected after disinfection and placed out of reach of children, in a safe place
6. Impact and strong vibration may cause the lamp tube to break. Should the lamp tube break, immediately turn off the power supply and dispose of the lamp, wearing protective
gloves and according to your local toxic and harmful garbage rules. Should a lamp break, immediately open the windows for 10-15 minutes of ventilation
7. Never disinfect areas with inflammable or explosive items as you may otherwise cause burning or explosion
8. If the lamp tube needs to be replaced, replace only with the original brand of lamp tube and complete the operation according to the procedures in the user manual
INDUSTRIAL PRODUCTS

_ 10
UVT72 UVM900 UVM216
Product description T8x2- tube ultraviolet disinfection light (72W) Large moveable ultraviolet disinfection light Large moveable ultraviolet disinfection light
Description on
marketing material
GSUV ULTRAVIOLET DISINFECTION LAMP FOR
COMMERCIAL ENVIRONMENTS GSUV DISINFECTION UNIT FOR LARGE SPACES GSUV DISINFECTION UNIT FOR MEDIUM SPACES
Product type Industrial Ultraviolet disinfection light Industrial Ultraviolet disinfection light Industrial Ultraviolet disinfection light
Applications Disinfection of medium to large size rooms (up to
120 sqm): hotel,office, workshops,classroom, small
theater,etc.
Disenfection of large spaces (up to 1440 sqm): hotels,
schools, studios, large theater, gymnasium, workshop
and other large public places.
Disenfection of large spaces (up to 360 sqm): hotels,
schools, studios, small theater, gymnasium, workshop
and other large public places.
Features 2 mins delay to light up, mechanical switch and remote
control, remote control through the wall, motion sensor,
buzzer alarm, 3 options of disinfection time
3 mins delay to light up, mechanical switch and remote control, remote control through the wall, radar sensor, buzzer
alarm, 3 options of disinfection time, falling power-off design
Disinfection duration/
Disinfection area 30 mins/20m², 60 mins/40m², 120 mins/80m² 30 mins/240m², 60 mins/480m², 120 mins/960m² 30 mins/60m², 60 mins/120m², 120 mins/240m²
Disinfection height
range 0-4m 0-8m 0-4m
IP Rating IP20 IP20 IP20
SOFTWARE
Child safety lock No
Software upgrade No
Lamp on delay 2 mins delay to boot up 3 mins delay to boot up
Motion detection Lamp immediately doused once detecting motion
Alarm Buzzer Buzzer for 2 mins at startup Buzzer for 3 mins at startup
Tilt protection No Luminaire immediately turns off when tilted at 45 degrees or more
Disinfection timing
options 3 options
CONTROL
Remote control Yes
Switch/panel type Mechanical switch and touch key
Control Mechanical switch, key switch and remote control
ELECTRICAL
PSU Electronic ballast
Power consumption 90W (Estimated) 1080W (Estimated) 270W (Estimated)
Voltage 100V-240V, 50/60Hz
Power factor >0.9
Current MAX 1A MAX 12A MAX 3A
Battery operation No
INDUSTRIAL PRODUCTS

_ 11
UVT72 UVM900 UVM216
DIMENSIONS & WEIGHT
Product dimensions 1266 x 76 x 200 mm 740 x 608 x 1353 mm
Inner dimension N/A N/A N/A
Packing dimensions
(Carton) N/A N/A N/A
Net weight N/A N/A N/A
Gross Weight (Carton) N/A N/A N/A
Dimensional drawing
OTHERS
Tube material -
Housing Material Aluminium alloy
Compliance CE ETL FCC
Mounting Surface mount or Wall mount Mobile placement Mobile placement
Accessory Reflector No Reflector
Power cord 1.8m 1.8m 1.8m
Instructions for use 1. Set the mechanical switch to the on position, then
press the key to start the luminaire
2. Leave the area immediately after the disinfection
time is selected. The disinfection will start automatically
after 2 minutes. The disinfection times available are 30
minutes, 60 minutes and 120 minutes
3. Please turn off the mechanical switch after disinfection
to avoid accidentallyactivating the luminaire again
Remote control:
1. Set the mechanical switch to the on position, then press
the button on the remote control to start the luminaire
2. Choose a disinfection time and the disinfection will
begin after a 2 minute delay.
1. Set the mechanical switch to the on position, then press the key to start the luminaire;
2. Leave the area immediately after the disinfection time is selected. The disinfection will start automatically after 3
minutes. The disinfection times available are 30 minutes, 60 minutes and 120 minutes;
3. Please turn off the mechanical switch after disinfection to avoid accidentally activating the luminaire again.
Remote control:
1. Set the mechanical switch to the on position, then press the button on the remote control to start the luminaire
2. Choose a disinfection time and the disinfection will begin after a 3 minute delay.
Cautions 1. Ultraviolet disinfection lamp products emitting UV-C at 253.7nm must only be used in an environment with no living things present (humans, animals, plants). Ultraviolet light
may cause skin redness, itching, peeling, and eye conjunctive damage caused by electro-optical ophthalmitis. Never look directly at the lamp without suitable eye protection when
it is powered on and emitting light. It is essential that all people and pets leave the room before the lamp is turned on and only re-enter the room after the lamp has been turned
off/ has finished its disinfection cycle.
2. Ultraviolet has a degrading effect on many materials including plastics, paper and cloth. Exposure to irradiation over long periods of time may cause the surface of the irradiated
objects to change color and or become more brittle. Never use ultraviolet sterilization lamp products emitting direct irradiation on expensive clothing, ornaments, calligraphy,
painting and other valuables.
3. The surface of the lamp tube should be kept clean when using the UV disinfection lamp. It is recommended to clean the lamp tube regularly when not in use (usually every 2
weeks). When cleaning, please use a soft clean cotton cloth with a small amount of alcohol to wipe the lamp tube surface, remove the dust and oil.
4. A side effect of disinfection can be an abnormal smell, similar to that of the sun drying wet bedding, we recommend that spaces are well ventilated for 10-15 minutes following
disinfection.
5.UV lamps should be properly protected after disinfection and placed out of reach of children, in a safe place.
6. Impact and strong vibration may cause the lamp tube to break. Should the lamp tube break, immediately turn off the power supply and dispose of the lamp, wearing protective
gloves and according to your local toxic and harmful garbage rules. Should a lamp break, immediately open the windows for 10-15 minutes of ventilation;
7. Never disinfect areas with inflammable or explosive items as you may otherwise cause burning or explosion.
8. If the lamp tube needs to be replaced, replace only with the original brand of lamp tube and complete the operation according to the procedures in the user manual.
INDUSTRIAL PRODUCTS

_ 12
UV-VRV UV4C
Product description High power A/C ultraviolet disinfection lightd Ultraviolet disinfection cabinet
Description on
marketing material GSUV DISINFECTION CABINET
Product type Industrial ultraviolet disinfection light Ultraviolet disinfection cabinet for household
Applications Disinfection of daily use items: mobile phone, headset, mask, office stationery, makeup
tools, and other small items
Features One key to start, 3 options of disinfection time, can disinfect multiple items
Disinfection duration/
Disinfection area 5mins/0.3m², 10mins/0.6m², 30mins/1.8m²
Disinfection height
range No
IP Rating IP20
SOFTWARE
Child safety lock No
Software upgrade No
Lamp on delay No
Motion detection Lamp immediately doused once opening the cabinet
Alarm Buzzer No
Tilt protection No
Disinfection timing
options 3 options
CONTROL
Remote control No
Switch/panel type Touch keys
Control Touch keys
ELECTRICAL
PSU Electronic ballast
Power consumption 12W (Estimated)
Voltage 100-120/60HZ, 220-240V /50HZ
Power factor >0.45
Current Max 100mA
Battery operation No
INDUSTRIAL PRODUCTS

_ 13
UV-VRV UV4C
DIMENSIONS & WEIGHT
Product dimensions 1300x240x50mm 395 x 430 x 620 mm
Inner dimension 215 x 105 x 38mm
Packing dimensions
(Carton) N/A
Net weight 10.8 KG
Gross Weight (Carton) 13.8 KG
Dimensional drawing
OTHERS
Tube material Quartz glass
Housing Material Aluminium, Anti-UV Organic glass
Compliance CE ETL FCC
Mounting Ceiling Desktop
Accessory No No
Power cord 1.8m 1.8m
Instructions for use 1. Open the cabinet door and put the items in the cabinet and close the door.
2. Hold the power button to start the machine, press the time button to select the
disinfection time, and press the power button to open the disinfection.
3. When you choose the time, you will hear a sharp warning sound
Cautions 1. The disinfection function can only be activated after the cabinet door is closed.
2. Valuables are not recommended to be put into the cabinet. Items may be discolored.
3. Inflammable and explosive articles are prohibited to be put into the disinfection
cabinet.
INDUSTRIAL PRODUCTS
