Goldmund MIMESIS 29.4M MILLENNIUM EDITION User manual

GOLDMUND MIMESIS 29.4M
MILLENNIUM EDITION
POWER AMPLIFIER

GOLDMUND MIMESIS 29.4
MILLENNIUM EDITION
POWER AMPLIFIER
USER MANUAL
CONGRATULATIONS
Thank you for purchasing the Goldmund Mimesis 29.4M.
You have acquired the best Analogue Power Amplifier ever made for professional
and domestic uses. Please take some time to read this manual. It may provide you
with useful information to make your pleasure of listening to the Mimesis 29.4M even
higher.
ATTENTION :
No connection or manipulation must be done before reading those instructions.
Damage of the amplifier may result if the following instructions are not consciously
understood and applied.

3
1 - UNPACKING
You will find in the GOLDMUND MIMESIS 29.4M box :
- The amplifier
- The power cord
- This manual
- Spare fuses.
Please keep the packaging in case you need to transport the amplifier at a later date
or if you have to send it for maintenance.
2 – CHOICE OF AMPLIFIER LOCATION AND COOLING
The GOLDMUND MIMESIS 29.4M amplifier, as all high quality amplifiers generates
a large amount of heat if driven at high level
It is mandatory to allow a proper cooling of the heat sinks. Avoid any location which
is not properly vented and avoid to put on top of it equipment sensitive to
temperature.
Due to its weight, and to maximize the effect of the built-in "Mechanical Grounding"
construction, the MIMESIS 29.4M is better located on the floor. But other very strong
supports can also be used, if they offer a very rigid transmission with the floor.
The MIMESIS 29.4M is built on four very hard conical feet to insure proper vibration
transmission to the amplifier support in order to evacuate all detrimental vibrations
inside the amplifier, following the famous GOLDMUND "Mechanical Grounding"
principle.
Depending on the flatness of the surface where the amplifier will be located, you will
choose to screw in the four round flat feet of the amplifier to allow full contact of the
points with the support.

4
3 – LINE VOLTAGE ADJUSTMENT
A voltage selection is provided inside the amplifier.
If your line voltage is not adapted to the voltage indicated on the serial plate of the
amplifier, please consult your local GOLDMUND dealer for internal adjustment.
ATTENTION : On the 220V position, the GOLDMUND MIMESIS 29.4N amplifier will
function properly for main line voltage in between 200V and 240V. On the 110V
position, the main line must deliver between 105 and 125V. If your main line is
usually out of these tolerances, please consult your GOLDMUND dealer.
Please check the value of the main line fuse. This fuse is located on the back panel
of the amplifier, above the two power cord receptacles.
Use a 5A delayed fuse for 220V and a 8A delayed fuse for 110V.
4 - CONNECTIONS
Connect the power cord to the back of the amplifier and plug it in the nearest wall
plug. Use only a 3 lugs grounded plug, for safety reasons. To get the best sound of
the amplifier, avoid any multiple plug or extension cord.
Connect the interconnects between the preamp and each power amp. You may
either use the RCA female socket or the XLR. The XLR socket, especially useful in
professional installations, is wired as follows :
1 - Grounding, Shielding.
2 - Hot.
3 - Cold.
Attention : if you want to use a symmetrical 4 wire cable, always maintain the
ground/earth switch to "Link" or you may destroy your amplifier.
Connect the speaker cable to one of the red and black terminals in the back of the
amplifier, or, if you use a Goldmund High Definition speaker cable, you can connect
directly the speaker cable to one of the coaxial plugs on the back panel of the
amplifier, bypassing the amplifier adapter module of the speaker cable.
The 3 separate outputs (both 5 way post and coaxial) are connected internally in
parallel. They are provided to facilitate the connection in bi-wiring or tri-wiring
systems.
You may notice that the ground of the input plug and the black speaker terminal are
the same polarity. The amplifier is non-inverting in phase.

5
5 – AMPLIFIER CONTROLS
Normal Operation
On the front plate of the GOLDMUND MIMESIS 29.4M amplifier you will find only two
POWER keys.
In the Standard Mode, the two POWER keys have to be activated simultaneously to
power the amp on.
This security feature is provided to avoid any fortuitous power on or power off.
When the two keys are pressed simultaneously, the amp switches on in "Muted"
mode and the center yellow led lights on showing the amp is powered on, but input is
muted.
By pressing once the right key, the amplifier becomes immediately operative, and the
green led shows it is.
By pressing once the right key again, the amplifier returns to "Muted" state.
The amp may be powered off by pressing simultaneously the two POWER keys at
any time.
Auto-Power Operation
When the power amp is powered off, pressing the right key provide additional mode
adjustments.
By pressing it twice, you reach the Auto-Power Mode adjustment. You may now
activate the Auto-Power Mode On or Off by pressing the left key.
In Auto-Power mode, the amp is turned on automatically when receiving an audio
signal. It also turns off automatically after few minutes if no signal is received during
this period. In this mode, the amp turns on automatically to ready, without going in
Muted first.
This mode is useful when several amplifiers are used together in a multi-amp system
or when the power amplifiers are not easily accessible.
When the amp is in Auto-Power mode and is operative, it may be muted by pressing
the right key, as in the normal mode.
Auto-Ranking Mode
When several amplifiers are used in a system and they are used in Auto-Power
mode, they risk to all start together when a signal appears, creating a large current
surge that may be dangerous for the Home breakers.
To avoid this big surge, the Goldmund amplifier provides a "ranking" adjustment
which gives each amp of the system a "rank" in the Auto-Power ON mode.
The rank is adjustable from 1 to 8.

6
When only one amp is used, leave the ranking to 1.
If you use several amplifiers, rank them from 1 to their number.
When they will be powered ON in Auto-Power mode by receiving a signal, they will
start in the order of the rank they have, each after the previous one (few 100 millisec
later), avoiding the power surges to add-up at the breaker level.
To adjust the rank of each amp, when it is powered off, press the right key until the
ONRank adjustment is displayed. Change the rank by pressing the left key.
Other display
An input sensitivity adjustment is provided on the back panel of the amplifier.
To read the attenuation introduced by this adjustment (in dB), press once the right
front panel key. The attenuation will be displayed for 10 seconds.
When pressed twice, the front panel right key will display on front panel the output
circuit temperature, again for 10 seconds.
6 – SOUND QUALITY OPTIMIZATION
- Warm-up sonic effect.
If the power amplifier has been powered off for some time, the optimum sound
quality is only reached after several minutes. The critical circuits have to warm up to
around +55 degrees Celsius (+131 degrees Fahrenheit). When the amplifier has
been used recently, the optimum is reached after only 10 to 15 minutes.
- Speaker polarity.
Even if you have a phase inverter on your preamplifier (as on the GOLDMUND
MIMESIS 2 or MIMESIS 22), and even if you have carefully selected the proper line
phase (see in next paragraph), there is a possibility to again increase the sonic
quality of your speakers by reverting the polarity of the speaker cable amp
termination. But since the line phase and the speaker polarity interfere to each other,
you have to experiment carefully all the combinations before picking the right one.
If your preamp has an absolute phase inverter, this will interfere too. If it has not,
don't forget the result will depend of the source, most of the record and CD being
recorded without care for the absolute phase. Be patient…
- Main line phase inversion.
To select the proper phase, you have to select, by trying, one of the two power cord
position, using a plug adapter.

7
We recommend that you proceed carefully to try this. You must do it in combination
with the speaker polarity and/or with absolute phase switching to be sure of the
result.
- The GOLDMUND exclusive "Mechanical grounding".
In the GOLDMUND MIMESIS 29.4 amplifier, GOLDMUND has, more than in any
other of its components, fully implemented an optimized vibration evacuation path.
This is called by GOLDMUND : "Mechanical Grounding". The perfect adjustment of
this evacuation provides the MIMESIS 29.4 with an extraordinary dynamic capability
and transparency, especially on low efficiency speakers.
To get all the benefits of this design, the MIMESIS 29.4 must be located on a very
rigid support, or better directly on the floor, to be directly coupled with the building
rigid construction. Try various location until you find the most rigid one. Avoid any
decoupling material, carpet especially, even between the furniture and the floor. Use
the four pin-point feet to couple the amplifier to the supporting furniture or to the
floor.
With a very top system, the sonic improvement when the proper grounding is found
is obvious and worth the try.
7 – SAFETY FEATURES
The GOLDMUND MIMESIS 29.4 amplifier provides sophisticated features to protect
the amplifier and the speakers against all mishandle or component failure. However
precautions must be taken to avoid problems with a very high power amplifier.
- Protection against DC.
The MIMESIS 29.4 is a DC-coupled amplifier. If the associated preamplifier is badly
designed or defective (often true for the tube preamps), the speakers could be
damaged.
In such a case, the DC protection circuit of the MIMESIS 29.4 will automatically turn
off the amplifier. This detection circuit is totally immune to any sonic effect.
To indicate that the amplifier has been turned off by the protection circuit, a red led
will be displayed on the front panel.
When the source of DC offset is suppressed, turn ON the amplifier again.
- Protection against HF oscillations.
In the same way, the speaker must be protected against a large amount of high
frequency oscillation if present to avoid any danger for the tweeters, even if these
frequencies remain unnoticed.
The amplifier is by itself extremely stable. However some mishandling must be
avoided in order to avoid any oscillation :

8
•Never plug an input cable on a power amp when it is turned on.
•Be careful to use only very high quality interconnects. If the ground connection
become loose, there is a big danger of oscillation. Warranty is voided if this
occurs.
•Never run the input and output (speaker) cables parallel.
If an oscillation of too high level is detected, the amplifier will be turned off
automatically. You will have to suppress the source of oscillation and turn it ON again
if the protection is activated.
- Overheating protection.
If for any reason (malfunction, too high level, too low load impedance) the
temperature of the amplifier may reach a dangerous level and the MIMESIS 29.4
could be damaged.
To avoid this type of damage, if the temperature rises too high, a protection circuit
switches the amp off automatically. A red front panel light indicates that the amplifier
has been turned off by the protection circuit.
If such a protection occurs, let the amplifier cool for some time. It is strongly
recommended to try to detect why the temperature has reached such a level before
operating the amp again.
- Protection against short-circuits.
If one output is short-circuited by accident and the current becomes too high, the AC
fuse may blow.
To replace the defective fuse, switch the amplifier off first. Then open the small
drawer located on the AC cord receptacle. The fuses are located inside. Change the
defective fuse.
Then switch the power on if the short-circuit has been detected and removed.
To avoid the fuses to blow, avoid to short-circuit the output terminals accidentally.
Always switch OFF the amp before trying any manipulation of the speaker cables.
There is no risk to leave the speaker terminals unconnected when the amp is on.
8 - MAINTENANCE
The GOLDMUND MIMESIS 29.4 amplifier usually requires no maintenance. For
audio purists who want to keep their amp sounding as new, we only recommend that
after a year or two, you have a technician or an official GOLDMUND representative
readjust the DC offset. This very simple operation takes only two minutes and will
give you the safety of long years of unmatched sound quality.
To clean your MIMESIS use only a soft cloth slightly wet. Always turn the power off
before cleaning your amplifier.

9
TECHNICAL DATA :
POWER
- Nominal power : 350 W RMS (2 - 8 Ohms).
175 W RMS (1 - 16 Ohms).
- Maximum instantaneous power : 500 W RMS (8 Ohms).
- Maximum voltage swing : 84 V peak.
- Maximum current swing : 28 A peak.
FREQUENCY RESPONSE
These figures are valid for the circuit alone, at any level between 0 and nominal
power.
- +/- 0.1 dB, 0 - 300 kHz, +/- 1 dB, 0 - 800 kHz.
- +/- 3 dB, 0 - 2.5 MHz.
INPUT SENSITIVITY
- Nominal level : 1.45 V RMS.
- Voltage Gain : 29, adjustable input sensitivity on the back panel.
- Input impedance : 10-52 kOhms.
GROUP DELAY
- Propagation delay < 100 ns stable with frequency from DC to 200 kHz.
DISTORTION
Figures valid for all levels from 0 to 40 V / 8 Ohms :
- Dynamic : TID < 0.01 % (- 80 dB).
- Static : THD < 0.01 % (- 80 dB).
SPEED
- Slew rate : > 200 V/us
- Rise time : < 300 ns.
CROSSTALK
- Separation : > 100 dB between channels. Isolated ground.
NOISE
- Signal-to noise ratio : > 115 dB (0.01 Hz - 1 Mhz).
- Weighted ASA A : > 130 dB.
OPERATING TEMPERATURE
- Room temperature : -30 to +40 degrees Celsius
(-22 to +104 degrees Fahrenheit).
- Internal temperature : +45 to +65 degrees Celsius
(+113 to +149 degrees Fahrenheit).

10
POWER SUPPLY
- Nominal line voltage : 117, 234 V (switchable).
- Input voltage range : +/- 10 %.
- Maximum power consumption : 2000 W.
- Power used in standby : 120 W.
- 8 toroidal transformers, 4 separated power supply.
GROUNDING
- Separated ground and earth.
- Floating chassis connected to mains earth.
- Possible link for optionally connecting both.
SAFETY FEATURES
- AC voltage fuse : min 10 A slow-blow for 220 V / 16 A slow-blow for 110 V.
FRONT PANEL CONTROLS
- 2 control keys.
- Display to show Input attenuation or inside temperature.
- Led display for temperature, DC offset or HF protection.
- Led display for Power on, operating mode.
- Led display for Power on, standby mode.
REAR PANEL CONNECTORS AND CONTROLS
- Power cord: universal socket 3 lugs.
- Main fuse (10A slow-blow 110V / 16 A slow-blow 220 V).
- Green-yellow AC earth binding post.
- Black signal ground binding post.
- Output speaker : 3 X 5 ways post in parallel.
- Output speaker 3 x Coaxial connectors in parallel.
- Input connector RCA.
- Input connector XLR for balanced input.
SIZE AND WEIGHT
- 44 cm (17") W x 51 cm (20") D x 23.5 cm (9.25") H.
- Weight : 75 kg net.
WARRANTY
- 3 years parts and labor.
