GoMax Electronics CV-505Q User manual

CV-505Q
HDMI 2.1 Audio Extractor & Embedder
User Manual
rev: 231226
Made in Taiwan
TABLE OF CONTENTS
INTRODUCTION................................................................................................................1
PACKAGE CONTENTS......................................................................................................1
FEATURES ........................................................................................................................2
SPECIFICATIONS..............................................................................................................3
PANEL DESCRIPTIONS....................................................................................................4
CONNECTION DIAGRAM..................................................................................................5
WARRANTY.......................................................................................................................6

-1-
INTRODUCTION
The CV-505Q HDMI 2.1 Audio Extractor & Embedder is an exceptional device that provides a
practical solution for audio compatibility issues with HDMI 2.1 devices. This device can extract
high-quality stereo analog and digital S/PDIF (Toslink) audio from incoming HDMI signals without
losing any active audio channels. It is particularly useful for audio systems that only support stereo
sound, such as TVs and stereo speakers.
Moreover, the CV-505Q can insert external stereo analog audio or digital S/PDIF (Toslink) audio
into the outgoing HDMI signal. This capability allows users to incorporate external audio sources into
their HDMI signal, which is beneficial for devices that do not have an HDMI output but require audio
support.
The CV-505Q's ability to co-work with any HDMI matrix on the market is another unique feature.
This allows different audio capacity HDMI-equipped devices to work with multi-channel HDMI audio
insertion simultaneously. The CV-505Q is a versatile device that can operate seamlessly with a broad
range of HDMI devices. Overall, the CV-505Q is a remarkable device that can significantly enhance the
audio experience of HDMI devices, making it a valuable addition to any home theater or audio system.
PACKAGE CONTENTS
1x CV-505Q
1x 5V power adapter
1x User Manual
-2-
FEATURES
HDMI2.1 compliant
Supports up to 8K60 4:2:0 10bits, 8K30 4:4:4 & 4K2K 120Hz
Supports HDR1, which is 4K2K@60 10bits/12bits2 & Dolby Vision
Supports VRR(Variable Refresh Rate) & ALLM(Auto Low Latency Mode)*
HDCP 2.3 and 1.4 compliant
Wide frequency range: 25MHz~1188MHz
Video bandwidth: 48G
Supports resolution downscaling from 8K to 4K & 4K to 1080P.
Supports resolution upscaling from 4K to 8K & 1080P to 4K.
Supports audio extraction via stereo & Toslink
Supports audio insertion via stereo & Toslink
Supports CEC & ARC bypass
Supports ARC audio extraction via Toslink
HDMI Audio Format: PCM2/5.1/7.1, Dolby 5.1/7.1, DTS 5.1/7.1
Optical Audio Format: PCM2, Dolby 5.1



1. HDR = High Dynamic Range.
2. The video bandwidth of 4K2K@60 4:2:0 10bits (HDR) is 384 MHz, and the 4K2K@60 4:4:4
8bits is 594MHz.
* Do NOT recommend using scale in VRR mode.
** If the output does not have image, please press “reset button” about 1-2 seconds to
reset the device.

-3-
SPECIFICATIONS
Model Name
CV-505Q
Technical
Role of usage
HDMII 2.1 Audio Extractor & Embedder
HDMI compliance
HDMI 2.1
HDCP compliance
HDCP 2.3 / 1.4
Video bandwidth
Up to FRL 5 (48G)
Video support
Up to 8K60 4:2:0 10bits, 8K30 4:4:4 & 4K2K 120Hz
Audio support
HDMI Audio Format: PCM2/5.1/7.1, Dolby 5.1/7.1, DTS 5.1/7.1
Optical Audio Format: PCM2, Dolby 5.1
ESD protection
Human body model — ±15kV [air-gap discharge] &
±8kV [contact discharge]
PCB stack-up
4-layer board [impedance control — differential 100; single 50]
CEC Channel
Bypass
Input
1x HDMI + 1x 3.5mm phone jack + 1x Toslink
Output
1x HDMI + 1x 3.5mm phone jack + 1x Toslink
HDMI connector
Type A [19-pin female]
3.5mm connector
Stereo
Optical audio connector
Toslink
Mechanical
Housing
Metal enclosure
Dimensions
[L x W x H]
Model
122 x 67 x 25mm [4.8" x2.6" x0.9"]
Package
198 x 137 x 74mm [7.8" x 5.4" x 2.9"]
Carton
420 x 400 x 300mm [1'4"x 1'3" x 11.8"]
Weight
Model
236g [8.3 oz]
Package
466 g [16.4 oz]
Fixedness
Wall-mounting case with screws
Power supply
5V DC
Power consumption
2.5 Watt [max]
Operation temperature
0~40°C [32~104°F]
Storage temperature
-20~60°C [-4~140°F]
Relative humidity
20~90% RH [no condensation]
-4-
PANEL DESCRIPTIONS
1. Micro-USB port: for F/W update / +5V power
2. Power LED indicator
3. HDMI input
4. Input Signal LED indicator
5. 4-Pin Dip Switch (Please refer to “Notes”)
6. S/PDIF input (TOSLINK)
7. Stereo input (3.5mm)
8. Stereo output (3.5mm)
9. S/PDIF output (TOSLINK)
10. 2-Pin Dip Switch (Please refer to “Notes”)
11. HDMI output
12. Output Signal LED indicator
13. Reset button
*Notes: DIP Switch Position
** ARC audio extraction is always via Toslink output
DIP Switch Position
(2-Pin)
Description
PIN#1
PIN#2
OFF []
OFF []
HDMI audio bypass; S/PDIF out – HDMI input audio
OFF []
ON []
HDMI audio bypass; S/PDIF out – ARC audio
ON []
OFF []
HDMI audio from S/PDIF input; S/PDIF out – HDMI input audio
ON []
ON []
HDMI audio from Stereo input; S/PDIF out – HDMI input audio
DIP Switch Position(4-Pin)
Description
PIN#1
PIN#2
PIN#3
PIN#4
OFF []
OFF []
-
-
8K Ultra HD(8K@60/4K@120) – 8bit video & 2ch audio
OFF []
ON []
-
-
4K Ultra HD(4K@60) – 8bit video & 2ch audio
ON []
OFF []
-
-
Learning EDID from output
ON []
ON []
-
-
User defined EDID
-
-
OFF []
OFF []
Normal Mode
-
-
OFF []
ON []
Reserved
-
-
ON []
OFF []
Scale Up
-
-
ON []
ON []
Scale Down

-5-
CONNECTION DIAGRAM
-6-
WARRANTY
The SELLER warrants the CV-505Q HDMI 2.1 Audio Extractor & Embedder to be free from defects
in the material and workmanship for 1 year from the date of purchase from the SELLER or an
authorized dealer. Should this product fail to be in good working order within 1 year warranty period,
The SELLER, at its option, repair or replace the unit, provided that the unit has not been subjected to
accident, disaster, abuse or any unauthorized modifications including static discharge and power
surge. This warranty is offered by the SELLER for its BUYER with direct transaction only. This warranty
is void if the warranty seal on the metal housing is broken.
Unit that fails under conditions other than those covered will be repaired at the current price of
parts and labor in effect at the time of repair. Such repairs are warranted for 90 days from the day of
reshipment to the BUYER. If the unit is delivered by mail, customers agree to insure the unit or assume
the risk of loss or damage in transit. Under no circumstances will a unit be accepted without a return
authorization number.
The warranty is in lieu of all other warranties expressed or implied, including without limitations,
any other implied warranty or fitness or merchantability for any particular purpose, all of which are
expressly disclaimed.
Proof of sale may be required in order to claim warranty. Customers outside Taiwan are
responsible for shipping charges to and from the SELLER. Cables are limited to a 30 day warranty and
cable must be free from any markings, scratches, and neatly coiled.
The content of this manual has been carefully checked and is believed to be accurate. However,
The SELLER assumes no responsibility for any inaccuracies that may be contained in this manual. The
SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting
from any defect or omission in this manual, even if advised of the possibility of such damages. Also,
the technical information contained herein regarding the CV-505Q features and specifications is
subject to change without further notice.
