GOMETRICS T210 User manual

DIGITAL MANOMETER T210
1
DIGITAL MANOMETER
T210
USER'S MANUAL
Reference: MI-T210-16-EN
Release: 1
Review: 6
© Copyright 2018
Gometrics S.L.
Pol. Ind. Riera de Caldes, C/ Basters 17
Palau
-
Solità i Plegamans
-
08184 Barcelona
Tel Main Office ([phone]
Tel Central Zone ([phone]
Web: http://www.gometrics.net
E-mail: [email protected]et

DIGITAL MANOMETER T210
2
EC DECLARATION OF CONFORMITY
The company: GOMETRICS, S.L.
C/Basters, 17 - Polg. Ind. Riera de Caldes
08184 - Palau-Solità i Plegamans (BARCELONA)
Telf.: 00 34 938 646 843 - Fax: [phone]
E-Mail: [e-mail]
http://www.gometrics.net
The company declares under its sole responsibility that the device:
Brand name: GOMETRICS
Model: T210 (series)
Type: Digital manometer and milliampere handheld device.
Year of manufacture: 2003
And it is in conformity with Directive 2004/108/EC of the European Parliament and of the Council of 15
December 2004 on the approximation of the laws of the Member States relating to electromagnetic
compatibility and repealing Directive 89/336/EEC.
Harmonised technical standards:
EN 55022:1998 Class B (UNE-EN 61326)
Radiated Emissions.
AT 61000-4-3:2002 (UNE-EN 61326)
Immunity to electromagnetic fields
AT 61000-4-2:1995 (UNE-EN 61326)
Electromagnetic discharges.
AT 61000-4-6:1996 (UNE-EN 61326)
Conducted RF-induced disturbances.
Name: Tomás
Surname de Miguel y de Blas
Job tritle: Managing Director
In Palau -Solità i Plegamans (BARCELONA), 15 February 2012
Fdo.: Tomás de Miguel y de Blas

DIGITAL MANOMETER T210
3
CONTENTS
Contents Page
Contents ................................................................................................ 3
Inspection .............................................................................................. 4
Power Supply ......................................................................................... 5
Portable Operation ................................................................................ 5
Installation............................................................................................... 6
Operation ................................................................................................ 7
Operation as Manometer .................................................................. 7
Operation as milli-Ammeter .............................................................. 8
Alternative Manometer-milli-Ammeter Operation ............................. 9
Changing Units ................................................................................. 10
Quick Access to the Engineering Unit .............................................. 11
Instrument Messages ....................................................................... 11
Installation and Use ............................................................................... 12
Adjustments ....................................................................................... 12
Input Current Adjustment ............................................................. 12
Input Pressure Adjustment ........................................................... 12
Instrument Calibration ....................................................................... 13
Guarantee............................................................................................... 13
Technical Specifications ........................................................................ 14
Accesories………………………………………………………………ANNEX

DIGITAL MANOMETER T210
4
INSPECTION
The standard instrument is supplied in individual packaging with the following
contents:
- 1 Manometer T210
- 1 rechargeable battery, 8.4 V, 250 mAh. Ref. EH6F22H250
- 1 battery charger, Ref PS-30B
- 1 set of cables for current measurement. Ref. PN1041
- 1 transport bag, Ref. GOM001
- 1 User's Manual
- 1 certificate of traceability (in attached envelope) or ENAC calibration
certificate (optional)
- 2 washers, U10351620
- **1 Ø6mm tube adapter (≤17 bars only ranges). Ref.RBQSF612
Please check the contents before using the instrument.

DIGITAL MANOMETER T210
5
POWER SUPPLY
The T210 manometer is designed for portable operation using the supplied
internal battery. This is supplied fully charged but, if the instrument's display
screen does not light up or the LOW BATT message is displayed at switch on,
the battery-charging instructions given on page 11 should be followed.
PORTABLE OPERATION
The T210 manometer is designed for continuous portable operation during
twelve hours.
The instrument uses a NiMH type battery. One of its characteristics is the
reduction of the memory effect with respect to NiCd batteries. This effect
involves a reduction in the battery's recharging capacity. To maintain this
recharging capacity, it is recommended that full recharging and discharging
cycles be carried out. However, although long, its lifetime is limited and in time
will have to be replaced by a new one.

DIGITAL MANOMETER T210
6
INSTALLATION
Follow the procedure provided below to start using the manometer:
1.- Open the battery compartment located at the rear of the instrument and
keep the screws in a safe place.
2.- Insert the battery and close the compartment again.
3.- Turn on the red main switch on the front panel and check that the
verification sequence is initiated on the screen of the model T210, version
V. X.XX and the last units selected on the instrument before it was
switched off, after which the screen will display a ZERO reading or one
close to it and is then ready for operation.
NOTE: If the screen does not light up or the LOW BATT message is displayed,
see page 11.
OPERATION
The T210 instrument has a double operating mode:
. Manometer
. Milli-ammeter
The T210 can operate simultaneously in both modes, although the readings
have to be selected using the P/mA key.

DIGITAL MANOMETER T210
7
OPERATION AS MANOMETER
Proceed as described below:
1.- Check that the T210 does not have the mA reading indicator active, as
displayed on the left-hand side of the screen by a small arrow. Otherwise
press the P/mA key to change the MANOMETER/MILLI-AMMETER so
that the mA indicator is deactivated.
2.- Press the UNIT key to change the engineering units in order to verify the
working unit.
WARNING: Pressing the key a single time will display the current unit,
and by keeping it pressed, the work unit will change consecutively. See
page 10 for unit changing and the use of the memories for quick access
to programmed units.
3.- Press the yellow ZERO key if the T210 screen displays any reading other
than zero. (NOTE: For absolute sensors not applicable)
4.- Connect the instrument to be calibrated and the pressure input to the
1/8” fitting on top of the T210.
5.- The manometer is now ready to take pressure readings.

DIGITAL MANOMETER T210
8
WARNING: The pressure connection is 1/8-inch BSP M, conical, 60º internal,
and to prevent leaks, one of the two washers supplied at the base of the fitting
connection must be used, Ref. U10351620.
NOTE: GOMETRICS has a pneumatic kit RB400BP01 together with
accessories (up to 20 bar) available that does not require any tools, tightening it
by hand and leak-tight to 20 bar.
GOMETRICS has other connection accessories available from 600 up to 1,000
bar.
OPERATION AS MILLI-AMMETER
The following instruction should be followed when using the T210 for current
readings in the 0-30 mA range, normally to verify the response of a 4-20 mA
pressure transmitter
WARNING: The T210 does not include an internal 24 Vdc power supply and
must be externally powered.
1.- Use the yellow P/mA key on the instrument's front panel to select the
current reading mode, which is indicated by the display of the mA icon on
the screen.
2.- The necessary connections should be made using the cables supplied on
the side of the T210 respecting the polarity indicated on the front panel.
3.- The instrument is now ready to take current readings in the range -30 / 0 /
+30 mA.

DIGITAL MANOMETER T210
9
MANOMETER-MILLI-AMMETER ALTERNATIVE OPERATION
Once the T210 is ready for operation in accordance with the section seen on
this and the previous pages, it can be employed for combined reading of
pressure or current by simply using the P/mA switch on the front panel.
This possibility is specially helpful with pressure and current transmitters.
When the mA icon is visible, the displayed readings are current values. When
this indicator is not visible, the displayed readings are pressure values.
NOTE: The T210 instrument includes current input protection against current
peaks and voltages up to 30 V.

DIGITAL MANOMETER T210
10
CHANGING ENGINEERING UNITS
The T210 manometer provides the possibility to perform pressure readings in
ten different engineering units.
These units are selected as follows:
1.- Press and maintain the UNIT key on the front panel until the desired unit is
displayed.
2.- Release the UNIT key when the desired engineering unit is displayed.
3.- Verify the selected unit by briefly pressing the UNIT key.
The available units are then displayed on the T210 screen, together with their
corresponding equivalence.
NOTE: The "UNIT" key has two functions:
1.- Pressing it once will display the current unit.
2.- Maintaining it pressed for more than one second will cause the unit to
change, with all those available being displayed consecutively.
BAR
PSI
mm H2O
ATM
mm Hg
miliBAR
m H2O
cm H2O
KiloPascal
Kg/cm2

DIGITAL MANOMETER T210
11
QUICK ACCESS TO THE INGINEERING UNIT
The T210 manometer is equipped with a series of keys, U1, U2 etc. U6
provides the means of quick selection of the engineering unit for pressure
values.
These memories can be programmed using the following routine:
1.- Press and maintain the "UNIT" key until the desired engineering unit is
displayed on the screen.
2.- Then press the quick selection key to assign the new unit and maintain it
pressed until the desired engineering unit is displayed again.
3.- Verify the selection by pressing the recently programmed selection key
and check that the displayed unit is correct.
4.- Repeat previous points 1 to 3 for the remaining quick selection keys, if
required.
INSTRUMENT MENSSAGES
The T210 can display the following messages prior to or during operation:
LOW BATT: This indicates that the available battery power is below the
minimum recommended for the level of reliability and correct operation.
When this message appears, for continued instrument use, it must be
connected to the mains supply by means of the PS-30B battery charger,
which is supplied with the unit.
Power supply voltage: 220 Vac
Approximate recharge time: 16 hours
NOTE: In this way, the manometer can be continued to be used and the
batteries will be recharged.

DIGITAL MANOMETER T210
12
INSTALLATION AND USE
The T210 manometer incorporates a folding support at the rear of the box that
permits the instrument to be used in an upright position, which facilitates both
use and reading.
It is recommended that the instrument be returned to its protective case when
not in use. It is also recommended that the battery be removed when the
instrument is not going to be used during a prolonged period of time.
ADJUSTMENTS
The T210 manometer leaves the factory fully adjusted and no further
adjustment is required. However, it is recommended that it be recalibrated
approximately once a year, with any necessary adjustment being carried out.
In order to correctly adjust the unit, it should be confirmed that all necessary
elements are available, such as adequately precise standards and required
means of connection.
In order to determine that the standards are adequate, consult the instrument's
technical sheet and check that the standard to be employed meets the ration
requirements, which must be greater than 2 to guarantee the correct assigned
uncertainty.
Note that a wrong choice of standard could lead to incorrect unit specifications.
If suitable standards are not available for calibration and adjustment, it should
be sent to an accredited laboratory in order to obtain a correct level of
certification and traceability. Gometrics laboratory complies with EN17025 in
pressure measurements.
Adjusting the input current
1.- Connect the instrument's measuring terminals to a current generator set
to 20 mA.
2.- Adjust with potentiometer P1 (located in the exterior section of the battery
compartment identified as I).

DIGITAL MANOMETER T210
13
Input pressure adjustment
1.- Perform the zero adjustment for the pressure measurement by pressing
the corresponding key indicated as ZERO *.
2.- Apply the maximum range pressure to the equipment.
3.- This is adjusted using potentiometer P2 (located in the central part of the
battery compartment).
*Non-functional key in case of absolute pressure. In this case, zero must be set using the
potentiometer located in the battery compartment and identified as Z and applying the lowest
possible absolute pressure.
NOTE:
The battery must be removed in order to access the adjustments in its .
compartment. In this situation the T210 must be powered using the charger/
power supply P-30B.
INSTRUMENT CALIBRATION
The T210 manometer is supplied with a factory calibration certificate.
GOMETRICS recommends that the instrument be inspected once a year.
Depending on instrument usage, maintenance and conservation, this time may
lengthened or shortened.
GOMETRICS can recalibrate this instrument, issuing a certificate with
traceability or issuing a new ENAC calibration certificate via its own accredited
ENAC-laboratory EN17025.
GUARANTEE
The GOMETRICS T210 manometer is guaranteed against all defects for a
period of 3 years. Instrument manipulation, improper use, exceeding its limits or
using it under abnormal conditions will automatically cancel the coverage
provided by the instrument's guarantee. The associated charges for transport,
insurance or other incidental costs within the Spanish peninsular territory,
Europe and the rest of the world are not covered by the manufacturer's
guarantee and, in all cases, will be subject to prior agreement.

DIGITAL MANOMETER T210
14
TECHNICAL SPECIFICATIONS
Pressure interval: Min: 0-25 mbar
(see table) Max: 0-1,000 bar
Uncertainty*: 0.25% FS and 0.10% FS
Current interval: ±30 mA
Uncertainty*: 0.025% of the reading + 2 µA
Resolution: 4 1/2 digits in pressure
(see table) 1 µA / 10 µA in current
Connection to process: 1/8-inch BSP M, 60º internal conical
Operating temperature: 0-50ºC
Temperature coefficient: 0.02% FS/ºC < 1 bar 0.01% FS/ºC > 1 bar
Fluids: Compatible with stainless steel and Buna N for
ranges ≥ 1 bar, air or inert gases for ranges < 1
bar and differential pressure.
Over-pressure: Twice the range. For differential pressure equal
to the maximum static. (See exception**)
Maximum static pressure: (only differential pressure), three times the
range of 14 bar (whichever is less)
Screen: 10-mm LCD
Batteries: NiMH, rechargeable
Charger power supply: 230 V, 50 Hz
Portable operation: 20 hours
Dimensions: 83 x 152 x 33 mm
Weight: 360 g
Guarantee: 3 years
Marking: CE
Calibration certificate with standard traceability (ENAC optional)
* includes non-linearity, hysteresis, repeatability, thermal drift between 20 and 26ºC and stability at
one year.

DIGITAL MANOMETER T210
15
Range
code
Relative
(G)
Vacuum
(V)
Combined
(E) (3)
Differential
pressure
(D) (1)
Absolute
(A)
Resolution
Display
reading
025 (4) 0 – 25 -25 / 0 -25 / +25 (2) -25 / +25 –0.01
070 (4) 0 – 70 -70 / 0 -70 / +70 (2) -70 / +70 –0.01
300 (4) 0 – 300 -300 / 0 -300 / +300 -300 / +300 0 – 300 (*) 0.1
101 0 – 1 -1 / 0 -1 / +1 -1 / +1 (4) 0 – 1 0.0001
201 0 – 2 –-1 / +2 -1 / +2 (4) 0 – 2 0.0001
701 0 – 7 –-1 / +7 -1 / +7 (4) 0 – 7 0.001
172 0 – 17 –-1 / +17 ––0.001
352 0 – 35 –-1 / +35 ––0.01
702 0 – 70 ––––0.01
173 0 – 170 ––––0.01
353 0 – 350 ––––0.1
105 0 – 1000 (**) ––––0.1
(*) not available with 0.1% FS uncertainty
(**) Execution with external sensor Connection to process, 1/4 -inch BSP M. Maximum
overpressure: 10%.
(1) Maximum static pressure 3 times the range or 14 bar (whichever is less)
(2) Maximum static pressure 300 mbar
(3) For combined ranges, the uncertainty is in % above SPAN
mbarbar
Table of existing ranges according to input type
Series
Range code
(see table)
Uncertainty
1 - 0.25% FS (all codes)
2 - 0.1% FS (all codes except (*))
Entry
G - Realtive pressure
V - Vacuum
A - Absloute pressure
D - Differential pressure
E - Combined (vacuum - pressure)

DIGITAL MANOMETER T210
16
WARNING
The equipment described here has been manufactured with components that are sensitive to
electrostatic discharge. Any incorrect or improper use of this equipment shall not be covered by the
guarantee.
The contents of this manual are for your own use. All rights are reserved to carry out modifications
to the equipment without any prior warning.
A reasonable effort has been taken with respect to the accuracy of the information in this manual.
Gometrics shall not be held responsible for any typographical errors or for the information contained
in this manual.
Change control register:
DATE REVIEW COMMENTS
15-05-2018
18-05-2018
v1.4
v1.5
Format and style aspects corrections.
Added change control register.
14-02-2020 v1.6 Format revision. Added Annex.

Operating diagram digital manometer Tinycal T210
Accesories
Pneumatic accesories (máx. 20 bar)
RS20012G
RS20012
RS20014
RS20016
RS20018
RS20012RG
RS20014RG
RS20016RG
RS20018RG
Connecting tubing with a lenght of 750 mm.
60º conical connection fitting 1/8" NPT M - 1/8" BSP M
Description
Connecting tubing with a length of 750 mm and two
extension of 500 mm.
Reference
R400BP-022
R400BP-011
60º conical connection fitting 1/8" BSP M at both ends
RBQSF612
U103S1620 1/8" BSP M thread USIT washer.
Stainless steel high pressure kit consist:
01-0706
01-0707
01-0708 Kit de 7 adaptadores SI, en acero inox., compuesto por:
(1) 1/4" BSP M x 1/2" NPT H
(1) 1/4" BSP male fitting
(1) 1/4" BSP female fitting
(1) 1/4" BSP M x 1/2" BSP H // (1) 1/4" BSP M x 1/8" NPT H
(1) 1/4" BSP M x 1/4" NPT H // (1) 1/4" BSP M x 3/8" NPT H
HTPA-1000 (1) 1/4" BSP M x 1/8" BSP H // (1) 1/4" BSP M x 3/8" BSP H
HK1-1000 (1) 1 meter long flexible tubing
High pressure accesories (from 600 to 1000 bars)
DescriptionReference
Up to 1000 bars accesories (stainless steel)
Up to 600 bars accesories
V600-14NPT6
V600-18NPT6
V600-14BSP6
V600-18BSP6
RS4TG
RS8RB4G
RS40012GG
U103S1620
U13702015
U20702815
1/8" BSP M x 1/8" BSP H connection fitting
1/4" NPT M high pressure fitting
1/4" BSP H Te connection fitting
Connecting tubing with a lenght of 750 mm x 6 mm
1/8" BSP M thread USIT washer
1/2" BSP M to 1/4" BSP H adapter
V6006-022
Manometer
T210 Pressure gauge
Pressure pump BP-102G
0000
Electronic
pressure
transmitter
for calibration
0000
Pressure pump BP-102G
Pressure pump
PGM
Manometer
T210
0000
Manometer
T210
4 - 20 mA
4 - 20 mA
Electronic
pressure
transmitter
for calibration
for calibration
60º conical connection fitting 1/4" NPT M - 1/8" BSP M
60º conical connection fitting 3/8" NPT M - 1/8" BSP M
60º conical connection fitting 1/2" NPT M - 1/8" BSP M
60º conical connection fitting 1/8" BSP M - 1/8" BSP M
60º conical connection fitting 1/4" BSP M - 1/8" BSP M
60º conical connection fitting 3/8" BSP M - 1/8" BSP M
60º conical connection fitting 1/2" BSP M - 1/8" BSP M
1/8" BSP H quick connection fitting to 6 mm tube.
1/8" NPT M high pressure fitting
1/4" BSP M high pressure fitting
1/8" BSP M high pressure fitting
1/4" BSP M thread USIT washer
1/2" BSP M thread USIT washer
ANNEX
