GMV95 40" 95% Gas Furnace Units

GCV9 40" 90% Gas Furnace Units Models listed

on page 2.

TECHNICALINFORMATION MANUAL

• Refer to Service Manual RS6610004* for installation,

operation,andtroubleshootinginformation.

• All safety information must be followed as provided in

theServiceManual.

• Refer to the appropriate Parts Catalog for part number

information.

RT6612012Rev.2

July2008

®This manual is to be used by qualified, professionally trained HVAC

technicians only. Goodman does not assume any responsibility for property

damage or personal injury due to improper service procedures performed by

an unqualified person.

PRODUCT IDENTIFICATION

Themodelandmanufacturingnumberareusedforpositiveidentificationofcomponentpartsusedinmanufacturing.

Pleaseusethesenumberswhen requesting service or parts information.

WARNING

HIGHVOLTAGE!

DisconnectALLpowerbeforeservicingorinstallingthis unit.Multiple

power sources may be present. Failure to do so may cause property

damage, personal injury or death.

Installation and repair of this unit should be performed ONLY by individu-

als meeting the requirements of an "entry level technician" as specified

by the the Air-Conditioning, Heating and Refrigeration Institute (AHRI).

Attempting to install or repair this unit without such background may

result in product damage, personal injury or death.

WARNING

Goodmanwillnotberesponsibileforanyinjuryorpropertydamagearising

from improper service or service procedures. If you install or perform

service on this unit, you assume responsibility for any personal injury or

property damage which may result. Many jurisdictions require a license to

install or service heating and air conditioning equipment.

Furnace Type

Product Type

G: GoodmanBrand

Supply Type

Nominal Input

Model Family

G M V 95 045 3 B X A

Additional Features

N: NaturalGas

X: LowNOx

Airflow Capability

Cabinet Width

Design Series

A:Initial Release

045: 45,000Btuh

070: 70,000Btuh

090: 90,000Btuh

115: 115,000Btuh

3: 1200

4: 1600

5: 2000

9: 90% AFUE

95: 95%AFUE

C: Counterflow/Horizontal

M: Upflow/Horizontal

B: 171/2"

C: 21" D: 241/2"

V: VariableSpeed,

Two-Stage

Themodelandmanufacturingnumberareusedforpositiveidentificationofcomponentpartsusedinmanufacturing.

Pleaseusethesenumberswhen requesting service or parts information.

PRODUCT IDENTIFICATION

WARNING

WARNING To prevent the risk of property damage, personal injury, or death, do not

store combustible materials or use gasoline or other flammable liquids or

vapors in the vicinity of this appliance.

Do not connect or use any device that is not design certified by Goodman

for use with this unit. Serious property damage, personal injury, reduced

unit performance and/or hazardous conditions may result from the use of

suchnon-approved devices.

WARNING

WARNING The United States Environmental Protection Agency (“EPA”) has issued

various regulations regarding the introduction and disposal of refrigerants

introduced into this unit. Failure to follow these regulations may harm the

environment and can lead to the imposition of substantial fines. These

regulations may vary by jurisdiction. Should questions arise, contact your

local EPA office.

GMV950453BX*

GMV950704CX*

GMV950905DX*

GMV951155DX*

GCV90704CX*

GCV90905DX*

GCV91155DX*

PRODUCT DESIGN

3. Conversionkitsforpropanegasandhighaltitude

naturalandpropanegasoperation are available. See

HighAltitudeDeratechartfor details.

4. Installer must supply the following gas line fittings,

dependingonwhichentrance is used:

Left --Two 90° Elbows, one close nipple, straight pipe

Right --Straightpipe to reachgasvalve.

Accessibility Clearances(Minimum)

POSITION* FRONT SIDES REAR TOP FLUE FLOOR

Upflow10010C

Horizontal Alcove 6 0 4 0 C

*= All positioning is determined as installed unit is viewed from the front.

C= If placed on combustible floor, floorMUST be wood only.

POSITION* FRONT SIDES REAR TOP FLUE FLOOR

Downflow 1 0 0 1 0 NC

Horizontal Alcove 6 0 4 0 C

*= All positioning is determined as installed unit is viewed from the front.

C= If placed on combustible floor, floorMUST be wood only.

GMV95 MINIMUM CLEARANCES TO COMBUSTIBLE MATERIALS

(INCHES)

NC= For instalaltion on non-combustible floors only. A combustible

subbase must be used for installations on combustible flooring.

GCV9 MINIMUM CLEARANCES TO COMBUSTIBLE MATERIALS

(INCHES)

NC= For instalaltion on non-combustible floors only. A combustible

subbase must be used for installations on combustible flooring.

AlcoveIllustration

REAR

SIDE

LCOVE

24"atfront isrequiredforservicing orcleaning.

Note: In all cases accessibility clearance shall take

precedence over clearances from the enclosure where

accessibility clearances are greater. All dimensions are

givenininches.

GeneralOperation

TheGMV95andGCV9 furnaces are equipped with an elec-

tronicignitiondeviceto light theburnersandaninduceddraft

blowerto exhaust combustion products.

An interlock switch prevents furnace operation if the blower

door is not in place. Keep the blower access doors in place

exceptforinspectionand maintenance.

This furnace is also equipped with a self-diagnosing elec-

tronic control module. In the event a furnace component is

not operating properly, the control module LED will flash on

andoffinafactory-programmedsequence, dependingonthe

problem encountered. This light can be viewed through the

observation window in the blower access door. Refer to the

TroubleshootingChartforfurtherexplanationoftheLEDcodes

andAbnormal Operation - IntegratedIgnitionControlsection

intheService Instructions for an explanation ofthe possible

problem.

The rated heating capacity of the furnace should be greater

than or equal to the total heat loss of the area to be heated.

The total heat loss should be calculated by an approved

method or in accordance with “ASHRAE Guide” or “Manual

J-LoadCalculations”publishedbytheAirConditioning Con-

tractorsofAmerica.

*Obtain from: American National Standards Institute 1430

BroadwayNewYork, NY10018

LocationConsiderations

• The furnace should be as centralized as is practical

with respect to the air distribution system.

• Do not install the furnace directly on carpeting, tile, or

combustiblematerialotherthanwoodflooring.

• When suspending the furnace from rafters or joists,

use3/8"threadedrodand2” x2”x1/8”angleasshown

intheInstallationandServiceInstructions.Thelength

oftherod will depend ontheapplicationandclearance

necessary.

• Wheninstalledina residentialgarage,thefurnacemust

be positioned so the burners and ignition source are

located not less than 18 inches (457 mm) above the

floorandprotectedfromphysical damage by vehicles.

Notes:

1. Installermustsupplyoneortwo PVC pipes: one for com-

bustionair(optional) andoneforthe flueoutlet(required).

Vent pipe must be either 2” or 3” in diameter, depending

uponfurnaceinput, number of elbows, lengthof run and

installation (1 or 2 pipes). The optional Combustion Air

Pipeisdependentoninstallation/coderequirementsand

must be 2” or 3” diameter PVC.

2. Linevoltagewiringcanenterthroughtherightorleftside

of the furnace. Low voltage wiring can enter through the

rightor left side of furnace.

PRODUCT DESIGN

High Altitude Derate

Whenthisfurnaceisinstalledat high altitude, the appropriate HighAltitudeorificekitmustbeinstalled.Thisisrequireddue

tothe natural reduction in thedensity of both the gasfuel and combustion air as altitude increases. The kitwill provide the

properdesigncertifiedinput rate within the specified altitude range.

Natural Propane Natural Propane Natural Propane

GMV950453BX*

GMV950704CX* No

Change LPM-05*

#55 Orifice No

Change

HANG13

#44

Orifice

HALP11

#56 Orifice HAPS28 HANG14

#45

Orifice

HALP11

#56

Orifice HAPS28

GMV950905DX*

GMV951155DX* No

Change LPM-05*

#55 Orifice No

Change

HANG13

#44

Orifice

HALP11

#56

Orifice HAPS29 HANG14

#45

Orifice

HALP11

#56

Orifice HAPS29

GCV90704CX*

GCV90905DX*

GCV91155DX*

Change LPM-05*

#55 Orifice No

Change

HANG13

#44

Orifice

HALP11

#56

Orifice HAPS29 HANG14

#45

Orifice

HALP11

#56

Orifice HAPS31

9,001 - 11,000 Feet

"STANDARD" and "HIGH ALTITUDE" KITS

Furnace ID Blwr

Pressure

Switch

Gas Orifices

0 - 7,000 Feet

(Standard Altitude) 7,001 - 9,000 Feet

Gas Orifices

ID Blwr

Pressure

Switch

ID Blwr

Pressure

Switch

Gas Orifices

Highaltitudekitsarepurchasedaccordingtotheinstallationaltitudeandusageofeithernaturalorpropanegas.Refertothe

chartaboveforatabularlistingofappropriatealtituderangesandcorrespondingmanufacturer’shighaltitudeNaturalGasand

PropaneGaskits.Foratabularlistingofappropriatealtituderangesandcorrespondingmanufacturer'sHighAltitudePressure

COMPONENT IDENTIFICATION

Upflow/Horizontal

1Two-StageGasValve

2 GasLineEntrance(Alternate)

3 PressureSwitch(es)

4 GasManifold

5 CombustionAir Intake Connection

6 HotSurfaceIgniter

7 RolloutLimit

8 Burners

9 FlameSensor

10 FluePipeConnection

11 FluePipe

12 Primary Limit

13 GasLine Entrance

14 FluePipeConnection(Alternate)

15 RubberElbow

16 Two-Speed InducedDraftBlower

17 ElectricalConnection Inlets (Alternate)

18 CoilFrontCoverPressureTap

19 CoilFrontCoverDrainPort

20 DrainLinePenetrations

21 DrainTrap

22 BlowerDoor Interlock Switch

23 Inductor(NotAll Models)

24 Two-StageIntegrated ControlModule

(withfuseanddiagnostic LED)

25 24VoltThermostatConnections

26 Transformer(40 VA)

27 ECMVariableSpeed Circulator Blower

28 Auxiliary Limits

29 JunctionBox

30 ElectricalConnection Inlets

31 CoilFrontCover

32 CombustionAirInletPipe(GCV9only)

Counterflow/Horizontal

BLOWER COMPARTMENT BURNER COMPARTMENT

56787910

16 18

19 20

1918

31 17

Intell-I

nition

BLOWER COMPARTMENT

97874

526 27 10

1514

1819

PRODUCT DIMENSIONS

GMV95___XA

NOTE: Airflow area will be reduced by approximately 18% if duct flanges are not unfolded. This could cause performance

issues and noise issues.

RIGHT SIDE

DRAIN LINE

HOLES

AIR

INTAKE

PIPE

2" PVC

1 5/8

RIGHT SIDE VIEW

1 1/2

UNFOLDED FLANGES

FOLDED FLANGES

UNFOLDED FLANGES

FOLDED FLANGES

DISCHARGE

AIR

DISCHARGE

CabinetSizeABCDE

20-7/16

GMV950453BX*

GMV950704CX*

GMV950905DX*

GMV951155DX*

19-1/2

17-1/2

13-5/8

17-1/2

20-7/8

All dimensions are in inches.

24-1/2

12-1/8

19-3/8

12-15/16

15-15/16

PRODUCT DIMENSIONS

GCV9_____XA

LOW VOLTAGE

ELECTRICAL HOLE

28 3/4

3/4 20 1/4 2 1/2

AIR INTAKE PIPE

2" PVC

LEFT SIDE

DRAIN LINE

HOLES

DRAIN

TRAP

28 5/16

11 1/2

9 13/16

18 13/16

UNFOLDED FLANGES

1 3/4

18 5/8

2 5/8

HIGH VOLTAGE

ELECTRICAL HOLE

20 5/32

AIR

DISCHARGE

LEFT SIDE

VIEW

3/4

UNFOLDED FLANGES

(DISCHARGEAIR)

CONDENSATE

DRAIN TRAP

w/ 3/4" PVC

DISCHARGE

(RIGHT OR

LEFT SIDE)

8 1/4

FOLDED FLANGES

(RETURN AIR) 3/4

HIGH VOLTAGE

ELECTRICAL HOLE

LOW VOLTAGE

ELECTRICAL HOLE

RIGHT SIDE

DRAIN LINE

HOLES

ALTERNATE

VENT/FLUE

LOCATION

VENT/FLUE PIPE

2" PVC

11 5/8

LTERNATE

IR INTAKE LOCATION

9 3/4

DRAIN

TRAPC

6 1/8

7 3/8

DISCHARGE

2 5/8

LTERNATE GAS

SUPPLY HOLE

RIGHT SIDE

VIEW

FRONTVIEW

4 1/8

1 3/4

28 5/16

15 7/16

19 7/8

STANDARD GAS

SUPPLY HOLE

FOLDED FLANGES

2 11/16

NOTE: Airflow area will be reduced by approximately 18% if duct flanges are not unfolded. This could cause performance

issues and noise issues.

CabinetSizeABCDE

21-1/2 23

GCV90704CX* 21 19-1/2 15-15/16

All dimensions are in inches.

18 19-1/2

GCV90905DX*

GCV91155DX* 24-1/2 23 20-7/16

PRODUCT DESIGN

LOW

FIRE HIGH

FIRE LOW

FIRE HIGH

FIRE LOW

FIRE HIGH

FIRE LOW

FIRE HIGH

FIRE

GMV950453BX*

GMV950704CX* -0.45 -0.90 -0.50 -0.95 -0.25 -0.25 -0.25 -0.25

GMV950905DX*

GMV951155DX* -0.65 -1.20 -0.70 -1.25 -0.25 -0.25 -0.25 -0.25

GCV90704CX* -0.35 -0.70 -0.20 -0.55 -0.52 -0.52 -0.37 -0.37

GCV90904DX* -0.35 -0.70 -0.20 -0.55 -0.52 -0.52 -0.37 -0.37

GCV91155DX* -0.35 -0.70 -0.20 -0.55 -0.52 -0.52 -0.37 -0.37

(2) Data given is least negative pressure required for pressure switch to remain closed.

Note: The typical sea level negative pressure data represents the minimum pressures expected. Shorter

length of flue pipe or single pipe systems compared to dual pipe systems should show higher(greater

negative) pressures.

PRESSURE SWITCH TRIP POINTS AND USAGE CHART

NEGATIVE

PRESSURE

ID BLOWER

WITHFLUE

NOT FIRING

TYPICAL SEA

LEVEL DATA(1)

NEGATIVE

PRESSURE

ID BLOWER

WITH FLUE

FIRING

TYPICAL SEA

LEVEL DATA(2)

NEGATIVE

PRESSURE

COIL COVER

WITH FLUE

NOT FIRING

TYPICAL SEA

LEVEL DATA(1)

NEGATIVE

PRESSURE

COIL COVER

WITH FLUE

FIRING

TYPICAL SEA

LEVEL DATA(2)

MODEL

(1) Data given is least negative pressure required for pressure switch to close.

LOW FIRE HIGH FIRE LOW FIRE HIGH FIRE LOW FIRE HIGH FIRE LOW FIRE HIGH FIRE

GMV950453BX*

GMV950704CX* -0.10 -0.10 20197308 -0.30 -0.75 11177113 -0.10 -0.10 -0.22 -0.55 HAPS28

11177115

GMV950905DX*

GMV951155DX* -0.10 -0.10 20197308 -0.50 -1.10 11177114 -0.10 -0.10 -0.38 -0.82 HAPS29

11177116

GCV90704CX* -0.37 -0.37 20197313 -0.20 -0.55 11177118 -0.37 -0.37 -0.15 -0.30 HAPS31

GCV90905DX* -0.37 -0.37 20197313 -0.20 -0.55 11177118 -0.37 -0.37 -0.15 -0.30 HAPS31

GCV91155DX* -0.37 -0.37 20197313 -0.20 -0.55 11177118 -0.37 -0.37 -0.15 -0.30 HAPS31

7,001 ft. to 11,000 ft.

PRESSURE SWITCH TRIP POINTS AND USAGE CHART

Note: All installations above 7,000 ft. require a pressure switch change. For installations in Canada the GMV95 & GCV9 furnaces are certified only to 4500 ft.

TRIP POINT

COIL COVER

PRESSURE SWITCH

TRIP POINT

COILCOVER

PRESSURE SWITCH

TRIP POINT

ID BLOWER

PRESSURE SWITCH

COIL COVER

PRESSURE

SWITCH

PART #

Note: Replacement pressure switch number is listed belowhigh altitude kit number.

Note: All negative pressure readings are in inches of water column (" w.c.).

0 to 7,000 ft.

MODEL

TRIP POINT

ID BLOWER

PRESSURE SWITCH HIGH

ALTITUDE

KIT

ID BLOWER

PRESSURE

SWITCH

PART #

PRODUCT DESIGN

Part Number 20162903 20162904 20162905 20162907 20162908

Open Setting (°F) 160 150 145 155 170

GMV950453BX* ---- ---- 1---- ----

GMV950704CX* ---- ---- ---- 1----

GMV950905DX* ---- ---- 1---- ----

GMV951155DX* ---- 1---- ---- ----

GCV90704CX* 1 ---- ---- ---- ----

GCV90905DX* ---- ---- ---- ---- 1

GCV91155DX* ---- ---- 1 ---- ----

PRIMARY LIMIT

Part Number 10123534 10123535 10123537 10123536 10123533

Open Setting (°F) 220 150 190 180 200

GMV950453BX* --- 2 --- --- ---

GMV950704CX* --- --- 2 --- ---

GMV950905DX* --- --- --- 2 ---

GMV951155DX* --- --- --- --- 2

GCV90704CXA 2------------

GCV90905DXA --- --- --- 2 ---

AUXILIARY LIMIT SWITCHES

Part Number 10123512 10123517 10123518 10123533 10123534 10123537

Open Setting (°F) 325 210 170 200 220 190

GMV950453BX* --- --- 1 --- --- ---

GMV950704CX* --- --- --- 2 --- ---

GMV950905DX* --- --- --- --- --- 2

GMV951155DX* --- --- --- 2 --- ---

GCV90704CX* ---- --- --- --- 2 ---

GCV90905DX* --- 2 --- --- --- ---

GCV91155DX* ---- 2 ---- ---- ---- ---

ROLLOUT LIMIT SWITCHES

PRODUCT DESIGN

Coil Matches (for Goodman®units using R22 and R-410A):

Product Type

C:IndoorCoil

C A P F 1824 A 6 A

Application

A:Upflow/DownflowCoil

H: Horizontal A Coil

S: Horizontal Slab Coil

Cabinet Finish

U:Uncased

P: Painted

C:UnpaintedCase

Expansion Device

F:Flowrator

Nominal Capacity Range @ 13 SEER

1824: 1 1/2 to 2 Tons

3030: 2 1/2Tons

3642: 3 to 3 1/2 Tons

4860: 4 & 5 Tons

Nominal Width for Gas Furnace

A: Fits14"FurnaceCabinet

B: Fits 17 1/2" Furnace Cabinet

C: Fits21"FurnaceCabinet

D: Fits 24 1/2" Furnace Cabinet

N: Does Not Apply (horizontal slab only)

6: R-22orR-410A

2: R-22

4: R-410A

Refrigerant

Revision

A:Revision

Coil Matches:

Alarge array of Goodman®brand coils are available forusewiththe GMV95 & GCV9 model furnaces,ineither

upflowor horizontal applications. These coils are available in both cased and uncased models, with or without

a TXV expansion device. These 90% - 95%+ furnaces match up with the existing Goodman®brand coils as

shown in the chart below.

• All CAPF coils in B, C, & D widths have insulated blank off plates for use with one size smaller furnaces.

• All CAPF coils have a CAUF equivalent.

• All CHPF coils in B, C & D heights have an insulated Z bracket for use with one size smaller furnace.

• All proper coil combinations are subject to being AHRI rated with a matched outdoor unit.

PRODUCT DESIGN

Thermostats:

Thefollowing2-stagethermostats are recommended for use with GMV95 &GCV9Furnace Models:

Filters:

Filters are required with this furnace and must be provided by the installer. The filters used must comply with UL900 or

CAN/ULCS111standards.Installingthis furnace without filters will void the unit warranty

Upflow Filters

This furnace has provisions for the installation of return air filters at the side and/or bottom return. The furnace will

accommodatethe following filter sizes depending on cabinet size:

RefertoMinimumFilterAreatablestodeterminefilterarearequirement.NOTE:Filterscanalsobeinstalledelsewherein

the duct system such as a central return.

Thermostat Mechanical / Digital

CHT90-120 Cooling/Heating, Mechanical

CH70TG Cooling/Heating, Digital, Non-programmable

CHSATG Cooling/Heating, Mechanical

H20TWR Heating Only, Mechanical

THERMOSTATS

Cabinet

Width (in.) Nominal

Filter Size (in.) Approx.

Flow Area (in2)Cabinet

Width (in.) Nominal

Filter Size (in.) Approx.

FlowArea (in2)

All 16 x 25 x 1 400 17-1/2 14 x 25 x 1 350

21 16 x 25 x 1 400

24-1/2 20 x 25 x 1 500

Side Return(s) Bottom Return

PRODUCT DESIGN

Disposable Minimum Filter Area (in2)

[Based on a 300 ft/min filter face velocity]

*Minimum filter area dictated by heating airflow requirement. *Minimum filter area dictated by heating airflow requirement.

Permanent Minimum Filter Area (in2)

[Based on 600 ft/min filter face velocity]

Counterflow Filters

Thisfurnacehasprovisionsfortheinstallationofreturnairfiltersatthecounterflowtopreturn. Thefurnacewillaccommodate

thefollowing filter sizes depending on cabinet size:

RefertoMinimumFilterAreatablestodeterminefilterarea requirement. NOTE: Filterscanalsobeinstalled elsewhere

in the duct system such as a central return.

Cabinet Width Filter Area

(in2)Qty Filter Size

(in) Dimension "A"

(in)

17 1/2 14.2

21 13.0

24 1/2 11.3

17 1/2 19.7

21 18.8

24 1/2 17.7

17 1/2 25.0

21 24.3

24 1/2 23.4

Counterflow Top Return

600 2 15 X 20 X 1

800 2 20 X 20 X 1

1000 2 25 X 20 X 1

Return Air

Optional

Access

Door

600 800 1000 1200 1400 1600 2000

0453__X* 415* 415* 480 576 --- --- ---

0704__X* --- --- 636* 636* 672 768

0905__X* --- --- --- 826* 826* 826* 960

1155__X* --- --- --- 875* 875* 875* 960

600 800 1000 1200 1400 1600 2000

0704__X* --- --- 634* 634* 672 768 ---

0905__X* --- --- --- 819* 819* 819* 960

115__X* --- --- --- 860* 860* 860* 960

Input__Airflow

UPFLOW

COOLING AIRFLOW REQUIREMENT (CFM)

COUNTERFLOW

COOLING AIRFLOW REQUIREMENT (CFM)

Input

Airflow

600 800 1000 1200 1400 1600 2000

0453__X* 207* 207* 240 288 --- --- ---

0704__X* --- --- 318* 318* 336 384 ---

0905__X* --- --- --- 413* 413* 413* 480

1155__X* --- --- --- 437* 437* 437* 480

600 800 1000 1200 1400 1600 2000

0704__X* --- --- 316* 316* 336 384 ---

0905__X* --- --- --- 409* 409* 409* 480

1155__X* --- --- --- 430* 430* 430* 480

Input__Airflow

UPFLOW

COOLING AIRFLOW REQUIREMENT (CFM)

COUNTERFLOW

COOLING AIRFLOW REQUIREMENT (CFM)

Input

Airflow

FURNACE SPECIFICATIONS

1. These furnaces are manufactured for natural gas operation. Optional kits are available for conversion to propane operation.

2. For elevations above 2000 feet the rating should be reduced by 4% for each 1000 feet above sea level. The furnace must not be derated, orifice changes should

only be made if necessary for altitude.

3. The total heat loss from the structure as expressed in TOTAL BTU/HR must be calculated by the manufacturers method or in accordance with the "A.S.H.R.A.E.

GUIDE" or "MANUAL J-LOAD CALCULATIONS" published by the AIR CONDITIONING CONTRACTORS OF AMERICA. The total heat loss calculated should be

equal to or less than the heating capacity. Output based on D.O.E. test procedures.

4. Minimum Circuit Ampacity calculated as: (1.25 x Circulator Blower Amps) + I.D. Blower Amps.

Unit specifications are subject to change without notice. ALWAYS refer to the units serial plate for the most up-to-date general and electrical information.

(1) Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.

(2) Maximum Overcurrent Protection Device: May use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.

(3) Off Heating - this fan delay timing is adjustable (90, 120, 150 and 180 seconds). Furnaces are shipped with 150 second off delay.

(4) See Installation Instructions for appropriate vent diameter, length and number of elbows.

(5) See Installation Instructions for appropriate combustion air pipe diameter, length and number of elbows.

MODEL GMV950453BX* GMV950704CX* GMV950905DX* GMV951155DX*

Btuh Input(US) High Fire 46,000 69,000 92,000 115,000

Output (US) High Fire 44,300 66,900 88,800 111,100

Btuh Input(US) Low Fire 32,000 48,000 64,000 80,000

Output (US) Low Fire 30,800 46,400 61,700 77,400

A.F.U.E. 95.0% 95.0% 95.0% 95.0%

Rated External Static (" w.c.) .10 - .50 .10 - .50 .10 - .50 .10 - .50

Temperature Rise (°F) 30 - 60 30 - 60 30 - 60 35 - 65

High Stage Pressure Switch Trip Point (" w.c.) -0.75 -0.75 -1.10 -1.10

Low Stage Pressure Switch Trip Point (" w.c.) -0.30 -0.30 -0.50 -0.50

Front Cover Pressure Switch Trip Point (" w.c) -0.10 -0.10 -0.10 -0.10

Blower Wheel (D"x W") 10 x 7 10 x 10 11 x 10 11 x 10

Blower Horsepower 1/2 3/4 1 1

Blower Speeds

Max CFM @ 0.5 E.S.P.

Power Supply 115-60-1 115-60-1 115-60-1 115-60-1

Minimum Circuit Ampacity (MCA) 10.4 12.8 14.6 14.6

Maximum Overcurrent Device 15 15 15 15

Transformer (VA) 40 40 40 40

Heat Anticipator (Amps) 0.7 0.7 0.7 0.7

Primary Limit Setting (°F) 145 155 145 150

AuxiliaryLimitSetting (°F) 150 190 180 200

Rollout Limit Setting (°F) 170 200 190 200

Fan Delay On Heating 30 secs. 30 secs. 30 secs. 30 secs.

Off Heating * 150 secs. 150 secs. 150 secs. 150 secs.

Fan Delay On Cooling 5 secs. 5 secs. 5 secs. 5 secs.

Off Cooling 45 secs. 45 secs. 45 secs. 45 secs.

Fan Delay On - Fan Only 5 secs. 5 secs. 5 secs. 5 secs.

Gas SupplyPressure (Natural/Propane) ("w.c.) 7/ 11 7 / 11 7 / 11 7 / 11

Manifold Pressure (Natural/Propane) High Stage ("w.c.) 3.5 / 10 3.5 / 10 3.5 /10 3.5 /10

Manifold Pressure (Natural/Propane) LowStage ("w.c.) 1.9 /6.0 1.9 /6.0 1.9 /6.0 1.9 / 6.0

Orifice Size (Natural/Propane) #43 / #55 #43 /#55 #43 / #55 #43 / #55

Number of Burners 2 3 4 5

Vent Connector Diameter (inches) 2 2 3 3

Combustion Air Connector Diameter (inches) 2 2 3 3

Shipping Weight (lbs.) 133 135 172 175

Refer to airflow charts on pages 16-18.

GMV95
