Goodman GMVM Operating instructions

1
96% Modulating Gas Furnaces
ACVM, AMVM, GCVM, GMVM
& Accessories
RS6612001r9
November 2013
This manual is to be used by qualified, professionally trained HVAC technicians only. Goodman does
not assume any responsibility for property damage or personal injury due to improper service
procedures or services performed by an unqualified person.
Copyright © 2011 - 2013 Goodman Manufacturing Company, L.P.
Service Instructions
is aregisteredtrademarkof MaytagCorporation orits relatedcompanies andis usedunder licenseto GoodmanCompany, L.P.,Houston,TX. All rightsreserved.

2
IMPORTANT INFORMATION
Prideandworkmanshipgointoeveryproducttoprovideourcustomerswithqualityproducts. Itispossible,however,
thatduringitslifetimeaproductmayrequireservice. Productsshouldbeservicedonlybyaqualifiedservicetechnician
whoisfamiliarwiththesafetyproceduresrequiredintherepairandwhoisequippedwiththeproper tools,parts,testing
instrumentsandtheappropriateservicemanual. REVIEWALLSERVICEINFORMATIONINTHEAPPROPRIATE
SERVICEMANUALBEFOREBEGINNINGREPAIRS.
IMPORTANT NOTICES FOR CONSUMERS AND SERVICERS
RECOGNIZESAFETYSYMBOLS,WORDSANDLABELS
WARNING
TO PREVENT THE RISK OF PROPERTY DAMAGE, PERSONAL INJURY, OR DEATH,
DO NOT STORE COMBUSTIBLE MATERIALS OR USE GASOLINE OR OTHER
FLAMMABLE LIQUIDS OR VAPORS IN THE VICINITY OF THIS APPLIANCE.
TABLEOFCONTENTS
WARNING
HIGH VOLTAGE
DISCONNECT ALL POWER BEFORE SERVICING OR
INSTALLING THIS UNIT. MULTIPLE POWER SOURCES MAY
BE PRESENT. FAILURE TO DO SO MAY CAUSE PROPERTY
DAMAGE, PERSONAL INJURY OR DEATH.
WARNING
GOODMAN WILL NOT BE RESPONSIBLE FOR ANY INJURY OR PROPERTY DAMAGE ARISING FROM IMPROPER SERVICE OR SERVICE PROCEDURES.
IF YOU INSTALL OR PERFORM SERVICE ON THIS UNIT, YOU ASSUME RESPONSIBILITY FOR ANY PERSONAL INJURY OR PROPERTY DAMAGE WHICH
MAY RESULT. MANY JURISDICTIONS REQUIRE A LICENSE TO INSTALL OR SERVICE HEATING AND AIR CONDITIONING EQUIPMENT.
IMPORTANTINFORMATION ........................... 2-3
PRODUCTIDENTIFICATION ........................ 4 - 7
ACCESSORIES........................................... 8 - 10
LIGHTINGINSTRUCTIONS ...............................11
PRODUCT DESIGN ...................................12 - 31
OPERATION ...............................................32 - 56
COMFORTNET™ SYSTEMS............................58
ABBREVIATIONS&DEFINITIONS ....................59
ABBREVIATIONS&OPERATION .....................60
SERVICE AND OPERATION......................61 - 62
OPERATIONAL CHECKS ..........................63 - 64
MAINTENANCE ..................................................65
SERVICING TABLE OF CONTENTS ................66
SERVICING .................................................67 - 74
TROUBLESHOOTING................................75 - 79
STATUS CODES...............................................80

3
IMPORTANT INFORMATION
Special Warning for Installation of Furnace or Air Handling Units in
Enclosed Areas such as Garages, Utility Rooms or Parking Areas
Carbon monoxide producing devices (such as an automobile, space
heater, gas water heater, etc.) should not be operated in enclosed areas
such as unventilated garages, utility rooms or parking areas because of
the danger of carbon monoxide (CO) poisoning resulting from the exhaust
emissions. If a furnace or air handler is installed in an enclosed area such
as a garage, utility room or parking area and a carbon monoxide producing
device is operated therein, there must be adequate, direct outside
ventilation.
This ventilation is necessary to avoid the danger of CO poisoning which
can occur if a carbon monoxide producing device continues to operate in
the enclosed area. Carbon monoxide emissions can be (re)circulated
throughout the structure if the furnace or air handler is operating in any
mode.
CO can cause serious illness including permanent brain damage or death.
To locate an authorized servicer, please consult your telephone book or the dealer from whom you purchased this
product. For further assistance, please contact:
CONSUMERINFORMATIONLINE
GOODMAN®BRANDPRODUCTS
TOLLFREE
1-877-254-4729(U.S.only)
email us at:
[email protected]
fax us at: [phone]
(Not a technical assistance line for dealers.)
CONSUMERINFORMATIONLINE
AMANA®BRANDPRODUCTS
TOLLFREE
1-877-254-4729(U.S.only)
email us at:
hac.consumer[email protected]
fax us at: [phone]
(Not a technical assistance line for dealers.)
Outside the U.S., call 1-713-861-2500.
(Not a technical assistance line for dealers.) Your telephone company will bill you for the call.
is aregistered trademarkof MaytagCorporation orits relatedcompanies andis usedunder licenseto GoodmanCompany, L.P.,Houston,TX. All rightsreserved.

PRODUCT IDENTIFICATION
4
Themodelandmanufacturingnumberareusedforpositiveidentificationofcomponentpartsusedinmanufacturing.
Pleaseusethesenumberswhenrequestingserviceorpartsinformation.
GMVM960603BXAA
SUPPLY TYPE
M:Upflow/Horizontal
C: Downflow/Horizontal
FURNACE TYPE
V: Variable-Speed
AFUE
96: 96%
NOMINAL INPUT
060: 60,000 Btuh
080: 80,000 Btuh
100: 100,000 Btuh
115: 115,000 Btuh
AIRFLOW
CAPABILITY
@ 0.5" ESP
3: 1200
4: 1600
5: 2000
CABINET
WIDTH
B: 17-1/2"
C: 21"
D: 24-1/2"
ADDITIONAL
FEATURES
N:Natural Gas
X: Low NOx
PRODUCT
TYPE:
G: Goodman
A: Amana®
Brand
MAJOR
REVISION
A: Initial Release
MINOR
REVISION
A: Initial Release
COMMUNICATION FEATURE
M: Modulating Furnace
4-Wire Communication Ready
isa registeredtrademark ofMaytag Corporationor itsrelated companiesand isused underlicensetoGoodmanCompany, L.P.,Houston, TX. Allrights reserved.

PRODUCT IDENTIFICATION
5
MODEL # MFG. # DESCRIPTION
ACVM96****** ACVM96******AA Amana® Brand 96% Modulating Gas Furnace, Downflow/Horizontal Left and Right, 40" tall,
Induced Draft, ClimateTalk™ communicating furnace. Modulating gas input from 35% -100% of
rated input. 4 wire serial ECM motor. Independent humidification with capable thermostat.
ACVM96****** ACVM96******BA Amana® Brand 96% Modulating Gas Furnace, same as AA revision above, but BA revision
models furnace cabinet Air Leakage must be <2.0%.
AMVM96****** AMVM96******AA Amana® Brand 96% Modulating Gas Furnace, Upflow/Horizontal Left or Right, 40" tall, Induced
Draft, ClimateTalk™ communicating furnace. Modulating gas input from 35% -100% of rated input.
4 wire serial ECM motor. Independent humidification with capable thermostat.
AMVM96****** AMVM96******BA Amana® Brand 96% Modulating Gas Furnace, same as AA revision above, but BA revision
models furnace cabinet Air Leakage must be <2.0%.
MODEL # MFG. # DESCRIPTION
GCVM96****** GCVM96******AA Goodman® Brand 96% Modulating Gas Furnace, Downflow/Horizontal Left and Right, 40" tall,
Induced Draft, ClimateTalk™ communicating furnace. Modulating gas input from 35% -100% of
rated input. 4 wire serial ECM motor. Independent humidification with capable thermostat.
GCVM96****** GCVM96******BA Goodman® Brand 96% Modulating Gas Furnace, same as the AA revision above but BA
models furnace cabinet Air Leakage must be <2.0%.
GMVM96****** GMVM96******AA Goodman® Brand 96% Modulating Gas Furnace, Upflow/Horizontal Left or Right, 40" tall,
Induced Draft, ClimateTalk™ communicating furnace. Modulating gas input from 35% -100% of
rated input. 4 wire serial ECM motor. Independent humidification with capable thermostat.
GMVM96****** GMVM96******BA Goodman® Brand 96% Modulating Gas Furnace, same as the AA revision above but BA
models furnace cabinet Air Leakage must be <2.0%.

PRODUCT IDENTIFICATION
6
MODEL # MFG # DESCRIPTION
AFE18-60A N/A
Fossil Fuel Kit. The AFE18-60Acontrol is designed for use where the indoorcoil is located above/downstream
of a gas or fossil fuel furnace when used with a heatpump.Itwill operate with single and two stage heat
pumps and single and two stage furnaces. The AFE18-60Acontrol will turn the heatpump unit off when the
furnace is turned on.An anti-shortcycle feature initiates a 3 minute timed off delaywhen the compressor goes
off.
AMU1620
AMU1625
AMU2020
AMU2025
GMU1620
GMU1625
GMU2020
GMU2025
P1251305F
P1251306F
P1251307F
P1251308F
N/A
Media Air Cleaner. For use with currentarchitectural greyGoodman® and Amana® Brand 96% variable speed,
modulating furnace models.The Amana (AMU*) and Goodman (GMU*) Media Air Cleaner is a high efficiency
airfiltration device designed to remove dirt, dust,pollen and othermicroscopicparticles from the air passing
through it.Flexible performance range up to 2,000 CFMcapacity. The air cleaner should be installed in the
system so that all the system air is circulated through the air cleaner.The air cleaner will onlyremove the
airborne contaminants delivered to it.Maximum performance is obtained when the system blower is setfor
continuous operation. Carbon filters (optional) are available.
ASAS-10
ASAS-11
ASAS-12
ASAS-18
P1251301F
P1251302F
P1251303F
P1251304F
Electronic Air Cleaner.For use with current architectural greyGoodman® and Amana® Brand 96% variable
speed, modulating furnace models. The High-EfficiencyElectronic Air Cleaner is designed to remove air
contaminants down to .01 microns.Carbon filters (optional) remove odors. Dual indicator lights show unit
operation ata glance. Electronic proving switch cycles the aircleanerOn/Offwith the system fan. Durable
powder-coatpaintfinishresists corrosion.
CFB17 P1228004F
Downflow Subbase Kit.For use with Goodman®,& Amana® Brand modulating furnace models.These kits
are available for the following furnace widths:17.5" wide (CFB17), 21"wide (CFB21) and 24"wide (CFB24).
The kits must be used to preventexcessive temperature from reaching combustible materials, ifthe furnace is
installed on a combustible floor.This subbase effectivelyseparated the furnace base and plenum from
combustible materials.To ensure safe installation, do notinstall the counterflow floor base directlyon
carpeting, tile, or other combustible material other than wood flooring.
CTK01 CTK01AA
Communicating Thermostat Kit- Digitallycommunicating touchscreen thermostat,a necessarypartofany
communicating system.Designed for use with compatible Amana® Brand or Goodman® Brand Air Handlers
or Furnaces and outdoor split AC or Heat Pump units.This thermostatsupports up to three stages ofheat,two
stages of cooling, dual fuel applications, dehumidification,filter maintenance reminders, outdoor temperature
displayand advanced menus including diagnostics. The CTK01AAkitincludes a communicating touchscreen
thermostat and sub base,230V-24V40va transformer,terminal blocks(2),wire jumpers,
mounting screws,installation manual and homeowner guide.
CTK01BA CTK01BA
Communicating Thermostat Kit- Digitallycommunicating touchscreen thermostat,a necessarypartofany
communicating system.Designed for use with compatible Amana® Brand or Goodman® Brand Air Handlers
or Furnaces and outdoor split AC or Heat Pump units.This thermostatsupports up to three stages ofheat,two
stages of cooling, dual fuel applications, dehumidification,filter maintenance reminders, outdoor temperature
displayand advanced menus including diagnostics. The CTK01BAkitincludes a communicating touchscreen
thermostat and sub base,terminal blocks(2),mounting screws, installation manual and homeowner guide.
CTK02** CTK02**
Communicating Thermostat Kit- Digitallycommunicating thermostat, a necessarypartof anycommunicating
system. Designed for use with compatible Amana® Brand or Goodman® Brand Air Handlers or Furnaces and
outdoor split AC or Heat Pump units. The CTK02** thermostat features full color, high definition display,
advanced programming options including humidification control & heat and cool maximum temperature
settings, a USB plug allowing dealers the abilityto insertpre-programmed operating parameters and dealer
information byuse of an online data entrysystem.
CTK03A* CTK03A*
Communicating Thermostat Kit- Digitallycommunicating touchscreen thermostat from Honeywell.Designed
for use with compatible Amana® Brand or Goodman® Brand Air Handlers or Furnaces and outdoor splitAC or
HeatPump units.The CTK03A* thermostat features full color high definition display, can be used with
RedLINK wireless accessories.

PRODUCT IDENTIFICATION
7
MODEL # MFG # DESCRIPTION
LPLP03 N/A LP Gas Low Pressure Kit. Designed for application on Goodman® and Amana® Brand's 80% and 90%
single-stage, two-stage and modulating furnaces converted to LP gas. The kit monitors gas line pressure with
a pressure switch and will open the circuit to the gas valve if the LP tank pressure gets low.
LPKMOD060UF N/A LP Conversion Kit For use with A/GMVM9603BX** furnace. The kit comes with a gas manifold equipped
with LP orifices and modulating LP gas valve. New burners designed for use with LP gas are also included.
LPKMOD080UF N/A LP Conversion Kit For use with A/GMVM960805CX** furnace. The kit comes with a gas manifold equipped
with LP orifices and modulating LP gas valve. New burners designed for use with LP gas are also included.
LPKMOD100UF N/A LP Conversion Kit For use with A/GMVM961005DX** furnace. The kit comes with a gas manifold equipped
with LP orifices and modulating LP gas valve. New burners designed for use with LP gas are also included.
LPKMOD115UF N/A LP Conversion Kit For use with A/GMVM961155DX** furnace. The kit comes with a gas manifold equipped
with LP orifices and modulating LP gas valve. New burners designed for use with LP gas are also included.
LPKMOD060CF N/A LP Conversion Kit For use with A/GCVM960604CX** furnace. The kit comes with a gas manifold equipped
with LP orifices and modulating LP gas valve. New burners designed for use with LP gas are also included.
LPKMOD080CF N/A LP Conversion Kit For use with A/GCVM960805DX** furnace. The kit comes with a gas manifold equipped
with LP orifices and modulating LP gas valve. New burners designed for use with LP gas are also included.
LPKMOD100CF N/A LP Conversion Kit For use with A/GCVM961005DX furnace. The kit comes with a gas manifoldequipped
with LP orifices and modulating LP gas valve. New burners designed for use with LP gas are also included.
RF000142 N/A Drain Coupling Kit For use when the drain/vent elbow has been removed ina horizontal left installation. This
kit prevents condensate from getting in the inducer and routes the condensate to a drain.
MODEL # MFG # DESCRIPTION
DCVK-20
DCVK-30
P1254001F
P1254002F
Concentric Vent Kit. For use with Amana® Brand Modulating furnace models. This kitis designed to allow
terminations of adirectventfurnace to be "concentrically" vented through a wall or roof.This kitallows a single
penetration to supportterminations for both the vent/flue and the combustion air intake pipe.The DCVK-20 (2")
and DCVK-30 (3") kits are certified for models listed above.See specification sheets on future models foruse
ofthe ventkit.
DEHUM1 P1227801F
Dehumidistat. For use with Goodman® & Amana® Brand two-stage variable speed modulating furnace
models.Wall mounted,24 volt humiditycontrol available as a Dehumidistatused to reducethe airflow in the air
conditioning mode when necessaryto lower the humidityin an occupied home to preventdew build-up
associated with high humiditylevels.This control features a moisture-sensitive nylon element andalso
provides positive ON-OFFsettings for manual operation.The control is a normallyclosed switch thatopens on
humidityrise causing the blower to switch to a lower speed to control the humiditywithin the structure.
EFR01 P1221001
P1221002F
External Filter Rack Kit.For use with Goodman®and Amana®Brand 96% upflow,variable speed *MVM
modulating gas furnaces.This kitis intended to provide a location,external to the furnace casing for installation
of a permanent filter. The rack is mounted over the indoor air blower compartment area of either side panel,
and provide filter retention as well as a location for attaching return airductwork.
0170K00000S N/A Side Wall Only Concentric Vent Kit.For use with 96% modulating furnace models. This kit is to be used with
2"- 3"ventsystems. The ventkitmustterminate outside the structure. This kitis NOTintended for use with
single pipe (indirectvent) installations.
0170K00001S N/A Side Wall Only Concentric Vent Kit.For use with 96% modulating furnace models. This kit is to be used with
2"ventsystems. The ventkitmust terminate outside the structure. This kitis NOTintended for use with single
pipe (indirect vent) installation

ACCESSORIES
8
MODEL
NUMBER AFE180-60A AMU / GMU ASAS / GSAS CFB17 CFB21 CFB24 CTK01* CTK02** CTK03AA
Description Fossil Fuel
Kit Media Air Cleaners Electronic Air Cleaner
Downflow
Subbase
17 . 5 "
Downflow
Subbase
21"
Downflow
Subbase
24.5"
Com.
Thermostat
Kit
Com
Thermostat
Kit
-M odulating,
High Def
Com
Thermostat
Kit
-M odulating,
High Def
AMVM960603BX** X X X X X X
AMVM960805CX** X X X X X X
AMVM961005DX** X X X X X X
ACVM960604CX** X X X X X X X
ACVM960805DX** X X X X X X X
Not used in this application
MODEL
NUMBER 0170K00000S 0170K00001S DCVK-20 DCVK-30 DEHUM1 EFR01
LPKMOD-
06/08/11UF
LPKMOD-
06/08/11CF
Description Concentric Side Wall
Vent Kit (3")
Concentric
Side Wall
Vent Kit (2")
Concentric
Vent Kit
(2")
Concentric
Vent Kit
(3") Dehumidistat External
Filter
Rack
Propane
Gas
Conversion
Kit
AMVM960603BX** X X XXXXX
AMVM960805CX** X X X X X X
AMVM961005DX** X X X X X X
ACVM960604CX** X X XXXXX
ACVM960805DX** X X XXXXX
Not used in this application
AMANA®BRAND Furnace Accessories

ACCESSORIES
9
MODEL
NUMBER AFE180-60A AMU / GMU ASAS / GSAS CFB17 CFB21 CFB24 CTK01* CTK02** CTK03AA
Description Fossil Fuel
Kit Media Air Cleaners Electronic Air Cleaner
Downflow
Subbase
17 .5 "
Downflow
Subbase
21"
Downflow
Subbase
24.5"
Com.
Thermostat
Kit
Com
Thermostat
Kit
-Modulating,
Hi
g
h Def
Com
Thermostat
Kit
-Modulating,
Hi
g
h Def
GMVM960603BX** X X X X X X
GMVM960805CX** X X X X X X
GMVM961005DX**XXX XXX
GMVM961155DX** X X X X X X
GCVM960604CX** X X X X X X X
GCVM960805DX** X X X X X X X
GCVM961005DX**XXX XXXX
Not used in this application
MODEL
NUMBER 0170K00000S 0170K00001S DCVK-20 DCVK-30 DEHUM1 EFR01
LPKM OD-
06/08/11UF
LPKM OD-
06/08/11CF
RF000142
Description Concentric Side Wall
Vent Kit (3")
Concentric
Side Wall
Vent Kit (2")
Concentric
Vent Kit
(2")
Concentric
Vent Kit
(3") Dehumidistat External
Filter
Rack
Propane
Gas
Conversion
Kit
Drain Kit
GMVM960603BX**XXXXXXXX
GMVM960805CX**XX XXXXX
GMVM961005DX**XX XXXXX
GMVM961155DX**XX XXXXX
GCVM960604CX**XXXXXXXX
GCVM960805DX**XXXXXXXX
GCVM961005DX**XX XXXXX
Not used in this application
GOODMAN®BRAND Furnace Accessories

ACCESSORIES
10
SIDEWALLVENTKIT(0170K00000S)
Vertical Installation
Horizontal Installation
This side wall only vent kit #0170K00000S is to be used
with 2” - 3” vent systems. This kit is NOT intended for use
withsinglepipe(indirect vent) installations.
The vent kit must terminate outside the structure and may
beinstalledwiththeintakeandexhaustpipeslocatedside-
by-sideorwithonepipe above the other.
See the section in this manual under "Vent Flue and Com-
bustionAirPipeTerminations"formoreinformationorcon-
sulttheInstallationInstructions(IO-635).
SIDEWALLVENTKIT(0170K00001S)
This side wall only vent kit #0170K00001S is to be used
with2”ventsystems. This kit isNOT intended for use with
singlepipe(indirectvent)installations.
Vent
Maintain 12" (18" for Canada)
minimum clearance above highest
anticipated snow level. Maximum of
24" above roof.
Combustion Air
Roof Boot/Flashing
(Field Supplied)
Support (Field Supplied)
45 Elbow
(Field Supplied)
Combustion Air
Vent
CONCENTRIC VENTCONVERSION KIT( DCVK-20 

DCVK-30)
DCVK
(Vertical Installation)
DCVK
(Horizontal Installation)
TheDCVK-20(2")ortheDCVK-30(3")isaconcentricvent
kit approved with furnaces listed in this manual.
Thisconcentricventkitallowsfor vertical or horizontal vent
termination. Theillustrationsgiveabriefviewofthe kit and
its application.
Vent
Combustion Air
Flush to
1" maximum
45 Elbow
(Field Supplied)
Combustion Air
Vent Strap
(Field Supplied)
EXTERNALFILTER RACK (EFR01 )
Used on 96% Upflow Modulating Furnaces
BLOWER DECK
SCREWS
SLOTS IN FILTER
CLEAR SCREWS
ON UNIT
FRONT
OF UNIT
RETURN AIR
CUTOUT AREA LOWER EDGE
SCREW
FILTER RACK ASSEMBLY
(FACE FILTER OPENING
TOWARDS FRONT
OF UNIT)
UNIT SIDE
PANEL
BASE
OF UNIT
See the section in this manual under "Vent Flue and Com-
bustionAirPipeTerminations"for more information or con-
sulttheInstallationandOperating Instructions (IO-619*).
The vent kit must terminate outside the structure and may
beinstalledwiththe intake and exhaust pipes located side-
by-sideorwithonepipe above the other.
See the section in this manual under "Vent Flue and Com-
bustionAirPipeTerminations"for more information or con-
sulttheInstallationInstructions(IO-805).
