Goodman SSZ 14 SEER User manual

SSZ 14 SEER
Split System Heat Pumps
•RefertoServiceManualRS6200005forinstallation,operation,andtroubleshootinginformation.
•Allsafetyinformation must be followedasprovided in the ServiceManual.
•RefertotheappropriatePartsCatalog for part number information.
•Models listed on page 3.
RT6213005r7
November2011
Copyright © 2006 - 2007, 2009-2011 Goodman Manufacturing Company, L.P.
®TECHNICAL MANUTECHNICAL MANU
TECHNICAL MANUTECHNICAL MANU
TECHNICAL MANUALAL
ALAL
AL
This manual is to be used by qualified, professionally trained HVAC technicians only. Goodman does
not assume any responsibility for property damage or personal injury due to improper service
procedures or services performed by an unqualified person.

PRODUCT IDENTIFICATION
2
The model number is used for positive identification of component parts used in manufacturing. Please use this number
whenrequestingserviceorpartsinformation.
WARNING
WARNING HIGH VOLTAGE!
Disconnect ALL power before servicing or installing this unit. Multiple power
sources may be present. Failure to do so may cause property damage, personal
injury or death.
Installation and repair of this unit
should be performed ONLY by in-
dividuals meeting (at a minimum)
the requirements of an "entry level technician", at a
minimum, as specified by the Air-Conditioning, Heating,
and Refrigeration Institute (AHRI). Attempting to install
or repair this unit without such background may result
in product damage, personal injury or death.
Goodman will not be responsible
for any injury or property damage
arising from improper service or service procedures. If
you install or perform service on this unit, you assume
responsibility for any personal injury or property damage
which may result. Many jurisdictions require a license to
install or service heating and air conditioning equipment.
WARNING
WARNING WARNING
WARNING
S S Z 14 036 1 A A
Major Revision
SEER
SEER Rating
Nominal Capacity
Electrical
1:208/230V/60Hz/1ph
3:208/230V/60Hz/3ph
4:460V/60Hz/3ph
Product Family
S: Split System
Product Type
Brand Name
018: 1.5 tons
024: 2 tons
030: 2.5 tons
036: 3 tons
042: 3.5 tons
048: 4 tons
060: 5 tons
G:Goodman
(Standard Feature Set Models)
S:Goodman
(High Feature Set Models)
C:CondenserR-22
X:CondenserR-410A
H:HeatPumpR-22
Z:HeatPumpR-410A
A:InitialRelease
MinorRevision
A:InitialRelease

PRODUCT IDENTIFICATION
3
The United States Environmental Protection Agency (“EPA”) has issued various regulations re-
garding the introduction and disposal of refrigerants introduced into this unit. Failure to follow
these regulations may harm the environment and can lead to the imposition of substantial fines.
These regulations may vary by jurisdiction. Should questions arise, contact your local EPA office.
WARNING
WARNING
Do not connect or use any device
that is not design certified by
Goodman for use with this unit.
Serious property damage, personal injury, reduced unit
performance and/or hazardous conditions may result
from the use of such non-approved devices.
WARNING
WARNING To prevent the risk of property
damage, personal injury, or death,
do not store combustible materials or use gasoline or
other flammable liquids or vapors in the vicinity of this
appliance.
WARNING
WARNING
The model number is used for positive identification of component parts used in manufacturing. Please use this number
whenrequestingserviceorpartsinformation.
* Indicates minor revision & is not used for order entry or inventory management
SSZ140181A*
SSZ140241A*
SSZ140301A*
SSZ140361A*
SSZ140421A*
SSZ140481A*
SSZ140601A*
SSZ140361B*

PRODUCT DESIGN
4
SSZ14modelsareavailablein 1 1/2 through 5 tonsizesand
use R-410A refrigerant. They are designed for 208/230 volt
singlephaseapplications.
The condenser air is pulled through the condenser coil by a
direct drive propeller fan. This condenser air is then dis-
charged out of the top of the cabinet.
These units are designed for free air discharge, so no addi-
tional resistance like duct work shall be attached.
The suction and liquid line connections on present models
areofthesweattypeforfieldpipingwithrefrigeranttypecop-
per. Front seating valves are factory installed to accept the
fieldruncopper. The total refrigerantcharge for a normal in-
stallationisfactoryinstalledinthecondensing unit. SSZunits
are charged for the matching evaporator coil and a 15 foot
refrigerantlineset.
Systems should be properly sized by heat gain and loss
calculations made according to methods of the Air Condi-
tioning Contractors Association (ACCA) or equivalent. It is
the contractors responsibility to ensure the system has ad-
equate capacity to heat or cool the conditioned space.
SSZmodelsusehigh-efficiencyCopeland®scroll "Ultratech"
compressorswhichare specifically desgined for R-410Are-
frigerant.Thereareanumberofdesigncharacteristicswhich
aredifferentfromthescrollcomparedtothetraditionalrecip-
rocatingcompressor.
"Ultratech" Series scroll compressors with Copeland®
ComfortAlert diagnositics will not have a discharge thermo-
stat. Some of the early model scroll compressors required
dischargethermostats.
Due to their design Scroll compressors are inherently more
tolerantofsmall quantities of liquid refrigerant.
NOTE: Eventhoughthecompressorsectionof aScrollcom-
pressor is more tolerant of liquid refrigerant, continued
floodback or flooded start conditions may wash oil from the
bearingsurfacescausing premature bearing failure.
"Ultratech" Series scroll compressors use "POE" or
polyolesteroil whichisNOT compatiblewithmineraloilbased
lubricants like 3GS. "POE" oil must be used if additional oil
isrequired.
WARNING
To avoid possible injury, explosion or death, practice
safe handling of refrigerants.
Operating pressures and amp draws may differ from stan-
dardreciprocatingand/orscroll compressors. This informa-
tion may be found in the "Cooling Performance Data" sec-
tion.
This unit is for outdoor installation only. Refer to minimum
figure for clearances from the sides of the unit to full walls
andother objects.
NOTE: This unit cannot be completely enclosed. At least
one side must be unrestricted.
Theseclearanceswillhelpavoidairrecirculation.Ifinstalling
two or more units at the same location, allow at least 24
inches between units. If only one side is restricted (for ex-
ample, against the outside wall of a house), the unit may be
placed as close as 8" to that one wall.
DO NOT locate the unit:
* Directlyundera vent termination fora gas appliance.
* Within 3 feet of a clothes drier vent
* Wheretherefreezingofdefrostwaterwould create
ahazard
* Where water may rise into the unit.
OK!
OK!
AA AAA
A
CC
CCOK!
OK!
OK!
OK!
NOT
RECOMMENDED
AA
AA AA
AA
AA
B B B
B
Model Type A B C AA
Residential 10" 10" 18" 20"
Light Commercial 12" 12" 18" 24"
Minimum Airflow Clearance
Model Dimensions - W x D x H
SSZ140181A* 29 x 29 x 34¼
SSZ140241A* 29 x 29 x 38¼
SSZ140301A* 29 x 29 x 38¼
SSZ140361A* 35½ x 35½ x 38¼
SSZ140421A* 35½ x 35½ x 38¼
SSZ140481A* 35½ x 35½ x 38¼
SSZ140601A* 35½ x 35½ x 38¼
SSZ140361B* 29 x 29 x 38¼

HEAT PUMP SPECIFICATIONS
5
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit breakers and
wires in accordance with all national and/or local electrical codes. Use copper wire only.
Unit specifications are subject to change without notice. ALWAYS refer to the unit's serial plate for the most up-to-date general
and electrical information.
SSZ140[18,30,342,48,60]1AA-AE;SSZ140241AA-AH;SSZ140361AA-AG
* Up to 24' in equivalent line length
(1) Wire size should be determined in accordance with National Electrical Codes; extensive wire runs will require larger wire sizes.
(2) Maximum Overcurrent Protection Device: MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
NOTES:
• Always check the S & R plate for electrical data on the unit being installed.
• Installer will need to supply 7/8" to 1-1/8" adapters for suction line connections (4 & 5 ton units).
• Installer will need to supply 3/4" to 7/8" adapters for suction line connections (3 ton unit).
• Unit is charged with refrigerant for 15' of 3/8" liquid line. System charge must be adjusted per Installation Instructions Final Charge
Procedure.
• Installation of these units requires the specified TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED BY THE
OUTDOORUNIT,NOTTHEINDOORCOIL.
SSZ140181AA-AE SSZ140241AA-AH SSZ140301AA-AE
SSZ140361AA-AG
SSZ140421AA-AE SSZ140481AA-AE SSZ140601AA-AE
Cooling Capacity, BTUH 18,000 24,000 30,000 36,000 42,000 48,000 60,000
Compressor
R.L. Amps 8.97 12.82 14.10 16.67 17.95 19.87 26.41
L.R. Amps 48.0 58.3 73.0 79.0 112.0 109.0 130.0
Low Pressure Switch
Open 22 PSIG 22 PSIG 22 PSIG 22 PSIG 22 PSIG 22 PSIG 22 PSIG
Close 50 PSIG 50 PSIG 50 PSIG 50 PSIG 50 PSIG 50 PSIG 50 PSIG
High Pressure Switch
Open 610 PSIG 610 PSIG 610 PSIG 610 PSIG 610 PSIG 610 PSIG 610 PSIG
Close 420 PSIG 420 PSIG 420 PSIG 420 PSIG 420 PSIG 420 PSIG 420 PSIG
Condenser Fan Motor
Horsepower 1/12 1/6 1/6 1/4 1/4 1/4 1/4
F.L. Amps 0.6 1.1 1.1 1.5 1.5 1.5 1.5
Liquid Line, Inches O.D.* 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8"
Suction Line, Inches O.D.* 3/4" 3/4" 3/4" 7/8" 7/8" 7/8" 7/8"
Refrigerant Charge 143.0 163.0 188.0 213.0 213.0 273.0 278.0
Power Supply 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1
Minimum Circuit Ampacity(1) 11.80 17.10 18.73 22.40 24.00 26.40 34.60
Maximum Overcurrent Device(2) 20 25 30 30 40 40 60
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight 199 207 219 242 242 266 280

HEAT PUMP SPECIFICATIONS
6
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/
circuit breakers and wires in accordance with all national and/or local electrical codes. Use copper wire only.
SSZ140[18,30]1AF; SSZ140241AJ; SSZ140361AH
* Up to 24' in equivalent line length
(1) Wire size should be determined in accordance with National Electrical Codes; extensive wire runs will require larger wire sizes.
(2) Maximum Overcurrent Protection Device: MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
NOTES:
• Always check the S & R plate for electrical data on the unit being installed.
• Installer will need to supply 7/8" to 1-1/8" adapters for suction line connections (4 & 5 ton units).
• Installer will need to supply 3/4" to 7/8" adapters for suction line connections (3 ton unit).
• Unit is charged with refrigerant for 15' of 3/8" liquid line. System charge must be adjusted per Installation Instructions Final Charge
Procedure.
• Installation of these units requires the specified TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED BY THE
OUTDOORUNIT,NOTTHEINDOORCOIL.
SSZ140181AF SSZ140241AJ SSZ140301AF
SSZ140361AH
Cooling Capacity,BTUH 18,000 24,000 30,000 36,000
Compressor
R.L. Amps 9.0 12.82 14.10 16.67
L.R. Amps 48.0 58.3 73.0 79.0
Low Pressure Switch
Open 22 PSIG 22 PSIG 22 PSIG 22 PSIG
Close 50 PSIG 50 PSIG 50 PSIG 50 PSIG
High Pressure Switch
Open 610 PSIG 610 PSIG 610 PSIG 610 PSIG
Close 420 PSIG 420 PSIG 420 PSIG 420 PSIG
Condenser Fan Motor
Horsepower 1/12 1/6 1/6 1/4
F.L.Amps 0.6 1.1 1.0 1.5
Liquid Line, Inches O.D.* 3/8" 3/8" 3/8" 3/8"
Suction Line, Inches O.D.* 3/4" 3/4" 3/4" 7/8"
Refrigerant Charge 140.0 160.0 185.0 210.0
Power Supply 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1
Minimum CircuitAmpacity(1) 11.90 17.10 18.60 22.40
Maximum Overcurrent Device(2) 20 25 30 30
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight 199 207 219 242

HEAT PUMP SPECIFICATIONS
7
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit breakers and
wires in accordance with all national and/or local electrical codes. Use copper wire only.
Unit specifications are subject to change without notice. ALWAYS refer to the unit's serial plate for the most up-to-date general
and electrical information.
* Up to 24' in equivalent line length
(1) Wire size should be determined in accordance with National Electrical Codes; extensive wire runs will require larger wire sizes.
(2) Maximum Overcurrent Protection Device: MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
NOTES:
• Always check the S & R plate for electrical data on the unit being installed.
• Installer will need to supply 7/8" to 1-1/8" adapters for suction line connections (4 & 5 ton units).
• Installer will need to supply 3/4" to 7/8" adapters for suction line connections (3 ton unit).
• Unit is charged with refrigerant for 15' of 3/8" liquid line. System charge must be adjusted per Installation Instructions Final Charge
Procedure.
• Installation of these units requires the specified TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED BY THE
OUTDOORUNIT,NOTTHEINDOORCOIL.
SSZ140[42,48,60]1AF; SSZ140481AG
SSZ140421AF SSZ140481AF
SSZ140481AG
SSZ140601AF
Cooling Capacity,BTUH 42,000 48,000 48,000 60,000
Compressor
R.L. Amps 17.95 19.9 19.9 26.41
L.R. Amps 112.0 109.0 109.0 130.0
Low Pressure Switch
Open 22 PSIG 22 PSIG 22 PSIG 22 PSIG
Close 50 PSIG 50 PSIG 50 PSIG 50 PSIG
High Pressure Switch
Open 610 PSIG 610 PSIG 610 PSIG 610 PSIG
Close 420 PSIG 420 PSIG 420 PSIG 420 PSIG
Condenser Fan Motor
Horsepower 1/4 1/4 1/4 1/4
F.L.Amps 1.51.51.51.5
Liquid Line, Inches O.D.* 3/8" 3/8" 3/8" 3/8"
Suction Line,Inches O.D.* 7/8" 7/8" 7/8" 7/8"
Refrigerant Charge 210.0 270.0 270.0 275.0
Power Supply 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1
Minimum CircuitAmpacity(1) 23.90 26.40 26.40 34.50
Maximum Overcurrent Device(2) 40 40 45 60
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight 242 266 266 280

HEAT PUMP SPECIFICATIONS
8
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/
circuit breakers and wires in accordance with all national and/or local electrical codes. Use copper wire only.
SSZ140361B*
SSZ140361B*
Cooling Capacity, BTUH 35,000
Compressor
R.L. Amps 14.1
L.R. Amps 77.0
LowPressure Switch
Open 22 PSIG
Close 50 PSIG
High Pressure Switch
Open 610 PSIG
Close 420 PSIG
Condenser Fan Motor
Horsepower 1/4
F.L.Amps 1.5
Liquid Line, Inches O.D.* 3/8"
Suction Line, Inches O.D.* 7/8"
Refrigerant Charge 186.0
Power Supply 208/230-60-1
Minimum Circuit Ampacity(1) 19.1
Maximum Overcurrent Device(2) 30
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4
Approximate Shipping Weight 215
* Up to 24' in equivalent line length
(1) Wire size should be determined in accordance with National Electrical Codes; extensive wire runs will require larger wire sizes.
(2) Maximum Overcurrent Protection Device: MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
NOTES:
• Always check the S & R plate for electrical data on the unit being installed.
• Installer will need to supply 7/8" to 1-1/8" adapters for suction line connections (4 & 5 ton units).
• Installer will need to supply 3/4" to 7/8" adapters for suction line connections (3 ton unit).
• Unit is charged with refrigerant for 15' of 3/8" liquid line. System charge must be adjusted per Installation Instructions Final Charge
Procedure.
• Installation of these units requires the specified TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED BY THE
OUTDOORUNIT,NOTTHEINDOORCOIL.

9
COOLING PERFORMANCE DATA SSZ140181A*
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: SSZ140181A* / CA*F3131*6A* +TXV / MBR800**-1
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
MBh 17.6 18.3 20.0 - 17.2 17.9 19.6 - 16.8 17.4 19.1 - 16.4 17.0 18.6 - 15.6 16.2 17.7 - 14.4 15.0 16.4 -
S/T 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.78 0.65 0.45 - 0.81 0.67 0.47 - 0.84 0.70 0.49 - 0.85 0.71 0.49 -
Delta T 18 15 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 15 12 - 17 14 11 -
675 KW 1.17 1.19 1.23 - 1.25 1.28 1.32 - 1.33 1.36 1.40 - 1.40 1.43 1.47 - 1.45 1.48 1.53 - 1.50 1.53 1.58 -
AMPS 4.2 4.3 4.4 - 4.5 4.6 4.8 - 4.9 5.0 5.2 - 5.3 5.4 5.6 - 5.6 5.7 5.9 - 5.9 6.1 6.3 -
HIPR 213 229 242 - 239 257 271 - 271 292 308 - 309 333 351 - 348 374 395 - 384 413 436 -
LO PR 107 113 124 - 113 120 131 - 117 124 136 - 123 131 143 - 129 137 150 - 133 142 155 -
MBh 17.1 17.7 19.4 - 16.7 17.3 19.0 - 16.3 16.9 18.5 - 15.9 16.5 18.1 - 15.1 15.7 17.2 - 14.0 14.5 15.9 -
S/T 0.70 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.62 0.43 - 0.77 0.64 0.45 - 0.80 0.67 0.46 - 0.81 0.67 0.47 -
Delta T 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 17 15 11 -
70 600 KW 1.16 1.18 1.22 - 1.24 1.27 1.31 - 1.32 1.35 1.39 - 1.38 1.41 1.46 - 1.44 1.47 1.52 - 1.49 1.52 1.57 -
AMPS 4.2 4.3 4.4 - 4.5 4.6 4.8 - 4.9 5.0 5.2 - 5.2 5.3 5.5 - 5.5 5.7 5.9 - 5.9 6.0 6.2 -
HIPR 210 227 239 - 236 254 268 - 269 289 305 - 306 329 348 - 344 370 391 - 380 409 432 -
LO PR 105 112 122 - 111 119 129 - 116 123 134 - 122 129 141 - 127 136 148 - 132 140 153 -
MBh 15.8 16.4 17.9 - 15.4 16.0 17.5 - 15.1 15.6 17.1 - 14.7 15.2 16.7 - 14.0 14.5 15.9 - 12.9 13.4 14.7 -
S/T 0.68 0.57 0.39 - 0.70 0.59 0.41 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.77 0.64 0.45 - 0.78 0.65 0.45 -
Delta T 19 16 12 - 19 16 12 - 19 16 12 - 19 17 13 - 19 16 12 - 18 15 12 -
525 KW 1.13 1.15 1.19 - 1.21 1.24 1.28 - 1.29 1.31 1.35 - 1.35 1.38 1.42 - 1.41 1.44 1.48 - 1.45 1.48 1.53 -
AMPS 4.1 4.2 4.3 - 4.4 4.5 4.6 - 4.7 4.9 5.0 - 5.1 5.2 5.4 - 5.4 5.5 5.7 - 5.7 5.8 6.0 -
HIPR 204 220 232 - 229 247 260 - 261 280 296 - 297 319 337 - 334 359 379 - 369 397 419 -
LO PR 102 109 119 - 108 115 126 - 112 119 130 - 118 126 137 - 124 132 144 - 128 136 149 -
MBh 17.9 18.5 20.0 21.5 17.5 18.0 19.5 21.0 17.1 17.6 19.1 20.5 16.7 17.2 18.6 20.0 15.9 16.3 17.7 19.0 14.7 15.1 16.4 17.6
S/T 0.84 0.75 0.57 0.36 0.87 0.78 0.59 0.38 0.89 0.80 0.60 0.39 0.92 0.82 0.62 0.40 0.95 0.85 0.65 0.42 0.96 0.86 0.65 0.42
DeltaT20191511211916112119161121 19 16 11 21 19 16 11 19 18 15 10
675 KW 1.18 1.20 1.24 1.27 1.26 1.29 1.33 1.37 1.34 1.37 1.41 1.46 1.41 1.44 1.48 1.53 1.46 1.50 1.54 1.59 1.51 1.55 1.60 1.65
AMPS 4.2 4.3 4.5 4.6 4.6 4.7 4.8 5.0 5.0 5.1 5.2 5.4 5.3 5.4 5.6 5.8 5.6 5.8 6.0 6.2 6.0 6.1 6.3 6.5
HIPR 215 231 244 255 241 259 274 286 274 295 311 325 312 336 355 370 351 378 399 416 388 418 441 460
LO PR 108 114 125 133 114 121 132 141 118 126 137 146 124 132 144 154 130 138 151 161 135 143 156 166
MBh 17.4 17.9 19.4 20.8 17.0 17.5 19.0 20.3 16.6 17.1 18.5 19.9 16.2 16.7 18.1 19.4 15.4 15.8 17.2 18.4 14.3 14.7 15.9 17.1
S/T 0.80 0.71 0.54 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.57 0.37 0.88 0.78 0.59 0.38 0.91 0.81 0.62 0.40 0.92 0.82 0.62 0.40
DeltaT21201611222016112220161122 20 16 11 21 20 16 11 20 18 15 10
75 600 KW 1.17 1.19 1.23 1.26 1.25 1.28 1.32 1.36 1.33 1.36 1.40 1.44 1.40 1.43 1.47 1.52 1.45 1.48 1.53 1.58 1.50 1.53 1.58 1.64
AMPS 4.2 4.3 4.4 4.6 4.5 4.6 4.8 5.0 4.9 5.0 5.2 5.4 5.3 5.4 5.6 5.8 5.6 5.7 5.9 6.1 5.9 6.1 6.3 6.5
HIPR 213 229 242 252 239 257 271 283 271 292 308 322 309 333 351 366 348 374 395 412 384 413 437 455
LO PR 107 113 124 132 113 120 131 139 117 124 136 145 123 131 143 152 129 137 150 159 133 142 155 165
MBh 16.1 16.5 17.9 19.2 15.7 16.2 17.5 18.8 15.3 15.8 17.1 18.3 15.0 15.4 16.7 17.9 14.2 14.6 15.8 17.0 13.2 13.5 14.7 15.7
S/T 0.77 0.69 0.52 0.34 0.80 0.71 0.54 0.35 0.82 0.73 0.55 0.36 0.84 0.76 0.57 0.37 0.88 0.78 0.59 0.38 0.88 0.79 0.60 0.39
DeltaT22201611222017112220171122 20 17 12 22 20 16 11 20 19 15 11
525 KW 1.14 1.16 1.20 1.24 1.22 1.25 1.29 1.33 1.30 1.32 1.37 1.41 1.36 1.39 1.44 1.48 1.42 1.45 1.49 1.54 1.47 1.50 1.54 1.60
AMPS 4.1 4.2 4.3 4.5 4.4 4.5 4.7 4.8 4.8 4.9 5.1 5.2 5.1 5.2 5.4 5.6 5.4 5.6 5.7 6.0 5.7 5.9 6.1 6.3
HIPR 206 222 234 244 231 249 263 274 263 283 299 312 300 323 341 355 337 363 383 400 373 401 423 442
LO PR 103 110 120 128 109 116 127 135 113 121 132 140 119 127 138 147 125 133 145 155 129 137 150 160
Shaded area is ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total systempow er AMPS=outdoor unit amps (comp.+fan

10
COOLING PERFORMANCE DATA SSZ140181A*
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: SSZ140181A* / CA*F3131*6A* +TXV / MBR800**-1 Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
MBh 18.3 18.7 19.9 21.3 17.8 18.2 19.5 20.8 17.4 17.8 19.0 20.3 17.0 17.4 18.5 19.8 16.1 16.5 17.6 18.8 14.9 15.3 16.3 17.4
S/T 0.92 0.86 0.70 0.52 0.95 0.89 0.73 0.54 1.00 0.92 0.75 0.56 1.00 0.94 0.77 0.57 1.00 1.00 0.80 0.60 1.00 1.00 0.80 0.60
DeltaT23221915232219152422191523 22 19 162222191520211814
675 KW 1.19 1.21 1.25 1.28 1.27 1.30 1.34 1.38 1.35 1.38 1.42 1.47 1.42 1.45 1.50 1.54 1.48 1.51 1.56 1.61 1.53 1.56 1.61 1.66
AMPS 4.3 4.4 4.5 4.7 4.6 4.7 4.9 5.1 5.0 5.1 5.3 5.5 5.3 5.5 5.7 5.9 5.7 5.8 6.0 6.2 6.0 6.2 6.4 6.6
HIPR 217 233 247 257 243 262 277 288 277 298 315 328 315 339 358 374 355 382 403 420 392 422 445 465
LO PR 109 116 126 134 115 122 133 142 119 127 139 148 125 133 146 155 131 140 153 162 136 145 158 168
MBh 17.7 18.1 19.4 20.7 17.3 17.7 18.9 20.2 16.9 17.3 18.5 19.7 16.5 16.8 18.0 19.2 15.7 16.0 17.1 18.3 14.5 14.8 15.8 16.9
S/T 0.88 0.82 0.67 0.50 0.91 0.85 0.69 0.52 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 1.00 0.94 0.76 0.57 1.00 0.94 0.77 0.57
DeltaT24232016242320162423201624 23 20 16 24 23 20 16 22 21 19 15
80 600 KW 1.18 1.20 1.24 1.27 1.26 1.29 1.33 1.37 1.34 1.37 1.41 1.46 1.41 1.44 1.48 1.53 1.46 1.50 1.54 1.59 1.51 1.55 1.60 1.65
AMPS 4.2 4.3 4.5 4.6 4.6 4.7 4.8 5.0 5.0 5.1 5.3 5.4 5.3 5.4 5.6 5.8 5.6 5.8 6.0 6.2 6.0 6.1 6.3 6.5
HIPR 215 231 244 255 241 259 274 286 274 295 311 325 312 336 355 370 351 378 399 416 388 418 441 460
LO PR 108 114 125 133 114 121 132 141 118 126 137 146 124 132 144 154 130 138 151 161 135 143 156 166
MBh 16.4 16.7 17.9 19.1 16.0 16.3 17.4 18.6 15.6 15.9 17.0 18.2 15.2 15.6 16.6 17.8 14.5 14.8 15.8 16.9 13.4 13.7 14.6 15.6
S/T 0.84 0.79 0.64 0.48 0.88 0.82 0.67 0.50 0.90 0.84 0.69 0.51 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 0.97 0.91 0.74 0.55
DeltaT24232016242320162523201625 24 21 162423201623221915
525 KW 1.15 1.17 1.21 1.24 1.23 1.26 1.30 1.34 1.31 1.34 1.38 1.42 1.37 1.40 1.45 1.49 1.43 1.46 1.51 1.56 1.48 1.51 1.56 1.61
AMPS 4.1 4.2 4.4 4.5 4.5 4.6 4.7 4.9 4.8 4.9 5.1 5.3 5.2 5.3 5.5 5.7 5.5 5.6 5.8 6.0 5.8 5.9 6.1 6.4
HIPR 208 224 237 247 234 252 266 277 266 286 302 315 303 326 344 359 341 367 387 404 376 405 428 446
LO PR 104 111 121 129 110 117 128 136 115 122 133 142 120 128 140 149 126 134 147 156 131 139 152 161
MBh 18.6 18.9 19.8 21.2 18.1 18.5 19.4 20.7 17.7 18.1 18.9 20.2 17.3 17.6 18.4 19.7 16.4 16.7 17.5 18.7 15.2 15.5 16.2 17.3
S/T 0.96 0.93 0.84 0.68 1.00 0.96 0.87 0.71 1.00 0.99 0.89 0.72 1.00 1.00 0.92 0.75 1.00 1.00 0.95 0.77 1.00 1.00 0.96 0.78
DeltaT24242320252423202424232024 24 23 202223232021212118
675 KW 1.19 1.22 1.26 1.29 1.28 1.31 1.35 1.39 1.36 1.39 1.43 1.48 1.43 1.46 1.51 1.56 1.49 1.52 1.57 1.62 1.54 1.57 1.62 1.68
AMPS 4.3 4.4 4.6 4.7 4.7 4.8 4.9 5.1 5.1 5.2 5.3 5.5 5.4 5.5 5.7 5.9 5.7 5.9 6.1 6.3 6.1 6.2 6.4 6.7
HIPR 219 236 249 260 246 265 279 291 280 301 318 331 318 343 362 377 358 386 407 425 396 426 450 469
LO PR 110 117 127 136 116 123 135 143 121 128 140 149 127 135 147 157 133 141 154 164 137 146 159 170
MBh 18.0 18.4 19.3 20.5 17.6 18.0 18.8 20.1 17.2 17.5 18.4 19.6 16.8 17.1 17.9 19.1 15.9 16.2 17.0 18.2 14.8 15.0 15.8 16.8
S/T 0.92 0.89 0.80 0.65 0.95 0.92 0.83 0.67 0.98 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.92 0.74
DeltaT25252420262524212625242126 25 24 212425242123232219
85 600 KW 1.19 1.21 1.25 1.28 1.27 1.30 1.34 1.38 1.35 1.38 1.42 1.47 1.42 1.45 1.50 1.54 1.48 1.51 1.56 1.61 1.53 1.56 1.61 1.66
AMPS 4.3 4.4 4.5 4.7 4.6 4.7 4.9 5.1 5.0 5.1 5.3 5.5 5.3 5.5 5.7 5.9 5.7 5.8 6.0 6.2 6.0 6.2 6.4 6.6
HIPR 217 233 247 257 243 262 277 288 277 298 315 328 315 339 358 374 355 382 403 420 392 422 445 465
LO PR 109 116 126 134 115 122 133 142 119 127 139 148 125 133 146 155 131 140 153 162 136 145 158 168
MBh 16.6 17.0 17.8 19.0 16.3 16.6 17.4 18.5 15.9 16.2 16.9 18.1 15.5 15.8 16.5 17.6 14.7 15.0 15.7 16.8 13.6 13.9 14.5 15.5
S/T 0.89 0.85 0.77 0.63 0.92 0.89 0.80 0.65 0.94 0.91 0.82 0.66 0.97 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 0.98 0.89 0.72
DeltaT26252421262624212626242126 26 24 212626242124242320
525 KW 1.16 1.18 1.22 1.25 1.24 1.27 1.31 1.35 1.32 1.35 1.39 1.43 1.38 1.41 1.46 1.51 1.44 1.47 1.52 1.57 1.49 1.52 1.57 1.62
AMPS 4.2 4.3 4.4 4.6 4.5 4.6 4.8 4.9 4.9 5.0 5.2 5.3 5.2 5.3 5.5 5.7 5.5 5.7 5.8 6.1 5.9 6.0 6.2 6.4
HIPR 210 226 239 249 236 254 268 280 269 289 305 318 306 329 348 362 344 370 391 408 380 409 432 451
LO PR 105 112 122 130 111 118 129 138 116 123 134 143 122 129 141 150 127 136 148 158 132 140 153 163
Shaded area is ARIRating Conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total systempow er
A
MPS=outdoor unit amps (comp.+fan
