Goodman DSZ180601A Series User manual

DSZ 18 SEER
Split System Heat Pumps
•RefertoServiceManualRS6200006forinstallation,operation,andtroubleshootinginformation.
•Allsafetyinformation must be followedasprovided in the ServiceManual.
•RefertotheappropriatePartsCatalog for part number information.
•Models listed on page 3.
RT6214008r1
August2009
TECHNICAL MANUTECHNICAL MANU
TECHNICAL MANUTECHNICAL MANU
TECHNICAL MANUALAL
ALAL
AL
This manual is to be used by qualified, professionally trained HVAC technicians only. Goodman does
not assume any responsibility for property damage or personal injury due to improper service
procedures or services performed by an unqualified person.
Copyright © 2009 Goodman Manufacturing Company, L.P.

PRODUCT IDENTIFICATION
2
The model number is used for positive identification of component parts used in manufacturing. Please use this number
whenrequestingserviceorpartsinformation.
WARNING
WARNING HIGH VOLTAGE!
Disconnect ALL power before servicing or installing this unit. Multiple power
sources may be present. Failure to do so may cause property damage, personal
injury or death.
Installation and repair of this unit
should be performed ONLY by
individuals meeting the requirements of an "entry level
technician"asspecifiedbytheAir-Conditioning,Heating,
and Refrigeration Institute (AHRI). Attempting to install
or repair this unit without such background may result
in product damage, personal injury or death.
Goodman will not be responsible
for any injury or property damage
arising from improper service or service procedures. If
you install or perform service on this unit, you assume
responsibility for any personal injury or property damage
which may result. Many jurisdictions require a license to
install or service heating and air conditioning equipment.
WARNING
WARNING WARNING
WARNING
D S Z 18 036 1 A A
PRODUCT
TYPE:
X: Condenser R-410A
Z: Heat Pump R-410A
PRODUCT
FAMILY:
S: Split System
SEER:
SEER Rating
BRAND:
D:Deluxe
Goodman®
Brand
NOMINAL
CAPACITY:
036:3 Tons
048:4 Tons
060:5 Tons
MAJOR
REVISION:
A
: Initial Release
MINOR
REVISION:
A
: Initial Release
ELECTRICAL:
1: 208-230V/1ph/60Hz
3: 208-230v/3ph/60Hz
4: 460v/3ph/60Hz

PRODUCT IDENTIFICATION
3
The United States Environmental Protection Agency (“EPA”) has issued various regulations re-
garding the introduction and disposal of refrigerants introduced into this unit. Failure to follow
these regulations may harm the environment and can lead to the imposition of substantial fines.
These regulations may vary by jurisdiction. Should questions arise, contact your local EPA office.
WARNING
WARNING
Do not connect or use any device
that is not design certified by
Goodman for use with this unit.
Serious property damage, personal injury, reduced unit
performance and/or hazardous conditions may result
from the use of such non-approved devices.
WARNING
WARNING To prevent the risk of property
damage, personal injury, or death,
do not store combustible materials or use gasoline or
other flammable liquids or vapors in the vicinity of this
appliance.
WARNING
WARNING
The model number is used for positive identification of component parts used in manufacturing. Please use this number
whenrequestingserviceorpartsinformation.
* Indicates minor revision & is not used for order entry or inventory management
DSZ180361A*
DSZ180481A*
DSZ180601A*

PRODUCT DESIGN
4
DSZ18 models are available in 3, 4 and 5 ton sizes and
use R-410A refrigerant. They are designed for 208/230 volt
singlephaseapplications.
The condenser air is pulled through the condenser coil by a
direct drive propeller fan. This condenser air is then dis-
charged out of the top of the cabinet.
These units are designed for free air discharge, so no addi-
tional resistance like duct work shall be attached.
The suction and liquid line connections on present models
areofthe sweat type for field piping withrefrigeranttypecop-
per. Front seating valves are factory installed to accept the
fieldruncopper. The total refrigerantcharge for a normal in-
stallationis factory installedinthecondensingunit. DSZ units
are charged for the matching evaporator coil and a 15 foot
refrigerantlineset.
Systems should be properly sized by heat gain and loss
calculations made according to methods of the Air Condi-
tioning Contractors Association (ACCA) or equivalent. It is
the contractors responsibility to ensure the system has ad-
equate capacity to heat or cool the conditioned space.
DSZmodels use high-efficiencyCopeland®scroll "Ultratech"
compressorswhichare specifically desgined for R-410Are-
frigerant.Thereare a number ofdesigncharacteristicswhich
aredifferentfromthescrollcomparedtothetraditionalrecip-
rocatingcompressor.
"Ultratech" Series scroll compressors with Copeland®
ComfortAlert diagnostics will not have a discharge thermo-
stat. Some of the early model scroll compressors required
dischargethermostats.
Due to their design Scroll compressors are inherently more
tolerantofsmall quantities of liquid refrigerant.
NOTE: Eventhough the compressorsectionofaScroll com-
pressor is more tolerant of liquid refrigerant, continued
floodback or flooded start conditions may wash oil from the
bearingsurfacescausing premature bearing failure.
"Ultratech" Series scroll compressors use "POE" or
polyolesteroil whichisNOT compatiblewithmineraloilbased
lubricants like 3GS. "POE" oil must be used if additional oil
isrequired.
WARNING
To avoid possible injury, explosion or death, practice
safe handling of refrigerants.
Operating pressures and amp draws may differ from stan-
dardreciprocatingand/orscroll compressors. This informa-
tion may be found in the "Cooling Performance Data" sec-
tion.
This unit is for outdoor installation only. Refer to minimum
figure for clearances from the sides of the unit to full walls
andother objects.
NOTE: This unit cannot be completely enclosed. At least
one side must be unrestricted.
Theseclearanceswillhelpavoidairrecirculation.Ifinstalling
two or more units at the same location, allow at least 24
inches between units. If only one side is restricted (for ex-
ample, against the outside wall of a house), the unit may be
placed as close as 8" to that one wall.
DO NOT locate the unit:
* Directlyundera vent termination fora gas appliance.
* Within 3 feet of a clothes drier vent
* Wheretherefreezingofdefrostwaterwould create
ahazard
* Where water may rise into the unit.
OK!
OK!
AA AAA
A
CC
CCOK!
OK!
OK!
OK!
NOT
RECOMMENDED
AA
AA AA
AA
AA
B B B
B
Model Type A B C AA
Residential 10" 10" 18" 20"
Light Commercial 12" 12" 18" 24"
Minimum Airflow Clearance
Model Dimensions - W x D x H
DSZ180361A* 35½ x 35½ x 38¼
DSZ180481A* 35½ x 35½ x 38¼
DSZ180601A* 35½ x 35½ x 38¼

HEAT PUMP SPECIFICATIONS
5
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit breakers and
wires in accordance with all national and/or local electrical codes. Use copper wire only.
Unit specifications are subject to change without notice. ALWAYS refer to the unit's serial plate for the most up-to-date general
and electrical information.
DSZ180361A* -DSZ180601A*
* Up to 24' in equivalent line length
(1) Wire size should be determined in accordance with National Electrical Codes; extensive wire runs will require larger wire sizes.
(2) Maximum Overcurrent Protection Device: MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
NOTES:
• Always check the S & R plate for electrical data on the unit being installed.
• Installer will need to supply 7/8" to 1-1/8" adapters for suction line connections (4 & 5 ton units).
• Installer will need to supply 3/4" to 7/8" adapters for suction line connections (3 ton unit).
• Unit is charged with refrigerant for 15' of 3/8" liquid line. System charge must be adjusted per Installation Instructions Final Charge
Procedure.
• Installation of these units requires the specified TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED BY THE
OUTDOORUNIT,NOTTHEINDOORCOIL.
DSZ180361A* DSZ180481A* DSZ180601A*
Cooling Capacity, BTUH 35,000 47,000 57,000
Compressor
R.L. Amps 16.7 21.2 25.6
L.R. Amps 82.0 96.0 118.0
Low Pressure Switch
Open 22 + / - 7 PSIG 22 + / - 7 PSIG 22 + / - 7 PSIG
Close 50 + / - 7 PSIG 50 + / - 7 PSIG 50 + / - 7 PSIG
High Pressure Switch
Open 610 PSIG 610 PSIG 610 PSIG
Close 420 PSIG 420 PSIG 420 PSIG
Condenser Fan Motor
Horsepower 1/3 1/3 1/3
F.L. Amps 2.8 2.8 2.8
Liquid Line, Inches O.D.* 3/8" 3/8" 3/8"
Suction Line, Inches O.D.* 7/8" 1 1/8" 1 1/8
Refrigerant Charge 188.0 278.0 278.0
Power Supply 208/230-60-1 208/230-60-1 208/230-60-1
Minimum Circuit Ampacity(1) 23.7 29.3 34.8
Maximum Overcurrent Device(2) 40 50 60
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight 285 330 350

6
COOLINGPERFORMANCEDATA DSZ180361A*-LOWSTAGE
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: DSZ180361A* / CA*F3743*6** + TXV / MBE1600**-1** Design Subcooling5 - 7 °F @ the liquid service valve, AHRI 95° F test conditions
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
MBh 24.8 25.7 28.1 - 24.2 25.1 27.5 - 23.6 24.5 26.8 - 23.1 23.9 26.2 - 21.9 22.7 24.9 - 20.3 21.0 23.0 -
S/T 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.81 0.68 0.47 - 0.84 0.70 0.49 - 0.87 0.73 0.50 - 0.88 0.73 0.51 -
DT 18 16 12 - 18 16 12 - 18 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -
956 KW 1.34 1.37 1.42 - 1.45 1.48 1.54 - 1.55 1.58 1.64 - 1.63 1.67 1.73 - 1.71 1.75 1.81 - 1.77 1.81 1.88 -
AMPS 5.3 5.4 5.6 - 5.7 5.9 6.1 - 6.2 6.4 6.6 - 6.7 6.8 7.1 - 7.1 7.3 7.5 - 7.5 7.7 8.0 -
HI PR 209 225 237 - 234 252 266 - 267 287 303 - 304 327 345 - 342 368 388 - 377 406 429 -
LO PR 111 118 128 - 117 124 136 - 121 129 141 - 128 136 148 - 134 142 155 - 138 147 161 -
MBh 24.1 24.9 27.3 - 23.5 24.4 26.7 - 22.9 23.8 26.1 - 22.4 23.2 25.4 - 21.3 22.0 24.1 - 19.7 20.4 22.4 -
S/T 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.84 0.70 0.48 -
DT 19 16 12 - 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 18 15 12 -
70 850 KW 1.33 1.36 1.40 - 1.44 1.47 1.52 - 1.54 1.57 1.63 - 1.62 1.66 1.72 - 1.69 1.73 1.79 - 1.76 1.80 1.86 -
AMPS 5.3 5.4 5.6 - 5.7 5.8 6.0 - 6.2 6.3 6.5 - 6.6 6.8 7.0 - 7.0 7.2 7.5 - 7.5 7.6 7.9 -
HI PR 207 223 235 - 232 250 264 - 264 284 300 - 301 324 342 - 338 364 384 - 374 402 425 -
LO PR 110 117 127 - 116 123 134 - 120 128 140 - 126 134 147 - 132 141 154 - 137 146 159 -
MBh 22.2 23.0 25.2 - 21.7 22.5 24.6 - 21.2 21.9 24.0 - 20.7 21.4 23.5 - 19.6 20.3 22.3 - 18.2 18.8 20.6 -
S/T 0.70 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.62 0.43 - 0.77 0.64 0.45 - 0.80 0.67 0.46 - 0.81 0.67 0.47 -
DT 19 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 19 17 13 - 18 16 12 -
744 KW 1.29 1.32 1.37 - 1.40 1.43 1.48 - 1.50 1.53 1.58 - 1.58 1.61 1.67 - 1.65 1.69 1.75 - 1.71 1.75 1.81 -
AMPS 5.1 5.2 5.4 - 5.5 5.7 5.9 - 6.0 6.2 6.4 - 6.4 6.6 6.8 - 6.8 7.0 7.2 - 7.2 7.4 7.7 -
HI PR 201 216 228 - 225 242 256 - 256 276 291 - 292 314 331 - 328 353 373 - 363 390 412 -
LO PR 106 113 123 - 112 119 130 - 117 124 135 - 123 130 142 - 128 137 149 - 133 141 154 -
MBh 25.2 25.9 28.1 30.1 24.6 25.3 27.4 29.4 24.0 24.7 26.8 28.7 23.4 24.1 26.1 28.0 22.3 22.9 24.8 26.6 20.6 21.2 23.0 24.7
S/T 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.92 0.83 0.63 0.40 0.95 0.85 0.65 0.42 0.99 0.89 0.67 0.43 1.00 0.89 0.68 0.44
DT 21 19 16 11 21 20 16 11 21 20 16 11 22 20 16 11 21 20 16 11 20 18 15 10
956 KW 1.35 1.38 1.43 1.48 1.46 1.50 1.55 1.60 1.56 1.60 1.65 1.71 1.65 1.69 1.75 1.81 1.72 1.76 1.83 1.89 1.79 1.83 1.89 1.96
AMPS 5.4 5.5 5.7 5.9 5.8 5.9 6.1 6.4 6.3 6.5 6.7 6.9 6.7 6.9 7.1 7.4 7.2 7.3 7.6 7.9 7.6 7.8 8.0 8.4
HI PR 211 227 240 250 237 255 269 281 269 290 306 319 307 330 349 364 345 371 392 409 381 410 433 452
LO PR 112 119 130 138 118 126 137 146 123 131 143 152 129 137 150 159 135 144 157 167 140 149 162 173
MBh 24.5 25.2 27.3 29.3 23.9 24.6 26.6 28.6 23.3 24.0 26.0 27.9 22.8 23.4 25.4 27.2 21.6 22.3 24.1 25.9 20.0 20.6 22.3 24.0
S/T 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.88 0.79 0.60 0.38 0.91 0.81 0.62 0.40 0.94 0.85 0.64 0.41 0.95 0.85 0.64 0.41
DT 22 20 17 11 22 20 17 12 22 20 17 12 22 21 17 12 22 20 17 12 21 19 16 11
75 850 KW 1.34 1.37 1.42 1.47 1.45 1.48 1.54 1.59 1.55 1.59 1.64 1.70 1.64 1.67 1.73 1.79 1.71 1.75 1.81 1.87 1.77 1.81 1.88 1.95
AMPS 5.3 5.4 5.6 5.8 5.7 5.9 6.1 6.3 6.2 6.4 6.6 6.9 6.7 6.8 7.1 7.3 7.1 7.3 7.5 7.8 7.5 7.7 8.0 8.3
HI PR 209 225 237 248 234 252 266 278 267 287 303 316 304 327 345 360 342 368 388 405 378 406 429 447
LO PR 111 118 128 137 117 124 136 145 121 129 141 150 128 136 148 158 134 142 155 165 138 147 161 171
MBh 22.6 23.3 25.2 27.0 22.1 22.7 24.6 26.4 21.5 22.2 24.0 25.8 21.0 21.6 23.4 25.1 20.0 20.5 22.2 23.9 18.5 19.0 20.6 22.1
S/T 0.80 0.72 0.54 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.88 0.79 0.59 0.38 0.91 0.81 0.62 0.40 0.92 0.82 0.62 0.40
DT 22 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 22 21 17 12 21 19 16 11
744 KW 1.31 1.34 1.38 1.43 1.41 1.45 1.50 1.55 1.51 1.54 1.60 1.65 1.59 1.63 1.69 1.75 1.66 1.70 1.76 1.82 1.72 1.77 1.83 1.89
AMPS 5.2 5.3 5.5 5.7 5.6 5.7 5.9 6.1 6.1 6.2 6.4 6.7 6.5 6.6 6.9 7.1 6.9 7.1 7.3 7.6 7.3 7.5 7.7 8.0
HI PR 203 218 230 240 227 245 258 270 259 278 294 307 295 317 335 349 331 357 377 393 366 394 416 434
LO PR 107 114 125 133 113 121 132 140 118 125 137 146 124 132 144 153 130 138 151 160 134 143 156 166
Shaded area is ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan) Hi
g
h and low
p
ressures are measured at the li
q
uid and suction service valves.

7
COOLINGPERFORMANCEDATA DSZ180361A*-LOWSTAGE
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: DSZ180361A* / CA*F3743*6** + TXV / MBE1600**-1** Design Subcooling 5 - 7 °F @ the liquid service valve, AHRI 95° F test conditions
OutdoorAmbient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
MBh 25.7 26.2 28.0 29.9 25.1 25.6 27.4 29.2 24.5 25.0 26.7 28.5 23.9 24.4 26.0 27.8 22.7 23.2 24.7 26.5 21.0 21.5 22.9 24.5
S/T 0.950.900.730.541.000.930.750.561.000.950.770.581.00 1.00 0.800.601.001.000.830.621.001.000.840.63
DT 24 23 20 16 24 23 20 16 24 23 20 16 23 23 20 16 22 22 20 16 20 21 18 15
956 KW 1.36 1.39 1.44 1.49 1.48 1.51 1.56 1.62 1.58 1.61 1.67 1.73 1.66 1.70 1.76 1.83 1.74 1.78 1.84 1.91 1.80 1.85 1.91 1.98
AMPS 5.4 5.5 5.7 5.9 5.9 6.0 6.2 6.4 6.4 6.5 6.7 7.0 6.8 7.0 7.2 7.5 7.2 7.4 7.7 8.0 7.7 7.9 8.1 8.4
HI PR 213 229 242 253 239 257 272 284 272 293 309 322 310 333 352 367 349 375 396 413 385 415 438 457
LO PR 113 120 131 140 119 127 138 147 124 132 144 153 130 138 151 161 136 145 158 169 141 150 164 175
MBh 24.9 25.4 27.2 29.1 24.3 24.9 26.6 28.4 23.7 24.3 25.9 27.7 23.2 23.7 25.3 27.0 22.0 22.5 24.0 25.7 20.4 20.8 22.3 23.8
S/T 0.910.850.690.520.940.880.720.540.970.910.740.551.00 0.94 0.76 0.57 1.00 0.97 0.79 0.59 1.00 0.98 0.80 0.60
DT 25 23 20 16 25 24 21 17 25 24 21 17 25 24 21 17 24 24 21 16 22 22 19 15
80 850 KW 1.35 1.38 1.43 1.48 1.46 1.50 1.55 1.60 1.56 1.60 1.65 1.71 1.65 1.69 1.75 1.81 1.72 1.76 1.83 1.89 1.79 1.83 1.89 1.96
AMPS5.45.55.75.95.85.96.16.46.36.56.76.96.7 6.9 7.1 7.47.27.37.67.97.67.88.08.4
HI PR 211 227 240 250 237 255 269 281 269 290 306 319 307 330 349 364 345 371 392 409 381 410 433 452
LO PR 112 119 130 138 118 126 137 146 123 131 143 152 129 137 150 159 135 144 157 167 140 149 162 173
MBh 23.0 23.5 25.1 26.8 22.5 22.9 24.5 26.2 21.9 22.4 23.9 25.6 21.4 21.8 23.3 25.0 20.3 20.8 22.2 23.7 18.8 19.2 20.5 22.0
S/T 0.880.820.670.500.910.850.690.520.930.870.710.530.96 0.90 0.730.551.000.940.760.571.010.940.770.57
DT 25 24 21 17 25 24 21 17 25 24 21 17 25 24 21 17 25 24 21 17 23 22 20 16
744 KW 1.32 1.35 1.39 1.44 1.43 1.46 1.51 1.56 1.52 1.56 1.61 1.67 1.61 1.64 1.70 1.76 1.68 1.72 1.78 1.84 1.74 1.78 1.84 1.91
AMPS 5.2 5.3 5.5 5.7 5.6 5.8 6.0 6.2 6.1 6.3 6.5 6.7 6.5 6.7 6.9 7.2 7.0 7.1 7.4 7.7 7.4 7.6 7.8 8.1
HI PR 205 220 233 243 230 247 261 272 261 281 297 310 298 320 338 353 335 360 380 397 370 398 420 438
LO PR 108 115 126 134 115 122 133 142 119 127 138 147 125 133 145 155 131 139 152 162 136 144 157 168
MBh 26.1 26.6 27.9 29.7 25.5 26.0 27.2 29.0 24.9 25.4 26.6 28.3 24.3 24.7 25.9 27.7 23.1 23.5 24.6 26.3 21.4 21.8 22.8 24.3
S/T 1.000.970.870.711.001.000.900.731.001.000.930.751.00 1.00 0.960.781.001.000.990.801.001.001.000.81
DT 25 25 23 20 25 25 24 20 24 24 24 20 23 24 24 21 22 23 23 20 21 21 22 19
956 KW 1.38 1.41 1.45 1.50 1.49 1.52 1.58 1.63 1.59 1.63 1.68 1.74 1.68 1.72 1.78 1.84 1.75 1.80 1.86 1.93 1.82 1.86 1.93 2.00
AMPS 5.5 5.6 5.8 6.0 5.9 6.0 6.2 6.5 6.4 6.6 6.8 7.0 6.9 7.0 7.3 7.5 7.3 7.5 7.7 8.0 7.7 7.9 8.2 8.5
HI PR 215 232 245 255 242 260 275 286 275 296 312 326 313 337 356 371 352 379 400 417 389 419 442 461
LO PR 114 121 132 141 120 128 140 149 125 133 145 155 131 140 153 163 138 147 160 170 143 152 166 176
MBh 25.3 25.8 27.1 28.9 24.7 25.2 26.4 28.2 24.2 24.6 25.8 27.5 23.6 24.0 25.2 26.8 22.4 22.8 23.9 25.5 20.7 21.1 22.1 23.6
S/T 0.950.920.830.670.990.950.860.701.000.980.880.721.00 1.00 0.910.741.001.000.950.771.001.000.950.77
DT 26 26 24 21 26 26 25 21 26 26 25 21 25 26 25 21 24 25 24 21 22 23 23 20
85 850 KW 1.36 1.39 1.44 1.49 1.48 1.51 1.56 1.62 1.58 1.61 1.67 1.73 1.66 1.70 1.76 1.83 1.74 1.78 1.84 1.91 1.80 1.85 1.91 1.98
AMPS 5.4 5.5 5.7 5.9 5.9 6.0 6.2 6.4 6.4 6.5 6.7 7.0 6.8 7.0 7.2 7.5 7.2 7.4 7.7 8.0 7.7 7.9 8.1 8.4
HI PR 213 229 242 253 239 257 272 284 272 293 309 322 310 333 352 367 349 375 396 413 385 415 438 457
LO PR 113 120 131 140 119 127 138 147 124 132 144 153 130 138 151 161 136 145 158 169 141 150 164 175
MBh 23.4 23.8 25.0 26.6 22.8 23.3 24.4 26.0 22.3 22.7 23.8 25.4 21.8 22.2 23.2 24.8 20.7 21.1 22.1 23.5 19.1 19.5 20.4 21.8
S/T 0.920.890.800.650.950.920.830.670.980.940.850.691.00 0.97 0.880.711.001.000.910.741.001.000.920.75
DT 26.6 26 25 21 27 26 25 22 27 27 25 22 27 27 25 22 26 26 25 22 24 24 23 20
744 KW 1.33 1.36 1.40 1.45 1.44 1.47 1.52 1.57 1.53 1.57 1.62 1.68 1.62 1.66 1.72 1.78 1.69 1.73 1.79 1.86 1.76 1.80 1.86 1.93
AMPS 5.3 5.4 5.6 5.8 5.7 5.8 6.0 6.2 6.2 6.3 6.5 6.8 6.6 6.8 7.0 7.3 7.0 7.2 7.4 7.7 7.5 7.6 7.9 8.2
HI PR 207 223 235 245 232 250 264 275 264 284 300 313 301 323 342 356 338 364 384 401 374 402 425 443
LO PR 109 116 127 135 116 123 134 143 120 128 140 149 126 134 147 156 132 141 154 164 137 146 159 169
Shaded area is AHRI Rating Conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves.

8
COOLINGPERFORMANCEDATA DSZ180481A*-LOWSTAGE
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: DSZ180481A* /CA*F4961*6** + TXV / MBE2000**-1** Design Subcooling5 - 7°F @ the liquid service valve, AHRI95° F test conditions
OutdoorAmbient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
MBh 35.0 36.3 39.8 - 34.2 35.5 38.9 - 33.4 34.6 37.9 - 32.6 33.8 37.0 - 31.0 32.1 35.2 - 28.7 29.7 32.6 -
S/T 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.86 0.72 0.50 - 0.87 0.72 0.50 -
DT 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
1350 KW 1.85 1.89 1.96 - 2.01 2.05 2.13 - 2.14 2.20 2.27 - 2.27 2.32 2.40 - 2.37 2.43 2.51 - 2.46 2.52 2.61 -
AMPS 0.1 0.1 0.1 - 0.1 0.1 0.1 - 0.1 0.1 0.1 - 0.1 0.1 0.1 - 0.1 0.1 0.1 - 0.1 0.1 0.1 -
HI PR 209 225 237 - 234 252 266 - 266 287 303 - 303 326 345 - 341 367 388 - 377 406 429 -
LO PR 110 117 128 - 116 123 135 - 121 128 140 - 127 135 147 - 133 141 154 - 137 146 160 -
MBh 34.0 35.3 38.6 - 33.2 34.4 37.7 - 32.4 33.6 36.8 - 31.6 32.8 35.9 - 30.1 31.2 34.1 - 27.8 28.9 31.6 -
S/T 0.72 0.60 0.42 - 0.75 0.62 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.69 0.47 - 0.83 0.69 0.48 -
DT 19 16 12 - 19 16 12 - 19 16 13 - 19 17 13 - 19 16 12 - 18 15 12 -
70 1200 KW 1.84 1.88 1.94 - 1.99 2.04 2.11 - 2.13 2.18 2.25 - 2.25 2.30 2.38 - 2.35 2.40 2.49 - 2.44 2.49 2.58 -
AMPS 0.1 0.1 0.1 - 0.1 0.1 0.1 - 0.1 0.1 0.1 - 0.1 0.1 0.1 - 0.1 0.1 0.1 - 0.1 0.1 0.1 -
HI PR 207 222 235 - 232 250 264 - 264 284 300 - 300 323 341 - 338 364 384 - 373 402 424 -
LO PR 109 116 126 - 115 122 133 - 119 127 139 - 125 133 146 - 131 140 153 - 136 145 158 -
MBh 31.4 32.5 35.7 - 30.7 31.8 34.8 - 29.9 31.0 34.0 - 29.2 30.3 33.2 - 27.7 28.8 31.5 - 25.7 26.6 29.2 -
S/T 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.80 0.67 0.46 -
DT 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 18 16 12 -
1050 KW 1.79 1.83 1.89 - 1.94 1.98 2.05 - 2.07 2.12 2.19 - 2.19 2.24 2.32 - 2.28 2.34 2.42 - 2.37 2.43 2.51 -
AMPS 0.1 0.1 0.1 - 0.1 0.1 0.1 - 0.1 0.1 0.1 - 0.1 0.1 0.1 - 0.1 0.1 0.1 - 0.1 0.1 0.1 -
HI PR 200 216 228 - 225 242 256 - 256 275 291 - 291 314 331 - 328 353 372 - 362 390 412 -
LO PR 106 112 123 - 111 119 129 - 116 123 135 - 122 129 141 - 128 136 148 - 132 140 153 -
MBh 35.6 36.7 39.7 42.6 34.8 35.8 38.8 41.6 34.0 35.0 37.9 40.6 33.1 34.1 36.9 39.6 31.5 32.4 35.1 37.7 29.2 30.0 32.5 34.9
S/T 0.860.770.580.370.890.800.600.390.910.820.620.400.94 0.84 0.64 0.41 0.98 0.87 0.66 0.43 0.99 0.88 0.67 0.43
DT 21 19 16 11 21 19 16 11 21 19 16 11 21 20 16 11 21 19 16 11 20 18 15 10
1350 KW 1.871.911.982.052.032.072.142.222.162.222.292.372.29 2.34 2.42 2.51 2.39 2.45 2.53 2.63 2.48 2.54 2.63 2.73
AMPS0.10.10.10.10.10.10.10.10.10.10.10.10.1 0.1 0.1 0.10.10.10.10.10.10.10.10.1
HI PR 211 227 240 250 237 255 269 280 269 290 306 319 306 330 348 363 345 371 392 409 381 410 433 452
LO PR 111 118 129 137 117 125 136 145 122 130 142 151 128 136 149 158 134 143 156 166 139 148 161 172
MBh 34.6 35.6 38.5 41.4 33.8 34.8 37.7 40.4 33.0 34.0 36.8 39.4 32.2 33.1 35.9 38.5 30.6 31.5 34.1 36.6 28.3 29.2 31.6 33.9
S/T 0.820.730.550.360.850.760.570.370.870.780.590.380.90 0.80 0.61 0.39 0.93 0.83 0.63 0.41 0.94 0.84 0.64 0.41
DT 22 20 16 11 22 20 17 11 22 20 17 11 22 20 17 12 22 20 16 11 20 19 15 11
75 1200 KW 1.851.891.962.032.012.052.132.202.152.202.272.352.27 2.32 2.40 2.49 2.37 2.43 2.51 2.60 2.46 2.52 2.61 2.70
AMPS0.10.10.10.10.10.10.10.10.10.10.10.10.1 0.1 0.1 0.10.10.10.10.10.10.10.10.1
HI PR 209 225 237 247 234 252 266 278 266 287 303 316 303 327 345 360 341 367 388 405 377 406 429 447
LO PR 110 117 128 136 116 124 135 144 121 128 140 149 127 135 147 157 133 141 154 164 137 146 160 170
MBh 31.9 32.9 35.6 38.2 31.2 32.1 34.8 37.3 30.4 31.3 33.9 36.4 29.7 30.6 33.1 35.5 28.2 29.0 31.4 33.7 26.1 26.9 29.1 31.3
S/T 0.790.710.530.340.820.730.550.360.840.750.570.370.87 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.91 0.81 0.61 0.40
DT 22 20 17 12 22 21 17 12 22 21 17 12 23 21 17 12 22 20 17 12 21 19 16 11
1050 KW 1.801.851.911.981.952.002.072.142.092.142.212.292.21 2.26 2.34 2.42 2.31 2.36 2.44 2.53 2.39 2.45 2.54 2.63
AMPS0.10.10.10.10.10.10.10.10.10.10.10.10.1 0.1 0.1 0.10.10.10.10.10.10.10.10.1
HI PR 203 218 230 240 227 245 258 269 258 278 294 306 294 317 334 349 331 356 376 392 366 394 416 434
LO PR 107 113 124 132 113 120 131 139 117 125 136 145 123 131 143 152 129 137 150 159 133 142 155 165
Shaded area is ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves.

9
COOLINGPERFORMANCEDATA DSZ180481A*-LOWSTAGE
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: DSZ180481A* /CA*F4961*6** + TXV / MBE2000**-1** Design Subcooling5 - 7°F @ the liquid service valve, AHRI95° F test conditions
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
MBh 36.3 37.1 39.6 42.3 35.4 36.2 38.7 41.3 34.6 35.3 37.7 40.3 33.7 34.5 36.8 39.4 32.0 32.7 35.0 37.4 29.7 30.3 32.4 34.6
S/T 0.940.880.720.541.000.920.750.561.000.940.760.571.00 0.97 0.79 0.591.001.000.820.611.001.000.830.62
DT 23 22 19 15 24 23 20 16 24 23 20 16 23 23 20 16 22 22 20 16 20 21 18 15
1350 KW 1.881.931.992.062.042.092.162.242.182.242.312.402.31 2.36 2.45 2.532.412.472.562.652.502.562.652.75
AMPS 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1
HI PR 213 229 242 252 239 257 272 283 272 292 309 322 310 333 352 367 348 375 396 413 385 414 437 456
LO PR 112 119 130 139 118 126 138 147 123 131 143 152 129 138 150 160 136 144 157 168 140 149 163 173
MBh 35.2 36.0 38.4 41.1 34.4 35.1 37.5 40.1 33.6 34.3 36.6 39.2 32.7 33.5 35.8 38.2 31.1 31.8 34.0 36.3 28.8 29.4 31.5 33.6
S/T 0.900.840.690.510.930.870.710.530.960.900.730.540.99 0.92 0.75 0.56 1.00 0.96 0.78 0.58 1.00 0.97 0.79 0.59
DT 24 23 20 16 25 24 20 16 25 24 20 16 25 24 21 16 24 23 20 16 22 22 19 15
80 1200 KW 1.871.911.982.052.032.072.152.222.162.222.292.382.29 2.34 2.42 2.51 2.39 2.45 2.54 2.63 2.48 2.54 2.63 2.73
AMPS0.10.10.10.10.10.10.10.10.10.10.10.10.1 0.1 0.1 0.10.10.10.10.10.10.10.10.1
HI PR 211 227 240 250 237 255 269 280 269 290 306 319 307 330 348 363 345 371 392 409 381 410 433 452
LO PR 111 118 129 137 117 125 136 145 122 130 142 151 128 136 149 158 134 143 156 166 139 148 161 172
MBh 32.5 33.2 35.5 37.9 31.7 32.4 34.6 37.0 31.0 31.7 33.8 36.2 30.2 30.9 33.0 35.3 28.7 29.3 31.3 33.5 26.6 27.2 29.0 31.0
S/T 0.870.810.660.490.900.840.690.510.920.860.700.530.95 0.89 0.73 0.540.990.930.750.560.990.930.760.57
DT 25 24 21 16 25 24 21 17 25 24 21 17 25 24 21 17 25 24 21 17 23 22 19 15
1050 KW 1.821.861.931.991.972.022.092.162.112.162.232.312.23 2.28 2.36 2.442.332.382.472.562.412.472.562.65
AMPS 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1
HI PR 205 220 232 242 230 247 261 272 261 281 297 309 297 320 338 352 334 360 380 396 370 398 420 438
LO PR 108 115 125 133 114 121 132 141 118 126 137 146 124 132 144 154 130 138 151 161 135 143 156 167
MBh 36.9 37.6 39.4 42.0 36.0 36.7 38.5 41.0 35.2 35.9 37.6 40.1 34.3 35.0 36.6 39.1 32.6 33.2 34.8 37.1 30.2 30.8 32.2 34.4
S/T 0.990.950.860.701.000.990.890.721.001.000.910.741.00 1.00 0.94 0.771.001.000.980.791.001.000.990.80
DT 25 24 23 20 25 25 23 20 24 24 23 20 23 24 24 20 22 23 23 20 21 21 22 19
1350 KW 1.901.942.012.082.062.112.182.262.202.262.332.422.33 2.38 2.47 2.562.432.492.582.672.532.592.682.78
AMPS 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1
HI PR 215 231 244 255 241 260 274 286 275 295 312 325 313 336 355 371 352 379 400 417 389 418 442 461
LO PR 113 120 132 140 120 127 139 148 124 132 144 154 131 139 152 162 137 146 159 169 142 151 164 175
MBh 35.8 36.5 38.2 40.8 35.0 35.7 37.4 39.8 34.2 34.8 36.5 38.9 33.3 34.0 35.6 38.0 31.7 32.3 33.8 36.1 29.3 29.9 31.3 33.4
S/T 0.940.910.820.670.980.940.850.691.000.970.870.711.00 1.00 0.90 0.731.001.000.930.761.001.000.940.76
DT 26 25 24 21 26 26 24 21 26 26 24 21 26 26 25 21 24 25 24 21 22 23 23 20
85 1200 KW 1.881.931.992.062.042.092.162.242.182.242.312.402.31 2.36 2.45 2.532.412.472.562.652.502.562.652.75
AMPS 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1
HI PR 213 229 242 252 239 257 272 283 272 292 309 322 310 333 352 367 348 375 396 413 385 414 437 456
LO PR 112 119 130 139 118 126 138 147 123 131 143 152 129 138 150 160 136 144 157 168 140 149 163 173
MBh 33.1 33.7 35.3 37.7 32.3 32.9 34.5 36.8 31.5 32.1 33.7 35.9 30.8 31.4 32.8 35.0 29.2 29.8 31.2 33.3 27.1 27.6 28.9 30.8
S/T 0.910.880.790.640.940.910.820.670.970.930.840.681.00 0.96 0.87 0.701.001.000.900.731.001.000.910.74
DT 26.3 26 24 21 27 26 25 21 27 26 25 21 27 26 25 22 26 26 25 21 24 24 23 20
1050 KW 1.841.881.942.011.992.042.112.182.132.182.252.332.25 2.30 2.38 2.472.352.402.492.582.442.492.582.68
AMPS 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1
HI PR 207 222 235 245 232 249 263 275 264 284 300 312 300 323 341 356 338 364 384 400 373 402 424 442
LO PR 109 116 126 135 115 122 133 142 119 127 139 148 125 133 146 155 131 140 153 163 136 145 158 168
Shaded area is AHRI Rating Conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves.

10
COOLINGPERFORMANCEDATA DSZ180601A*-LOWSTAGE
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: DSZ180601A* / CA*F4961*6** + TXV / MBE2000**-1** Design Subcooling 5 - 7 °F @ the liquid service valve, AHRI 95° F test conditions
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
MBh 41.6 43.1 47.2 - 40.6 42.1 46.1 - 39.7 41.1 45.0 - 38.7 40.1 43.9 - 36.8 38.1 41.7 - 34.0 35.3 38.7 -
S/T 0.71 0.59 0.41 - 0.74 0.62 0.43 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.82 0.68 0.47 -
DT 20 17 13 - 20 18 13 - 20 18 13 - 21 18 14 - 20 18 13 - 19 16 12 -
1350 KW 2.35 2.41 2.49 - 2.55 2.61 2.71 - 2.73 2.80 2.90 - 2.89 2.96 3.06 - 3.02 3.09 3.21 - 3.14 3.21 3.33 -
AMPS 9.1 9.4 9.7 - 9.9 10.2 10.5 - 10.8 11.1 11.5 - 11.6 11.9 12.3 - 12.3 12.7 13.1 - 13.1 13.4 13.9 -
HI PR 209 225 237 - 234 252 266 - 266 287 303 - 303 326 345 - 341 367 388 - 377 406 428 -
LO PR 105 112 122 - 111 118 129 - 115 123 134 - 121 129 141 - 127 135 147 - 131 140 152 -
MBh 40.4 41.8 45.9 - 39.4 40.9 44.8 - 38.5 39.9 43.7 - 37.6 38.9 42.7 - 35.7 37.0 40.5 - 33.1 34.3 37.5 -
S/T 0.68 0.57 0.39 - 0.70 0.59 0.41 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.77 0.65 0.45 - 0.78 0.65 0.45 -
DT 21 18 14 - 21 18 14 - 21 18 14 - 21 19 14 - 21 18 14 - 20 17 13 -
70 1200 KW 2.33 2.39 2.47 - 2.53 2.59 2.68 - 2.71 2.77 2.87 - 2.86 2.93 3.04 - 2.99 3.07 3.18 - 3.11 3.18 3.30 -
AMPS 9.1 9.3 9.6 - 9.8 10.1 10.4 - 10.7 11.0 11.4 - 11.5 11.8 12.2 - 12.2 12.5 13.0 - 13.0 13.3 13.8 -
HI PR 207 222 235 - 232 249 263 - 264 284 300 - 300 323 341 - 338 364 384 - 373 402 424 -
LO PR 104 111 121 - 110 117 128 - 114 121 133 - 120 128 139 - 126 134 146 - 130 138 151 -
MBh 37.3 38.6 42.3 - 36.4 37.7 41.3 - 35.5 36.8 40.4 - 34.7 35.9 39.4 - 32.9 34.1 37.4 - 30.5 31.6 34.6 -
S/T 0.65 0.55 0.38 - 0.68 0.57 0.39 - 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.75 0.62 0.43 - 0.75 0.63 0.43 -
DT 21 18 14 - 22 19 14 - 22 19 14 - 22 19 14 - 21 19 14 - 20 17 13 -
1050 KW 2.27 2.32 2.40 - 2.46 2.52 2.61 - 2.63 2.70 2.79 - 2.78 2.85 2.95 - 2.91 2.98 3.09 - 3.02 3.10 3.21 -
AMPS 8.8 9.0 9.3 - 9.5 9.8 10.1 - 10.4 10.7 11.0 - 11.1 11.4 11.8 - 11.9 12.2 12.6 - 12.6 12.9 13.4 -
HI PR 200 216 228 - 225 242 256 - 256 275 291 - 291 313 331 - 328 353 372 - 362 390 411 -
LO PR 101 107 117 - 107 113 124 - 111 118 129 - 116 124 135 - 122 130 142 - 126 134 146 -
MBh 42.3 43.5 47.1 50.6 41.3 42.5 46.0 49.4 40.3 41.5 44.9 48.2 39.3 40.5 43.8 47.1 37.4 38.5 41.7 44.7 34.6 35.6 38.6 41.4
S/T 0.81 0.72 0.55 0.35 0.84 0.75 0.57 0.37 0.86 0.77 0.58 0.37 0.89 0.79 0.60 0.39 0.92 0.82 0.62 0.40 0.93 0.83 0.63 0.40
DT 23 21 18 12 24 22 18 12 24 22 18 12 24 22 18 12 23 22 18 12 22 20 17 11
1350 KW 2.37 2.43 2.51 2.60 2.58 2.64 2.73 2.83 2.76 2.82 2.92 3.03 2.91 2.98 3.09 3.20 3.05 3.12 3.24 3.35 3.17 3.24 3.36 3.48
AMPS 9.2 9.5 9.8 10.2 10.0 10.3 10.6 11.0 10.9 11.2 11.6 12.0 11.7 12.0 12.4 12.9 12.5 12.8 13.2 13.7 13.2 13.6 14.0 14.6
HI PR 211 227 240 250 237 255 269 280 269 289 306 319 306 330 348 363 345 371 392 409 381 410 433 451
LO PR 106 113 123 131 112 119 130 139 116 124 135 144 122 130 142 151 128 136 149 159 133 141 154 164
MBh 41.1 42.3 45.8 49.1 40.1 41.3 44.7 48.0 39.2 40.3 43.6 46.8 38.2 39.3 42.6 45.7 36.3 37.4 40.4 43.4 33.6 34.6 37.5 40.2
S/T 0.77 0.69 0.52 0.34 0.80 0.72 0.54 0.35 0.82 0.73 0.55 0.36 0.85 0.76 0.57 0.37 0.88 0.79 0.59 0.38 0.89 0.79 0.60 0.39
DT 24 22 18 13 25 23 19 13 25 23 19 13 25 23 19 13 24 22 18 13 23 21 17 12
75 1200 KW 2.35 2.41 2.49 2.58 2.55 2.61 2.71 2.80 2.73 2.80 2.90 3.00 2.89 2.96 3.06 3.18 3.02 3.09 3.21 3.32 3.14 3.21 3.33 3.45
AMPS 9.1 9.4 9.7 10.1 9.9 10.2 10.5 10.9 10.8 11.1 11.5 11.9 11.6 11.9 12.3 12.8 12.3 12.7 13.1 13.6 13.1 13.4 13.9 14.5
HI PR 209 225 237 247 234 252 266 278 266 287 303 316 303 326 345 360 341 367 388 404 377 406 428 447
LO PR 105 112 122 130 111 118 129 137 115 123 134 143 121 129 141 150 127 135 147 157 131 140 152 162
MBh 37.9 39.0 42.2 45.3 37.0 38.1 41.3 44.3 36.1 37.2 40.3 43.2 35.3 36.3 39.3 42.2 33.5 34.5 37.3 40.1 31.0 31.9 34.6 37.1
S/T 0.74 0.67 0.50 0.32 0.77 0.69 0.52 0.34 0.79 0.71 0.54 0.34 0.82 0.73 0.55 0.36 0.85 0.76 0.57 0.37 0.85 0.76 0.58 0.37
DT 25 23 19 13 25 23 19 13 25 23 19 13 25 23 19 13 25 23 19 13 23 21 17 12
1050 KW 2.29 2.34 2.43 2.51 2.49 2.54 2.63 2.73 2.66 2.72 2.82 2.92 2.81 2.88 2.98 3.09 2.94 3.01 3.12 3.23 3.05 3.12 3.24 3.36
AMPS 8.9 9.1 9.4 9.8 9.6 9.9 10.2 10.6 10.5 10.8 11.1 11.6 11.2 11.5 11.9 12.4 12.0 12.3 12.7 13.2 12.7 13.1 13.5 14.0
HI PR 202 218 230 240 227 244 258 269 258 278 294 306 294 317 334 349 331 356 376 392 366 394 416 434
LO PR 102 108 118 126 108 114 125 133 112 119 130 138 117 125 136 145 123 131 143 152 127 135 148 158
Shaded area is ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves.

11
COOLINGPERFORMANCEDATA DSZ180601A*-LOWSTAGE
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: DSZ180601A* / CA*F4961*6** + TXV / MBE2000**-1** Design Subcooling 5 - 7 °F @ the liquid service valve, AHRI 95° F test conditions
Outdoor Ambient Temperature
65 75 85 95 105 115
EnteringIndoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
MBh 43.0 44.0 47.0 50.2 42.0 43.0 45.9 49.1 41.0 41.9 44.8 47.9 40.0 40.9 43.7 46.7 38.0 38.9 41.5 44.4 35.2 36.0 38.5 41.1
S/T 0.89 0.83 0.68 0.51 0.92 0.86 0.70 0.52 0.94 0.88 0.72 0.54 1.00 0.91 0.74 0.56 1.00 0.95 0.77 0.58 1.00 0.96 0.78 0.58
DT 26 25 22 17 26 25 22 18 26 25 22 18 27 25 22 18 26 25 22 17 24 23 20 16
1350 KW 2.39 2.45 2.54 2.63 2.60 2.66 2.76 2.86 2.78 2.85 2.95 3.06 2.94 3.01 3.12 3.23 3.08 3.15 3.27 3.38 3.19 3.27 3.39 3.52
AMPS 9.3 9.5 9.9 10.3 10.1 10.4 10.7 11.1 11.0 11.3 11.7 12.1 11.8 12.1 12.5 13.0 12.6 12.9 13.4 13.9 13.4 13.7 14.2 14.7
HI PR 213 229 242 252 239 257 271 283 272 292 309 322 309 333 352 367 348 375 396 413 385 414 437 456
LO PR 107 114 124 133 113 120 131 140 118 125 137 146 124 131 144 153 130 138 150 160 134 143 156 166
MBh 41.8 42.7 45.6 48.8 40.8 41.7 44.6 47.6 39.8 40.7 43.5 46.5 38.9 39.7 42.4 45.4 36.9 37.7 40.3 43.1 34.2 35.0 37.3 39.9
S/T 0.85 0.79 0.65 0.48 0.88 0.82 0.67 0.50 0.90 0.84 0.69 0.51 0.93 0.87 0.71 0.53 0.96 0.90 0.74 0.55 0.97 0.91 0.74 0.55
DT 27 26 23 18 27 26 23 18 27 26 23 18 28 26 23 18 27 26 23 18 25 24 21 17
80 1200 KW 2.37 2.43 2.51 2.60 2.58 2.64 2.73 2.83 2.76 2.82 2.92 3.03 2.91 2.98 3.09 3.20 3.05 3.12 3.24 3.35 3.17 3.24 3.36 3.48
AMPS 9.2 9.5 9.8 10.2 10.0 10.3 10.6 11.0 10.9 11.2 11.6 12.0 11.7 12.0 12.4 12.9 12.5 12.8 13.2 13.7 13.2 13.6 14.0 14.6
HI PR 211 227 240 250 237 255 269 280 269 290 306 319 306 330 348 363 345 371 392 409 381 410 433 451
LO PR 106 113 123 131 112 119 130 139 116 124 135 144 122 130 142 151 128 136 149 159 133 141 154 164
MBh 38.6 39.4 42.1 45.0 37.7 38.5 41.1 44.0 36.8 37.6 40.2 42.9 35.9 36.7 39.2 41.9 34.1 34.8 37.2 39.8 31.6 32.3 34.5 36.9
S/T 0.82 0.77 0.62 0.47 0.85 0.79 0.65 0.48 0.87 0.81 0.66 0.49 0.89 0.84 0.68 0.51 0.93 0.87 0.71 0.53 0.94 0.88 0.71 0.53
DT 28 26 23 18 28 27 23 19 28 27 23 19 28 27 23 19 28 27 23 18 26 25 22 17
1050 KW 2.31 2.36 2.45 2.53 2.51 2.57 2.66 2.75 2.68 2.75 2.84 2.95 2.84 2.90 3.01 3.12 2.97 3.04 3.15 3.26 3.08 3.15 3.27 3.39
AMPS 9.0 9.2 9.5 9.9 9.7 10.0 10.3 10.7 10.6 10.9 11.2 11.7 11.4 11.6 12.0 12.5 12.1 12.4 12.8 13.4 12.9 13.2 13.6 14.2
HI PR 204 220 232 242 229 247 261 272 261 281 297 309 297 320 338 352 334 360 380 396 369 398 420 438
LO PR 103 109 120 127 109 116 126 134 113 120 131 140 119 126 138 147 124 132 144 154 129 137 149 159
MBh 43.8 44.6 46.8 49.9 42.8 43.6 45.7 48.7 41.8 42.6 44.6 47.6 40.7 41.5 43.5 46.4 38.7 39.5 41.3 44.1 35.9 36.5 38.3 40.8
S/T 0.93 0.90 0.81 0.66 0.96 0.93 0.84 0.68 0.99 0.95 0.86 0.70 1.00 0.98 0.89 0.72 1.00 1.00 0.92 0.75 1.00 1.00 0.93 0.75
DT 28 27 26 22 28 28 26 23 28 28 26 23 28 28 26 23 26 27 26 22 24 25 24 21
1350 KW 2.42 2.47 2.56 2.65 2.62 2.69 2.78 2.88 2.81 2.87 2.98 3.08 2.97 3.04 3.15 3.26 3.10 3.18 3.30 3.42 3.22 3.30 3.42 3.55
AMPS 9.4 9.6 10.0 10.4 10.2 10.5 10.8 11.2 11.1 11.4 11.8 12.3 11.9 12.2 12.6 13.1 12.7 13.0 13.5 14.0 13.5 13.8 14.3 14.9
HI PR 215 231 244 255 241 260 274 286 274 295 312 325 313 336 355 370 352 378 400 417 389 418 442 460
LO PR 108 115 126 134 114 122 133 141 119 126 138 147 125 133 145 154 131 139 152 162 135 144 157 167
MBh 42.5 43.3 45.4 48.4 41.5 42.3 44.3 47.3 40.5 41.3 43.3 46.2 39.6 40.3 42.2 45.1 37.6 38.3 40.1 42.8 34.8 35.5 37.2 39.6
S/T 0.89 0.86 0.77 0.63 0.92 0.89 0.80 0.65 0.94 0.91 0.82 0.67 0.97 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 0.98 0.89 0.72
DT 29 28 27 23 29 29 27 24 29 29 27 24 29 29 27 24 29 29 27 23 27 27 25 22
85 1200 KW 2.39 2.45 2.54 2.63 2.60 2.66 2.76 2.86 2.78 2.85 2.95 3.06 2.94 3.01 3.12 3.23 3.08 3.15 3.27 3.38 3.19 3.27 3.39 3.52
AMPS 9.3 9.5 9.9 10.3 10.1 10.4 10.7 11.1 11.0 11.3 11.7 12.1 11.8 12.1 12.5 13.0 12.6 12.9 13.4 13.9 13.4 13.7 14.2 14.7
HI PR 213 229 242 252 239 257 271 283 272 292 309 322 309 333 352 367 348 375 396 413 385 414 437 456
LO PR 107 114 124 133 113 120 131 140 118 125 137 146 124 131 144 153 130 138 150 160 134 143 156 166
MBh 39.2 40.0 41.9 44.7 38.3 39.1 40.9 43.7 37.4 38.1 40.0 42.6 36.5 37.2 39.0 41.6 34.7 35.4 37.0 39.5 32.1 32.7 34.3 36.6
S/T 0.86 0.83 0.74 0.60 0.89 0.86 0.77 0.63 0.91 0.88 0.79 0.64 0.94 0.91 0.82 0.66 0.97 0.94 0.85 0.69 0.98 0.95 0.86 0.69
DT29.39292724302928243029282430 29 28 243029272428272622
1050 KW 2.33 2.39 2.47 2.56 2.53 2.59 2.68 2.78 2.71 2.77 2.87 2.97 2.86 2.93 3.03 3.15 2.99 3.07 3.18 3.29 3.11 3.18 3.30 3.42
AMPS 9.1 9.3 9.6 10.0 9.8 10.1 10.4 10.8 10.7 11.0 11.3 11.8 11.5 11.8 12.2 12.6 12.2 12.5 13.0 13.5 13.0 13.3 13.8 14.3
HI PR 207 222 235 245 232 249 263 275 264 284 300 312 300 323 341 356 338 363 384 400 373 402 424 442
LO PR 104 111 121 129 110 117 128 136 114 121 133 141 120 128 139 148 126 134 146 155 130 138 151 161
Shaded area is AHRI Rating Conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves.

12
COOLINGPERFORMANCEDATA DSZ180361A*-HIGHSTAGE
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: DSZ180361A* / CA*F3743*6** + TXV / MBE1600**-1** DesignSubcooling 5 - 7 °F @ the liquid service valve, AHRI 95° F test conditions.
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet BulbTemperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
MBh 34.5 35.8 39.2 - 33.7 34.9 38.3 - 32.9 34.1 37.4 - 32.1 33.3 36.5 - 30.5 31.6 34.6 - 28.3 29.3 32.1 -
S/T 0.76 0.63 0.44 - 0.79 0.66 0.45 - 0.81 0.67 0.47 - 0.83 0.70 0.48 - 0.86 0.72 0.50 - 0.87 0.73 0.50 -
DT 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 11 -
1406 KW 2.10 2.14 2.21 - 2.26 2.31 2.39 - 2.41 2.47 2.55 - 2.54 2.60 2.69 - 2.65 2.71 2.81 - 2.75 2.81 2.91 -
AMPS 7.8 8.0 8.2 - 8.4 8.6 8.9 - 9.2 9.4 9.7 - 9.8 10.1 10.4 - 10.5 10.7 11.1 - 11.1 11.4 11.8 -
HI PR 219 235 249 - 245 264 279 - 279 300 317 - 318 342 361 - 358 385 406 - 395 425 449 -
LO PR 107 114 124 - 113 120 131 - 117 125 136 - 123 131 143 - 129 137 150 - 134 142 155 -
MBh 33.5 34.7 38.1 - 32.7 33.9 37.2 - 32.0 33.1 36.3 - 31.2 32.3 35.4 - 29.6 30.7 33.6 - 27.4 28.4 31.2 -
S/T 0.72 0.60 0.42 - 0.75 0.63 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.69 0.48 - 0.83 0.69 0.48 -
DT 18 15 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
70 1250 KW 2.08 2.13 2.19 - 2.25 2.30 2.37 - 2.39 2.45 2.53 - 2.52 2.58 2.67 - 2.63 2.69 2.78 - 2.73 2.79 2.88 -
AMPS 7.7 7.9 8.1 - 8.3 8.5 8.8 - 9.1 9.3 9.6 - 9.7 10.0 10.3 - 10.4 10.6 11.0 - 11.0 11.3 11.7 -
HI PR 217 233 246 - 243 261 276 - 276 297 314 - 315 339 358 - 354 381 402 - 391 421 445 -
LO PR 106 113 123 - 112 119 130 - 116 124 135 - 122 130 142 - 128 136 149 - 132 141 154 -
MBh 30.9 32.1 35.1 - 30.2 31.3 34.3 - 29.5 30.6 33.5 - 28.8 29.8 32.7 - 27.3 28.3 31.0 - 25.3 26.2 28.8 -
S/T 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.80 0.67 0.46 -
DT 18 16 12 - 18 16 12 - 18 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -
1094 KW 2.03 2.07 2.14 - 2.19 2.24 2.31 - 2.33 2.38 2.46 - 2.46 2.51 2.60 - 2.56 2.62 2.71 - 2.66 2.72 2.81 -
AMPS 7.5 7.7 7.9 - 8.1 8.3 8.6 - 8.8 9.0 9.3 - 9.4 9.7 10.0 - 10.1 10.3 10.7 - 10.7 10.9 11.3 -
HI PR 210 226 239 - 236 254 268 - 268 288 305 - 305 329 347 - 343 370 390 - 379 408 431 -
LO PR 103 109 119 - 108 115 126 - 113 120 131 - 118 126 138 - 124 132 144 - 128 137 149 -
MBh 35.1 36.1 39.1 42.0 34.3 35.3 38.2 41.0 33.5 34.5 37.3 40.0 32.7 33.6 36.4 39.1 31.0 31.9 34.6 37.1 28.7 29.6 32.0 34.4
S/T 0.86 0.77 0.58 0.38 0.89 0.80 0.60 0.39 0.92 0.82 0.62 0.40 0.95 0.85 0.64 0.41 0.98 0.88 0.66 0.43 0.99 0.89 0.67 0.43
DT 20 18 15 10 20 18 15 10 20 18 15 10 20 19 15 11 20 18 15 10 19 17 14 10
1406 KW 2.11 2.16 2.23 2.31 2.28 2.33 2.41 2.49 2.43 2.49 2.57 2.66 2.56 2.62 2.71 2.81 2.68 2.74 2.83 2.93 2.77 2.84 2.94 3.04
AMPS 7.8 8.0 8.3 8.6 8.5 8.7 9.0 9.3 9.2 9.5 9.8 10.2 9.9 10.2 10.5 10.9 10.6 10.8 11.2 11.6 11.2 11.5 11.9 12.3
HI PR 221 238 251 262 248 267 282 294 282 303 320 334 321 346 365 381 361 389 411 428 399 430 454 473
LO PR 108 115 125 134 114 121 133 141 119 126 138 147 125 133 145 154 131 139 152 161 135 144 157 167
MBh 34.1 35.1 38.0 40.8 33.3 34.3 37.1 39.8 32.5 33.5 36.2 38.9 31.7 32.6 35.3 37.9 30.1 31.0 33.6 36.0 27.9 28.7 31.1 33.4
S/T 0.82 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.94 0.84 0.63 0.41 0.94 0.84 0.64 0.41
DT 21 19 16 11 21 19 16 11 21 19 16 11 21 19 16 11 21 19 16 11 19 18 15 10
75 1250 KW 2.10 2.14 2.21 2.29 2.26 2.32 2.39 2.47 2.41 2.47 2.55 2.64 2.54 2.60 2.69 2.78 2.65 2.72 2.81 2.91 2.75 2.81 2.91 3.01
AMPS 7.8 8.0 8.2 8.5 8.4 8.6 8.9 9.3 9.2 9.4 9.7 10.1 9.8 10.1 10.4 10.8 10.5 10.7 11.1 11.5 11.1 11.4 11.8 12.2
HI PR 219 235 249 259 245 264 279 291 279 300 317 331 318 342 361 377 358 385 406 424 395 425 449 468
LO PR 107 114 124 132 113 120 131 140 117 125 136 145 123 131 143 153 129 138 150 160 134 142 155 165
MBh 31.5 32.4 35.1 37.6 30.7 31.6 34.2 36.8 30.0 30.9 33.4 35.9 29.3 30.1 32.6 35.0 27.8 28.6 31.0 33.3 25.8 26.5 28.7 30.8
S/T 0.79 0.71 0.54 0.35 0.82 0.74 0.56 0.36 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.91 0.81 0.62 0.40
DT 21 19 16 11 21 20 16 11 21 20 16 11 21 20 16 11 21 19 16 11 20 18 15 10
1094 KW 2.04 2.09 2.16 2.23 2.21 2.26 2.33 2.41 2.35 2.40 2.48 2.57 2.48 2.53 2.62 2.71 2.59 2.64 2.73 2.83 2.68 2.74 2.83 2.93
AMPS 7.5 7.7 8.0 8.3 8.2 8.4 8.7 9.0 8.9 9.1 9.4 9.8 9.5 9.8 10.1 10.5 10.2 10.4 10.8 11.2 10.8 11.1 11.4 11.9
HI PR 212 228 241 251 238 256 271 282 271 291 308 321 308 332 350 366 347 373 394 411 383 413 436 454
LO PR 104 110 120 128 110 117 127 136 114 121 132 141 120 127 139 148 125 133 146 155 130 138 151 160
Shaded area is ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves.

13
COOLINGPERFORMANCEDATA DSZ180361A*-HIGHSTAGE
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: DSZ180361A* / CA*F3743*6** + TXV / MBE1600**-1** DesignSubcooling 5 - 7 °F @ the liquidservice valve, AHRI 95° F test conditions
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet BulbTemperature
IDB*Airflow 59 63 677159 636771 59 63 677159 63 67 715963677159636771
MBh 35.7 36.5 39.0 41.7 34.9 35.7 38.1 40.7 34.1 34.8 37.2 39.8 33.2 34.0 36.3 38.8 31.6 32.3 34.5 36.8 29.2 29.9 31.9 34.1
S/T 0.95 0.89 0.72 0.54 1.00 0.92 0.75 0.56 1.00 0.94 0.77 0.57 1.00 1.00 0.79 0.59 1.00 1.00 0.82 0.61 1.00 1.00 0.83 0.62
DT 22 21 18 15 23 21 19 15 22 21 19 15 22 22 19 15 21 21 19 15 19 20 17 14
1406 KW 2.13 2.18 2.25 2.33 2.30 2.35 2.43 2.52 2.45 2.51 2.59 2.68 2.59 2.65 2.74 2.83 2.70 2.76 2.86 2.96 2.80 2.86 2.96 3.07
AMPS 7.9 8.1 8.4 8.7 8.6 8.8 9.1 9.4 9.3 9.6 9.9 10.3 10.0 10.2 10.6 11.0 10.7 10.9 11.3 11.7 11.3 11.6 12.0 12.5
HI PR 223 240 254 265 250 269 285 297 285 306 324 338 324 349 369 384 365 393 415 433 403 434 458 478
LO PR 109 116 127 135 115 123 134 143 120 127 139 148 126 134 146 156 132 140 153 163 136 145 158 169
MBh 34.7 35.4 37.9 40.5 33.9 34.6 37.0 39.5 33.1 33.8 36.1 38.6 32.3 33.0 35.2 37.7 30.7 31.3 33.5 35.8 28.4 29.0 31.0 33.1
S/T 0.90 0.85 0.69 0.51 0.93 0.88 0.71 0.53 0.96 0.90 0.73 0.55 0.99 0.93 0.76 0.56 1.00 0.96 0.78 0.59 1.00 0.97 0.79 0.59
DT 23 22 19 15 23 22 19 16 23 22 19 16 23 23 20 16 23 22 19 15 21 21 18 14
80 1250 KW 2.11 2.16 2.23 2.31 2.28 2.33 2.41 2.49 2.43 2.49 2.57 2.66 2.57 2.62 2.71 2.81 2.68 2.74 2.83 2.93 2.77 2.84 2.94 3.04
AMPS 7.8 8.0 8.3 8.6 8.5 8.7 9.0 9.3 9.2 9.5 9.8 10.2 9.9 10.2 10.5 10.9 10.6 10.8 11.2 11.6 11.2 11.5 11.9 12.3
HI PR 221 238 251 262 248 267 282 294 282 303 320 334 321 346 365 381 361 389 411 428 399 430 454 473
LO PR 108 115 125 134 114 121 133 141 119 126 138 147 125 133 145 154 131 139 152 162 135 144 157 167
MBh 32.0 32.7 35.0 37.4 31.3 32.0 34.1 36.5 30.5 31.2 33.3 35.6 29.8 30.4 32.5 34.8 28.3 28.9 30.9 33.0 26.2 26.8 28.6 30.6
S/T 0.87 0.82 0.66 0.50 0.90 0.85 0.69 0.51 0.92 0.87 0.71 0.53 0.95 0.89 0.73 0.54 0.99 0.93 0.76 0.56 1.00 0.94 0.76 0.57
DT 23 22 20 16 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 22 21 18 15
1094 KW 2.06 2.11 2.18 2.25 2.23 2.28 2.35 2.43 2.37 2.42 2.51 2.59 2.50 2.56 2.64 2.73 2.61 2.67 2.76 2.85 2.70 2.76 2.86 2.96
AMPS 7.6 7.8 8.1 8.4 8.3 8.5 8.7 9.1 9.0 9.2 9.5 9.9 9.6 9.9 10.2 10.6 10.3 10.5 10.9 11.3 10.9 11.2 11.5 12.0
HI PR 214 231 244 254 240 259 273 285 274 294 311 324 312 335 354 369 350 377 398 415 387 417 440 459
LO PR 105 111 122 130 111 118 129 137 115 122 134 142 121 129 140 149 127 135 147 157 131 139 152 162
MBh 36.4 37.1 38.8 41.4 35.5 36.2 37.9 40.4 34.7 35.3 37.0 39.5 33.8 34.5 36.1 38.5 32.1 32.7 34.3 36.6 29.8 30.3 31.8 33.9
S/T 0.99 0.96 0.86 0.70 1.00 0.99 0.89 0.73 1.00 1.00 0.92 0.74 1.00 1.00 0.95 0.77 1.00 1.00 0.98 0.80 1.00 1.00 0.99 0.80
DT 24 23 22 19 23 23 22 19 23 23 22 19 22 23 22 19 21 21 22 19 19 20 21 18
1406 KW 2.15 2.20 2.27 2.35 2.32 2.37 2.45 2.54 2.47 2.53 2.62 2.71 2.61 2.67 2.76 2.86 2.72 2.79 2.88 2.98 2.82 2.89 2.99 3.09
AMPS 8.0 8.2 8.5 8.8 8.7 8.9 9.2 9.5 9.4 9.7 10.0 10.4 10.1 10.3 10.7 11.1 10.8 11.0 11.4 11.9 11.4 11.7 12.1 12.6
HI PR 225 243 256 267 253 272 287 300 288 310 327 341 328 353 372 388 369 397 419 437 407 438 463 483
LO PR 110 117 128 136 116 124 135 144 121 129 141 150 127 135 148 157 133 142 155 165 138 147 160 170
MBh 35.3 36.0 37.7 40.2 34.5 35.1 36.8 39.3 33.7 34.3 35.9 38.3 32.8 33.5 35.1 37.4 31.2 31.8 33.3 35.5 28.9 29.5 30.8 32.9
S/T 0.95 0.91 0.82 0.67 0.98 0.95 0.85 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.94 0.76 1.00 1.00 0.95 0.77
DT 25 24 23 20 25 24 23 20 25 24 23 20 24 25 23 20 23 23 23 20 21 22 21 19
85 1250 KW 2.13 2.18 2.25 2.33 2.30 2.35 2.43 2.52 2.45 2.51 2.59 2.68 2.59 2.65 2.74 2.83 2.70 2.76 2.86 2.96 2.80 2.86 2.96 3.07
AMPS 7.9 8.1 8.4 8.7 8.6 8.8 9.1 9.4 9.3 9.6 9.9 10.3 10.0 10.2 10.6 11.0 10.7 10.9 11.3 11.7 11.3 11.6 12.0 12.5
HI PR 223 240 254 265 250 269 285 297 285 306 324 338 324 349 369 384 365 393 415 433 403 434 458 478
LO PR 109 116 127 135 115 123 134 143 120 127 139 148 126 134 146 156 132 140 153 163 136 145 158 169
MBh 32.6 33.2 34.8 37.1 31.8 32.4 34.0 36.2 31.1 31.7 33.2 35.4 30.3 30.9 32.4 34.5 28.8 29.3 30.7 32.8 26.7 27.2 28.5 30.4
S/T 0.91 0.88 0.79 0.64 0.94 0.91 0.82 0.67 0.97 0.93 0.84 0.68 1.00 0.97 0.87 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.91 0.74
DT 25 25 23 20 25 25 23 20 25 25 24 20 25 25 24 21 24 25 23 20 22 23 22 19
1094 KW 2.08 2.12 2.19 2.27 2.24 2.29 2.37 2.45 2.39 2.45 2.53 2.61 2.52 2.58 2.67 2.76 2.63 2.69 2.78 2.88 2.73 2.79 2.88 2.98
AMPS 7.7 7.9 8.1 8.5 8.3 8.5 8.8 9.2 9.1 9.3 9.6 10.0 9.7 10.0 10.3 10.7 10.4 10.6 11.0 11.4 11.0 11.3 11.7 12.1
HI PR 216 233 246 257 243 261 276 288 276 297 314 327 315 339 358 373 354 381 402 420 391 421 444 464
LO PR 106 113 123 131 112 119 130 138 116 124 135 144 122 130 142 151 128 136 149 158 132 141 154 164
Shaded area is AHRI Rating Conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves.

14
COOLINGPERFORMANCEDATA DSZ180481A*-HIGHSTAGE
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: DSZ180481A* /CA*F4961*6** + TXV / MBE2000**-1** Design Subcooling 5 - 7 °F @ the liquidservice valve, AHRI 95° F test conditions
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 596367715963677159 63 677159 63 67 715963677159636771
MBh 49.0 50.8 55.6 - 47.9 49.6 54.3 - 46.7 48.4 53.1 - 45.6 47.2 51.8 - 43.3 44.9 49.2 - 40.1 41.6 45.5 -
S/T 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.86 0.72 0.50 - 0.87 0.72 0.50 -
DT 17 15 11 - 17 15 11 - 17 15 11 - 18 15 12 - 17 15 11 - 16 14 11 -
1969 KW 2.88 2.94 3.04 - 3.10 3.17 3.28 - 3.31 3.38 3.49 - 3.48 3.56 3.68 - 3.63 3.72 3.84 - 3.76 3.85 3.98 -
AMPS 10.3 10.6 10.9 - 11.2 11.5 11.8 - 12.2 12.5 12.9 - 13.1 13.4 13.9 - 13.9 14.3 14.8 - 14.8 15.2 15.7 -
HI PR 214 231 244 - 241 259 273 - 274 295 311 - 312 335 354 - 351 377 399 - 387 417 440 -
LO PR 106 113 123 - 112 119 130 - 116 124 135 - 122 130 142 - 128 136 149 - 132 141 154 -
MBh 47.6 49.3 54.0 - 46.5 48.2 52.8 - 45.4 47.0 51.5 - 44.3 45.9 50.3 - 42.0 43.6 47.7 - 38.9 40.4 44.2 -
S/T 0.72 0.60 0.42 - 0.75 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.83 0.69 0.48 -
DT 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
70 1750 KW 2.85 2.92 3.01 - 3.08 3.15 3.25 - 3.28 3.35 3.46 - 3.45 3.53 3.65 - 3.60 3.68 3.81 - 3.73 3.82 3.95 -
AMPS 10.2 10.5 10.8 - 11.1 11.3 11.7 - 12.1 12.4 12.8 - 12.9 13.3 13.7 - 13.8 14.1 14.6 - 14.7 15.0 15.6 -
HI PR 212 229 241 - 238 256 271 - 271 292 308 - 309 332 351 - 347 374 395 - 384 413 436 -
LO PR 105 112 122 - 111 118 129 - 115 123 134 - 121 129 141 - 127 135 147 - 131 140 152 -
MBh 43.9 45.5 49.9 - 42.9 44.4 48.7 - 41.9 43.4 47.5 - 40.8 42.3 46.4 - 38.8 40.2 44.1 - 35.9 37.3 40.8 -
S/T 0.69 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.80 0.66 0.46 -
DT 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -
1531 KW 2.78 2.84 2.94 - 3.00 3.07 3.17 - 3.20 3.27 3.37 - 3.37 3.44 3.56 - 3.51 3.59 3.71 - 3.64 3.72 3.84 -
AMPS 9.9 10.2 10.5 - 10.7 11.0 11.4 - 11.7 12.0 12.4 - 12.6 12.9 13.3 - 13.4 13.7 14.2 - 14.2 14.6 15.1 -
HI PR 206 222 234 - 231 249 263 - 263 283 299 - 299 322 340 - 337 362 383 - 372 400 423 -
LO PR 102 108 118 - 108 114 125 - 112 119 130 - 117 125 136 - 123 131 143 - 127 135 148 -
MBh 49.8 51.3 55.5 59.6 48.7 50.1 54.2 58.2 47.5 48.9 52.9 56.8 46.4 47.7 51.7 55.4 44.0 45.3 49.1 52.7 40.8 42.0 45.5 48.8
S/T 0.860.770.580.370.890.790.600.390.91 0.81 0.620.400.940.84 0.64 0.41 0.98 0.87 0.66 0.42 0.98 0.88 0.67 0.43
DT 20 18 15 10 20 19 15 11 20 19 15 11 20 19 15 11 20 18 15 10 19 17 14 10
1969 KW 2.90 2.96 3.06 3.16 3.13 3.20 3.31 3.42 3.33 3.41 3.52 3.64 3.51 3.59 3.71 3.84 3.67 3.75 3.88 4.01 3.80 3.88 4.02 4.16
AMPS 10.4 10.7 11.0 11.4 11.3 11.6 12.0 12.4 12.3 12.6 13.0 13.6 13.2 13.5 14.0 14.5 14.1 14.4 14.9 15.5 14.9 15.3 15.9 16.5
HI PR 217 233 246 257 243 262 276 288 277 298 314 328 315 339 358 373 354 381 403 420 391 421 445 464
LO PR 107 114 124 132 113 120 131 140 118 125 137 145 123 131 143 153 129 138 150 160 134 142 155 166
MBh 48.4 49.8 53.9 57.9 47.3 48.6 52.7 56.5 46.1 47.5 51.4 55.2 45.0 46.3 50.2 53.8 42.8 44.0 47.6 51.1 39.6 40.8 44.1 47.4
S/T 0.820.730.550.360.850.760.570.370.87 0.78 0.590.380.900.80 0.61 0.39 0.93 0.83 0.63 0.41 0.94 0.84 0.64 0.41
DT 21 19 16 11 21 19 16 11 21 19 16 11 21 20 16 11 21 19 16 11 20 18 15 10
75 1750 KW 2.88 2.94 3.04 3.14 3.11 3.17 3.28 3.39 3.31 3.38 3.49 3.61 3.48 3.56 3.68 3.81 3.63 3.72 3.84 3.98 3.76 3.85 3.98 4.12
AMPS 10.3 10.6 10.9 11.3 11.2 11.5 11.8 12.3 12.2 12.5 12.9 13.4 13.1 13.4 13.9 14.4 13.9 14.3 14.8 15.4 14.8 15.2 15.7 16.3
HI PR 215 231 244 254 241 259 274 285 274 295 311 324 312 336 354 370 351 377 399 416 388 417 440 459
LO PR 106 113 123 131 112 119 130 138 116 124 135 144 122 130 142 151 128 136 149 158 133 141 154 164
MBh 44.7 46.0 49.8 53.4 43.6 44.9 48.6 52.2 42.6 43.8 47.4 50.9 41.5 42.8 46.3 49.7 39.5 40.6 44.0 47.2 36.6 37.6 40.7 43.7
S/T 0.790.700.530.340.820.730.550.360.84 0.75 0.570.360.860.77 0.59 0.38 0.90 0.80 0.61 0.39 0.90 0.81 0.61 0.39
DT 21 19 16 11 21 20 16 11 21 20 16 11 22 20 16 11 21 20 16 11 20 18 15 10
1531 KW 2.81 2.87 2.96 3.06 3.03 3.09 3.20 3.30 3.22 3.29 3.40 3.52 3.39 3.47 3.59 3.71 3.54 3.62 3.74 3.87 3.67 3.75 3.88 4.01
AMPS 10.0 10.3 10.6 11.0 10.9 11.1 11.5 12.0 11.8 12.1 12.6 13.0 12.7 13.0 13.5 14.0 13.5 13.9 14.4 14.9 14.4 14.7 15.2 15.9
HI PR 208 224 236 247 233 251 265 277 266 286 302 315 302 325 344 358 340 366 387 403 376 405 427 446
LO PR 103 109 119 127 109 116 126 134 113 120 131 140 119 126 138 147 124 132 144 154 129 137 149 159
Sh
a
d
e
d
area
i
s
ACCA
(TVA)
con
diti
ons
IDB
:
E
n
t
er
i
n
g
I
n
d
oor
D
r
y
B
u
lb
T
empera
t
ure
KW
=
T
o
t
a
l
s
y
s
t
em power
AMPS
=ou
td
oor un
it
amps
(
comp.+
f
an
)
High
an
d
l
ow pressures are measure
d
att
h
e
li
qu
id
an
d
suct
i
onserv
i
ce va
l
ves.

15
COOLINGPERFORMANCEDATA DSZ180481A*-HIGHSTAGE
EXPANDED PERFORMANCE DAT
A
COOLING OPERATION
MODEL: DSZ180481A* / CA*F4961*6** + TXV / MBE2000**-1** Design Subcooling 5 - 7 °F @ the liquidservice valve, AHRI 95° F test conditions
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 596367715963677159 63 677159 63 67 715963677159636771
MBh 50.7 51.8 55.4 59.2 49.5 50.6 54.1 57.8 48.4 49.4 52.8 56.4 47.2 48.2 51.5 55.1 44.8 45.8 48.9 52.3 41.5 42.4 45.3 48.4
S/T 0.94 0.88 0.72 0.54 1.00 0.91 0.74 0.56 1.00 0.94 0.76 0.57 1.00 0.97 0.79 0.59 1.00 1.00 0.82 0.61 1.00 1.00 0.82 0.62
DT 22 21 19 15 23 22 19 15 23 22 19 15 22 22 19 15 21 21 19 15 19 20 17 14
1969 KW 2.93 2.99 3.09 3.19 3.16 3.23 3.33 3.45 3.36 3.44 3.55 3.67 3.54 3.62 3.75 3.87 3.70 3.78 3.91 4.05 3.83 3.92 4.05 4.19
AMPS10.510.811.111.611.411.712.112.512.4 12.7 13.213.713.313.6 14.1 14.714.214.615.115.715.115.516.016.6
HI PR 219 236 249 259 246 264 279 291 279 301 317 331 318 342 361 377 358 385 407 424 395 426 449 469
LO PR 108 115 126 134 114 122 133 141 119 126 138 147 125 133 145 154 131 139 152 162 135 144 157 167
MBh 49.2 50.3 53.8 57.5 48.1 49.1 52.5 56.1 46.9 48.0 51.3 54.8 45.8 46.8 50.0 53.5 43.5 44.5 47.5 50.8 40.3 41.2 44.0 47.0
S/T 0.90 0.84 0.68 0.51 0.93 0.87 0.71 0.53 0.95 0.89 0.73 0.54 0.98 0.92 0.75 0.56 1.00 0.96 0.78 0.58 1.00 0.97 0.79 0.59
DT 23 22 19 15 23 22 20 16 23 23 20 16 24 23 20 16 23 22 19 16 21 21 18 15
80 1750 KW 2.90 2.96 3.06 3.16 3.13 3.20 3.31 3.42 3.33 3.41 3.52 3.64 3.51 3.59 3.71 3.84 3.67 3.75 3.88 4.01 3.80 3.88 4.02 4.16
AMPS 10.4 10.7 11.0 11.5 11.3 11.6 12.0 12.4 12.3 12.6 13.0 13.6 13.2 13.5 14.0 14.5 14.1 14.4 14.9 15.5 14.9 15.3 15.9 16.5
HI PR 217 233 246 257 243 262 276 288 277 298 314 328 315 339 358 373 354 381 403 420 391 421 445 464
LO PR 107 114 124 132 113 120 131 140 118 125 137 145 123 131 143 153 129 138 150 160 134 142 155 166
MBh 45.4 46.4 49.6 53.0 44.4 45.4 48.5 51.8 43.3 44.3 47.3 50.6 42.3 43.2 46.2 49.3 40.2 41.0 43.8 46.9 37.2 38.0 40.6 43.4
S/T 0.86 0.81 0.66 0.49 0.90 0.84 0.68 0.51 0.92 0.86 0.70 0.52 0.95 0.89 0.72 0.54 0.98 0.92 0.75 0.56 0.99 0.93 0.76 0.57
DT 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 22 21 18 15
1531 KW 2.83 2.89 2.98 3.08 3.05 3.12 3.22 3.33 3.25 3.32 3.43 3.55 3.42 3.50 3.62 3.74 3.57 3.65 3.78 3.91 3.70 3.78 3.91 4.05
AMPS10.110.410.711.111.011.211.612.111.9 12.3 12.713.212.813.1 13.6 14.113.714.014.515.114.514.915.416.0
HI PR 210 226 239 249 236 254 268 280 268 289 305 318 306 329 347 362 344 370 391 407 380 409 432 450
LO PR 104 110 121 128 110 117 127 136 114 121 132 141 120 127 139 148 126 134 146 155 130 138 151 161
MBh 51.6 52.6 55.1 58.8 50.4 51.4 53.8 57.4 49.2 50.2 52.5 56.0 48.0 48.9 51.2 54.7 45.6 46.5 48.7 51.9 42.2 43.1 45.1 48.1
S/T 0.99 0.95 0.86 0.70 1.00 0.99 0.89 0.72 1.00 1.00 0.91 0.74 1.00 1.00 0.94 0.76 1.00 1.00 0.98 0.79 1.00 1.00 0.99 0.80
DT 24 23 22 19 24 24 22 19 23 23 22 19 22 23 23 19 21 22 22 19 20 20 21 18
1969 KW 2.95 3.01 3.11 3.22 3.18 3.25 3.36 3.48 3.39 3.47 3.58 3.71 3.57 3.65 3.78 3.91 3.73 3.81 3.94 4.08 3.86 3.95 4.09 4.23
AMPS10.610.911.211.711.511.812.212.712.5 12.9 13.313.813.413.8 14.3 14.814.314.715.215.815.215.616.216.8
HI PR 221 238 251 262 248 267 282 294 282 304 321 334 321 346 365 381 361 389 411 428 399 430 454 473
LO PR 109 116 127 135 115 123 134 143 120 128 139 148 126 134 146 156 132 140 153 163 137 145 159 169
MBh 50.1 51.1 53.5 57.1 48.9 49.9 52.2 55.7 47.8 48.7 51.0 54.4 46.6 47.5 49.8 53.1 44.3 45.1 47.3 50.4 41.0 41.8 43.8 46.7
S/T 0.94 0.91 0.82 0.66 0.97 0.94 0.85 0.69 1.00 0.96 0.87 0.71 1.00 0.99 0.90 0.73 1.00 1.00 0.93 0.76 1.00 1.00 0.94 0.76
DT 25 24 23 20 25 25 23 20 25 25 23 20 24 25 23 20 23 24 23 20 22 22 22 19
85 1750 KW 2.93 2.99 3.09 3.19 3.16 3.23 3.33 3.45 3.36 3.44 3.55 3.67 3.54 3.62 3.75 3.87 3.70 3.78 3.91 4.05 3.83 3.92 4.05 4.19
AMPS10.510.811.111.611.411.712.112.512.4 12.7 13.213.713.313.6 14.1 14.714.214.615.115.715.115.516.016.6
HI PR 219 236 249 259 246 264 279 291 279 301 317 331 318 342 361 377 358 385 407 424 395 426 449 469
LO PR 108 115 126 134 114 122 133 141 119 126 138 147 125 133 145 154 131 139 152 162 135 144 157 167
MBh 46.2 47.1 49.4 52.7 45.2 46.0 48.2 51.4 44.1 44.9 47.1 50.2 43.0 43.8 45.9 49.0 40.9 41.7 43.6 46.5 37.9 38.6 40.4 43.1
S/T 0.91 0.87 0.79 0.64 0.94 0.91 0.82 0.66 0.96 0.93 0.84 0.68 0.99 0.96 0.87 0.70 1.00 1.00 0.90 0.73 1.00 1.00 0.91 0.74
DT 25 25 23 20 25 25 24 20 25 25 24 21 26 25 24 21 25 25 24 20 23 23 22 19
1531 KW 2.85 2.92 3.01 3.11 3.08 3.15 3.25 3.36 3.28 3.35 3.46 3.58 3.45 3.53 3.65 3.77 3.60 3.68 3.81 3.94 3.73 3.82 3.95 4.08
AMPS10.210.510.811.211.111.311.712.212.1 12.4 12.813.312.913.3 13.7 14.313.814.114.615.214.615.015.516.2
HI PR 212 228 241 252 238 256 271 282 271 292 308 321 309 332 351 366 347 374 394 411 384 413 436 455
LO PR 105 112 122 130 111 118 129 137 115 123 134 142 121 129 140 150 127 135 147 157 131 139 152 162
Shaded area is AHRI Rating Conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan)
High
an
d
l
ow pressures are measure
d
att
h
e
li
qu
id
an
d
suct
i
onserv
i
ce va
l
ves.

16
COOLINGPERFORMANCEDATA DSZ180601A*-HIGHSTAGE
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: DSZ180601A* /CA*F4961*6** + TXV /MBE2000**-1** Design Subcooling 5 - 7 °F @ the liquid service valve, AHRI 95° F test conditions
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
MBh 55.4 57.4 62.9 - 54.1 56.1 61.4 - 52.8 54.7 59.9 - 51.5 53.4 58.5 - 48.9 50.7 55.6 - 45.3 47.0 51.5 -
S/T 0.72 0.60 0.42 - 0.75 0.63 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.69 0.48 - 0.83 0.69 0.48 -
DT 19 16 12 - 19 16 12 - 19 16 12 - 19 16 13 - 19 16 12 - 18 15 12 -
1969 KW 3.59 3.67 3.80 - 3.89 3.98 4.11 - 4.15 4.24 4.39 - 4.38 4.48 4.64 - 4.57 4.68 4.85 - 4.74 4.86 5.03 -
AMPS 7.2 7.5 8.0 - 8.3 8.7 9.2 - 9.6 10.0 10.6 - 10.8 11.2 11.8 - 11.9 12.4 13.0 - 13.0 13.5 14.2 -
HI PR 218 235 248 - 245 264 278 - 279 300 317 - 317 342 361 - 357 384 406 - 395 425 448 -
LO PR 101 107 117 - 106 113 124 - 111 118 129 - 116 124 135 - 122 130 141 - 126 134 146 -
MBh 53.8 55.7 61.0 - 52.5 54.4 59.6 - 51.3 53.1 58.2 - 50.0 51.8 56.8 - 47.5 49.2 53.9 - 44.0 45.6 50.0 -
S/T 0.69 0.58 0.40 - 0.71 0.60 0.41 - 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.78 0.66 0.45 - 0.79 0.66 0.46 -
DT 19 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -
70 1750 KW 3.56 3.64 3.76 - 3.85 3.94 4.08 - 4.11 4.21 4.35 - 4.34 4.44 4.60 - 4.53 4.64 4.80 - 4.70 4.81 4.98 -
AMPS 7.1 7.4 7.9 - 8.2 8.5 9.1 - 9.5 9.9 10.4 - 10.6 11.0 11.6 - 11.7 12.2 12.8 - 12.8 13.3 14.0 -
HI PR 216 233 246 - 243 261 276 - 276 297 314 - 314 338 357 - 354 381 402 - 391 420 444 -
LO PR 100 106 116 - 105 112 122 - 110 117 127 - 115 122 134 - 121 128 140 - 125 133 145 -
MBh 49.6 51.4 56.3 - 48.5 50.2 55.0 - 47.3 49.0 53.7 - 46.2 47.8 52.4 - 43.8 45.4 49.8 - 40.6 42.1 46.1 -
S/T 0.66 0.55 0.38 - 0.69 0.58 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.76 0.64 0.44 -
DT 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 19 16 12 -
1531 KW 3.47 3.55 3.67 - 3.75 3.84 3.97 - 4.01 4.10 4.24 - 4.23 4.33 4.47 - 4.42 4.52 4.68 - 4.58 4.69 4.85 -
AMPS 6.7 7.0 7.5 - 7.8 8.1 8.6 - 9.0 9.4 10.0 - 10.1 10.5 11.1 - 11.2 11.7 12.3 - 12.3 12.8 13.4 -
HI PR 210 226 238 - 235 253 267 - 268 288 304 - 305 328 346 - 343 369 390 - 379 408 431 -
LO PR 97 103 112 - 102 109 119 - 106 113 123 - 112 119 130 - 117 124 136 - 121 129 141 -
MBh 56.3 58.0 62.7 67.3 55.0 56.6 61.3 65.8 53.7 55.3 59.8 64.2 52.4 53.9 58.4 62.649.851.255.559.546.147.551.455.1
S/T 0.820.730.560.360.850.760.580.370.870.780.590.380.90 0.81 0.61 0.39 0.93 0.84 0.63 0.41 0.94 0.84 0.64 0.41
DT 22 20 16 11 22 20 16 11 22 20 17 11 22 20 17 11 22 20 16 11 20 19 15 11
1969 KW 3.62 3.71 3.83 3.96 3.92 4.01 4.15 4.29 4.19 4.28 4.43 4.59 4.42 4.52 4.68 4.84 4.62 4.72 4.89 5.06 4.79 4.90 5.07 5.25
AMPS 7.3 7.7 8.1 8.7 8.5 8.8 9.4 10.0 9.8 10.2 10.8 11.4 10.9 11.4 12.0 12.712.112.513.214.013.213.714.415.2
HI PR 221 237 251 261 248 266 281 293 282 303 320 334 321 345 364 380 361 388 410 428 399 429 453 472
LO PR 102 108 118 126 108 114 125 133 112 119 130 138 117 125 136 145 123 131 143 152 127 135 148 157
MBh 54.7 56.3 60.9 65.4 53.4 55.0 59.5 63.9 52.1 53.7 58.1 62.3 50.9 52.4 56.7 60.848.349.753.857.844.746.149.953.5
S/T 0.780.700.530.340.810.730.550.350.830.740.560.360.86 0.77 0.58 0.37 0.89 0.80 0.60 0.39 0.90 0.80 0.61 0.39
DT 22 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 21 19 16 11
75 1750 KW 3.59 3.67 3.80 3.93 3.89 3.98 4.11 4.26 4.15 4.25 4.39 4.55 4.38 4.48 4.64 4.80 4.58 4.68 4.85 5.02 4.74 4.86 5.03 5.21
AMPS 7.2 7.5 8.0 8.5 8.3 8.7 9.2 9.8 9.6 10.0 10.6 11.3 10.8 11.2 11.8 12.511.912.413.013.813.013.514.215.0
HI PR 218 235 248 259 245 264 279 291 279 300 317 330 318 342 361 376 357 384 406 423 395 425 448 468
LO PR 101 107 117 125 106 113 124 132 111 118 129 137 116 124 135 144 122 130 142 151 126 134 146 156
MBh 50.5 51.9 56.2 60.3 49.3 50.7 54.9 58.9 48.1 49.5 53.6 57.5 46.9 48.3 52.3 56.144.645.949.753.341.342.546.049.4
S/T 0.760.680.510.330.780.700.530.340.800.720.540.350.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.87 0.78 0.59 0.38
DT 23 21 17 12 23 21 17 12 23 21 17 12 23 21 18 12 23 21 17 12 21 20 16 11
1531 KW 3.50 3.58 3.70 3.83 3.79 3.87 4.01 4.14 4.04 4.13 4.28 4.43 4.26 4.36 4.52 4.67 4.45 4.56 4.72 4.89 4.62 4.73 4.89 5.07
AMPS6.87.17.68.17.98.38.89.39.29.610.110.810.310.7 11.3 12.011.411.812.513.212.513.013.614.4
HI PR 212 228 241 251 238 256 270 282 270 291 307 320 308 331 350 365 346 373 394 411 383 412 435 454
LO PR 98 104 114 121 103 110 120 128 107 114 125 133 113 120 131 139 118 126 137 146 122 130 142 151
Shaded area is ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves.

17
COOLINGPERFORMANCEDATA DSZ180601A*-HIGHSTAGE
EXPANDED PERFORMANCE DAT
A
COOLING OPERATION
MODEL: DSZ180601A* /CA*F4961*6** + TXV / MBE2000**-1** Design Subcooling 5 - 7 °F@ the liquid service valve, AHRI 95° F test conditions
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet BulbTemperature
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
MBh 57.3 58.6 62.6 66.9 56.0 57.2 61.1 65.3 54.6 55.8 59.6 63.8 53.3 54.5 58.2 62.2 50.6 51.7 55.3 59.1 46.9 47.9 51.2 54.7
S/T 0.900.840.690.510.930.880.710.530.960.900.730.551.00 0.93 0.75 0.561.000.960.780.591.000.970.790.59
DT 24 23 20 16 24 23 20 16 24 23 20 16 25 24 20 16 24 23 20 16 22 22 19 15
1969 KW 3.65 3.74 3.86 4.00 3.96 4.05 4.19 4.33 4.22 4.32 4.47 4.63 4.46 4.56 4.72 4.89 4.66 4.77 4.93 5.11 4.83 4.94 5.12 5.30
AMPS 7.4 7.8 8.3 8.8 8.6 9.0 9.5 10.1 9.9 10.4 10.9 11.6 11.1 11.5 12.2 12.9 12.3 12.7 13.4 14.2 13.4 13.9 14.6 15.4
HI PR 223 240 253 264 250 269 284 296 284 306 323 337 324 349 368 384 364 392 414 432 403 433 458 477
LO PR 103 109 119 127 109 116 126 134 113 120 131 140 119 126 138 147 124 132 144 154 129 137 149 159
MBh 55.6 56.9 60.7 64.9 54.3 55.5 59.3 63.4 53.0 54.2 57.9 61.9 51.8 52.9 56.5 60.4 49.2 50.2 53.7 57.4 45.5 46.5 49.7 53.2
S/T 0.86 0.81 0.66 0.49 0.89 0.83 0.68 0.51 0.91 0.86 0.70 0.52 0.94 0.88 0.72 0.54 0.98 0.92 0.75 0.56 0.99 0.92 0.75 0.56
DT 25 24 21 17 25 24 21 17 25 24 21 17 26 25 21 17 25 24 21 17 24 23 20 16
80 1750 KW 3.62 3.71 3.83 3.96 3.92 4.01 4.15 4.29 4.19 4.28 4.43 4.59 4.42 4.52 4.68 4.85 4.62 4.73 4.89 5.06 4.79 4.90 5.07 5.25
AMPS 7.3 7.7 8.1 8.7 8.5 8.8 9.4 10.0 9.8 10.2 10.8 11.4 10.9 11.4 12.0 12.7 12.1 12.6 13.2 14.0 13.2 13.7 14.4 15.2
HI PR 221 237 251 262 248 266 281 293 282 303 320 334 321 345 364 380 361 388 410 428 399 429 453 472
LO PR 102 108 118 126 108 114 125 133 112 119 130 138 117 125 13
6
145 123 131 143 152 127 135 148 157
MBh 51.4 52.5 56.1 59.9 50.2 51.3 54.8 58.5 49.0 50.0 53.5 57.1 47.8 48.8 52.1 55.7 45.4 46.4 49.5 53.0 42.0 43.0 45.9 49.1
S/T 0.830.780.630.470.860.810.660.490.880.830.670.500.91 0.85 0.69 0.520.940.880.720.540.950.890.730.54
DT 26 24 21 17 26 25 22 17 26 25 22 17 26 25 22 17 26 25 21 17 24 23 20 16
1531 KW 3.53 3.61 3.73 3.86 3.82 3.91 4.04 4.18 4.08 4.17 4.31 4.47 4.30 4.40 4.56 4.72 4.49 4.60 4.76 4.93 4.66 4.77 4.94 5.11
AMPS 6.9 7.3 7.7 8.3 8.0 8.4 8.9 9.5 9.3 9.7 10.3 10.9 10.4 10.9 11.5 12.2 11.6 12.0 12.6 13.4 12.7 13.1 13.8 14.6
HI PR 214 230 243 254 240 258 273 285 273 294 310 324 311 335 354 369 350 377 398 415 387 416 439 458
LO PR 99 105 115 122 104 111 121 129 108 115 126 134 114 121 132 141 119 127 139 148 123 131 143 153
MBh 58.3 59.4 62.2 66.4 56.9 58.1 60.8 64.9 55.6 56.7 59.4 63.3 54.2 55.3 57.9 61.8 51.5 52.5 55.0 58.7 47.7 48.7 51.0 54.4
S/T 0.940.910.820.670.980.940.850.691.000.970.870.711.00 1.00 0.90 0.731.001.000.940.761.001.000.940.77
DT 26 25 24 21 26 26 24 21 26 26 24 21 25 26 24 21 24 25 24 21 22 23 22 19
1969 KW 3.69 3.77 3.90 4.03 3.99 4.08 4.22 4.37 4.26 4.36 4.51 4.67 4.50 4.60 4.76 4.93 4.70 4.81 4.98 5.16 4.87 4.99 5.16 5.35
AMPS 7.6 7.9 8.4 9.0 8.7 9.1 9.7 10.3 10.1 10.5 11.1 11.8 11.3 11.7 12.3 13.1 12.4 12.9 13.6 14.4 13.6 14.1 14.8 15.6
HI PR 225 242 256 267 253 272 287 299 287 309 326 340 327 352 372 388 368 396 418 436 407 438 462 482
LO PR 104 111 121 128 110 117 127 136 114 121 132 141 120 127 139 148 126 134 146 155 130 138 151 161
MBh 56.6 57.7 60.4 64.5 55.3 56.4 59.0 63.0 54.0 55.0 57.6 61.5 52.7 53.7 56.2 60.0 50.0 51.0 53.4 57.0 46.3 47.2 49.5 52.8
S/T 0.900.870.780.640.930.900.810.660.960.920.830.680.99 0.95 0.86 0.701.000.990.890.721.001.000.900.73
DT 27 26 25 22 27 27 25 22 27 27 25 22 27 27 25 22 26 27 25 22 24 25 23 20
85 1750 KW 3.65 3.74 3.86 4.00 3.96 4.05 4.19 4.33 4.22 4.32 4.47 4.63 4.46 4.56 4.72 4.89 4.66 4.77 4.93 5.11 4.83 4.94 5.12 5.30
AMPS 7.4 7.8 8.3 8.8 8.6 9.0 9.5 10.1 9.9 10.4 10.9 11.6 11.1 11.5 12.2 12.9 12.3 12.7 13.4 14.2 13.4 13.9 14.6 15.4
HI PR 223 240 253 264 250 269 284 296 284 306 323 337 324 349 368 384 364 392 414 432 403 433 458 477
LO PR 103 109 119 127 109 116 126 134 113 120 131 140 119 126 138 147 124 132 144 154 129 137 149 159
MBh 52.2 53.3 55.8 59.5 51.0 52.0 54.5 58.1 49.8 50.8 53.2 56.7 48.6 49.5 51.9 55.4 46.2 47.1 49.3 52.6 42.8 43.6 45.7 48.7
S/T 0.870.840.760.610.900.870.780.640.920.890.800.650.95 0.92 0.83 0.670.990.950.860.701.000.960.870.70
DT 27 27 25 22 28 27 26 22 28 27 26 22 28 27 26 22 27 27 25 22 26 25 24 21
1531 KW 3.56 3.64 3.76 3.89 3.85 3.94 4.08 4.22 4.11 4.21 4.35 4.50 4.34 4.44 4.60 4.76 4.53 4.64 4.80 4.97 4.70 4.81 4.98 5.16
AMPS 7.1 7.4 7.9 8.4 8.2 8.5 9.1 9.6 9.5 9.9 10.4 11.1 10.6 11.0 11.6 12.3 11.7 12.2 12.8 13.6 12.8 13.3 14.0 14.8
HI PR 216 233 246 256 243 261 276 287 276 297 313 327 314 338 357 372 353 380 402 419 391 420 444 463
LO PR 100 106 116 123 105 112 122 130 110 117 127 135 115 122 134 142 121 128 140 149 125 133 145 154
Shaded area is AHRIRating Conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unitamps (comp.+fan) High and low pressures are measured at the liquid and suction service valves.

18
PERFORMANCE DATA LOW STAGE
Outdoor
Temp. ° F. Total Btuh Sensible Btuh Latent Btuh Total Watts
75° 26,556 19,120 7,435 1,549
80° 26,239 19,133 7,107 1,602
85° 25,923 19,139 6,784 1,654
90° 25,607 19,211 6,397 1,701
95° 25,291 19,274 6,017 1,748
100° 24,659 19,148 5,510 1,787
105° 24,026 19,004 5,022 1,827
110° 23,141 18,381 4,760 1,861
115° 22,256 17,752 4,504 1,895
95° 23,436 19,082 4,354 1,674
DSZ180361A* / CA*F3743*6**+ TXV / MBE1600**-1**
Conditions: 80 °FIDB, 67 °FIDW @850 CFM LOW STAGE
TVA Conditions @ 95° OD DB, 75°ID DB, 63° ID WB
Outdoor
Temp. ° F. Total Btuh Sensible Btuh Latent Btuh Total Watts
75° 37,540 26,689 10,851 2,145
80° 37,093 26,706 10,386 2,219
85° 36,646 26,716 9,930 2,293
90° 36,199 26,815 9,384 2,359
95° 35,752 26,904 8,848 2,424
100° 34,858 26,728 8,130 2,480
105° 33,964 26,527 7,437 2,535
110° 32,713 25,657 7,056 2,583
115° 31,462 24,779 6,683 2,631
95° 33,129 26,635 6,494 2,320
DSZ180481A* / CA*F4961*6**+TXV / MBE2000**-1**
Conditions: 80 °FIDB, 67 °FIDW @1200 CFM LOW STAGE
TVA Conditions@95° OD DB, 75°ID DB,63° ID WB
Outdoor
Temp. ° F. Total Btuh Sensible Btuh Latent Btuh Total Watts
75° 44,563 29,825 14,738 2,731
80° 44,032 29,844 14,188 2,827
85° 43,502 29,855 13,647 2,923
90° 42,971 29,966 13,005 3,007
95° 42,441 30,065 12,375 3,092
100° 41,379 29,869 11,510 3,164
105° 40,318 29,644 10,674 3,236
110° 38,833 28,672 10,161 3,298
115° 37,348 27,690 9,657 3,360
95° 39,327 29,765 9,562 2,958
TVA Conditions @ 95° OD DB, 75°ID DB, 63° ID WB
DSZ180601A* /CA*F49610*6**+TXV / MBE2000**-1**
Conditions: 80 °FIDB, 67 °FIDW @1200 CFM LOW STAGE

19
PERFORMANCE DATA HIGH STAGE
Outdoor
Temp. ° F. Total Btuh Sensible Btuh Latent Btuh Total Watts
75° 36,990 26,394 10,595 2,413
80° 36,550 26,412 10,138 2,492
85° 36,109 26,421 9,688 2,572
90° 35,669 26,519 9,149 2,643
95° 35,229 26,607 8,621 2,713
100° 34,348 26,434 7,914 2,773
105° 33,467 26,235 7,232 2,833
110° 32,234 25,374 6,860 2,884
115° 31,001 24,505 6,496 2,936
95° 32,644 26,341 6,303 2,601
DSZ180361A* / CA*F3743*6**+TXV/ MBE1600**-1**
Condition: 80° IDB, 67° IWB, @ 1250 CFM, HIGH STAGE
TVA Conditions @ 95° OD DB, 75° ID DB, 63° ID WB
Outdoor
Temp. ° F. Total Btuh Sensible Btuh Latent Btuh Total Watts
75° 52,500 37,231 15,269 3,306
80° 51,875 37,256 14,619 3,415
85° 51,250 37,269 13,981 3,523
90° 50,625 37,407 13,218 3,618
95° 50,000 37,531 12,469 3,714
100° 48,750 37,286 11,464 3,795
105° 47,500 37,006 10,494 3,876
110° 45,750 35,792 9,958 3,947
115° 44,000 34,566 9,434 4,017
95° 46,332 37,156 9,176 3,562
DSZ180481A* / CA*F4961*6**+TXV/ MBE2000**-1**
Condition: 80° IDB, 67° IWB, @ 1750 CFM, HIGH STAGE
TVA Conditions @ 95° OD DB, 75° ID DB, 63° ID WB
Outdoor
Temp. ° F. Total Btuh Sensible Btuh Latent Btuh Total Watts
75° 59,325 40,312 19,013 4,150
80° 58,619 40,339 18,280 4,290
85° 57,913 40,353 17,559 4,431
90° 57,206 40,503 16,703 4,555
95° 56,500 40,638 15,862 4,680
100° 55,088 40,372 14,715 4,785
105° 53,675 40,069 13,606 4,891
110° 51,698 38,754 12,943 4,982
115° 49,720 37,427 12,293 5,073
95° 52,355 40,231 12,124 4,482
TVA Conditions @ 95° OD DB, 75° ID DB, 63° ID WB
DSZ180601A* / CA*F4961*6** + TXV / MBE2000**-1**
Condition: 80° IDB, 67° IWB, @ 1750 CFM, HIGH STAGE

20
SPLIT SYSTEM HEATING PERFORMANCE
High pressure is measured at the suction service valve ( the larger valve). AMPS = Outdoor unit amps (comp.+fan)
Low pressure is measured at the gauge port connection. KW = Total system power
Calculations are based on nominal CFM and 70 °F indoor dry bulb.
*Note:ShadedareaisARIRatingConditionsat 47°outdoorambienttemperature
LOW STAGE
MODEL: DSZ180361A* / CA*F3743*6** + TXV/ MBE1600**-1** HEATINGOPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 30.829.227.425.6 24.5 23.7 22.0 20.3 18.0 16.6 15.3 14.5 13.9 12.5 11.1 9.7 8.3 6.8
DeltaT33.531.829.927.9 26.7 25.924.022.119.618.116.715.815.213.612.110.5 9.0 7.4
KW 1.98 1.94 1.90 1.86 1.83 1.81 1.77 1.73 1.78 1.74 1.69 1.67 1.65 1.60 1.56 1.51 1.47 1.42
AMPS 9.5 8.8 8.2 7.7 7.5 7.3 6.9 6.5 6.2 6.0 5.7 5.5 5.5 5.2 4.8 4.5 4.2 3.7
COP 4.54 4.39 4.23 4.04 3.91 3.83 3.64 3.44 2.96 2.81 2.65 2.54 2.48 2.28 2.08 1.87 1.64 1.39
EER 15.5 15.0 14.4 13.8 13.4 13.1 12.4 11.7 10.1 9.6 9.1 8.7 8.5 7.8 7.1 6.4 5.6 4.7
HI PR 393 377 362 346 338 332 319 306 293 280 269 262 258 248 238 229 221 213
LOPR 145 134 126 116 109 105 97 86 78 69 61 57 55 46 40 34 29 23
EXPANDED PERFORMANCE DATA
MODEL: DSZ180481A* / CA*F4961*6** + TXV / MBE2000**-1** HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 43.8 41.4 39.0 36.5 34.8 33.7 31.3 28.9 27.0 25.0 23.0 21.7 20.9 18.7 16.6 14.5 12.4 10.1
Delta T 33.8 32.0 30.1 28.1 26.9 26.0 24.2 22.3 20.9 19.3 17.7 16.7 16.1 14.5 12.8 11.2 9.5 7.8
KW 2.67 2.62 2.56 2.50 2.47 2.44 2.39 2.33 2.44 2.38 2.32 2.28 2.26 2.19 2.13 2.07 2.01 1.95
AMPS 12.7 11.7 10.9 10.2 9.8 9.6 9.0 8.5 8.1 7.7 7.2 7.0 6.9 6.5 6.0 5.6 5.1 4.5
COP 4.79 4.63 4.46 4.27 4.13 4.04 3.84 3.63 3.24 3.07 2.90 2.78 2.71 2.50 2.28 2.05 1.80 1.52
EER 16.4 15.8 15.2 14.6 14.1 13.8 13.1 12.4 11.1 10.5 9.9 9.5 9.3 8.5 7.8 7.0 6.2 5.2
HI PR 391 375 360 344 336 330 317 304 292 278 267 261 256 247 237 227 219 212
LO PR 145 134 126 115 109 105 97 86 78 69 61 57 55 46 40 34 29 23
EXPANDED PERFORMANCE DATA
MODEL: DSZ180601A* / CA*F4961*6** + TXV / MBE2000**-1** HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 52.049.246.343.341.4 40.1 37.2 34.3 32.6 30.1 27.7 26.1 25.2 22.6 20.0 17.5 14.9 12.2

T 40.138.035.733.
4
31.9 30.9 28.7 26.
5
25.1 23.2 21.
4
20.2 19.4 17.4 15.5 13.5 11.5 9.4
KW 3.66 3.58 3.50 3.42 3.37 3.34 3.26 3.18 3.23 3.15 3.06 3.01 2.98 2.90 2.81 2.73 2.65 2.57
AMPS 17.5 16.2 15.1 14.2 13.6 13.4 12.6 11.9 11.3 10.8 10.3 10.0 9.8 9.3 8.6 8.1 7.4 6.6
COP 4.16 4.02 3.87 3.71 3.59 3.51 3.34 3.16 2.95 2.80 2.64 2.54 2.47 2.28 2.08 1.87 1.65 1.39
EER 14.2 13.7 13.2 12.7 12.3 12.0 11.4 10.8 10.1 9.6 9.0 8.7 8.4 7.8 7.1 6.4 5.6 4.8
HI PR 421 403 388 371 362 355 341 328 314 300 288 281 276 265 255 245 236 228
LO PR 138 128 120 110 104 100 92 82 74 66 58 54 52 44 38 32 28 22
EXPANDED PERFORMANCE DATA
