Goodmans GPS02 User manual

USER MANUAL
MODEL: GPS02
CD BOOMBOX
RESUME
OPEN

Welcome1
Troubleshooting5
Technical Specifications6
Customer Support7
Your CD Boombox
2.1 In The Box
2.2 Front View
2.3 Rear View
2
Quick Setup
3.1 Power On/Off and Function Selection
3.2 Standby & Auto Standby
3.3 Adjusting the Volume
3
Operation4
CD Operation
4.1 Load a Disc
4.2 Play a Disc
4.3 Skip Tracks And Search For A Specific
Point To Play
4.4 PROGRAMMEmed Play
4.5 Repeat Single/All Track(s)
Radio Operation
4.6 Tuning a Station
Aux-In Mode
4.7 Aux In Mode
2.4 Side view 1
2.5 Side view 2
3.4 Fitting Batteries

GPS02
Welcome
Thank you for choosing this Goodmans product. We’ve been
making electronics for the British people for 70 years. Each of
our projects has been carefully designed to be great at what it
does and this one is no exception. We hope you enjoy your
new CD Boombox.
1
Your CD Boombox2
In The Box
Carefully remove your CD Boombox from the packaging.
Inside the box you will find:
• CD Boombox
• Mains Power Supply Lead
• Quick Start Guide
• Guarantee Booklet
If any of these items are missing, contact customer support.
Visit: www.goodmans.co.uk/support
2.1
Mains Power
Your CD Boombox requires a mains supply of 230-240V AC ~ 50Hz.
Please ensure that your mains supply is compatible before use.
Disconnect the power cord from the mains when not in use.
Position of CD Boombox
Place on a flat, stable surface that is not subject to vibrations. Avoid
the following locations:
• Where it is exposed to direct sunlight
• Where it is close to heat radiating sources
• Where the humidity is high and ventilation is poor
• Where it is dusty
Adjusting the Aerial
Fully extend the aerial to ensure good reception in both MW and FM
Radio modes. It may be necessary to alter the position of the CD
Boombox and/or the aerial to achieve the best signal.

GPS02
Front View2.2
A CD compartment.
Load a CD into this compartment.
B / RESUME.
Press to Play or Pause playback of a
CD. This button also doubles up as a
standby button. Press and hold to
enter standby and press again to
wake.
C PLAY indicator. This will illuminate
during CD playback.
D LED display. Displays CD track
information.
E POWER indicator. This will
illuminate when the power is on.
F button. Press to stop playback of a
CD.
G CD compartment release button.
Press to open the CD compartment.
H Speakers. Stereo speakers.
I button. Press to skip to next CD
track(s). Press and hold to fast
forward CD tracks.
J button. Press to skip to previous
CD tracks. Press and hold to fast
rewind CD tracks.
K REPEAT indicator. This will
illuminate when the repeat function is
active.
L PROGRAMME indicator. This will
illuminate when the programme
function is active.
M REPEAT button. Press repeatedly to
toggle the repeat functions.
N PROGRAMME button. Press to
enable the programme function.
RESUME
OPEN
RADIOAUX / OFF
MAX
VOLUME
MIN
CD
540
1600
MW FM FM ST
TUNING
AUX
AC~
A
O
S T U
P Q
H
V W
R
I NMJ K L
B C D E F G
TAKE CARE WITH
LIVE ELEMENTS

GPS02
Rear View
Side View 1
Side View 2
2.3
2.4
2.5
TAKE CARE WITH
LIVE ELEMENTS
RESUME
OPEN
RADIOAUX / OFF
MAX
VOLUME
MIN
CD
540
1600
MW FM FM ST
TUNING
AUX
AC~
AO
S T
U
P Q
H
V W
R I NMJ K L
B C D E F G
RESUME
OPEN
RADIOAUX / OFF
MAX
VOLUME
MIN
CD
540
1600
MW FM FM ST
TUNING
AUX
AC~
AO
S T
U
P Q
H
V W
R I NMJ K L
B C D E F G
RESUME
OPEN
RADIOAUX / OFF
MAX
VOLUME
MIN
CD
540
1600
MW FM FM ST
TUNING
AUX
AC~
A
O
S T U
P Q
H
V W
R
I NMJ K L
B C D E F G
O Telescopic antenna.
P Carry handle
Q AUX INPUT socket. Connect
external audio sources with a 3.5mm
audio cable.
R AC mains input socket. Connect
the mains cable to this socket.
S VOLUME control. Rotate to
increase or decrease the volume
output.
T Function switch. Enable CD/
RADIO/ AUX functions or turn off.
U TUNING dial. Use this dial to locate
a radio frequency using the tuning
control.
V BAND selection switch. Set to
either MW or FM.
W TUNING control. Rotate to fine tune
a radio frequency.

GPS02
Quick Setup3
Power On/Off and Function Selection
1. This CD Boombox is supplied with a mains cable.
To connect the power insert the figure 8 shaped end in the
rear of the unit.
2. Insert the plug into a power socket, and switch the power on.
3. Set the function switch to either CD or RADIO /AUX for
operation. Set to the off position to turn the radio off.
Standby & Auto Standby
1. Press the /RESUME button to wake from standby
mode.
2. Press and hold the /RESUME button to enter Standby
mode.
Due to new ECO regulation requirements this product
incorporates a power saving feature.
3. When in CD mode or AUX mode, once audio playback has
ceased and the unit has stood idle for approximately 20
minutes, it will switch into a ‘power-down’ power saving
mode.
4. To wake the unit up, press the /RESUME button.
3.1
3.2
RADIOAUX / OFF
MAX
VOLUME
MIN
CD
RADIOAUX / OFF
MAX
VOLUME
MIN
CD
AUX
AC~
RESUME

GPS02
Adjusting the Volume
Rotate the volume control clockwise or anti-clockwise to
increase or decrease the volume output.
Fitting Batteries
1. Open the battery compartment on the bottom of the unit
(see diagram below).
2. Insert 8 x C size batteries taking care to match the + & -
polarity symbols correctly.
3. Replace the battery compartment cover.
The mains cable must be detached from the AC socket of the
player for the batteries to power the unit.
Leaking batteries may damage the battery cabinet and the
player as a whole. If you are not going to use the CD Boombox
for an extended period, please remove the batteries to avoid
damage.
Caution: Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
3.3
3.3
RADIOAUX / OFF
MAX
VOLUME
MIN
CD

GPS02
RESUME
CD Operation
Operation4
4.1
4.2
4.3
LOAD A DISC
1. Open the CD lid using the OPEN button.
2. Load a disc onto the disc tray with the label side facing up.
3. Close the CD door.
PLAY A DISC
1. Slide the function switch to the CD position.
2. Follow the steps above to load a disc (if not already loaded).
3. The player begins to read the disc immediately.
4. When the disc is successfully read, the total number of
tracks on the disc will appear on the LED display and
playback follows with the first track.
5. Press the /RESUME button once to pause the music
playback. The track number flashes to indicate the player is
in pause mode; press the button to cease music
playback. The LED shows the total number of tracks again.
SKIP TRACKS AND SEARCH FOR A SPECIFIC
POINT TO PLAY
1. Press the button once during playback to skip to the
next track. To skip to a specific track, press this button
several times until you reach the track number required.
2. Press the button once during playback to return to the
beginning of the current track. Press the button twice
repeatedly to skip to the previous track. To skip back to a
specific track, press this button several times.
3. Hold the button during playback to fast forward the
current track.
4. Hold the button during playback to fast rewind the
current track.
OPEN
RADIOAUX / OFF
MAX
VOLUME
CD
RESUME
RESUME

GPS02
PROGRAMMED PLAY
To programme an alternative playback order of tracks follow
the below steps.
1. Make sure the unit is not playing a disc.
2. Press the PROGRAMME button once. The programme
sequence “01” appears on the LED display & the
PROGRAMME LED indicator flashes.
3. Select the first track to be programmed using the /
buttons.
4. Press the PROGRAMME button again to store and advance
to the next programmed track. The programme sequence
indication changes to “02” momentarily waiting for your next
input.
5. Repeat the steps above to programme more tracks.
A maximum of 20 tracks can be programmed.
6. Press the button to begin the programmed playback in
the preferred order.
7. You can press the button to terminate programmed
playback.
REPEAT SINGLE/ALL TRACK(S)
1. During playback press the REP. button once, you will see
the REPEAT indicator flash. This indicates the current track
will repeat until the button is pressed.
2. During playback press the REP. button twice, you will see
the REPEAT indicator illuminate steadily. This indicates that
all the tracks of the current disc will repeat until the button
is pressed.
3. To turn off the REPEAT function press the REP. button until
the REPEAT indicator goes OFF.
CD Operation
4.4
4.5
RESUME

GPS02
FM ST
TUNING
MW FM FM ST
TUNING
Tuning a station
1. Slide the function switch to the RADIO /AUX position.
2. Set the required band with the BAND selection switch.
To listen to an FM station in stereo set the function switch to
FM ST.
3. Tune the station by rotating the TUNING control.
When receiving an FM broadcast, fully extend the telescopic
antenna and angle it for the best reception.
For MW broadcasts, vary the position of the unit until the best
reception is located.
4. Adjust the volume to a comfortable listening level using the
VOLUME control.
Aux In Mode
It is possible to connect an external audio source like an MP3
player using a 3.5mm audio cable (not supplied).
1. Connect one end of the cable to the MP3 player headphone
output and the other end to the AUX input on the right hand
side of the unit.
2. Slide the function switch to the RADIO /AUX position.
3. Press on the external audio source.
The volume output is affected by the volume level on the
source EG: MP3 player so make sure that is set to about
70-80% ( not too loud to avoid distortion ).
4. Adjust the VOLUME control on the unit to the required
listening level.
Radio Operation
4.6
4.7
RADIOAUX / OFF
MAX
VOLUME
CD
AUX
AC~
RADIOAUX / OFF
MAX
VOLUME
MIN
CD
AUX
AC~

GPS02
Problem What to do
No Power Check the mains plug is connected to the wall socket.
Switch the wall socket on.
Press the / RESUME button to wake from Standby
mode.
No sound from the CD
No sound from an AUX input
The volume level is too low. Increase using the
volume control.
Remove any connected 3.5mm cable from the AUX
input socket.
The volume level is too low. Increase using the
volume control.
The external audio source volume is too low,
increase the volume level.
The sound is distorted
The sound is distorted from an AUX input
Reduce the CD boombox volume level using the
volume control.
The external audio source volume is too high,
decrease the volume level.
Unable to play a CD Check there is a disc present in the CD
compartment.
Remove and re-insert the CD with the label side
facing upwards.
Clean the disc, it may be dirty. If scratched try
another disc.
Static interference when listening to the
radio
This is caused by poor reception. Re-locate the
antenna or if that fails try moving the CD boombox
to a different location.
Troubleshooting5

GPS02
Model Number GPS02
Power Supply AC 230-240V ~ 50 Hz
DC 12V UM-2/’C’ size x 8pcs
Speaker Output Power 1W x 2 (RMS)
Speaker Impedance 8 Ohms
Frequency Range FM: 88-108MHz
MW: 540-1600KHz
Supported Disc Types CD-DA.CD-R/CD-RW
Max Power Consumption AC 12W
Dimensions 235mm (L) x 250mm (W) x 142mm (H)
Technical Specification6
www.goodmans.co.uk
Customer Support7
Our customer service team is available for technical or
guarantee support. Visit www.goodmans.co.uk/support
QSG-JUNE14-GPS02
