Google Nexus One Car Dock User manual

Car Dock
Google, Android, Nexus One, the stylized
Nexus One logo, and Google Maps are
trademarks of Google Inc. All other company
and product names may be trademarks of the
companies with which they are associated.
Copyright © 2009 Google Inc.
NOCD-2.1.0-EN-005
Mounting the dock
1Remove the protective plastic
sheet from the suction cup.
2Position the base of the dock on
your windscreen or other smooth
surface and then press the base
firmly while twisting it clockwise,
until it locks in place (about a
quarter-turn). To mount the dock
on a textured surface, first ax the
included disc and allow its adhesive
to cure for a day before using it.
3Plug the supplied charger into your
car’s 12V utility socket and the
other end into the base of the dock.
4Insert your phone into the dock.
Power on/o
Power
Volume up/down
Speaker
(rear)
Suction cup
release tab
Microphone
1
2
1
2

Nexus One car dock
The Nexus One car dock gives you
convenient access to the Android
applications most useful when
driving. It also turns your phone
into a speakerphone and charges
its battery.
Mounting the dock
Follow the instructions on the reverse
side of this document.
Your phone communicates with the
dock via a Bluetooth connection,
which it establishes automatically the
first time you insert the phone. It also
prompts you to set whether you want
to use the dock as a speakerphone
and to play music and other media.
Unmounting the dock
1Unplug the dock and remove
your phone.
2Twist the base counter-clockwise.
3Lift up on the suction cup’s tab to
release it.
Cleaning the suction cup
If the suction cup gets dirty it won’t
attach very well. Remove the suction
cup from the base before cleaning it,
so you don’t wet the electronics in the
base of the dock (see the instructions
inside the suction cup). Clean the
suction cup with a lint-free cloth
moistened with water.
Using the Car Home application
When you insert the phone in the dock,
the Car Home application opens.
Answer the phone
Drag to answer to the phone
Drag to divert calls to voicemail
When the phone is in the dock, it
can use the dock as a hands-free
speakerphone. You can also use a
Bluetooth headset with the phone
when it’s docked.
Charging
The status light on the front of the
phone turns amber while the phone
is charging. It turns green when the
phone is fully charged.
Warning! The dock power port does
not transmit data. Use only the
supplied charger. Never connect the
dock to a computer.
Learn more
Read all about your phone and
Maps, Contacts, searching, pairing
Bluetooth devices, and the many
Android applications, in the Nexus
One User’s Guide, available from:
google.com/phone/support
Please drive safely!
Be sure to follow all local laws and
exercise caution when using your
phone’s features and the car dock
while driving.
Touch to open
Google Maps
Touch to speak voice commands, for example:
• “Call Mike LeBeau mobile phone”
• “Directions to 199 Maiden Lane”
• “Navigate to Union Square San Francisco”
Touch to get spoken,
turn-by-turn directions
to your destination
Touch to open your
contacts, so you can
call them or map
their addresses
Touch to search your
phone and the web
Touch to open
the Home screen
