Gopet Petrun PR700 User manual

Treadmill User Manual
This Manual is applicable to the following models
Specification
MODEL
PR700
PR710F
PR720F
PR725
PR730
Horse Power
HP
1 HP
1.25 HP
1.5 HP
Input Voltage
V
115 V AC
Max Input Current
A
10 A (max)
Dog Length Limit
In
18”
28”
35”
48”
65”
Dog Weight Limit
Lb
44 lbs
88 lbs
132 lbs
176 lbs
265 lbs
Running Speed
MPH
0.6 - 7.5 MPH
0.6 –10 MPH
Foldable Function
No
Yes
Yes
No
No
Incline Function
No
No
No
Yes
Yes
Remote Control
Yes
No
Safety Device
Emergency Switch/Safety Locker (Foldable model only)
Model Size
In
21 x 44 x 15
21 x 62 x 16.25
21 x 72 x 16
21 x 87 x 48
33 x 99 x 54
(W) (L) (H)
(W) (L) (H)
(W) (L) (H)
(W) (L) (H)
(W) (L) (H)
Net Weight
lbs
63
83
99
137
273
Safety Standard
CE Certification
Warranty
1 year
Notice
Read this User Manual thoroughly before using treadmill to ensure its proper set-up and operation.

ASSEMBLY PROCEDURES
WARNING
Your GoPet Petrun Treadmill is NOT DESIGNED for use by humans of any size or age. It is specifically
designed for four legged animals within the weight and length criteria listed above for each particular
model.
Animals should always be fully supervised during use.
Children should always be supervised to ensure that they do not play with or on the unit.
PR 700 - PR 710F - PR 720F
Note: Since the PR 700 does not include incline feature use second person to assist with assembly.
(Step 1) (Step 2)
Insert front rail Lift up the PetRun, then fasten screws
(M6x18L) by L-wrench (4mm)
(Step 3) (Step 4)
Insert left & right rails Fasten screws (M6x18L)
with L-wrench (4mm)

PR 725
NOTE –Front and rear gates have been discontinued for improved safety
(Step 1)
Use L-wrench (5mm), screw (M8x40L) and
washer (M8x1.6T) to fasten the Left & Right Fences
(Step 2)
Use L-wrench (5mm), screw(M8x15L) and washer
(M8x1.6T) to fasten the harness support on the top of
both sides of the fence.
PR 730
NOTE –Front and rear gates have been discontinued for improved safety
(Step 1) (Step 2)
Use L-wrench (5mm) and screw (M8x40L) to fasten Use L-wrench (4mm) and screw (M6x40L) to
the side fence pipes fasten the end board of Control Console on the
vertical fence pipe.

(Step 3) (Step 4)
Use Phillips screw (M4x8L) to fasten the Control Plug in the control cable connector.
Console on the end board (NOTE: insert the 6 Pin
Connector first!).
Make sure all the pipes are attached completely after assembly.
◆ Thoroughly read the entire User Manual before use.
◆ Be sure to follow all instructions.
WARNINGS
◆ Do not, under any circumstances allow humans on to the treadmill.
◆ Consult your veterinarian before beginning any exercise plan for your pet
◆ Make sure to use the correct voltage and fully inspect all electrical cords and outlets prior to use.
◆ Do not dress your pet during use and do not allow any dangling leashes or collars from your pet
◆ Do not store or operate your treadmill outdoors
Key Warnings Regarding Use
◆ Before turning on the power switch, let your dog stand on the running belt first, then turn on the power switch
and adjust the speed slowly.
◆ Don’t let dog jump on the PetRun when it is turned on. It may cause injury or accident.
◆ When the dog is using the PetRun, we suggest the owner stands beside and adjusts it to a suitable speed
according to the dog’s condition.
◆ T wice a day and each time about 10 to 15 minutes of exercise are suggested.
◆ Please stop using PetRun if any unusual condition such as unstable step or breathlessness occurred on running.
◆ If the position of running belt is not in the middle, but moved to one side, or a noise occurred, please stop using it
Immediately. Make adjustment till the running belt moves back to middle position then continue using it (Refer
to Running Belt Adjustment Guide in User Manual).
◆ if there were any unusual noise, burning smell, motor cover damage, inside parts coming out, weld section loose
and spare parts loose. Please unplug, stop using it, and contact your dealer for further assistance.
Key Warnings after use of Pe t R un
◆ Always unplug when not using PetRun.
◆ Remove hair and dirt from the running belt firstby using cotton fabric soaked with 3-5% diluted warm neutral
detergent. Dry the surface of the running belt with a towel.
◆ Don’t use cleaner detergent containing toluene for cleaning.
◆ Do not touch the plug with wet hands.
-----To avoid damage, electric shock, or electric fire.
◆ Always put a mat under the PetRun to avoid damage to the floor.
◆ Always put the PetRun on a flat floor and allow enough space to use it.
◆ Avoid unusual use of the PetRun to avoid accident or damage.

Daily storage and Ma
i n t e n a nc e
◆ Unplug your treadmill when not in use.
◆ Do not use or store your treadmill outdoors, in a bathroom or high humidity environment. Avoid direct sunlight
and keep away from direct sources of heat or other electrical equipment.
◆ For “F” model units, always lock the safety latch when your treadmill is in the folded position.
◆ Keep children away
- Do not allow them to play on or around your treadmill.
◆ Use a mild household cleanser to wipe down your unit when dirty. Do not directly spray unit. Never leave unit damp
or wet. Use a vacuum to remove hair build-up.
Wa
rr a n t y
◆ The warrant period is accordance with the warranty.
◆ An unexpected or artificial disaster is exempt from the warranty.
◆ The damage from taking apart from the buyer itself is exempt from the warranty.
◆ An injury to anyone, dogs or machine damage due to improper use is exempt from the warranty.
Beginner’s user gu i d e
Note: ensure your pet is properly hydrated before, during and after exercising. Consult your veterinarian as to how
much water to provide your pet.
Pet, sooth, and encourage your pet before it exercises. Continue to provide positive reinforcement during exercise.
Walk your pet onto the treadmill and let it walk directly over the front. Do this a few times –pausing for a few
seconds each time, encouraging your pet. Then walk your pet onto the belt allow it to stand a little longer.
Once your pet is comfortable on the treadmill, turn the power on, walk your pet onto the treadmill and stand
beside it as if you were taking it for a walk. Begin to speed the treadmill up, slowly at first, encouraging your dog
to come along. Gradually increase the speed of the treadmill while standing next to your pet until it has a natural
gait.
Be sure to use a slow speed at the beginning and then increase the speed after your dog gets used to the movement.
Once your pet is comfortably running without any tension on its leash you can remove its leash.
Don’t stop the treadmill suddenly when the dog is finished, speed down slowly and let your dog have enough time

ACCESSORY PARTS
PR700 / PR710F / PR720F
(1) (2) (3) (4)
(5) (6) (7) (8)
PR725
(1) (2) (3)
(4) (5) (6) (7) (8) (9)
No
Accessory Parts Name
Q’ty
1
Front Rail
1
2
Left & Right Rails
1 ea
3
Power Cable
1
4
Screw M6x18L (short)
4
5
Screw M6x35L (long)
2
6
L-Wrench_4mm
1
7
T-Wrench_5mm
1
8
Remote Controller
1
No.
Accessory Parts Name
Q’ty
No.
Accessory Parts Name
Q’ty
1
Left Fence –new style not
illustrated.
1
6
Washer M8x1.6T
12
2
Right Fence –new style
not illustrated.
1
7
L-Wrench_5mm
1
3
Harness Support
1
8
T-Wrench_5mm
1
4
Power Cable
1
9
Remote Controller
1
5
Screw M8x15L (short)
12

PR730
(1) (2) (3) (4)
*Please make sure the quantity of accessory parts is correct
before assembly.
Manual
control button & Power switch ill us t r a t i on
For the following models - PR 700, PR 710F, PR 720F and PR 725E
Manual Control Button Outlet / Electric Current Protector / Power Switch
E.SW
Stop motor emergency, Power can be
restarted by turning OFF and ON the
power switch again
START
Start the belt running from .6 mph
STOP
Stop, can restart without reset power
switch
SPEED UP
Speed up (1-12Km)
SPEED
DOWN
Speed down (12-1Km)
No.
Accessory Parts Names
Q’ty
1
Front rail(no gate
included)
1
2
Rear rail(no gate
included)
1
3
Side Fence Pipe
8
4
Control Console
1
5
Power Cable
1
6
Screw M6x40L
2
7
Screw M8x40L
16
8
Screw M8x25L
4
9
Screw M4x8L
1
10
L-Wrench_4mm
1
11
L-Wrench_5mm
1
12
T-Wrench_6mm
1
Outlet
Input AC Power
Electric Current
Protector
Cut off the AC Power
when over
current.
Power Switch
[O]=Power OFF
[ | ]=Power ON

Remote control instruction manual
Remote control button key illustration
Name
Definition
1
Red LED Light
Infrared signal light.
2
[ RESET ]
Will stop unit in any situation, and go back to set
up mode
3
LCD Window
Time: count up/down 00-99 Min.
Speed: up/down 00.0-99.9 Km/H
(Imperial system unit will not show)
4
IR transmitter
For Infrared ray transmittance
5
[ TM ]
Press to set up time
6
[ CLR ]
Clear wrong time setting, and back to set up
mode
7
[ START ]
Treadmill starts to work
8
[ STOP ]
Push the [STOP] key, the unit will stop working
and go back to set up model (Need to wait 3-6
seconds for long beep sound, then push the
[START] to re-start)
9
[ MODE ]
Speed / Distance display exchange
10
[ SPD ]
Speed setting
11
[ S.KEY ]
Push [S.KEY] + [MODE] for channel set up.
Electric Saving Mode
The LCD display will switch to Electric Saving
Mode under any mode if not operated over 1
minute, push [RESET] key to go back to the
normal display.
Battery Box
1.5V Alkaline Battery x 2 pcs
Infrared ray receiving zone
* Pantoscopic IR receiving angle,
Achieved 180° both left
And right side.

Process of remote control operation
[ START ] [ SPD ]
Speed Seting
( 1.0 - 16.0 km )
[ STOP ]
Stop Function
Stop automatically
when time isreached
99 Min..
Normal Mode
W / O Time Setting
[ Reset ]
Push & Release
Push the [ STOP ] key and hold for
3 - 6 sec., when a long beep sounds
push the [ START ] key to re-start
Time Setting Mode
[ START ]
[ TM ]
Time Seting
( 1.0 - 99.0 Min. )
[ SPD ]
Speed Seting
( 1.0 - 12.0 km )
[ STOP ]
Stop Function
[ Reset ]
Push & Release
Stop automatically
when time isreached
00.00 Min..
[ CLR ]
Time setting
Modify
Push the [ STOP ] key and hold for 3 -
6 sec., when a long beep sounds push
the [ START ] key to re-start

Remote Controller Reset Procedure
(STEP 1) Remote Controller Side
A. Take the batteries out of the remote controller and then
replace them.
B. Push and hold Mode button and then push SPD
UP button, the screen will display as pictured,
C. Release both buttons at the same time.
(STEP 2) Machine Side
A. Push and hold both the Speed Up button (orange color) &
Speed Down button (black color). They are located on the
side of the motor cover. A continuous beep will sound and
will stop after 3 seconds and then an intermittent beep will
sound. (Keep pushing both keys until this intermittent beep
occurs)
B. Release both buttons together.
(STEP 3) Remote Controller Side
A. Point the remote controller (slightly off center) toward the
IR receiver located on the side of the motor cover, then
push and hold the Reset key for about 7 seconds.
B. If a long beep sounds when you release the Reset key,
the set up procedures are complete.

Control console instruction manual - for PR730 on l y
Control conso l e button key ill us t r a t i on
No.
Name
Definition
1
LED Window
Speed: up/down 01.0-16.0Km/H (Imperial system unit will not show)
2
LED Window
Time: count up/down 00:00–99:59 Min.(Imperial system unit will not show)
3
Green LED Light
Working light
4
Red LED Light
Stop light
5
Speed Up/Down
Speed setting
6
Time Up/Down
Time setting
7
[ START ]
The key to start unit
8
[ STOP ]
The key to stop unit
9
Emergency Stop
To stop unit for emergency

Process of control console operation - for PR730 only
[ START ] [ Speed Up / Down ] Speen setting
(1.0 - 16.0 km.)
[ STOP ]
Stop Function
Stop automatically
when time isreached
99 Min..
Normal Mode
W / O Time Setting
[ E. STOP ] - To Stop PetRun at any time,push again to reset

[ E. STOP ] - To Stop PetRun at anytime,push again to reset
[ START ] [ Speed Up / Down ]
Speen setting
(1.0 - 16.0 km.)
[ STOP ]
Stop Function
Stop automatically
when time is reached
00.00 Min..
Time Setting Mode
Time Up / Down
Time Setting
(00.00 - 99.00 Min.)
Time Up / Down
Time Setting
(00.00 - 99.00 Min.)
Using The Time Setting
[ Speed Up / Down ]
Speen setting
(1.0 - 16.0 km.)
[ STOP ]
Stop Function
Stop automatically
when time is reached
00.00 Min..
[ E. STOP ] - To Stop PetRun at anytime,push again to reset

Running belt adjustment guide
*The running belt needs to be adjusted once the running belt is loosened or cannot be kept in the right
position (move to the right or left side).
1. Turn the power switch on.
2. Increase the speed to 4 Km/Hr, and keep it working for 2-3 minutes, then start to adjust.
If the running belt moves to left side If the running belt moves to right If the running belt is loose,
please use attached 5mm wrench side, please use attached 5mm please use attached 5mm
fastening the left side screw in wrench fastening the left side wrench fastening the left
clockwise. Turn ¼ turn each time screw in anticlockwise. Turn ¼ and right side screw in
until the running belt moves and turn each time until the running clockwise. Turn ¼ turn each
stays in the middle. belt moves and stays in the time until the running belt is
middle. not loose and stays in the
middle.
Rear rubber feet adjustment
If the floor is not flat, adjust the rubber feet
Counter clockwise turning until the whole
machine is stable.
Folding & storage –for PR710F & PR720F only
(Step 1) (Step 2)
Lift up the frame from rear side with both hands Put lock pin from B into position A

Unfolding –for PR710F/PR720F only
(Step 1) (Step 2)
Pull out the lock pin from A and put into Pull down from the back side of PetRun. It will
drop Position B to the flat level slowly.
Moving –for PR710F/PR720F only
(Step 1) (Step 2)
Place PetRun on level area , and switch Lift up the back portion, then it will be easy to
the fixing locker to position (Lock move.

Incline –for PR725 & PR730 only
(Step 1)
Pull out the incline lever and lift up to adjust incline
PR725 PR730
(Step 2)
Adjust the height by pulling out the adjust lever, and releasing the lever at the required position. (Stepless)
PR725 PR730
