Gorenje BM171E2X User manual

We sincerely thank you for your purchase. We believe you
will soon find ample evidence that you can really rely on
our products. To make the use of the appliance easier, we
attach these comprehensive instruction manual.
The instructions should aid you in getting familiar with
your new appliance. Please, read them carefully before
using the appliance for the first time.
In any case, please make sure the appliance was supplied
to you undamaged. Should you identify and transport
damage, contact your sales representative or the regional
warehouse from where the product was delivered. You
will find the telephone number on the receipt or delivery
report.
We wish you a lot of pleasure with your new household
appliance.
The appliance for household use for heating
food and beverages using electromagnetic
energy, for indoor use only.
These instructions are intended for the user.
They describe the cooker and how to use it. They also
apply to dierent types of appliances, therefore you may
find some descriptions of functions that may not apply to
your appliance.
INSTRUCTIONS FOR
USE
DEAR CUSTOMER
GB
4
MICROWAVE OVEN

Never touch the surfaces of heating or cooking
appliances. They will become hot during
operation. Keep children at a safe distance. There
is a risk of burning!
Microwave energy & High voltage!
Do not remove the cover.
WARNING! The appliance and its accessible parts become
hot during use. Care should be taken to avoid touching
heating elements. Children less than 8 years of age shall
be kept away unless continuously supervised. Children
should be supervised to ensure that they do not play with
the appliance.
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and maintenance shall
not be made by children unless they are older than 8 and
supervised.
Keep the appliance and its cord out of reach of children
less than 8 years.
• WARNING: When the appliance is operated in the
combination mode, children should only use the oven
under adult supervision due to the temperatures
generated; (Only for the model with grill function)
5
IMPORTANT SAFETY INSTRUCTIONS

• WARNING: If the door or door seals are damaged, the
oven must not be operated until it has been repaired by
a competent person;
• WARNING: It is hazardous for anyone other than a
competent person to carry out any service or repair
operation that involves the removal of a cover which
gives protection against exposure to microwave energy;
• WARNING: liquids and other foods must not be heated
in sealed containers since they are liable to explode.
• Children should be supervised to ensure that they do not
play with the appliance.
• Don't remove oven's feet, do not block air events of the
oven.
• Only use utensils that are suitable for use in microwave
ovens.
• When heating food in plastic or paper containers, keep
an eye on the oven due to the possibility of ignition;
• If smoke is observed, switch o or unplug the appliance
and keep the door closed in order to stifle any flames;
• Microwave heating of beverages can result in delayed
eruptive boiling, therefore care must be taken when
handling the container;
• The contents of feeding bottles and baby food jars shall
be stirred or shaken and the temperature checked before
consumption, in order to avoid burns;
• Eggs in their shell and whole hard-boiled eggs should
not be heated in microwave ovens since they may
explode, even after microwave heating has ended;
• When cleaning surfaces of door, door seal, cavity of the
oven, use only mild, nonabrasive soaps, or detergents
applied with a sponge or soft cloth.
6

• The oven should be cleaned regularly and any food
deposits removed;
• Failure to maintain the oven in a clean condition could
lead to deterioration of the surface that could adversely
aect the life of the appliance and possibly result in a
hazardous situation;
• If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
• Do not let the cord hang over the edge of the table or
worktop.
• Never connect this appliance to an external timer switch
or remote control system in order to avoid a hazardous
situation.
• Never replace the light bulb inside the oven. It must
always be replaced by Gorenje service.
• Do not clean the appliance with steam cleaners, high-
pressure cleaners, sharp objects, abrasive cleaning
agents, and abrasive sponges and stain removers.
7

Listed below are, as with all appliances, certain rules to
follow and safeguards to assure top performance from this
oven:
1. Always have the glass tray, roller arms, coupling and
roller track in place when operating the oven.
2. Do not use the oven for any reason other than food
preparation, such as for drying clothes, paper, or any
other nonfood items, or for sterilizing purposes.
3. Do not operate the oven when empty. This could
damage the oven.
4. Do not use the oven cavity for any type of storage,
such a papers, cookbooks, etc.
5. Do not cook any food surrounded by a membrane,such
as egg yolks, potatoes, chicken livers, etc without first
being pierced several times with a fork.
6. Do not insert any object into the openings on the
outer case.
7. Do not at any time remove parts from the oven such
as the feet, coupling, screws, etc.
8. Do not cook food directly on the glass tray. Place food
in/on proper cooking utensil before placing in the
oven.
IMPORTANT - COOKWARE NOT TO USE IN YOUR
MICROWAVE OVEN
– Do not use metal pans or dishes with metal handles.
– Do not use anything with metal trim.
– Do not use paper covered wire twist-ties on plastic
bags.
– Do not use melamine dishes as they contain a
material which will absorb microwave energy. This
may cause the dishes to crack or char and will slow
down the cooking speed.
– Do not use Centura Tableware. The glaze is not
suitable for microwave use. Corelle Livingware
closed handle cups should not be used.
– Do not cook in a container with a restricted
opening, such as a pop bottle or sealed oil bottle, as
they may explode if heated in a microwave oven.
– Do not use conventional meat or candy
thermometers.
– There are the thermometers available specifically
for microwave cooking. These may be used.
9. Microwave utensils should be used only in accordance
with manufacturer's instructions.
10. Do not attempt to deep-fry foods in this oven.
11. Please remember that a microwave oven only heats
the liquid in a container rather than the container itself.
SAFETY
INSTRUCTIONS FOR
GENERAL USE
8

Therefore, even though the lid of a container is not
hot to the touch when removed from the oven, please
remember that the food/liquid inside will be releasing
the same amount of steam and/or spitting when the
lid is removed as in conventional cooking.
12. Always test the temperature of cooked food yourself
especially if you are heating or cooking food/liquid for
babies. It is advisable never to consume food/liquid
straight from the oven but allow it to stand for a few
minutes and stir food/liquid to distribute heat evenly.
13. Food containing a mixture of fat and water,
e.g.stock,should stand for 30-60 seconds in the oven
after it has been turned o. This is to allow the mixture
to settle and to prevent bubbling when a spoon is
placed in the food/liquid or a stock cube is added.
14. When preparing/cooking food/liquid and remember
that there are certain foods, e.g. Christmas puddings,
jam and mincemeat, which heat up very quickly. When
heating or cooking foods with a high fat or sugar
content do not use plastic containers.
15. Cooking utensil may become hot because of heat
transferred from the heated food. This is especially
true if plastic wrap has been covering the top and
handles of the utensil. Potholders may be needed to
handle the utensil.
16. To reduce the risk of fire in the oven cavity:
a) Do not overcook food. Carefully attend microwave
oven if paper, plastic, or other combustible materials
are placed inside the oven to facilitate cooking.
b) Remove wire twist-ties from bags before placing
bag in oven.
c) If materials inside the oven should ignite, keep oven
door closed, turn the oven o at the wall switch, or
shut o power at the fuse or circuit breaker panel.
9

1 - Timer Knob (0-35 Minutes)
1. Door Safety Lock System
2. Oven Window
3. Roller Ring
4. Glass Tray
5. Control Panel
6. Wave guide (please do not remove
the mica plate covering the wave
guide)
Grill rack (Only be used for grill or for
combination function and be placed
on glass tray
2 - Cooking Power Control knob
10
CONTROL PANEL

1. To stop temporarily; Open the door. Result:Cooking
stops. To resume cooking close the door.
2. To stop completely: turn the Timer knob to »0«.
The defrost feature enables you to defrost meat, poultry
and fish. First place the frozen food in the centre of cavity
and close the door.
1. Turn the Cooking Power Control knob to DEFROST.
2. Turn the Timer knob to select the appropriate time.
The oven light comes on.
NOTE: The microwave will run through the time set. An
acoustic signal sound when the time expires. You can
change the cooking time whenever you like.
The following procedure explains how to cook or reheat
food. Always check your cooking settings before leaving
the oven unattended. First place the food in the centre of
cavity and close the door.
1. Set the power level by turning Cooking Power Control
knob.
2. Set the time by turning Timer knob. The oven light
comes on.
NOTE: The microwave will run through the time set. An
acoustic signal sound when the time expires. You can
change the cooking time whenever you like.
20% time for microwave cooking, 80% for grill cooking.
Use for fish or au gratin.
Suppose you want to set combination 1 and cooking for 25
minutes. Open the door and place the food into the oven,
close it.
1. Set the power level by turning Cooking Power Control
knob to COMB 1.
2. Set the time by turning Timer knob to 25min. The oven
light comes on.
NOTE: The microwave will run through the time set. An
acoustic signal sound when the time expires. You can
change the cooking time whenever you like.
STOPPING THE
COOKING
DEFROST COOKING
MICROWAVE COOKING
COMBINATION
COOKING 1
11
OPERATION INSTRUCTION

30% time for microwave cooking, 70% for grill cooking.
Use for puddings omelettes, baked potatoes and
poultry.
Suppose you want to set combination 2 and cooking for
25 minutes. Open the door and place the food into the
oven, close it.
1. Set the power level by turning Cooking Power Control
knob COMB 2.
2. Set the time by turning Timer knob to 25min. The oven
light comes on.
NOTE: The microwave will run through the time set. An
acoustic signal sound when the time expires. You can
change the cooking time whenever you like.
40% time for microwave cooking, 60% for grill cooking.
Use for puddings omelettes, baked potatoes and
poultry.
Suppose you want to set combination 3 and cooking for
25 minutes. Open the door and place the food into the
oven, close it.
1. Set the power level by turning Cooking Power Control
knob to COMB 3.
2. Set the time by turning Timer knob to 25min. The oven
light comes on.
NOTE: The microwave will run through the time set. An
acoustic signal sound when the time expires. You can
change the cooking time whenever you like.
The grill cooking is particularly useful for thin slices
of meat, steaks, chops, kebabs, sausages of piece of
chicken. It is also suitable for hot sandwiches and an
gratin dishes.
For example, suppose you want to grill for 12 minutes.
Open the door and place the food into the oven, close it.
1. Set the power level by turning Cooking Power Control
knob to GRILL.
2. Set the time by turning Timer knob to 12min. The oven
light comes on.
NOTE: The microwave will run through the time set. An
acoustic signal sound when the time expires. You can
change the cooking time whenever you like.
COMBINATION
COOKING 2
COMBINATION
COOKING 3
GRILL
12

1. Turn the oven o and remove the power plug from
the wall socket before cleaning.
2. Keep the inside of the oven clean. When food
splatters of spilled liquids adhere to oven walls,wipe
with a damp cloth. The use of harsh detergent or
abrasives is not recommended.
3. The outside oven surface should be cleaned with
a damp colth. To prevent damage to the operating
parts inside the oven, water should not be allowed
to seep into the ventilation openings.
4. Do not allow the Control Panel to become
wet. Clean with a soft, damp cloth, Do not use
detergents, abrasives or spray-on cleaners on the
control Panel.
5. If steam accumulates inside or around the outside
of the oven door, wipe with a soft cloth.This may
occur when the microwave oven is operated under
high humidity conditions and in no way indicates
malfunction of the unit.
6. It is occasionally necessary to remove the glass tray
for cleaning. Wash the tray in warm sudsy water or
in a dishwasher.
7. The roller ring and oven cavity floor should be
cleaned regularly to avoid excessive noise. Simply
wipe the bottom surface of the oven with mild
detergent, water or window cleaner and dry. The
roller ring may be washed in mild sudsy water
or dish washer. Cooking vapours collect during
repeated use but in no way aect the bottom
surface or roller ring wheels. When removing the
roller ring from cavity floor for cleaning, be sure to
replace it in the proper position.
8. Remove odors from your oven by combining a cup
of water with the juice and skin of one lemon in a
deep microwaveable bowl. Microwave for 5 minutes,
wipe thoroughly and dry with a soft cloth.
13
CARE OF YOUR MICROWAVE OVEN

Do not throw away the appliance with the normal
household waste at the end of its life, but hand it in at an
ocial collection point for recycling. By doing this, you
help to preserve the environment.
ENVIRONMENT
14

1. Make sure all the packing materials are removed from
the inside of the door.
2. Inspect the oven after unpacking for any visual
damage such as:
– Misaligned Door
– Damaged Door
– Dents or Holes in Door Window and Screen
– Dents in Cavity
If any of the above are visible, DO NOT use the oven.
3. This Microwave Oven weighs 14 kg and must be placed
on a horizontal surface strong enough to support this
weight.
4. The oven must be placed away from high temperature
and steam.
5. DO NOT place anything on top of the oven.
6. DO NOT remove the turn -table drive shaft.
7. As with any appliance, close supervision is necessary
when used by children.
8. Make sure that the AC outlet is easily accessible so
that the plug can be removed quickly in an emergency.
Otherwise, it should be possible to disconnect the
device using a switch from the circuit. In this case, the
existing provisions of the electrical safety standards
are considered.
The product has to be correctly installed on earthed
socket with a single-phase AC (230 V/50 Hz).
WARNING! THIS APPLIANCE MUST BE EARTHED!
9. This oven requires 1.2 KVA for its input consultation
with service engineer is suggested when installing the
oven.
CAUTION: This oven is protected internally by a 250V,
10 Amp Fuse.
INSTALLATION
15
MOUNTING THE MICROWAVE OVEN

Power consumption.............................................. 230V~50Hz, 1250W
Output power .......................................................................................700W
Grill heater ............................................................................................1000W
Operating Frequency.................................................................2450MHz
Outside Dimensions...... 595mm(W) x 298mm(H) x 344mm(D)
Oven Capacity....................................................................................17 litres
Uncrated Weight .................................................................Approx. 14 kg
Noise level.............................................................................Lc < 58 dB (A)
This appliance is marked according to the European
directive 2002/96/EC on Waste Electrical and
Electronic Equipment (WEEE).
This guideline is the frame of a European-wide
validity of return and recycling on Waste Electrical
and Electronic Equipment.
Microwave oven may cause interference to your radio, TV,
or similar equipment. When interference occurs, it may be
eliminated or reduced by the following procedures.
a) Clean the door and sealing surface of the oven.
b) Place the radio, TV, etc. as far away from your
microwave oven as possible.
c) Use a properly installed antenna for your radio, TV,
etc. to get a strong signal reception.
SPECIFICATIONS
RADIO INTERFERENCE
WE RESERVE THE RIGHT TO MAKE ANY CHANGES
THAT DO NOT AFFECT THE FUNCTIONALITY OF THE
APPLIANCE.
16

1. Put the template on the bottom of the cabinet.
NOTE: If you want to install microwave oven into 37
cm niche, you have to remove feet from the bottom.
(some models)
2. Make the marks on the bottom of the cabinet
according to marks »a« on the template.
aa
Acenter line
Bbracket
Cscrews A
PREPARE THE
CABINET
BUILT-IN CABINET
17

3. Remove the bottom cabinet template and fix the
bracket with screw A.
4. Install the oven into the cabinet
– Make sure the back of the oven is locked with
bracket.
– Do not cut the power cord.
5. Open the door, fix the oven to the cabinet with screw
(D), at the installation hole.
Then fix the plastic cover to the installation hole (E).
INSTALL THE OVEN
18

1. If the oven will not perform at all, the information
on the display does not appear or the display
disappeared:
a) Check to ensure that the oven is plugged in
securely. If it is not, remove the plug from the outlet,
wait 10 seconds and plug it in again securely.
b) Check the premises for a blown circuit fuse or a
tripped main circuit breaker. If these seem to be
operating properly, test the outlet with another
appliance.
2. If the microwave power will not function:
a) Check to see whether the timer is set.
b) Check to make sure that the door is securely closed
to engage the safety interlocks. Otherwise, the
microwave energy will not flow into the oven.
If none of the above rectify the situation, then
contact the nearest authorized service agent.
The appliance for household use for heating food and
beverages using electromagnetic energy, for indoor use
only.
If you need information or if you have a problem, please
contact the Gorenje Customer Care Centre in your country
(you find its phone number in the worldwide guarantee
leaflet). If there is no Customer Care Centre in your
country, go to your local Gorenje dealer or contact the
Service department of Gorenje domestic appliances.
For personal use only!
Additional recommendations for cooking with
microwave and useful advices can be found on web
side:
http://www.gorenje.com
WISHES YOU A LOT OF PLEASURE WHILE USING YOUR
APPLIANCE
19
BEFORE YOU CALL FOR SERVICE
GUARANTEE & SERVICE
