Gorenje WS53125 User manual

Instructions for Use
Washing machine

311220
Thank you for your confidence in purchasing our washing machine, and congratulations on the
excellent choice.
Your new washing machine meets the requirements of modern treatment of laundry. It is rational in
the consumption of energy, water and washing agents.
Our appliances are friendly to the environment. Some of the materials may be recycled, others
deposited or decomposed. To avoid pollution of environment, once your appliance is no longer
useful, take it to your local authorized waste appliance dealer.
The appliance is intended exclusively for use in households. If the appliance is used for
professional purposes, for profit, or for purposes beyond regular use in a household, or if appliance
is used by a person who is not a consumer, the warranty period equals the shortest warranty period
possible as stipulated by the relevant legislation.
Description of washing machine ..................................3
Cautions ..........................................................................4
Installation and connection...........................................5
Operation.........................................................................9
Tips for washing and energy saving ..........................19
Cleaning and maintenance..........................................20
Troubleshooting ........................................................... 23
Tables ............................................................................27
2

311220
1. Front panel
2. Detergent dispenser
3. Door
4. Filter lid
5. Adjustable legs
6. Water outlet hose
7. Water inlet hose
8. Mains power cable
• Max. load: 8 kg / 7 kg
Dimensions (w x d x h):
600 mm x 600 mm x 850 mm
Depth with door open: 106 cm
Weight (net): 78 kg / 93 kg
Nominal voltage: 230 V, 50 Hz
Power: 2300 W
Power socket: (230 V, 50 Hz, 10 A)
Water pressure: min. 0,05 MPa, max. 0,8 MPa
Fuse: 10 A
• Max. load: 5,5 kg / 5 kg
Dimensions (w x d x h):
600 mm x 440 mm x 850 mm
Depth with door open: 88 cm
Weight (net): 78 kg / 63 kg
Nominal voltage: 230 V, 50 Hz
Power: 2000 W
Power socket: (230 V, 50 Hz, 10 A)
Water pressure: min. 0,05 MPa, max. 0,8 MPa
Fuse: 10 A
3
Description of washing machine
Technical information
(depending on model)

311220
• Be sure to remove transport brackets prior first use of the appliance. Attempted operation of the
blocked machine may result in irreparable damage which is not covered by the manufacturer’s
warranty!
• When connecting your washing machine to water supply, be sure to use brand new water inlet
hose and appropriate sealing gaskets (attached).
• Do not locate the machine in a room with temperature below 0°C. Parts of the machine may be
damaged if frozen.
• Install the washing machine in a perfectly horizontal position, on solid flat concrete floor.
• Follow the instructions for correct installation and water and mains connections.
• Never immerse the end of the drain hose into the draining water.
• Prior starting the washing cycle lock the door by pressing them at the designed spot.
• Door may not be open during the washing cycle.
• We recommend running the self-cleaning program before the first wash in order to remove any
impurities from the washing machine drum. (See chapter on” Selecting additional functions”.)
• Use only detergents and softeners for machine wash. Manufacturer may not assume
responsibility for any damage and eventual discoloring of gaskets and plastic components as a
consequence of incorrect use of bleach and/or coloring agents.
• When removing limescale deposits, use substances with added anti-corrosion agent. Heed
manufacturer’s instructions. Finish the descaling process with several rinsing cycles to remove
any residual acids.
• For removal of lime residues use such agents with added anti-corrosion agents. Follow the
manufacturer’s instructions. Finish the lime removal by multiple rinsing to remove completely
eventual acid residues.
• Never use detergents containing solvents, since there is a danger of creating toxic gasses which
may damage the machine and result in ignition or explosion.
• This product does not release silver ions during the washing cycle.
• Upon completion of washing operation close the water faucet.
• Before any transport block the machine by inserting at least one transport blocking rod. Prior this
operation disconnect the appliance from the mains power!
• Rating plate with basic information is located above the opening of the machine.
• The warranty shall not apply to consumables (bulbs), minor discoloration or deviations of color,
increased noise level as a consequence of appliance age, which does not affect appliance
functionality, and aesthetical deficiencies which do not affect appliance functionality or safety.
• The appliance is manufactured in compliance with all relevant safety standards; however, it is
recommended that persons with impaired physical, motional, or mental abilities, or persons with
inadequate experience and knowledge, do not use the appliance without due supervision. The
same recommendation applies to minors using the appliance.
Before connecting the appliance read these instructions carefully. Repairing the failure
arising from inappropriate connections or use of the appliance is not covered by the
guarantee.
4
Cautions

311220
In removing the wrapping be careful not to damage the
appliance with a sharp object.
Before connecting the appliance, let it warm up to room
temperature (wait for two hours).
• Our appliances are packed in environmentally friendly
materials which may be recycled, deposited or decomposed
without any threat to the environment.
• To this end all wrappings are marked accordingly.
• Move the pipes.
• Loosen screws (A) at the rear of the machine (Fig. 1).
• Remove the brackets (B) (Fig. 1) and slide them into the
groove on the blocking rod (Fig. 2) - the right one should be
turned around.
• Use the brackets to rotate blocking rods for 90° and pull them
out.
• Close the openings with attached plastic pegs.
Save transport brackets for eventual later use.
Fig. 1 Fig. 2
Be sure to remove the transport brackets prior first
use, otherwise the appliance may be permanently
damaged. In such cases the warranty conditions are
void.
Package removal
Removal of transport
brackets
The symbol on the product or on its packaging indicates that this product may not
be treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. By
ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. For more
detailed information about recycling of this product, please contact your local city
office, your household waste disposal service or the shop where you purchased the
product.
5
Installation and connection

311220
• Put the appliance in horizontal position by turning the
adjustable legs. The legs are adjustable up to +/- 1 cm.
After the adjustment tighten the nuts firmly (A) - towards
the bottom of the machine!
Vibrations, moving of the appliance and loud operation
due to incorrect setting of the adjustable feet shall not
be covered by this warranty.
The appliance should be placed on a surface with
concrete base; the surface should be dry and clean in
order to prevent slipping. The adjustable feet should
also be cleaned before installation.
• If you have a tumble dryer of the same dimensions, you can
place it on top of the washing machine.
To ensure correct operation of the appliance, water
pressure inlet must be between 0,05 and 0,8 MPa.
Minimum water pressure can be established by
measuring the quantity of poured out water. 3 litres of
water must be poured out from completely opened tap
in 15 seconds.
• Take the water inlet hose from the drum and attach the inlet
hose angle extension (1) to the washing machine by screwing
it onto the provided thread (certain models only).
• Insert the gasket with a filter net into the straight inlet hose
attachment nut (2) and screw the nut onto the water tap. (With
some models, the gasket with filter net is already fitted and
any additional fitting into the nut on the straight attachment is
not required).
• In case of hot and cold water connection, connect one hose to
cold and other to hot water faucet as marked at the rear of the
appliance (letters C and H) (C - cold; H - hot)
The inlet hose should be tightened manually, firmly
enough to prevent any leaks. After tightening the hose,
check for any leaks.
Use of pliers, wrenches, or other similar tools is not
allowed when installing the hose, as these tools can
damage the nut thread.
Leveling the appliance
Water inlet connection
6

311220
Partial Aqua-stop (water stop system)
In case of damage on the interior pipe, leaking is prevented by
automatic closing system which stops water inlet to the machine.
In such cases display A turns red.
Inlet pipe must be replaced.
Complete Aqua-stop (certain models only)
In case of damage on the interior pipe, leaking is prevented by
automatic closing system which stops water inlet to the machine.
Security system also detects whether there is any water leakage
within the interior of the machine. In such cases washing is
suspended, machine switches on the pump and signals error.
Do not immerse the Aqua-stop system inlet pipe into
the water, because it contains the electric valve!
• Fix the outlet hose to run into the sink or the bathtub, or
connect it directly to the wall drain outlet (diameter min. 4 cm).
• Wall drain must be installed properly and must enable
occasional cleaning.
• Fasten the outlet hose support with a piece of rope led through
the hose elbow, to prevent the hose from slipping to the floor.
The end of outlet hose should be placed between minimum 60
cm and maximum 100 cm above the floor level.
• Plug the mains power cable to the wall mains socket.
• Required voltage and other information are written on the
rating plate above the door opening of the machine.
The wall socket must be accessible at all times and
must be equipped with an earth lead (in accordance
with the local safety regulations).
The permanent connection must be fitted by an
authorized personnel only.
Damaged mains power cable may be replaced only by
the producer or his authorized personnel.
Never plug the appliance into the electric shaver socket
or hair dryer socket.
Water outlet connection
Connect the appliance to
the mains supply
7

311220
8

311220
Keys for settings
Key C (MENU) -Use this key to scroll through additional functions.
Key D (SELECTION) -Use this key to confirm the selected function.
Key F (START/PAUSE) -Use this key to start or stop the program.
A - Program selector knob
B - Spinning rpm setting key / pump stop
C - Additional function key
D - Confirm additional function key
E - Delayed start key
F - START / PAUSE button
G - Display
9
Program selector Basic programs Partial programs
Cotton
Heavy duty
Quick program
15° Tap Water+
Rinse
Synthetics Softening
Delicate Spinning + Pumping water
Wool
Sportswear
Manual wash
Mix
Operation

311220
- Open the door of the machine.
Door is opened by pulling the handle (lever) on the right hand
side of the door towards you.
- Sort the laundry by the type of fabrics.
Do the buttons and zippers, tie the strings and pull out
the pockets.
Very delicate laundry should be put in a special
protective sack.
It is suggested to load the drum with items of different
sizes.
Pay attention to the labels on the clothes, indicating
the recommending washing mode (see table of
textile treatment symbols on the last page of these
instructions).
- Load the laundry into the drum.
Check that the drum is empty.
- Close the door of the appliance.
- Open the water inlet faucet.
- Push the ON/OFF button and select washing program.
- Add washing and treatment agents (detergent and softener).
- Start the operation by pushing the START knob (F).
Switch on the washing machine by rotating the program selector
dial (A) from the “0” position. Select the desired washing program
according to type of fabric and washing temperature (see
program table). Choose between basic and partial programs.
Program selector dial (A) can be rotated in both directions.
During operation, the dial will not rotate.
Press the corresponding keys to select additional functions or
settings.
Selection of washing program and additional functions can be
changed before pressing the START (F) key.
Washing procedure
Washing machine
operation
10

311220
1 - Spinning rpm;
2 - Time remaining until program completion / delayed start
countdown
3 - Additional functions;
4 - Washing stages (prewash, washing, rinsing, spinning);
Display (G)
After setting the basic or partial programs and pressing the
START (F) key, the display indicates spinning rpm of the selected
program and time remaining until program completion. If the
additional function of delayed start is used, the time remaining
until the start of the program is first displayed; when this time
expires (when the countdown reaches zero), the display will
indicate the time remaining until program completion. If any of
the other additional functions are selected, they will be lit up
on the display (some combinations of additional functions are
mutually exclusive; see Combination Table).
During the wash, time remaining until the end of the program is
displayed in hours and minutes.
If no program is selected and started and no other action is taken
within five minutes after turning on the machine, the display will
be automatically turned off to save energy.
The display will turn on again when you rotate the program
selector dial or press any button.
If no action is taken after the end of the program, the display will
also turn off after five minutes.
LOW POWER MODE
P o = weighted power in ‘off mode’ [W] 0,09
P l = weighted power in the ‘left on mode’ [W] 1,16
T l = time in ‘left on mode’ [min] 10,0
11

311220
Low water temperature, low network voltage, and
smaller loads of laundry may extend the washing time;
the time indicated on the display is constantly adjusted
to account for such conditions.
- Selecting the basic programs ( , , , , , , )
Select one of the basic programs by rotating the program
selector dial (A). These are full programs that include all washing
stages, including conditioning and spinning (see program
table). According to the program selected, the display will
indicate spinning speed (rpm) and time remaining until program
completion (however, both can be adjusted).
Cotton
Normally soiled cotton and linen bedding and underwear,
tablecloths, towels, upper body garments, etc.
• Intensive program
- for heavily soiled laundry with resistant dyes
• Quick program
- for minor loads, less soiled laundry, for refreshing the
laundry etc.
- save time and power
• Pipeline water
- for less soiled laundry
- use washing gels for washing at 15°C
- save time and power (the machine only heats the water if its
temperature is below 15°C)
Synthetics
Normally soiled shirts, blouses, and other garments made of
polyester, polyamide, or combination of these fibres with cotton.
Delicate
Delicate clothes (dresses, skirts, blouses, etc.) and curtains.
Woollens
Woollen products indicated as washing machine safe.
Sportswear
Quick wash of lightly soiled sports clothes made of cotton and
synthetic fibres.
Hand wash
For laundry made of flax, silk, wool, or viscose, indicated for
manual washing.
Very gentle program, completed with a short spinning cycle
(maximum of 600 rpm).
12

311220
Mix
Normally soiled dyed laundry made of various resistant fibres,
washed at 30 or 40°C.
- Selecting additional functions
(, , , , , , , , , , )
Selecting an additional function allows changing the basic
programs or partial programs. Additional functions can be
selected with the following keys:
Dodatne funkcije lahko izbirate s tipkami:
- Key (B) – selecting spinning speed (rpm)
- Key (C) – other functions
- Key (E) – delayed start
Select the function after selecting the basic program,
but before pressing the START (F) key.
Spinning speed / pump stop (select with (B) key)
Pressing the (B) key will reduce spinning speed in steps until it
reaches “0”. With each pres, the spinning rpm will decrease. The
last option is “pump stop”, which means that the laundry remains
soaked in the water from the last rinsing (pump stop icon and
maximum spinning speed for selected program are indicated).
Use the pump stop function when you want to prevent wrinkling
or if you are unable to take the laundry from the machine
immediately after program completion. It is particularly convenient
and appropriate with programs for synthetic fibres and delicate
program . Use of pump stop function is not recommended with
woollens and manual wash (see section Interruption / By
the user / Activating the PUMP STOP function).
Choosing additional functions with the (C) key
Each time the (C) key is pressed, a set of function is displayed
which are possible with a particular program. The currently
highlighted function will flash before it is selected. Use the (D)
key to confirm your selection and then the symbol of the selected
functions is highlighted and it no longer flashes. If you do not
wish to select the currently displayed function, use the (C) key to
move to the next function. With settings were several functions
can be selected, those that are basically possible are indicated
on the display. If you wish to select more additional functions,
repeat the process. Follow the same process to deactivate a
function. Some settings cannot be selected simultaneously (see
Program / Additional Settings Table).
If the key (C) or (D) is not pressed after a certain period of time,
the program will jump back to the main menu.
13

311220
Prewash
For washing heavily soiled laundry with mostly superficial dirt.
In basic programs, prewash is switched off. It can be activated
using the Selection (C) key in programs for cotton, synthetics,
delicates, and mix.
Short program
Power-efficient function for washing less soiled laundry or a
smaller load. Washing and rinsing time is decreased. With some
programs, water consumption is also lower.
If the short program function is selected with the Cotton 30°C
program, “Quick program” is activated.
Additional rinse
For laundry worn by persons highly sensitive to washing
detergents.
Self-cleaning program (SterilTub)
This function is designed to remove impurities, bacteria, and any
odour from the appliance. It can only be selected with the Cotton
95°C program. No other function can be selected simultaneously.
Before running the self-cleaning program, empty the washing
machine drum; there should be no laundry in the washing
machine during this program.
Adding a small amount of powder detergent will improve the elf-
cleaning program effect. If washing programs with temperatures
above 60°C are not used regularly, it is recommended that self-
cleaning program be run at least once per month.
Easy ironing
Gentle tumbling and final spin prevent excessive creasing of
laundry. Follow the determined maximum load for particular
programs. Suggested reduced load (cotton 3 kg, synthetics 2 kg).
Cold wash (only available with some models)
For washing lightly soiled or color-sensitive laundry.
When this function is activated, the heaters in the washing
machine are turned off, and the washing program is shortened.
Higher water level
• Improves rinsing, which is particularly important if your skin is
oversensitive to detergents.
• For washing heavily soiled laundry.
14

311220
Delayed start (select with (E) key)
When the (E) key is pressed, the display (G) will indicate the
time 00:00 and the symbol . With each subsequent press on
the (E) key, time on the display will increase by 30 minutes (up
to 2:00) or by 1 hour (for a maximum delay of 24 hours). If no
other key is pressed, the display will again indicate the duration
of the program after a while, but the delay time will be saved. The
function is activated when the START (F) key is pressed. Time
will count down by minutes. When the countdown reaches zero,
the washing program will begin automatically. The symbol
disappears and the symbol appears.
• If you wish to cancel the delayed start function, press the
START/PAUSE key and then the (E) key and press it for three
seconds. If you wish to continue with the program (without
delayed start), press the START key.
• If you wish to change the delayed start setting, first rotate
the program selector dial (A) to “0” position and repeat the
process.
- Selection of partial programs ( , , )
These are independent programs and may be used when you do
not need the entire washing program. In case you would like to
use more additional programs in a sequence, you must turn off
the appliance prior any new program selection (turn the program
selector to “0” for at least one second).
Rinse
Independent program for rinsing delicate laundry without
spinning between the rinsing cycles and only with a short final
spin. Use it to rinse hand-washed delicate laundry. Spinning
speed can be decreased with the (B) key .
Conditioning
The program is intended for softening, starching, or impregnation
of washed laundry.
The Conditioning program can also be used as an independent
or additional rinse; in this case, do not add the softener /
conditioner.
The program is ended with a spin cycle at a maximum of 1000
rpm.
Spinning speed can be decreased with the (B) key .
Spinning + pumping
Intensive spinning for non-delicate laundry at highest rpm.
Spinning speed can be decreased with the (B) key .
If you wish to pump the water out of the machine, without
spinning, press the (B) key several times to decrease the
setting to “0”.
15

311220
- Adding washing and softening agents
(see Tips for washing and energy saving)
• pre-wash compartment
• main wash compartment
• softener compartment
If you do not apply the program which includes the pre-wash
feature, you may add washing detergent directly into the drum,
using the measuring vessel.
When adding softener, be careful to fill the dispenser
only up to the marked level.
Be sure to close the detergent dispenser when
opening/closing the appliance door.
• Press the START (F) key. A sound signal will be emitted. After
a few seconds, the machine starts the program. If the door
is not closed after starting the program, the washing symbol
will start to flash after a few seconds, and a warning beep will
be heard. When the door is closed, the machine will start the
selected program.
• After the completion of each washing stage, the symbol
disappears and the following symbol appears.
• In case you would like to alter the washing program after the
initiated washing operation, turn the program selector for one
second to the position “0”, followed by the selection of a new
program. Switching the machine off deletes any previously
selected additional functions(i.e. Pump stop), so they have to
be reactivated.
Upon switching OFF, all additional pre-selected
functions are deleted; therefore they must be switched-
ON again.
- End of washing program
The display reads End.
• A sound is emitted, indicating that washing machine door can
be opened.
• Take the laundry out of the drum and remove any remaining
particles or foreign bodies from the door seal.
• Leave the door ajar to let the machine dry.
• Close the water inlet tap.
• Turn off the washing machine by rotating the program selector
knob (A) to position “0”.
• After the end of washing program, power supply should be
turned off by pulling the mains cord plug out of the outlet.
Start the operation
16

311220
• By the user
Selecting the PUMP STOP function
If you have chosen the pump stop function, the program will
stop at the last rinse and the PUMP STOP symbol will flash
on the display (washing machine door locked the entire time).
Before pressing the START (F) key, spinning rpm can be
decreased. If you do not wish to do so, the program can be
ended by pressing the START (F) key, and the washing process
will end with the spinning cycle defined by the program.
While washing program is running (after pressing the START
key), you can use (B) key to decrease the spinning speed.
Manual (physical) termination
The program can be cancelled / terminated by rotating the
program selector dial (A) to the “0” position. If there is water in
the machine, select the additional program (pump + spin ).
PAUSE key
The program can be paused at any time by pressing the PAUSE
(F) key. If there is no water in the drum, the water can be opened
after a while; if there is water in the drum, the door cannot be
opened. To resume the program, press the START (F) key.
• Faults and errors
The program is interrupted in case of faults and errors.
An audio signal will notify you of such occurrence and the
type of fault will be indicated on the display (see section
Troubleshooting).
• Power failure
At electric cutout the program is interrupted, however, after the
power supply has been re-established, the program operation
automatically proceeds.
If a power failure occurs when the drum is still full of
water, be careful not to open the door before you pump
the water out.
Interruptions
17

311220
• Child lock
- Engage the child lock by simultaneously pressing the (C)
and (D) keys and holding them for at least three seconds.
Selection is confirmed with an audio signal and the symbol
which appears on the display. Use the same procedure to
deactivate the child lock.
- As long as the Child lock function is engaged you may not alter
the program or additional functions. You may merely switch off
the machine by turning the program selector (A) to the position
“0”. Child lock remains active even after the appliance is
switched off, and you have to disengage it if you want to select
a new washing program.
• Setting the sound signal
The appliance allows setting a louder sound signal or turning
it off. Set the function before choosing your basic program.
To set the function, press the (C) key and simultaneously
move the program selector dial (A) from the “0” position to
the first washing position (clockwise). S1 will be indicated on
the display, which means preset normal loudness of the beep
(audio signal). Press the (C) key to increase the loudness
(S2), or press the same key again to turn off the beep (S0). If
nothing is pressed, the program will return to the main menu
after a while. The setting will remain stored even in case the
washing machine is switched off.
Special functions
18

311220
• Before washing sort out the laundry according to the type, degree of dirtiness and color
resistance.
• Prior selecting the washing program consult the sewn tab with information on a particular piece
of laundry (see Maintenance Chart on the last page).
• Wash separately the new colored textile products for the first time.
• Wash heavily soiled laundry in small quantities and add more detergent.
• Treat stubborn stains with special stain remover, it will save energy.
• With lightly stained laundry select washing program without pre-wash, use short program and
select lower washing temperature. This way you may save up to 50% of energy.
• Avoid washing too little quantities of laundry because of energy saving and for better
performances of the appliance.
• The largest allowed quantity of dry laundry is indicated in the Program chart.
• Before washing empty the pockets, close zip fasteners, and remove any metal fasteners or
badges that might clog the drain or damage the laundry or drum interior.
• Loosen the stacked laundry prior inserting it into the drum.
• Use only detergents for machine wash.
• Add powder or liquid detergents according to the manufacturer’s instructions.
• For different washing temperatures and selected washing programs, please note the
recommendations provided by detergent manufacturers.
• If water hardness level exceeds 14°dH degrees, the use of water conditioner is required. Any
damage to the heater due to failure to use a water conditioning agent shall not be covered by
this warranty.
• Chlorine-based whitening agents are not recommended, as it can damage the heater.
Hardness
scale
Degree of hardness
°dH(°N) m mol/l °fH(°F) p.p.m.
1 - Soft < 8,4 < 1,5 < 15 < 150
2 - Medium 8,4 - 14 1,5 - 2,5 15 - 25 150 - 250
3 - Hard > 14 > 2,5 > 25 > 250
In case of hard water add detergent according to the Chart for
degree 1 and add appropriate quantity of water softener (see
manufacturer’s instructions).
• If you do not apply the program which includes the pre-wash
feature, you may add washing detergent directly into the drum.
• If you use thick liquid softener it is recommended to dilute
it with water, to prevent clogging of dispenser compartment
ducts.
• Washing machine is equipped with the dispenser partition
gate, so you may pour liquid detergent also into the central
compartment (depending on model). If you use powder
detergent the gate is lifted up, and in case of liquid detergent it
is slid down.
19
Tips for washing and energy saving

311220
• Liquid detergents are intended for main wash only, without
pre-wash.
• Insert particularly delicate linen (stockings, delicate female
underwear, etc.) into the special bag.
• High spin RPM leave less moisture in laundry which dries out
much quicker in the tumble dryer, thereby saving energy.
Do not put clods of detergent into the soap dispenser
as the tube in the washing machine may clog.
Disconnect the washing machine from the mains
before cleaning!
• The casing should be cleaned with soft cloth and mild
detergent.
• The interior of the drum and the door gasket is cleaned by
washing at 60°C without laundry and adding half quantity of
detergent.
• Frequent, or predominant, washing at low temperatures, using
liquid detergents, may result in development of bacteria which
causes odor in the washing machine.
To prevent this, we recommend running the auto-clean
(SterilTub) program occasionally (see chapter “OPERATION /
selecting additional functions”).
• If necessary, clean the detergent dispenser. Pull it out from its
casing completely by pressing the flap (see Fig.).
20
Cleaning and maintenance
