Gorenje WA 63 Series User manual

Instructions for Use
Washing machine

141576
Thank you for your confidence in purchasing our washing machine, and congratulations on the
excellent choice.
Your new washing machine meets the requirements of modern treatment of laundry. It is rational
in the consumption of energy, water and washing agents. Our appliances are friendly to the
environment. Some of the materials may be recycled, others deposited or decomposed. To avoid
pollution of environment, once your appliance is no longer useful, take it to your local authorized
waste appliance dealer.
The appliance is intended exclusively for use in households. If the appliance is used for
professional purposes, for profit, or for purposes beyond regular use in a household, or if appliance
is used by a person who is not a consumer, the warranty period equals the shortest warranty period
possible as stipulated by the relevant legislation.
Description of washing machine ..................................3
Cautions ..........................................................................4
Installation and connection...........................................5
Operation.........................................................................8
Tips for washing and energy saving ..........................19
Cleaning and maintenance..........................................20
Failures..........................................................................22
Tables ............................................................................25
2

141576
1. Front panel
2. Detergent dispenser
3. Door (depending on the model)
4. Filter lid
5. Adjustable legs
6. Water outlet hose
7. Water inlet hose
8. Mains power cable
• Max. load: 6 kg / 7 kg
Dimensions (w x d x h):
600 mm x 600 mm x 850 mm
Depth with door open: 106 cm
Weight (net): 90 kg
Nominal voltage: 230 V, 50 Hz
Power: 2300 W
Power socket: (230 V, 50 Hz, 10 A)
Water pressure: min. 0,05 MPa, max. 0,8 MPa
Fuse: 10 A
• Max. load: 4,5 kg
Dimensions slim aparat (w x d x h):
600 mm x 440 mm x 850 mm
Depth with door open: 88 cm
Weight (net): 76 kg
Nominal voltage: 2000 W
3
Description of washing machine
Technical information
(depending on the model)

141576
• Be sure to remove transport brackets prior first use of the appliance. Attempted operation of the
blocked machine may result in irreparable damage which is not covered by the manufacturer’s
warranty!
• When connecting your washing machine to water supply, be sure to use brand new water inlet
hose and appropriate sealing gaskets (attached).
• Do not locate the machine in a room with temperature below 0°C. Parts of the machine may be
damaged if frozen.
• Install the washing machine in a perfectly horizontal position, on solid flat concrete floor.
• Follow the instructions for correct installation and water and mains connections.
• Never immerse the end of the drain hose into the draining water.
• Prior starting the washing cycle lock the door by pressing them at the designed spot.
• Door may not be open during the washing cycle.
• Use only detergents and softeners for machine wash. Manufacturer may not assume
responsibility for any damage and eventual discoloring of gaskets and plastic components as a
consequence of incorrect use of bleach and/or coloring agents.
• For removal of lime residues use such agents with added anti-corrosion agents. Follow the
manufacturer’s instructions. Finish the lime removal by multiple rinsing to remove completely
eventual acid residues.
• Never use detergents containing solvents, since there is a danger of creating toxic gasses which
may damage the machine and result in ignition or explosion.
• Upon completion of washing operation close the water faucet.
• Before any transport block the machine by inserting at least one transport blocking rod. Prior this
operation disconnect the appliance from the mains power!
• Rating plate with basic information is located above the opening of the machine.
• The warranty shall not apply to consumables (bulbs), minor discoloration or deviations of color,
increased noise level as a consequence of appliance age, which does not affect appliance
functionality, and aesthetical deficiencies which do not affect appliance functionality or safety.
Before connecting the appliance read these instructions carefully. Repairing the failure
arising from inappropriate connections or use of the appliance is not covered by the
guarantee.
The belt can be replaced by a servising engineer only, who incorporates an original
spare part with the marking MIG OPTIBELT 6EPJ 1260, code 111622 or 6EPJ 1278 code
587612.
The symbol on the product or on its packaging indicates that this product may not
be treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. By
ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of thisproduct. For more
detailed information about recycling of this product, please contact your local city
office, your household waste disposal service or the shop where you purchased the
product.
4
Cautions

141576
In removing the wrapping be careful not to damage the
appliance with a sharp object.
Before connecting the appliance, let it warm up to room
temperature (wait for two hours).
• Our appliances are packed in environmentally friendly
materials which may be recycled, deposited or decomposed
without any threat to the environment.
• To this end all wrappings are marked accordingly.
• Move the pipes.
• Loosen screws A at the rear of the machine (Fig. 1).
• Remove the brackets B (Fig. 1) and slide them into the groove
on the blocking rod (Fig. 2) - the right one should be turned
around.
• Use the brackets to rotate blocking rods for 90° and pull them
out.
• Close the openings with attached plastic pegs.
Save transport brackets for eventual later use.Save the transport
brackets for eventual later use.
Be sure to remove the transport brackets prior first
use, otherwise the appliance may be permanently
damaged. In such cases the warranty conditions are
void.
Fig. 1 Fig. 2
• Put the appliance in horizontal position by turning the
adjustable legs.
The legs are adjustable up to +/- 1 cm.
After the adjustment tighten the nuts firmly (A) - towards
the bottom of the machine!
Vibrations, moving of the appliance and loud operation
due to incorrect setting of the adjustable feet shall not
be covered by this warranty.
The appliance should be placed on a surface with
concrete base; the surface should be dry and clean in
order to prevent slipping. The adjustable feet should
also be cleaned before installation.
Package removalPackage removal
Removal of transport
brackets
Removal of transport
brackets
Leveling the applianceLeveling the appliance
5
Installation and connection

141576
• If you have a tumble dryer of the same dimensions, you can
place it on top of the washing machine.
To ensure correct operation of the appliance, water
pressure inlet must be between 0,05 and 0,8 MPa.
Minimum water pressure can be established by
measuring the quantity of poured out water. 3 litres of
water must be poured out from completely opened tap
in 15 seconds.
• Insert the gasket with screen into the water inlet hose thread
Screw the hose thread to the water faucet
• In case of hot and cold water connection, connect one hose to
cold and other to hot water faucet as marked at the rear of the
appliance (letters C and H) (C - cold; H - hot)
Partial Aqua-stop (water stop system)
In case of damage on the interior pipe, leaking is prevented by
automatic closing system which stops water inlet to the machine.
In such cases display A turns red.
Inlet pipe must be replaced.
Complete Aqua-stop
In case of damage on the interior pipe, leaking is prevented by
automatic closing system which stops water inlet to the machine.
Security system also detects whether there is any water leakage
within the interior of the machine. In such cases washing is
suspended, machine switches on the pump and signals error.
Do not immerse the Aqua-stop system inlet pipe into
the water, because it contains the electric valve!
Water inlet connectionWater inlet connection
6

141576
• Fix the outlet hose to run into the sink or the bathtub, or
connect it directly to the wall drain outlet (diameter min. 4 cm).
• Wall drain must be installed properly and must enable
occasional cleaning.
• Fasten the outlet hose support with a piece of rope led through
the hose elbow, to prevent the hose from slipping to the floor.
The end of outlet hose should be placed between minimum 60
cm and maximum 100 cm above the floor level.
• Plug the mains power cable to the wall mains socket.
• Required voltage and other information are written on the
rating plate above the door opening of the machine.
The wall socket must be accessible at all times and
must be equipped with an earth lead (in accordance
with the local safety regulations).
The permanent connection must be fitted by an
authorized personnel only.
Damaged mains power cable may be replaced only by
the producer or his authorized personnel.
Never plug the appliance into the electric shaver socket
or hair dryer socket.
If the socket, the machine is connected to, is protected by the
overload protection switch (FID), the nominal differential current
of the switch must be 30 mA (switch mark Idn or I∆n). In case of a
smaller nominal current in the switch, the machine may be switched
off during its normal operation.
Water outlet connectionWater outlet connection
Connect the appliance to
the mains supply
Connect the appliance to
the mains supply
7

141576
Functional knobs
Knob B (MENU) - Use this knob to scroll around main menu.
Knob C (SELECTION) - Use this knob to scroll around main menu.
Knob F (START/PAUSE) - Use it to start or finish the program.
A - program selector
B - MENU knob
C - SELECTION knob
D - short program knob
E - easy ironing knob
F - START/PAUSE knob
G - door knob (depending on the model)
H - display
8
Program selector Basic programs Partial programs
Cotton
Heavy duty Rinse
Synthetics Softening
Delicate Pumping water
Wool Spinning
Manual wash
Jogging
Mix
Operation

141576
- Selecting language
To change the language in which the information appear on
the display, press simultaneously the key MENU (B) and
SELECTION(C), and turn the program selector (A) from
position “0” to the first program in clockwise direction (Cotton
95°C). The name of actually selected language appears on the
display. Scroll down the selection of languages by pressing the
SELECTION knob (C), until you find the desired language. Then
turn the program selector back to position “0”. Last selected
language will be saved automatically.
• Open the door of the machine.
• Load the laundry into the drum.
• Close the door.
• Open the water inlet faucet.
• Push the ON/OFF button and select the program
• Add washing and treatment agents (detergent and softener).
• Start the operation by pushing the START knob (F).
- Open the door of the machine.
Door is opened by pulling the handle (lever) on the right hand
side of the door towards you (in certain models the door is
opened by pressing the knob DOOR (G).
- Sort the laundry by the type of fabrics.
Do the buttons and zippers, tie the strings and pull out
the pockets.
Very delicate laundry should be put in a special
protective sack.
It is suggested to load the drum with items of different
sizes.
Pay attention to the labels on the clothes, indicating
the recommending washing mode (see table of
textile treatment symbols on the last page of these
instructions).
- Load the laundry into the drum.
Check that the drum is empty.
- Close the door of the appliance.
- Open the water inlet faucet.
- Switch the machine on.
Before first useBefore first use
Washing procedureWashing procedure
9

141576
1. Name of the program, 2. Duration or time of day, 3. Symbols
for activation of additional functions, 4. Water quantity in liters,
5. Spin RPM
Program is selected by turning the program selector from the “0”
position to the desired washing program. The display indicates
particular washing program, selected by the program selector.
The
program selector may be turned in both directions, and the
appropriate program selected according to the type of laundry
washed and the required washing temperature (see Program
Chart for help).
You may select basic or partial programs.
With each basic program you may also select additional
functions.
Selected program may be changed at random prior pushing the
START button (F).
- Selection of basic programs (, , , , , , )
Basic programs are selected by turning the program selector
(A) to the desired program. The display indicates the selected
program, along with basic settings.
With each basic program you may also select additional
functions.
Cotton: whites/colored
Normally stained cotton and flax bed linen and underwear, table
cloth, bathroom towels, top garments, etc.
For heavily stained permanent press use the heavy duty
program, or program with the pre-wash, or select soaking in case
of stains.
Synthetics
Normally stained shirts, blouses and other polyester and
polyamide garments, or a mixture of these fabrics with cotton.
For heavily stained resistant color laundry, use program with
pre-wash.
Washing machine
operation
Washing machine
operation
10

141576
Delicate
This is a program for delicate fabrics (dresses, skirts, blouses)
and curtains.
Wool
Especially gentle program for washing wool and garments made
from mixture of other fabrics with wool, appropriately marked for
machine washing.
Manual wash
Very gentle program concluded with short gentle spin (max. 400
RPM).
It is suitable for washing fabrics from flax, silk, wool or viscose,
marked accordingly for manual wash.
Jogging
Quick program for washing less stained athletic attires made of
cotton or synthetic fabrics.
Mix
Special program for washing normally stained colored laundry
made from various resistant fabrics at 30°C.
- Selection of additional function
(, , , , , , , , , )
The display always indicates only the menus with functions which
are available for a particular program. Certain functions may not
be selected at the same time (see Program /Additional Functions
Chart). Our suggestion is to select first the additional functions
with ‘Short program (D) and Easy ironing knobs (E). In this case,
only the available additional functions, compatible with the two
selected will be displayed in menus.
Short program (selection by separate knob)
• Program saves energy.
• Convenient for washing less stained laundry, or smaller
quantities of laundry.
• Washing and rinsing time is reduced.
• Reduced water consumption (with certain models).
Easy ironing (selection by separate knob)
Gentle tumbling and final spin prevent excessive creasing of
laundry. Follow the determined maximum load for particular
programs. Suggested reduced load (cotton 3 kg, synthetics 2 kg).
- Selection of additional functions using the MENU knob (B)
By pressing the MENU knob (B) additional functions available
for changing or adding to the pre-selected washing program
11

141576
are displayed in sequence. If you do not wish to activate or
change certain displayed function, press knob B (MENU) to
move to the next available function.Functions with the choice
of multiple available settings, display the default one in bold
(spin RPM, extra rinse, more water, sound signal). Using the
SELECTION knob (C) you may change settings. Activation of a
particular function is confirmed by the relevant symbol appearing
on the display. Function is deactivated by another pressing the
SELECTION knob (C).
Spin speed / Rinse hold
Best recommended spin RPM for the selected program appear on
the display. Using the button (C) in some models you can increase
the selected RPM (1300-1800) or reduce in steps till “0”, when all
spins are off. Last selection is “pump stop” meaning that laundry
will remain soaked in the last rinse water.
RINSE HOLD function is selected if you want the laundry not to be
excessively creased in case you are unable to remove it from the
drum immediately after the end of washing cycle. This is specially
handy for washing of synthetics and delicate laundry .
However, it is not recommended for wool or manual wash .
Extra rinse/ Clean water sensor
This function is for persons, especially sensitive to detergents.
Using the SELECTION knob (C) you may select one or two extra
rinses, or activate the Clean water sensor (S) - certain models
only. By activating extra rinse the display indicates adequately
increased quantity of water. If the clean water sensor is activated,
the display indicates the symbol “S” instead of water quantity. In
such cases the machine will select appropriate number of rinses
in relation to how clean is rinsing water, detected (measured) by
the sensor.
Higher water level (Water plus)
For washing heavily stained laundry.
Using the SELECTION knob (C) you may increase quantity of
water for rinsing one or two times more; for certain programs
this function is available also for washing. Appropriately larger
quantity of water is indicated by the display.
Cold wash
For washing less soiled or colour-sensitive clothes.
Upon switching this function ON, the heating function of this
cycle is switched OFF, therefore the whole program is adequately
shortened.
12

141576
Pre-wash
Used for washing heavily stained laundry, especially with
superficial stains. In default setting the pre-wash function is off. It
is activated by pressing the SELECTION knob (C) on programs
for cotton, synthetics, delicate and mixed laundry.
Soaking
This program is intended for removal of stubborn stains. In
default setting the soaking function is off. It is engaged by
pressing the SELECTION knob (C). Soaking time may be set
from 1 h to maximum 6 hours, in 30 minute steps. At the end of
the preset time the machine automatically starts the selected
washing program.
Delayed start
The function enables delay of starting the washing procedure for
up to 20 hours, in 30 minute intervals for the first two hour delay,
and in hourly intervals for the rest.
Delay is set by pressing or keeping pressed the SELECTION
knob (C) for the required time of delay.
In case you wish to change or suspend the delayed start after
starting the machine with the START knob (F), you may do so by
pressing the MENU knob (B). The delayed start appears; using
the SELECTION button (C) reset the delay period.
Setting the end of program
(certain models only)
Caution: prior this setting check whether the current time of day
is set correctly (see section Special functions). Set the time you
want the program to end the washing procedure.
The machine will automatically calculate the starting time,
depending on the selected program. End of washing may be
delayed for maximum 20 hours, in 30 minute intervals for the first
two hour delay, and in hourly intervals for the rest.
Function is set by pressing or keeping pressed the SELECTION
knob (C) until the required time to end the washing appears on
display.
Caution: If Clean water sensor is engaged, the program may
last longer for extra rinsing time.
In case you wish to change or suspend the end of washing time
after starting the machine with the START knob (F), you may
do so by pressing the MENU knob. The end of washing time
appears; using the
13

141576
SELECTION button (C) reset the selected time.
Sound signal
Sound signal beeps when a knob is pressed (function selection),
and it also signals the end of washing program and reporting
failures.
In default setting the sound signal is on. You may select to switch
the sound signal off, or increase volume.
Legend: sound signal off
normal sound signal setting
increased volume setting
If you switch the sound signal off the display indicates relevant
symbol .
Child protection
Operation of the washer may be protected against accidental
changes of programs or functions. The function is activated by
pressing the START/PAUSE button (F).
Temporary disengagement of the function (during the operation):
- Keep the MENU knob (B) pressed for 4 seconds, relevant
symbol flashes on the display.
- Stop the program by pressing the START/PAUSE knob (F).
- Change settings.
- Press the START/PAUSE button (F) and reactivate the child
lock.
In case you fail press any knob within 15 seconds, the protection
is automatically reactivated.
Permanent disengagement of the function:
a.) During the operation:
- Keep the MENU knob (B) pressed for 4 seconds.
- Stop the program by pressing the START/PAUSE knob (F).
- Using the MENU knob (B) move to child lock option.
- Press the SELECTION knob (C) to disengage the function.
b.) After the program is completed:
- Keep the MENU knob (B) pressed for 4 seconds.
If you switch the machine off after the end of program and fail
to disengage the child lock, it remains active during subsequent
start of the machine. To select new program, you must first
temporarily or permanently disengage the child lock function. The
function remains active even during power failure.
- Selection of partial programs (, , , )
These are independent programs and may be used when you do
not need the entire washing program. In case you would like to
use more additional programs in a sequence, you must turn off
the appliance prior any new program selection (turn the program
selector to “0” for at least one second).
14

141576
Rinse
Independent program for rinsing delicate laundry, without
intermediate spinning and with short final spin. You may use it
for rinsing manually washed delicate laundry.
You may engage the reduced spin RPM function.
Softening
This program is intended for softening, bleaching or impregnating
of washed laundry. It is completed with aggressive spinning at
high RPM.
You may engage the reduced spin RPM function.
Pumping the water out
Use it when the washing program was interrupted or if pump stop
function was engaged, and you only wish to pump the water
out of the drum, without spinning.
Spinning
Intensive spin for non-delicate laundry at maximum speed.
Spin revolutions can be altered.
- Adding washing and softening agents
(see tips for washing and energy saving)
• pre-wash compartment
• main wash compartment
• softener compartment
If you do not apply the program which includes the pre-wash
feature, you may add washing detergent directly into the drum,
using the measuring vessel.
When adding softener, be careful to fill the dispenser
only up to the marked level.
Be sure to close the detergent dispenser when
opening/closing the appliance door.
15

141576
Program is activated by pushing the START/PAUSE button (F).
Sound signal confirms the start, the display indicates first
washing stage and time left to the end of washing. Washing
stages are consecutively displayed in accordance with the
selected program.
If the machine is set with the delayed start, it will start operating
after the delay time expires.
If the pump stop function was set, the program will stop at the
final rinse and the display indicates flashing sign pump stop
(RINSE).
You may conclude the program by pressing the START knob (F)
and the machine will finish the program with the spin, determined
by that particular program.
In case you would like to alter the washing program, turn the
program selector to the position “0”, followed by the selection of
rinse or merely pumping the water out.
Low water temperature, low network voltage, and
smaller loads of laundry may extend the washing time;
the time indicated on the display is constantly adjusted
to account for such conditions.
- End of operation
• Sound signal indicates that you may now open the door of the
machine.
• Extract the laundry from the drum and remove any alien
objects from the door gasket.
• Leave the door ajar to allow the interior to dry.
• Close the water inlet faucet.
• Switch the machine off by turning the program selector (A) to
position “0”.
• Pull the power lead from the socket and cut the power supply
from the mains.
• By the user
Temporary interruption
By pressing the START/PAUSE knob (F) the program may be
suspended at any time.
If the Child lock is engaged you have to deactivate it first. Display
reads PAUSE.
After certain time you may open the door if the water level in the
drum is low enough, otherwise you must fist empty the water
(use additional program Pumping water out or Spin .
By pressing the START knob (F) the program is continued where
Start the operationStart the operation
InterruptionsInterruptions
16

141576
it had been interrupted.
Permanent suspension - change of program
By turning the program selector to the position “0” the program
is permanently suspended. Consequently you may select a new
program
(see Program selection).
• Failures
Program is suspended in case a failure occurs. This is
signalled by the relevant reading on the display and a sound
signal (see cf. Troubleshooting).
• Power failure
At electric cutout the program is interrupted, however, after the
power supply has been re-established, the program operation
automatically proceeds.
If a power failure occurs when the drum is still full of
water, be careful not to open the door before you pump
the water out.
After certain time you may open the door if the water level in the
drum is low enough, otherwise you must fist empty the water
(use additional program Pumping water out or Spin .
MA (models with the door opening by pressing the G knob
feature the function which enables you to open the door of
the appliance during power failure using special lever, located
adjacent to the filter.
• Setting the time of day
- Press MENU (B) and QUICK knobs (D), and turn the program
selector (A) to the first clockwise program. Display reads
CLOCK and =00:00 (hh:mm) in the right corner.
- Hours start flashing; push the SELECTION knob (C) to set the
time of day.
- Confirm setting by pushing the MENU knob (B).
- Now minutes start flashing; they are set the same way as
hours.
- Confirm setting by pushing the MENU knob (B).
- Return the program selector back to “0” position. Set time is
automatically saved.
• Setting the Clean water sensor
In order for the Clean water sensor to start working
properly, it must be first calibrated with water that the washing
machine is connected to. This is performed in the following
Special functions
(certain models only)
Special functions
(certain models only)
17

141576
manner:
- Press MENU (B) and Easy ironing knobs (E), and turn the
program selector to the first clockwise program. Display
reads SENSOR CALIBRATION.
- Start calibration by pushing the START knob (F). The
machine performs calibration procedure automatically.
During the process the reading SENSOR CALIBRATION
is flashing. When the procedure is completed, the display
reads END.
- Return the program selector (A) back to “0” position.
If you change the inlet water source during the use of your
washing machine, or in case you think that water quality has
changed, you may repeat the calibration procedure at any
time. The machine will save the value of the last calibration.
18

141576
• Before washing sort out the laundry according to the type, degree of dirtiness and color
resistance.
• Prior selecting the washing program consult the sewn tab with information on a particular piece
of laundry (see Maintenance chart on the last page).
• Wash separately the new colored textile products for the first time.
• Wash heavily soiled laundry in small quantities and add more detergent.
• Treat stubborn stains with special stain remover, it will save energy.
• For lightly stained laundry select washing program without pre-wash, use short program and
select lower washing temperature. This way you may save up to 50% of energy.
• Avoid washing too little quantities of laundry because of energy saving and for better
performances of the appliance.
• The largest allowed quantity of dry laundry is indicated in the Program chart on the last page.
• Before washing empty the pockets, close zip fasteners, and remove any metal fasteners or
badges that might clog the drain or damage the laundry or drum interior.
• Loosen the stacked laundry prior inserting it into the drum.
• Use only detergents for machine wash.
• Add powder or liquid detergents according to the manufacturer’s instructions.
• If water hardness level exceeds 14°dH degrees, the use of water conditioner is required. Any
damage to the heater due to failure to use a water conditioning agent shall not be covered by
this warranty.
• Chlorine-based whitening agents are not recommended, as it can damage the heater.
• If you do not apply the program which includes the pre-wash
feature, you may add washing detergent directly into the drum.
• If you use thick liquid softener it is recommended to dilute
it with water, to prevent clogging of dispenser compartment
ducts.
• Washing machine is equipped with the dispenser partition
gate, so you may pour liquid detergent also into the central
compartment. If you use powder detergent the gate is lifted up,
and in case of liquid detergent it is slid down.
• Liquid detergents are intended for main wash only, without
pre-wash.
• In models with the delayed start feature, add liquid detergent
directly into the drum, in the attached vessel.
19
Hardness scale Degree of hardness
°dH(°N) m mol/l °fH(°F) p.p.m.
1 - Soft < 8,4 < 1,5 < 15 < 150
2 - Medium 8,4 - 14 1,5 - 2,5 15 - 25 150 - 250
3 - Hard > 14 > 2,5 > 25 > 250
In case of hard water add detergent according to the Chart for
degree 1 and add appropriate quantity of water softener (see
manufacturer’s instructions).
Tips for washing and energy saving

141576
• Insert particularly delicate linen (stockings, delicate female
underwear, etc.) into the special bag.
• High spin RPM leave less moisture in laundry which dries out
much quicker in the tumble dryer, thereby saving energy.
Do not put clods of detergent into the soap dispenser
as the tube in the washing machine may clog.
Disconnect the washing machine from the mains
before cleaning!
• The casing should be cleaned with soft cloth and mild
detergent.
• The interior of the drum and the door gasket is cleaned by
washing at 60°C without laundry and adding half quantity of
detergent.
• If necessary, clean the detergent dispenser. Pull it out from its
casing completely by pressing the flap (see Fig.).
• If necessary, clean the cover of the bung under the running
water.
20
Cleaning and maintenance
