Gorlitz GO 68HD Series Installation and operation manual

OPERATING &
MAINTENANCE
INSTRUCTIONS
GO 68HD • GO 68 • GO 62HD SERIES
GO 50 • GO 380 / 250 • GO 15 SERIES
SEWER & DRAIN CLEANING MACHINES &
POWER CABLE FEEDERS
“The Drain Cleaning Machine & Equipment Specialist”
G
O
R
L
I
T
Z
I
N
C
.
“The Drain Cleaning Machine & Equipment Specialist”
“The Drain Cleaning Machine & Equipment Specialist”
“The Drain Cleaning Machine & Equipment Specialist”
“The Drain Cleaning Machine & Equipment Specialist”
G
O
R
L
I
T
Z
I
N
C
.
“The Drain Cleaning Machine & Equipment Specialist”
“The Drain Cleaning Machine & Equipment Specialist”
“The Drain Cleaning Machine & Equipment Specialist”
HOW TO ORDER
PRICES
SALES TAX
FREIGHT POLICY
MERCHANDISE CLAIMS AND RETURN POLICY
GORLITZ LIMITED WARRANTY
MANUFACTURERS WARRANTIES AND LITERATURE
In order to avoid mistakes or delays of your shipment, please refer to our part number and description.
Since prices are subject to change we cannot guarantee them for more than 30 days. The prices listed are valid for the period
indicated on the cover of the price list only. Prices are Net F.O.B. Factory, Santa Fe Springs, California.
Gorlitz Sewer & Drain, Inc. is required to charge applicable State Sales Tax on every item sold unless a California State Sales
Tax Exemption Certificate has been provided.
All merchandise shipped per parcel service are prepaid and added to the invoice. All shipping fees per trucking lines are the
responsibility of the customer. If any freight damages or losses are experienced, Gorlitz Sewer & Drain, Inc. requests that the
freight company carrying the merchandise be contacted by the customer for freight claims.
All discrepancies in goods received must be claimed within five days after receipt of goods. Any item to be returned must be
referenced by invoice number, date of sale and written consent of seller.
All products manufactured at Gorlitz Sewer&Drain, Inc. are warranted to be free from defects in material and workmanship
under normal use and maintenance foraperiod of one (1) year from date of purchase to original buyer. If any parts break or
fail, we ask you to notify your nearest dealer or Gorlitz Sewer&Drain, Inc. and supply us with proof of purchase and nature of
failure. Gorlitz will repair or replace (at our option) any parts found to be defective. The replacement part assumes the
unused portion of the warranty. Transportation of the product to any service station is the responsibility of the user unless
stated otherwise in this warranty.
This warranty does not apply to expendable items (Cables, Knives, Nozzles, Hoses, Fittings, etc.) and damage due to
negligence, unauthorized repair or alteration, chemicals, misuse or accidents. Adjustments of any kind can not be made on
shaved, kinked or broken hoses and kinked or broken cables because it shows evidence of abuse or to much pressure.
This warranty is exclusive and in lieu of all other expressed warranties and Gorlitz Sewer&Drain, Inc. does not authorize any
part to assume for it any other obligation or liability. In no event shall Gorlitz Sewer&Drain, Inc. be liable for special or
consequential damages arising from the use of this product or for any delay in the performance of this warranty due to causes
beyond our control.
In placing this order Buyer expressly understands, acknowledges and agrees that: (1) Buyer has received and read the
Operating and Maintenance Instructions that accompanied this equipment order, including Gorlitz’s Limited Warranty and all
of the other Terms and Conditions of doing business with Gorlitz Sewer & Drain, Inc. (“Gorlitz”) as stated therein; (2) Buyer will
operate and maintain the equipment in accordance with the specifications stated in the Instructions; (3) Buyer indemnifies
and holds Gorlitz harmless for Buyer’s failure to use the equipment in accordance with the specifications stated in the
Instructions; (4) the equipment is being sold to Buyer on an “as is” and “where is” basis and that except as specifically set forth
in this agreement, Gorlitz makes no other representations or warranties, whether express or implied; and (5) all disputes
arising under this agreement shall be submitted to courts of competent jurisdiction in the State of California and the prevailing
party in any action or proceeding to enforce any provision of this agreement will be awarded reasonable attorney fees and
costs incurred in that action or proceeding or in efforts to negotiate the matter.
Most products used on our equipment are warranted to the final consumer by their manufacturers. Copies of such warranties
are supplied with our products or are available from the manufacturers. Asaservice, Gorlitz Sewer & Drain, Inc. will obtain
copies of consumer warranties from the warrantor and will furnish them free of charge to consumers upon request. Gorlitz
Sewer & Drain, Inc. assumes no responsibility for the content of such warranties or sales literature by performing this service.

Thank you very much for choosing an Gorlitz product!
For future reference, please complete the owner’s record below:
Serial Number/Lot Date Code: ____________________________________
Purchase Date: ________________________________________________
Save the receipt, warranty, and this manual. It is important that you read the
entire manual to become familiar with this product before you begin using it.
This drain cleaner is designed for certain applications only. Gorlitz Sewer &
Drain Inc. is not responsible for issues arising from modication or improper
use of this product such as an application for which it was not designed. We
strongly recommend that this product not be modied and/or used for any
application other than that for which it was designed.
For technical questions, please contact via emailing to [email protected].
DO NOT ATTEMPT TO OPERATE ANY DRAIN CLEANING MACHINE UNTIL YOU
HAVE READ AND THOROUGHLY UNDERSTAND ALL INSTRUCTIONS, RULES, ETC.
CONTAINED IN THIS MANUAL. FAILURE TO COMPLY CAN RESULT IN ACCIDENTS
INVOLVING FIRE, ELECTRIC SHOCK, OR PERSONAL INJURY. MAINTAIN OWNERS
MANUAL AND REVIEW FREQUENTLY FOR CONTINUING SAFE OPERATION.
WARNING
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE
ELECTRIC SHOCK RESULTING IN DEATH CAN OCCUR IF YOU PLUG THIS MACHINE
INTO AN IMPROPERLY WIRED OUTLET. IF THE GROUND WIRE IS ELECTRIFIED,
YOU CAN BE ELECTROCUTED BY JUST TOUCHING THE MACHINE, EVEN WHEN
THE POWER SWITCH IS OFF. A GROUND FAULT CIRCUIT INTERRUPTER WILL NOT
PROTECT YOU IN THIS SITUATION. USE A UL LISTED TESTER TO DETERMINE IF
THE OUTLET IS SAFE.
DO NOT OPERATE POWER TOOLS IN EXPLOSIVE ATMOSPHERES, SUCH AS IN THE
PRESENCE OF FLAMMABLE LIQUIDS, GASES, OR DUST. POWER TOOLS CREATE
SPARKS WHICH MAY IGNITE THE DUST OR FUMES.
ONLY WEAR LEATHER GLOVES. NEVER USE ANY OTHER TYPE OF GLOVE SUCH AS
CLOTH, RUBBER, OR COATED GLOVES. NEVER GRASP A ROTATING CABLE WITH A
RAG. THESE ITEMS COULD BECOME WRAPPED AROUND THE CABLE AND CAUSE
SERIOUS INJURY.
ALWAYS WEAR SAFETY GLASSES AND RUBBER SOLED, NON-SLIP SHOES. USE OF
THIS SAFETY EQUIPMENT MAY PREVENT SERIOUS INJURY.
DO NOT OVERSTRESS CABLES. OVERSTRESSING CABLES MAY CAUSE TWISTING,
KINKING, OR BREAKING OF THE CABLE AND MAY RESULT IN SERIOUS INJURY.
This product can expose you to chemicals including lead, which is known to the
State of California to cause cancer and birth defects or other reproductive harm. For
more information go to www.P65Warnings.ca.gov.
1 Gorlitz Operating & Maintenance Manual

GENERAL SAFETY INSTRUCTIONS
KNOW YOUR EQUIPMENT: READ OWNERS MANUAL CAREFULLY, LEARN ITS
APPLICATIONS AND LIMITATIONS.
GUARD AGAINST ELECTRIC SHOCK: THE DRILL MOTOR COMES WITH A TWO (2)
PRONG, THIRTEEN (13) FOOT LONG CORD. IT IS INTENDED TO BE PLUGGED INTO
AN OUTLET AWAY FROM THE WET ENVIRONMENT OF THE JOB SITE. THE MOTOR IS
DOUBLE INSULATED FOR INCREASED OPERATOR PROTECTION.
EXTENSION CORD: DO NOT USE AN EXTENSION CORD OF ANY TYPE DUE TO THE
POSSIBILITY OF THE CORD CONNECTIONS BEING EXPOSED TO WATER. NEVER YANK
THE DRILL MOTOR CORD TO DISCONNECT FROM RECEPTACLE. KEEP CORD AWAY
FROM SHARP EDGES, MOVING OBJECTS AND HIGH HEAT AREAS.
AVOID ACCIDENTAL START: BE SURE THE TRIGGER SWITCH IS NOT DEPRESSED
BEFORE PLUGGING INTO ANY ELECTRICAL SOURCE.
AVOID DANGEROUS ENVIRONMENT: DO NOT EXPOSE OR OPERATE MACHINE IN RAIN
OR USE IN DAMP OR WET LOCATIONS. DO NOT OPERATE IN PRESENCE OF FLAMMABLE
LIQUIDS, GAS OR IN ANY TYPE OF EXPLOSIVE ATMOSPHERE.
WEAR PROPER APPAREL: FOR ADDED PROTECTION WHEN OPERATING MACHINE,
USE RUBBER LATEX GLOVES WITH LEATHER GLOVES AND RUBBER BOOTS WITH NON
SKID SOLES. ALWAYS USE EYE PROTECTION AS WELL AS A DUST MASK.
KEEP UNAUTHORIZED PERSONS AWAY: ALL SPECTATORS SHOULD BE KEPT AT A SAFE
DISTANCE, ESPECIALLY CHILDREN.
KEEP WORK AREA CLEAN AND WELL LIT: KEEP AWAY ALL LOOSE OBJECTS LIKE
TOOLS, WRENCHES, SHIRT SLEEVES, ETC. FROM ROTATING CABLE AND DRUM.
ADEQUATE LIGHTING IS ESSENTIAL IN AVOIDING ACCIDENTS.
DISCONNECT MACHINE: UNPLUG MACHINE WHEN NOT IN USE, BEFORE SERVICING
AND WHEN CHANGING CABLES.
STAY ALERT: WATCH WHAT YOU ARE DOING AND USE COMMON SENSE. DO NOT
OPERATE MACHINE WHILE UNDER THE INFLUENCE OF DRUGS, ALCOHOL OR
MEDICATION.
MAINTAIN DRAIN CLEANER WITH PROPER CARE: KEEP ALL DRAIN CLEANING
EQUIPMENT CLEAN FOR BEST AND SAFEST PERFORMANCE. FOLLOW INSTRUCTIONS
FOR LUBRICATION, CHANGING ACCESSORIES AND MAINTENANCE. CHECK FOR
MISALIGNMENTS OF ANY MOVING PARTS. IF DAMAGED, HAVE THE UNIT REPAIRED
PRIOR TO USE. ACCIDENTS ARE CAUSED BY IMPROPERLY MAINTAINED TOOLS.
DO NOT OVERLOAD THE DRAIN CLEANER: THE GO 31 DRAIN CLEANER WILL ONLY DO
THE JOB IT WAS DESIGNED FOR.
MAINTAIN LABELS: ALL LABELS HAVE IMPORTANT INFORMATION. IF WORN,
UNREADABLE OR MISSING, CONTACT GORLITZ SEWER & DRAIN FOR REPLACEMENTS.
THIS IS THE SAFETY ALERT SYMBOL. IT IS USED TO ALERT YOU TO POTENTIAL
PERSONAL INJURY HAZARDS. OBEY ALL SAFETY MESSAGES THAT FOLLOW
THIS SYMBOL TO AVOID POSSIBLE INJURY OR DEATH.
READ ALL SAFETY WARNINGS AND ALL INSTRUCTIONS. FAILURE TO FOLLOW ALL INSTRUCTIONS
LISTED BELOW MAY RESULT IN ELECTRIC SHOCK, FIRE, AND/OR SERIOUS INJURY.
Gorlitz Operating & Maintenance Manual 2

UNCRATING AND CHECKING CONTENTS
GORLITZ SEWER AND DRAIN CLEANING MACHINES ARE SHIPPED ASSEMBLED WITH CABLES INSTALLED
IN REELS OR DRUMS. IN ORDER TO FACILITATE PACKING, CERTAIN ITEMS LIKE CHUCKS, BLADES,
FEEDER, ETC., ARE NOT ATTACHED TO EQUIPMENT AND MUST BE ASSEMBLED WHEN RECEIVED BY
PURCHASER. DUE TO SHIPMENT AND HANDLING BY VARIOUS FREIGHT COMPANIES, INSPECT ALL ITEMS
AND CHECK FOR DAMAGED PARTS. INSPECT CABLES FOR KINKS, CHECK FOR ALIGNMENT OF MOVING
PARTS, RETIGHTEN SET SCREWS ON DRIVE ARM, DRIVE PLATE, PULLEYS, BELT TENSIONER, ETC. AND
ANY OTHER CONDITIONS THAT MAY AFFECT ITS OPERATION.
LUBRICATION
ALL GORLITZ SEWER AND DRAIN CLEANING MACHINES SHOULD BE GIVEN THE BEST OF CARE. IF KEPT
CLEAN AND PROPERLY LUBRICATED, IT WILL PROVIDE MANY YEARS OF TROUBLE-FREE SERVICE. THE
FOLLOWING INSTRUCTIONS SHOULD BE CAREFULLY OBSERVED AT ALL TIMES:
• SHAFT PILLOW BLOCKS, DRIVE ARM PILLOW BLOCKS AND BELT TENSIONER BEARING HAVE BEEN
PACKED AT THE FACTORY WITH PROPER LUBRICANT AND REQUIRE NO ADDITIONAL LUBRICATION.
• OIL OR GREASE ALL POINTS WHERE FRICTION EXISTS BETWEEN TWO OR MORE MOVING PARTS.
• SPECIAL ATTENTION SHOULD BE GIVEN WHERE A SLIP FIT IS NECESSARY, ESPECIALLY BETWEEN DRUM
OR REEL AND DRIVE SHAFT. REMOVE DRUM OR REEL PERIODICALLY IN ORDER TO APPLY GREASE TO THE
INSIDE OF DRUM OR REEL CENTER TUBE AND DRIVE SHAFT.
• GREASE ALL REELS, WHEELS AND SHAFT SLEEVES EQUIPPED WITH ZERK FITTINGS.
• TO LUBRICATE MOTOR, CONSULT SEPARATE MOTOR MANUAL.
• TO MAINTAIN GEAR BOX, CHANGE OIL EVERY 100 HOURS OF OPERATION. USE A SYNTHETIC
INDUSTRIAL GEAR LUBE ISO GRADE 460 OR EQUIVELANT.
• TO SERVICE HANDYGUN SEE SEPARATE CARE AND OPERATING INSTRUCTIONS
WHEN UNLOADING MACHINE FROM SHIPPING CARTON, DO NOT ALLOW MACHINE TO
DROP, FALL OR SLAM HARD ON ITS BACK FRAME. THE SUDDEN IMPACT MAY BEND
THE DRIVE SHAFT AND/OR DAMAGE THE BEARING OR PILLOW BLOCKS.
BROKEN THRUST BEARINGS AND FRACTURED RACES ARE A DIRECT RESULT OF
THIS ABUSE, AND ARE NOT COVERED UNDER THE MANUFACTURER’S OR GORLITZ’S
WARRANTY.
IF MACHINE IS NOT IN USE FOR SOME TIME, SPRAY CABLE WITH WD40 OR APPLY ANY
GRADE MOTOR OIL TO PREVENT CABLE FROM OXIDATION.
3 Gorlitz Operating & Maintenance Manual

GO 15
LITTLE ROOTER
GO 31
HANDYGUN*
GO 250
DRAIN CLEANING
MACHINE
GO 380
DRAIN CLEANING
MACHINE
GO 380A
DRAIN CLEANING
MACHINE
GO 380/250
DRAIN CLEANING
MACHINE
GO 380A/250
DRAIN CLEANING
MACHINE
GO 50 SERIES
DRAIN CLEANING
MACHINE
GO 50A SERIES
DRAIN CLEANING
MACHINE
GO 50B SERIES
DRAIN CLEANING
MACHINE
GO 62HD SERIES
COMBINATION SEWER &
DRAIN CLEANING MACHINE
GO 62A HD SERIES
SEWER CLEANING
MACHINE
GO 68 SERIES
SEWER CLEANING
MACHINE
GO 68HD SERIES
SEWER CLEANING
MACHINE
1/4”X 35’ 1/6 HP
CAPACITOR
1.85 AMP
1/4 HP
CAPACITOR
1/4 HP
CAPACITOR
1/4 HP
CAPACITOR
1/4 HP
CAPACITOR
1/4 HP
CAPACITOR
1/3 HP
CAPACITOR
1/3 HP
CAPACITOR
1/3 HP
CAPACITOR
1/3 HP
CAPACITOR
1/3 HP
CAPACITOR
1/2 HP
GEARED
3/4 HP
CAPACITOR
GEARED
265
0-500
235
235
235
235
235
190
190
190
165
165
160
175
1 1/4” TO 2”
1 1/4” TO 2”
1 1/4” TO 2”
1 1/2” TO 3”
1 1/2” TO 3”
1 1/4” TO 3”
1 1/4” TO 3”
2” TO 3”
1 1/2” TO 3”
1 1/2” TO 3”
1 1/2” TO 4”
3” TO 4”
3” TO 8”
3” TO 10”
TUBS
SINKS
SHOWERS
TUBS
SINKS
SHOWERS
TUBS
SINKS
SHOWERS
ROOFS
VENTS
SMALL DRAINS
ROOFS
VENTS
SMALL DRAINS
SINKS, VENTS
SHOWERS, TUBS
SMALL DRAINS
SINKS, VENTS
SHOWERS, TUBS
SMALL DRAINS
VENTS
SMALL DRAINS
LIGHT ROOTS
VENTS
SMALL DRAINS
VENTS
SMALL DRAINS
VENTS
GREASE
DRAINS
DRAINS
GREASE
MEDIUM ROOTS
DRAINS, ROOTS
SAND, GREASE
DIAPERS
DRAINS, ROOTS
SAND, GREASE
DIAPERS
5/16”X 25’
1/4”X 50’
3/8”X 65’
3/8”X 90’
3/8”X 65’
1/4”X 50’
3/8”X 90’
1/4”X 50’
1/2”X 80’
3/8”X 90’
13/32”X 75’
3/8”X 90’
1/2”X 80’
5/8”X 100’
5/8”X 100’
11/16”X 150’
11/16”X 150’
MODEL CABLE SIZE MOTOR CABLE RPM PIPE DIAMETER APPLICATION
MODEL COMPARISON CHART
THE MODEL COMPARISON CHART PICTURED ABOVE SHOULD BE ONLY USED AS A
GUIDELINE. ITS SUGGESTED APPLICATION MAY VARY DEPENDING ON SITE OF LOCATION,
AGE, BENDS, MATERIAL AND LENGTH OF DRAINAGE PIPE AND OPERATOR.
* SEE SEPARATE MANUFACTURER’S OPERATING INSTRUCTIONS FOR MODEL GO 31
HANDYGUN.
Gorlitz Operating & Maintenance Manual 4

GENERAL OPERATING INSTRUCTIONS
1. POSITION MACHINE AS CLOSE AS POSSIBLE TO CLEAN OUT. MAXIMUM 3 FEET DISTANCE BETWEEN
MACHINE AND OPENING WORKED ON.
2. ATTACH YOUR CHOICE OF CUTTING TOOL.
3. BEFORE PLUGGING EXTENSION CORD INTO RECEPTACLE MAKE SURE ON/OFF SWITCH ON MACHINE
IS IN OFF POSITION.
IF YOU ARE OPERATING ANY MACHINE WITH AN ELECTRIC FOOT SWITCH:
• PLUG FOOT SWITCH INTO MACHINE OUTLET.
• PUSH FEMALE END OF EXTENSION CORD INTO FOOT SWITCH.
• PLUG MALE END OF EXTENSION CORD INTO ELECTRICAL SOURCE.
• MOVE ON/OFF SWITCH ON MACHINE TO “ON” POSITION.
• STEP ON FOOT SWITCH AND MACHINE WILL START RUNNING.
IF YOU ARE OPERATING ANY MACHINE WITH AN AIR FOOT SWITCH:
• STEP ON AIR BULB AND MACHINE WILL START RUNNING.
4. MOVE SWITCH TO “ON” POSITION. IN NORMAL OPERATING MODE, DRUM OR REEL MUST TURN
COUNTER CLOCKWISE WHEN THE OPERATOR FACING THE MACHINE.
• IF DRUM OR REEL TURNS CLOCKWISE, STOP MACHINE. ALL MODELS ARE EQUIPPED WITH A
FORWARD/REVERSE SWITCH LOCATED AT THE ELECTRIC CONTROL BOX. FOR MODELS GO 380/250
SERIES AND GO 15 THE FORWARD/REVERSE SWITCH IS LOCATED AT THE COVER HOUSING. ONLY
WHEN THE MACHINE COMES TO A COMPLETE STOP SWITCH THE FORWARD/REVERSE TOGGLE
SWITCH INTO THE OPPOSITE DIRECTION.
5. FEED CABLE INTO SEWER LINE SLOWLY, FEELING YOUR WAY AS YOU GO. PLACE BOTH HANDS
EQUALLY DISTANT BETWEEN MACHINE AND CLEAN-OUT. NEVER LET YOUR HANDS GO, AS YOUR
HANDS PROVIDE A GUIDE FOR THE CABLE AND PREVENT THE CABLE FROM SWINGING, BUCKLING
OR KINKING.
6. MOST IMPORTANT, KEEP THE CABLE ROTATING AT ALL TIMES.
7. WHEN YOUR CUTTING TOOL MEETS BLOCKAGE, IT WILL SLOW DOWN OR EVEN MOMENTARILY STOP
ROTATION OF CABLE. AS SOON AS YOU FEEL A RPM REDUCTION, PULL CABLE BACK IN ORDER TO
PREVENT THE CUTTING TOOL FROM GETTING HUNG UP.
8. AS SOON AS MOTOR IS AT FULL RPM AGAIN, FEEL YOUR CABLE AGAINST STOPPAGE. PUSH AND PULL
CABLE IN QUICK SUCCESSION AGAINST AND FROM OBSTRUCTION UNTIL YOU BREAK THROUGH
BLOCKAGE.
9. ONCE YOU’VE CUT THROUGH BLOCKAGE, PULL CABLE BACK FOR SEVERAL FEET. NOW PASS CABLE
THROUGH SAME STOPPAGE LOCATION AGAIN AND ADVANCE CABLE TO NEXT LARGER DRAIN LINE
CONNECTION OR TO MAIN SEWER LINE FOR A THOROUGH CLEANING JOB.
10. AFTER THE CUTTING AND CLEANING OPERATION IS COMPLETED, RETURN CABLE INTO DRUM OR REEL
WITH MACHINE RUNNING IN ORDER FOR YOUR DRIVE ARM TO DISTRIBUTE CABLE INTO DRUM OR REEL
EVENLY.
5 Gorlitz Operating & Maintenance Manual
ALWAYS KEEP AIR HOSE CLEAR OF ANY MOVING PARTS. REPLACE ANY LEAKING OR
DAMAGED COMPONENTS.
AVOID RUNNING OF MACHINE AT LOW RPM’S FOR EXTENDED PERIOD OF TIME AS THE
UNIT MAY BECOME OVERHEATED.
IF YOUR CABLE GETS HUNG UP IN A MASS OF ROOTS, ETC. SWITCH OFF MACHINE IN ORDER
TO ALLOW CABLE AND/OR REEL OR DRUM TO BACK SPIN. LET MACHINE COME TO A
COMPLETE STOP.
IF YOU ARE UNABLE TO RETRIEVE CABLE, SWITCH MACHINE INTO REVERSE AND RUN
MOMENTARILY TO ALLOW CABLE TO UNWIND FROM STOPPAGE. ONCE CABLE IS FREE, PULL
CABLE BACK FOR SEVERAL FEET, PLACE REVERSING SWITCH IN FORWARD POSITION AND
THEN START MACHINE AGAIN.
WHEN OPERATING MACHINE WITH A POWER CABLE FEEDER AND PULLER, DO NOT ALLOW
ANY CABLE ENDS OR CABLE CONNECTORS TO PASS THROUGH FEEDER AS IT MAY DAMAGE
OR BREAK THE FEEDER BEARINGS.
(EXCEPT HANDYGUN MODEL GO31)

Gorlitz Operating & Maintenance Manual 6
TO CLEAN SEWER LINE 100 FEET OR LONGER
RUN OUT FULL LENGTH OF CABLE
DISCONNECT AT ANCHOR CABLE AND
REMOVE EMPTY REEL
REPLACE WITH FULL REEL
COUPLE CABLES TOGETHER CONTINUE DOWN THE PIPE
STEP
1
STEP
2
STEP
3
STEP
4
STEP
5
TO CLEAN SEWER LINE 100 FEET OR LONGER
CONTINUE DOWN THE PIPECOUPLE CABLES TOGETHER
STEP 5STEP 4
RUN OUT FULL LENGTH OF CABLE
DISCONNECT AT ANCHOR CABLE AND
REMOVE EMPTY REEL
REPLACE WITH FULL REEL
STEP 3STEP 2
R
O
T
A
T
I
O
N
6
PART # DESCRIPTION REQ
151C REAR DRUM SECTION 1
151D BRASS DRUM BUSHING 1
1MRAEVIRDA251
152C THRUST WASHER* 1
1*GNIRGNINIATERD251
153DRUMRUBBER SLEEVE* 1
154COVER HOUSING* 1
1TFAHSEVIRD551
156 PILLOW BLOCK 1/2"* 2
157 PILLOW BLOCK 5/8"* 1
1*YELLUPTFAHS951
1*TLEB061
1*ROTOM161
162 MOTOR CAPACITOR* 1
163 ELEPHANT TRUNK 1
2*PUCREBBUR461
2*EVEELSREBBUR561
166 ELECTRIC PLUG SLEEVE* 1
1*YELLUPROTOM852
262 TOGGLE SWITCH* 1
393RUBBER BUMPER* 2
1*GULPCIRTCELE596
700 FOR/REV SWITCH* 1
1*IFG707
PART # DESCRIPTION REQ
1EMARF051
1YLBMESSAMURD151
151A 1GNIHSUBMURD
151B FRONT DRUMSECTION 1
1BUHRENNIB283
383DRUM ASSY (3/8" X 90' MAX) 1
383ADRUM (3/8" X 90' MAX) 1
1BUHRENNIB383
1MRAEVIRD483
384ADRIVE ARM COLLAR* 1
1TFAHSEVIRD583
386 PILLOW BLOCK 5/8"* 2
1*YELLUPTFAHS783
1*TLEB983
1*GNIHSUB093
1*GNIRGNINIATER193
392 COVER HOUSING* 1
393RUBBER BUMPER* 4
2*GULP493
166 ELECTRIC PLUG SLEEVE* 1
1ETALPEVIRD352
256 PILLOW BLOCK 7/8"* 1
1*YELLUPROTOM852
1*ROTOM162
261A MOTOR CAPACITOR* 1
262 TOGGLE SWITCH* 1
263 ELEPHANT TRUNK (SM 1/4") 1
263A ELEPHANT TRUNK (LG 3/8") 1
1*GULPCIRTCELE596
700 FOR/REV SWITCH* 1
1*IFG70
7
1EMARF083
381DRUMASSY (3/8" X 65' MAX) 1
381A DRUM (3/8" X 65' MAX) 1
1BUHRENNIB183
382DRUMASSY (1/4" X 50' MAX) 1
382A DRUM (1/4" X 50' MAX) 1
GO 380/250
MACHINE PARTS LIST
GO 15
GFI
707
262
695
700
166
163
162
161
154
165
150 164
156
155
159
160
393
258
152A
152C
152D
157
151D
153
151B
151C
152A
152C
152D
151D
153
151B
151C
151 Drum Assembly
253
384
385
256
387
258
389
390
390
261
261A
263
380
391
391
392
394
382B
383B
381B
382B
383B
381B
386
381A
382A
383A
381A
382A
383A
381, 382, 383
Drum Assembly’s
GFI
707
262
695
700
166
393
263A
384A
TO CLEAN SEWER LINE 100 FEET OR LONGER
CONTINUE DOWN THE PIPECOUPLE CABLES TOGETHER
STEP 5STEP 4
RUN OUT FULL LENGTH OF CABLE
DISCONNECT AT ANCHOR CABLE AND
REMOVE EMPTY REEL
REPLACE WITH FULL REEL
STEP 3STEP 2
R
O
T
A
T
I
O
N
6
PART # DESCRIPTION REQ
151C REAR DRUM SECTION 1
151D BRASS DRUM BUSHING 1
1MRAEVIRDA251
152C THRUST WASHER* 1
1*GNIRGNINIATERD251
153DRUMRUBBER SLEEVE* 1
154COVER HOUSING* 1
1TFAHSEVIRD551
156 PILLOW BLOCK 1/2"* 2
157 PILLOW BLOCK 5/8"* 1
1*YELLUPTFAHS951
1*TLEB061
1*ROTOM161
162 MOTOR CAPACITOR* 1
163 ELEPHANT TRUNK 1
2*PUCREBBUR461
2*EVEELSREBBUR561
166 ELECTRIC PLUG SLEEVE* 1
1*YELLUPROTOM852
262 TOGGLE SWITCH* 1
393RUBBER BUMPER* 2
1*GULPCIRTCELE596
700 FOR/REV SWITCH* 1
1*IFG707
PART # DESCRIPTION REQ
1EMARF051
1YLBMESSAMURD151
151A 1GNIHSUBMURD
151B FRONT DRUMSECTION 1
1BUHRENNIB283
383DRUM ASSY (3/8" X 90' MAX) 1
383ADRUM (3/8" X 90' MAX) 1
1BUHRENNIB383
1MRAEVIRD483
384ADRIVE ARM COLLAR* 1
1TFAHSEVIRD583
386 PILLOW BLOCK 5/8"* 2
1*YELLUPTFAHS783
1*TLEB983
1*GNIHSUB093
1*GNIRGNINIATER193
392 COVER HOUSING* 1
393RUBBER BUMPER* 4
2*GULP493
166 ELECTRIC PLUG SLEEVE* 1
1ETALPEVIRD352
256 PILLOW BLOCK 7/8"* 1
1*YELLUPROTOM852
1*ROTOM162
261A MOTOR CAPACITOR* 1
262 TOGGLE SWITCH* 1
263 ELEPHANT TRUNK (SM 1/4") 1
263A ELEPHANT TRUNK (LG 3/8") 1
1*GULPCIRTCELE596
700 FOR/REV SWITCH* 1
1*IFG70
7
1EMARF083
381DRUMASSY (3/8" X 65' MAX) 1
381A DRUM (3/8" X 65' MAX) 1
1BUHRENNIB183
382DRUMASSY (1/4" X 50' MAX) 1
382A DRUM (1/4" X 50' MAX) 1
GO 380/250
MACHINE PARTS LIST
GO 15
GFI
707
262
695
700
166
163
162
161
154
165
150 164
156
155
159
160
393
258
152A
152C
152D
157
151D
153
151B
151C
152A
152C
152D
151D
153
151B
151C
151 Drum Assembly
253
384
385
256
387
258
389
390
390
261
261A
263
380
391
391
392
394
382B
383B
381B
382B
383B
381B
386
381A
382A
383A
381A
382A
383A
381, 382, 383
Drum Assembly’s
GFI
707
262
695
700
166
393
263A
384A
TO CLEAN SEWER LINE 100 FEET OR LONGER
CONTINUE DOWN THE PIPECOUPLE CABLES TOGETHER
STEP 5STEP 4
RUN OUT FULL LENGTH OF CABLE
DISCONNECT AT ANCHOR CABLE AND
REMOVE EMPTY REEL
REPLACE WITH FULL REEL
STEP 3STEP 2
R
O
T
A
T
I
O
N
6
PART # DESCRIPTION REQ
151C REAR DRUM SECTION 1
151D BRASS DRUM BUSHING 1
1MRAEVIRDA251
152C THRUST WASHER* 1
1*GNIRGNINIATERD251
153DRUMRUBBER SLEEVE* 1
154COVER HOUSING* 1
1TFAHSEVIRD551
156 PILLOW BLOCK 1/2"* 2
157 PILLOW BLOCK 5/8"* 1
1*YELLUPTFAHS951
1*TLEB061
1*ROTOM161
162 MOTOR CAPACITOR* 1
163 ELEPHANT TRUNK 1
2*PUCREBBUR461
2*EVEELSREBBUR561
166 ELECTRIC PLUG SLEEVE* 1
1*YELLUPROTOM852
262 TOGGLE SWITCH* 1
393RUBBER BUMPER* 2
1*GULPCIRTCELE596
700 FOR/REV SWITCH* 1
1*IFG707
PART # DESCRIPTION REQ
1EMARF051
1YLBMESSAMURD151
151A 1GNIHSUBMURD
151B FRONT DRUMSECTION 1
1BUHRENNIB283
383DRUM ASSY (3/8" X 90' MAX) 1
383ADRUM (3/8" X 90' MAX) 1
1BUHRENNIB383
1MRAEVIRD483
384ADRIVE ARM COLLAR* 1
1TFAHSEVIRD583
386 PILLOW BLOCK 5/8"* 2
1*YELLUPTFAHS783
1*TLEB983
1*GNIHSUB093
1*GNIRGNINIATER193
392 COVER HOUSING* 1
393RUBBER BUMPER* 4
2*GULP493
166 ELECTRIC PLUG SLEEVE* 1
1ETALPEVIRD352
256 PILLOW BLOCK 7/8"* 1
1*YELLUPROTOM852
1*ROTOM162
261A MOTOR CAPACITOR* 1
262 TOGGLE SWITCH* 1
263 ELEPHANT TRUNK (SM 1/4") 1
263A ELEPHANT TRUNK (LG 3/8") 1
1*GULPCIRTCELE596
700 FOR/REV SWITCH* 1
1*IFG70
7
1EMARF083
381DRUMASSY (3/8" X 65' MAX) 1
381A DRUM (3/8" X 65' MAX) 1
1BUHRENNIB183
382DRUMASSY (1/4" X 50' MAX) 1
382A DRUM (1/4" X 50' MAX) 1
GO 380/250
MACHINE PARTS LIST
GO 15
GFI
707
262
695
700
166
163
162
161
154
165
150 164
156
155
159
160
393
258
152A
152C
152D
157
151D
153
151B
151C
152A
152C
152D
151D
153
151B
151C
151 Drum Assembly
253
384
385
256
387
258
389
390
390
261
261A
263
380
391
391
392
394
382B
383B
381B
382B
383B
381B
386
381A
382A
383A
381A
382A
383A
381, 382, 383
Drum Assembly’s
GFI
707
262
695
700
166
393
263A
384A
TO CLEAN SEWER LINE 100 FEET OR LONGER
CONTINUE DOWN THE PIPECOUPLE CABLES TOGETHER
STEP 5STEP 4
RUN OUT FULL LENGTH OF CABLE
DISCONNECT AT ANCHOR CABLE AND
REMOVE EMPTY REEL
REPLACE WITH FULL REEL
STEP 3STEP 2
R
O
T
A
T
I
O
N
6
PART # DESCRIPTION REQ
151C REAR DRUM SECTION 1
151D BRASS DRUM BUSHING 1
1MRAEVIRDA251
152C THRUST WASHER* 1
1*GNIRGNINIATERD251
153DRUMRUBBER SLEEVE* 1
154COVER HOUSING* 1
1TFAHSEVIRD551
156 PILLOW BLOCK 1/2"* 2
157 PILLOW BLOCK 5/8"* 1
1*YELLUPTFAHS951
1*TLEB061
1*ROTOM161
162 MOTOR CAPACITOR* 1
163 ELEPHANT TRUNK 1
2*PUCREBBUR461
2*EVEELSREBBUR561
166 ELECTRIC PLUG SLEEVE* 1
1*YELLUPROTOM852
262 TOGGLE SWITCH* 1
393RUBBER BUMPER* 2
1*GULPCIRTCELE596
700 FOR/REV SWITCH* 1
1*IFG707
PART # DESCRIPTION REQ
1EMARF051
1YLBMESSAMURD151
151A 1GNIHSUBMURD
151B FRONT DRUMSECTION 1
1BUHRENNIB283
383DRUM ASSY (3/8" X 90' MAX) 1
383ADRUM (3/8" X 90' MAX) 1
1BUHRENNIB383
1MRAEVIRD483
384ADRIVE ARM COLLAR* 1
1TFAHSEVIRD583
386 PILLOW BLOCK 5/8"* 2
1*YELLUPTFAHS783
1*TLEB983
1*GNIHSUB093
1*GNIRGNINIATER193
392 COVER HOUSING* 1
393RUBBER BUMPER* 4
2*GULP493
166 ELECTRIC PLUG SLEEVE* 1
1ETALPEVIRD352
256 PILLOW BLOCK 7/8"* 1
1*YELLUPROTOM852
1*ROTOM162
261A MOTOR CAPACITOR* 1
262 TOGGLE SWITCH* 1
263 ELEPHANT TRUNK (SM 1/4") 1
263A ELEPHANT TRUNK (LG 3/8") 1
1*GULPCIRTCELE596
700 FOR/REV SWITCH* 1
1*IFG70
7
1EMARF083
381DRUMASSY (3/8" X 65' MAX) 1
381A DRUM (3/8" X 65' MAX) 1
1BUHRENNIB183
382DRUMASSY (1/4" X 50' MAX) 1
382A DRUM (1/4" X 50' MAX) 1
GO 380/250
MACHINE PARTS LIST
GO 15
GFI
707
262
695
700
166
163
162
161
154
165
150 164
156
155
159
160
393
258
152A
152C
152D
157
151D
153
151B
151C
152A
152C
152D
151D
153
151B
151C
151 Drum Assembly
253
384
385
256
387
258
389
390
390
261
261A
263
380
391
391
392
394
382B
383B
381B
382B
383B
381B
386
381A
382A
383A
381A
382A
383A
381, 382, 383
Drum Assembly’s
GFI
707
262
695
700
166
393
263A
384A
TO CLEAN SEWER LINE 100 FEET OR LONGER
CONTINUE DOWN THE PIPECOUPLE CABLES TOGETHER
STEP 5STEP 4
RUN OUT FULL LENGTH OF CABLE
DISCONNECT AT ANCHOR CABLE AND
REMOVE EMPTY REEL
REPLACE WITH FULL REEL
STEP 3STEP 2
R
O
T
A
T
I
O
N
6
PART # DESCRIPTION REQ
151C REAR DRUM SECTION 1
151D BRASS DRUM BUSHING 1
1MRAEVIRDA251
152C THRUST WASHER* 1
1*GNIRGNINIATERD251
153DRUMRUBBER SLEEVE* 1
154COVER HOUSING* 1
1TFAHSEVIRD551
156 PILLOW BLOCK 1/2"* 2
157 PILLOW BLOCK 5/8"* 1
1*YELLUPTFAHS951
1*TLEB061
1*ROTOM161
162 MOTOR CAPACITOR* 1
163 ELEPHANT TRUNK 1
2*PUCREBBUR461
2*EVEELSREBBUR561
166 ELECTRIC PLUG SLEEVE* 1
1*YELLUPROTOM852
262 TOGGLE SWITCH* 1
393RUBBER BUMPER* 2
1*GULPCIRTCELE596
700 FOR/REV SWITCH* 1
1*IFG707
PART # DESCRIPTION REQ
1EMARF051
1YLBMESSAMURD151
151A 1GNIHSUBMURD
151B FRONT DRUMSECTION 1
1BUHRENNIB283
383DRUM ASSY (3/8" X 90' MAX) 1
383ADRUM (3/8" X 90' MAX) 1
1BUHRENNIB383
1MRAEVIRD483
384ADRIVE ARM COLLAR* 1
1TFAHSEVIRD583
386 PILLOW BLOCK 5/8"* 2
1*YELLUPTFAHS783
1*TLEB983
1*GNIHSUB093
1*GNIRGNINIATER193
392 COVER HOUSING* 1
393RUBBER BUMPER* 4
2*GULP493
166 ELECTRIC PLUG SLEEVE* 1
1ETALPEVIRD352
256 PILLOW BLOCK 7/8"* 1
1*YELLUPROTOM852
1*ROTOM162
261A MOTOR CAPACITOR* 1
262 TOGGLE SWITCH* 1
263 ELEPHANT TRUNK (SM 1/4") 1
263A ELEPHANT TRUNK (LG 3/8") 1
1*GULPCIRTCELE596
700 FOR/REV SWITCH* 1
1*IFG70
7
1EMARF083
381DRUMASSY (3/8" X 65' MAX) 1
381A DRUM (3/8" X 65' MAX) 1
1BUHRENNIB183
382DRUMASSY (1/4" X 50' MAX) 1
382A DRUM (1/4" X 50' MAX) 1
GO 380/250
MACHINE PARTS LIST
GO 15
GFI
707
262
695
700
166
163
162
161
154
165
150 164
156
155
159
160
393
258
152A
152C
152D
157
151D
153
151B
151C
152A
152C
152D
151D
153
151B
151C
151 Drum Assembly
253
384
385
256
387
258
389
390
390
261
261A
263
380
391
391
392
394
382B
383B
381B
382B
383B
381B
386
381A
382A
383A
381A
382A
383A
381, 382, 383
Drum Assembly’s
GFI
707
262
695
700
166
393
263A
384A

714
HOW TO SPLICE CABLES
1. CUT AWAY ANY KINKS OR SEPARATED COILS WITH A GOOD BOLT CUTTER.
2. CLAMP ONE END OF CABLE TO BE SPLICED IN VISE AND LET CABLE EXTEND FROM VISE JAWS
APPROXIMATELY 1”.
3. HOLD SPLICE TIGHT WITH VISE GRIP AND SCREW HALF WAY INTO CABLE
4. RECLAMP SPLICED CABLE SECTION IN VISE. CLAM FIRM ON SPLICED END.
5. VISE GRIP THE SECOND CABLE SECTION TO BE SPLICED 1” FROM END.
6. APPLYING PRESSURE, TURN ALL THE CABLE WITH VISE GRIP OVER SECOND HALF OF SPLICE UNTIL
ENDS OF CABLE MEET.
SPLICING INNERCORE CABLES: MAKE SURE INNERCORE IS AT LEAST 1” INSIDE FROM EACH CABLE
END.
• IF YOU HAVE TROUBLE GETTING SPLICE STARTED, SLIGHTLY SPREAD FIRST COIL OF CABLE WITH
A DRIFT OR CENTER PUNCH.
IF YOU ARE SPLICING CABLES WITH HEX SPLICES, SQUARE EACH END OF CABLE TO BE
SPLICED ON DISC SANDER OR GRINDER. YOU MAY SPOT WELD EACH END OF CABLE TO
SHOULDER OF HEX SPLICE.
DO NOT ATTEMPT TO REPAIR ANY BROKEN CABLES BY MEANS OF WELDING. WELDED
CABLE SECTIONS DO CRYSTALLIZE AND WILL BREAK.
HOW TO INSTALL CABLE ENDS OR CABLE CONNECTORS
1. LET CABLE EXTEND FROM VISE JAWS APPROXIMATELY 1” AND CLAMP TIGHT.
2. HOLD CABLE END OR CABLE CONNECTOR FIRM WITH VISE GRIP.
3. SCREW COUPLING INTO CABLE BY APPLYING PRESSURE UNTIL SHOULDER OF COUPLING MEETS
CABLE.
IF YOU HAVE TROUBLE GETTING CABLE END OR CABLE CONNECTOR STARTED, SLIGHTLY
SPREAD FIRST COIL OF CABLE WITH A DRIFT OR CENTER PUNCH.
ONLY BY MEANS OF ARC WELDING, SPOTWELD CABLE TO COUPLING. ANY ATTEMPT TO
WELD OR BRACE CABLE TO ANY COUPLING WITH AN ACETYLENE TORCH WILL SOFTEN
THE FIRST COILS OF CABLE AND THEREBY RENDERING THE CABLE AT THAT POINT
USELESS.
7 Gorlitz Operating & Maintenance Manual
714
714

813
1. UNCOIL CABLE TO BE INSTALLED AND LAY IN
A STRAIGHT LINE ON THE FLOOR.
2. PASS A SHORT SECTION OF ANCHOR CABLE
THROUGH DRIVE ARM.
3. SLIDE CABLE CONNECTORS TOGETHER AND
FASTEN BOTH CAP SCREWS.
4. DRIVE ARM MUST TURN COUNTER
CLOCKWISE (FACING MACHINE) WHEN
STARTING TO INSTALL CABLE.
5. LAY OUTER CABLE TURNS BY HAND TO FILL
REEL PROPERLY.
6. START MACHINE.
7. FEED REMAINING CABLE INTO REEL.
8. STOP MACHINE OCCASIONALLY TO CHECK
DISTRIBUTION AND REPOSITION CABLE IF
NEEDED.
9. ATTACH CUTTING TOOL OF YOUR CHOICE.
IF YOU ARE USING OUR POWER CABLE FEEDER AND PULLER, DO NOT ALLOW TO PASS
ANY CABLE ENDS OR CABLE CONNECTORS THROUGH FEEDER, AS IT MAY DAMAGE IT.
813
HOW TO INSTALL A NEW CABLE
MODEL GO 68HD, GO 68, GO 62 SERIES
MODEL GO 50 SERIES
1. UNCOIL CABLE TO BE INSTALLED AND LAY IN
A STRAIGHT LINE ON THE FLOOR.
2. MAKE SURE DRIVE ARM ROTATES FREELY.
3. FEED CABLE WITH INSTALLED CABLE END
THROUGH DRIVE ARM.
4. SCREW CABLE END INTO REEL CONNECTOR.
5. FASTEN REEL CONNECTOR TO REEL WITH
BOLT.
6. DRIVE ARM MUST TURN COUNTER
CLOCKWISE (FACING MACHINE) WHEN
STARTING TO INSTALL CABLE.
7. LAY OUTER CABLE TURNS BY HAND TO FILL
REEL PROPERLY.
8. START MACHINE.
9. FEED REMAINING CABLE INTO REEL.
10. STOP MACHINE OCCASIONALLY TO CHECK
DISTRIBUTION AND REPOSITION CABLE IF
NEEDED.
11. ATTACH CUTTING TOOL OF YOUR CHOICE.
MODEL GO 380/250 SERIES, GO 15
1. UNCOIL CABLE TO BE INSTALLED AND LAY IN
A STRAIGHT LINE ON THE FLOOR.
2. MAKE SURE DRIVE ARM ROTATES FREELY.
3. FEED CABLE THROUGH DRIVE ARM.
4. DRIVE ARM MUST TURN COUNTER
CLOCKWISE WHEN INSTALLING CABLE.
5. START MACHINE.
6. FEED REMAINING CABLE INTO DRUM
ALLOWING ADEQUATE LENGTH OF EXPOSED
CABLE TO ATTACH FLEXIBLE LEADER
(ELEPHANT TRUNK) WHEN APPLICABLE.
7. INSTALL CABLE END AND CUTTING BLADE
(AVAILABLE ONLY FOR 3/8” DIA. CABLE) AND/
OR MAKE CABLE BENDS OF YOUR CHOICE.
Gorlitz Operating & Maintenance Manual 8

9
12
HOW TO ADJUST BELT TENSION:
MODEL GO 68HD, GO 380/250 SERIES
1. LOOSEN MOTOR MOUNTING SCREWS.
2. ADJUST MOTOR AS NEEDED..
3. MAKE SURE PULLEY’S ARE IN LINE.
4. REFASTEN MOTOR MOUNTING SCREWS.
PROPER BELT TENSION FOR ALL MODELS SHOULD BE 1/4” BELT MOVEMENT IN EITHER DIRECTION.
COVER HOUSING MUST BE REMOVED ON MODEL GO 380/250 SERIES.
MODEL GO 68, GO 62 SERIES
1. LOOSEN BELT TENSIONER HEX BOLTS.
2. ADJUST BELT TENSION PLATE AS NEEDED.
3. MAKE SURE PULLEY’S ARE IN LINE.
4. REFASTEN BELT TENSIONER HEX BOLTS.
MODEL GO 50 SERIES
1. LOOSEN UPPER AND LOWER NUTS ON
MOUNTING BOLTS.
2. RAISE OR LOWER MOTOR FOR RIGHT BELT
TENSION.
3. CHECK ALIGNMENT OF BELT AND PULLEYS.
4. REFASTEN ALL NUTS.
MODEL GO 15
1. REMOVE TRUNK, PILLOW BLOCK AND DRUM.
2. LOOSEN MOTOR MOUNTING NUTS.
3. ADJUST MOTOR FOR PROPER BELT TENSION.
4. REFASTEN ALL MOTOR MOUNTING NUTS.
5. REINSTALL DRUM, PILLOW BLOCK AND
TRUNK.
DRUM MUST BE REMOVED BEFORE BELT TENSION CAN BE PERFORMED.
DO NOT OVER TIGHTEN BELT TENSION, AS YOU WILL RAISE MOTOR SHAFT, LOOSEN
AND WEAR OUT SEALS AND EXPERIENCE THE LOSS OF GEAR LUBRICANT.
HOW TO ADJUST BELT TENSION
MODEL GO 68, GO 68HD, GO 62 SERIES
CABLE IS ALWAYS UNDER TENSION. DO NOT LET CABLE FLY OUT OF CAGE.
WHEN INSTALLING REEL, REVERSE PROCEDURE. BE POSITIVE DRIVE PLATE ENGAGE
PROPERLY INTO BACK OF REEL.
1. PUSH CABLE INTO DRIVE ARM..
2. LOOSEN SET SCREW ON DRIVE EXTENSION.
3. PUSH DRIVE ARM EXTENSION INTO DRIVE
ARM BUSHING.
4. PULL DRIVE ARM OUT OF FRONT BEARING.
5. REMOVE REMAINING CABLE FROM DRIVE
ARM AND PLACE INTO REEL.
6. SLIDE REEL FORWARD AND OFF DRIVE
SHAFT.
9 Gorlitz Operating & Maintenance Manual

HOW TO REMOVE DRUMS OR REELS
MODEL GO 50 SERIES, GO 380/250 SERIES
1. PUSH CABLE INTO DRIVE ARM.
2. LOOSEN SET SCREW ON COLLAR AND SLIDE
COLLAR TOWARD DRUM/REEL.
3. SLIDE DRIVE ARM INTO FRONT PILLOW
BLOCK AS FAS AS POSSIBLE.
4. PUSH DRIVE ARM SIDEWAYS, UP OR DOWN
TO CLEAR CENTER STEM OF DRUM OR REEL.
5. MOVE DRIVE ARM TOWARD DRUM/REEL
UNTIL IT CLEARS FRONT PILLOW BLOCK.
6. FEED REMAINING CABLE FROM DRIVE ARM
INTO DRUM/REEL AND REMOVE DRIVE ARM.
7. SLIDE DRUM/REEL FORWARD AND OFF DRIVE
SHAFT.
TO GAIN ACCESS TO INSIDE OF DRUMS ON MODEL 380/250 SERIES, REMOVE RETAINING RING
AND PULL INNER HUB FROM CENTER GUIDE.
WHEN INSTALLING REEL OR DRUM, REVERSE PROCEDURE BUT MAKE CERTAIN DRIVE PLATE
OR DRIVE PIN ENGAGE PROPERLY INTO REEL OR DRUM.
10 11
HOW TO REMOVE DRUMS
MODEL GO 15
1. REMOVE FLEXIBLE TRUNK.
2. PUSH CABLE BACK INTO DRIVE ARM.
3. LOOSEN THUMP SCREWS AND REMOVE
PILLOW BLOCK.
4. LOOSEN SET SCREW AT BACK SIDE OF DRUM.
5. SLIDE DRUM FORWARD AND OF DRIVE SHAFT.
10 11
BEFORE SEPARATING DRUM PULL OUT ENTIRE CABLE. REMOVE 4 SMALL SCREWS AND PULL
DRUM SECTIONS APART.
WHEN INSTALLING DRUM, REVERSE PROCESS. MAKE CERTAIN SET SCREW ENGAGES FLAT
AREA ON DRIVE SHAFT.
Gorlitz Operating & Maintenance Manual 10
HOW TO ASSEMBLE CHUCK AND CUTTING TOOLS
3
PART # DESCRIPTION REQ
1EMARF086
1ETELPMOCLEER186
681P POLY DRUMCOMPLETE 1
1ELBACROHCNA286
683 REEL CENTER BEARING* 1
1ETALPEVIRD486
1MRAEVIRD586
685ADRIVE ARM SET SCREW* 1
686DRIVE ARM EXTENSION 1
1TFAHSEVIRD786
1YEKTFAHSA786
689 PILLOW PLOCK 1 1/4"* 1
PART # DESCRIPTION REQ
1*YELLUPROTO
M096
690A MOTOR PULLEY-FAST* 1
1*YELLUPTFAHS196
1*TLEB296
1*TSAF-TLEBA296
1*ROTOM396
693A MOTOR SEALS-KIT OF 2* 1
693B MOTOR COVER GASKET* 1
693C WOO 1*YEKFFURD
1*RALLOCTFAHS496
1*GULPCIRTCELE596
1*XOBHCTIWS796
1*ETALPREVOC896
2*LEEHW996
700 FOR/REV SWITCH* 1
702 BELT TENSION PLATE 1
703BELT TENSION BEARING* 1
704 THRUSTBEARING* 2
705 THRUST WASHER* 4
706 GFI COVER PLATE 1
1*IFG707
708 COMPRESSION FITTING* 1
709CORDCONNECTOR* 2
710DRUMCONNECTOR 11/16" 1
711DRUMCONNECTOR 3/4" 1
712DRUM SAFETY DISK 1
2*GNIHSUB
TFAHS605
1*GNITTIFKREZ705
1TFAHSEVIRDDH786
1YEKTFAHSADH786
688HD PILLOW BLOCK 1"* 1
689 PILLOW PLOCK 1 1/4"* 1
1*YELLUPROTOMDH096
691HD GEAR BOX PULLEY* 1
1*TLEBDH296
1*ROTOMDH396
693HDA C 1*ROTICAPA
693HDB MOTOR SHAFT KEY* 1
3*RALLOCTFAHS496
1*GULPCIRTCELE596
1*XOBHCTIWS796
1*ETALPREVOC896
2*LEEHW996
700 FOR/REV SWITCH* 1
1*XOBRAEGDH407
704HDA GEAR BOX REPAIR KIT* 1
1DRAUGNEERCSDH507
706HD RU 2*TEEFREBB
706 GFI COVER PLATE 1
1*IFG707
708 COMPRESSION FITTING* 1
709CORDCONNECTOR* 2
710DRUMCONNECTOR 11/16" 1
711DRUMCONNECTOR 3/4" 1
712DRUM SAFETY DISK 1
1EMARFDH086
1ETELPMOCLEER186
681P POLY DRUM COMPLETE 1
1ELBACROHCNA286
683 REEL CENTER BEARING* 1
1ETALPEVIRD486
1MRAEVIRDDH586
685ADRIVE ARM SET SCREW* 1
686DRIVE ARM EXTENSION 1
GO 68
Go 68HD
680
GFI
681
681P 682
683
684
685
685A
686
687
689
691
693
507
694
695
697
698 699
700
702
703
704
704
705
705
706
707
708
709
709
710
711
712
506
506
687A
692
692A
690
690A 693C
693A
693B
681
681P 682
683
685A
686
689
694
694
697
698 699
GFI
695
700
706
707
708
709
709
710
711
712
680HD
685HD
687HD
690HD
692HD
704HD
705HD
694
706HD 693HD
693HDA
693HDB
687HDA
688HD
684
A-G
691HD
3
PART # DESCRIPTION REQ
1EMARF086
1ETELPMOCLEER186
681P POLY DRUMCOMPLETE 1
1ELBACROHCNA286
683 REEL CENTER BEARING* 1
1ETALPEVIRD486
1MRAEVIRD586
685ADRIVE ARM SET SCREW* 1
686DRIVE ARM EXTENSION 1
1TFAHSEVIRD786
1YEKTFAHSA786
689 PILLOW PLOCK 1 1/4"* 1
PART # DESCRIPTION REQ
1*YELLUPROTO
M096
690A MOTOR PULLEY-FAST* 1
1*YELLUPTFAHS196
1*TLEB296
1*TSAF-TLEBA296
1*ROTOM396
693A MOTOR SEALS-KIT OF 2* 1
693B MOTOR COVER GASKET* 1
693C WOO 1*YEKFFURD
1*RALLOCTFAHS496
1*GULPCIRTCELE596
1*XOBHCTIWS796
1*ETALPREVOC896
2*LEEHW996
700 FOR/REV SWITCH* 1
702 BELT TENSION PLATE 1
703BELT TENSION BEARING* 1
704 THRUSTBEARING* 2
705 THRUST WASHER* 4
706 GFI COVER PLATE 1
1*IFG707
708 COMPRESSION FITTING* 1
709CORDCONNECTOR* 2
710DRUMCONNECTOR 11/16" 1
711DRUMCONNECTOR 3/4" 1
712DRUM SAFETY DISK 1
2*GNIHSUB
TFAHS605
1*GNITTIFKREZ705
1TFAHSEVIRDDH786
1YEKTFAHSADH786
688HD PILLOW BLOCK 1"* 1
689 PILLOW PLOCK 1 1/4"* 1
1*YELLUPROTOMDH096
691HD GEAR BOX PULLEY* 1
1*TLEBDH296
1*ROTOMDH396
693HDA C 1*ROTICAPA
693HDB MOTOR SHAFT KEY* 1
3*RALLOCTFAHS496
1*GULPCIRTCELE596
1*XOBHCTIWS796
1*ETALPREVOC896
2*LEEHW996
700 FOR/REV SWITCH* 1
1*XOBRAEGDH407
704HDA GEAR BOX REPAIR KIT* 1
1DRAUGNEERCSDH507
706HD RU 2*TEEFREBB
706 GFI COVER PLATE 1
1*IFG707
708 COMPRESSION FITTING* 1
709CORDCONNECTOR* 2
710DRUMCONNECTOR 11/16" 1
711DRUMCONNECTOR 3/4" 1
712DRUM SAFETY DISK 1
1EMARFDH086
1ETELPMOCLEER186
681P POLY DRUM COMPLETE 1
1ELBACROHCNA286
683 REEL CENTER BEARING* 1
1ETALPEVIRD486
1MRAEVIRDDH586
685ADRIVE ARM SET SCREW* 1
686DRIVE ARM EXTENSION 1
GO 68
Go 68HD
680
GFI
681
681P 682
683
684
685
685A
686
687
689
691
693
507
694
695
697
698 699
700
702
703
704
704
705
705
706
707
708
709
709
710
711
712
506
506
687A
692
692A
690
690A 693C
693A
693B
681
681P 682
683
685A
686
689
694
694
697
698 699
GFI
695
700
706
707
708
709
709
710
711
712
680HD
685HD
687HD
690HD
692HD
704HD
705HD
694
706HD 693HD
693HDA
693HDB
687HDA
688HD
684
A-G
691HD

HUBBELL OPERATION AND TEST INSTRUCTIONS
NOTE: The automatic set version (A sufx) will immediately supply power to the load when power is
applied to the line connections. Manual versions (no sufx) must be reset manually before power is
applied to the load.
1. Turn on power to the Circuit Guard® Module.
2. Press the “RESET” button, the power “ON” light should go on.
3. Press the “TEST” button, the power “ON” light should go off.
4. Press the “RESET” button, the power “ON” light should go on.
5. Do not use this device if it fails the above tests. This device does not protect against electric shock due to
contact with both circuit conductors and also due to a fault in any wiring supplying this device.
6. Connect the desired load equipment to the receptacle connected to Circuit Guard® Module and operate the
equipment normally.
1. If the GFCI fails to trip when the test button is pressed (power “ON” light does not go off) or fails to reset
(power “ON” light does not go on), the device is inoperative and should be replaced immediately.
2. If the GFCI tests properly without any appliance connected to it but trips each time an appliance is
connected to it, the appliance has a ground fault and needs to be repaired or replaced. DO NOT USE THE
MACHINE IF THIS CONDITION OCCURS; A REAL SHOCK HAZARD MAY EXIST.
LEVITON OPERATION AND TEST INSTRUCTIONS
1. A Self-Test GFCI receptacle has all the features of a conventional GFCI receptacle. In addition, this receptacle tests
itself periodically to conrm the GFCI electronics are functional. The Status Indicator Light will be solid green when
the GFCI is powered from Line side and working correctly.
2. Self-Test Indications: If the Status Indicator Light is solid or ashing RED a problem may exist. Press the TEST
button to trip the GFCI. If unable to Reset, replace the GFCI. NOTE: The status indicator may ash Red at power
“ON” and Reset. IF GFCI WILL NOT RESET OR SOLID OR BLINKING RED LIGHT CONTINUES, REPLACE
DEVICE.
1. This device is to be used on normal electrical distribution systems on circuits rated at 120 V AC, 60 Hz
ONLY.
2. DO NOT USE in a wet environment if any of the Circuit Guard® Module’s push-button seals or its mounting
gasket is damaged.
3. Test at least monthly, or preferably before each use, to ensure correct operation.
4. The Circuit Guard Module is designed as a protective device. Do not use as an OFF/ON switch.
5. 5. To minimize false tripping, do not connect to swimming-pool equipment installed before adoption of the
1965 National Electrical Code®.
A GFCI limits the duration but not the magnitude of ground fault current and, therefore, does not prevent
electric shock. It limits the duration of the shock to a period considered safe for healthy people.
GENERAL
The Hubbell Circuit Guard® & Leviton SmartLockPro® Modules provides personnel ground fault protection.
Conventional overcurrent protection devices such as fuses and circuit breakers cannot protect people from electrical
shock due to low level ground fault current. Fuses and circuit breakers are designed to disconnect the power when
current levels (amperes) owing in the circuit exceed the rating of the fuse or circuit breaker. However, currents as low
as a few milliamperes can be harmful to normal healthy human beings. One ampere equals 1000 milliamperes. Many
electric shocks occur where the path of current ow is from the hot wire through the metal housing of a defective tool
or appliance, through the body of a human being to ground. Because of the resistance of the human body to electrical
current ow, the current will be quite low relative to that required to cause conventional over-current devices to function.
However, it may be high enough to cause a painful or possibly lethal electric shock to a human being. The Hubbell
Circuit Guard® & Leviton SmartLockPro® Module is designed to remove power from equipment loads when these loads
have a potential lethal current ow to ground in excess of six milliamperes. Normal loads will draw current from the Line
Conductor (black wire) and return it to the power source through the Neutral Conductor (white wire). Faulty loads can
return some of the current to the power source through a ground path such as a water pipe, gas pipe, wet oor, third
conductor (green wire), or worst of all, through a person who is in contact with a grounding path. The Hubbell Circuit
Guard® Module weather-resistant construction allows it to be used in outdoor or indoor locations, where ground fault
protection is desired. When energized by actuation of the reset button, it will conveniently supply power to any power
tool or appliance whose power requirement does not exceed 20 amperes at 120 volts RMS, 60 Hertz or 2400 watts.
HUBBELL & LEVITON GFCI OPERATING & TESTING INSTRUCTIONS
CIRCUIT GUARD® Module GFM20A, SMARTLOCKPRO® GFRBF-B
11 Gorlitz Operating & Maintenance Manual

GENERAL MAINTENANCE TIPS
TO KEEP YOUR GORLITZ ELECTRIC SEWER CLEANING MACHINES IN GOOD, CLEAN AND SAFE OPERATING
CONDITION, PERIODICALLY CHECK THE FOLLOWING PARTS:
• LUBRICATE ALL SLIDING, ROTATING AND MOVING PARTS.
• PAY SPECIAL ATTENTION TO WEARS ON DRIVE ARMS.
• CHECK ALIGNMENT OF PULLEYS AND BELT.
• INSPECT, REFASTEN OR REPLACE ALL SET SCREWS ON DRIVE ARM, PULLEYS, DRIVE PLATE,
SHAFT COLLARS AND PILLOW BLOCKS IF NEEDED.
• INSPECT ELECTRICAL OUTLET WIRING AND SWITCH BOX FOR VISIBLE WEAR AND TEAR.
• CHECK TIRE PROFILE.
WHY DO CABLES JUMP OUT OF REELS OR DRUMS?
• CABLE WAS RETURNED INTO DRUM OR REEL BY HAND WHILE DRUM OR REEL WAS NOT ROTATING:
ALWAYS KEEP MACHINE RUNNING FEEDING CABLE BACK INTO DRUM OR REEL. CABLE MUST BE
PACKED TIGHT.
• SHARP KINKS IN CABLE: CUT OUT ALL KINKS WITH A GOOD BOLT CUTTER AND INSTALL SPLICE OR
CABLE CONNECTOR.
• CABLE GOT HUNG UP OR USING TOO MUCH PRESSURE TO OPEN BLOCKAGE: BACK PRESSURE MAY
ALLOW CABLE TO FLY OUT OF DRUM OR REEL. USE CAUTION AND FEEL YOUR WAY AS YOU FEED
CABLE INTO DRAIN PIPE.
• CABLE HAS SOFT SPOTS: CUT OUT ALL WEAK SECTIONS AND INSTALL SPLICE OR CABLE CONNECTOR.
• CABLE EXCEEDED LIFESPAN: REPLACE WITH A NEW CABLE.
MOST COMMON CAUSES FOR DAMAGED OR BROKEN CABLES
• ALLOWING CABLES TO GET HUNG UP IN AN OBSTRUCTION: THIS IS THE MOST COMMON REASON FOR
CABLE BREAKAGE. THE OPERATOR ALLOWED THE CUTTING TOOL OR CABLE END TO GET HUNG UP IN
ROOTS, TOWELS, PAPER, ETC. OR IN A BROKEN, SEPARATED OR CRUSHED SEWER LINE. REMEMBER,
KEEP THE CABLE ROTATING AT ALL TIMES.
• CABLE STARTS SWINGING WHEN DOING OVERHEAD JOBS: WHILE DOING OVERHEAD JOBS, GUIDE
CABLE BY MEANS OF TUBES OR PIPES (PVC, ETC.) AND/OR USE SECOND OPERATOR.
• APPLYING TOO MUCH PRESSURE: FEEL YOUR WAY THROUGH THE PIPE AND TRY NOT TO DO THE JOB
IN A HURRY.
• LETTING CABLE GET AWAY FROM YOU: ALWAYS GUIDE YOUR CABLE WITH BOTH HANDS. KEEP
DISTANCE AS CLOSE AS POSSIBLE BETWEEN CLEAN-OUT AND MACHINE.
• FORCING CABLE AROUND TIGHT TURNS OR THROUGH A TRAP: IF CABLE IS SLOWED OR STOPPED
BECAUSE OF TIGHT TURNS, TRAPS OR BLOCKAGES, BUT YOU CONTINUE TO FEED CABLE INTO SEWER
LINE, IT MAY BECOME WAVY. BE EXTREMELY CAREFUL WHEN USING SMALLER SIZE CABLES ON LONG
RUNS OR TOO LARGE OF A DIAMETER SEWER LINE.
• USING CABLES WITH SHARP KINKS OR SOFT SPOTS: CUT OUT ALL SHARP KINKS, STRETCHED,
LIMBER OR WEAK SECTIONS, INSTALL SPLICE.
• CABLE EXCEEDED LIFESPAN: REPLACE WITH A NEW CABLE.
CABLE EXPOSED TO A CHEMICAL DRAIN CLEANER MAY BECOME CRYSTALLIZED AND VERY
BRITTLE. IT MAY ALSO BREAK INTO VERY SHORT SECTIONS. INSPECT CABLE FOR GRAY,
WHITE OR BLUE COLOR AND/OR CHEMICAL ETCHINGS.
Gorlitz Operating & Maintenance Manual 12

9
12
MODEL T 01 POWER CABLE FEEDER AND PULLER
SAFETY INSTRUCTIONS
BEFORE SWITCHING ON SEWER CLEANING MACHINE, MAKE SURE MOVEMENT ASSEMBLY LEVER IS
IN UPRIGHT POSITION. THIS PREVENTS ACCIDENTALLY RUNNING CABLE FITTINGS THROUGH POWER
FEED DAMAGING COUPLINGS AND/OR DRIVE BEARINGS.
WHILE OPERATING THE POWER CABLE FEEDER AND PULLER, ALWAYS WEAR GLOVES AND KEEP
FINGERS AND FOREIGN OBJECTS OUT OF DRIVE MECHANISMS.
FOR STORAGE OR WHEN SEWER CLEANING MACHINE AND POWER FEED IS NOT IN USE, ALWAYS
TIGHTEN HAND KNOB ASSEMBLY TO LOCK CABLE INTO DRUM OR REEL.
MAINTAIN POWER FEED WITH PROPER CARE, KEEP IT CLEAN FOR BEST AND SAFEST PERFORMANCE.
FOLLOW INSTRUCTIONS FOR LUBRICATION, CHANGING BEARINGS AND MAINTENANCE.
INSTALLATION
THE SEWER CABLE SHOULD PASS FROM THE DISTRIBUTING ARM OF THE MACHINE OVER THE TWO
LOWER BEARINGS AND THROUGH THE CENTER HOLE OF THE MOVEMENT ASSEMBLY. THE MOUNTING
BRACKET IS PROVIDED WITH SEVERAL MACHINED HOLES AND SLOTS TO ALLOW CENTERLINE
LOCATIONS. IF FURTHER ADJUSTMENTS ARE NEEDED, USE SHIM STOCK.
ONCE YOU HAVE DETERMINED THE DESIRED CABLE SIZE, THE CHART BELOW SHOWS THE CORRECT
AMOUNT OF SPACERS REQUIRED BETWEEN THE SHORT HOUSING AND LOWER END PLATES.
CABLE SIZE SPACE REQUIRED
5/16”
3/8”
13/32”
1/2”
5/8”
11/16”
3/4”
0
1
1
2
3
4
4
GENERAL OPERATING INSTRUCTIONS
1. THE MOVEMENT ASSEMBLY LEVER SHOULD BE IN THE NEUTRAL POSITION.
2. RELEASE PRESSURE FROM THE HAND KNOB ASSEMBLY.
3. START SEWER CLEANING MACHINE (FOR REFERENCE SEE OPERATING & MAINTENANCE
INSTRUCTIONS IN THIS MANUAL).
4. PLACE MOVEMENT ASSEMBLY LEVER IN THE FORWARD POSITION (MOVE LEVER TO THE RIGHT)
AND START TO TIGHTEN HAND KNOB. ONCE SEWER CABLE IS DRIVING STEADILY FORWARD, STOP
TURNING HAND KNOB. POSITION MOVEMENT LEVER IN REVERSE POSITION (MOVE LEVER TO THE
LEFT) AND SEWER CABLE SHOULD RETRIEVE STEADILY.
5. IF THE CABLE BEGINS TO SLIP OR DOES NOT FEED, THE HAND KNOB MAY BE TIGHTENED WITH
CAUTION UNTIL CABLE IS MOVING AGAIN.
EXTREME TIGHTENING OF HAND KNOB ASSEMBLY MAY DAMAGE POWER FEEDER
BEARING, OVERLOAD MOTOR AND/OR ADD EXCESSIVE TENTION TO CABLE.
SHORT HOUSING, THRUST
BEARING AND SPACER
ASSEMBLY SHOWN.
DRAIN HOLE ON LOWER END PLATE MUST BE TOWARD BOTTOM OF POWERFEED.
9
12
POWER CABLE FEEDER
LEVER SHOWN IN REVERSE
POSITION.
13 Gorlitz Operating & Maintenance Manual

6. WHEN YOUR CUTTING TOOL ENCOUNTERS THE BLOCKAGE, IT WILL SLOW DOWN OR MOMENTARILY
STOP THE ROTATION OF CABLE. AS SOON AS YOU FEEL A RPM REDUCTION, PLACE LEVER INTO
REVERSE POSITION TO RETRACT CABLE FROM STOPPAGE. ONCE TORQUE IS RELIEVED, MOVE
LEVER INTO UPRIGHT POSITION AND RELEASE PRESSURE FROM HAND KNOB.
7. ONCE YOU HAVE CUT THROUGH THE BLOCKAGE, TIGHTEN HAND KNOB. PLACE LEVER INTO REVERSE
POSITION TO RETRACT CABLE INTO REEL OR DRUM.
IT IS RECOMMENDED TO CLEAR STOPPAGE MANUALLY.
TO CLEAR BLOCKAGE REFER TO PAGE 6, STEPS 6 THROUGH 10.
LUBRICATION
THE GORLITZ POWER CABLE FEEDER AND PULLER SHOULD BE GIVEN THE BEST OF CARE AND IF KEPT
CLEAN AND PROPERLY LUBRICATED, IT WILL PROVIDE MANY YEARS OF TROUBLE-FREE SERVICE.
OBSERVE THE FOLLOWING INSTRUCTIONS AT ALL TIMES:
• THE DRIVE BEARING HAVE BEEN PACKED AT THE FACTORY WITH PROPER LUBRICANT AND REQUIRE
NO ADDITIONAL LUBRICATION.
• GREASE ALL HOUSING EQUIPPED WITH ZERK FITTINGS.
• REMOVE FRONT DISC PERIODICALLY IN ORDER TO APPLY GREASE TO BOTH SIDES OF MOVEMENT
ASSEMBLY.
IF THE POWER FEED IS NOT BEING USED FOR A LONG PERIOD OF TIME, LUBRICATE FEEDER
WITH WD40 OR EQUIVALENT LUBRICANT TO PREVENT PARTS FROM OXIDATION.
1. REMOVE SIX ACORN NUTS AND LOCK
WASHERS.
2. REMOVE FRONT DISC AND MOVEMENT
ASSEMBLY.
3. SLIP LONG AND/OR SHORT HOUSINGS FROM
HEX BOLTS.
4. REMOVE UPPER AND/OR LOWER PISTONS.
5. REMOVE SPRING RETAINER.
6. PULL OUT DRIVE PIN.
7. REMOVE SPACERS AND DRIVE BEARING.
8. CLEAN ALL PARTS IN A CLEANING SOLVENT.
9. LUBRICATE ALL MOVING PARTS.
HOW TO INSTALL A NEW DRIVE BEARINGS
WHEN REASSEMBLING CABLE FEEDER AND PULLER, REVERSE PROCEDURES. BE POSITIVE
DRIVE PINS ENGAGE PROPERLY INTO U-SHAPED BRACKETS.
813
DRIVE PIN ASSEMBLY AND PISTON
SHOWN.
LUBRICATION
TO KEEP YOUR GORLITZ POWER CABLE FEEDER AND PULLER IN GOOD AND SAFE OPERATING CONDITION,
PERIODICALLY CHECK THE FOLLOWING ITEMS:
• LUBRICATE ALL SLIDING, ROTATING AND MOVING PARTS.
• PAY SPECIAL ATTENTION FOR WEAR ON DRIVE PINS AND DRIVE BEARINGS.
• CHECK, REFASTEN OR REPLACE IF NEEDED ALL BOLTS, NUTS, WASHERS AND SPRING RETAINERS.
• INSPECT MOVEMENT ASSEMBLY DISC FOR WEAR.
• CHECK ANGLE AND CENTER LINE ALIGNMENT OF POWER FEED.
Gorlitz Operating & Maintenance Manual 14

MACHINE
PARTS LIST
GO 15
GO 380/250
GO 50
GO 62HD
GO 68
GO 68HD
T 01
T 01A
T 05 WINCH
15 Gorlitz Operating & Maintenance Manual

GO 15
PART # DESCRIPTION REQ
161
162
163
164
165
166
258
262
393
695
700
707
MOTOR*
MOTOR CAPACITOR*
ELEPHANT TRUNK
RUBBER CUP*
RUBBER SLEEVE*
ELECTRIC PLUG SLEEVE*
MOTOR PULLEY*
TOGGLE SWITCH*
RUBBER BUMPER*
ELECTRIC PLUG*
FOR/REV SWITCH*
GFI*
1
1
1
2
2
1
1
1
2
1
1
1
PART # DESCRIPTION REQ
150
151P
151D
152A
152C
152D
153
154P
155
156
157
159
160
FRAME
POLY DRUM - Red - Blue - Black
BRASS DRUM BUSHING
DRIVE ARM
THRUST WASHER*
RETAINING RING*
DRUM RUBBER SLEEVE*
COVER HOUSING*
DRIVE SHAFT
PILLOW BLOCK 1/2”*
PILLOW BLOCK 5/8”*
SHAFT PULLEY*
BELT*
1
1
1
1
1
1
1
1
1
2
1
1
1
Gorlitz Operating & Maintenance Manual 16

PART # DESCRIPTION REQ
380
381
381A
381B
382
382A
382B
383
383A
383B
384
384A
385
386
387
389
390
FRAME
DRUM ASSEMBLY (3/8” X 65’ MAX)
DRUM (3/8” X 65’ MAX)
INNER HUB
DRUM ASSEMBLY (1/4” X 50’ MAX)
DRUM (1/4” X 50’ MAX)
INNER HUB
DRUM ASSEMBLY (3/8” X 90’ MAX)
DRUM (3/8” X 90’ MAX)
INNER HUB
DRIVE ARM
DRIVE ARM COLLAR*
DRIVE SHAFT
PILLOW BLOCK 5/8”*
SHAFT PULLEY*
BELT*
BUSHING*
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
PART # DESCRIPTION REQ
391
392P
393
394
166
253
256
258
261
261A
262
263
263A
695
700
707
RETAINING RING*
COVER HOUSING*
RUBBER BUMPER*
PLUG*
ELECTRIC PLUG SLEEVE*
DRIVE PLATE
PILLOW BLOCK 7/8”*
MOTOR PULLEY*
MOTOR*
MOTOR CAPACITOR*
TOGGLE SWITCH*
ELEPHANT TRUNK (SM 1/4”)
ELEPHANT TRUNK (LG 3/8”)
ELECTRIC PLUG*
FOR/REV SWITCH*
GFI*
1
1
4
2
1
1
1
1
1
1
1
1
1
1
1
1
GO 380/250
17 Gorlitz Operating & Maintenance Manual

PART # DESCRIPTION REQ
500
501
501A
501P
502
502P
503
504
505
505A
506
507
508
509
510
511
511A
512
513
FRAME
REEL (1/2” X 100’ MAX)
REEL (1/2” X 125’ MAX)
POLY DRUM (1/2” X 100’ MAX)
REEL (3/8” X 90’ MAX)
POLY DRUM (3/8” X 90’ MAX)
REEL CABLE CONNECTOR
DRIVE SHAFT
DRIVE ARM
DRIVE ARM COLLAR*
SHAFT BUSHING*
ZERK FITTING*
MOTOR PULLEY*
SHAFT PULLEY*
BELT*
MOTOR*
MOTOR CAPACITOR*
PHENOLIC 4” WHEEL*
PHNEUMATIC 6” WHEEL*
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
2
1
PART # DESCRIPTION REQ
514
516
683
684
685A
687A
688
694
695
697
698
700
706
707
708
709
713HD
1501A-A
DRUM CONNECTOR 3/8” THRU 1/2”
REEL & DRUM SAFETY DISK
REEL CENTER BEARING*
DRIVE PLATE
DRIVE ARM SET SCREW*
SHAFT KEY
PILLOW BLOCK 1”*
SHAFT COLLAR*
ELECTRIC PLUG*
SWITCH BOX*
COVER PLATE*
FOR/REV SWITCH*
GFI COVER PLATE
GFI*
COMPRESSION FITTING*
CORD CONNECTOR*
RUBBER BUMPER*
PULL STICK ASSEMBLY
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
2
1
1
GO 50
Gorlitz Operating & Maintenance Manual 18

PART # DESCRIPTION REQ
620HD
621
621P
622
623
624
625
626HD
627HD
630HD
630HDC
631
631A
632
501
501A
501P
502
502P
514
516
683
FRAME
REEL COMPLETE
POLY DRUM COMPLETE
ANCHOR CABLE
DRIVE ARM-LARGE
DRIVE ARM-SMALL
DRIVE ARM BUSHING
DRIVE SHAFT
MOTOR PULLEY*
MOTOR* 1/3 HP, GO 62
CAPACITOR SET
WHEEL*
WHEEL BEARING *
DRUM CONNECTOR 5/8”
REEL (1/2” X 100’ MAX)
REEL (1/2” X 125’ MAX)
POLY DRUM (1/2” X 100’ MAX)
REEL (3/8” X 90’ MAX)
POLY DRUM (3/8” X 90’ MAX)
DRUM CONNECTOR 3/8” THRU 1/2”
REEL & DRUM SAFETY DISC
REEL CENTER BEARING*
1
1
1
1
1
1
1
1
1
1
2
2
1
1
1
1
1
1
1
1
1
1
PART # DESCRIPTION REQ
684
685A
686
687HDA
687HDB
688HD
689
693HDB
694
695
697
698
690HD
692HD
700
704HD
706
707
708
709
712
713HD
DRIVE PLATE
DRIVE ARM SET SCREW*
DRIVE ARM EXTENSION
SHAFT KEY
SHAFT KEY
PILLOW BLOCK 1”*
PILLOW BLOCK 1 1/4”*
MOTOR SHAFT KEY*
SHAFT COLLAR*
ELECTRIC PLUG*
SWITCH BOX*
COVER PLATE*
MOTOR PULLEY*
BELT*
FOR/REV SWITCH*
GEAR BOX*
GFI COVER PLATE
GFI*
COMPRESSION FITTING*
CORD CONNECTOR*
DRUM SAFETY DISK
RUBBER BUMPER*
1
1
1
1
1
1
1
1
3
1
1
1
1
1
1
1
1
1
1
2
1
1
GO 62HD
19 Gorlitz Operating & Maintenance Manual
