GOVI arktik 2000US User manual

Stationary Trailer Refrigeration Unit
Installation Manual
2000US - 2500US - 1500US/F
501 N. Grandview Avenue #135
Daytona Beach, FL 32118
Email: [email protected]
Inc.
govitrailerrefrigeration.com
GOVI Inc.
Inc.
GOVI Inc. (USA)
GOVI GmbH (Germany)

Installation Manual
Stationary Trailer Refrigeration Unit
Page 2 71.01.121 / 00
Copyright by GOVI GmbH 2013. The reproduction of this document or any part there of is prohibited! The right is reserved to make technical changes in the course of further development!
You shall read and understand this manual, before you operate the
refrigerator unit.
You should retrain this operation manual for future reference after
reading it thoroughly
501 N. Grandview Avenue #135
Daytona Beach, FL 32118
Email: [email protected]
Inc.
govitrailerrefrigeration.com
GOVI Inc.
Inc.
GOVI Inc. (USA)
GOVI GmbH (Germany)

Installation Manual
Stationary Trailer Refrigeration Unit
71.01.121 / 00
Page 3
Copyright by GOVI GmbH 2013. The reproduction of this document or any part there of is prohibited! The right is reserved to make technical changes in the course of further development!
Contents
1 Introduction ......................................................................................... 5
2 Safety Instructions ............................................................................. 6
2.1 Safety Messages and Safety Alert Symbols ............................................................. 6
2.2 Not Hazard-related Messages .................................................................................. 6
2.3 General Safety Precautions ...................................................................................... 7
2.4 Safety Precautions concerning the refrigerant ........................................................ 10
2.4.1 First Aid ....................................................................................................... 10
2.4.2 Environmental considerations ...................................................................... 10
3 Carriage, Transportation and Storage ............................................. 11
4 Technical Data .................................................................................. 12
5 System Description .......................................................................... 15
6 Installation ......................................................................................... 18
6.1 Conditions for installation ........................................................................................ 19
6.2 Required tools, equipment and safety gear ............................................................ 20
6.3 Required additional parts ........................................................................................ 22
6.4 Delivery Inspection ................................................................................................. 23
6.5 Preparing Installation .............................................................................................. 25
6.5.1 Preparing a template for the wall opening and the bore holes ..................... 25
6.5.2 Preparing the installation area ..................................................................... 26
6.5.3 Preparing the trailer ..................................................................................... 27
6.6 Attaching the refrigeration unit at the trailer ............................................................ 30
6.7 Sealing from inside the trailer and laying of drain hose .......................................... 33
6.8 Installation of ancillary components ........................................................................ 34
6.9 Electrical installation ............................................................................................... 35
7 Commissioning ................................................................................. 38
8 Index and summary .......................................................................... 44
9 Appendix ........................................................................................... 45
9.1 Wiring diagram ....................................................................................................... 45
9.2 Safety data sheet .................................................................................................... 46
9.3 Installation Checklist ............................................................................................... 50
501 N. Grandview Avenue #135
Daytona Beach, FL 32118
Email: [email protected]
Inc.
govitrailerrefrigeration.com
GOVI Inc.
Inc.
GOVI Inc. (USA)
GOVI GmbH (Germany)

Installation Manual
Stationary Trailer Refrigeration Unit
Page 4 71.01.121 / 00
Copyright by GOVI GmbH 2013. The reproduction of this document or any part there of is prohibited! The right is reserved to make technical changes in the course of further development!
501 N. Grandview Avenue #135
Daytona Beach, FL 32118
Email: [email protected]
Inc.
govitrailerrefrigeration.com
GOVI Inc.
Inc.
GOVI Inc. (USA)
GOVI GmbH (Germany)

Installation Manual
Stationary Trailer Refrigeration Unit
71.01.121 / 00
Page 5
Copyright by GOVI GmbH 2013. The reproduction of this document or any part there of is prohibited! The right is reserved to make technical changes in the course of further development!
1 Introduction
GOVI provides this manual merely for informational purposes. GOVI has put in dili-
gent effort and due consideration to compile a manual of great help to you. Howev-
er, GOVI makes no representations warranties express or implied with respect to
the information, recommendations and descriptions contained in this manual. Infor-
mation provided in this manual should at no time be regarded as all-inclusive or
covering all contingencies. If you feel you need further information, please contact
and consult your GOVI Distributor.
GOVI‘s warranty shall not apply to any refrigeration unit which has been so in-
stalled, maintained, repaired or altered as, in the manufacturer‘s judgment, to affect
its integrity. Any change and alteration of this refrigeration unit and aviation from
the installation process without prior written permission will void GOVI‘s warranty.
GOVI does not accept any liability to any person or entity for personal injury of any
kind, property damage or any other direct, indirect, special, or consequential dam-
ages whatsoever, arising out of the use of this manual or deriving from any infor-
mation, recommendations or descriptions contained in this manual.
In order to ensure the durability of GOVI products, please follow the instructions of
this manual.
At GOVI, we recognize the need to preserve the environment and limit the potential
harm to the ozone layer that can result from allowing refrigerant to escape into the
atmosphere.
We therefore adopted a policy that promotes the recovery and limits the loss of re-
frigerant into the atmosphere. GOVI supplies refrigeration units fully charged with
sufficient refrigerant. The installation process poses only marginal risks of refriger-
ant leaks.
Dispose the refrigeration unit properly to keep the environment clean.
WARNING!
Do not dismantle the refrigeration unit yourself.
Only qualified, special trained specialists are allowed to dispose the refrigera-
tion unit. Refrigeration fluid must be handled with care as it poses serious
health hazards.
There are federal regulations and state regulations regarding the disposal of refrig-
eration machines. Consult professionals or specialists and make sure they follow all
federal and state regulations strictly when disposing of the refrigeration unit.
501 N. Grandview Avenue #135
Daytona Beach, FL 32118
Email: [email protected]
Inc.
govitrailerrefrigeration.com
GOVI Inc.
Inc.
GOVI Inc. (USA)
GOVI GmbH (Germany)

Installation Manual
Stationary Trailer Refrigeration Unit
Page 6 71.01.121 / 00
Copyright by GOVI GmbH 2013. The reproduction of this document or any part there of is prohibited! The right is reserved to make technical changes in the course of further development!
2 Safety Instructions
2.1 Safety Messages and Safety Alert Symbols
DANGER!
Indicates a hazardous situation that, if not avoided, will result in death or
serious injury.
WARNING!
Indicates a hazardous situation that, if not avoided, could result in death
or serious injury.
CAUTION!
Indicates a hazardous situation that, if not avoided, could result in minor
or moderate injury.
2.2 Not Hazard-related Messages
Notice indicate a not hazard-related message.
NOTICE
Indicates information considered important, but not hazard-related (e.g. mes-
sages related to property damage).
501 N. Grandview Avenue #135
Daytona Beach, FL 32118
Email: [email protected]
Inc.
govitrailerrefrigeration.com
GOVI Inc.
Inc.
GOVI Inc. (USA)
GOVI GmbH (Germany)

Installation Manual
Stationary Trailer Refrigeration Unit
71.01.121 / 00
Page 7
Copyright by GOVI GmbH 2013. The reproduction of this document or any part there of is prohibited! The right is reserved to make technical changes in the course of further development!
2.3 General Safety Precautions
WARNING!
The electrical connection must be accomplished by a licensed electri-
cian.
Unless you are a certified electrician, do not take the plug or receptacle apart.
Do not loosen any screws or cable glands of the plug and receptacle.
There is risk of electric shock causing property damage, serious personal injury
or death.
WARNING!
This refrigeration unit contains fluorocarbon refrigerants which, in the
presence of an open flame or electrical short, produce toxic gases that
are severe respiratory irritants capable of causing death.
Make sure there is no open fire (cigarette, gas heater, welding, electrical short)
in the place where you assemble the refrigeration unit onto a trailer.
WARNING!
Never install the unit while it is connected to electricity.
There is risk of electric shock. Any accidental contact with electricity could
cause serious personal injury or death.
WARNING!
Do not use a damaged cord, plug or loose socket.
There is risk of electric shock causing property damage, serious personal injury
or death.
WARNING!
Never apply heat to the refrigeration unit, because it could explode caus-
ing serious personal injury and death.
501 N. Grandview Avenue #135
Daytona Beach, FL 32118
Email: [email protected]
Inc.
govitrailerrefrigeration.com
GOVI Inc.
Inc.
GOVI Inc. (USA)
GOVI GmbH (Germany)

Installation Manual
Stationary Trailer Refrigeration Unit
Page 8 71.01.121 / 00
Copyright by GOVI GmbH 2013. The reproduction of this document or any part there of is prohibited! The right is reserved to make technical changes in the course of further development!
WARNING!
Be careful when working with a refrigerant or refrigeration system in any
enclosed or confined area with a limited air supply (i.e. a trailer, garage,
container or alike).
Refrigerant tends to displace air and can cause oxygen depletion which may
result in death by suffocation.
WARNING!
Do not remove the safety caps from the end of electrical harness.
Before you work on the electrical wiring, be sure to disconnect from power
supply by unplugging the main plug.
There is risk of electric shock causing death or serious injury.
WARNING!
Always use personal protective equipment.
Wear eye protection such as goggles or safety glasses. Refrigerant liquid and
refrigeration oil can permanently damage the eyes.
Wear appropriate hand protection such as work gloves. Exposed coil fins are
very sharp and can cause painful laceration and cuts.
Wear safety shoes. Due to its weight the refrigeration unit can cause painful
injuries when it falls down.
WARNING!
Keep your hands away from fans.
Accidental contact with the sharp edges of the fan blades can cause severe
personal injury.
WARNING!
Never drill holes into the refrigeration unit.
Holes drilled into the unit may weaken structural components.
Holes drilled into electrical wiring can cause fire or explosion.
Holes drilled into tubes and coils can cause a leak of refrigeration oil. Direct
contact with refrigeration oil can cause painful personal injuries.
501 N. Grandview Avenue #135
Daytona Beach, FL 32118
Email: [email protected]
Inc.
govitrailerrefrigeration.com
GOVI Inc.
Inc.
GOVI Inc. (USA)
GOVI GmbH (Germany)

Installation Manual
Stationary Trailer Refrigeration Unit
71.01.121 / 00
Page 9
Copyright by GOVI GmbH 2013. The reproduction of this document or any part there of is prohibited! The right is reserved to make technical changes in the course of further development!
WARNING!
Never attempt to plug in or unplug the refrigeration unit from the power
supply when your hands are wet.
There is risk of electric shock.
WARNING!
Avoid fires, electric shock, suffocation or cuts.
Always unplug the refrigeration unit before removing the main cover. Don’t pull
the power cord. Never use a power socket shared with other equipment. No
extension cords, 2- or 3-way adapters, etc. No heavy objects on the power
cord, no modifications, stretching or excessively bending. If damaged, call a
licensed electrician to have the power cord replaced.
No flammable sprays in the vicinity of refrigeration unit.
Leaking refrigerant tends to displace air and can cause oxygen depletion and
suffocation. Be especially careful in any enclosed or confined area with limited
air supply like a garage, container or building.
Moving parts like the fan have sharp edges. Don’t reach in!
WARNING!
There is a low-level magnetic field.
If you have a pacemaker and feel anything abnormal, step away quickly and
seek prompt medical attention.
NOTICE
Keep foreign objects and contaminants from entering. If any foreign object
(metal or liquid) has fallen in, disconnect from power by unplugging the main
plug. Then seek immediate technical support.
501 N. Grandview Avenue #135
Daytona Beach, FL 32118
Email: [email protected]
Inc.
govitrailerrefrigeration.com
GOVI Inc.
Inc.
GOVI Inc. (USA)
GOVI GmbH (Germany)

Installation Manual
Stationary Trailer Refrigeration Unit
Page 10 71.01.121 / 00
Copyright by GOVI GmbH 2013. The reproduction of this document or any part there of is prohibited! The right is reserved to make technical changes in the course of further development!
2.4 Safety Precautions concerning the refrigerant
Fluorocarbon refrigerants are classified as safe refrigerants, however you must ob-
serve certain precautions during the installation process. When released to the at-
mosphere in the liquid state, fluorocarbon refrigerants evaporate rapidly. This fast
evaporation freezes anything in contact with the liquid refrigerant instantaneously. In
contact with parts of the human body, it can cause severe frostbites.
2.4.1 First Aid
General provisions in case of frostbite
In the event of frostbite, you should generally protect the affected area from further
injury, warm the affected area but do not apply heat and observe and maintain res-
piration.
Frostbite of the eyes:
In case of contact with liquid refrigerant, immediately flush eyes with large amounts
of water and get prompt medical attention.
Frostbite of the skin:
Flush the affected area with large amounts of lukewarm water for a long time. Do
not apply heat. Remove contaminated clothing and shoes. Loosely bandage frost-
bite burns with dry, sterile, sizeable dressing to protect from infection or injury. Get
medical attention without delay. Wash contaminated clothing before wearing it
again.
2.4.2 Environmental considerations
There is no need to handle refrigerants in the installation process. In case of servic-
ing, service personnel must be aware of federal regulations concerning the use of
refrigerants and the certification of technicians. For additional information on regula-
tions and technician certification programs, contact your local GOVI dealer or in-
quire [e-mail].
GOVI refrigeration units and are shipped with a suitable charge of refrigerant
R452A and R134a. The refrigerant shall not be vented into the atmosphere. There
is risk of severe injuries upon contact with eyes or skin.
In case of fluid leaking out of the refrigeration unit, do not continue with the installa-
tion process. Contact your GOVI dealer for assistance immediately. The fluid may
contain substances that need special provisions for a clean environment and may
cause injury on contact with skin.
Please read and understand the safety sheet for R452A and R134a with the pro-
ducer‘s description in chapter 9.2 Safety data sheet.
501 N. Grandview Avenue #135
Daytona Beach, FL 32118
Email: [email protected]
Inc.
govitrailerrefrigeration.com
GOVI Inc.
Inc.
GOVI Inc. (USA)
GOVI GmbH (Germany)

Installation Manual
Stationary Trailer Refrigeration Unit
71.01.121 / 00
Page 11
Copyright by GOVI GmbH 2013. The reproduction of this document or any part there of is prohibited! The right is reserved to make technical changes in the course of further development!
3 Carriage, Transportation and Storage
For safe transportation the refrigeration unit is securely packed in a box mounted on
pallets.
Always use suitable equipment intended for this purpose.
Fig. 3 1 Carriage and transportation
The refrigeration unit is only to be carried horizontally.
Should the unit have been positioned vertically during transport, it must be allowed
to stand horizontally for a minimum of six hours before commissioning.
The refrigeration units are packed on pallets for transportation. Lift the refrigeration
unit according chapter 6.6 Attaching the refrigeration unit at the trailer.
The weight of the refrigeration unit is given in the chapter 4 Technical Data.
The unit is to be positioned horizontally during transportation.
When removing the packaging, bear in mind any loose parts which are an important
part of the supply.
The following points are to be borne in mind when storing the refrigeration unit:
• horizontal positioning
• no temperatures in excess of 140°F [60°C]
• do not store in aggressive atmospheres
• avoid direct sunlight
501 N. Grandview Avenue #135
Daytona Beach, FL 32118
Email: [email protected]
Inc.
govitrailerrefrigeration.com
GOVI Inc.
Inc.
GOVI Inc. (USA)
GOVI GmbH (Germany)

Installation Manual
Stationary Trailer Refrigeration Unit
Page 12 71.01.121 / 00
Copyright by GOVI GmbH 2013. The reproduction of this document or any part there of is prohibited! The right is reserved to make technical changes in the course of further development!
4 Technical Data
Fig. 4-1 Nameplate
You can find the serial number of the refrigeration unit and other important technical
data on the name plate located on the right hand side of the main cover next to the
receptacle.
To allow for a prompt and precise respond please always state the Serial Number of
the GOVI Refrigeration unit with any technical inquiry.
501 N. Grandview Avenue #135
Daytona Beach, FL 32118
Email: [email protected]
Inc.
govitrailerrefrigeration.com
GOVI Inc.
Inc.
GOVI Inc. (USA)
GOVI GmbH (Germany)

Installation Manual
Stationary Trailer Refrigeration Unit
71.01.121 / 00
Page 13
Copyright by GOVI GmbH 2013. The reproduction of this document or any part there of is prohibited! The right is reserved to make technical changes in the course of further development!
Fig. 4-2 Dimensions
501 N. Grandview Avenue #135
Daytona Beach, FL 32118
Email: [email protected]
Inc.
govitrailerrefrigeration.com
GOVI Inc.
Inc.
GOVI Inc. (USA)
GOVI GmbH (Germany)

Installation Manual
Stationary Trailer Refrigeration Unit
Page 14 71.01.121 / 00
Copyright by GOVI GmbH 2013. The reproduction of this document or any part there of is prohibited! The right is reserved to make technical changes in the course of further development!
Table 4-1 Technical data
Table 4-2 List of material
Designation Material
Structure Sheet metal, ferrous material
Condenser, evaporator Aluminium, copper
Electrical components Copper, PVC,
miscellaneous materials
Compressor Ferrous materials, copper and other
materials
Coating Epoxide compound
Designation
arktik 2000US arktik 2500US arktik 1500US/F
Refrigerated trailer internal
temperature T
A
=35,6°F [2°C] T
A
=35,6°F [2°C] T
A
=0°F [-18°C]
Supply voltage 115 V / 1 ~ Phase 115 V / 1 ~ Phase 220 V / 1 ~ Phase
Frequency 60 Hz 60 Hz 60 Hz
Refrigeration capacity 6845 BTU/h [2000 W] 7240 BTU/h [2120 W] 4720 BTU/h [1380 W]
Power consumption 1428 W 1207 W 1817 W
Current consumption LRA 70 A 59 A 39 A
FLA 15 A 15 A 8 A
Defrost Automatic hot gas defrost Automatic hot gas defrost Automatic electrical
Evaporator air flow 650 cfm [1100m³/h] 560 cfm [950m³/h] 560 cfm [950m³/h]
Condenser air flow 650 cfm [1100m³/h] 650 cfm [1100m³/h] 650 cfm [1100m³/h]
Protection class, mounting
side IP54 IP54 IP54
Refrigerant
(Chlorine:
zero – non ozone depleting)
R452A
R134a R452A
Refrigerant quantity 2,22 lbs [1,00kg] 1,33 lbs [0,6kg] 2,58 lbs [1,17kg]
Maximum operating
temperature 104°F [40°C] 104°F [40°C] 104°F [40°C]
Dimensions See Fig. 4-2 See Fig. 4-2 See Fig. 4-2
Weight 138 lbs [63kg] 122 lbs [55kg] 138 lbs [63kg]
Colour RAL9010 RAL9010 RAL9010
501 N. Grandview Avenue #135
Daytona Beach, FL 32118
Email: [email protected]
Inc.
govitrailerrefrigeration.com
GOVI Inc.
Inc.
GOVI Inc. (USA)
GOVI GmbH (Germany)

Installation Manual
Stationary Trailer Refrigeration Unit
71.01.121 / 00
Page 15
Copyright by GOVI GmbH 2013. The reproduction of this document or any part there of is prohibited! The right is reserved to make technical changes in the course of further development!
5 System Description arktik 2000US / arktik 2500US
1 Compressor 4 Expansion valve 7 Hot gas solenoid valve (arktik 2000US only)
2 Condenser fan 5 Evaporator fan 8 Hot gas defrost solenoid valve
3
Condenser 6 Evaporator 9 Filter drier / liquid receiver
Fig. 5-1 Functional schematic
The refrigeration unit is intended for utilization in refrigerated trailers in which tem-
peratures from
10°F to 50°F (arktik 2000US)
32°F to 50°F (arktik 2500US)
10°F to 0°F (arktik 1500US/F) are required.
Operation is based on the cooling cycle principle in that heat transference is by
means of a refrigerant which absorbs heat in the evaporator and then releases this
in the condenser. All this takes place within a closed loop. The refrigerant is pres-
surized by an electrically driven compressor, fluidized in the condenser, atomized
by means of a throttle valve and evaporated in the evaporator. The evaporator is lo-
cated inside the trailer, the condenser on the outside.
The refrigeration unit is equipped with forced-ventilated condenser and evaporator
and fitted with axial fans; the unit has electronic temperature control.
The refrigeration unit consists of a self-supporting, powder coated, sheet metal
chassis and an ABS front cover.
501 N. Grandview Avenue #135
Daytona Beach, FL 32118
Email: [email protected]
Inc.
govitrailerrefrigeration.com
GOVI Inc.
Inc.
GOVI Inc. (USA)
GOVI GmbH (Germany)

Installation Manual
Stationary Trailer Refrigeration Unit
Page 16 71.01.121 / 00
Copyright by GOVI GmbH 2013. The reproduction of this document or any part there of is prohibited! The right is reserved to make technical changes in the course of further development!
1 Main cover 4 Air intake
(Do not obstruct!)
2 Evaporator
(with refrigerant in the system)
5 Air outlet
(Do not obstruct!)
3 Protection cover
Fig. 5-2 Overview of refrigeration unit
501 N. Grandview Avenue #135
Daytona Beach, FL 32118
Email: [email protected]
Inc.
govitrailerrefrigeration.com
GOVI Inc.
Inc.
GOVI Inc. (USA)
GOVI GmbH (Germany)

Installation Manual
Stationary Trailer Refrigeration Unit
71.01.121 / 00
Page 17
Copyright by GOVI GmbH 2013. The reproduction of this document or any part there of is prohibited! The right is reserved to make technical changes in the course of further development!
Main cover (1)
The main cover (1) covers the outer parts of the refrigeration
unit.
Evaporator (2)
(with refrigerant
in the system)
The refrigerant is a liquid gas used inside the pipes of a refriger-
ating unit. Refrigerants usually need special attention in han-
dling. This refrigeration unit works with a hermetic piping system.
Under normal conditions there is no need to recharge refriger-
ant. Some States may have statutory provisions and regulations
for disposal of refrigerants. Make sure you know and follow
these statutory provisions and regulations when changing or
disposing of refrigerants.
Protection
cover and
Target tem-
perature
The protection cover (3) is a cover that opens like a window. The
lid window shields the control unit from harsh weather and im-
pedes unintended changes of the settings. You need a turn
spanner (included in delivery) to open the lid.
See chapter 7 Commissioning for further information.
Air intake (4) Do not obstruct air intake!
Air outlet (5) Do not obstruct air outlet!
501 N. Grandview Avenue #135
Daytona Beach, FL 32118
Email: [email protected]
Inc.
govitrailerrefrigeration.com
GOVI Inc.
Inc.
GOVI Inc. (USA)
GOVI GmbH (Germany)

Installation Manual
Stationary Trailer Refrigeration Unit
Page 18 71.01.121 / 00
Copyright by GOVI GmbH 2013. The reproduction of this document or any part there of is prohibited! The right is reserved to make technical changes in the course of further development!
6 Installation
WARNING!
Avoid serious injury, malfunction or damage to the refrigeration unit.
Only qualified, experienced mechanics who also know and understand electri-
cal installations and electrical circuitry as well as necessary safety measures
are allowed to install the refrigeration unit.
WARNING!
Do not remove the main cover during the installation process.
Accidental contact with tubes may damage the refrigeration system. Leaking
refrigerant from damaged pipes may cause serious injuries to eyes and skin by
chemical burn. There is also the risk of electric shock leading to personal injury
or death.
WARNING!
Refrigeration oil contains toxic substances, which may cause harm on
contact.
In case of a damaged refrigeration unit, refrigeration oil may leak.
Avoid refrigeration oil contact with the eyes and prolonged or repeated contact
of refrigeration oil with skin or clothing.
In case of eye contact, immediately flush with plenty of water and seek prompt
medical attention.
In case of skin contact wash skin with soap and plenty of water and seek
prompt medical attention.
Wash contaminated clothing before reuse.
NOTICE
Pay attention to each step in the installation process.
Altering the process may lead to damage to the trailer or personal injury.
501 N. Grandview Avenue #135
Daytona Beach, FL 32118
Email: [email protected]
Inc.
govitrailerrefrigeration.com
GOVI Inc.
Inc.
GOVI Inc. (USA)
GOVI GmbH (Germany)

Installation Manual
Stationary Trailer Refrigeration Unit
71.01.121 / 00
Page 19
Copyright by GOVI GmbH 2013. The reproduction of this document or any part there of is prohibited! The right is reserved to make technical changes in the course of further development!
6.1 Conditions for installation
Before starting the installation:
1. Read this Installation Manual to understand how the unit is mounted and in-
stalled.
2. Verify that the refrigeration unit is delivered according to your order. Compare
the description on the unit with the order confirmation.
3. Verify by eye sight the unit is in good condition and has no damages.
4. Verify all necessary tools, all gear, all special equipment and all additionally re-
quired parts according to chapter 6.2 Required tools, equipment and safety
gear are readily available at hand and in good operating condition.
5. Verify that the trailer is designed and built for refrigeration applications with in-
sulated walls, ceilings and floors. All doors must close and seal tightly.
6. Verify the front wall of the trailer is able to adequately support the weight of the
refrigeration unit. Additional supports may be required.
7. Provide protection to the trailer‘s finish to prevent damage by swarf and alike
during the installation process.
8. Verify meticulously all measurements before cutting or drilling any mounting
holes in the trailer.
9. Verify there is no interference with any OEM electrical wiring, internal supports,
etc. before cutting and drilling any mounting holes in the trailer.
10. Leave clearances for carrying out maintenance; see also chapter 4 Technical
Data.
11. Install all components with correct hardware and tighten securely.
12. Route electrical harnesses orderly and secure it with band wraps or clamps.
13. Route the drain hoses correctly with no kinks or sharp bends to provide for
proper drainage.
14. Make sure to have a lifting device for safely lifting approximately 180 lbs
(80 kg).
Depending on operating conditions, individual cautionary measures may be neces-
sary for the application.
501 N. Grandview Avenue #135
Daytona Beach, FL 32118
Email: [email protected]
Inc.
govitrailerrefrigeration.com
GOVI Inc.
Inc.
GOVI Inc. (USA)
GOVI GmbH (Germany)

Installation Manual
Stationary Trailer Refrigeration Unit
Page 20 71.01.121 / 00
Copyright by GOVI GmbH 2013. The reproduction of this document or any part there of is prohibited! The right is reserved to make technical changes in the course of further development!
6.2 Required tools, equipment and safety gear
WARNING!
All tools, equipment and safety gear must be in good working condition.
NOTICE
Use calibrated scale and lever to assure accurate readings.
Ear protection
Helmet
Protective eye wear
Safety shoes
Work gloves
Drill
Drill bits
File
Installation manual
501 N. Grandview Avenue #135
Daytona Beach, FL 32118
Email: [email protected]
Inc.
govitrailerrefrigeration.com
GOVI Inc.
Inc.
GOVI Inc. (USA)
GOVI GmbH (Germany)
