DK_USB2.0_GW2AR-LV18QN88PC7I6_GW
1NSR-LV4CMG64PC7I6_V3.0
User Guide
DBUG408-1.0E, 07/15/2022

Copyright © 2022 Guangdong Gowin Semiconductor Corporation. All Rights Reserved.
is a trademark of Guangdong Gowin Semiconductor Corporation and is registered
in China, the U.S. Patent and Trademark Office, and other countries. All other words and
logos identified as trademarks or service marks are the property of their respective holders.
No part of this document may be reproduced or transmitted in any form or by any denotes,
electronic, mechanical, photocopying, recording or otherwise, without the prior written
consent of GOWINSEMI.
Disclaimer
GOWINSEMI assumes no liability and provides no warranty (either expressed or implied)
and is not responsible for any damage incurred to your hardware, software, data, or
property resulting from usage of the materials or intellectual property except as outlined in
the GOWINSEMI Terms and Conditions of Sale. GOWINSEMI may make changes to this
document at any time without prior notice. Anyone relying on this documentation should
contact GOWINSEMI for the current documentation and errata.

Revision History
Date
Version
Description
07/15/2022
1.0E
Initial version published.

Contents
DBUG408-1.0E
i
Contents
Contents ...............................................................................................................i
List of Figures....................................................................................................iii
List of Tables......................................................................................................iv
1 About This Guide.............................................................................................1
1.1 Purpose .............................................................................................................................. 1
1.2 Related Documents ............................................................................................................1
1.3 Terminology and Abbreviations........................................................................................... 1
1.4 Support and Feedback ....................................................................................................... 2
2 Development Board Introduction ...................................................................3
2.1 Overview.............................................................................................................................3
2.2 A Development Board Kit....................................................................................................4
2.3 PCB Components ............................................................................................................... 6
2.4 System Block Diagram ....................................................................................................... 6
2.5 Features..............................................................................................................................7
3 Development Board Circuit ............................................................................8
3.1 FPGA Module .....................................................................................................................8
3.2 Download Module ............................................................................................................... 8
3.2.1 Introduction ......................................................................................................................8
3.2.2 Pinout............................................................................................................................... 9
3.3 Power Supply....................................................................................................................10
3.3.1 Introduction ....................................................................................................................10
3.4 Clock and Reset ...............................................................................................................10
3.4.1 Introduction ....................................................................................................................10
3.4.2 Pinout............................................................................................................................. 11

Contents
DBUG408-1.0E
ii
3.5 USB 2.0 interface.............................................................................................................. 11
3.5.1 Introduction .................................................................................................................... 11
3.5.2 Pinout............................................................................................................................. 11
3.6 GPIO .................................................................................................................................13
3.6.1 Introduction ....................................................................................................................13
3.6.2 Pinout.............................................................................................................................14
3.7 LED Module ......................................................................................................................15
3.7.1 Introduction ....................................................................................................................15
3.7.2 Pinout.............................................................................................................................15
3.8 Keys Module .....................................................................................................................15
3.8.1 Introduction ....................................................................................................................15
3.8.2 Pinout.............................................................................................................................16

List of Figures
DBUG408-1.0E
iii
List of Figures
Figure 2-1 DK_USB2.0_GW2AR-LV18QN88PC8I7_GW1NSR-LV4CMG64PC7I6_ V3.0 Development
Board.................................................................................................................................................. 3
Figure 2-2 A Development Board Suite ............................................................................................. 5
Figure 2-3 PCB Components.............................................................................................................6
Figure 2-4 System Block Diagram ..................................................................................................... 6
Figure 3-5 Connection Diagram of FPGA Download and Configuration ...........................................9
Figure 3-6 Connection Diagram of Clock and Reset ......................................................................... 10
Figure 3-7 Connection Diagram of FPGA and USB 2.0 Interface .....................................................11
Figure 3-8 Connection Diagram of GPIO........................................................................................... 13
Figure 3-9 Connection Diagram of LED............................................................................................. 15
Figure 3-10 Key Circuit ......................................................................................................................16

List of Tables
DBUG408-1.0E
iv
List of Tables
Table 1-1 Terminology and Abbreviations ..........................................................................................2
Table 3-5 FPGA-GW2AR-LV18QN88P Download and Configuration Pinout ....................................9
Table 3-6 FPGA-GW1NSR-LV4CMG64P Download and Configuration Pinout ................................ 9
Table 3-7 GW1NSR-LV4CMG64P Clock and Reset Pinout ..............................................................11
Table 3-8 GW2AR-LV18QN88P Clock and Reset Pinout .................................................................. 11
Table 3-9 GW1NSR-LV4CMG64P USB 2.0 Module Pinout............................................................... 11
Table 3-10 GW2AR-LV18QN88P USB 2.0 Module Pinout ................................................................ 12
Table 3-11 GW1NSR-LV4CMG64P GPIO Pinout .............................................................................. 14
Table 3-12 GW2AR-LV18QN88P GPIO Pinout..................................................................................14
Table 3-13 GW1NSR-LV4CMG64P LED Pinout ................................................................................ 15
Table 3-14 GW2AR-LV18QN88P LED Pinout....................................................................................15
Table 3-15 GW1NSR-LV4CMG64P Keys Module Pinout ..................................................................16
Table 3-16 GW2AR-LV18QN88P Key Module Pinout ....................................................................... 16

1 About This Guide
1.1 Purpose
DBUG408-1.0E
1(16)
1About This Guide
1.1 Purpose
DK_USB2.0_GW2AR-LV18QN88PC8I7_GW1NSR-LV4CMG64PC7I6
_V3.0 development board (hereinafter referred to development board) user
guide consists of following three parts:
1. A brief introduction to the features of the development board;
2. An introduction to the development board system architecture and
hardware resources;
3. An introduction to the functions, circuits, and pinouts of each module.
1.2 Related Documents
The latest user guides are available on the GOWINSEMI Website. You
can find the related documents at www.gowinsemi.com:
1. DS226, GW2AR series of FPGA Products Data Sheet
2. UG115, GW2AR-18 Pinout
3. UG229, GW2AR series of FPGA Products Package and Pinout User
Guide
4. DS861, GW1NSR series of FPGA Products Data Sheet
5. UG864, GW1NSR-4 Pinout
6. UG863, GW1NSR series of FPGA Products Package and Pinout User
Guide
1.3 Terminology and Abbreviations
The terminology and abbreviations used in this manual are as shown
in Table 1-1.

1 About This Guide
1.4 Support and Feedback
DBUG408-1.0E
2(16)
Table 1-1 Terminology and Abbreviations
Terminology and Abbreviations
Meaning
BSRAM
Block Static Random Access Memory
DDR
Double-Data-Rate Synchronous Dynamic
Random Access Memory
DSP
Digital Signal Processing
FLASH
Flash Memory
FPGA
Field Programmable Gate Array
GPIO
Gowin Programmable I/O
LDO
Low Dropout Regulator
LUT4
4-input Look-up Table
LVDS
Low-Voltage Differential Signaling
SSRAM
Shadow Static Random Access Memory
1.4 Support and Feedback
Gowin Semiconductor provides customers with comprehensive
technical support. If you have any questions, comments, or suggestions,
please feel free to contact us directly by the following ways.
Website: www.gowinsemi.com
E-mail: [email protected]

2 Development Board Introduction
2.1 Overview
DBUG408-1.0E
3(16)
2Development Board Introduction
2.1 Overview
Figure 2-1 DK_USB2.0_GW2AR-LV18QN88PC8I7_GW1NSR-LV4CMG64PC7I6_
V3.0 Development Board
DK_USB2.0_GW2AR-LV18QN88PC8I7_GW1NSR-LV4CMG64PC7I6
_V3.0 development board can apply to USB 2.0 communication, USB
communication test, the function evaluation of GW1NSR-4C and
GW2AR-18 series of FPGA, hardware reliability verification, and software
learning and debugging.
The development board uses Gowin GW2AR-LV18QN88P FPGA
products, which are the first generation products of the Arora family. As a

2 Development Board Introduction
2.2 A Development Board Kit
DBUG408-1.0E
4(16)
kind of SIP chips, GW2AR series of FPGA products offer a range of
features and rich resources like high-performance DSP, high-speed LVDS
interface and abundant BSRAM resources. These embedded resources
combine a streamlined FPGA architecture with a 55nm process to make
the GW2AR series of FPGA products ideal for high-speed and low-cost
applications.
The development board uses Gowin GW1NSR-LV4CMG64P FPGA
products, which are the first generation products of the LittleBee® family. As
a kind of SIP chips, GW1NSR-LV4MG64P chip integrates GW1NS series
of FPGA products and PSRAM chips. The GW1NSR series of products
include GW1NSR-2C and GW1NSR-2 devices. GW1NSR-2C devices are
embedded with ARM Cortex-M3 hard-core processor. In addition, the
GW1NSR series of FPGA products are also embedded with USB2.0PHY,
user flash, and ADC.
The development board equipped with a USB-PHY chip supports
480Mbps high-speed (HS) and 12Mbps full-speed (FS) communication; the
GW2AR-LV18QN88P is externally connected to FLASH chip to store the
FPGA configuration program; keys and LEDs are convenient for user
debugging.
2.2 A Development Board Kit
The development board suite includes the following items:
1. DK_USB2.0_GW2AR-LV18QN88PC8I7_GW1NSR-LV4CMG64PC7I6
_V3.0 development board
2. 5V power (input: AC 100-240V~50/60Hz 25VA, output: DC 5V 2A)
3. USB Mini B Cable

2 Development Board Introduction
2.2 A Development Board Kit
DBUG408-1.0E
5(16)
Figure 2-2 A Development Board Suite
1
2 3
①DK_Motor_GW2A-LV55PG484C8I7_V3.0 development board
②USB Mini B data cable
③5V power (Input: 100-240V~50/60Hz 0.5A, Output: DC 5V 2A)

2 Development Board Introduction
2.3 PCB Components
DBUG408-1.0E
6(16)
2.3 PCB Components
Figure 2-3 PCB Components
Power:
5V IN
GPIOFPGA
1.8V/3.3V
1.0V
Key
JTAGOSC
MODE
USB2.0
USB2.0
Flash
JTAG Key
FPGA OSCGPIO 1.2V
2.4 System Block Diagram
Figure 2-4 System Block Diagram
GW2AR-
LV8QN88PC8I7
GW1NSR-
LV4CMG64PC7I6
USB2.0
USB2.0
LED KEY CLK
LED KEY CLK
JTAG
FLASH
JTAG
IO
IO
5V，3.3V，
1.8V，1.2V，
1.0V

2 Development Board Introduction
2.5 Features
DBUG408-1.0E
7(16)
2.5 Features
The key features are as follows:
1. The FPGA device
Gowin GW2AR-LV18QN88P, GW1NSR-LV4CMG64P
Max. user I/O : 66, 55
2. Download and Boot
Integrate download module on the board, download through JTAG
cable
Flash boot
After loading, boot board.
3. Power
External DC 5V 2A
The green POWER light is on after power on
The development board generates 5V, 3.3V, 1.8V, 1.2V, 1.0V, and
1.0V
4. Clock system
12MHz crystal oscillator input
5. Memory Device
64Mbit FLASH
6. USB 2.0 interface
One USB 2.0 interface communicates with GW2AR-LV18QN88P
One USB 2.0 interface communicates with GW1NSR-LV4CMG64P
7. GPIO Interface
GPIO interface, enable communication with peripherals.
8. Debug
Two keys
Two green LEDs
Note!
Each FPGA chip connects to one key and one LED.

3 Development Board Circuit
3.1 FPGA Module
DBUG408-1.0E
8(16)
3Development Board Circuit
3.1 FPGA Module
Overview
For the resources of GW2AR FPGA products, please refer to DS226,
GW2AR Series of FPGA Products.
For the resources of GW1NSR FPGA products, please refer to DS861,
GW1NSR Series of FPGA Products.
I/O BANK Introduction
For the I/O BANK, package, and pinout information, see UG229,
GW2AR Series of FPGA Products Package and Pinout User Guide for
more details.
For the I/O BANK, package, and pinout information, see UG863,
GW1NSR Series of FPGA Products Package and Pinout User Guide for
more details.
3.2 Download Module
3.2.1 Introduction
The development board provides a JTAG download interface. You can
set the MODE value to download the programs to the on-chip SRAM or
external Flash. When downloaded to SRAM, the bitstream file will be lost if
the device is power down. When downloaded to Flash, the bitstream file
will not be lost if the device powers down.
The MODE value configuration is as follows:
1. In any mode, you can download the bitstream file to the on-chip SRAM
and run it immediately.

3 Development Board Circuit
3.2 Download Module
DBUG408-1.0E
9(16)
2. Set MODE as "011" to download the bitstream file to the external Flash.
Set MODE to "000" and power on again. The device will read the FPGA
configuration data from the Flash automatically.
The connection diagram of download and configuration is as shown in
Figure 3-1.
Figure 3-1 Connection Diagram of FPGA Download and Configuration
FLASH_SPI_MISO
FLASH_SPI_MOSI
FLASH_SPI_CS_N
FLASH_SPI_CLK
JTAG_TCK
JTAG_TDO
JTAG_TDI
JTAG_TMS
JTAG
Interface
Configuration
FLASH
3.2.2 Pinout
Table 3-1 FPGA-GW2AR-LV18QN88P Download and Configuration Pinout
Signal Name
FPGA Pin No.
BANK
I/O Level
Description
F2_TCK
6
2
1.8V
JTAG Signal
F2_TDO
8
2
1.8V
JTAG Signal
F2_TDI
7
2
1.8V
JTAG Signal
F2_TMS
5
2
1.8V
JTAG Signal
MSPI_DO
62
3
3.3V
Configure
FLASH Signal
MSPI_DI
61
3
3.3V
Configure
FLASH Signal
MSPI_CS
60
3
3.3V
Configure
FLASH Signal
MSPI_CK
59
3
3.3V
Configure
FLASH Signal
Table 3-2 FPGA-GW1NSR-LV4CMG64P Download and Configuration Pinout
Signal Name
FPGA Pin No.
BANK
I/O Level
Description
F1_TCK
D3
0
3.3V
JTAG Signal
F1_TDO
E3
0
3.3V
JTAG Signal

3 Development Board Circuit
3.3 Power Supply
DBUG408-1.0E
10(16)
Signal Name
FPGA Pin No.
BANK
I/O Level
Description
F1_TDI
E2
0
3.3V
JTAG Signal
F1_TMS
D2
0
3.3V
JTAG Signal
3.3 Power Supply
3.3.1 Introduction
The development board is powered via a power adapter. The input
parameter is 100-240V~50/60MHz 25VA, and the output is DC +5V 2A.
The input 5V power can generate 3.3V, 1.8V, 1.2V, and 1.0V via the
power supply chip on the development board.
Use two FP6165ADXR-G1 power chips to generate 1.2V and 1.0V
power, and the maximum output current is 3A.
Use one PAM2306AYPAA DC-DC power chip to generate 3.3V and
1.8V power, and the maximum output current is 1A.
3.4 Clock and Reset
3.4.1 Introduction
The development board offers a 12MHz oscillator connecting to the
global clock pins and 8.192MHz IIS clock for
FPGA-GW1NSR-LV4CMG64P at the same time.
The development board offers a 12MHz oscillator connecting to the
global clock pins and 8.192MHz IIS clock for FPGA-GW2AR-LV18QN88P
at the same time.
The development board resets through the key, and press the key to
reset FPGA after power up.
Figure 3-2 Connection Diagram of Clock and Reset
KEY1
12MHz
RST_N
CLK_G

3 Development Board Circuit
3.5 USB 2.0 interface
DBUG408-1.0E
11(16)
3.4.2 Pinout
Table 3-3 GW1NSR-LV4CMG64P Clock and Reset Pinout
Signal Name
FPGA Pin No.
BANK
I/O Level
Description
F1_CLK
C5
1
3.3V
12MHz crystal oscillator input
F1_IIS_CLK
C4
1
3.3V
8.192MHz
F1_RST_N
A5
1
3.3V
Reset Signal, active Low
Table 3-4 GW2AR-LV18QN88P Clock and Reset Pinout
Signal Name
FPGA Pin No.
BANK
I/O Level
Description
F2_CLK
10
6
3.3V/2.5V
12MHz crystal oscillator
input
F2_IIS_CLK
35
4
3.3V
8.192MHz
F2_RST_N
19
6
3.3V/2.5V
Reset Signal, active-low
3.5 USB 2.0 interface
3.5.1 Introduction
USB 2.0 interface is directly connected to FPGA through configuration
resistor. The connection diagram is as shown in Figure 3-3.
Figure 3-3 Connection Diagram of FPGA and USB 2.0 Interface
PULLIP
USB_D-_CN
USB_D+_CP
USB_TERM_P
USB_D-_CP
USB_TERM_N
USB_D-
USB_D+
USB_D+_CN RC Circuit USB2.0
D+
D-
VBUS_DETECT
3.5.2 Pinout
Table 3-5 GW1NSR-LV4CMG64P USB 2.0 Module Pinout
Signal Name
FPGA Pin No.
BANK
I/O Level
Description
1N_Pullip
G6
2
3.3V
Pull-up
USB_1N_D+_CP
G7
2
3.3V
USB+ signal
USB_1N_D+/-_CN
H7
2
3.3V
USB+ Reference

3 Development Board Circuit
3.5 USB 2.0 interface
DBUG408-1.0E
12(16)
Signal Name
FPGA Pin No.
BANK
I/O Level
Description
signal
USB_1N_D-_CP
G3
2
3.3V
USB- signal
USB_1N_D+/-_CN
H3
2
3.3V
USB- Reference signal
1N_Term_p
G5
2
3.3V
Terminal resistance
control at high speed,
USB data pin at full
speed and low speed
1N_Term_n
H5
2
3.3V
Terminal resistance
control at high speed,
USB data pin at full
speed and low speed
USB_1N_D+
G4
2
3.3V
USB high speed data
pin
USB_1N_D-
H4
2
3.3V
USB high speed data
pin
VBUS_DETECT_1N
G2
2
3.3V
VBUS disconnect
detection to reset USB
Table 3-6 GW2AR-LV18QN88P USB 2.0 Module Pinout
Signal Name
FPGA Pin No.
BANK
I/O Level
Description
2A_Pullip
80
0
3.3V
Pull-up
USB_2A_D+_CP
77
1
3.3V
USB+ signal
USB_2A_D+/-_CN
76
1
3.3V
USB+ Reference signal
USB_2A_D-_CP
71
1
3.3V
USB- signal
USB_2A_D+/-_CN
70
1
3.3V
USB- Reference signal
2A_Term_p
75
1
3.3V
Terminal resistance
control at high speed,
USB data pin at full
speed and low speed
2A_Term_n
74
1
3.3V
Terminal resistance
control at high speed,
USB data pin at full
speed and low speed
USB_2A_D+
73
1
3.3V
USB high speed data
pin
USB_2A_D-
72
1
3.3V
USB high speed data
pin
VBUS_DETECT_2A
83
0
3.3V
VBUS disconnect
detection to reset USB

3 Development Board Circuit
3.6 GPIO
DBUG408-1.0E
13(16)
3.6 GPIO
3.6.1 Introduction
There are 40 GPIOs reserved on the development board, including
eight 3.3V pins, four ground pins, fourteen GW1NSR-LV4CMG64P pins,
and fourteen GW2AR-LV18QN88P pins. The connection diagram is as
shown in Figure 3-4.
Figure 3-4 Connection Diagram of GPIO
GPIO0
GPIO1
GPIO2
GPIO3
GPIO4
GPIO5
GPIO6
GPIO7
GPIO8
GPIO9
Pin
Header
GPIO10
GPIO11
GPIO12
GPIO13
