GPX PD909B User manual

USER’S GUIDE
V:1211-0409-09
PD909B
9” Portable DVD Player
For the most up-to-date version of this User’s Guide, go to www.gpx.com
█CONTENTS
WARNINGS AND PRECATIONS 2
PRODUCT INFORMATION 4
IN THE BOX .........................................................................................................4
FEATURES............................................................................................................4
POWERING THE UNIT 5
AC/DC ADAPTER ................................................................................................5
DC CAR ADAPTER..............................................................................................5
RECHARGEABLE BATTERY PACK..................................................................5
OPERATIONS 6
PLAYING A DVD .................................................................................................6
PROGRAMMING A DVD....................................................................................6
OPERATIONS 7
PLAYING A CD ....................................................................................................7
PROGRAMMING A CD .......................................................................................7
SETUP MENU 8
LANGUAGE SETTINGS .....................................................................................8
VIDEO SETTINGS ...............................................................................................8
AUDIO SETTINGS...............................................................................................8
SETUP MENU 9
RATING SETTINGS .............................................................................................9
SYSTEM SETTINGS............................................................................................9
CONTROLS 10
CONTROL GLOSSARY 11
CONTROLS 12
CONTROL GLOSSARY 13
CONTROLS 14
CONTROL GLOSSARY 15
COMPANY INFORMATION 16
GREEN INITIATIVE ..........................................................................................16
INTERNATIONAL SUPPORT ...........................................................................16
SERVICE INFORMATION.................................................................................16
PD909B.indd 1 4/9/2009 12:11:09 PM

• CAUTION: TO PREVENT ELECTRIC
SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT, FULLY INSERT.
• WARNING:Topreventreorshock
hazards,donotexposethisunittorainor
moisture.
• CAUTION:Useofcontrolsoradjustments
orperformanceofproceduresotherthan
thosespeciedmayresultinhazardous
radiationexposure.
• WARNING:Changesormodications
tothisunitnotexpresslyapprovedbythe
partyresponsibleforcompliancecouldvoid
theuser’sauthoritytooperatetheequip-
ment.
• WARNING:Donotplacetheunitontop
ofanysoft,porous,orsensitivesurfacesto
avoiddamagingthesurface.Useaprotec-
tivebarrierbetweentheunitandsurfaceto
protectthesurface.
• WARNING:Useofthisunitnearuores-
centlightingmaycauseinterferenceregard-
inguseoftheremote.Iftheunitisdisplay-
ingerraticbehaviormoveawayfromany
uorescentlighting,asitmaybethecause.
Thelightningashwitharrowhead
symbol,withinanequilateraltriangle,
isintendedtoalerttheusertothe
presenceofuninsulated"dangerous
voltage"withintheproduct'senclosure
thatmaybeofsufcientmagnitudeto
constituteariskofelectricshockto
persons.
Theexclamationpointwithinan
equilateraltriangleisintendedtoalert
theusertothepresenceofimportant
operatingandmaintenance(servicing)
instructionsintheliteratureaccompa-
nyingtheappliance.
WARNING: TO REDUCE THE RISK
OF ELECTRIC SHOCK, DO NOT
REMOVECOVER(ORBACK).
NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
ThisproductutilizesaClass1lasertoreadCompactDiscs.ThislaserCompactDiscPlayerisequippedwithsafety
switchestoavoidexposurewhentheCDdoorisopenandthesafetyinterlocksaredefeated.Invisiblelaserradia-
tionispresentwhentheCDPlayer’slidisopenandthesystem’sinterlockhasfailedorbeendefeated.Itisvery
importantthatyouavoiddirectexposuretothelaserbeamatalltimes.Pleasedonotattempttodefeatorbypassthe
safetyswitches.
• CAUTION: Dangerofexplosionifbattery
isincorrectlyreplaced.Replaceonlywith
thesameorequivalenttype.
• PRÉCAUTION: Danger d’explosion si les
piles sont remplacées de façon incorrect.
Remplacer les piles seulement par le même
type de pile ou l’équivalent.
• WARNING:Thereisadangerofexplosion
ifyouattempttochargestandardAlkaline
batteriesintheunit.Onlyuserechargeable
NiMHbatteries.
• WARNING:Theremotecontrol’sbutton
cellbatterycontainsmercury.Donotputin
thetrash,insteadrecycleordisposeofas
hazardouswaste
• WARNING: Lithiumionbatteries,likeall
rechargeablebatteriesarerecyclableand
shouldberecycledordisposedofinnormal
householdwaste.Contactyourlocalgov-
ernmentfordisposalorrecyclingpractices
inyourarea.Theyshouldneverbeinciner-
atedsincetheymightexplode.
Donotmixoldandnewbatteries.
Donotmixalkaline,standard(carbon-
zinc),orrechargeable(ni-cad,ni-mh,etc)
batteries.
No mezcle baterías viejas y nuevas.
No mezcle baterías alcalinas, estándar
(carbono-zinc) o recargables (ni-cad, ni-
mh, etc.).
WARNINGS AND PRECATIONS
PD909B.indd 2 4/9/2009 12:11:09 PM

1. ReadtheseInstructions.
2. KeeptheseInstructions.
3. HeedallWarnings.
4. Followallinstructions.
5. Donotusethisapparatusnearwater.
6. Cleanonlywithadrycloth.
7. Donotblockanyventilationopenings.Installin
accordancewiththemanufacturer’sinstructions.
8. Donotinstallnearanyheatsourcessuchasradiators,heat
registers,stoves,orotherapparatus(includingampliers)
thatproduceheat.
9. Donotdefeatthesafetypurposeofthepolarizedor
grounding-typeplug.Apolarizedplughastwoblades
withonewiderthantheother.Agroundingtypeplughas
twobladesandathirdgroundingprong.Thewideblade
orthethirdprongareprovidedforyoursafety.Whenthe
providedplugdoesnottintoyouroutlet,consultan
electricianforreplacementoftheobsoleteoutlet.
10. Protectthepowercordfrombeingwalkedonorpinched
particularlyatplugs,conveniencereceptacles,andthe
pointwheretheyexitfromtheapparatus.
11. Onlyuseattachments/accessoriesspeciedbythe
manufacturer.
12. Useonlywithacart,stand,tripod,bracket,ortable
speciedbythemanufacturer,orsoldwiththeapparatus.
Whenacartisused,usecautionwhenmovingthecart/
apparatuscombinationtoavoidinjuryfromtip-over.
13. Unplugthisapparatusduringlightningstormsorwhen
unusedforlongperiodsoftime.
14. Referallservicingtoqualiedservicepersonnel.
Servicingisrequiredwhentheapparatushasbeen
damagedinanyway,suchaspower-supplycordorplug
isdamaged,liquidhasbeenspilledorobjectshavefallen
intotheapparatus,theapparatushasbeenexposedto
rainormoisture,doesnotoperatenormally,orhasbeen
dropped.
Additional Warnings
• Theapparatusshallnotbeexposedtodrip-
pingorsplashingandthatnoobjectslled
withliquids,suchasvases,shallbeplacedon
apparatus.
L'appareil ne doit pas être exposé aux écoule-
ments ou aux éclaboussures et aucun objet ne
contenant de liquide, tel qu'un vase, ne doit être
placé sur l'objet.
• Mainplugisusedasdisconnectdeviceandit
shouldremainreadilyoperableduringintended
use.Inordertodisconnecttheapparatusfrom
themainscompletely,themainsplugshould
bedisconnectedformthemainssocketoutlet
completely.
La prise du secteur ne doit pas être obstruée
ou doit être facilement accessible pendant son
utilisation. Pour être complètement déconnecté
de l'alimentation d'entrée, la prise doit être
débranchée du secteur.
• Batteryshallnotbeexposedtoexcessiveheat
suchassunshine,reorthelike.
Les piles ne doivent pas être exposées à de forte
chaleur, tel qu'à la lumière du soleil, au feu ou
autres choses de semblable.
• Cautionmarkingislocatedatthebottomof
apparatus.
Les précautions d'emploi sont inscrites en bas
de l'appareil.
• Themarkinginformationislocatedatthebot-
tomofapparatus.
Les marquages sont inscrits en bas de
l'appareil.
FCC Warnings
NOTE:Thisequipmenthasbeentestedand
foundtocomplywiththelimitsforaClassB
digitaldevice,pursuanttoPart15oftheFCC
Rules.Theselimitsaredesignedtoprovide
reasonableprotectionagainstharmfulinterfer-
enceinaresidentialinstallation.Thisequip-
mentgenerates,uses,andcanradiateradio
frequencyenergyand,ifnotinstalledandused
inaccordancewiththeinstructions,maycause
harmfulinterferencetoradiocommunications.
However,thereisnoguaranteethatinterference
willnotoccurinaparticularinstallation.If
thisequipmentdoescauseharmfulinterference
toradioortelevisionreception,whichcanbe
determinedbyturningtheequipmentoffand
on,theuserisencouragedtotrytocorrectthe
interferencebyoneormoreofthefollowing
measures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipment
andreceiver.
• Connecttheequipmentintoanoutletona
circuitdifferentfromthattowhichthereceiver
isconnected.
• Consultthedealeroranexperiencedradio/TV
technicianforhelp.
IMPORTANT SAFETY INSTRUCTIONS
PD909B.indd 3 4/9/2009 12:11:09 PM

4
PRODUCT INFORMATION
█IN THE BOX
PD909B
AC/DC Adapter
DC Car Adapter
OnesetofEarbuds
Remote Control
CarryingCase
CarryingCaseStrap
Documentation
█FEATURES
9”Display
DiscCompatibility:DVD±RW,CD,
CD-R/RW,JPEGPhotoCD
DolbyDigitalReady
CompositeVideoOutput
CoaxialDigitalAudioOutput
StereoAudioOutput
HeadphoneJack
Multi-AngleVideoPlayback
PD909B.indd 4 4/9/2009 12:11:09 PM

5
POWERING THE UNIT
█AC/DC ADAPTER
PlugtheincludedAC/DCAdapterintoa
standardACpowersourcetopowerthe
unit.
█DC CAR ADAPTER
PlugtheDCCarAdapterintoacarlighter
orDCcarpowersourcetopowertheunit.
█RECHARGEABLE BATTERY PACK
Attachtheincludedbatterypacktothe
backoftheunittopoweritonthego.
WhentheunitispluggedintoanAC
orDCpowersource,theconnected
rechargeablebatterywillcharge.
PD909B.indd 5 4/9/2009 12:11:10 PM

6
OPERATIONS
█PLAYING A DVD
1. PresstheOpen Buttontoopenthedisc
door.
2. LoadaDVDintotheunitandclosethe
discdoor.
The DVD should start playing
automatically.
• PressthePlay/Pause Buttontoplaythe
loadedDVDiftheDVDdoesn’tstart
playingautomatically.
• PresstheStop ButtontostopaDVD
duringplay.
• PressthePrev/NextButtonstoskip
betweenchaptersonaloadedDVD.
• PressandholdtheFWD/REVButtonsto
searchanindividualchapteronaloaded
DVD.
█PROGRAMMING A DVD
1. LoadaDVDintotheunitandclosethe
discdoor.
The DVD should start playing
automatically.
• PressthePlay/Pause Buttontoplaythe
loadedDVDiftheDVDdoesn’tstart
playingautomatically.
2. PresstheProgram Buttonwhilethe
maintitleoftheloadedDVDisplaying.
3. UsetheDirectional Buttonstoselecta
titleandpresstheEnter Button.
4. UsetheDirectional Buttonstoselecta
chapterandpresstheEnter Button.
5. Repeatsteps3and4tosetselectedtitles
andchapterstoplayinnumericalorder.
6. Afterthedesiredtitlesandchaptershave
beenprogrammed,pressthePlay Button
tobeginplayingtheprogrammedDVD.
PD909B.indd 6 4/9/2009 12:11:13 PM

7
OPERATIONS
█PLAYING A CD
1. PresstheOpen Buttontoopenthedisc
door.
2. LoadaCDintotheunitandclosethedisc
door.
The CD should start playing
automatically.
• PressthePlay/Pause Buttontoplaythe
loadedCDiftheCDdoesn’tstartplaying
automatically.
• PresstheStop ButtontostopaCD
duringplay.
• PressthePrev/NextButtonsonthe
remotetoskipbetweentracksonaloaded
CD.
• PressandholdtheFWD/REVButtons
tosearchanindividualtrackonaloaded
CD.
█PROGRAMMING A CD
1. LoadaCDintotheunitandclosethedisc
door.
The CD should start playing
automatically.
• PressthePlay/Pause Buttontoplaythe
loadedCDiftheCDdoesn’tstartplaying
automatically.
2. UsetheDirectional Buttonstohighlight
theon-screenEdit Mode Buttonandpress
theEnter Button.
3. UsetheDirectional Buttonstohighlight
thedesiredtracks,andpresstheEnter
Button.
Repeat step 3 until the desired tracks are
checked.
4. UsetheDirectional Buttonstohighlight
theon-screenAdd to Program Button,
andpresstheEnter Button.
5. UsetheDirectional Buttonstohighlight
theon-screenProgram View Button, and
presstheEnter Button.
6. PressthePlay Buttontobeginplaying
theprogrammedtracks.
PD909B.indd 7 4/9/2009 12:11:16 PM

8
SETUP MENU
PresstheSetupButtontoentertheSetupMenu.
█LANGUAGE SETTINGS
OSDLanguage
Subtitles
AudioLanguage
DVDMenuLanguage
█VIDEO SETTINGS
SmartPictureSettings
PD909B.indd 8 4/9/2009 12:11:18 PM

9
SETUP MENU
PresstheSetupButtontoentertheSetupMenu.
█SYSTEM SETTINGS
AspectRatio
TVSystem
UseDefaultSettings
█AUDIO SETTINGS
DigitalOutputSettings
PD909B.indd 9 4/9/2009 12:11:21 PM

10
CONTROLS
4
3
2
1
5
9
8
11
10
7
6
12
16
15
20
19
13
14
17
18
21
PD909B.indd 10 4/9/2009 12:11:22 PM

11
CONTROL GLOSSARY
01. Mute Button
PresstheMuteButtontomutethevolume
oftheunit.
02. Zoom Button
PresstheZoomButtonrepeatedlyto
zoominonamovieduringplay.
03. L/R Button
PresstheL/RButtoncyclethroughthe
loadedDVD’savailableaudiooptions.
04. DVD Door
05. Open Button
PresstheOpenButtontoopentheDVD
Door.
06. Audio Output
UsetheAudioOutputtoconnecttheunit
toaTelevisionorAudioSystem.
07. Coaxial Audio Output
UsetheCoaxialAudioOutputtoconnect
theunittoanAudioSystemforhigh
qualityaudiooutput.
08. Power Switch
AdjustthePowerSwitchtoturntheunit
offandon.
09. DC Power Input
UsetheDCPowerInputtoconnectthe
unittoapowersource.
10. Receiver for Remote
11. Power Indicator
12. Setup Button
PresstheSetupButtontoentertheSetup
Menu.
13. Title Button
PresstheTitleButton,inStop Mode, to
gototheDVD’stitlemenu.
14. A-B Repeat Button
PresstheA-B Button to repeat a
speciedsectionofaDVD.Pressonce
tocreateastartingpoint(A),andpressa
secondtimetocreateanendingpoint(B).
PresstheA-B Buttonathirdtimetoturn
theABRepeatFunctionoff.
15. Menu Button
PresstheMenuButtontoreturntothe
DVD’smainmenu.
16. Stop Button
PresstheStopButtontostopaDVDor
CDduringplay.
17. Play/Pause Button
PressthePlay/PauseButtontoplayor
pausealoadedDVDorCD.
18. Prev/Next Buttons
PressthePrev/NextButtonstoskip
betweenchaptersortracksonaloaded
DVD or CD.
PresstheRev/FwdButtonstosearchan
individualchapterortrackonaloaded
DVD or CD.
Directional Buttons
UsetheDirectionalButtonstonavigatea
loadedDVDorCDmenu,ortonavigate
theunit’ssetupmenu.
Enter Button
PresstheEnterButtontomakeselections
onaloadedDVD,CD,ortheunit’ssetup
menu.
19. Video Output
UsetheVideoOutputtooutputvideo
fromtheunittoatelevisionorexternal
display.
20. Headphone Jack
UsetheHeadphoneJacktoconnectaset
ofheadphonesorearbudstotheunit.
21. Volume Dial
PD909B.indd 11 4/9/2009 12:11:22 PM

12
CONTROLS
WIDE
23 30
31
32
33
29
25
26
27
28
22
24
PD909B.indd 12 4/9/2009 12:11:22 PM

13
CONTROL GLOSSARY
22. Angle Button
PresstheAngleButtontoadjusttheangle
on a loaded DVD.
Not all DVDs support the Angle Function.
23. OSD Button
PresstheOSDButtontoviewtheon-
screendisplay.
24. Number Keypad
25. Directional Buttons
UsetheDirectionalButtonstonavigatea
loadedDVDorCDmenu,ortonavigate
theunit’ssetupmenu.
Return Button
PresstheReturnButtonaftermarking
alocationonaloadedDVDtoreturnto
thatmarkedlocation.
26. Mark Button
PresstheMarkButtontomarkthecurrent
locationonaDVD.PresstheReturn
Buttontoreturntothemarkedlocation.
27. Wide Button
PresstheWideButtontoswitchbetween
4:3and16:9aspectratios.
28. Mute Button
PresstheMuteButtontomutetheunit’s
volume.
29. L/R Button
PresstheL/RButtoncyclethroughthe
loadedDVD’savailableaudiooptions.
30. Subtitle Button
PresstheSubtitleButtontocyclethrough
thesubtitleoptionsavailableonthe
loaded DVD.
Not all DVDs support the Angle Function.
31. Zoom Button
PresstheZoomButtonrepeatedlyto
zoominonamovieduringplay.
32. Setup Button
PresstheSetupButtontoaccesstheSetup
Menu.
33. Menu Button
PresstheMenuButtontoreturntothe
DVD’smainmenu.
PD909B.indd 13 4/9/2009 12:11:22 PM

14
CONTROLS
WIDE
37
38
40
39
41
42
43
35
36
34
PD909B.indd 14 4/9/2009 12:11:23 PM

15
34. Repeat Button
PresstheRepeatButton
35. Title Button
PresstheTitleButton,inStop Mode, to
gototheDVD’stitlemenu.
36. A-B Repeat Button
PresstheA-B Button to repeat a
speciedsectionofaDVD.Pressonce
tocreateastartingpoint(A),andpressa
secondtimetocreateanendingpoint(B).
PresstheA-B Buttonathirdtimetoturn
theABRepeatFunctionoff.
37. Search Button
PresstheSearchButtontosearchfora
speciclocationonaloadedDVD.
38. Play Button
PressthePlayButtontoplayaloaded
DVD or CD.
39. Program Button
PresstheProgramButtontoprograma
DVDorCDtoplaychaptersandtracksin
aparticularorder.
40. Stop Button
PresstheStopButtontostopaDVDor
CDduringplay.
41. Pause/Step Button
PressthePauseButtontopauseaDVDor
CDduringplay.
PresstheStepButtonafteraloadedDVD
hasbeenpausedtostepthroughtheDVD
oneframeatatime.
CONTROL GLOSSARY
42. Slow Button
PresstheSlowButtontoviewtheloaded
DVDinslowmotion.
43. Prev/Next Buttons
PressthePrev/NextButtonstoskip
betweenchaptersortracksonaloaded
DVD or CD.
Rev/Fwd Buttons
PresstheRev/FwdButtonstosearchan
individualchapterortrackonaloaded
DVD or CD.
PD909B.indd 15 4/9/2009 12:11:23 PM

COMPANY INFORMATION
©2009DigitalProductsInternational(DPI,Inc.)|Allothertrademarksappearinghereinarethepropertyoftheir
respectiveowners.Specicationsaresubjecttochangewithoutnotice
█INTERNATIONAL SUPPORT
TodownloadthisUser’sGuideinEnglish,Spanish,orFrench,visitthesupportsectionat
www.gpx.com.
Paratransferirestaguíadeusuarioeninglés,español,ofrancés,visitelaseccióndela
ayudaenwww.gpx.com.
Pourtéléchargerceguidedel’utilisateurenanglais,espagnol,oufrançais,visitezla
sectiondesoutienchezwww.gpx.com.
█SERVICE INFORMATION
Address:2116CarrStreet,St.LouisMO,63106
Phone:1-314-621-2881
Fax:1-314-588-1805
Email:[email protected]
PartsEmail:[email protected]
Website:www.gpx.com
PD909B.indd 16 4/9/2009 12:11:23 PM
