GPX PD951R User manual
USER’S GUIDE
V: 601-01
PD951R Portable DVD Player
Introduction and Setup
BACKLIT MENU SOURCESTOP
180
CHARGE
VOL +
VOL
AV OUT ON OFF
DC IN 9-12V
Menu
Press to access
the DVD menu.
Backlight
Press to turn the
backlight on or o.
LCD Display
Play/Pause
Press to pause or
play a loaded disc.
Press to make
selections in
the menu.
Disc Door
Arrows
Press to navigate
on-screen menus.
Open
Press to open
the Disc Door.
Power
Adjust to turn the
power on or o.
DC Power Input
Stereo Headphone
Jack
Audio/Video Output
Warning: Changes or modications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
• The apparatus shall not be exposed to dripping or splashing and that no
objects lled with liquids, such as vases, shall be placed on apparatus.
L’appareil ne doit pas être exposé aux écoulements ou aux éclaboussures et aucun
objet ne contenant de liquide, tel qu’un vase, ne doit être placé sur l’objet.
• Main plug is used as disconnect device and it should remain readily operable during
intended use. In order to disconnect the apparatus from the mains completely, the
mains plug should be disconnected form the mains socket outlet completely.
La prise du secteur ne doit pas être obstruée ou doit être facilement
accessible pendant son utilisation. Pour être complètement déconnecté de
l’alimentation d’entrée, la prise doit être débranchée du secteur.
• Battery shall not be exposed to excessive heat such as sunshine, re or the like.
Les piles ne doivent pas être exposées à de forte chaleur, tel qu’à la
lumière du soleil, au feu ou autres choses de semblable.
• Caution marking is located at the rear or bottom of the apparatus.
Attention marquage est situé sur le paneau arrière ou inférieur de l’unité.
• The marking information is located at the rear or bottom of apparatus.
Le marquage est situé sur le paneau arrière ou inférieur de l’unité.
1. Read these Instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized
or grounding - type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong are
provided for your safety. When the provided plug
does not t into your outlet, consult an electrician
for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. Only use attachments/accessories
specied by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table
specied by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury
from tip-over. Unplug this apparatus during lightning
storms or when unused for long periods of time.
13. Refer all servicing to qualied
service personnel. Servicing
is required when the apparatus
has been damaged in any way,
such as power-supply cord or
plug is damaged, liquid has been
spilled or objects have fallen
into the apparatus, the apparatus
has been exposed to rain or
moisture, does not operate
normally, or has been dropped.
• CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
• WARNING:To reduce the risk of re or electric shock, do
not expose this apparatus to rain or moisture.
• AVERTISSEMENT: Pour réduire le risque d’incendie ou de choc
électrique, ne pas exposer cet appareil sous la pluie et l’humidité.
• CAUTION: Use of controls or adjustments or performance of procedures
other than those specied may result in hazardous radiation exposure.
• WARNING: Changes or modications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
• WARNING: Do not place the unit on top of any soft, porous, or sensitive surfaces to avoid
damaging the surface. Use a protective barrier between the unit and surface to protect the surface.
• WARNING: Use of this unit near uorescent lighting may cause interference
regarding use of the remote. If the unit is displaying erratic behavior move
away from any uorescent lighting, as it may be the cause.
• CAUTION:Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
• PRÉCAUTION: Danger d’explosion si les piles sont remplacées de façon incorrect.
Remplacer les piles seulement par le même type de pile ou l’équivalent.
• WARNING: There is a danger of explosion if you attempt to charge standard
Alkaline batteries in the unit. Only use rechargeable NiMH batteries.
• WARNING: The remote control’s button cell battery contains mercury. Do
not put in the trash, instead recycle or dispose of as hazardous waste
• WARNING:Lithium batteries, like all rechargeable batteries are recyclable and should be
recycled or disposed of in normal household waste. Contact your local government for disposal
or recycling practices in your area. They should never be incinerated since they might explode.
• WARNING: Shock hazard - Do Not Open.
• AVIS: RISQUE DE CHOC ÉLECTRIQUE - NE PAS OUVRIR
Mains plug is used as disconnect device and it should remain readily operable during
intended use. In order to disconnect the apparatus from the mains completely, the
mains plug should be disconnected form the mains socket outlet completely.
La prise du secteur est utilisé pour déconnecter le système.
La prise du secteur ne doit pas être obstruée ou doit être facilement
accessible pendant son utilisation. Pour être complètement déconnecté de
l’alimentation d’entrée, la prise doit être débranchée du secteur.
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or rechargeable (ni-cad, ni-mh, etc) batteries.
No mezcle baterías viejas y nuevas.
No mezcle baterías alcalinas, estándar (carbono-zinc) o recargables (ni-cad, ni-mh, etc.).
WARNING: TO REDUCE THE RISK
OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
ATTENTION
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
This symbol indicates that this product
incorporates double insulation between hazardous
mains voltage and user accessible parts.
The lightning ash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufcient magnitude to
constitute a risk of electric shock to persons.
IMPORTANT SAFETY INSTRUCTIONS
FCC Warnings
Additional Warnings
WARNINGS AND PRECAUTIONS
This product utilizes a Class 1 laser to read Compact Discs. This laser Compact Disc Player is equipped with safety
switches to avoid exposure when the CD door is open and the safety interlocks are defeated. Invisible laser radiation is
present when the CD Player’s lid is open and the system’s interlock has failed or been defeated. It is very important that you
avoid direct exposure to the laser beam at all times. Please do not attempt to defeat or bypass the safety switches.
For Warranty Information and the most up-to-date version of this User’s Guide, go to www.gpx.com Customer Service: 1-888-999-4215
Copyright © 2012 Digital Products International (DPI, Inc.) All other trademarks appearing herein are the property of their respective owners. Specications are subject to change without notice.
Mode
OSD
Number Keypad
Program
Create a
program to
play chapters
or tracks in a
specied order
Repeat
Search
Arrows/Enter
Zoom
FF/Rew
Play/Pause
Stop
Mute
Source
Setup
Setup menu
Menu
Main DVD menu
Title
Subtitle
Audio
Angle
Step
Slow
Skip
Volume
USB Port
SD/MMC Card
Reader
Volume
Press to adjust
the volume.
Skip/Rew/FF
Press to skip forward
or backward.
Press and hold to fast
forward or rewind.
Source
Press to switch
between DVD and
Media mode.
Stop
Press to stop a
disc during play.
1. Press the Open button to open the Disc
Door.
2. Load a disc into the portable DVD player,
label side facing up.
3. Close the Disc Door.
After a disc is loaded, it will begin playing
automatically.
• Remote control: requires 2 AAA
batteries (included)
• 3.5mm to RCA audio adapter
• Two sets of stereo earbuds
• Carrying bag
• Headphone splitter
• AC/DC power adapter
• 12V DC car adapter
DVD and CD
Loading a Disc
To download this User’s Guide in English, Spanish,
or French, or to get answers to frequently
asked questions, visit the support section at:
www.gpx.com
Para descargar este Manual del Usuario en
inglés, español y francés, o para obtener
respuestas a preguntas frecuentes,
visite la sección de apoyo en
www.gpx.com
Pour télécharger ce guide de l’utilisateur en
anglais, espagnol ou français, ou pour obtenir
des réponses à des questions fréquemment
posées, consultez la rubrique d’assistance sur
www.gpx.com
International Support
1. Follow the instructions for Loading a Disc.
2. If the disc does not begin playing
automatically, press the Play/Pause
button.
Playing a Loaded Disc
1. Follow the instructions for Loading a Disc
and Playing a Loaded Disc.
2. While the loaded disc is playing, press the
Program button on the remote.
3. Use the Arrow buttons to select a
program slot.
4. Use the Number Keypad to enter in the
chapter and title, or track.
Titles and chapters, or tracks will play in
the order they are listed.
5. Repeat step 3 until the desired titles and
chapters, or tracks are programmed.
6. Use the Arrow buttons to highlight the
on-screen PLAY button. Press the Enter
button to begin playing the programmed
disc.
Programming a Loaded Disc
Requires a 3.5mm to 3 x RCA audio/video
adapter (included) and an RCA audio/
video cable (not included).
1. Connect the 3.5mm to 3 x RCA audio/
video adapter to the AV Output on the
unit.
2. Connect the RCA audio/video cable to the
3.5mm to 3 x RCA audio/video adapter
and the RCA stereo audio inputs and
composite video input on a television.
3. Audio and video played through the
portable DVD player will now be output
through the connected television.
Using the 3.5mm Audio/Video
Audio/Video Output
DC power input: requires an AC/DC adapter
(included)
AVOUT ON OFF
DCIN 9-12V
Power
Requires a CR2025 battery (pre-installed)
LITHIUM BATTERY
CR 2025
3V
CR2025
PUSH
OPEN
Remote
DC battery power: built-in rechargeable battery
Battery Power
1. Plug the included AC/DC power adapter
into the DC Power Input on the portable
DVD player and an AC power outlet.
2. Adjust the Power switch to the off
position.
It is recommended to charge the unit fully
before initial use.
The Battery Indicator will display a red
light when the unit is charging, and a
green light when the unit is fully charged
Charging the Built-in Battery
Setup
Includes
1. Press and hold the Setup button to
access the setup menu.
Accessing the Setup Menu
Setup Menu
For Warranty Information and the most up-to-date version of this User’s Guide, go to www.gpx.com Customer Service: 1-888-999-4215
Copyright © 2012 Digital Products International (DPI, Inc.) All other trademarks appearing herein are the property of their respective owners. Specications are subject to change without notice.
1. Connect a SD or MMC memory card to
the Memory Card Slot.
Supports: JPEG, MP3, MPEG1, and
MPEG2
Memory Card Slot
Connecting a Memory Card
1. Follow the instructions for Connecting a
Memory Card.
2. Press the Source button on the remote
and press the Arrow and Play/Pause
buttons to switch to Media mode.
3. Use the Arrow and Play/Pause buttons
to select SD or MMC.
4. Use the Arrow and Play/Pause buttons
to select and play content from the
connected SD or MMC memory card.
Connecting a Memory Card
1. Connect a USB Thumb Drive to the USB
Port.
Supports: JPEG, MP3, MPEG1, and
MPEG2
USB Port
Connecting a USB Thumb Drive
1. Follow the instructions for Connecting a
USB Thumb Drive.
2. Press the Source button on the remote
and press the Arrow and Play/Pause
buttons to switch to Media mode.
3. Use the Arrow and Play/Pause buttons
to select USB.
4. Use the Arrow and Play/Pause buttons
to select and play content from the
connected Media thumb drive.
Accessing Content on a USB Drive
Other GPX Portable DVD Player manuals
