GRA & AFCH Divergence Meter NCS3 Series User manual

NCS3XX NIXIE CLOCK SHIELD FOR
ARDUINO
OPERATING INSTRUCTION
2036
Release 1.98
GRA & AFCH

G E N E R A L G U I D E
1. Press “Mode” to change from mode to mode. Each mode is explained in detail on the following
pages.
T I M E K EE P I N G M O D E
T o s e t th e t i m e
1. Hold down “Mode” while in the Timekeeping Mode until the hours digits start to flash. The hours
flash because they are selected.
2. Press “Mode” to change the selection in the following sequence:
Once you reach the Timekeeping display, you have to hold down “Mode” again to display flashing
hours.
While the digits are selected (flashing), hold down “Mode” to return to Timekeeping Mode without
saving.
3. While any digits are selected, press “Up” to increase the number, or “Down” to decrease the
number. Holding down “Up” or “Down” changes the current selection at high speed.
4. After you set the time, press “Mode” to select the Timekeeping Mode.
If you do not operate any button for a few minutes while selection is flashing, the flashing stops
and the clock goes back to the Timekeeping Mode automatically.
D A T E M O D E
T o s e t t h e d a t e
1. Hold down “Mode” while in the Date Mode until the all digits start to flash.
2. Press “Mode” to change selection in following sequence:
3. While the digits are selected (flashing), hold down “Mode” to return to Timekeeping Mode without
saving.
4. Press “UP” or “Down” button to switch between dd/mm (31/12/99) format and mm/dd
(12/31/99) format.
While any digits are selected, press “Up” to increase the number, or “Down” to decrease the
number. Holding down “Up” or “Down” changes the current selection at high speed.
5. After you set the date, press “Mode” to select the Date Mode.
If you do not operate ant button for a few minutes while a selection is flashing, the flashing stops
and clock goes back to the Date Mode automatically.
The clock does make validation for correct date. So clock not to return to Date Mode if date is
incorrect.
Time Date Alarm 12/24
Time mode
TemperatureTime Zone*Night Mode

A L A R M M O D E
When the Daily Alarm Function is switched on, the alarm sounds at the preset time each day.
Press any button to stop the alarm after it starts to sound.
To set the alarm time
1. Hold down “Mode” while in Alarm Mode until the hour digits start to flash. The hour digits flash
because they are selected.
2. Press “Mode” to change selection in the following sequence.
3. Press “Up” or “Down” buttons to increase or decrease selected digits. Holding down buttons
changes the selections at high speed.
4. Daily alarm on/off mode is representing by upper separate dots, press “Up” or “Down” to enable
or disable daily alarm.
Entering in Alarm Mode always switch daily alarm on.
If you do not operate any buttons a few minutes while a selection is flashing, the flashing stops
and the clock goes to the Timekeeping Mode.
1 2 / 24 H o ur s Mo d e
T o c h a n g e 1 2 / 2 4 m o d e
1. Enter in 12/24 mode settings, by holding down “Mode” button until 12 or 24 digits start to flash.
2. Press “Up” or “Down” buttons to switch between 12 and 24 modes.
3. After you set time format press “Mode” button to return to Timekeeping mode.
If you do not operate any buttons a few minutes while a selection is flashing, the flashing stops
and the clock goes to the Timekeeping Mode
T e m p e ra t u r e Mo d e
T o c h a n g e t h e t e m p e r a t u r e f o r m a t f r o m C e l s i u s t o F a h r e n h e i t a n d v i c e
v e r s a .
1. Select Temperature Mode, pressing the mode button several times...
2. Enter in temperature mode settings, by holding down “Mode” button until digits start to flash.
3. Press “Up” or “Down” buttons to switch between Celsius and Fahrenheit formats.
4. Press “Mode” button to save settings and return to Temperature mode.
T i m e z o n e *
T o c h a n g e T i m e z on e f r o m - 1 2 t o + 1 4
1. Select Time zone mode, pressing the mode button several times (default value is +02).
2. Press “Up” to increase the number, or “Down” to decrease the number.
3. For negative values, the top (or right) dots is turned off.
4. Press “Mode” button to save settings and return to Time zone mode.
* Time Zone Mode available only with Arduino Mega, and it is used together with an external GPS
receiver GA-6.

web-site: www.gra-afch.com
N i g ht Mo d e
Night mode allows you to set the daily tubes and LED backlight shutdown time (hour) and the
daily tubes and RGB backlight activation time (hour). The night mode activation and deactivation
times are set exclusively in the 24-hour format. When the clock is in night mode, pressing any button
will exit the night mode. When configuring the night mode, the digits 01 are displayed on tubes 5
and 6 –OFF:ON:01
A c c e s s o ri e s
Any additional accessories must be connected only when the clock is turned off.
GPS Receiver (GA-6): It doesn't require any setup except specifying the time zone (Menu #6). It
is supported only by Arduino Mega-based clocks. During the initial startup, the GPS receiver may take
up to an hour to determine the precise time. Subsequently, time synchronization occurs every 30
minutes. For reliable GPS reception, the receiver should be placed in a location with a clear view of
the sky. Also, make sure that the connector is fully inserted.
Remote Controller (RM-X153): It doesn't require any setup. For clocks in an opaque case, an
external IR receiver is required. Direct line of sight with the IR receiver (built-in or external) is required
for proper operation. The remote control uses only three buttons: UP, DOWN, MODE, and their
functions are identical to the buttons on the clock. The remote control periodically requires replacing
the CR2025 battery.
Temperature Sensor (DS18B20): It doesn't require any setup. Like any other accessory, it must
be connected before turning on the clock.
R G B L E D B a c kl i g h t
T o d i sa b l e L ED b a c k l ig h t
Hold down “Down” until the LED backlight turns off.
T o e n a b l e L E D b a c k l i g h t
Hold down “Up” until the LED backlight turns on.
T o f i x c o l o r o f L E D s
Press “Down” button.
T o r e s u m e a u t o m a t i c L E D s c o l o r c h a n g i n g
Pres “Up” button.
P O W E R O N S E LF T E S T
Immediately after a clock is powered on Self-Test is starting in the following sequence:
1. Red LEDs on.
2. Green LEDs on.
3. Blue LEDs on.
4. Tubes test which display all digits from 0 to 9 on all tubes simultaneously.
5. Firmware version.
6. Sound test.
