Graco C Series Parts list manual

05771B
Instructions – Parts
HEAVY-DUTY STAINLESS STEEL
Drum Agitators 308609V
Heavy-duty, back-geared agitator for mixing and maintaining suspension of industrial
coatings stored in 55-gallon drums. For professional use only.
100 psi (0.7 MPa, 7 bar) Maximum Working Pressure
See page 3 for model information and approvals.
Important Safety Instructions
Read all warnings and instructions in this
manual before using the equipment.
Save these instructions.
EN
Model 231414 shown

2308609V
Contents
Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Related Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Assemble and Position the Agitator . . . . . . . . . . . 7
Install With or Without an Elevator . . . . . . . . . . . . 7
Install an In-Drum Heavy Duty Back Geared Agitator
8
Install the Siphon Kit . . . . . . . . . . . . . . . . . . . . . . 8
Return Tube Kit 238884 (Accessory) . . . . . . . . . . 9
Air Requirements . . . . . . . . . . . . . . . . . . . . . . . . . 9
Air Line Accessories. . . . . . . . . . . . . . . . . . . . . . . 9
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Find the Proper Agitator Speed . . . . . . . . . . . . . 10
Pressure Relief Procedure . . . . . . . . . . . . . . . . . 10
Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Flush the Air Motor. . . . . . . . . . . . . . . . . . . . . . . 11
Lubricate the Air Motor. . . . . . . . . . . . . . . . . . . . 11
Agitator Blades. . . . . . . . . . . . . . . . . . . . . . . . . . 11
Clean the Agitator Shaft and Seal . . . . . . . . . . . 12
Clean an Agitator with a Siphon Kit . . . . . . . . . . 12
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Service the Gear Reducer . . . . . . . . . . . . . . . . . 13
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Heavy-Duty Stainless Steel Agitator, Model 238157
16
Heavy-Duty Stainless Steel Agitator with Siphon Kit,
Model 240209 . . . . . . . . . . . . . . . . . . . . . . . 16
Siphon Kit, Model 238250 . . . . . . . . . . . . . . . . . 16
Heavy-Duty Stainless Steel Agitator, Drum
Mounted, Models 24C293 and 24C522 . . . . 18
Non-Siphon Agitator Package, Model 231413 . . 20
Technical Specifications . . . . . . . . . . . . . . . . . . . . 21
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Heavy-Duty Stainless Steel Agitator. . . . . . . . . . 22
Siphon Kit, Model 238250 . . . . . . . . . . . . . . . . . 22
Mounting Hole Layout . . . . . . . . . . . . . . . . . . . . . . 23
California Proposition 65 . . . . . . . . . . . . . . . . . . . . 23
Graco Standard Warranty. . . . . . . . . . . . . . . . . . . . 24

Models
308609V 3
Models
Related Manuals
Part Series Description Agency Approvals
238157 C Back-Geared, Air-Powered Agitator
24C293
24C522 BBack-Geared, Drum Mounted, Air-Powered
Agitator
240209 C Back-Geared, Air-Powered Siphon Agitator
231413 A Non-Siphon Agitator Package
231414 A Siphon Agitator Package
238250 A Siphon Tube Kit ---
II 1/2 G Ex h IIB T4 Ga/Gb
ITS03ATEX11226X
ITS21UKEX0224X
2575 0359
Manuals in English Description
306287 Elevators and Pump Supports Instructions-Parts List
308466 Stainless Steel, Passivated Drum Covers Instructions-Parts List
406358 Return Tube Kit (238884) Instructions
3A4792 Air-Driven Agitators Instructions

Warnings
4308609V
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The
exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks.
When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings.
Product-specific hazard symbols and warnings not covered in this section may appear throughout the body of this
manual where applicable.
WARNING
FIRE AND EXPLOSION HAZARD
Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. Paint or solvent
flowing through the equipment can cause static sparking. To help prevent fire and explosion:
• Use equipment only in well ventilated area.
• Eliminate all ignition sources; such as pilot lights, cigarettes, portable electric lamps, and plastic drop
cloths (potential static arc).
• Ground all equipment in the work area. See Grounding instructions.
• Never spray or flush solvent at high pressure.
• Keep work area free of debris, including solvent, rags, and gasoline.
• Do not plug or unplug power cords, or turn power or light switches on or off when flammable fumes
are present.
• Use only grounded hoses.
• Hold gun firmly to side of grounded pail when triggering into pail. Do not use pail liners unless they
are antistatic or conductive.
• Stop operation immediately if static sparking occurs or you feel a shock. Do not use equipment until
you identify and correct the problem.
• Keep a working fire extinguisher in the work area.
MOVING PARTS HAZARD
Moving parts can pinch, cut or amputate fingers and other body parts.
• Keep clear of moving parts.
• Do not operate equipment with protective guards or covers removed.
• Do not wear loose clothing, jewelry or long hair while operating equipment.
• Equipment can start without warning. Before checking, moving, or servicing equipment, follow the
Pressure Relief Procedure and disconnect all power sources.
SPECIAL CONDITIONS FOR SAFE USE
• Electrostatic charging hazard. Clean surfaces with a damp cloth and read instructions for additional
techniques to mitigate risk of electrostatic discharge.
• The Ambient Temperature Range of each agitator depends on the air motor included in the assembly.
Refer to Models and Technical Specifications in Instruction manual for additional information.

Warnings
308609V 5
WARNING
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
• Do not operate the unit when fatigued or under the influence of drugs or alcohol.
• Do not exceed the maximum working pressure or temperature rating of the lowest rated system
component. See Technical Specifications in all equipment manuals.
• Use fluids and solvents that are compatible with equipment wetted parts. See Technical
Specifications in all equipment manuals. Read fluid and solvent manufacturer’s warnings. For
complete information about your material, request Safety Data Sheets (SDSs) from distributor or
retailer.
• Do not leave the work area while equipment is energized or under pressure.
• Turn off all equipment and follow the Pressure Relief Procedure when equipment is not in use.
• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine
manufacturer’s replacement parts only.
• Do not alter or modify equipment. Alterations or modifications may void agency approvals and create
safety hazards.
• Make sure all equipment is rated and approved for the environment in which you are using it.
• Use equipment only for its intended purpose. Call your distributor for information.
• Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.
• Do not kink or over bend hoses or use hoses to pull equipment.
• Keep children and animals away from work area.
• Comply with all applicable safety regulations.
TOXIC FLUID OR FUMES HAZARD
Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin, inhaled, or
swallowed.
• Read Safety Data Sheets (SDSs) to know the specific hazards of the fluids you are using.
• Store hazardous fluid in approved containers, and dispose of it according to applicable guidelines.
PERSONAL PROTECTIVE EQUIPMENT
Wear appropriate protective equipment when in the work area to help prevent serious injury, including
eye injury, hearing loss, inhalation of toxic fumes, and burns. Protective equipment includes but is not
limited to:
• Protective eyewear, and hearing protection.
• Respirators, protective clothing, and gloves as recommended by the fluid and solvent manufacturer.

Installation
6308609V
Installation
Key:
SV: Bleed-type air shutoff valve
AF: Air line filter
AR: Air regulator and gauge
AL: Air line lubricator
AM: Agitator motor
MT: Mix tank (reference only)
NOTE: Reference numbers and letters in parentheses
refer to the callouts in the figures and in Parts on page
16.
Grounding
Check your local electrical code for detailed grounding
instructions for your area and type of equipment.
To ground the agitator, connect one end of the ground
wire (A) to the ground connector (B) on the agitator. See
FIG. 2. Connect the other end of the ground wire to a true
earth ground.
For an additional ground wire and clamp, order part
number 237569.
To reduce the risk of fire and explosion, always
maintain a minimum of 1 in. (25.4 mm) clearance
between the rotating agitator parts and the container
to prevent sparks from contact.
FIG. 1: Typical Installation
AM
SV
AL
MT
AR
AF
The equipment must be grounded to reduce the risk
of static sparking. Static sparking can cause fumes to
ignite or explode. To reduce the risk of static sparking,
all electrically conductive objects or devices in the
spray area must be properly grounded.
FIG. 2
A
B

Installation
308609V 7
Assemble and Position the
Agitator
With an Elevator
Mount the drum cover as described in manual 306287.
The elevator must be in the down position when you do
any work on the elevator, agitator, or drum cover
assembly. Do not go under the elevator when it is
raised. Proceed to step 1 in Install With or Without an
Elevator.
Without an Elevator
If your system does not have an elevator, you should
install the Handles Kit to facilitate handling the drum
cover and agitator. Two people are needed to safely lift
and move the drum cover and agitator. To order the
Handles Kit, order part number 237524.
Place two standard 55 U.S. gallon (45 Imperial gallon)
barrels 14 in. (approximately 36 cm) apart, and center the
drum cover on the barrels with the Graco logo centered
and facing you, as shown in FIG. 3. Proceed to step 1 in
Install With or Without an Elevator.
Install With or Without an
Elevator
1. Slide the agitator shaft through the large hole in the
center of the drum cover (29).
2. Rotate the agitator so that the air motor is to the left
of the shaft, as shown in FIG. 3, which will align the
three tapped holes in the bottom of the agitator with
the three through holes in the drum cover.
3. Thread the three hex head screws (25) up through the
drum cover and into the agitator, and torque them to
75 in-lb (8.4 N•m).
4. Assemble one pair of agitator blades (28) so that the
four through holes in the blade halves are lined up
(see Parts on page 16 for blade orientation).
5. Push four cap screws (31) through the four holes in
the blades, and start the lock nuts (32) onto the cap
screws.
6. Slide the loose blade assembly up the shaft, and
position it approximately 13 in. (33 cm) from the
bottom of the shaft.
7. Tighten the four lock nuts (32) evenly to draw the
blades together until they are tight on the shaft.
Torque the locknuts to 50 to 55 in-lb (5.6 to 6.2
N•m). A gap will remain between the blade halves.
8. Repeat steps 4 and 5 with the second pair of
agitator blades.
9. Position the second blade assembly near the
bottom end of the shaft, but not on the bottom plug
(20).
10. Rotate the lower blade assembly so that it is oriented
90 degrees relative to the upper blade assembly, and
torque the lock nuts (32) to 50 to 55 in-lb (5.6 to 6.2
N•m). A gap will remain between the blade halves.
FIG. 3: Assemble and Position Agitator Without an
Elevator
05734
14 in. (36 cm)

Installation
8308609V
Install an In-Drum Heavy Duty
Back Geared Agitator
1. Determine which size adaptor nut (20) is needed.
The adaptor nuts in the kit are double–sided
meaning that each adaptor nut will cover two
agitator shaft sizes. Select the size you need by
placing the adaptors onto the built in agitator shaft in
the drum. The one you should use is the smallest
one that will fit. There should only be a small
amount of slop between the adaptor nut and the
shaft.
2. Thread the adaptor into the gearbox output shaft (6)
with the side you are going to use pointed down.
Tighten it down using the wrench flats.
3. Place the threaded bung adaptor (34) onto the
gearbox and align the bolt holes.
4. Thread the three bolts (28) into the gear box and
torque to 10 ft-lbs (13.5 N•m).
5. Align the adaptor nut to engage the built–in shaft in
the 55–gallon drum.
6. Slowly screw the unit onto the threads on the center
bung fitting of the 55–gallon drum. Hand tighten to
secure the unit. The unit should not easily unthread
from the drum.
NOTE: To upgrade back-geared agitators with radial
piston air motors for high viscosity (500cP to 3000 cP)
material applications, see Retrofit Kit 25T862 or manual
3A4792.
Install the Siphon Kit
See the Siphon Kit, Model 238250, Heavy-Duty
Stainless Steel Agitator, Model 238157 on page 17.
1. Remove the top plug (5) and the bottom plug (20).
2. Replace the bottom plug (20) with the plain bearing
(53), and tighten the bearing with a wrench.
3. Work the PTFE o-ring (54) onto the siphon tube
retainer (51), and press it into the o-ring groove.
4. Replace the top plug (5) with the siphon tube
retainer (51). Leave the retaining nut (52) on the
siphon tube retainer, but make sure it is not
tightened. Tighten the siphon tube retainer into the
top of the agitator housing with a wrench.
5. Slide the siphon tube (50) down through the retaining
nut (52), siphon tube retainer (51), and agitator shaft
(6) until the siphon tube touches the bottom of the
drum. Raise the siphon tube approximately 1/4 in.
(approximately 6 mm) so that it does not touch the
bottom of the drum. Hold the siphon tube at this
height with one hand, and tighten the retaining nut
with the other hand (hand tight is enough to hold the
siphon tube in place).
NOTICE
Barrel Heights Vary.
Loosen the retaining nut on the siphon tube retainer
before you raise the drum cover. If you do not loosen
the retaining nut, the siphon tube may make contact
with the bottom of the barrel when you lower the drum
cover onto a new barrel, which could damage the
siphon tube or the barrel.

Installation
308609V 9
Return Tube Kit 238884
(Accessory)
Return Tube Kit 238884 is available as an accessory. The
kit must be ordered separately. Refer to the sheet (406358)
packed with the kit for installation instructions.
Air Requirements
For continuous use, the 3/4 HP (550 W) agitator air
motor typically requires 3 to 4 cfm (0.09 to 0.12 m3/min)
air supply.
Air Line Accessories
A bleed-type air shutoff valve (SV) is required; it isolates
the air line components for servicing. The air shutoff
valve should be installed in the supply line and can be
used to stop and start the agitator. If the valve is used to
stop and start the agitator, you do not need to set the
agitator speed each time it is used.
Order air shutoff valves by the part numbers listed
below:
110223 1/4” npt(f) x 1/4” npt(f)
110224 3/8” npt(f) x 3/8” npt(f)
113333 3/8” npt(m) x 3/8” npt(f)
Optionally, attach a quick disconnect air line fitting and
coupler. To order the 1/8” npt(m) air line fitting, order part
number 169969. To order the coupler, order part number
208536.
Install an air line filter (AF) to remove harmful dirt and
moisture from the air supply. To order an air line filter,
order part number 106148 (3.8” npt, 20–micron element,
5 oz. Bowl, without gauge).
Downstream from the filter, install an air line lubricator
(AL) for automatic air motor lubrication. Set the
lubricator feed rate at 1 drop of oil per minute for high
speed or continuous duty usage. Do not overfeed oil or
exhaust air may become contaminated. To manually
lubricate the air motor, see Lubricate the Air Motor on
page 11. To order a 3/8” npt air line lubricator, order part
number 214847.
FIG. 4: Install the Siphon Kit
05736B
5
20
53
50
52
51
54
6
1
1
Make sure the center
tabs on the retaining nut
ferrule point down.
NOTICE
Not lubricating the air motor will cause air motor
failure.

Operation
10 308609V
Operation
Find the Proper Agitator Speed
NOTE: Attach ground wire before using agitator.
1. Fill the fluid supply container to about 3–4 inches (75–
100 mm) above the agitator blade.
2. Start the agitator, and gradually increase the speed by
turning the needle valve (14) until a vortex begins to
form in the paint.
3. Reduce the speed slightly, then fill the fluid
container. Use the lowest agitator speed needed for
thorough agitation of the paint. Excessive agitator
speed may cause the paint to foam.
Pressure Relief Procedure
1. Close the bleed-type air shutoff valve (SV) to relieve
pressure to the air motor.
2. Disconnect the air line.
Shutdown
To stop the agitator, close off the air supply with the
needle valve (23) and close the bleed-type shut off
valve (SV), or disconnect the air line coupler.
Moving parts, such as an impeller blade, can cut or
amputate fingers. To reduce the risk of serious injury,
always shut off the agitator and disconnect the air line
before checking or repairing the agitator.
NOTICE
Always maintain moderate agitator speed, which is
approximately 50 rpm of the agitator blades.
Excessive agitator speed may cause vibration,
foaming of fluid, and increased wear on parts. Always
agitate fluid thoroughly before supplying it to the
dispensing equipment. Continue agitating fluid while
the dispensing equipment is being supplied.
This equipment stays pressurized until pressure is
manually relieved. To help prevent serious injury from
splashing fluid and moving parts, follow the Pressure
Relief Procedure before cleaning, checking, or
servicing the equipment.
NOTICE
Keep the agitator upright. Do not lay it on its side or
upside down, or liquid may flow down the shaft and
into the gear reducer area causing damage.

Maintenance
308609V 11
Maintenance
Flush the Air Motor
If the air motor is sluggish or inefficient, follow this
procedure.
1. Disconnect the air line and muffler (22). See Parts
on page 16.
2. Add several teaspoons of non-flammable solvent, or
spray the solvent directly into the male
quick-disconnect coupler (24).
NOTE: The recommended solvent for air motors
and lubricated pumps is Gast®Flushing Solvent
(Gast part number AH255 or AH255A) or Penetone
Inhibisol®Safety Solvent.
3. Reconnect the air line, and slowly increase the air
pressure until there is no trace of solvent in the
exhaust air.
4. Reconnect the muffler (22).
5. Re-lubricate the motor with a squirt of lightweight oil
into the male quick-disconnect coupler (24).
Lubricate the Air Motor
If an air line lubricator is not installed, the air motor must
be manually lubricated every 8 hours. Lubricate the
agitator air motor by placing 10–20 drops of SAE #10
light oil in the motor’s air inlet. Oil must have an
auto-ignition rating of 365°F (185°C) or greater. Run the
agitator for about 30 seconds.
Agitator Blades
Regularly check the agitator for dried material buildup.
Clean using a rag soaked in solvent that is compatible
with the spray material and the surfaces being cleaned.
Additionally, extra precautions need to be taken if using
lower conductive materials (<1000 pS/m) such as:
• Avoid stirring/mixing at high speeds.
• Avoid insoluble mixtures.
• When possible, increase the material conductivity
with additives.
• Use liquids with a high conductivity (>1000 pS/m).
Do not use kerosene or other flammable solvents to
flush the air motor. Flushing with flammable solvents
could cause fire or explosion and result in serious
injury or property damage.
Hazardous fluids or toxic fumes can cause serious
injury or death if splashed in the eyes or on the skin,
swallowed, or inhaled. When flushing the air motor:
• Perform the procedure in a well ventilated area.
• Keep your face away from the exhaust port.
• Wear the appropriate protective clothing, gloves,
eyewear, and respirator.
NOTICE
Not lubricating the air motor will cause air motor
failure.
Materials can become electrostatically charged when
stirred or blended. To prevent fire and explosion,
ground equipment and do not allow material to build
up on agitator. Dried material could allow static build
up and interfere with grounding.

Maintenance
12 308609V
Clean the Agitator Shaft and
Seal
If any material is on the shaft (6) within 1/2 in. (13 mm)
of the housing (13), it must be removed to prevent
damage to the bearing seal (14*). If the flexible lips on
the bearing seal are torn or worn such that they do not
make contact all the way around the shaft, the seal must
be replaced. A worn seal may allow foreign material into
the bearing and cause premature failure. See Service
the Gear Reducer on page 13 for instructions on
getting access to the seal and for the Bearing
Replacement Kit part number.
Clean an Agitator with a
Siphon Kit
The procedure for flushing and cleaning the siphon tube
(50) and agitator shaft (6) is as follows:
1. Raise the agitator out of the drum.
2. Remove the plain bearing (53) from the agitator
shaft (6), and clean it.
3. Detach any attachments from the siphon tube, and
flush the siphon tube.
4. Loosen the retaining nut (52), and slowly lift the
siphon tube (50) out of the agitator.
5. Clean the inside and outside of the siphon tube (50),
flush the inside of the agitator shaft (6), and clean
the agitator blades (28) and the outside of the shaft.
6. Reassemble the siphon tube by doing the reverse of
steps 2 through 4.
NOTICE
Keep the agitator upright. Do not lay it on its side or
upside down, or liquid may flow down the shaft and
into the gear reducer area causing damage.

Service
308609V 13
Service
If the unit requires more than installation of a service kit,
it is usually quickest and easiest to send the unit to the
Graco distributor for repair or replacement.
• If the vanes need replacing or foreign material is
present in the motor chamber, an experienced
mechanic may remove the end plate opposite the
drive shaft end.
• New vanes should have the edges with cut corners
(or the notched edges, if the vanes are reversible)
pointing toward the bottom of the vane slot.
Service the Gear Reducer
You may want to have the Bearing Replacement Kit
238251 on hand before you begin this procedure.
Bearing removal and installation instructions are
included in the kit.
Disassemble
1. Relieve the pressure to the existing agitator. Follow
the Pressure Relief Procedure, page 10.
2. If your agitator has a siphon kit, perform steps 2–4
in Clean an Agitator with a Siphon Kit, page 12.
If your agitator does not have a siphon kit, proceed
to step 3 below.
3. Remove the agitator from the drum of material.
Separate the agitator from the agitator shaft (if
applicable):
a. For an in-drum agitator:
i. Unscrew the gearbox unit from the center
bung fitting of the 55-gallon drum.
Disengage and remove the unit from the
built-in shaft in the 55-gallon drum.
b. For an agitator without an elevator:
i. Remove and position the drum cover and
agitator by following the instructions in
Assemble and Position the Agitator,
page 7, see Without an Elevator.
ii. Carefully separate the gearbox output shaft
(6a) from the agitator shaft (6b) using the
wrench flats on both shaft sections.
iii. Remove the agitator assembly from the
drum cover by loosening the screws (25)
that attach the gearbox to the drum cover.
c. For an agitator with an elevator:
i. Raise the elevator (102), remove the drum
and place it out of the way. Lower the
elevator to the down position. The elevator
must be in the down position when you do
any work on the elevator, agitator, or drum
cover assembly.
ii. Carefully separate the gearbox output shaft
(6a) from the agitator shaft (6b) using the
wrench flats on both shaft sections
iii. Remove the agitator assembly from the
drum cover by loosening the screws (25)
that attach the gearbox to the drum cover.
4. Remove the two short bolts (11) and the two long
bolts (19) that hold the upper housing (8) and the
lower housing (13) together. Carefully lifting straight
up, lift the upper housing off of the lower housing.
Clean and Service
1. Clean any foreign material off of the outside of the
upper and lower housings (8 and 13).
NOTE: Do not lose the two small thrust balls (4).
One is in the upper housing (8), and one is in the
lower housing (13).
2. Inspect the parts for any wear. If any of the parts are
worn or damaged, replace them. The Bearing
Replacement Kit contains replacement bearings
and seals (items 2, 7, 9, 12, 14, and 15).
NOTICE
Do not pry with a screwdriver. It will dent the surface
of the plate and body, causing leaks. Use a puller
tool, which will remove the end plate while
maintaining the position of the shaft.

Service
14 308609V
Reassemble
NOTE: See the Parts on page 16 for proper bearing and
seal placement and orientation.
1. Reposition the lower housing (13) on the agitator
shaft.
2. Thread the 50-mm nut (26) onto the agitator shaft by
turning it clockwise, and tighten it hand tight.
3. Reposition the pinion/gear assembly (3, 16) in the
lower housing, thread the large gear (10) onto the
agitator shaft, and tighten the large gear hand tight.
4. Make sure the small thrust balls (4) are in place.
5. Reposition the pinion/gear assembly (3, 16) in the
lower housing, thread the large gear (10) onto the
agitator shaft, and tighten the large gear hand tight.
6. Carefully lowering it straight down, reposition the
upper housing (8) on the lower housing (13).
7. Replace the two short bolts (11) and the two long
bolts (19) that hold the upper housing (8) and the
lower housing (13) together, and torque the bolts to
75 in-lb (8.5 N•m).
8. Reposition the agitator onto the drum by repeating the
instructions for your agitator from step 3 in reverse
order. For agitators with and without an elevator,
torque the three hex head screws (25) to 75 in-lb (8.5
N•m) when installing.
9. If your agitator has a siphon kit, re-install it by doing
the reverse of steps 2 through 4 in Clean an
Agitator with a Siphon Kit on page 12.
Additional Agitator Service
If the unit requires more than installation of a bearing
replacement kit or gear replacement, it may be
advisable to send the unit to a Graco distributor for
repair or replacement.
NOTICE
To prevent damage to the bearings and seals, avoid
scraping them against the threaded agitator shaft
while you are lowering the lower housing in place.

Service
308609V 15

Parts
16 308609V
Parts
Heavy-Duty Stainless Steel Agitator, Model 238157
Includes items 1–34
Heavy-Duty Stainless Steel Agitator with Siphon Kit, Model 240209
Includes items 1–4, 6–19, 21–34, 50–54
Siphon Kit, Model 238250
Includes items 50–54
53
50
52
51
54
05736B
05735B
23
1
2*
2*
3
4
4
5
*7
8
*9
10
11
19
12*
13
14*
15*
26
17
16
18
18
6B
20
21
22
23a
23b
23c
23d
23e
24
28
31
32
27
34
0911B
23f
6A
(See DETAIL A)
DETAIL A
REF 23

Parts
308609V 17
Heavy-Duty Stainless Steel Agitator, Model 238157
Includes items 1–34
Heavy-Duty Stainless Steel Agitator with Siphon Kit, Model 240209
Includes items 1–4, 6–19, 21–34, 50–54
†Air Motor Repair Kit, part number 207335, is
available.
*Included in Bearing Replacement Kit 238251.
VReplacement safety labels, tags, and cards are
available at no cost.
NOTE: Part number 24C821 Agitator Drive Kit is
available. The kit includes all of the above parts except
items 6b, 20, 28, 31, and 32.
Siphon Kit, Model 238250
(includes items 50–54)
Ref. Part Description Qty.
1† 101140 AIR MOTOR 1
2* 191004 BEARING, needle; 3/4'' 2
3 190988 GEAR, pinion #2 1
4 100069 BALL, thrust 2
5 191003 PLUG, top 1
6 24D311 KIT, agitator shaft
Includes items 6a and 6b 1
6a 16A519 SHAFT, agitator 1
6b 16C238 SHAFT, agitator 1
7* 113363 SEAL, bearing 1
8 194389 HOUSING, upper 1
9* 190980 BEARING, needle, 45 mm 1
10 190989 GEAR #2 1
11 113357 SCREW, cap, socket head 2
12* 190978 BEARING, needle, 50 mm 1
13 194390 HOUSING, lower 1
14* 113359 SEAL, bearing 1
15* 190979 BEARING, needle, thrust; 50
mm 1
16 190987 GEAR #1 1
17 190986 GEAR, pinion #1 1
18 108161 SET SCREW, cup pt; SST 3
19 113356 SCREW, cap, socket head 2
20 191002 PLUG, bottom 1
21 105489 PIN, dowel 2
22 113779 MUFFLER 1
23 206264 VALVE, needle
Includes items 23a to 23f 1
23a 166529 VALVE, needle 1
23b 166532 NUT, packing 1
23c 164698 KNOB, adjusting 1
23d 157628 O-RING, packing 1
23e 165722 BODY, valve 1
23f 166531 WASHER 1
24 169969 FITTING, air line, male 1
25 113358 SCREW, hex head; for mounting
to drum cover (see page 23) 3
26 190976 NUT; 50 mm 1
27 104029 LUG, grounding 1
28 190985 BLADE, agitator 4
30V17P806 KIT, safety tag (not shown) 1
31 113413 SCREW, cap 8
32 113414 NUT, lock 8
34 104582 WASHER, tab 1
Ref
No.
Part
No. Description Qty.
50 238161 TUBE, siphon 1
51 190998 RETAINER, siphon tube 1
52 190999 NUT, retaining 1
53 191000 BEARING, plain 1
54 164557 O-RING; PTFE 1
Ref. Part Description Qty.

Parts
18 308609V
Heavy-Duty Stainless Steel Agitator, Drum Mounted, Models 24C293 and 24C522
For drums with built-in shaft and blades
ti14500a
23
1
2*
2*
3
4
4
5
*7
8
*9
10
11
19
12*
13
14*
15*
26
17
16
18
6
20
21
22
23a
23b
23c
23d
23e
24
34
27
0911B
23f
28
(See DETAIL A)
DETAIL A
REF 23

Parts
308609V 19
Heavy-Duty Stainless Steel Agitator, Drum Mounted, Models 24C293 and 24C522
†Air Motor Repair Kit, part number 207335, is
available.
*Included in Bearing Replacement Kit 238251
Included in Adapter Kit, 24D588
VReplacement safety labels, tags, and cards are
available at no cost.
NOTE: Part number 24C821 Agitator Drive Kit is
available. The kit includes all of the above parts except
items 20 and 34.
Ref. Part Description Qty
.
1† 101140 AIR MOTOR 1
2 191004 BEARING, needle; 3/4'' 2
3 190988 GEAR, pinion #2 1
4 100069 BALL, thrust 2
5 191003 PLUG, top 1
6 16A519 SHAFT, agitator 1
7* 113363 SEAL, bearing 1
8 194389 HOUSING, upper 1
9* 190980 BEARING, needle, 45mm 1
10 190989 GEAR #2 1
11 113357 SCREW, cap, socket head 2
12* 190978 BEARING, needle, 50 mm 1
13 194390 HOUSING, lower 1
14* 113359 SEAL, bearing 1
15* 190979 BEARING, needle, thrust; 50 mm 1
16 190987 GEAR #1 1
17 190986 GEAR, pinion #1 1
18 108161 SET SCREW, cup pt; SST 3
19 113356 SCREW, cap, socket head 2
2016H554 ADAPTER, nut, double-sided
(7/16 and 3/8) 1
16H555 ADAPTER, nut
(1/2 and 5/8) 1
21 105489 PIN, dowel 2
22 113779 MUFFLER 1
23 206264 VALVE, needle
Includes items 23a to 23f 1
23a 166529 VALVE, needle 1
23b 166532 NUT, packing 1
23c 164698 KNOB, adjusting 1
23d 157628 O-RING, packing 1
23e 165722 BODY, valve 1
23f 166531 WASHER 1
24 169969 FITTING, air line, male 1
25 113358 SCREW, hex head; for mounting
to drum cover (see page 23) 3
26 190976 NUT, 50 mm 1
27 116343 SCREW, grounding 1
28 113358 SCREW, cap, hex 3
30V17P806 KIT, safety tag (not shown) 1
3416A521 HOUSING, adapter (for 24C293) 1
16A754 HOUSING, adapter (for 24C522) 1
Ref. Part Description Qty
.

Parts
20 308609V
Non-Siphon Agitator Package, Model 231413
Siphon Agitator Package, Model 231414 (shown)
100
101
102
107
104
103
106
05771B
Raised height:
94 in (239 cm)
55 in (140 cm)
Lowered height:
Ref. Part Description Qty.
100 238157 AGITATOR: see page 16 for
parts 1
101 238283 COVER, sst; see manual 308466 1
102 204385 ELEVATOR; see manual 306287 1
103 237579 AIR CONTROL KIT; see manual
306287 1
104 237578 COVER SUPPORT KIT; see
manual 306287 1
105 238425 DESIGNATION PLATE KIT;
Model 231413 (not shown) 1
238426 DESIGNATION PLATE KIT;
Model 231414 (not shown) 1
106 237569 GROUND WIRE AND CLAMP 1
107 238250 SIPHON KIT; Model 231414
only; see page 16 for parts 1
Ref. Part Description Qty.
