Graco 232443 Operation manual

Instructions – Parts List
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
Copyright 1999, Graco Inc. is registered to I.S. EN ISO 9001
Pail Mount 308766 rev.F
Air–Assisted Packages
Model 232443 Shown
8162A
0359 II 1/2 G T3
ITS03ATEX11251
For air–assisted application of single and plural component coatings
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
Parts

2 308766
Table of Contents
List of Models 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warnings 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setup 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical Data 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Graco Warranty 24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Graco Information 24. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
List of Models
Package
Part No. Series Pump Model Ratio
Maximum Fluid
Working Pressure
Maximum Air
Input Pressure
232439 B Monarkr, carbon steel, with hose and gun,
without agitator
23:1 2300 psi
(16 MPa, 160 bar)
100 psi
(0.7 MPa, 7 bar)
232440 A Monarkr, carbon steel, without agitator,
hose, and gun
23:1 2300 psi
(16 MPa, 160 bar)
100 psi
(0.7 MPa, 7 bar)
232443 B Monarkr, carbon steel, with agitator,
hose, and gun
23:1 2300 psi
(16 MPa, 160 bar)
100 psi
(0.7 MPa, 7 bar)
232451 B Monarkr, stainless steel, with hose and
gun, without agitator
23:1 2300 psi
(16 MPa, 160 bar)
100 psi
(0.7 MPa, 7 bar)
232452 A Monarkr, stainless steel, without agitator,
hose, and gun
23:1 2300 psi
(16 MPa, 160 bar)
100 psi
(0.7 MPa, 7 bar)
232455 B Monarkr, stainless steel, with agitator,
hose, and gun
23:1 2300 psi
(16 MPa, 160 bar)
100 psi
(0.7 MPa, 7 bar)
232457 B Monarkr, stainless steel, with fluid regula-
tor, hose, and gun, without agitator
15:1 1500 psi
(10 MPa, 100 bar)
100 psi
(0.7 MPa, 7 bar)
232458 A Monarkr, stainless steel, with fluid regula-
tor, without agitator, hose, and gun
15:1 1500 psi
(10 MPa, 100 bar)
100 psi
(0.7 MPa, 7 bar)
232461 B Monarkr, stainless steel, with fluid regula-
tor, agitator, hose, and gun
15:1 1500 psi
(10 MPa, 100 bar)
100 psi
(0.7 MPa, 7 bar)
232463 B Monarkr, carbon steel, with fluid regulator,
hose, and gun, without agitator
15:1 1500 psi
(10 MPa, 100 bar)
100 psi
(0.7 MPa, 7 bar)
232464 A Monarkr, carbon steel, with fluid regulator,
without agitator, hose, and gun
15:1 1500 psi
(10 MPa, 100 bar)
100 psi
(0.7 MPa, 7 bar)
232467 B Monarkr, carbon steel, with fluid regulator,
agitator, hose, and gun
15:1 1500 psi
(10 MPa, 100 bar)
100 psi
(0.7 MPa, 7 bar)

308766 3
Symbols
Warning Symbol
WARNING
This symbol alerts you to the possibility of serious
injury or death if you do not follow the instructions.
Caution Symbol
CAUTION
This symbol alerts you to the possibility of damage to
or destruction of equipment if you do not follow the
instructions.
WARNING
INSTRUCTIONS
EQUIPMENT MISUSE HAZARD
Equipment misuse can cause the equipment to rupture or malfunction and result in serious injury.
DThis equipment is for professional use only.
DRead all instruction manuals, tags, and labels before operating the equipment.
DUse the equipment only for its intended purpose. If you are uncertain about usage, call your Graco
distributor.
DDo not alter or modify this equipment. Use only genuine Graco parts and accessories.
DCheck equipment daily. Repair or replace worn or damaged parts immediately.
DDo not exceed the maximum working pressure of the lowest rated system component. Refer to the
Technical Data on page 22 for the maximum working pressure of this equipment.
DUse fluids and solvents which are compatible with the equipment wetted parts. Refer to the Tech-
nical Data section of all equipment manuals. Read the fluid and solvent manufacturer’s warnings.
DRoute hoses away from traffic areas, sharp edges, moving parts, and hot surfaces. Do not expose
Graco hoses to temperatures above 180_F (82_C) or below –40_F (–40_C).
DWear hearing protection when operating this equipment.
DDo not lift pressurized equipment.
DComply with all applicable local, state, and national fire, electrical, and safety regulations.

4 308766
WARNING
INJECTION HAZARD
Spray from the gun, hose leaks, or ruptured components can inject fluid into your body and cause
extremely serious injury, including the need for amputation. Fluid splashed in the eyes or on the skin
can also cause serious injury.
DFluid injected into the skin might look like just a cut, but it is a serious injury. Get immediate surgi-
cal treatment.
DDo not point the gun at anyone or at any part of the body.
DDo not put your hand or fingers over the spray tip.
DDo not stop or deflect leaks with your hand, body, glove or rag.
DDo not “blow back” fluid; this is not an air spray system.
DAlways have the tip guard and the trigger guard on the gun when spraying.
DCheck the gun diffuser operation weekly. Refer to the gun manual.
DBe sure the gun trigger safety operates before spraying.
DLock the gun trigger safety when you stop spraying.
DFollow the Pressure Relief Procedure on page 10 whenever you: are instructed to relieve pres-
sure; stop spraying; clean, check, or service the equipment; and install or clean the spray tip.
DTighten all fluid connections before operating the equipment.
DCheck the hoses, tubes, and couplings daily. Replace worn, damaged, or loose parts immediately.
Permanently coupled hoses cannot be repaired; replace the entire hose.
DUse only Graco approved hoses. Do not remove any spring guard that is used to help protect the
hose from rupture caused by kinks or bends near the couplings.
MOVING PARTS HAZARD
Moving parts, such as the air motor piston, can pinch or amputate your fingers.
DKeep clear of all moving parts when starting or operating the pump.
DBefore servicing the equipment, follow the Pressure Relief Procedure on page 10 to prevent the
equipment from starting unexpectedly.

308766 5
WARNING
FIRE AND EXPLOSION HAZARD
Improper grounding, poor ventilation, open flames or sparks can cause a hazardous condition and
result in a fire or explosion and serious injury.
DGround the equipment and the object being sprayed. Refer to Grounding on page 7.
DIf there is any static sparking or you feel an electric shock while using this equipment, stop spray-
ing immediately. Do not use the equipment until you identify and correct the problem.
DProvide fresh air ventilation to avoid the buildup of flammable fumes from solvents or the fluid
being sprayed.
DKeep the spray area free of debris, including solvent, rags, and gasoline.
DElectrically disconnect all equipment in the spray area.
DExtinguish all open flames or pilot lights in the spray area.
DDo not smoke in the spray area.
DDo not turn on or off any light switch in the spray area while operating or if fumes are present.
DDo not operate a gasoline engine in the spray area.
TOXIC FLUID HAZARD
Hazardous fluid or toxic fumes can cause serious injury or death if splashed in the eyes or on the skin,
inhaled, or swallowed.
DKnow the specific hazards of the fluid you are using.
DStore hazardous fluid in an approved container. Dispose of hazardous fluid according to all local,
state and national guidelines.
DAlways wear protective eyewear, gloves, clothing and respirator as recommended by the fluid and
solvent manufacturer.

6 308766
Setup
General Information
NOTE: Reference numbers and letters in parentheses
in the text refer to the callouts in the figures and the
parts drawing.
NOTE: Always use Genuine Graco Parts and Acces-
sories, available from your Graco distributor. Refer to
Product Data Sheet 305899. If you supply your own
accessories, be sure they are adequately sized and
pressure-rated for your system.
Fig. 2 is only a guide for selecting and installing sys-
tem components and accessories. Contact your Graco
distributor for assistance in designing a system to suit
your particular needs.
Prepare the Operator
All persons who operate the equipment must be
trained in the safe, efficient operation of all system
components as well as the proper handling of all fluids.
All operators must thoroughly read all instruction
manuals, tags, and labels before operating the equip-
ment.
The following manuals are included with this equip-
ment:
D308766, Pail Mount Air-Assisted Packages
D307619, 23:1 CST and SST Monark Pumps, or
308106, 15:1 SST Monark Pump, or
306981, 15:1 CST Monark Pump, or
307595, 10:1 CST Monark Pump
D307043, Monark Air Motor
D308686, Air Regulator Kit
D307273, Fluid Filter
D307886, Fluid Pressure Regulator (included on 15:1
Monarks only)
D306565, Agitator (included on Models 232443,
232455, 232461, and 232467 only)
D311001, AA Series Spray Gun (included on all
models except 232440, 232452, 232458, and
232464)
Prepare the Site
NOTE: The compressed air supply to the gun must be
clean and dry, to prevent damage to the finish. Use a
coalescing air filter in the main air supply line.
Ensure that you have an adequate compressed air
supply. Refer to the performance charts on page 23 to
find the air consumption of your pump.
Refer to Fig. 2 on page 9. Bring a compressed air
supply line from the air compressor to the pump loca-
tion. Be sure all air hoses are properly sized and
pressure-rated for your system. Use only electrically
conductive hoses. The air hose (A) should have a 3/8
npsm(m) thread.
Install a bleed-type shutoff valve (B) in the air line to
isolate the air line components for servicing. Install an
air line filter (C) and a moisture trap and drain valve
(D) to help remove moisture and contaminants from
the compressed air supply.
Keep the site clear of any obstacles or debris that
could interfere with the operator’s movement.
Have a grounded, metal pail available for use when
flushing the system.

308766 7
Setup
Grounding
WARNING
FIRE AND EXPLOSION HAZARD
Before operating the pump, ground the
system as explained below. Also read
the section FIRE AND EXPLOSION
HAZARD on page 5.
1. Pump: use the ground wire and clamp (supplied).
See Fig. 1. Loosen the grounding lug locknut (W)
and washer (X). Insert one end of the ground wire
(18) into the slot in lug (Z) and tighten the locknut
securely. Connect the other end of the wire to a
true earth ground.
2. Agitator (Models 232443, 232455, 232461, and
232467 only): one end of the agitator ground wire
(40, supplied) is fastened to the agitator motor with
a screw. Insert the other end of the ground wire
into the slot in lug (Z). Insert the pump ground wire
(18) as described in step 1 and tighten the locknut
(W) securely.
8238A
Fig. 1
W
18
X
Z
40
1Models with agitator only.
1
3. Air and fluid hoses: use only electrically conductive
hoses.
4. Air compressor: follow manufacturer’s recommen-
dations.
5. Spray gun: ground through connection to a prop-
erly grounded fluid hose and pump.
6. Fluid supply container: follow your local code.
7. Object being sprayed: follow your local code.
8. Solvent pails used when flushing: follow your local
code. Use only metal pails, which are conductive,
placed on a grounded surface. Do not place the
pail on a nonconductive surface, such as paper or
cardboard, which interrupts the grounding continu-
ity.
9. To maintain grounding continuity when flushing or
relieving pressure, hold a metal part of the spray
gun firmly to the side of a grounded metal pail,
then trigger the gun.

8 308766
Setup
Supplied Components
Refer to Fig. 2.
WARNING
A red-handled bleed-type master air valve (E) and
a fluid drain valve (F) are supplied. These compo-
nents help reduce the risk of serious injury, includ-
ing fluid injection and splashing of fluid in the eyes
or on the skin, and injury from moving parts if you
are adjusting or repairing the pump.
The bleed-type master air valve relieves air trapped
between this valve and the pump after the valve is
closed. Trapped air can cause the pump to cycle
unexpectedly. Locate the valve close to the pump.
The fluid drain valve assists in relieving fluid pres-
sure in the displacement pump, hose, and gun.
Triggering the gun to relieve pressure may not be
sufficient.
DThe red-handled bleed-type master air valve (E)
is required in your system to relieve air trapped
between it and the air motor and gun when the
valve is closed (see the WARNING above). Do not
block access to the valve.
DThe pump air regulator (G) controls pump speed
and outlet pressure by adjusting the air pressure to
the pump.
DThe air relief valve (15) opens automatically to
prevent overpressurization of the pump.
DThe gun air regulator (J) adjusts the air pressure
to the air-assisted spray gun (106).
DThe air inlet swivel (H) connects incoming air to
the pump and to the gun.
DThe strainer (42) keeps large particles from enter-
ing the pump.
DThe fluid filter (13) includes a 60 mesh (250
micron) stainless steel element to filter particles
from the fluid as it leaves the pump. It also includes
the fluid drain valve (F), which is required in your
system to relieve fluid pressure in the hose and gun
(see the WARNING at left).
DThe agitator (39), included on Models 232443,
232455, 232461, 232467, and 232473 only, keeps
the fluid in suspension.
DThe air-assisted spray gun (106) dispenses the
fluid. The gun houses the spray tip (107), which is
available in a wide range of sizes for different spray
patterns and rates of flow.
DThe twin hose (101) includes a gun air supply
hose (101a) and a gun fluid supply hose (101b).
The fluid whip hose (103) allows greater gun
maneuverability.
DThe gun filter/swivel (104) provides a final filtering
of fluid before it enters the gun, and allows greater
gun maneuverability.
DThe fluid pressure regulator (201), included on
15:1 Monarks only, allows more precise adjustment
of the fluid pressure at the gun.

308766 9
Setup
KEY
SUPPLIED COMPONENTS
1 5 Gallon (19 liter) Pail Cover
2 Pump
13 Fluid Filter
(includes fluid drain valve F)
15 Air Relief Valve
18 Pump Ground Wire (required;
see page 7 for installation instructions)
19 5 Gallon (19 liter) Pail
39 Agitator
40 Agitator Ground Wire
101 Electrically Conductive Gun Air/Fluid Hose
(includes items 101a and 101b)
101a Gun Air Supply Hose
101b Gun Fluid Supply Hose
103 Fluid Whip Hose
104 Gun Filter/Swivel
106 Air-Assisted Spray Gun
201 Fluid Pressure Regulator
(15:1 Monarks only)
E* Red-Handled Bleed-Type Master Air Valve
(required, for pump)
F Fluid Drain Valve
G* Pump Air Regulator
H* Air Inlet Swivel
J* Gun Air Regulator
* Included in Air Regulation Kit (21).
COMPONENTS YOU MUST SUPPLY
A Electrically Conductive Air Supply Hose
B Bleed-Type Master Air Valve (for accessories)
C Air Line Filter
D Air Line Moisture Trap and Drain Valve
8163A
Fig. 2
Model 232443 Shown
1
106
104
101b
13
103
D
F
A
19
C
*H
B
15
2
*E
*G
18
40
39
101a
J*
8237A
13
101b (Ref)
101a (Ref)
Detail of Fluid Regulator
201
1Fluid Pressure Regulator included with
10:1 and 15:1 Monarks only
1

10 308766
Operation
Pressure Relief Procedure
WARNING
INJECTION HAZARD
The system pressure must be manually
relieved to prevent the system from
starting or spraying accidentally. Fluid
under high pressure can be injected through the
skin and cause serious injury. To reduce the risk of
an injury from injection, splashing fluid, or moving
parts, follow the Pressure Relief Procedure
whenever you:
Dare instructed to relieve the pressure,
Dstop spraying,
Dcheck or service any of the system equipment,
Dor install or clean the spray tip.
1. Lock the gun trigger safety.
2. Close the red-handled bleed-type master air valve
(E, required in your system). See Fig. 3.
3. Unlock the gun trigger safety.
4. Hold a metal part of the gun firmly to the side of a
grounded metal pail, and trigger the gun to relieve
pressure.
5. Lock the gun trigger safety.
6. Open the drain valve (F, required in your system),
having a container ready to catch the drainage.
7. Leave the drain valve open until you are ready to
spray again.
If you suspect that the spray tip or hose is completely
clogged, or that pressure has not been fully relieved
after following the steps above, very slowly loosen the
tip guard retaining nut or hose end coupling and relieve
pressure gradually, then loosen completely. Now clear
the tip or hose.
Flush the Pump Before First Use
The pump is tested with lightweight oil, which is left in
to protect the pump parts. If the fluid you are using
may be contaminated by the oil, flush it out with a
compatible solvent. See Flushing on page 13.
Packing Nut
Before starting, fill the packing nut 1/3 full with Graco
Throat Seal Liquid (TSL) or compatible solvent. See
your separate pump manual.
WARNING
To reduce the risk of serious injury whenever you
are instructed to relieve pressure, always follow the
Pressure Relief Procedure at left.
The packing nut is torqued at the factory and is ready
for operation. If it becomes loose and there is leaking
from the throat packings, relieve pressure, then torque
the nut as specified in your separate pump manual. Do
this whenever necessary. Do not overtighten the
packing nut.
Prime the Pump
1. See Fig. 3. Remove the tip guard and spray tip
from the gun (106). Refer to the gun manual.
2. Close the gun air regulator (J), pump air regulator
(G), and bleed-type air valves (B, E).
3. Connect the air line (A) to the air inlet swivel (H).
4. Check that all fittings throughout the system are
tightened securely.
5. Fill the pail (19) with fluid. Make sure the pail cover
(1) is fastened securely to the pail with the screw
knobs (20).
6. Close the fluid drain valve (F). Open the fluid
regulator (201), if present.
7. Hold a metal part of the gun (106) firmly to the side
of a grounded metal pail and hold the trigger open.
8. Open the bleed-type air valves (B, E) and the gun
air regulator (J). Slowly open the pump air regula-
tor (G) until the pump starts.
9. Cycle the pump slowly until all air is pushed out
and the pump and hoses are fully primed.
10. Release the gun trigger and lock the trigger safety.
The pump should stall against pressure.
11. If the pump fails to prime properly, open the drain
valve (F). Use the drain valve as a priming valve
until the fluid flows from the valve. Close the valve.
NOTE: When changing fluid containers with the hose
and gun already primed, open the drain valve (F) to
help prime the pump and vent air before it enters the
hose. Close the drain valve when all air is eliminated.

308766 11
Operation
Fig. 3
KEY
SUPPLIED COMPONENTS
1 5 Gallon (19 liter) Pail Cover
2 Pump
13 Fluid Filter
(includes fluid drain valve F)
19 5 Gallon (19 liter) Pail
20 Screw Knobs
39 Agitator
41 Agitator Air Supply Tube
101 Electrically Conductive Gun Air/Fluid Hose
(includes items 101a and 101b)
101a Gun Air Supply Hose
101b Gun Fluid Supply Hose
103 Fluid Whip Hose
104 Gun Filter/Swivel
106 Air-Assisted Spray Gun
201 Fluid Pressure Regulator
(10:1 and 15:1 Monarks only)
A Electrically Conductive Air Supply Hose
B Bleed-Type Master Air Valve (for accessories)
E Red-Handled Bleed-Type Master Air Valve
(required, for pump)
F Fluid Drain Valve
G Pump Air Regulator
H Air Inlet Swivel
J Gun Air Regulator
K Agitator Control Valve
8163A
Model 232443 Shown
K
1
106
104
101b
13
103
F
A
19
H
B
2
E
G
41
39
101a
J
8237A
13
101b (Ref)
101a (Ref)
Detail of Fluid Regulator
201
1Fluid Pressure Regulator included with
10:1 and 15:1 Monarks only
1
20

12 308766
Operation
Agitator Operation (Models 232443,
232455, 232461, and 232467 only)
1. Slowly open the control valve (K) to start the
agitator (39). See Fig. 3.
2. Use the valve (K) to adjust the speed. Do not
operate the agitator too fast. If the fluid foams or a
vortex forms on the fluid surface, reduce the speed
of the agitator.
3. Refer to manual 306565 for further agitator operat-
ing instructions.
Install the Spray Tip
WARNING
To reduce the risk of serious injury whenever you
are instructed to relieve pressure, always follow the
Pressure Relief Procedure on page 10.
Relieve the pressure. Install the spray tip and tip guard
as explained in your separate gun manual, supplied.
The fluid output and pattern width depend on the size
of the spray tip, the fluid viscosity, and the fluid pres-
sure. Use the Spray Tip Selection Chart in your gun
instruction manual as a guide for selecting an
appropriate spray tip for your application.
Adjust the Spray Pattern
1. Start the pump. Use the pump air regulator (G) to
adjust the pump speed and fluid pressure until the
spray is completely atomized. Use the lowest
pressure necessary to get the desired results.
Higher pressure may not improve the spray pattern
and will cause premature tip and pump wear.
NOTE: The fluid pressure regulator (201), which is
included on 10:1 and 15:1 Monarks, allows more
precise adjustment of the fluid pressure at the gun.
WARNING
COMPONENT RUPTURE HAZARD
To reduce the risk of overpressurizing
your package, which could cause com-
ponent rupture and serious injury, never
exceed 100 psi (0.7 MPa, 7 bar) air input pressure
to the package. Never exceed 100 psi (0.7 MPa, 7
bar) air input pressure to the spray gun. Also refer
to the Technical Data on page 22 and to your sep-
arate component manuals.
2. When applying the fluid, keep the gun a consistent
distance, about 8 to 12 inches (200 to 300 mm)
from the surface of the object being sprayed.
Always hold the gun at a right angle from the
surface. Do not make an arc with the gun, as it
causes an uneven coat of fluid. Use a full-open,
full-close triggering action. Practice to find the best
length and speed of stroke.
3. To adjust the spray pattern, follow the instructions
in your gun manual, supplied.
4. With the pump and lines primed, and with ade-
quate air pressure and volume supplied, the pump
will start and stop as you open and close the gun.
CAUTION
Do not allow the pump to run dry. It will quickly
accelerate to a high speed, causing damage. If your
pump is running too fast, stop it immediately and
check the fluid supply. If the container is empty and
air has been pumped into the lines, refill the con-
tainer and prime the pump and the lines, or flush and
leave it filled with a compatible solvent. Eliminate all
air from the fluid system.
Shutdown and Care of the Pump
WARNING
To reduce the risk of serious injury whenever you
are instructed to relieve pressure, always follow the
Pressure Relief Procedure on page 10.
For overnight shutdown, stop the pump at the bottom
of its stroke to prevent fluid from drying on the ex-
posed displacement rod and damaging the throat
packings. Shut off the agitator (39), if present. Relieve
the pressure.
Always flush the pump before the fluid dries on the
displacement rod. See Flushing on page 13.

308766 13
Maintenance
Preventive Maintenance Schedule
The operating conditions of your particular system
determine how often maintenance is required. Estab-
lish a preventive maintenance schedule by recording
when and what kind of maintenance is needed, and
then determine a regular schedule for checking your
system.
Clean the In-Line Fluid Filter Element
The filter/swivel (104) includes a 100 mesh stainless
steel filter element (105). Clean the element periodical-
ly with a compatible solvent, as follows.
WARNING
To reduce the risk of serious injury whenever you
are instructed to relieve pressure, always follow the
Pressure Relief Procedure on page 10.
1. Relieve the pressure.
2. Disassemble the filter/swivel (104) and remove the
filter element (105).
3. Clean or replace the element, as necessary.
4. Reassemble. Torque the two halves of the filter/
swivel to 10–15 ft-lb (14–20 NSm).
Flushing
WARNING
FIRE AND EXPLOSION HAZARD
Before flushing, read the section FIRE
AND EXPLOSION HAZARD on page
5. Be sure the entire system and flush-
ing pails are properly grounded. Refer to
Grounding on page 7.
Flush the pump:
DBefore the first use
DWhen changing colors or fluids
DBefore fluid can dry or settle out in a dormant pump
(check the pot life of catalyzed fluids)
DBefore storing the pump.
Flush with a fluid that is compatible with the fluid you
are pumping and with the wetted parts in your system.
Check with your fluid manufacturer or supplier for
recommended flushing fluids and flushing frequency.
CAUTION
If you have a carbon steel package, never leave
water or water-base fluid in the pump overnight. If
you are pumping water-base fluid, flush with water
first, then with a rust inhibitor such as mineral spirits.
Relieve the pressure, but leave the rust inhibitor in
the pump to protect the parts from corrosion.
WARNING
To reduce the risk of serious injury whenever you
are instructed to relieve pressure, always follow the
Pressure Relief Procedure on page 10.
1. Relieve the pressure.
2. Remove the tip guard and spray tip from the gun.
See the gun manual.
3. Remove the filter element from the fluid filter (13).
Reinstall the filter bowl.
4. Remove the strainer (42). Place the pump inlet in a
container of solvent.
5. Hold a metal part of the gun firmly to the side of a
grounded metal pail.
6. Start the agitator and run it slowly.
7. Start the pump. Always use the lowest possible
fluid pressure when flushing.
8. Trigger the gun. Flush the system until clear
solvent flows from the gun.
9. Relieve the pressure.
10. Clean the tip guard, spray tip, strainer, and fluid
filter element separately, then reinstall them.

14 308766
Parts
Part No. 232443, Series A, 23:1 Monark, cst, with agitator, hose, and gun (shown)
A
A
B
B
C
C
D
E
E
D
F
F
8165A
21 1
3
4
5
2
101
104
6
7
8
9
10
7 (Ref)
11
12
13
14
15
16
17
17 (Ref)
18
19
20
22
23, 25
24
30
31
41
41 (Ref)
42
39
39 (Ref)
101 (Ref)
102
103
106
40 (Ref)
40
101
1
2
10:1 and 15:1 Monarks include a fluid pressure
regulator kit. Refer to page 18 for parts.
If you order a new twin air/fluid hose (101), cut
the coupling off one end of the red air hose so
that the hose is 2 in. (50 mm) longer than the
blue fluid hose. Make sure the cut is straight,
not slanted. Push the cut end of the air hose
into the outlet fitting of the gun air regulator.
1
2
2

308766 15
Parts
23:1 Monark Carbon Steel Packages, Part Nos. 232439, 232440, and 232443
23:1 Monark Stainless Steel Packages, Part Nos. 232451, 232452, and 232455
NOTE: Refer to page 16 for 10:1 and 15:1 Monark Packages.
NOTE: Some packages include a hose and gun. Refer to page 19 for details.
NOTE: To find the part number used in your package, read down the chart to find the desired ref. no., then read left
to right to find the part number for your package.
Packages
Ref.
No. Description
CST
232439,
232440
CST
232443
SST
232451,
232452
SST
232455 Qty
1COVER, pail 240435 240435 240435 240435 1
2PUMP, 23:1 Monark; cst; see manual 307619 223596 223596 1
PUMP, 23:1 Monark; sst; see manual 307619 237958 237958 1
3CAPSCREW, hex hd; 1/4–20 x 3/4 in. (19 mm) 100644 100644 100644 100644 2
4LOCKWASHER; 1/4 in. 100016 100016 100016 100016 2
5ELBOW, 90_; cst; 3/8 npt(m) x 3/8 npt(f) 155699 155699 1
ELBOW, 90_; sst; 3/8 npt(m) x 3/8 JIC 114484 114484 1
6ADAPTER; cst; 3/8 npt x 9/16–18 unf–2a 114337 114337 Not used Not used 1
7TUBE, flare; sst; 9/16–18 unf–2a x 3/8 in. (10 mm) OD 114478 114478 1
TUBE, flare; sst; 9/16–18 unf–2a x 3/8 in. (10 mm) OD 114477 114477 1
8FITTING, bulkhead 192889 192889 192889 192889 1
9WASHER, flat; 9/16 in. 114830 114830 114830 114830 1
10 NUT, hex; 9/16–18 102300 102300 102300 102300 1
11 NIPPLE; cst; 3/8 npt 156849 156849 1
NIPPLE; sst; 3/8 npt 166469 166469 1
12 UNION, swivel, straight; cst; 3/8 npt(m) x 3/8 npsm(f) 155665 155665 1
UNION, swivel, straight; sst; 3/8 npt(m) x 3/8 npsm(f) 235208 235208 1
13 FLUID FILTER; cst; see manual 307273 239060 239060 1
FLUID FILTER; sst; see manual 307273 239063 239063 1
14 TEE; 3/8 npt(f) run x 3/8 npt(m) branch 113777 113777 113777 113777 1
15 VALVE, relief; 125 psi (0.86 MPa, 8.6 bar) 113769 113769 113769 113769 1
16 CONNECTOR, tube fitting;
3/8 npt(m) x 1/2 in. (13 mm) OD tube
114129 114129 114129 114129 1
17 TUBE; polyurethane; 1/2 in. (13 mm) OD;
1.3 ft (0.4 m) long
Obtain
locally
Obtain
locally
Obtain
locally
Obtain
locally
1
18 PUMP GROUND WIRE AND CLAMP 238909 238909 238909 238909 1
19 PAIL; 5 gallon (19 liter) 101108 101108 101108 101108 1
20 KNOB, screw; 1/4–20 114371 114371 114371 114371 3
21 AIR REGULATOR KIT; see manual 308686 240446 240446 240446 240446 1
22 SCREW, socket; M5 x 0.8; 20 mm (3/4 in.) 115439 115439 115439 115439 4
23 NUT, hex, self-locking; M5 x 0.8 105332 105332 105332 105332 4
24 QUICK CONNECTOR, elbow, 90_, tube;
1/8 npt(m) x 1/4 in. (6 mm) OD tube; acetal
Not used 114367 Not used 114367 1
25 WASHER, flat 110874 110874 110874 110874 4

16 308766
Parts
23:1 Monark Carbon Steel Packages, Part Nos. 232439, 232440, and 232443
23:1 Monark Stainless Steel Packages, Part Nos. 232451, 232452, and 232455
NOTE: Some packages include a hose and gun. Refer to page 19 for details.
NOTE: To find the part number used in your package, read down the chart to find the desired ref. no., then read left
to right to find the part number for your package.
Packages
Ref.
No. Description
CST
232439,
232440
CST
232443
SST
232451,
232452
SST
232455 Qty
30 SCREW, set; 1/4–20 x 1/4 in. (6 mm) 101962 101962 101962 101962 2
31 PLUG, pipe; 3/8 npt; not shown 100040 100040 1
ELBOW, tube fitting, 90_; 3/8 npt(m) x
1/4 in. (6 mm) OD tube
114366 114366 1
39 PLUG, agitator; not shown 114575 114575 1
AGITATOR; see manual 306565 224571 224571 1
40 AGITATOR GROUND WIRE Not used 240585 Not used 240585 1
41 TUBE; nylon; 1/4 in. (6 mm) OD; 9.6 in. (244 mm) long Not used Obtain
locally
Not used Obtain
locally
1
42 STRAINER, fluid inlet 187190 187190 187190 187190 1
15:1 Monark Stainless Steel Packages, Part Nos. 232457, 232458, and 232461
15:1 Monark Carbon Steel Packages, Part Nos. 232463, 232464, and 232467
10:1 Monark Carbon Steel Packages, Part Nos. 232469, 232470, and 232473
NOTE: These packages all include a fluid regulator kit. Refer to page 18.
NOTE: Some packages include a hose and gun. Refer to page 19 for details.
NOTE: To find the part number used in your package, read down the chart to find the desired ref. no., then read left
to right to find the part number for your package.
Packages
Ref.
No. Description
SST
232457,
232458
SST
232461
CST
232463,
232464
CST
232467 Qty
1COVER, pail 240435 240435 240435 240435 1
2PUMP, 15:1 Monark; sst;
see manual 308106
223844 223844 1
PUMP, 15:1 Monark; cst;
see manual 306981
239327 239327 1
PUMP, 10:1 Monark; cst;
see manual 307595
1
3CAPSCREW, hex hd; 1/4–20 x
3/4 in. (19 mm)
100644 100644 100644 100644 2
4LOCKWASHER; 1/4 in. 100016 100016 100016 100016 2
5ELBOW, 90_; cst; 3/8 npt(m) x 3/8 npt(f) 155699 155699 1
ELBOW, 90_; sst; 3/8 npt(m) x 3/8 JIC 114484 114484 1
6ADAPTER; cst; 3/8 npt x 9/16–18 unf–2a Not used Not used 114337 114337 1
7TUBE, flare; sst; 9/16–18 unf–2a x
3/8 in. (10 mm) OD
114478 114478 1
TUBE, flare; sst; 9/16–18 unf–2a x
3/8 in. (10 mm) OD
114477 114477 1

308766 17
Parts
15:1 Monark Stainless Steel Packages, Part Nos. 232457, 232458, and 232461
15:1 Monark Carbon Steel Packages, Part Nos. 232463, 232464, and 232467
NOTE: These packages all include a fluid regulator kit. Refer to page 18.
NOTE: Some packages include a hose and gun. Refer to page 19 for details.
NOTE: To find the part number used in your package, read down the chart to find the desired ref. no., then read left
to right to find the part number for your package.
Packages
Ref.
No. Description
SST
232457,
232458
SST
232461
CST
232463,
232464
CST
232467 Qty
8FITTING, bulkhead 192889 192889 192889 192889 1
9WASHER, flat; 9/16 in. 114830 114830 114830 114830 1
10 NUT, hex; 9/16–18 102300 102300 102300 102300 1
11 NIPPLE; cst; 3/8 npt 156849 156849 1
NIPPLE; sst; 3/8 npt 166469 166469 1
12 UNION, swivel, straight; cst;
3/8 npt(m) x 3/8 npsm(f)
155665 155665 1
UNION, swivel, straight; sst;
3/8 npt(m) x 3/8 npsm(f)
235208 235208 1
13 FLUID FILTER; cst; see manual 307273 239060 239060 1
FLUID FILTER; sst; see manual 307273 239063 239063 1
14 TEE; 3/8 npt(f) run x 3/8 npt(m) branch 113777 113777 113777 113777 1
15 VALVE, relief; 125 psi (0.86 MPa, 8.6 bar) 113769 113769 113769 113769 1
16 CONNECTOR, tube fitting;
3/8 npt(m) x 1/2 in. (13 mm) OD tube
114129 114129 114129 114129 1
17 TUBE; polyurethane; 1/2 in. (13 mm) OD;
1.3 ft (0.4 m) long
Obtain
locally
Obtain
locally
Obtain
locally
Obtain
locally
1
18 PUMP GROUND WIRE AND CLAMP 238909 238909 238909 238909 1
19 PAIL; 5 gallon (19 liter) 101108 101108 101108 101108 1
20 KNOB, screw; 1/4–20 114371 114371 114371 114371 3
21 AIR REGULATOR KIT;
see manual 308686
240446 240446 240446 240446 1
22 SCREW, socket; M5 x 0.8; 20 mm (3/4 in.) 115439 115439 115439 115439 4
23 NUT, hex, self-locking; M5 x 0.8 105332 105332 105332 105332 4
24 QUICK CONNECTOR, elbow, 90_, tube;
1/8 npt(m) x 1/4 in. (6 mm) OD tube; acetal
Not used 114367 Not used 114367 1
25 WASHER, flat 110874 110874 110874 110874 4
30 SCREW, set; 1/4–20 x 1/4 in. (6 mm) 101962 101962 101962 101962 2
31 PLUG, pipe; 3/8 npt; not shown 100040 100040 1
ELBOW, tube fitting, 90_; 3/8 npt(m) x
1/4 in. (6 mm) OD tube
114366 114366 1
39 PLUG, agitator; not shown 114575 114575 1
AGITATOR; see manual 306565 224571 224571 1
40 AGITATOR GROUND WIRE Not used 240585 Not used 240585 1
41 TUBE; nylon; 1/4 in. (6 mm) OD;
9.6 in. (244 mm) long
Not used Obtain
locally
Not used Obtain
locally
1
42 STRAINER, fluid inlet 187190 187190 187190 187190 1

18 308766
Fluid Regulator Parts
15:1 Monark Stainless Steel Packages, Part Nos. 232457, 232458, and 232461
15:1 Monark Carbon Steel Packages, Part Nos. 232463, 232464, and 232467
NOTE: The following part numbers apply only to packages supplied with a fluid regulator. Part numbers vary by
package. To find the part number used in your package, read down the chart to find the desired ref. no., then read
left to right to find the part number for your package.
Packages
Ref.
No. Description
SST
232457,
232458,
232461
CST
232463,
232464,
232467,
Qty
201 FLUID PRESSURE REGULATOR; sst; see manual 307886 222121 222121 1
202 TEE; cst; 1/4 npt(m) x 1/4 npt(f) 108638 1
TEE; sst; 1/4 npt(m) x 1/4 npt(f) 185281 1
203 GAUGE, pressure, fluid; cst 102814 1
GAUGE, pressure, fluid; sst 112564 1
204 SWIVEL; cst; 1/4 npt x 1/4 npsm 162453 2
SWIVEL; sst; 1/4 npt x 1/4 npsm 166846 2
205 BRACKET, mounting, fluid regulator 193306 193306 1
206 LOCKWASHER; 1/4 in. 100016 100016 2
207 CAPSCREW, hex hd; 1/4–20 x 5/8 in. (16 mm) 100270 100270 2
208 PLUG, pipe; 1/4 npt 111697 111697 1
8236A
201202, 208 203
204
205
206
207
101 (Ref)
13 (Ref)

308766 19
Hose and Gun Parts
23:1 Monark Carbon Steel Packages, Part Nos. 232439 and 232443
23:1 Monark Stainless Steel Packages, Part Nos. 232451 and 232455
15:1 Monark Stainless Steel Packages, Part Nos. 232457 and 232461
15:1 Monark Carbon Steel Packages, Part Nos. 232463 and 232467
NOTE: The following part numbers apply only to packages supplied with a hose and gun. Part numbers vary by
package. To find the part number used in your package, read down the chart to find the desired ref. no., then read
left to right to find the part number for your package.
Packages
Ref.
No.
Description
CST
232439, 232443,
232463, 232467,
SST
232451, 232455,
232457, 232461 Qty
101 HOSE, twin, air/fluid; nylon; cst fluid fittings; 1/4 npsm (fbe);
1/4 in. (6 mm) ID; 24.6 ft (7.5 m) long
239102 1
HOSE, twin, air/fluid; nylon; sst fluid fittings; 1/4 npsm (fbe);
1/4 in. (6 mm) ID; 24.6 ft (7.5 m) long
239074 1
102 NIPPLE; cst; 1/4 npt x 1/4 npsm 162453 1
NIPPLE; sst; 1/4 npt x 1/4 npsm 166846 1
103 HOSE, whip, fluid; nylon; cst fittings;1/4 npsm (fbe);
3/16 in. (5 mm) ID; 23.6 in. (0.6 m) long
238708 1
HOSE, whip, fluid; nylon; sst fittings;1/4 npsm (fbe);
3/16 in. (5 mm) ID; 23.6 in. (0.6 m) long
239069 1
104 FILTER/SWIVEL, gun; includes replaceable item 105 239394 239394 1
105 . ELEMENT, filter; 100 mesh sst; not shown 205264 205264 1
106 AA SERIES SPRAY GUN; with AAM413 tip; see manual 311001 249242 249242 1
107 SPRAY TIP; customer’s choice; not shown AAMxxx AAMxxx 1

20 308766
Notes
