Graco Oil King 238866 Operation manual

308667
Rev. E
First choice when
quality counts.t
INSTRUCTIONS-PARTS LIST
INSTRUCTIONS
This manual contains important
warnings and information.
READ AND KEEP FOR REFERENCE.
25-Gallon (95-Liter)
Oil Kingt
Used–Oil Receiver
Model 238866, Series B
Funnel Kit
Model 243650, Series A
U.S. Patent No. Des. 395,439
Table of Contents
Warnings 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts List 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts Drawing 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical Data 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Graco Phone Number 6. . . . . . . . . . . . . . . . . . . . . . . . . . .
NOTE: This used-oil receiver can be used with the
Graco used-oil receiver evacuation system and acces-
sories documented in instruction manual 307870.
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
ECOPYRIGHT 1996, GRACO INC.
Graco Inc. is registered to I.S. EN ISO 9001
TI0414

2 308667
Symbols
Warning Symbol
WARNING
This symbol alerts you to the possibility of serious
injury or death if you do not follow the instructions.
Caution Symbol
CAUTION
This symbol alerts you to the possibility of damage to
or destruction of equipment if you do not follow the
instructions.
WARNING
INSTRUC
-
TIONS
EQUIPMENT MISUSE HAZARD
Equipment misuse can cause the equipment to malfunction and result in serious injury.
DThis equipment is for professional use only.
DRead all instruction manuals before you operate this equipment.
DUse the equipment only for its intended purpose. If you are not sure, contact your Graco distribu-
tor.
DDo not alter or modify this equipment.
DCheck equipment daily. Repair or replace worn or damaged parts immediately.
DThis equipment is intended for collection of petroleum lubricants or antifreeze only. Any other use
or collection of any other fluids could result in damage to the equipment or serious bodily injury.
DAlways wear protective eyewear, gloves, clothing, and respirator as recommended by the fluid and
solvent manufacturer.
DComply with all applicable local, state, and national fire, electrical, and safety regulations.
DDispose of waste fluids according to all local, state, and national guidelines.
FIRE AND EXPLOSION HAZARD
Poor ventilation, open flames, or sparks can cause a hazardous condition and result in a fire or explo-
sion and serious injury.
DIf you are using this unit with an evacuation system, make sure the pumping system is installed
and grounded according to the manufacturer’s recommendation.
DProvide fresh air ventilation to avoid the buildup of flammable fumes.
DExtinguish all open flames in the work area.
DDo not smoke in the work area.
United States Government safety standards have been adopted under the Occupational Safety and Health Act.
You should consult these standards–particularly the General Standards, Part 1910.

308667 3
Operation
Used Oil Receiver Operation
Refer to parts drawing. Squeeze the handles together on the torsion spring (8), and slide the funnel up or down to
achieve the proper height.
WARNING
To lower the center of gravity and reduce the possibility of tipping, make sure you lower
the funnel before you roll the unit anywhere.
To ensure that the funnel does not plug and fill up, keep the strainer (24) clean.
DTo drain the unit, use the lower drain, or use an evacuation system as described in instruction manual
307870.
WARNING
To prevent spill, do not fill unit above the 25 gallon indication on the site tube.
CAUTION
NOTE: If you will use the lower drain, remove the pipe plug (12) from the tee (10), and replace it
with the drain valve (25) before you put any fluid into the unit.
DFor ease in positioning the unit during use, it is best to guide the unit by the front handle, because the
pivoting casters are on the front.

4 308667
Parts Drawing
21
1
2a
34
6
7
9
10
16
16
11
13
14
17
19
20
22
22
24
8
12
25
1Drain valve handle is shown in the
closed position. To open it, rotate
the handle so it points away from
the unit.
1
26
27
15
TI0415
2b
2c
2d
2e
15
2
2Torque to 30 –35 in.lbs.

308667 5
Parts List
Used-Oil Receiver, Model 238866, Series B
Ref.
No. Part No. Description Qty.
1 276445 TANK; 25 gallon (95 liter) 1
2 243650 FUNNEL ASSEMBLY 1
2a FUNNEL 1
2b SCREW, machine, pan head,
5/16–18 UNC 4
2c 111959 O–RING 4
2d TUBE, drain 1
2e 116092 GASKET 1
3 113645 CASTER, polyurethane;
3 in. (76 mm) 2
4 113647 WHEEL, semi-pneumatic, syn-
thetic rubber;10.5 in. (267 mm) 2
6 191748 COLLAR, funnel 1
7 191752 AXLE 1
8 104820 SPRING, torsion 1
9 192871 TUBE, sight;
1.29 in. O.D x 1 in. I.D. x 29 in. 1
10 113655 TEE, pipe;
3/4 in. x 3/4 in. x 3/4 in. 1
11 113656 NIPPLE, pipe; 3/4 in. x 3/4 in. 1
12 113657 PLUG, pipe; 3/4 in. 1
Ref.
No. Part No. Description Qty.
13 113648 FILL CAP, vented 1
14 113783 SCREW, machine, panhead;
1/4–20 UNC–2A 4
15 113908 CLAMP, hose; 1.25 in. (32 mm) 2
16 113649 ADAPTER, hose 2
17 113658 CREST NUT, hat 2
19 801940 BOLT, hex hd; 5/16–18 x 3/4 in. 8
20 100214 WASHER, lock; 5/16 in. 8
21 191824 WASHER, spacer;
0.66 in. I.D. x 0.25 in. thick 2
22 111841 WASHER, plain; 5/8 in. 4
24 196562 STRAINER; 20 x 20 S.S. mesh 1
25 113895 VALVE, drain; 3/4 in. 1
26 113902 COUPLING, cam, male; 3/4 in. 1
27 113907 COUPLING, cam, female; 3/4 in. 1
Technical Data
Length 24 in. (610 mm). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Width 24 in. (610 mm). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Height
with bowl at lowest adjustment 45 in. (1143 mm). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
with bowl at highest adjustment 69 in. (1573 mm). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dry Weight 54 lb (24.5 kg). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid inlet/inspection port size 3 in. (76 mm) buttress. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid outlet fitting size 3/4 in. npt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wetted parts linear low-density polyethylene (LLDPE), zinc-plated steel,. . . . . . . . . . . . . . . .
brass, nylon, polypropylene, PVC, Buna–N, polyurethane
Recommended operating temperature 30_to 105_F (–1_to 41_C). . . . . . . . . . . . . . . . . . . .
