Graco Husky 1050A Instruction Manual

Intended for fluid transfer applications powered by sweet natural gas (less than 4 ppm
hydrogen sulfide) in accordance with American and Canadian National Standards for
Natural Gas Operated Diaphragm Pumps (ANSI LC 6-2008 and CSA TIL R-14).
For professional use only.
See page 3 for model information.
120 psi (0.83 MPa, 8.3 bar) Maximum Fluid
Working Pressure
120 psi (0.83 MPa, 8.3 bar) Maximum Gas Input
Pressure
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
ti13946a
Operation
Husky®1050A,
CSA-Certified
Diaphragm Pumps 313598C
ENG
151481
II 2 GD c IIC T4
0359

Related Manual
2313598C
Contents
Related Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Process Fluid Compatibility . . . . . . . . . . . . . . . . . 3
ATEX Note . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
General Information . . . . . . . . . . . . . . . . . . . . . . 7
Tighten Fasteners Before Setup . . . . . . . . . . . . . 7
Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Gas Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Exhaust Ventilation . . . . . . . . . . . . . . . . . . . . . . . 9
Fluid Supply Line . . . . . . . . . . . . . . . . . . . . . . . 11
Fluid Outlet Line . . . . . . . . . . . . . . . . . . . . . . . . 11
Fluid Inlet and Outlet Ports . . . . . . . . . . . . . . . . 11
Fluid Pressure Relief Valve . . . . . . . . . . . . . . . . 12
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Pressure Relief Procedure . . . . . . . . . . . . . . . . 13
Flush the Pump Before First Use . . . . . . . . . . . 13
Tighten Fasteners Before Setup . . . . . . . . . . . . 13
Starting and Adjusting the Pump . . . . . . . . . . . 13
Pump Shutdown . . . . . . . . . . . . . . . . . . . . . . . . 13
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Maintenance Schedule . . . . . . . . . . . . . . . . . . . 14
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Tighten Threaded Connections . . . . . . . . . . . . . 14
Flushing and Storage . . . . . . . . . . . . . . . . . . . . 14
Torque Instructions . . . . . . . . . . . . . . . . . . . . . . 15
Repair and Parts . . . . . . . . . . . . . . . . . . . . . . . . 15
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Performance Chart . . . . . . . . . . . . . . . . . . . . . . . . . 18
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . 20
Graco Information . . . . . . . . . . . . . . . . . . . . . . . . . 20
Related Manual
Manual Description
313435 Husky 1050 Air-Operated
Diaphragm Pump, Repair/Parts

Models
313598C 3
Models
Process Fluid Compatibility
Models with Buna-N seats, balls, and diaphragms:
Petroleum-based fluids, water, oils, hydrocarbons, mineral spirits.
NO acetone, MEK, ozone, chlorinated hydrocarbons, nitro hydrocarbons.
Models with FKM Fluoroelastomer seats, balls, and diaphragms:
Acids, xylene, mineral spirits, water, oils, unleaded fuels.
NO ketones, low molecular weight ester and nitro containing compounds.
ATEX Note
The muffler included with the pump is not approved for use in explosive atmosphere locations.
ATEX applications require the use of a metal or conductive plastic muffler, or remote exhaust
using static-free hoses or metal piping.
Graco
Part Graco Matrix Identification Number
Maximum
Working Pressure
psi (MPa, bar)
647043 1050A-AC1AA1BNBNBN— 120 (0.83, 8.3)
647047 1050A-AC1AA1FKFKFK— 120 (0.83, 8.3)
647124 1050A-AC1AA2BNBNBN— 120 (0.83, 8.3)
647128 1050A-AC1AA2FKFKFK— 120 (0.83, 8.3)
Pump size
and material
1050A
Configuration Fluid Covers
and Manifolds
A1 or A2
Seats, Check Balls,and
Diaphragms
BN or FK
Manifold
O-rings
—AC1A
1 inch ports,
50 gpm,
Aluminum
Aluminum
Center
Section and
Air Valve
CSA-Certified Standard No Data
Monitoring A1
Aluminum, npt
A2
Aluminum, bspt
BN
Buna-N
FK
FKM Fluoroelastomer
None

Warnings
4313598C
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this equip-
ment. The exclamation point symbol alerts you to a general warning and the hazard symbol refers
to procedure-specific risk. Refer back to these warnings. Additional, product-specific warnings
may be found throughout the body of this manual where applicable.
WARNING
FIRE AND EXPLOSION HAZARD
When flammable fluids are present in the work area, such as gasoline and windshield
wiper fluid, be aware that flammable fumes can ignite or explode. To help prevent fire
and explosion:
• Use equipment only in well ventilated area.
• Eliminate all ignition sources; such as cigarettes and portable electric lamps.
• Keep work area free of debris, including rags and spilled or open containers of sol-
vent and gasoline.
• Route exhaust away from all sources of ignition. If diaphragm ruptures, fluid may be
exhausted with gas. See Exhaust Ventilation, page 9.
• Do not plug or unplug power cords, or turn lights on or off when flammable fumes
are present.
• Ground all equipment in the work area. See Grounding instructions.
• Use only grounded hoses.
• Hold gun firmly to side of grounded pail when triggering into pail.
• If there is static sparking or you feel a shock, stop operation immediately. Do not
use equipment until you identify and correct the problem.
• Keep a working fire extinguisher in the work area.

Warnings
313598C 5
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
• Do not operate the unit when fatigued or under the influence of drugs or alcohol.
• Do not exceed the maximum working pressure or temperature rating of the lowest
rated system component. See Technical Data in all equipment manuals.
• Use fluids and solvents that are compatible with equipment wetted parts. See Tech-
nical Data in all equipment manuals. Read fluid and solvent manufacturer’s warn-
ings. For complete information about your material, request MSDS from distributor
or retailer.
• Do not leave the work area while equipment is energized or under pressure. Turn
off all equipment and follow the Pressure Relief Procedure when equipment is not
in use.
• Check equipment daily. Repair or replace worn or damaged parts immediately with
genuine manufacturer’s replacement parts only.
• Do not alter or modify equipment.
• Use equipment only for its intended purpose. Call your distributor for information.
• Route hoses and cables away from traffic areas, sharp edges, moving parts, and
hot surfaces.
• Do not kink or over bend hoses or use hoses to pull equipment.
• Keep children and animals away from work area.
• Comply with all applicable safety regulations.
PRESSURIZED EQUIPMENT HAZARD
Fluid from the gun/dispense valve, leaks, or ruptured components can splash in the
eyes or on skin and cause serious injury.
• Follow the Pressure Relief Procedure when you stop spraying and before clean-
ing, checking, or servicing equipment.
• Tighten all fluid connections before operating the equipment.
• Check hoses, tubes, and couplings daily. Replace worn or damaged parts immedi-
ately.
PRESSURIZED ALUMINUM PARTS HAZARD
Use of fluids that are incompatible with aluminum in pressurized equipment can cause
serious chemical reaction and equipment rupture. Failure to follow this warning can
result in death, serious injury, or property damage.
• Do not use 1,1,1-trichloroethane, methylene chloride, other halogenated
hydrocarbon solvents or fluids containing such solvents.
• Many other fluids may contain chemicals that can react with aluminum. Contact
your material supplier for compatibility.
WARNING

Warnings
6313598C
PLASTIC PARTS CLEANING SOLVENT HAZARD
Many solvents can degrade plastic parts and cause them to fail, which could cause
serious injury or property damage.
• Use only compatible water-based solvents to clean plastic structural or pres-
sure-containing parts.
• See Technical Data in this and all other equipment instruction manuals. Read fluid
and solvent manufacturer’s MSDS’s and recommendations.
TOXIC FLUID OR FUMES HAZARD
Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on
skin, inhaled, or swallowed.
• Read MSDS’s to know the specific hazards of the fluids you are using.
• Route exhaust away from work area. If diaphragm ruptures, fluid may be exhausted
with gas.
• Store hazardous fluid in approved containers, and dispose of it according to appli-
cable guidelines.
BURN HAZARD
Equipment surfaces and fluid that’s heated can become very hot during operation. To
avoid severe burns:
• Do not touch hot fluid or equipment.
PERSONAL PROTECTIVE EQUIPMENT
You must wear appropriate protective equipment when operating, servicing, or when in
the operating area of the equipment to help protect you from serious injury, including
eye injury, hearing loss, inhalation of toxic fumes, and burns. This equipment includes
but is not limited to:
• Protective eyewear, and hearing protection.
• Respirators, protective clothing, and gloves as recommended by the fluid and sol-
vent manufacturer
WARNING

Installation
313598C 7
Installation
General Information
• The Typical Installation shown in FIG. 3 is
only a guide for selecting and installing sys-
tem components. Contact your Graco dis-
tributor for assistance in planning a system
to suit your needs.
• Installation and use must be in accordance
with the American and/or Canadian
National Standards for Natural Gas Oper-
ated Diaphragm Pumps (ANSI LC 6-2008,
CSA TIL R-14) and must comply with all
local, state, and federal codes.
• If the diaphragm ruptures, natural gas may
mix with the fluid being pumped. Take
appropriate precautions.
Tighten Fasteners Before Setup
Before using the pump for the first time, check
and retorque all external fasteners. See
Torque Instructions, page 15.
Mounting
1. Be sure the mounting surface can support
the weight of the pump, hoses, and acces-
sories, as well as the stress caused during
operation.
2. Mount in an upright, horizontal position as
shown in FIG. 3.
3. For all mountings, be sure the pump is
bolted directly to the mounting surface.
4. For ease of operation and service, mount
the pump so air valve, gas inlet, fluid inlet
and fluid outlet ports are easily accessible.
5. Rubber Foot Mounting Kit 236452 is avail-
able to reduce noise and vibration during
operation.
Grounding
The equipment must be grounded. Grounding
reduces the risk of static and electric shock by
providing an escape wire for the electrical cur-
rent due to static build up or in the event of a
short circuit.
Pump: See FIG. 1. Loosen the grounding
screw (GS). Insert one end of a 12 ga. mini-
mum ground wire (R) behind the screw and
tighten the screw securely. Connect the clamp
end of the ground wire to a true earth ground.
A ground wire and clamp, Part 238909, is
available from Graco.
• This pump exhausts natural gas and must
be ventilated to a remote area. See
Exhaust Ventilation on page 9.
• Never lift a pump under pressure. If
dropped, the fluid section may rupture.
Always follow the Pressure Relief Proce-
dure on page 13 before moving or lifting
the pump.
This pump must be electrically grounded
using the grounding conductor provided.
Improper grounding can cause hazardous
operation.

Installation
8313598C
Gas and fluid hoses: Use only grounded
hoses with a maximum of 500 ft (150 m) com-
bined hose length to ensure grounding
continuity.
Solvent pails used when flushing: Follow
local code. Use only conductive metal pails,
placed on a grounded surface. Do not place
the pail on a nonconductive surface, such as
paper or cardboard, which interrupts ground-
ing continuity.
Fluid supply container: follow local code.
Suction device nozzle: must be bonded to
metal container from which it is suctioning by
firm metal-to-metal contact to a properly
grounded suction hose and pump.
Piping, valves, and fittings: use only electri-
cally conductive materials. Bond and ground
per code.
Check your system electrical continuity after
the initial installation, and then set up a regular
schedule for checking continuity to be sure
proper grounding is maintained.
Gas Line
See FIG. 3, page 10.
1. Install a regulator (C) and gauge to control
the fluid pressure. Locate it close to the
pump.
2. Locate a bleed-type master gas valve (B,
required in your system) close to the pump
and use it to relieve trapped natural gas. Be
sure the valve is easily accessible from the
pump and located downstream from the
regulator.
3. Locate another bleed-type master valve (E)
upstream from all natural gas line accesso-
ries and use it to isolate them during clean-
ing and repair.
4. A filter (F) removes harmful dirt and mois-
ture from the compressed gas supply.
5. Install a grounded, flexible gas hose
between the accessories and the 1/2 in.
npt(f) pump inlet (D). See FIG. 3. Use a
minimum 1/2 in. (13 mm) ID hose.
FIG. 1. Ground Screw and Wire
GS R
ti12214a
Trapped gas can cause the pump to cycle
unexpectedly, which could result in serious
injury from splashing.

Installation
313598C 9
Exhaust Ventilation
The gas exhaust port is 3/4 npt(f). Do not
restrict the gas exhaust port. Excessive
exhaust restriction can cause erratic pump
operation.
1. Remove the muffler (T) from the pump gas
exhaust port.
2. Install a grounded exhaust hose (U) and
connect the muffler (T) to the other end of
the hose. The minimum size for the exhaust
hose is 3/4 in. (19 mm) ID. If a hose longer
than 15 ft (4.57 m) is required, use a larger
diameter hose. Avoid sharp bends or kinks
in the hose.
3. Place a container at the end of the exhaust
line to catch fluid in case a diaphragm rup-
tures. Locate the container away from all
sources of ignition, including pilot lights and
waste materials. If the diaphragm ruptures,
the fluid being pumped will exhaust with the
natural gas.
Be sure to read and follow the TOXIC FLUID
OR FUMES HAZARD warning, page 6, and
FIRE AND EXPLOSION HAZARD warning,
page 4, before operating this pump. You must
vent the exhaust to a safe location, such as
away from people, animals, food handling
areas, and all sources of ignition. Vent in
accordance with local codes, or in the
absence of local codes, an industry or
nationally recognized code having jurisdic-
tion over the specific installation.
FIG. 2. Vent exhaust gas
Key:
A Main natural gas supply line
B Bleed-type master gas valve
(required for pump)
CGasregulator
DGasinlet
E Master gas valve (for accessories)
F Gas line filter
T Muffler
U Grounded gas exhaust hose
V Container for remote gas exhaust
A
B
CD
EF
T
U
V
ti14219a

Installation
10 313598C
Key:
A Main natural gas supply line
B Bleed-type master gas valve (required)
C Gas regulator
DGasinlet
E Master gas valve (for accessories)
F Gas line filter
G Fluid suction line
J Fluid drain valve (required)
K Fluid shutoff valve
L Fluid line
M Fluid inlet
R Ground wire (required; see page 7 for
installation instructions)
U Grounded gas exhaust hose
FIG. 3. Typical Installation
1
to remote
exhaust
location
EF
C
BA
KL
J
G
M
R
U
ti14359a
D
