Gradus Group REMORA User manual

RBP-URSAM-RIG
REMORA

THANK YOU FOR CHOOSING AXLER
The Axler Remora Shoulder Rig is specifically
designed to add functionality to Blackmagic
Design URSA Mini cameras by adding a shoulder
rig that accepts the URSA Mini’s viewfinder
and side handle. It features a baseplate with a
shoulder pad, and receivers for two 15 mm rods
so you can add a matte box or follow focus to the
rig. A side rosette accommodates an extension
arm that places the URSA Mini’s side handle at a
comfortable arm’s length so you can control the
camera functions and steady your shoulder rig
at the same time. The Remora Shouder Rig also
comes with a top handle with an adapter to attach
the URSA viewfinder to complete your rig.

•Please read and follow these instructions, and
keep this manual in a safe place.
•Keep this product away from children.
•Make sure everything is secure before
proceeding.
•Make sure this product is intact and that there
are no missing parts.
•To avoid damage to this product, be careful not
to overtighten or improperly thread any of the
threaded fittings.
•All images are for illustrative purposes only.
PRECAUTIONS
SPECIFICATIONS
Baseplate
Dimensions
(L�W�H)
9.5 �4.4 �1.4 in.
(24.2 �11.2 �3.5 cm)
Top Handle
Dimensions
(L�W�H)
5.4 �1.5 �2.75 in.
(13.7 �3.9 �7 cm)
Extension Arm
Dimensions
(L�W�H)
8.3 �1.3 �1.2 in.
(21 �3.3 �3.2 cm)
Material Body: Aluminum
Shoulder pad: Foam
rubber
Weight 4.3 lb. (1.95 kg)

1. Top handle
2. Viewfinder adapter plate
3. Baseplate
4. Locking knobs
5. Extension arm
6. 15 mm rods (×2)
7. Side handle extension cable
8. Assembly tools and hardware
OVERVIEW
8
4
6
7
1
2
3
4
5

Fig. 2
Fig. 3
ATTACHING THE BASEPLATE
Attach the baseplate to the URSA mini camera
to use the shoulder rig feature, or to mount the
included 15 mm rods and add an accessory such
as a matte box or follow focus to the rig.
Use the two slotted screws to attach the
baseplate to the camera body. (Fig. 1)
ATTACHING THE TOP HANDLE
To attach the top handle to the URSA Mini, follow
these steps:
1. Attach the viewfinder adapter plate to the
base of the top handle. Use the small hex key to
tighten the four small hex screws until secure.
(Fig. 2)
2. Secure the top handle and viewfinder adapter
plate to the camera. Use the large hex key to
tighten the two large hex screws. (Fig. 3)
Fig. 1

ADDING A VIEWFINDER
To attach the URSA Viewfinder to the rig, follow
these steps:
1. Follow the instructions above in Attaching the
Top Handle .
2. Slide the viewfinder onto the viewfinder
plate’s rails. Adjust it to the desired position,
and secure it with the included thumbscrew.
(Fig.4)
ADDING A FOLLOW FOCUS OR MATTE
BOX
To use the Remora Shoulder Rig with a matte box
or follow focus:
1. Insert the rods into the 15 mm receivers, and
tighten the locking knobs until secure. (Fig.5)
Make sure the rods extend far enough to
accommodate your accessory.
2. Mount your accessory onto the rods, and
make the necessary connection to your
camera and lens.
Fig. 4
Fig. 5

ATTACHING THE SIDE HANDLE
EXTENSION ARM
Attach the side handle extension arm to move
the URSA Mini’s side handle away from the side
of the camera to a comfortable arm’s length. The
extension arm also lets you balance and steady
your shoulder rig while you’re shooting.
1. Align the extension arm’s rosette, rosette
screw, and receiver on the baseplate. (Fig.6)
2. Screw in the extension arm until secure. (Fig.6)
3. Screw the side handle onto the extension
arm, and use the extension cable to make
the appropriate connection to the URSA Mini
camera. (Fig.7)
ATTACHING ACCESSORIES
The top handle features 1/4-20 mounting points
and a cold shoe for accessories like LED lights,
microphones, or an articulating arm for a monitor.
Fig. 6
Fig. 7

www.AxlerSupports.com
GG3
AXLER
®
A Gradus Group Brand
ONE-YEAR LIMITED WARRANTY
This Axler product is warranted to the original purchaser to
be free from defects in materials and workmanship under
normal consumer use for a period of one (1) year from the
original purchase date or thirty (30) days after replacement,
whichever occurs later. The warranty provider’s
responsibility with respect to this limited warranty shall
be limited solely to repair or replacement, at the provider’s
discretion, of any product that fails during normal use of
this product in its intended manner and in its intended
environment. Inoperability of the product or part(s) shall be
determined by the warranty provider. If the product has been
discontinued, the warranty provider reserves the right to
replace it with a model of equivalent quality and function.
This warranty does not cover damage or defect caused
by misuse, neglect, accident, alteration, abuse, improper
installation or maintenance. EXCEPT AS PROVIDED
HEREIN, THE WARRANTY PROVIDER MAKES NEITHER ANY
EXPRESS WARRANTIES NOR ANY IMPLIED WARRANTIES,
INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. This warranty provides you with specific legal
rights, and you may also have additional rights that vary from
state to state.
To obtain warranty coverage, contact the Axler Customer
Service Department to obtain a return merchandise
authorization (“RMA”) number, and return the defective
product to Axler along with the RMA number and proof
of purchase. Shipment of the defective product is at the
purchaser’s own risk and expense.
For more information or to arrange service, visit
www.axlersupports.com or call Customer Service at
212-594-2353.
Product warranty provided by the Gradus Group.
www.gradusgroup.com
Axler is a registered trademark of the Gradus Group.
© 2020 Gradus Group LLC. All Rights Reserved.
