HT704
Analog Telephone Adapter
QuickStart
Guide
QuickStart
Guide

~1~
EN
The HT704 is not pre-configured to support or
carry emergency calls to any type of hospital,
law enforcement agency, medical care unit
(“Emergency Service(s)”) or any other kind
of Emergency Service. You must make ad-
ditional arrangements to access Emergency
Services. It is Your responsibility to purchase
SIP-compliant Internet telephone service,
properly configure the HT704 to use that ser-
vice, and periodically test your configura-
tion to confirm that it works as You expect.
If You do not do so, it is Your responsibility to
purchase traditional wireless or landline tele-
phone services to access Emergency Servic-
es.
GRANDSTREAM DOES NOT PROVIDE CON-
NECTIONS TO EMERGENCY SERVICES VIA THE
HT704. NEITHER GRANDSTREAM NOR ITS OF-
FICERS, EMPLOYEES OR AFFILIATES MAY BE
HELD LIABLE FOR ANY CLAIM, DAMAGE, OR
LOSS, AND YOU HEREBY WAIVE ANY AND ALL
SUCH CLAIMS OR CAUSES OF ACTION ARIS-
ING FROM OR RELATING TO YOUR INABILITY
TO USE THE HT704 TO CONTACT EMERGENCY
SERVICES, AND YOUR FAILURE TO MAKE AD-
DITIONAL ARRANGEMENTS TO ACCESS EMER-
GENCY SERVICES IN ACCORDANCE WITH
THE IMMEDIATELY PRECEDING PARAGRAPH.
~2~
PRECAUTIONS
PACKAGE CONTENTS
Power Adapter
QUICKSTART GUIDE
12V
• Do not attempt to open, disassemble, or modify the
device
• Do not use a third party power adapter
• Do not expose this device to temperatures outside
range of -10 °C to +55 °C
• Do not expose the HT704 to environments
outside of the following humidity range: 10-90%RH
(non-condensing)
• Do NOT power cycle the HantyTone during system
boot up or firmware upgrade. You may corrupt firm-
ware images and cause the unit to malfunction.
Handy Tone
1 X Ethernet Cable Stand

~3~
CONNECTING THE HT704
Refer to the illustration below when following the
instructions on the next page.
OVERVIEW
Grandstream HandyTone Analog Telephone Adapt-
ers/IAD series offers a comprehensive line of afford-
able VoIP access devices based on Grandstream’s
innovative and proprietary technology platform. The
HandyTone series offers the entry-level IP Telephony
user superb audio quality, rich functionalities, interop-
erability with the leading 3rd party VoIP providers, and
compatibility with most service providers. The Handy-
Tone series is compact, works with any cordless phone
and fax machines and offers the simplicity of plug and
dial, making it ideal for the basic IP telephony user
LAN Port Reset Power
PHONE 1/2/3/4
~4~
HT704 CONFIGURATION
1. Connect a standard touch-tone analog
telephone (or fax machine) to PHONE 1/2/3/4 port.
2. Insert the Ethernet cable into the LAN port of
HandyTone and connect the other end of the Ether-
net cable to an uplink port (a router, a modem, etc.).
3. UsingtheHandyToneembeddedwebserver
orIVR(InteractiveVoicePrompt)menu,youcanfurther
configure the phone using either a static IP or DHCP.
CONNECTING THE HANDYTONE
1. From the analog phone, press *** to get into
the IVR menu. Enter option 02 to obtain the Handy-
Tone’s IP address.
2. Type the HandyTone’s IP address in your PC
browser.
3. Log in using password “admin” to configure
the HandyTone.
Configure using Interactive Voice Prompt

~5~
• IP address, subnet mask and gateway IP if using
static IP.
• SIP server and/or Outbound Proxy FQDN or IP
address.
• User subscriber information: User ID, Authentica-
tion ID, Password
• HandyTone supports “Plug-n-Call” if your ITSP
(Internet Telephony Service Provider) provides
this automatic provisioning service. Ensure the
HandyTone has an internet connection (either
DHCP or static IP in your internet ready network),
then power up the device.
• Please contact your ITSP for additional settings
that may be necessary to configure the device.
You will need the following information to configure
the HandyTone via the web browser:
Application Diagram
There are three scenarios where the HT704 can be ef-
fectively used to enable any business to leverage the
benefits of VoIP and the Internet.
~6~
Please download the user manual and FAQ for
more detailed configuration instructions:
http://www.grandstream.com/products
