Grandstream Networks HT702 User manual

HT702
Analog Telephone Adapter
126 Brookline Avenue -3rd Floor,
Boston, MA 02215, USA
Tel : [phone] – 9300
Fax: [phone] – 1987
For Warranty and RMA information, please visit www.grandstream.com
Grandstream Networks, Inc.
www.grandstream.com
QuickStart
Guide

~1~ ~2~
PRECAUTIONS
PACKAGE CONTENTS
Power Adapter
12V
• Do not attempt to open, disassemble, or modify the
device
• Do not use a third party power adapter
• Do not expose this device to temperatures outside
range of -10 °C to +55 °C
• Do not expose the HT702 to environments
outside of the following humidity range: 10-90% RH
(non-condensing)
• Do NOT power cycle the HantyTone during system
boot up or rmware upgrade. You may corrupt rm-
ware images and cause the unit to malfunction.
EN
The HT702 is not pre-congured to support or
carry emergency calls to any type of hospital,
law enforcement agency, medical care unit
(“Emergency Service(s)”) or any other kind
of Emergency Service. You must make ad-
ditional arrangements to access Emergency
Services. It is Your responsibility to purchase
SIP-compliant Internet telephone service,
properly congure the HT702 to use that ser-
vice, and periodically test your congura-
tion to conrm that it works as You expect.
If You do not do so, it is Your responsibility to
purchase traditional wireless or landline tele-
phone services to access Emergency Servic-
es.
GRANDSTREAM DOES NOT PROVIDE CON-
NECTIONS TO EMERGENCY SERVICES VIA THE
HT702. NEITHER GRANDSTREAM NOR ITS OF-
FICERS, EMPLOYEES OR AFFILIATES MAY BE
HELD LIABLE FOR ANY CLAIM, DAMAGE, OR
LOSS, AND YOU HEREBY WAIVE ANY AND ALL
SUCH CLAIMS OR CAUSES OF ACTION ARIS-
ING FROM OR RELATING TO YOUR INABILITY
TO USE THE HT702 TO CONTACT EMERGENCY
SERVICES, AND YOUR FAILURE TO MAKE AD-
DITIONAL ARRANGEMENTS TO ACCESS EMER-
GENCY SERVICES IN ACCORDANCE WITH
THE IMMEDIATELY PRECEDING PARAGRAPH.
Handy Tone
QUICKSTART GUIDE
1 X Ethernet Cable Stand

~3~ ~4~
HT702 CONFIGURATION
1. Connectastandard touch-tone analogtele-
phone (or fax machine) to PHONE 1 or PHONE 2 port.
2. Insert the Ethernet cable into the LAN port of
HandyTone and connect the other end of the Ether-
net cable to an uplink port (a router, a modem, etc.).
3. Using the HandyTone embedded web server
or IVR(InteractiveVoicePrompt)menu,youcanfurther
congure the phone using either a static IP or DHCP.
CONNECTING THE HANdyTONE
1. From the analog phone, press *** to get into
the IVR menu. Enter option 02 to obtain the Handy-
Tone’s IP address.
2. Type the HandyTone’s IP address in your PC
browser.
3. Log in using password “admin” to congure
the HandyTone.
Congure using Interactive Voice Prompt
CONNECTING THE HT702
Refer to the illustration below when following the
instructions on the next page.
Overview
Grandstream HandyTone Analog Telephone Adapt-
ers/IAD series offers a comprehensive line of afford-
able VoIP access devices based on Grandstream’s
innovative and proprietary technology platform. The
HandyTone series offers the entry-level IP Telephony
user superb audio quality, rich functionalities, interop-
erability with the leading 3rd party VoIP providers, and
compatibility with most service providers. The Handy-
Tone series is compact, works with any cordless phone
and fax machines and offers the simplicity of plug and
dial, making it ideal for the basic IP telephony user
LAN Port Reset Power PHONE 1
PHONE 2

~5~ ~6~
• IP address, subnet mask and gateway IP if using
static IP.
• SIP server and/or Outbound Proxy FQDN or IP
address.
• User subscriber information: User ID, Authentica-
tion ID, Password
• HandyTone supports “Plug-n-Call” if your ITSP
(Internet Telephony Service Provider) provides
this automatic provisioning service. Ensure the
HandyTone has an internet connection (either
DHCP or static IP in your internet ready network),
then power up the device.
• Please contact your ITSP for additional settings
that may be necessary to congure the device.
You will need the following information to congure
the HandyTone via the web browser:
Please download the user manual and FAQ for
more detailed conguration instructions:
http://www.grandstream.com/products
