Granit BEX 4000 User manual

Operating Instructions
Battery-powered LED spotlight BEX 4000
11011199
These operating instructions must be read thoroughly before use and followed carefully.
Please retain these operating instructions for future reference.
Translation of the original operating instructions

Operating Instructions
11011199
Page 2
Table of contents
1. About these operating instructions and symbol description.......................................
2. Safety and accident prevention regulations................................................................
2.1 General safety instructions....................................................................................
3. Performance specifi cation............................................................................................
3.1 Technical data.......................................................................................................
4. Operation and charging instruction............................................................................
4.1 Operating instructions..........................................................................................
4.2 Charging instructions.............................................................................................
5. Safety instructions......................................................................................................
6. EU Declaration of Conformity......................................................................................
7. UKCA Declaration of Conformity.................................................................................
8. Disposal......................................................................................................................
9. Warranty....................................................................................................................
10. Addresses..................................................................................................................
11. Legal notice...............................................................................................................
3
3
3
4
4
5
5
5
6
7
8
9
10
10
10

1. About these operating instructions and symbol descriptions
Incorrect operation can lead to serious injury or death.
Incorrect operation or negligence may result in personal injury,
cause damage to the device or incorrect measurement results.
Instructions and tips for operation.
• Numbers in the fi gures (1, 2, 3 ...) refer to the corresponding numbers in brackets
(1), (2), (3) ... in the text next to the item numbers in the tables.
• Instructions, for which the order must be followed, are numbered (1, 2, 3, ...).
• Lists are marked with bullet points (•, •, ...).
2. Safety and accident prevention rules
• Do not open the device.
• Do not look directly into the lamp - risk of eye injury!
• Do not operate in direct sunlight or in extreme temperatures.
• The working temperature is between -10°C and +40°C
• Keep away from children! Do not let children play with the device,
Use only under supervision.
Operating Instructions
11011199
Page 3
WARNING
CAUTION!
CAUTION!
NOTE

Operating Instructions
11011199
Page 4
3. Performance specifi cations
3.1 Technical specifi cations
High power COB LED
High-power mode: 4000 lm (±10%)
Normal mode: 1600 lm (±10%)
ECO mode: 800 lm (±5%)
High-power mode: 1.5 hours (±15min)
Normal mode: 4.0 hours (±30min)
ECO mode: 9.0 hours (±30min)
11.1 V, 5200 mAh Li-ion, 57.72Wh
4.0 hours (±30min)
DC 15V 1.5A
IP 65, IK 07
-10 °C to +40 °C
Light source
Lighting power
Use period
Battery specifi cation
Charging time
Charging input
Protection class
Operating temperature

Operating Instructions
11011199
Page 5
4. Operation and charging instruction
4.1 Operating instructions:
• Press the switch for the fi rst time to switch the main light to ECO mode.
• Press the switch a second time, the main light switches to normal mode.
• Press the switch a third time, the main light switches to high-power mode.
• Press the switch a fourth time to switch the entire light is off.
4.2 Loading instructions:
• Turn off the lamp while charging and connect the charger to the lamp.
• The battery indicator fl ashes while charging.
• When charging is complete, the entire battery indicator remains lit
• If the battery indicator does not light up, please remove the charger and try again
• In an emergency it can be used as a power bank to charge the electronic devices.
• Always use the manufacturer's approved charger to charge the lamp.
The use of a NON-APPROVED charger can cause a fi re and destroy
the lamp.
• Charge the lamp for 4-5 hours before using it for the fi rst time.
• Fully charge the lamp before storing it for a long period of time.
• Only use the lamp's charging function if it is constantly monitored.
Unnoticed short circuits lead to fi res with high personal injury and property damage.
CAUTION!
NOTE
CAUTION!

Operating Instructions
11011199
Page 6
5. Safety instructions
• Do not use the device if there is damage on the housing, plug or cable.
In this case, contact your authorised specialist!
• Do not open the device! • Repairs or replacement of the battery should only be
carried out by a trained specialist.
• Only clean the device once the main plug has been unplugged from the power supply.
• There is a risk that damage caused by dropping the device could lead to the battery
overheating and auto-igniting.
• There is a risk of short-circuit. Repairs to the device should only be carried out by
trained specialists. In this case, contact your nearest approved dealer.
• Protect the battery against heat, continuous and/or intensive exposure to the sun, fi re,
water and moisture. Risk of explosion!
• If the battery is damaged or not used correctly, liquids can escape from
the battery. Avoid touching any liquids. Escaping battery liquids can
cause skin irritation or burns. Rinse your skin off with water if you should
come into contact with battery liquids. Should the battery liquid enter
your eye, make sure that you seek medical advice.
• There is a risk that damage caused by dropping the device could lead
to the battery overheating and auto-igniting.
• The lamp must not be placed on the light surface while in operation.
WARNING
WARNING

Operating Instructions
11011199
Page 7
6. EU Declaration of Conformity
The manufacturer,
Wilhelm Fricke SE
Zum Kreuzkamp 7
DE-27404 Heeslingen
hereby declares on its sole responsibility that the battery powered
LED spotlight BEX 4000
Type/series identifi cation: 11011199
conforms to the provisions of
2014/30/EU Electromagnetic Compatibility Directive (EMC Directive)
2011/65/EU Restriction of the Use of Certain Hazardous Substances in Electronic
and Electrical Equipment (RoHS) ((EU) 2015/863)
The product was developed in accordance with the following standards:
EN 61547:2009
Authorised person for documentation:
Mr Eike Viebrock
Wilhelm Fricke SE
Zum Kreuzkamp 7
DE-27404 Heeslingen
Heeslingen, 25/03/2022
Translation of the original Conformity Declaration
Holger Wachholtz, Executive Board
Holger Wachholtz, Executive Board

Operating Instructions
11011199
Page 8
Holger Wachholtz, Executive Board
7. UKCA Declaration of Conformity
The manufacturer,
Wilhelm Fricke SE
Zum Kreuzkamp 7
DE-27404 Heeslingen
declares under their sole responsibility that battery powered LED spotlight BEX 4000
Type/series identifi cation: 11011199
conforms to the provisions of
Electromagnetic Compatibility Regulations 2016
The Restriction of the Use of Certain Hazardous Substances in Electrical and
Electronic Equipment Regulations 2012
The product was developed in accordance with the following standards:
BS EN 61547:2009
Authorised person for documentation:
Mr. Eike Viebrock
Wilhelm Fricke SE
Zum Kreuzkamp 7
DE-27404 Heeslingen
Heeslingen, 25/03/2022
Original UKCA Declaration of Conformity
Holger Wachholtz, Executive Board

Operating Instructions
11011199
Page 9
8. Disposal
If a product is marked with the symbol of a dustbin with a cross through it, this
indicates that the product must not be disposed of with the household waste. In the
case of batteries or rechargeable batteries/accumulators containing mercury (Hg),
cadmium (Cd) or lead (Pb), the chemical symbol is shown under the crossed-out dustbin
symbol. The end user has an obligation to return the batteries or rechargeable batteries/
accumulators. These can be returned free of charge to the retailer or handed in at any
collection point. Electronic devices and rechargeable batteries/accumulators should be
handed in separately to each other. Make sure that the (rechargeable) batteries are in
a discharged state or protected from short-circuiting, if applicable. When purchasing
products, try to ensure that the products have a long service life to minimise the amount
of waste produced. If your electric or electronic device contains personal data, you are
responsible for erasing it.
Because of the substances they contain, improper disposal of batteries or rechargeable
batteries/accumulators can harm the environment and human health. Special care
should be taken when handling lithium batteries. Products should be checked to see if
they can be re-used, for example, by being repaired, before you dispose of them.
!!! Always observe local waste disposal regulations!!!

Operating Instructions
11011199
Page 10
9. Warranty
The warranty conditions of Wilhelm Fricke SE apply, which can be found in the sales
documents and the current version of the General Terms and Conditions.
In case of questions, please contact the company’s customer service line.
10. Addresses
Sales/customer service: Tel: [phone]
Spare parts sales: Fax: [phone]
Postal and shipping address: Wilhelm Fricke SE
Zum Kreuzkamp 7
DE-27404 Heeslingen
11. Legal notice
Translation of the original operating instructions for the battery powered LED spotlight BEX 4000
Manufacturer: Wilhelm Fricke SE - DE-27404 Heeslingen
1st edition february 2022
©2022 Wilhelm Fricke SE
Reproduction in whole or in part is prohibited without the written consent of the
Wilhelm Fricke SE company.
All product names mentioned in these operating instructions are trademarks
of their respective companies.
Printed on paper made from chlorine and acid-free bleached pulp.
