GRASS VALLEY CameraMan User manual

CameraMan
1-CCD ANALOG ROBOTIC CAMERA SYSTEM
Installation and Operation Manual
L1204101 Rev D
2000

3 CameraMan Installation and Operation Manual
Contacting Grass Valley
Copyright © Grass Valley. All rights reserved.
Grass Valley Web Site
The www.thomsongrassvalley.com web site offers the following:
Online User Documentation — Current versions of product catalogs, brochures,
data sheets, ordering guides, planning guides, manuals, and release notes
in .pdf format can be downloaded.
FAQ Database — Solutions to problems and troubleshooting efforts can be
found by searching our Frequently Asked Questions (FAQ) database.
Software Downloads — Software updates, drivers, and patches can be down-
loaded.
Region Voice Fax Address Web Site
North America [phone]
Support: 530-478-4148
Sales: [phone]
Support: [phone]
Grass Valley
P.O. Box 599000
Nevada City, CA 95959-7900
USA
www.thomsongrassvalley.com
Pacific Operations [phone]
Support: 852-2585-6579
[phone]
U.K., Asia, Middle East [phone] [phone]
France [phone]
Germany, Europe [phone] [phone]

Table of Contents
CameraMan1-CCD Camera System Installation and Operations Manual iii
MEET YOUR CAMERAMAN ?
??
?............................... 1-1
GENERAL INFORMATION ...................................................... 1-1
?About this Manual...........................................................1-1
?Support Information........................................................1-1
PRODUCT INFORMATION ...................................................... 1-2
?Equipment Checklist ........................................................1-2
?Product Description .........................................................1-2
?Upgrade Packages...........................................................1-3
Student Camera Upgrade Package ...................................... 1-3
Presenter Camera Upgrade Package.................................... 1-3
Personal Locator Camera Upgrade Package.........................1-3
Deluxe Camera Upgrade Package........................................1-3
?Recommended Accessories .............................................1-4
Camera Control Keypad ......................................................1-4
SHOT Director .....................................................................1-4
CameraMan?Tally Light...................................................... 1-4
SCRIPT Viewer Display.........................................................1-4
1-CCD CAMERA SYSTEM COMPONENTS................................. 1-5
?1-CCD CameraMan
?Camera...........................................1-5
?CameraMan?Connector Box ..........................................1-5
?CameraMan?Power Supply ............................................1-5
?Connection Accessories ...................................................1-5
CAMERAMAN?JACKS AND SWITCHES ................................... 1-6
?Connection Jacks.............................................................1-6
INSTALLATION AND STARTUP ............................ 2-1
MOUNTING YOUR CAMERAMAN?CAMERA ............................ 2-1
CONNECTING TO THECAMERA SYSTEM .................................. 2-2
?Restraining the Cable Connections.................................. 2-2
?Connecting the Video Output ......................................... 2-2
?Connecting to the RS-232 Port........................................ 2-3
?Connecting the Power Supply......................................... 2-4
CONNECTING CAMERA CONTROL DEVICES .............................. 2-5
?Camera Control Keypad or Tracking System Keypad....... 2-5
?SHOT Director................................................................. 2-5
SWITCH CONFIGURATION..................................................... 2-6
?Conguration Table ........................................................ 2-7
SYSTEM STARTUP ............................................................... 2-8
?Powering Up................................................................... 2-8
?Setting Up Gen Lock....................................................... 2-8
APPENDICES ......................................................... 3-1
A: MULTIPLE CAMERA APPLICATIONS .................................... 3-1
?Daisy-chain Network Conguration................................. 3-1
B: CAMERA SPECIFICATIONS................................................. 3-2
?1-CCD General Pan/Tilt Camera ...................................... 3-2
?CameraMan?Clearance.................................................. 3-2
C: TYPICAL SYSTEM DIAGRAM ............................................. 3-3
D: P
IN-OUT DIAGRAMS ....................................................... 3-4
E: F
IELD OFVIEW SPECIFICATIONS ......................................... 3-5
F: T
ROUBLESHOOTING......................................................... 3-6
INDEX ................................................................... 4-1

CameraMan?1-CCD Camera System Installation and Operations Manual 1-5
Meet Your CameraMan?
??
?
General Information
Your new CameraMan
?1-CCD General Pan/Tilt Camera is unmatched in quality, exibility and expandability, providing
you with one of the best video communications cameras in the industry.
About this Manual
This manual will introduce you to your new CameraMan
?, explain
how to install, connect and co gure it, and how to use it in single
and multi-camera network applications. In the appendices you'll nd
diagrams and charts containing technical speci cations.
Throughout this manual, you will see the following icons:
!
This icon alerts you to important instructions in the operation
and maintenance of your CameraMan
?system.
This icon alerts you to tips or noteworthy suggestions in the
operation, use or maintenance of your CameraMan
?system.
Support Information
The manufacturer reserves the right to change speci cations and
warranty at any time without notice or obligation.
Refer all warranty and servicing issues to Customer
Support at [phone].
Section
1
DURACELL?is a registered trademark of
Duracell, Inc.

Meet Your CameraMan ?
??
?
1-6 CameraMan?1-CCD Camera System Installation and Operations Manual
Product Information
The 1-CCD General Pan/Tilt Camera System is designed for use in a variety of applications. This section
provides information on products and packages o ered. You will also nd information on upgrade
packages and recommended accessories.
Equipment Checklist
Your 1-CCD General Pan/Tilt Camera System should include the
following components:
•One 1-CCD CameraMan
?camera
•One CameraMan
?connector box (not included in Presenter
Systems)
•One CameraMan
?power supply
•One RS-485 T-connector
•One 3' CameraMan
?communications cable
•One 25' CameraMan
?keypad cable
•One 1-CCD Installation and Operations Manual
Product Description
You can control 1-CCD CameraMan's pan/tilt functions, zoom
perspective and IMAGE settings using the Camera Control
Keypad, SHOT Director, or Tracking System Keypad. These
accessories provide multi-camera control and store up to 99 presets
per camera.
The camera has a standard 12x lens and advanced camera
setup functionality and gen locking for glitch-free video switching.

Meet Your CameraMan ?
??
?
CameraMan?1-CCD Camera System Installation and Operations Manual 1-7
Upgrade Packages
The following upgrade packages are available:
Student Camera Upgrade Package
Best for: Distance Learning applications. This system allows the
camera to respond to a signal from a button on a hard-wired table-
top microphone. To make the camera focus on them, the student
presses the button, the camera instantly responds and the gate on
the microphone opens.
Includes: Programmable Response Module for distributed preset
control and Camera Control Keypad.
Presenter Camera Upgrade Package
Best for: Distance Learning, Telemedicine and Videoconferencing
applications. This system gives presenters and instructors the ability
to provide dynamic presentations while the camera automatically
follows their every move.
Includes: Tracking Ring Package, Tracking System Keypad and Main
Docking Station.
Personal Locator Camera Upgrade Package
Best for: Videoconferencing applications. This system gives each
videoconferencing participant the power to be instantly identied by
the camera with the touch of a MY TURN
TM button on individually
controlled wireless keypads.
Includes: Three RF Personal Locator Keypads and one RF
Chairperson Locator Keypad for distributed preset control.
Deluxe Camera Upgrade Package
This system combines the distributed preset control of the Personal
Locator System and the autoTRACK
TM presentation capabilities of the
Presenter Camera System.
Includes: Three RF Personal Locator Keypads, one RF Chairperson
Locator Keypad, Tracking Ring Package, Tracking System Keypad and
Main Docking Station.
mytur
n
™
Table-top
microphone
Tracking Ring
Package for
Presenter
and Deluxe
Systems
Personal Locator
Keypad for Personal
Locator and Deluxe
Systems

Recommended Accessories
The following accessories are available:
Camera Control Keypad
Whether you use it in wireless, RF, or hard-wired mode, the keypad
enables you to control the pan, tilt, zoom, focus, iris, gain, and
location presets for up to three cameras. The keypad comes standard
with the Student Camera System.
SHOT Director
Some applications require precise and exible camera control.
The SHOT Director is a joystick controller designed to give
you the ultimate in single and multi-camera control by allowing you
to adjust the pan, tilt, zoom, focus, iris and location presets on up to
16 cameras from one location. SHOT Director is available in standard
or autoTRACK
TM-equipped models.
CameraMan ?
??
?Tally Light
The CameraMan
?Tally Light provides a high-intensity visual
indication of which camera is selected in a multiple-camera
application. You simply install it into the interface on the rear of the
camera. The bright red indicator mounts to the top of a exible
shaft, allowing precise adjustment and positioning of the light for the
best possible studio-wide observation.
You can control the Tally Light through the CONTROL
Center, STUDIO software, or through an external contact closure
connected to a side-mounted Phoenix connector. All current 1-CCD
cameras are compatible with the Tally Light and previous models are
factory-upgradeable.
SCRIPT Viewer Display
Adding a full-feature teleprompting display that moves with the
camera is now available with the addition of a powerful
SCRIPT Viewer system. The 12" active-matrix, full-color displays are
available separately and mount easily to the camera. Contact your
reseller for more information on the complete SCRIPT Viewer system.
2 31
Camera Controls
Location Presets
Camera Select
C a m e r a M a n
auto
1
3
5
7
9
2
4
6
8
0
PAN/TILT
ZOOM
IN
OUT
ENTER
P A R K E R V I S I O N
®
1-CCD Camera
Control Keypad
SHOT Director
CameraMan?Tally Light
SCRIPT Viewer
Display
Meet Your CameraMan ?
??
?
1-8 CameraMan?1-CCD Camera System Installation and Operations Manual

Meet Your CameraMan ?
??
?
CameraMan?1-CCD Camera System Installation and Operations Manual 1-9
1-CCD Camera System Components
This section describes the components that are included with your 1-CCD camera system.
1-CCD CameraMan ?
??
?Camera
The CameraMan camera is the primary component and the basis for
all CameraMan camera systems.
CameraMan ?
??
?Connector Box
The connector box should be attached to the back of the camera.
This box is the connection point for all RS-232, RS-485, power and
video signals. The only time you would need to remove this box is
when you are connecting this camera to a Main Docking Station
(included with the Presenter and Deluxe Camera Systems).
!
If you purchased a Presenter or Deluxe Camera System,
you do not need a connector box.
CameraMan ?
??
?Power Supply
The power supply enables use with 120 VAC sources.
!
International Models include a 50/60Hz, 100-240V
power supply.
Connection Accessories
•RS-485 T-connector
•3' CameraMan
?communication cable
•25' CameraMan
?Keypad cable
Power Supply
1-CCD CameraMan
?Camera
Connector Box
Top of T-
connector with
RS-485 cables. Front and back of
T-connector

Meet Your CameraMan


1-10 CameraMan1-CCD Camera System Installation and Operations Manual
CameraMan

Jacks and Switches
All of the connection jacks and configuration switches described below appear on the back of your CameraMan.
!
Do not use telephone cords or jacks for any of the following connections. They are wired differently.
Connection Jacks
•PVI COM Jack – A standard 6-conductor RJ-11 jack used by
the keypads as a communication interface to the
camera system. For example, a hard-wired keypad attaches here.
•RS-485 Jack – A standard 4-conductor modular telephone jack
used for RS-485 communications between the camera and other
devices. You can use this jack to network multiple
cameras or to connect appropriate, approved
peripherals using a T-connector.
•Auxiliary Communication Port – Provides communications to
select peripherals and provides capability for future
expansion.
•RS-232 Port – A standard DB-9 female connector that provides
RS-232 communications to external devices such as PCs or other
vendor control systems.
•S-VIDEO Jack – A standard min-DIN jack that provides direct
S-VIDEO video output. S-VIDEO cable is not provided.
•Cable Restrainer – Helps keep cables from becoming dislodged
or hindering the pan and tilt of the camera.
•Composite Video Jack – A standard BNC-type jack that
provides direct composite video output. Video cable is not
provided.
•DC Power Jack - Power input for the CameraMan
?camera.
Plug only the included power supply into this jack.
Do not use any other type of power supply. This item is not
used with Presenter Systems.
•Power – Use this switch to power on/o the CameraMan
?
camera.
•Tally Light Port – Provides output and external control for the
CameraMan?Tally Light.
•Gen Lock Connector – Provides input and external control for
setting up Gen Lock.
!
If you purchased a Presenter or Deluxe Camera System,
refer to their respective manuals for information on the
Main Docking Station that replaces the connector box.
UP
DOWN
SWITCH BANK
-A- SWITCH BA NK -B-
1234567812345678
S-VIDEO
COM POSI T E
BAS E UNIT
ADDRESS
TALLYLIGHT
INTERFACE
TALLY LIGHT
INTERFACE
Back of 1-CCD camera with
connector box attached and
configuration plate
removed.
Ports and Jacks
Tally Light Port
Gen Lock Connector

CameraMan1-CCD Camera System Installation and Operations Manual 2-11
Installation and Startup
Mounting Your CameraMan

Camera
You can mount your CameraMancamera on any flat, non-slick, nonmetal surface with a minimum supporting area of 8"
x 8". Follow the instructions below:
1. Check your selected camera location to ensure that you have
enough camera and cable clearance space for the CameraMan
camera to pan and tilt without obstruction.
!
Do not mount the camera upside down or with more
than a 10 degree angle from horizontal.
Refer to Appendix E, Field of View Specifications, to
assist you with positioning the CameraMancamera to
achieve optimum optical views.
2. Locate the zero-degree position mark labeled "Front" on the
bottom of the base unit. This mark helps ensure that the base
unit is calibrated correctly.
Point this indicator mark in the direction that best reflects the
center of travel for the camera. (This is usually the center of the
room.)
!
Lift the unit by its base, not by its tilt assembly.
3. To ensure that the mounting surface is not prone to vibrations,
fasten the camera to a flat, rigid surface using a 1/4"-20 UNC
cap screw that does not extend into the base platform by
more than 0.4". (The cap screw is not included.) To use a 3/8"-
16 UNC cap screw, remove the insert provided in the mounting
screw hole.
!
To avoid overtightening, tighten this screw by hand. If
necessary, use a non-hardening threadlock to prevent
the screw from loosening. Overtightening can prevent
the camera from panning properly and may
damage the unit.
Never attempt pan or tilt movement by hand.
Always use a control device.
!
Always operate the camera indoors and follow the
temperature and humidity specifications outlined in
Appendix B, Camera Specifications.
Section
2
x
x
12.0” 22.0”
3.0”
18.0”
3/8"-16 UNC
Mounting Screw
Hole with 1/4"-20
UNC insert.
Zero degree
pan position
mark

Installation and Startup
2-12 CameraMan1-CCD Camera System Installation and Operations Manual
Connecting to the Camera System
This section provides connection instructions. Refer to the left-side connection ports.
Restraining the Cable Connections
For the following camera connections:
•Run the cables through the cable restrainer from left to right.
•Tighten the cable restrainer to prevent any cables from
dislodging.
This should result in the cables being located approximately in the
center of the camera, instead of near the edge.
!
To relieve stress on the camera and the cable
connections, fasten all cables using the cable restrainer
on the back of the camera.
Connecting the Video Output
!
CameraMansupports both composite and S-VIDEO
formats, although you can use only one at a time.
For composite format, connect to the BNC jack on the Connector
Box on the back of the camera, labeled COMPOSITE VIDEO OUT,
using a standard coaxial cable with a BNC connector (not provided).
!
Verify that the Video Select switch is set to
COMPOSITE. The switch is located behind the
switch plate on the back right of the camera. Refer
to the "Switch Configuration" topic in this section.
For S-VIDEO format, connect to the S-VIDEO jack on the back of the
camera using a standard S-VIDEO cable (not provided).
PVI C OM RS -23 2
AUXA
S-VIDEO
OUT COM POSI TE VID EO OU T DC POWER
POWER
RS-48 5
Feed cables from left
to right through the
restrainer.
S-VIDEO and
Composite Video
Out Jacks

Installation and Startup
CameraMan1-CCD Camera System Installation and Operations Manual 2-13
!
Verify that the Video Select switch is set to S-VIDEO.
The switch is located behind the switch plate on the
back right of the camera. Refer to the "Switch
Configuration" topic in this section.
For video output specifications, refer to Appendix B,
Camera Specifications.
Connecting to the RS-232 Port
CameraMan?provides for RS-232 communications using the DB-9
jack on the back of the camera, labeled RS-232. You can use this
port to control the camera using external devices such as a PC or
other vendor-control system such as AMX
TM and Creston TM.
Our RS-232 protocol is available by calling Customer Support at
[phone].
Connect to this port using a standard computer cable with a DB-9
connector. This port operates with No Parity and software hand-
shaking using High Reliability or Basic protocols.
!
Verify the protocol being used by checking the Protocol
switch on the camera. Refer to the "Switch
Configuration" topic in this section.
The COM light above the RS-232 port is used to indicate
communication activity.
For the DB-9 pin-out port information, refer to Appendix
D, Pin-out Diagrams.
COM light

Installation and Startup
2-14 CameraMan1-CCD Camera System Installation and Operations Manual
Connecting the Power Supply
You can mount the power supply with any orientation or on top of a
table or roll-about unit. Follow the steps below:
1. Verify that the power switch located on the back of the camera
is turned off.
2. Plug the 5.5mm female connector of the power supply into the
DC POWER jack on the back of the camera.
3. Connect the other end of the power supply into a 120 VAC
source.
!
Do not modify the length of the AC or the DC wiring.
PVI COM RS -232
AUXA
S-VIDEO
OUT COM POSI TE VI DEO OUT DC POWER
RS-4 85 PO WER
POWER

Installation and Startup
CameraMan1-CCD Camera System Installation and Operations Manual 2-15
Connecting Camera Control Devices
There are several ways to control your camera's movement. The following information explains how to connect and
configure the optional Camera Control Keypad and the SHOT Director.
Camera Control Keypad or Tracking System Keypad
The optional Camera Control Keypad controls the camera's
movement via wireless RF technology up to 60', or hard-wired
connection up to 250'. If you choose to use a Camera Control
Keypad in the hard-wired mode, follow the installation directions
below:
1. Connect one end of the 25' CameraManKeypad Cable included
with your camera to the RJ-11 type jack located in the battery
compartment of the keypad.
2. Connect the other end of the cable to the RJ-11 type jack on the
back of the camera, labeled PVI COM.
When the system is powered on, the light on the keypad
illuminates momentarily and you will hear two beeps
indicating that the keypad is ready for operation. The
light located above the PVI COM port indicates
communication activity.
!
Use only the cable supplied for the PVI
COM port. Using non-supplied cables such as
telephone cords may cause damage.
SHOT Director
You can connect the optional SHOT Director joystick controller in
hard-wired mode only.
To connect the SHOT Director to your camera:
1. Connect one end of the RS-485 cable to one of the RS-485 jacks
on the back of the SHOT Director.
2. Connect the other end of the cable to one of the following:
✦For single camera applications, use the jack labeled RS-485
on the back of the CameraManconnector box.
✦For multiple camera applications, use the T-connector. Use
the 3' CameraMancommunications cable (provided) to
connect the T-connector the camera's RS-485 jack. Longer
cables are available.
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
UP
DOWN
SWITCH BANK
-A- SWITCH BANK -B-
1234567812345678
S-VIDEO
COMP OSI T E
BASE UNIT
ADDRESS
TALLYLIGHT
INT ERFACE
LCD
CONTRAST LCD BRIGHT N ESS
COM 1
RS-485
18-20 VDC
1
Camera
Control
Keypad
connected
via PVI COM
Port
SHOT Director connected
via RS-485

Installation and Startup
2-16 CameraMan1-CCD Camera System Installation and Operations Manual
Switch Configuration
Now that you have connected your camera to the power supply and control devices, you need to configure the camera
to work in your specific application. To begin, remove the switch plate on the back right side of the camera by removing
the two screws holding it in place. Behind the plate you will see all of the configuration switches.
Refer to the next page for a table describing the switches.
UP
DOWN
SWITCH BANK
-A- SWITCH BANK -B-
12345678 12345678
S-VIDEO
COMPOSITE
BASEUNIT
ADDRESS
Up
Down
This diagram
shows the
default switch
configuration
of the camera
as shipped.
UP
DOWN
SWITCH BA NK
-A- SWITCH BA NK -B-
12345678
12345678
S-VIDEO
COM POSI T E
BA SE UNIT
ADDRESS
TALL Y LIGHT
INTERFACE
Switches A1 – A8 Base Unit Switches B1 – B8
Address Switch
Video Out Switch

Installation and Startup
CameraMan1-CCD Camera System Installation and Operations Manual 2-17
Configuration Table
!
After changing any switch settings, turn off the camera and
then turn it back on to activate the change.
Switch
Number Description DOWN Position UP Position Factory Default Function
A1 Lens Select Normal Adapter DOWN Use this switch with Personal Locator and Deluxe Camera Systems to indicate the use
of a lens adapter. Refer to their manuals for more information.
A2 Sub-carrier
Coarse
Adjustment
0°180°DOWN Use this switch to change the sub-carrier phase from 0°to 180°.
A3 -- -- -- DOWN NOT USED
A4 Lens
Converter
Type
Wide -- DOWN Use this switch with switch A1 to select the type of lens adapter being used. Always
set to the DOWN position.
A5 & A6 -- -- -- DOWN NOT USED
A7 Baud Rate 9600 19200 UP Use this switch to configure the camera's baud rate for the RS-232 and RS-485 ports.
A8 Memory Lock Lock Unlock UP For the majority of applications, use this switch in the UP (Unlock) position to prevent
programmed settings from being accidentally overriden.
Video Out Composite/S-
VIDEO Composite S-VIDEO DOWN
!
Use this switch to set the video source to composite (DOWN) or S-VIDEO (UP).
You must choose one source, you cannot use them simultaneously.
Base Unit
Address -- -- -- Zero (0) Use this 16-position rotary switch to set the unique identification number of your camera. If you use the optional keypad, SHOT Director, or another control system,
refer to the documentation provided with those accessories for proper configuration.
For setting up a camera network, refer to Appendix A, Multiple Camera Applications.
B1 Protocol High
Reliability Basic DOWN Use this switch to select the communication protocol to be used by the RS-232 and
RS-485 ports. The High Reliability protocol includes some advanced error checking
that is not performed in the Basic protocol.
B2 Data Source Local Remote DOWN Use this switch to determine whether the camera will receive data from a local source
such as a keypad, or from a remote source, such as a SHOT Director.
B3 Digital Zoom Off On DOWN Use this switch to turn on or off the digital zoom feature.
B4 RF Command Enable Disable DOWN
!
Use this switch to enable/disable the camera to respond to commands sent from an
RF Keypad.
When using multiple cameras networked on the RS-485 bus, only one camera should
have its RF receiver enabled. Set switch B4 on the other cameras to Disable (UP).
B5 Preset Save Manual
Gain, Iris
and Focus
Auto
Settings DOWN Use this switch to determine how the preset settings will be saved. DOWN saves your Manual Gain, Iris and Focus settings. UP saves only the Auto settings for presets and
autoTRACK views.
B6 & B7 -- -- -- DOWN NOT USED
B8 Interlink Enable Disable DOWN Use this switch in multi-camera applications. The DOWN position passes all commands
through the RS-485 communication bus to the appropriate camera. This switch has no
effect in a single camera application.

Installation and Startup
2-18 CameraMan1-CCD Camera System Installation and Operations Manual
System Startup
Once you have made all of the necessary connections and configured the camera to your application, you are ready to
turn on the system.
Powering Up
To turn on the system:
1. Switch the Power button on the back of the camera to the ON
position. The camera should automatically enter its position-
calibration mode and stop at the zero-degree pan/tilt point.
2. Verify that the camera is now facing in the direction the FRONT
label was pointing during mounting. Refer to the "Mounting
Your CameraManCamera" topic in this section.
3. If you are using the optional Camera Control Keypad, make sure
its address is the same as the address on the camera. Also verify
that the camera's pan and tilt functions are working properly.
If the camera does not move, refer to the
Troubleshooting section of your Camera Control Keypad
or SHOT Director manual.
Setting Up Gen Lock
Refer to either of the following manuals for instructions on adjusting
gen lock timing parameters:
•CameraMan

1-CCD Camera Control Keypad Operations
Manual
•SHOT Director Installation and Operations Manual
PVI C OM RS -2 3 2
AUX A
S-VIDEO
OUT COMPOSIT E VID EO OUT DC POWER
RS-48 5 POWER
POWER

CameraMan1-CCD Camera System Installation and Operations Manual 3-2
Appendices
A: Multiple Camera Applications
If your application requires that you have more than one CameraMan, you will need to set them up in a daisy-chain
network configuration.
Daisy-chain Network Configuration
To daisy-chain your cameras:
1. To connect the cameras together, plug one end of the
CameraMan?communication cable into the supplied T-
connector and plug the other end into the RS-485 port on the
back of the camera.
2. Connect each camera using a 4-conductor cable with 4-position
modular handset plugs wired straight-through:
Pin 1 . . . . Pin 1 Pin 3 . . . . Pin 3
Pin 2 . . . . Pin 2 Pin 4 . . . . Pin 4
!
Do not use a standard phone cable. These are wired
differently and may cause damage.
3. Using the BASE UNIT ADDRESS rotary switch located on the
back of the camera, configure each camera with a unique base
unit address.
EXAMPLE: Camera 1 set with address 0, camera 2 set with
address 1, etc.
4. In order to control each camera with your Camera Control
Keypad, the rotary switch inside the keypad battery
compartment must match the lowest base unit address in your
system. Only one base unit should have its RF enabled. Refer to
the "Switch Configuration" topic of Section 2, Installation and
Statup.
EXAMPLE: If the BASE UNIT ADDRESS switches are set
according to the illustration to the right, the rotary switch inside
the keypad should be set to 0. The Camera Control Keypad can
control up to 3 cameras. Refer to the "Camera Control Keypad"
topic of Section 2, Installation and Startup.
Section
3
UP
DOWN
SWITCH BA NK
-A-
12345678
UP
DOWN
SWITCH BANK
-A - SWITCHBANK -B -
1234567 812345678
S-VIDEO
CO MPOSI TE
BA SEUNI T
ADDRESS
TALL Y LI GHT
INTERFACE
UP
DOWN
SWITCHBANK
-A- SWITCH BANK -B-
12345 67812345678
S-VIDEO
COM POSI TE
BASE UNIT
AD DRESS
TALLYLIG HT
INTERFACE
T-Connector Camera 2
Camera
3
Camera 1
SWITCHBANK
-B-
123456 78
S-VIDEO
COMPOSI T E
BA SEUNI T
ADDRESS
TALL Y LI GHT
INTERFACE
BASE UNIT
ADDRESS
BASE UNIT
ADDRESS
BASE UNIT
ADDRESS
