Great Lakes WEN 721830 User manual
INSTRUCTION MANUAL
SPECIFICATIONS
18" x 30"MOVER DOLLIES
Maximum Dynamic Load 660 Pounds
Maximum Static Load 1000 Pounds
Product Dimensions 29-3/4 in. x 17-3/4 in. x 5-1/4 in.
Product Weight 7.7 Pounds
INSTRUCTION MANUAL
V. 2022.09.27
(2 PACK)
NEED HELP? CONTACT US!
Have product questions? Need technical support? Please feel free to contact us:
WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this
commitment and our dedication to qualit
y.
LIMITED WARRANTY OF WEN PRODUCTS FOR HOME USE
GREA
T LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN
consumer
power tools will be free from defects in material or workmanship during personal use for a period of two (2) years
used
for professional or commercial use. Purchaser has 30 days from the date of purchase to report missing
or
damaged parts.
SELLER’S
SOLE OBLIGATION AND YOUR EXCLUSIVE REMEDY under this Limited Warranty and, to the extent per-
mitted
by law, any warranty or condition implied by law, shall be the replacement of parts, without charge, which
are
defective
in material or workmanship and which have not been subjected to misuse, alteration, careless
handling,
misrepai
r, abuse, neglect, normal wear and tear,
improper maintenance, or other conditions adversely affecting the
Product
or the component of the Product, whether by accident or intentionally, by persons other than Seller. T
o
make
a claim under this Limited Warranty, you must make sure to keep a copy of your proof of purchase that
clearly
-
dor
of Great Lakes Technologies, LLC. Purchasing through third party vendors, including but not limited to
garage
sales,
pawn shops, resale shops, or any other secondhand merchant, voids the warranty included with this
product.
your
shipping address, phone number, serial number, required part numbers, and proof of purchase. Damaged
or
defective parts and products may need to be sent to WEN before the replacements can be shipped out.
-
turning
a product for warranty service, the shipping charges must be prepaid by the purchaser. The product
must
be
shipped in its original container (or an equivalent), properly packed to withstand the hazards of shipment.
The
product
must be fully insured with a copy of the proof of purchase enclosed. There must also be a description of
the
will be returned and shipped back to the pur
chaser at no charge for addresses within the contiguous United States.
THIS
LIMITED WARRANTY DOES NOT APPLY TO ITEMS THAT WEAR OUT FROM REGULAR USAGE OVER T
IME,
INCLUDING
BELTS, BRUSHES, BLADES, BATTERIES, ETC. ANY IMPLIED WARRANTIES SHALL BE LIMITED
IN
DUR
ATION TO TWO (2) YEARS FROM DATE OF PURCHASE. SOME STATES IN THE U.S. AND SOME
CANADIAN
PROVINCES
DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMI-
TAT
ION MAY NOT APPLY TO YOU.
IN
NO EVENT SHALL SELLER BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES
(INCLUDING
BUT
NOT LIMITED TO LIABILITY FOR LOSS OF PROFITS) ARISING FROM THE SALE OR USE OF THIS PRODUCT
.
SOME ST
ATES IN THE U.S. AND SOME CANADIAN PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITAT
ION
OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPL
Y
TO YOU.
THIS
LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER
RIGHTS
WHICH
VARY FROM STATE TO STATE IN THE U.S., PROVINCE TO PROVINCE IN CANADA AND FROM COUNTRY
TO COUNT
RY.
THIS
LIMITED WARRANTY APPLIES ONLY TO ITEMS SOLD WITHIN THE UNITED STATES OF AMERICA, CANA-
DA
AND THE COMMONWEALTH OF PUERTO RICO. FOR WARRANTY COVERAGE WITHIN OTHER
COUNTRIES,
CONT
ACT THE WEN CUSTOMER SUPPORT LINE. FOR WARRANTY PARTS OR PRODUCTS REPAIRED
UNDER
W
ARRANTY SHIPPING TO ADDRESSES OUTSIDE OF THE CONTIGUOUS UNITED STATES, ADDITIONAL
SHIPPING
CHARGES MA
Y APPLY.
INSTRUCTION MANUAL
GENERAL SAFETY WARNINGS
ASSEMBLY INSTRUCTIONS
WORK AREA SAFETY
1. Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
PERSONAL SAFETY
1. Stay alert, watch what you are doing and use common
sense when operating a tool. Do not use a tool while
you are tired or under the influence of drugs, alcohol
or medication. A moment of inattention while operating
tools may result in serious personal injury.
2. Use personal protective equipment. Always wear eye
protection. Protective equipment such as a respiratory
mask, non-skid safety shoes and hearing protection
used for appropriate conditions will reduce the risk of
personal injury.
3. Dress properly. Do not wear loose clothing or jewelry.
Keep your hair and clothing away from moving parts.
Loose clothes, jewelry or long hair can be caught in
moving parts.
TOOL USE AND CARE
1. Do not force the tool. Use the correct tool for your
application. The correct tool will do the job better and
safer at the rate for which it was designed.
2. Do not use the tool if the switch does not turn it on
and off. Any tool that cannot be controlled with the
switch is dangerous and must be repaired.
3. Disconnect the plug from the power source and/
or the battery pack from the tool before making any
adjustments, changing accessories, or storing power
tools. Such preventive safety measures reduce the risk
of starting the tool accidentally.
4. Store idle tools out of the reach of children and do
not allow persons unfamiliar with the tool or these
instructions to operate the tool. Tools are dangerous in
the hands of untrained users.
5. Maintain tools. Check for misalignment or binding of
moving parts, breakage of parts and any other condition
that may affect the tool’s operation. If damaged, have
the tool repaired before use. Many accidents are caused
by poorly maintained tools.
6. Use the tool, accessories, and tool bits, etc. in
accordance with these instructions, taking into account
the working conditions and the work to be performed.
Use of the tool for operations different from those
intended could result in a hazardous situation.
SERVICE
1. Have your power tool serviced by a qualified repair
person using only identical replacement parts. This will
ensure that the safety of the power tool is maintained.
CALIFORNIA PROP 65 WARNING
Some dust created by power sanding, sawing,
grinding, drilling, and other construction activities may
contain chemicals, including lead, known to the State
of California to cause cancer, birth defects, or other
reproductive harm. Wash hands after handling. Some
examples of these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks, cement, and other
masonry products.
• Arsenic and chromium from chemically treated
lumber.
Your risk from these exposures varies depending on
how often you do this type of work. To reduce your
exposure to these chemicals, work in a well-ventilated
area with approved safety equipment such as dust
masks specially designed to filter out microscopic
particles.
INSTRUCTION MANUAL
1. Do not climb, sit or stand on the dolly.
2. Do not exceed the loading capacity.
3. Do not use the dolly if any part is missing or damaged. Replace damaged parts immediately.
MOVER DOLLY SAFETY WARNINGS
PACKING LIST
Components
Casters (8)
(Part 721830-001)
Hex Nuts (32)
(Part 721830-002)Short Wood Sides (4) Long Wood Sides (4)
1. Place two short wood sides (Fig. 1 - 1) on a sturdy, flat surface with the bolts (Fig. 1 - 2) facing up.
2. Fit the holes in the long wood sides (Fig. 1 - 3) over the bolts on the short wood sides as shown below.
3. Fit four casters (Fig. 1 - 4) over the bolts as shown in the figure below.
4. Secure the wood sides and casters with sixteen hex nuts (Fig. 1 - 5). Make sure that all nuts are tightly secure
before beginning operation.
Fig. 1
5
55
5
4
3
1
2
22
2
