GREAT PLAINS 2S-2600 User manual

Manufacturing, Inc.
www.greatplainsmfg.com
© Copyright 2019 Printed 04/25/2019 195-201Q
EN
Table of Contents
Table of Contents
ORIGINAL INSTRUCTIONS
Pre-Delivery Manual
2S-2600 and 2S-2600F
26-Foot 2-Section Folding Drill
Read the operator’s manual entirely. When you see this symbol, the subsequent
instructions and warnings are serious - follow without exception. Your life and
the lives of others depend on it
Cover illustration may show optional equipment not supplied with standard unit.
EN

Table of Contents
Table of Contents

2S-2600 and 2S-2600F Cover iii
2019-04-25 Cover 195-201Q
© Copyright 2006, 2017, 2019 All rights Reserved
Great Plains Manufacturing, Inc. provides this publication “as is” without warranty of any kind, either expressed or implied. While every precaution has been
taken in the preparation of this manual, Great Plains Manufacturing, Inc. assumes no responsibility for errors or omissions. Neither is any liability assumed for
damages resulting from the use of the information contained herein. Great Plains Manufacturing, Inc. reserves the right to revise and improve its products as
it sees fit. This publication describes the state of this product at the time of its publication, and may not reflect the product in the future.
Trademarks of Great Plains Manufacturing, Inc. include: AccuShot, Max-Chisel, Row-Pro,
Singulator Plus, Short Disk, Swath Command, Terra-Tine, Ultra-Chisel, and X-Press.
Registered Trademarks of Great Plains Manufacturing, Inc. include: Air-Pro, Clear-Shot, Discovator, Great Plains, Land Pride, MeterCone,
Nutri-Pro, Seed-Lok, Solid Stand, Terra-Guard, Turbo-Chisel, Turbo-Chopper, Turbo-Max, Turbo-Till, Ultra-Till, Whirlfilter, and Yield-Pro.
Brand and Product Names that appear and are owned by others are trademarks of their respective owners.
Printed in the United States of America
Table of Contents
Important Safety Information.................................................1
Introduction.............................................................................4
Document Family...............................................................4
Description of Unit .............................................................4
Intended Usage ..........................................................4
Models Covered .........................................................4
Using This Manual.............................................................4
Definitions...................................................................4
Assembly.................................................................................5
Unloading Truck ................................................................5
Tools Required ..................................................................5
Pre-Assembly Checklist.....................................................5
Install Press Wheels ..........................................................6
Install Walkboards .............................................................6
Install Ladder Mounts.................................................7
Install Ladders ............................................................8
Apply Reflectors and Decals .............................................8
Walkboard Inside End Reflectors ...............................9
Slow Moving Vehicle (SMV) Reflector........................9
Ladder Reflectors and Decals ..................................10
Handles and Lights..........................................................10
Install Box Handles...................................................10
Install Lights .............................................................11
Other Assembly Items .....................................................11
Two Outlet Kit...........................................................11
Point Row Option .....................................................12
Post Assembly Checklist .................................................12
Setup......................................................................................13
Hitching............................................................................13
Electrical Connections .....................................................15
Hydraulic Hose Hookup...................................................16
Hydraulic Operations.......................................................16
Bleeding Hydraulics.........................................................17
Bleeding Opener Lift Hydraulics...............................18
Bleeding Fold Hydraulics .........................................19
Bleeding Transport Lift Hydraulics ...........................20
Leveling the Drill..............................................................21
Opener Frames Level ..............................................21
Link Tube .................................................................21
Toolbar Height..........................................................22
Wing Box Alignment.................................................23
Install Final Accessories..................................................24
Acremeter Installation ..............................................24
Open Center Conversion .........................................24
Markers ....................................................................25
Shaft Monitor............................................................26
Scraper Installation ..................................................26
Appendix ...............................................................................27
Specifications and Capacities .........................................27
Tire Inflation Chart...........................................................27
Torque Values Chart .......................................................28
Hydraulic Diagrams .........................................................29
Transport Lift ............................................................29
Fold ..........................................................................29
Dual Markers............................................................30
Single Marker ...........................................................30
Two Outlet Conversion.............................................31
Opener Lift: Standard Closed-Center.......................32
Opener Lift: Optional Open-Center ..........................33
Point-Row.................................................................34
© Copyright 2006, 2017, 2019 All rights Reserved
Great Plains Manufacturing, Inc. provides this publication “as is” without warranty of any kind, either expressed or implied. While every precaution has been
taken in the preparation of this manual, Great Plains Manufacturing, Inc. assumes no responsibility for errors or omissions. Neither is any liability assumed for
damages resulting from the use of the information contained herein. Great Plains Manufacturing, Inc. reserves the right to revise and improve its products as
it sees fit. This publication describes the state of this product at the time of its publication, and may not reflect the product in the future.
Trademarks of Great Plains Manufacturing, Inc. include: AccuShot, Max-Chisel, Row-Pro,
Singulator Plus, Short Disk, Swath Command, Terra-Tine, Ultra-Chisel, and X-Press.
Registered Trademarks of Great Plains Manufacturing, Inc. include: Air-Pro, Clear-Shot, Discovator, Great Plains, Land Pride, MeterCone,
Nutri-Pro, Seed-Lok, Solid Stand, Terra-Guard, Turbo-Chisel, Turbo-Chopper, Turbo-Max, Turbo-Till, Ultra-Till, Whirlfilter, and Yield-Pro.
Brand and Product Names that appear and are owned by others are trademarks of their respective owners.
Printed in the United States of America

2019-04-25 Table of Contents 195-201Q
2S-2600 and 2S-2600F Table of Contents iv

2019-04-25 Table of Contents 195-201Q
2S-2600 and 2S-2600F Table of Contents 1
Important Safety Information
For your safety, thoroughly read Important Safety
Information in the operator’s manuals before proceeding.
Look for Safety Symbol
The SAFETY ALERT SYMBOL indicates there is a
potential hazard to personal safety involved and extra
safety precaution must be taken. When you see this
symbol, be alert and carefully read the message that
follows it. In addition to design and configuration of
equipment, hazard control and accident prevention are
dependent upon the awareness, concern, prudence and
proper training of personnel involved in the operation,
transport, maintenance and storage of equipment.
Be Aware of Signal Words
Signal words designate a degree or level of hazard
seriousness.
DANGER indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
This signal word is limited to the most extreme situations,
typically for machine components that, for functional
purposes, cannot be guarded.
WARNING indicates a potentially hazardous situation
which, if not avoided, could result in death or serious
injury, and includes hazards that are exposed when
guards are removed. It may also be used to alert against
unsafe practices.
CAUTION indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury. It may also be used to alert against unsafe
practices.
Transport Machinery Safely
Maximum transport speed for drill is 20 mph (32 kph).
Some rough terrains require a slower speed. Sudden
braking can cause a towed load to swerve and upset.
Do not exceed 20 mph (32 kph). Never travel at a speed
which does not allow adequate control of steering and
stopping. Reduce speed if towed load is not equipped with
brakes.
Comply with national, regional and local laws.
Follow your tractor manual recommendations for
maximum hitch loads. Insufficient weight on tractor
steering wheels will result in loss of control.
Carry reflectors or flags to mark drill in case of breakdown
on the road.
Keep clear of overhead power lines and other obstructions
when transporting. Refer to transport dimensions under
“Specifications and Capacities” on page 27.

2019-04-25 Table of Contents 195-201Q
2S-2600 and 2S-2600F Table of Contents 2
Check for Overhead Lines
Drill markers contacting overhead electrical lines can
introduce lethal voltage levels on drill and tractor frames.
A person touching almost any metal part can complete
the circuit to ground, resulting in serious injury or death.
Avoid overhead lines during seed loading/unloading and
marker operations.
Avoid High Pressure Fluids
Escaping fluid under pressure can penetrate the skin,
causing serious injury.
Avoid the hazard by relieving pressure before
disconnecting hydraulic lines.
Use a piece of paper or cardboard, NOT BODY PARTS, to
check for suspected leaks.
Wear protective gloves and safety glasses or goggles when
working with hydraulic systems.
If an accident occurs, see a doctor immediately. Any fluid
injected into the skin must be surgically removed within a
few hours or gangrene may result.
Practice Safe Maintenance
Understand procedure before doing work. Use proper tools
and equipment. Refer to this manual for additional
information.
Work in a clean, dry area.
Put tractor in park, turn off engine, and remove key before
performing maintenance.
Make sure all moving parts have stopped and all system
pressure is relieved.
Disconnect battery ground cable (-) before servicing or
adjusting electrical systems or before welding on drill.
Inspect all parts. Make sure parts are in good condition
and installed properly.
Remove buildup of grease, oil or debris.
Remove all tools and unused parts from drill before
operation.
Tire Safety
Tire changing can be dangerous and should be
performed by trained personnel using correct tools and
equipment.
When inflating tires, use a clip-on chuck and extension
hose long enough for you to stand to one side–not in front
of or over tire assembly. Use a safety cage if available.
When removing and installing wheels, use wheel-handling
equipment adequate for weight involved.
OFF

2S-2600 and 2S-2600F Table of Contents 3
2019-04-25 Table of Contents 195-201Q
Prepare for Emergencies
Be prepared if a fire starts
Keep a first aid kit and fire extinguisher handy.
Keep emergency numbers for doctor, ambulance, hospital
and fire department near phone.
Safety Decals
Safety Reflectors and Decals
Your implement comes equipped with all lights, safety
reflectors and decals in place. They were designed to
help you safely operate your implement.
Read and follow decal directions.
Keep lights in operating condition.
Keep all safety decals clean and legible.
Replace all damaged or missing decals. Order new decals
from your Great Plains dealer. Refer to this section for
proper decal placement.
When ordering new parts or components, also request
corresponding safety decals.
To install new decals:
1. Clean the area on which the decal is to be placed.
2. Peel backing from decal. Press firmly on surface,
being careful not to cause air bubbles under decal.
911

2019-04-25 Table of Contents 195-201Q
2S-2600 and 2S-2600F Table of Contents 4
Introduction
Great Plains Manufacturing wants you to be satisfied
with any new machine delivered by the Great Plains
Trucking network. To ease the assembly task and
produce a properly working machine, read this entire
manual before assembling or setting up new equipment.
Document Family
195-440M Operator’s Manual
195-200P 2S-2600 Parts Manual
195-325B Seed Rate Manual
Description of Unit
The 2S-2600 is a towed seeding implement. This
two-section drill has a working width of 26 feet and folds
to a transport width of 15 feet. The drill has straight-arm,
double-disk openers. The opener disks make a seed
bed, and seed tubes mounted between the disks place
seed in the furrow. Press wheels following the opener
disks close the furrow and gauge opener seeding depth.
A T-handle on the opener body is for seeding-depth
adjustments. Seeding rates are adjustable with the
seed-rate-adjustment handle and the sprocket box.
The 2S-2600 features active hydraulic down pressure on
the opener frames. When used on a tractor with
closed-center hydraulics, constant down pressure
ensures even opener penetration in uneven ground.
Hydraulic down pressure is adjustable at a single point.
The 2S-2600F allows you to plant seed and apply
fertilizer in the same field pass. Dividers partition the drill
boxes into seed and fertilizer compartments. The
openers apply dry fertilizer to the seed trench before the
furrow is closed. You also can use both compartments for
seed.
Intended Usage
Use this implement to seed production-agriculture crops
in conventional-tillage applications. Do not modify the
drill for use with attachments other than Great Plains
options and accessories specified for use with the
2S-2600 Drill.
Models Covered
Using This Manual
This manual was written to help you assemble and
prepare the new machine for the customer. The manual
includes instructions for assembly and setup. Read this
manual and follow the recommendations for safe,
efficient and proper assembly and setup.
An operator’s manual is also provided with the new
machine. Read and understand “Important Safety
Information”and “Operating Instructions” in the
operator’s manual before assembling the machine. As a
reference, keep the operator’s manual on hand while
assembling.
The information in this manual is current at printing.
Some parts may change to assure top performance.
Definitions
The following terms are used throughout this manual.
Right-hand and left-hand as used in this manual are
determined by facing the direction the machine will travel
while in use unless otherwise stated.
Paragraphs in this format present a crucial point of information
related to the current topic. For safe and correct operation,
read and follow the directions provided before continuing.
NOTE:
Paragraphs in this format provide useful information
related to the current topic.
Further Assistance
For additional help with understanding these assembly
instructions or for any other assembly or setup related
questions, please contact our service department at the
following address:
Great Plains Service Department
1525 E. North St.
P.O. Box 5060
Salina, KS 67402-5060
Or call us at [phone] to speak over the phone
with a service representative.
Copies of this machine’s operator manual are available
by mail or online. Please visit www.greatplainsag.com
and follow the product link for information on your
machine.
2S-2600-3210 32-row, 10 inch (25.4 cm)
2S-2600-4275 42-row, 7.5 inch (19 cm)
2S-2600-5206 52-row, 6 inch (15 cm)
2S-2600F-3210 32-row, 10 inch (25.4 cm)
2S-2600F-4275 42-row, 7.5 inch (19 cm)
2S-2600F-5206 52-row, 6 inch (15 cm)

2019-04-25 Table of Contents 195-201Q
2S-2600 and 2S-2600F Table of Contents 5
Assembly
The following headings are step-by-step instructions for
assembling the drill. Begin with “Tools Required” and
“Pre-Assembly Checklist” to make sure you have all
necessary parts and equipment. Follow each step to
make the job as quick and safe as possible and
produce a properly working machine.
Unloading Truck
Before unloading the drill from the truck, connect all
opener springs (1) to the opener frames (2).
Opener Damage Risk:
To prevent damage to openers, make sure all openers are
connected before unloading the drill.
Unload all equipment before beginning assembly.
Tools Required
•Forklift, loader or overhead hoist with a capacity of:
at least 13,000 pounds (5900 kg)
•A tractor of sufficient size and horsepower with at
least two remote hydraulic circuits. Refer to
“Specifications and Capacities” in the operator
manual.
•General hand tools
•Jack stands or blocks and safety chain
NOTE:
You will need about 4.5 gallons of hydraulic oil to
refill the tractor hydraulic reservoir after initial
bleeding and cycling of the hydraulic systems.
Pre-Assembly Checklist
1. Read and understand “Important Safety
Information” on page 1 before assembling.
2. Have at least two people on hand while assembling.
3. Make sure assembly area is level and free of
obstructions (preferably an open concrete area).
4. Have all major components accounted for.
5. Have all fasteners and pins shipped with implement.
If a pre-assembled part or fastener is temporarily removed,
remember where it goes. Keep the parts separated.
6. Have a copy of the implement Parts Manual on hand.
If unsure of proper placement or use of any part or
fastener, refer to the parts manual.
7. Check that all working parts are moving freely, bolts
are tight, and cotter pins are spread.
8. Check that all factory-applied safety labels and
reflectors are correctly located and legible. Replace
if improperly located or damaged. Refer to Safety
Decals, in the “Important Safety Information”
section of the implement Operator’s Manual.
9. Inflate tires to recommended pressure as listed on
the “Tire Inflation Chart” on page 27.
10. Tighten wheel bolts as specified on “Torque Values
Chart” on page 28.
1
2
Figure 1
Opener Spring to Opener Frame
71302

2019-04-25 Table of Contents 195-201Q
2S-2600 and 2S-2600F Table of Contents 6
Install Press Wheels
Refer to Figure 2.
1. Remove 1/2 x 3 3/4-inch flange bolt (1) and flange
lock nut (4) from each opener body.
2. Leave pivot bushing (2) in place and bolt
press-wheel arm (3) to opener with 1/2 x 3 3/4-inch
flange bolt (1) and lock nut (4). Repeat for all
openers.
3. Remove 5/8-inch bolt (5) from each press-wheel
arm (3) and use bolts to assemble press wheels (6)
to press-wheel arms.
Install Walkboards
Refer to Figure 3
1. Remove 1/2-13 x 1 1/4-inch bolts (1) from end panels.
2. Bolt each walkboard (2) to box support channels (3)
with 1/2-13 x 1 1/4 inch bolts, lock washer, and hex
nuts.
1
2
3
65
4
Figure 2
Press Wheel Arm and Press Wheel
Assembly
24432
Figure 3
Walkboard Installation
18810
2
1
3

2S-2600 and 2S-2600F Table of Contents 7
2019-04-25 Table of Contents 195-201Q
Install Ladder Mounts
Refer to Figure 4 and Figure 5.
Location of the ladder mounts depends on whether the
drill has the small seeds option.
•For drills without the small seeds option, refer to
Figure 4 as a reference.
•For drills with the small seeds option, refer to Figure 5
as a reference.
Top ladder mount weldments are provided in left-side and
right-side versions and are not interchangeable. All other
parts may be used on either end.
Start with the left drill box:
3. Select one:
(13) 195-063H LADDER MOUNT TOP WELDMENT LH,
and four:
(22) 802-030C RHSNB 7/16-14X1 3/4 GR5.
Position top left-hand ladder mount (13) over the
appropriate four walkboard holes (4).
Insert the four bolts (22) to loosely hold the top ladder
mount in place on the walkboard
4. Select one:
(15) 195-340D LADDER MOUNT BOTTOM PLATE
and four sets of:
(35) 804-014C WASHER LOCK 7/16 PLT
(27) 803-015C NUT HEX 7/16-14 PLT
Position the bottom ladder mount plate (15) under the
walkboard and inside the top ladder mount. Loosely
hold it in place with the washers (35) and nuts (27).
5. Select two sets of:
(21) 802-017C HHCS 3/8-16X1 GR5
(34) 804-013C WASHER LOCK SPRING 3/8 PLT
(28) 803-068C NUT HEX FLANGE 3/8-16 PLT
Insert the bolts (21) through the side holes in both the
top mount and bottom plate, and secure with lock
washers (34) and flange nuts (28).
Tighten the four nuts (27), securing the top mount to
the bottom plate.
6. Select one:
(14) 195-064H LADDER MOUNT TOP WELDMENT RH
in place of left-hand mount. Repeat step 3 through
step 5 for right wing section.
Figure 4
Installation without Small Seeds
Option
27036
13 22
21
34
28
15
35
27
4
Figure 5
Installation with Small Seeds
Option
27055
13 22
21
34
28
15
35
27
4

2019-04-25 Table of Contents 195-201Q
2S-2600 and 2S-2600F Table of Contents 8
Install Ladders
The ladders mount between the lugs (5) of the upper
mounts. Flat washers are placed between ladder side
frame and the lugs. Hex head bolts install from the
inside, to minimize obstructions to foot movement during
climbing.
Refer to Figure 6
(which shows only the right side assembly, on a drill
without Small Seeds)
Start with the right walkboard ladder:
7. Select one:
(12) 195-062H LADDER WELDMENT 3-STEP
NARROW
Lay the ladder (12) on the walkboard with the swing
holes up and near the top mount lug holes. Align the
holes in the ladder in between the holes in the lugs.
8. Select two sets of:
(23) 802-079C HHCS 3/8-16X1 1/4 GR5
(36) 804-016C WASHER FLAT 1/2 SAE PLT
(31) 803-209C NUT FLANGE LOCK 3/8-16 PLT
Insert a bolt (23) through (in the following order):
a. the ladder (12) side plate,
b. a washer (36), and
c. the mounting lug (5).
Secure with lock nut (31).
9. Repeat step 7 and step 8 for left walkboard ladder.
10. Swing both ladders down to check operation and
position for decal placement.
Apply Reflectors and Decals
To prevent scuffing in shipment, walkboard reflectors and
decals are shipped separate, and are applied after
walkboard installation.
To install new reflectors and decals:
•Clean and dry the area where the reflector or decal is
to be placed.
•Peel backing from reflector or decal. Press firmly on
surface, being careful not to cause air bubbles under
reflector or decal.
31
36
23
5
12
Figure 6
Ladder Installation
27037

2S-2600 and 2S-2600F Table of Contents 9
2019-04-25 Table of Contents 195-201Q
Walkboard Inside End Reflectors
Refer to Figure 7
Starting with the right walkboard, inside end:
1. Select two:
(42) 838-266C DECAL REFLECTOR RED 2X9
Place the red reflector (42) on the end face of the
walkboard mounting bracket. Align the outside end of
the reflector with the top corner. This reflector marks
the left and right extents of the drill in transport
(folded).
Place another red reflector toward the front of the
seed box (1) as shown.
2. Select one:
(43) 838-267C DECAL REFLECTOR DAYTIME 2X9
Place the daytime reflector (43) on the end face of the
walkboard mounting bracket just below the red
reflector.
Place another daytime reflector below the red
reflector at the front end of the seed box.
3. Select one:
(16) 195-561D WALKBOARD REFLECTOR MNT
SINGLE
(41) 838-265C DECAL REFLECTOR AMBER 2X9
and two sets of:
(25) 802-633C RHSNB 1/4-20X5/8 PLT
(26) 803-006C NUT HEX 1/4-20 PLT
Install the reflector mount (16) using two bolts (25)
and hex nuts (26) on the rear face of the walkboard.
Place an amber reflector (41) on the reflector mount.
4. Repeat the procedure for the left walkboard.
Slow Moving Vehicle (SMV) Reflector
Refer to Figure 8.
5. Select one:
(17) 195-562D 2600 SMV MOUNTING BRKT
(37) 806-132C U-BOLT 3/8-16 X 3 1/32 X 2 3/4
(29) 803-078C NUT LOCK 3/8-16 NYLON INSERT
(38) 818-055C DECAL SLOW MOVING-GALV.
BACKED
and two sets of:
(19) 801-018C SCREW RD HD 1/4-20 X 5/8
(33) 804-007C WASHER FLAT 1/4 SAE PLT
(32) 804-006C WASHER LOCK SPRING 1/4 PLT
(26) 803-006C NUT HEX 1/4-20 PLT
At the rear center of the mainframe, install the SMV
mounting bracket (17) to the upper bar (2). Secure
with the U-bolt (37) and lock nuts (29).
Attach the slow moving vehicle reflector (38) to the
bracket with two screws (19), flat washers (33), lock
washers (32), and hex nuts (26).
1
42 16
43
25 41
Figure 7
Walkboard Inside End
Reflectors
68426D
2
38
17
19
37
29
Figure 8
Slow Moving Vehicle Reflector
68426F

2019-04-25 Table of Contents 195-201Q
2S-2600 and 2S-2600F Table of Contents 10
Ladder Reflectors and Decals
Refer to Figure 9
Starting on the right walkboard:
6. Select one:
(16) 195-561D WALKBOARD REFLECTOR MNT
SINGLE
and two of:
(41) 838-265C DECAL REFLECTOR AMBER 2X9
(25) 802-633C RHSNB 1/4-20X5/8 PLT
(26) 803-006C NUT HEX 1/4-20 PLT
(40) 838-102C DECAL WARNING FALLING
HAZARD (if separate)
Place an amber reflector (41) on the outside face of
the ladder mount, between the ladder side plates (2)
(so it will not be damaged by ladder operation).
Install a reflector mount (16) with two bolts (25) and
hex nuts (26) on the rear face of the walkboard beside
the ladder mount.
Place an amber reflector (41) on the reflector mount.
If the Warning decals (40) are separately provided,
place in front of and near the top of the ladder, where
they are visible to climbers.
7. Repeat the procedure for the left walkboard.
Handles and Lights
Install Box Handles
Refer to Figure 10
On outside ends of drill boxes, by the ladders, bolt
handles to boxes. Secure with 1/2-13 x 1 1/2 inch bolts
and lock nuts.
16
41 25
40
41
Figure 9
Ladder Reflectors and Decals
68426E
2
Figure 10
Box Handle
17347

2S-2600 and 2S-2600F Table of Contents 11
2019-04-25 Table of Contents 195-201Q
Install Lights
Refer to Figure 11
The red lights will already be install on the drill at the
front of each inside end of the drill boxes.
Starting on the right drill box:
1. Select one:
(18) 195-563D 2600 SIDE LIGHT BRKT
(39) 833-697C LIGHT, AMBER LAMP LED
and two sets of:
(24) 802-203C HFSS 1/2-13X1 1/2 GR5
(30) 803-169C NUT HEX FLG LOCK 1/2-13 PLT
(20) 801-081C SCREW HEX SELF TAP 1/4-20X3/4
At the rear of the inside end of the drill box, install an
amber light bracket (18) with two bolts (24) and lock
nuts (30).
Install an amber light (39) to the bracket using two
screws (20).
2. Plug the amber light lead into the drill harness.
3. Repeat the procedure for the left drill box.
Other Assembly Items
There are a few additional standard components, and
several possible optional items, that are not factory
installed. Some of these, which follow in this chapter,
need to be installed prior to first hydraulic hookup. Others
are installed after hookup, bleeding and leveling. See
“Install Final Accessories” on page 24.
Two Outlet Kit
If the two-outlet hydraulic kit was ordered, install it now
(before the markers, as this kit contains items needed
when both 2-outlet and markers are installed).
Installation instructions are provided in a separate
manual with the two-outlet hydraulic kit.
30
24
20
18 39
Figure 11
Amber Light Installation
17346
Figure 12
Two-Outlet Selector
27020

2019-04-25 Table of Contents 195-201Q
2S-2600 and 2S-2600F Table of Contents 12
Point Row Option
If the point row option was ordered with the drill, the
hydraulics and drill electrical lead are factory-installed.
If the customer’s primary tractor is available, install the
control module in the tractor cable and make the electrical
connection. Consult the point row installation manual
provided.
If the primary tractor is not available, temporarily connect
the control module so that openers can be operated
during Setup.
Post Assembly Checklist
Check that all working parts are moving freely, bolts
are tight, and cotter pins are spread.
Check for proper tension and alignment on all drive
chains.
Check that all safety decals and reflectors are located
correctly and are legible. Replace if improperly
located or damaged. Refer to “Safety Decals” in the
Operator’s manual.
Inflate tires to recommended pressures as listed on
the “Tire Inflation Chart” on page 27. Tighten wheel
bolts as specified on “Torque Values Chart” on page
28.
Figure 13
Point-Row Connector
26469

2019-04-25 Table of Contents 195-201Q
2S-2600 and 2S-2600F Table of Contents 13
Setup
The Assembly steps of the preceding chapter must be
completed prior to setup.
Setup steps consist of:
1. Hitch to suitable tractor.
2. Connect hydraulics.
3. Bleed hydraulics.
4. Level drill.
5. Install any accessories and options not
factory-installed, which can or must be deferred until
after first unfolding.
Hitching
You may be severely injured or killed by being crushed between
the tractor and drill. Do not stand or place any part of your
body between machines being hitched. Stop tractor engine and
set park brake before installing hitch pins.
This drill can have positive and negative tongue weight, which
can work the hitch pin loose during transport. To avoid serious
injury or death due to a road accident, always use a clevis hitch
or clevis drawbar with a locking-style hitch pin.
Choose a drill-hitch option that is compatible with your
tractor drawbar.
Refer to Figure 14
The 2S-2600 has three hitch options:
•a clevis hitch,
•a small-hole, single-strap hitch or;
•a large-hole, single-strap hitch.
Use the clevis hitch with tractors that have single-tang
drawbars. Use the single-strap hitch for tractors with
clevis drawbars. Always use a locking-style hitch pin sized
to match the holes in the hitch and drawbar.
Figure 14
Hitch Options
27006

2019-04-25 Table of Contents 195-201Q
2S-2600 and 2S-2600F Table of Contents 14
Refer to Figure 15 and Figure 16
To adjust the drill hitch to match your tractor-drawbar
height, mount tongue jack on side of tongue. Use jack to
raise drill tongue so lowest hitch hole is 18 inches
(45.7cm) above ground level with drill lowered to FIELD
position.
Refer to Figure 16
Bolt drill hitch onto drill tongue to match your
tractor-drawbar height. You can turn the hitch over for a
total of six different hitch heights. Always have two (2)
bolts in two holes of both tongue and hitch.
NOTE:
When hitching drill to a different tractor, check for a
difference in drawbar heights. If heights are different,
readjust hitch height accordingly.
Securely attach safety chain to an anchor on a tractor
capable of pulling the drill.
Refer to Figure 17
Use crank to raise jack foot. Remove pin and jack. Store
jack on top of tongue.
Figure 15
Jack in Lifting Location
15564
Figure 16
Heights for Various Hitch Positions - Correct Tongue Height
15623
32.0in
81.3cm 29.0in
73.7cm 26.0in
66.0cm 21.5in
54.6cm 18.5in
47.0cm 15.5in
39.4cm
18.0in
45.7cm
Figure 17
Jack in Storage Location
15563

2S-2600 and 2S-2600F Table of Contents 15
2019-04-25 Table of Contents 195-201Q
Electrical Connections
Refer to Figure 18
Plug drill electrical lead into tractor seven-pin connector.
Refer to Figure 19
If the drill is equipped with the point row option, mate the
connector for the cab control.
Figure 18
Lighting Connector
26467
Figure 19
Point-Row Connector
26469

2019-04-25 Table of Contents 195-201Q
2S-2600 and 2S-2600F Table of Contents 16
Hydraulic Hose Hookup
Only trained personnel should work on system hydraulics!
Escaping fluid under pressure can have sufficient pressure to
penetrate the skin, causing serious injury. Avoid the hazard by
relieving pressure before disconnecting hydraulic lines. Use a
piece of paper or cardboard, NOT BODY PARTS, to check for
leaks. Wear protective gloves and safety glasses or goggles
when working with hydraulic systems. If an accident occurs,
see a doctor immediately. Any fluid injected into the skin must
be surgically removed within a few hours or gangrene will
result.
Refer to Figure 20
Great Plains hydraulic hoses are color coded handle
grips to help you hookup hoses to your tractor outlets.
Hoses that go to the same remote valve are marked with
the same color.
Current Style Color Coded Hose Handles
To distinguish hoses on the same hydraulic circuit, refer
to the symbol molded into the handle grip. Hoses with
an extended-cylinder symbol feed cylinder base ends.
Hoses with a retracted-cylinder symbol feed cylinder rod
ends.
1. Connect opener-lift hoses to circuit designated for
hydraulic-motor control.
2. Connect transport-lift hoses to tractor remote valve.
3. Connect fold hoses to tractor remote valve.
4. Connect marker hoses to tractor remote valve.
NOTE:
If your tractor has only two remote valves, you must
install a double-selector valve to combine the
transport-lift and opener-lift circuits. See “Two Outlet
Kit” on page 11.
Hydraulic Operations
Consult the Operator’s Manual for unfolding and lowering
instructions. Pay strict attention to the step ordering.
Both Opener and Transport Lift circuits must be raised and
locked up before folding, or implement damage will result.
Color Hydraulic Function
Red Opener Lift Cylinders
Blue Transport Lift Cylinders
Gray Fold Cylinders
Green Marker Cylinders
To run drill on tractors with open-center hydraulics or on
tractors with fixed-displacement hydraulic pumps, you must
install a Great Plains kit, part number 194-143A. If you are
not familiar with your tractor hydraulics, consult your tractor
dealer.
Figure 20
Plastic Hose Label
31733
