GREAT PLAINS 3S-5000 Series User manual

Manufacturing, Inc.
www.greatplainsmfg.com
© Copyright 2017 Printed 2017-10-26 195-325M
EN
Table of Contents Index
Table of Contents Index
ORIGINAL INSTRUCTIONS
Operator Manual
3S-5000/F/HD/HDF
3-Section 50 Foot Folding Drill
Read the operator manual entirely. When you see this symbol, the
subsequent instructions and warnings are serious - follow without
exception. Your life and the lives of others depend on it!
Illustrations may show optional equipment not supplied with standard unit or
may depict similar 2S, 3S-3000, 3S-4000 and HD drills where a topic is
identical.
36268

2017-10-26 Table of Contents Index 195-325M
3S-5000/F/HD/HDF Table of Contents Index ii
Machine Identification
Record your machine details in the log below. If you replace this manual, be sure to transfer this information
to the new manual.
If you, or the dealer, have added Options not originally ordered with the machine, or removed Options that
were originally ordered, the weights and measurements are no longer accurate for your machine. Update
the record by adding the machine weight and measurements on page 96 with the Option(s) weight and
measurements.
Dealer Contact Information
Model Number
Serial Number
Machine Height
Machine Length
Machine Width
Machine Weight
Year of Construction
Delivery Date
First Operation
Accessories
Name:
Street:
City/State:
Telephone:
Email:
Dealer’s Customer
No.:
Dealer QRC
The QR Code (Quick Response) to the
left will take you to available dealers for
Great Plains products. Refer to the
Parts Manual QR Locater for detailed
instructions.
Manual Family QRC
The QR Code (Quick Response) to the
left will take you to this machine’s family
of manuals. Use your smart phone or
tablet to scan the QR Code with an
appropriateApp to begin viewing.

3S-5000/F/HD/HDF Cover Index Table of Contents iii
2017-10-26 Cover Index 195-325M
© Copyright 2001, 2002, 2003, 2006, 2007, 2009, 2010, 2012, 2013, 2014, 2015, 2016, 2017 All rights Reserved
Great Plains Manufacturing, Inc. provides this publication “as is” without warranty of any kind, either expressed or implied. While every precaution has been
taken in the preparation of this manual, Great Plains Manufacturing, Inc. assumes no responsibility for errors or omissions. Neither is any liability assumed
for damages resulting from the use of the information contained herein. Great Plains Manufacturing, Inc. reserves the right to revise and improve its products
as it sees fit. This publication describes the state of this product at the time of its publication, and may not reflect the product in the future.
Trademarks of Great Plains Manufacturing, Inc. include:AccuShot, Max-Chisel, Row-Pro,
Singulator Plus, Short Disk, Swath Command, Terra-Tine, Ultra-Chisel, and X-Press.
Registered Trademarks of Great Plains Manufacturing, Inc. include:Air-Pro, Clear-Shot, Discovator, Great Plains, Land Pride, MeterCone,
Nutri-Pro, Seed-Lok, Solid Stand, Terra-Guard, Turbo-Chisel, Turbo-Chopper, Turbo-Max, Turbo-Till, Ultra-Till, Whirlfilter, and Yield-Pro.
Brand and Product Names that appear and are owned by others are trademarks of their respective owners.
Printed in the United States of America
Table of Contents
Important Safety Information.................................................1
Safety Decals ....................................................................6
Introduction...........................................................................14
Description of Unit...........................................................14
Intended Usage........................................................14
Models Covered ..............................................................14
Document Family .....................................................14
Using This Manual...........................................................15
Definitions.................................................................15
Owner Assistance............................................................16
Further Assistance...........................................................16
Preparation and Setup .........................................................17
Post-Delivery/Seasonal Setup.........................................17
Pre-Planting Setup ..........................................................17
Leveling the Drill..............................................................18
Center Box Frame Leveling......................................18
Opener Frames........................................................18
Wing Box Alignment.................................................19
Tool Bar Height ........................................................19
Align Transfer Drive Shaft........................................20
Hitching Tractor to Drill....................................................22
Adjusting the Drill Hitch ...........................................22
Hydraulic Hose Hookup...................................................25
Operating Instructions .........................................................26
Pre-Start Checklist...........................................................26
Folding.............................................................................27
Unfolding .........................................................................29
Folding and Unfolding Quick Reference..........................31
Setting the Bypass Valve.................................................31
Opener Operation............................................................33
Active Hydraulic Systems.........................................34
Priority Flow Hydraulic Systems...............................35
Non-Active Hydraulic System...................................35
Opener Depth...........................................................36
Raising and Lowering Openers .......................................36
Opener Lock Up .............................................................37
Loading Materials............................................................38
Fertilizer Box Operation...................................................40
Using Fertilizer Compartment...................................40
Seeding with Both Compartments............................40
Liquid Fertilizer System (Option).....................................42
Liquid Fertilizer System Elements............................43
Loading Liquid Fertilizer...........................................44
Transporting the Drill.......................................................46
Transport Checklist ..................................................46
Point Row Operation (Option)..................................47
Shaft Monitor Operation (Option).............................47
Acremeter Operation.......................................................48
Parking............................................................................49
Parking with Drill Unfolded.......................................49
Parking with Drill Folded ..........................................49
Storage............................................................................50
Adjustments..........................................................................51
Main Box Seed Rate Handle...........................................52
Position Seed Cup Doors................................................52
Frame Adjustments.........................................................53
Tool Bar Height Adjustment.....................................53
Opener Frame Adjustment..............................................54
Opener Frame Clearance ........................................55
Frame Level ....................................................................56
Hydraulic Down Pressure All Openers............................57
00 Row Unit Adjustments................................................59
00HD Row Unit Adjustments...........................................60
Opener Height.................................................................61
Row Unit Down Pressure (Spring) ..................................61
Disc Blade Adjustments ..................................................62
Adjusting Disc Contact.............................................62
Dry Fertilizer Tube Adjustment........................................63
Liquid Fertilizer Adjustments (Option) .............................64
00 Series Disk Scraper Adjustment.................................67
Seed Firmer Adjustments................................................67
Keeton®Seed Firmer Adjustment............................67
00 Series Seed-Lok®Lock Up.................................68
00 & 00HD Series Opener Depth....................................68
Press Wheel Adjustment..........................................68
Troubleshooting ...................................................................69
Maintenance and Lubrication..............................................72
Maintenance....................................................................72
Bleeding Hydraulics.........................................................73
Bleeding Opener Lift Hydraulics...............................74
Bleeding Fold Hydraulics .........................................75
Bleeding Transport Lift Hydraulics...........................76
Opener Hydraulic Filters ..........................................77
Drive System Maintenance .............................................78
Seed Flap Replacement..................................................79
Marker Maintenance........................................................79
Materials Clean-Out ........................................................80
Main Box Clean-Out.................................................80
Fertilizer Box Clean-Out...........................................80
Small Seeds Box Clean-Out ....................................80

3S-5000/F/HD/HDF Cover Index Table of Contents iv
2017-10-26 Cover Index 195-325M
Liquid Fertilizer Clean-Out........................................81
Chain Maintenance..........................................................82
Chain Slack..............................................................82
Lubrication.......................................................................83
Options..................................................................................90
Appendix A - Reference Information ..................................96
Specifications and Capacities..........................................96
Tire Inflation Chart...........................................................96
Dimensions (Transport) 3S-5000/F/HD/HDF ..................97
Hydraulic Diagrams.........................................................98
Torque Values Chart.....................................................109
Appendix B - Option Installation.......................................110
Carbide Disc Scraper Installation..................................110
Mount Fertilizer Boom (Option).....................................111
Liquid Fertilizer Drop Lines (Option)..............................112
Install Caps on Taps ..............................................112
Install Drop Lines to Rows .....................................112

2017-10-26 Table of Contents Index 195-325M
3S-5000/F/HD/HDF Table of Contents Index Important Safety Information 1
Important Safety Information
Look for Safety Symbol
The SAFETY ALERT SYMBOL indicates there is a
potential hazard to personal safety involved and extra
safety precaution must be taken. When you see this
symbol, be alert and carefully read the message that
follows it. In addition to design and configuration of
equipment, hazard control and accident prevention are
dependent upon the awareness, concern, prudence and
proper training of personnel involved in the operation,
transport, maintenance and storage of equipment.
Be Aware of Signal Words
Signal words designate a degree or level of hazard
seriousness.
DANGER indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
This signal word is limited to the most extreme situations,
typically for machine components that, for functional
purposes, cannot be guarded.
WARNING indicates a potentially hazardous situation
which, if not avoided, could result in death or serious
injury, and includes hazards that are exposed when
guards are removed. It may also be used to alert against
unsafe practices.
CAUTION indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury. It may also be used to alert against unsafe
practices.
Prepare for Emergencies
Be prepared if a fire starts
Keep a first aid kit and fire extinguisher handy.
Keep emergency numbers for doctor, ambulance, hospital
and fire department near phone.
Be Familiar with Safety Decals
Read and understand “Safety Decals” on page 6,
thoroughly.
Read all instructions noted on the decals.
Keep decals clean. Replace damaged, faded and illegible
decals.

2017-10-26 Table of Contents Index 195-325M
3S-5000/F/HD/HDF Table of Contents Index Important Safety Information 2
Wear Protective Equipment
Great Plains advises all users of chemical pesticides or
herbicides to use the following personal safety
equipment.
Waterproof, wide-brimmed hat
Waterproof apron.
Face shield, goggles or full face respirator.
Goggles with side shields or a full face respirator is
required if handling or applying dusts, wettable powders,
or granules or if being exposed to spray mist.
Cartridge-type respirator approved for pesticide vapors
unless label specifies another type of respirator.
Waterproof, unlined gloves. Neoprene gloves are
recommended.
Cloth coveralls/outer clothing changed daily; waterproof
items if there is a chance of becoming wet with spray
Waterproof boots or foot coverings
Do not wear contaminated clothing. Wash protective
clothing and equipment with soap and water after each
use. Personal clothing must be laundered separately from
household articles.
Clothing contaminated with certain pesticides must be
destroyed according to state and local regulations. Read
chemical label for specific instructions.
Wear clothing and equipment appropriate for the job.
Avoid loose-fitting clothing.
Prolonged exposure to loud noise can cause hearing
impairment or loss. Wear suitable hearing protection such
as earmuffs or earplugs.
Avoid wearing entertainment headphones while operating
machinery. Operating equipment safely requires the full
attention of the operator.
Handle Chemicals Properly
Agricultural chemicals can be dangerous. Improper use
can seriously injure persons, animals, plants, soil and
property.
Read and follow chemical manufacturer’s instructions.
Wear protective clothing.
Handle all chemicals with care.
Avoid inhaling smoke from any type of chemical fire.
Store or dispose of unused chemicals as specified by
chemical manufacturer.

3S-5000/F/HD/HDF Table of Contents Index Important Safety Information 3
2017-10-26 Table of Contents Index 195-325M
Avoid High Pressure Fluids
Escaping fluid under pressure can penetrate the skin,
causing serious injury.
Avoid the hazard by relieving pressure before
disconnecting hydraulic lines.
Use a piece of paper or cardboard, NOT BODY PARTS, to
check for suspected leaks.
Wear protective gloves and safety glasses or goggles when
working with hydraulic systems.
If an accident occurs, seek immediate medical assistance
from a physician familiar with this type of injury.
Use A Safety Chain
Use a safety chain to help control drawn machinery
should it separate from tractor draw-bar.
Use a chain with a strength rating equal to or greater than
the gross weight of towed machinery.
Attach chain to tractor draw-bar support or other
specified anchor location. Allow only enough slack in
chain to permit turning.
Replace chain if any links or end fittings are broken,
stretched or damaged.
Do not use safety chain for towing.
Use Safety Lights and Devices
Slow-moving tractors and towed implements can create
a hazard when driven on public roads. They are difficult
to see, especially at night.
Use flashing warning lights and turn signals whenever
driving on public roads.
Use lights and devices provided with implement
Keep Riders Off Machinery
Riders obstruct the operator’s view. Riders could be
struck by foreign objects or thrown from the machine.
Never allow children to operate equipment.
Keep all bystanders away from machine during operation.

2017-10-26 Table of Contents Index 195-325M
3S-5000/F/HD/HDF Table of Contents Index Important Safety Information 4
Transport Machinery Safely
Maximum transport speed for implement is 20 mph (32
kph). Some rough terrains require a slower speed.
Sudden braking can cause a towed load to swerve and
upset.
Do not exceed 20 mph. Never travel at a speed which does
not allow adequate control of steering and stopping.
Reduce speed if towed load is not equipped with brakes.
Comply with state and local laws.
Do not tow an implement that, when fully loaded, weighs
more than 1.5 times the weight of towing vehicle.
Carry reflectors or flags to mark drill in case of
breakdown on the road.
Do not fold or unfold the drill while the tractor is moving.
Shutdown and Storage
Lower drill, put tractor in park, turn off engine, and
remove the key.
Secure drill using blocks and supports provided.
Detach and store drill in an area where children normally
do not play.
Tire Safety
Tire changing can be dangerous and should be
performed by trained personnel using correct tools and
equipment.
When inflating tires, use a clip-on chuck and extension
hose long enough for you to stand to one side–not in front
of or over tire assembly. Use a safety cage if available.
When removing and installing wheels, use wheel-handling
equipment adequate for weight involved.

3S-5000/F/HD/HDF Table of Contents Index Important Safety Information 5
2017-10-26 Table of Contents Index 195-325M
Practice Safe Maintenance
Understand procedure before doing work. Use proper
tools and equipment. Refer to this manual for additional
information.
Work in a clean, dry area.
Lower the drill, put tractor in park, turn off engine, and
remove key before performing maintenance.
Make sure all moving parts have stopped and all system
pressure is relieved.
Allow drill to cool completely.
Disconnect battery ground cable (-) before servicing or
adjusting electrical systems or before welding on drill.
Inspect all parts. Make sure parts are in good condition
and installed properly.
Remove buildup of grease, oil or debris.
Remove all tools and unused parts from drill before
operation.
Safety At All Times
Thoroughly read and understand the instructions in this
manual before operation. Read all instructions noted on
the safety decals.
Be familiar with all drill functions.
Operate machinery from the driver’s seat only.
Do not leave drill unattended with tractor engine running.
Do not dismount a moving tractor. Dismounting a moving
tractor could cause serious injury or death.
Do not stand between the tractor and drill during
hitching.
Keep hands, feet and clothing away from power-driven
parts.
Wear snug-fitting clothing to avoid entanglement with
moving parts.
Watch out for wires, trees, etc., when folding and raising
drill. Make sure all persons are clear of working area.

2017-10-26 Table of Contents Index 195-325M
3S-5000/F/HD/HDF Table of Contents Index Important Safety Information 6
Safety Decals
Safety Reflectors and Decals
Your implement comes equipped with all lights, safety
reflectors and decals in place. They were designed to
help you safely operate your implement.
Read and follow decal directions.
Keep lights in operating condition.
Keep all safety decals clean and legible.
Replace all damaged or missing decals. Order new decals
from your Great Plains dealer. Refer to this section for
proper decal placement.
When ordering new parts or components, also request
corresponding safety decals.
Slow Moving Vehicle Reflector
818-055C
On center section;
1 total
Red Reflectors (S/N C1304L-)
838-266C
On rear of center section, one each outside corner;
2 total
Red Reflectors (S/N C1305L+)
838-266C
On rear of center section, one on decal bracket at each
end;
2 total
To install new decals:
1. Clean the area on which the decal is to be placed.
2. Peel backing from decal. Press firmly on surface,
being careful not to cause air bubbles under decal.
34283
34284
68380A

3S-5000/F/HD/HDF Table of Contents Index Important Safety Information 7
2017-10-26 Table of Contents Index 195-325M
Daytime Reflectors (S/N C1304L-)
838-267C
On rear of center section;
2 total
Daytime Reflectors (S/N C1305L+)
838-267C
On rear of center section, one on decal bracket at each
end;
2 total
Amber Reflectors (S/N C1304L-)
838-265C
Three reflectors on each wing section, one reflector
on each end of center section;
8 total
Amber Reflectors (S/N C1305L+)
838-265C
One reflector on each end of center section;
2 total
34284
68380A
34300
68380A

2017-10-26 Table of Contents Index 195-325M
3S-5000/F/HD/HDF Table of Contents Index Important Safety Information 8
Amber Reflectors (S/N C1305L+)
838-265C
One on decal bracket at each end of wings, one on
outside end of wings;
6 total
Transport Lock Road
818-257C
Place above lever: two each RH and LH end section,
two on center section;
6 total
Transport Lock Field
818-258C
Place below lever: two each RH and LH end section,
two on center section;
6 total
68380B
34285
ROAD
P.N. 818-257C
34285
FIELD
P.N. 818-258C

3S-5000/F/HD/HDF Table of Contents Index Important Safety Information 9
2017-10-26 Table of Contents Index 195-325M
Danger (in Spanish):
818-557C
Advising non-English readers to seek translation
On tongue, at hitch;
1 total
Warning: Negative Tongue Weight Hazard
818-019C
On the tongue;
1 total
Warning: Pinch/Crush
818-045C
On top of tongue;
1 total
34287
34288
WARNING
NEGATIVETONGUEWEIGHT
HAZARD
Negative tongue weight can cause immediate
elevation of tongue when unhitching implement
To prevent serious injury or death:
Always be certain implement is hitched securely
to tractor drawbar before raising.
Lower implement BEFORE unhitching.
818-019C Rev. D
34289

2017-10-26 Table of Contents Index 195-325M
3S-5000/F/HD/HDF Table of Contents Index Important Safety Information 10
Warning: Speed
818-188C
On left side of tongue,
1 total
Warning: High Pressure Fluid Hazard
818-339C
On left side of tongue;
1 total
Warning: Transport Lock
818-660C
On top of tongue;
1 total
34288
818-188C Rev. C
Do Not exceed 20 mph maximum transport
speed. Loss of vehicle control and/or machine
can result.
To Prevent Serious Injury or Death:
EXCESSIVE SPEED HAZARD
WARNING
34288
34289
WARNING

3S-5000/F/HD/HDF Table of Contents Index Important Safety Information 11
2017-10-26 Table of Contents Index 195-325M
Warning: Transport Lock
818-660C
One on each side of drill frame;
2 total
Warning: Falling Hazard
838-102C
One decal on each end of the drill;
2 total
34290
WARNING
34291
WARNING
To avoid serious injury or death:
Watch your step when climbing ladder or
walking on walkboard.
838-102C

2017-10-26 Table of Contents Index 195-325M
3S-5000/F/HD/HDF Table of Contents Index Important Safety Information 12
Caution: General Instructions
818-078C
On tongue;
1 total
Caution: Tires Not A Step
818-398C
One on each transport axle leg;
2 total
Caution: Tires Not A Step
818-398C
One on outside face each gauge wheel weldment;
2 total
34288
CAUTION
34290
34295

3S-5000/F/HD/HDF Table of Contents Index Important Safety Information 13
2017-10-26 Table of Contents Index 195-325M
Caution: Tire Pressure and Torque
838-258C
Wing sections: one on each gauge wheel rim;
4 or 0 total
Caution: Tire Inflation and Torque
848-801C
Center section: one on each transport wheel rim;
4 or 0 total
Caution: Tire Inflation and Torque
858-781C
Liquid fertilizer drive: on side of wheel fork;
1 total
34298
34292
To Avoid Injury or Machine Damage from ImproperTire
Inflation orTorquing ofWheel Bolts:
Maximum inflation pressure of tires is 80 psi.
Torque wheel bolts to 300 lb-ft.
848-801C
CAUTION
36288
858-781C
Maximum inflation pressure of tires is 40 psi.
Torque wheel bolts to 120 ft-lbs.
To Avoid Injury or Machine Damage from ImproperTire
Inflation orTorquing ofWheel Bolts:
CAUTION

2017-10-26 Table of Contents Index 195-325M
3S-5000/F/HD/HDF Table of Contents Index Introduction 14
Introduction
Great Plains welcomes you to its growing family of new
product owners. The 3-Section 50 Foot Folding Drill
(3S-5000/F/HD/HDF) has been designed with care and
built by skilled workers using quality materials. Proper
setup, maintenance, and safe operating practices will
help you get years of satisfactory use from the machine.
Description of Unit
The 3S-5000/F/HD/HDF Drill is a towed seeding
implement for use in conventional or minimum tillage
conditions. This three section drill has a working width of
50 feet (12.2 m). The drill has straight arm, double disk
openers. The opener disks make a seed bed, and seed
tubes mounted between the disks place seed in the
furrow. Press wheels following the opener disks close the
furrow and gauge opener seeding depth. A T-handle on
the opener body is for seeding depth adjustments.
Seeding rates are adjustable with the seed rate
adjustment handle and sprocket changes.
The 3S-5000/F/HD/HDF features active hydraulic down
pressure on the opener frames. When used on a tractor
with closed-center hydraulics, constant down pressure
ensures even opener penetration in uneven ground.
Hydraulic down pressure is adjustable at a single point.
Intended Usage
Use the 3S-5000/F/HD/HDF Drill to seed
production-agriculture crops only. Do not modify the drill
for use with attachments other than Great Plains options
and accessories specified for use with the 3S-5000 Drill
Models Covered
Document Family
Figure 1
3S-5000/F/HD/HDF Drill 34310
U
D
F
B
L
R
L
R
3S-5000-6010 60 Row, 10 inch (25.4 cm) Spacing
3S-5000-8075 80 Row, 7.5 inch (19.1 cm) Spacing
3S-5000-1006 100 Row, 6 inch (15.2 cm) Spacing
3S-5000F-6010 60 Row, 10 inch (25.4 cm) Spacing
3S-5000F-8075 80 Row, 7.5 inch (19.1 cm) Spacing
3S-5000F-1006 100 Row, 6 inch (15.2 cm) Spacing
3S-5000HD-6010 60 Row, 10 inch (25.4 cm) Spacing
3S-5000HD-8075 80 Row, 7.5 inch (19.1 cm) Spacing
3S-5000HD-1006 100 Row, 6 inch (15.2 cm) Spacing
3S-5000HDF-6010 60 Row, 10 inch (25.4 cm) Spacing
3S-5000HDF-8075 80 Row, 7.5 inch (19.1 cm) Spacing
3S-5000HDF-1006 100 Row, 6 inch (15.2 cm) Spacing
195-325M Owner’s Manual (this document)
195-325B Seed Rate Charts
133-322M Small Seeds Manual
195-325P Parts Manual

3S-5000/F/HD/HDF Table of Contents Index Introduction 15
2017-10-26 Table of Contents Index 195-325M
Using This Manual
This manual will familiarize you with safety, assembly,
operation, adjustments, troubleshooting, and
maintenance. Read this manual and follow the
recommendations to help ensure safe and efficient
operation.
The information in this manual is current at printing.
Some parts may change to assure top performance.
Definitions
The following terms are used throughout this manual.
Right-hand and left-hand as used in
this manual are determined by facing
the direction the machine will travel
while in use unless otherwise stated.
An orientation rose in some line art
illustrations shows the directions of:
Up, Back, Left, Down, Front, Right.
A crucial point of information related to the current topic. Read
and follow the directions to remain safe, avoid serious damage
to equipment and ensure desired field results.
NOTE:
Useful information related to the preceding topic.
U
D
F
B
L
R

2017-10-26 Table of Contents Index 195-325M
3S-5000/F/HD/HDF Table of Contents Index Introduction 16
Owner Assistance
If you need customer service or repair parts, contact a
Great Plains dealer. They have trained personnel, repair
parts and equipment specially designed for Great Plains
products.
Refer to Figure 2
Your machine’s parts were specially designed and
should only be replaced with Great Plains parts. Always
use the serial and model number when ordering parts
from your Great Plains dealer. The serial-number plate is
located on the left end of seed box frame, as shown.
Record your 3S-5000/F/HD/HDF Drill model and serial
number here for quick reference:
Model Number:__________________________
Serial Number: __________________________
Further Assistance
Great Plains Manufacturing, Inc. and your Great Plains
dealer want you to be satisfied with your new drill. If for
any reason you do not understand any part of this
manual or are otherwise dissatisfied, please take the
following actions first:
1. Discuss the matter with your dealership service
manager. Make sure they are aware of any problems
so they can assist you.
2. If you are still unsatisfied, seek out the owner or
general manager of the dealership.
If your dealer is unable to resolve the problem or the
issue is parts related, please contact:
Great Plains Service Department
1525 E. North St.
P.O. Box 5060
Salina, KS 67402-5060
Or go to www.greatplainsag.com and follow the contact
information at the bottom of your screen for our service
department.
Figure 2
Serial Number Plate 34299
