GREAT PLANES ElectriFly MICRO DC 2S LIPO CHARGER User manual

SPECIFICATIONS
Input voltage: 11.7 V–15V DC
Battery types, # cells: 2 lithium-polymer cells
connected in Series
(7.4V LiPo)
Charge current: 450mA maximum
Charge method: CC-CV (current drop-off
termination)
Battery capacity: 150 – 750 mAh
Status indicator: Two LEDs;
one green, one red
Input connectors: polarized DC power jack
for DC input
Output connectors: one 2S balance plug
Case size: 2.18”
x1.13” x3.26”
[55
x28 x82 mm]
Weight: 2.1 oz. [59 g]
SPECIAL FEATURES
●A very economical, portable and simple way to balance
charge LiPo batteries
●Specifically designed for 2-cell 7.4V lithium-polymer
batteries only
●“Constant current/constant voltage” charge method
●Automatically starts charge upon connection of battery
to the balance plug
●450 mA maximum charge current requires no
adjustment
●Twin LEDs indicate charging status
IMPORTANT PRECAUTIONS
●Charge only lithium-polymer (LiPo) rechargeable
batteries that are 2S (2 cells in series) 7.4V nominal
voltage, from 150 mAh to 750 mAh, which have a
balance connector.
●Do not attempt to use this charger with NiCd, NiMH or
different types of Lithium-Ion batteries as they are not
compatible!
●Do not leave the charger unattended while charging.
Disconnect the battery and remove input power from
charger immediately if either becomes hot! However, it
is normal for the charger to get warm.
●Disconnect the battery from the charger immediately
and remove to a fireproof location if the battery begins
to swell or smoke!
●Only use the included car adapter or approved AC
adapter to power the charger.
●Do not use charger with car running.
●Do not allow water, moisture or foreign objects into the
charger.
●Do not block the air intake holes, which could cause the
charger to overheat.
●Do not place the charger or any battery on a flammable
surface or near a combustible material while in use.
●Do not charge on a carpet, cluttered workbench, paper,
plastic, vinyl, leather, wood, or inside an R/C model.
●Never charge inside a full-sized vehicle.
●Always disconnect charger from input power when not
in use.
●Do not attempt to charge a battery if it is swollen or hot.
●Keep out of reach of children.
CHARGING BATTERIES
IMPORTANT!! ALWAYS charge a LiPo battery in a
location that is fireproof. NEVER leave the battery
unattended while being charged! If the battery feels
warm during charge, remove the battery at once and
disconnect the charger from the power source.
Heat-resistant LiPo charging bags (GPMP0751) provide
additional safety when charging and are available
through your hobby supplier.
Use only approved power input accessories – the
included car adapter and AC adapter (also available
separately GPMM3310).
To charge a battery:
1. Connect input power to
the charger. The GREEN
LED will be lit, indicating
standby mode. The RED
LED will be OFF.
2. Connect the battery to
be charged to the balance
plug. The RED LED will also be lit, and remain RED during
charging. Both LEDs should be lit solid while charging.
The ElectriFly
®
LiPo Battery Charger is great for simple balance
charging of 2-cell lithium-polymer batteries for small electric
models. Use it only to charge batteries within a capacity range
of 150 to 750mAh.
MICRO DC 2S LIPO CHARGER
®

3. When the battery is fully charged, the GREEN LED will turn
OFF. Remove the battery from the charger at this time.
4. Charging time depends on level of discharge and capacity
of the battery. To estimate how long it should take to charge an
empty battery, divide the capacity of the battery in mAh by the
charge rate in milliamps:
200 mAh battery / 450 mA ~ 30 minutes
350 mAh battery / 450 mA ~ 50 minutes
LED scheme – Use this table to determine charge action:
RED LED GREEN LED ACTION
OFF Solid ON No battery is connected
OFF Flashing Conditioning battery
Solid ON Solid ON Battery charging
Solid ON OFF Charge complete
Flashing Flashing ERROR
Possible sources of battery error may include a highly unbalanced
pack, charger timed out, or one cell in the pack which is low
voltage. In the case of a battery error, please remove the battery
pack from the charger and inspect it carefully for swelling or any
other damage, such as broken wires.
1-Year Limited Warranty – *USA and Canada Only
Great Planes®warrants this product to be free from defects
in materials and workmanship for a period of one (1) year
from the date of purchase. During that period, Great Planes
will, at its option, repair or replace without service charge
any product deemed defective due to those causes. You will
be required to provide proof of purchase (invoice or receipt).
This warranty does not cover damage caused by abuse,
misuse, alteration or accident. If there is damage stemming
from these causes within the stated warranty period, Great
Planes will, at its option, repair or replace it for a service
charge not greater than 50% of its then current retail list
price. Be sure to include your daytime telephone number in
case we need to contact you about your repair. This warranty
gives you specific rights. You may also have other rights,
which vary from state to state.
For service on your Great Planes product, warranty or non-
warranty, send it post-paid and insured to:
HOBBY SERVICES [phone]
3002 N. Apollo Drive, Suite 1
Champaign, IL 61822
*For warranty and service information if purchased outside
the USA or Canada, see the additional warranty information
insert (if applicable) or ask your retailer for more information.
www.greatplanes.com www.electrifly.com
ONLY use a LiPo approved charger. NEVER use a NiCd/
NiMH peak charger to charge a LiPo battery.
NEVER charge in excess of 4.20V per cell.
ONLY charge through the “charge” lead. NEVER charge
through the “discharge” lead.
NEVER charge at currents greater than 1C unless the
battery is rated for a higher charge rate.
ALWAYS set the charger’s output volts to match the
battery volts.
ALWAYS charge in a fireproof location.
NEVER trickle charge.
NEVER allow the battery temperature to exceed 150
degrees F (65 degrees C).
NEVER disassemble or modify the pack wiring in any way
or puncture the cells.
NEVER discharge below 2.5V per cell.
NEVER place the battery or charger on combustible
materials or leave it unattended during charge or discharge.
ALWAYS KEEP OUT OF THE REACH OF CHILDREN.
NEVER charge the battery in the plane.
ALWAYS remove the battery from the plane after a crash.
Set it aside in a safe location for at least 20 minutes. If
the battery is damaged in the crash it could catch fire.
If the battery starts to swell, quickly move the battery to
a safe location, preferably outside. Place it in a bucket,
covering the battery with sand. Never use water to try and
put out a LiPo fire.
LITHIUM BATTERY HANDLING & USAGE
GPMM3322INSTR
© 2012 Hobbico, Inc. All rights reserved.
