General information
Reading and storing the user manual
This user manual accompanies this upper arm
blood pressure monitor and contains important
information on setup and handling. For
improved readability, the upper arm blood pressure
monitor will be referred to only as the “blood pressure
monitor” below.
Before using the blood pressure monitor, read the user
manual carefully. This particularly applies to the safety
notes. Failure to do so may result in personal injury or
damage to the blood pressure monitor.
Store the user manual for further use. Make sure to
include the user manual when passing the blood
pressure monitor on to third parties.
Explanation of symbols
The following symbols and signal words are used in this
user manual, on the blood pressure monitor or on the
packaging.
WARNING!
This signal symbol/word designates a hazard with
moderate risk, which may result in death or severe
injury if not avoided.

[e-mail]
AFTER SALES SUPPORT
General information
USA
8
USA 815-342-5850
CAUTION!
This signal symbol/word designates a hazard with low
risk, which may result in minor or moderate injury if not
avoided.
NOTICE!
This signal word warns of possible damage to property.
This symbol provides you with useful
additional information on handling and use.
This symbol identifies devices classified as
type BF.
This symbol indicates that you should read
the user manual and hold on to it.
This symbol identifies information from the
manufacturer (see chapter “Manufacturer
information”).
This symbol identifies the serial number of
the device.
This symbol indicates that the center (tip) of
the output plug is positive (+) and the barrel
(ring) of the output plug is negative (-).

[e-mail]
AFTER SALES SUPPORT
USA 815-342-5850
9
Safety USA
Safety
Proper use
The blood pressure monitor is exclusively designed
for non-invasive measurement of an adult’s systolic,
diastolic blood pressure and pulse rate using the
oscillometric method. The readings are shown on the
display.
The blood pressure monitor issues a warning in the
event of cardiac arrhythmia. The levels measured
are classified and rendered in accordance with the
guidelines of the WHO (World Health Organisation).
The blood pressure monitor is not intended for use on
infants and children.
The blood pressure monitor is designed exclusively for
private use and is not suitable for commercial or clinical
use. The measurement position is on an adult’s upper
arm only.
Only use the blood pressure monitor as described in
this user manual. Any other use is deemed improper
and may result in damage to property or even personal
injury. The pressure blood monitor is not a toy for
children.
The manufacturer or vendor accepts no liability for
damage caused by improper or incorrect use.

[e-mail]
AFTER SALES SUPPORT
Safety
USA
10
USA 815-342-5850
Safety notes
WARNING!
Danger for children and persons with
impaired physical, sensory or mental
capacities (e.g. partially disabled
persons, older persons with reduced
physical and mental capacities) or lack
of experience and knowledge (e.g.
children).
− The blood pressure monitor may not
be used by children under the age of 8.
Keep the blood pressure monitor and its
accessories away from children under
the age of 8.
− The blood pressure monitor may be
used by children ages eight and over as
well as persons with impaired physical,
sensory or mental capacities or those
lacking experience and/or knowledge
if they are supervised or have been
instructed in how to safely use the blood
pressure monitor and have understood
the risks associated with operating it.

[e-mail]
AFTER SALES SUPPORT
USA 815-342-5850
11
Safety USA
− Do not allow children to play with the
packaging wrapper. They may get
caught in it and suffocate.
WARNING!
Risk of injury!
Improper use of the blood pressure monitor
may result in injury.
− Only use the blood pressure monitor for
its intended purpose. Do not misuse in
any way.
− The blood pressure monitor is not
intended for infants or individuals who
cannot express their intentions.
− People with serious circulation problems
may experience discomfort. Consult
your physician prior to use.
− Contact your physician if test results
regularly indicate abnormal readings. Do
not attempt to self-treat these symptoms
without consulting a physician.

[e-mail]
AFTER SALES SUPPORT
Safety
USA
12
USA 815-342-5850
NOTICE!
Risk of damage!
Improper use of the blood pressure monitor
may result in inaccurate measurements and
damage to the blood pressure monitor.
− Do not disassemble or attempt to repair
the blood pressure monitor.
− Do not expose the blood pressure
monitor to strong magnetic fields (e.g.
transformers). Otherwise this could
cause errors in readings or damage to
the blood pressure monitor.
− Only use the blood pressure monitor at
an ambient temperature of +50 °F to
+104 °F and a humidity of 15 % to 90 %.
− Do not open the housing of the blood
pressure monitor.
− Protect the blood pressure monitor
against dirt, direct sunlight, severe
temperature fluctuations, chemicals and
mechanical shocks.
− Do not let the blood pressure monitor
fall down.
− Only use enclosed or original
replacement cuffs to ensure that the

[e-mail]
AFTER SALES SUPPORT
USA 815-342-5850
13
Safety USA
measurements are correct.
− Do not start the measurement process
until the cuff has been fitted.
− Do not immerse the blood pressure
monitor in water and do not rinse it off
under running water.
− Protect the cuff and its hose from sharp
and pointy objects.
− Do not kink the cuff hose.
− Do not place any heavy objects on the
blood pressure monitor, the cuff or cuff
hose.
Battery notes
WARNING!
Health hazards!
There is a high health hazard if children or
animals swallow the batteries.
− Store the batteries so they are not
accessible to children and animals. If you
suspect a battery has been swallowed,
seek immediate medical advice.

[e-mail]
AFTER SALES SUPPORT
Safety
USA
14
USA 815-342-5850
WARNING!
Risk of explosion!
Improper handling of batteries increases
the risk of explosion.
− Store the batteries in a cool, dry place.
Never expose the batteries to excessive
heat (e.g. direct sunlight) and never
dispose of them in a fire.
− Only use batteries of the same type.
− Do not charge the batteries and do not
reactivate them with other means.
− Do not short circuit the batteries.
− Do not open the batteries.
− Ensure the correct polarity when
inserting the batteries. This is shown
in the battery compartment. Incorrect
installation may damage the blood
pressure monitor.
− Always use batteries of premium quality.
Batteries of poor quality may leak and
cause damage.
− Before inserting the batteries, make
sure the contacts inside the battery

[e-mail]
AFTER SALES SUPPORT
USA 815-342-5850
15
Safety USA
compartment and on the battery itself
are clean and intact. Clean them if
necessary.
− Always replace all batteries in the
battery compartment at the same time.
− Remove the batteries from the blood
pressure monitor if they are dead.
Also remove the batteries if you do not
intend on using the blood pressure
monitor for a prolonged period of time.
Otherwise, the batteries may leak and
cause damages.
− If the batteries are leaking, remove
them immediately to prevent damaging
the blood pressure monitor. Do not
remove the batteries with your bare
hands or allow the battery fluid to come
into contact with skin, eyes or mucous
membranes. Wear normal household
rubber gloves to do so. If, however,
your skin has come into contact with
the battery fluid, wash your hands
immediately and consult a physician if
necessary.

[e-mail]
AFTER SALES SUPPORT
Safety
USA
16
USA 815-342-5850
− Batteries should be installed or replaced
only by an adult.
− Keep the blood pressure monitor away
from children when the battery cover is
removed.
− Remove the batteries before disposing
of the blood pressure monitor.
Safe use of power adaptor
WARNING!
Risk of injury!
Improper use of the power adaptor may
result in injury.
− Only use a suitable medical power
adaptor (DC 6.0 V, 600 mA, not provided)
with the blood pressure monitor.
− Only use the power adaptor in dry
and indoor areas. Do not let the power
adaptor come into contact with water or
other liquids.
− Connect the power adaptor only to an
alternating current (AC) power supply.
Make sure that the voltage corresponds

[e-mail]
AFTER SALES SUPPORT
USA 815-342-5850
17
Safety USA
with the voltage details on the power
adaptor.
− Only connect the power adaptor to a
properly installed and easily accessible
socket so that you can quickly pull the
plug in an emergency.
− Never cover the power adaptor. Ensure
that sufficient ventilation is provided
in order to prevent the power adaptor
from overheating.
− Do not use the power adaptor if the
housing or cord is defective or has
other visible damages. In the event of
damage, only have the power adaptor
serviced by the manufacturer, its
customer service team or a similarly
qualified person to avoid risks.
− Always remove the power adaptor from
the power socket if you want to clean
the blood pressure monitor or do not
intend on using the blood pressure
monitor for a prolonged period of time.

[e-mail]
AFTER SALES SUPPORT
First use
USA
18
USA 815-342-5850
First use
Checking the blood pressure monitor
and package contents
NOTICE!
Risk of damage!
If you are not cautious when opening the
packaging with a sharp knife or other
pointy objects, you could damage the blood
pressure monitor.
− Be very careful when opening the
packaging.
1. Take the blood pressure monitor out of the
packaging and remove the packaging material.
2. Check to make sure that all components and
accessories have been received (see Fig. A).
3. Check whether the blood pressure monitor or the
individual parts exhibit damage. If this is the case,
do not use the blood pressure monitor. Contact the
manufacturer at the service address specified in the
warranty certificate.

[e-mail]
AFTER SALES SUPPORT USA 815-342-5850
19
First use
USA
Installing or replacing batteries
NOTICE!
Risk of damage!
Incorrect battery installation may damage
the blood pressure monitor.
− Pay attention to the correct battery
polarity (+ or -).
1. Open the battery compartment 6by removing the
battery compartment door 5.
2. For battery replacement, remove the old batteries
first. Insert 4 batteries 12 (size AA) into the battery
compartment.
3. Close the battery compartment by replacing the
battery compartment door.
Using a power adaptor
The blood pressure monitor can also be
powered by a power adaptor (not provided).
A medical power adaptor (DC 6.0 V, 600 mA)
is recommended for use. The adaptor
connection pin must be positive inside and
negative outside with a 0.08 inch (2.1 mm)
coaxial joint.
1. Connect the output plug of the power adaptor (not
provided) to the power adaptor jack 8.
2. Connect the power adaptor to a socket.

[e-mail]
AFTER SALES SUPPORT
System settings
USA
20
USA 815-342-5850
System settings
The system settings allow you to select users, and set
date, time and time format.
1. After the blood pressure monitor is powered, press
the SET button 4.
Do not press the START/STOP button 3at this
moment.
A user icon ( or ) 14 will show on the display 1.
2. Press the M button 2to select either user icon 1 or
user icon 2.
This allows up to two users to save and accumulate
the test results (60 memory slots per user).
3. Press the SET button to confirm the setting.
A message “ ” (year) will show on the display.
4. Press the M button to set the year and then press the
SET button to confirm.
5. Repeat steps 3 to 4 to set the month, date, hour time
and minute time.
The date 20 and time 21 are shown at the lower left
corner of the display.
6. After the minute time is set, press the M button to
select 12-hour time format or 24-hour time format.
The 12-hour time format is indicated by the message
“” and the 24-hour time format by “ ”.
7. Press the SET button for the voice readout setting.
Press the M button to set it “ ” (English),
“” (Spanish) or “ ” (OFF).

[e-mail]
AFTER SALES SUPPORT USA 815-342-5850
21
Advice on use
USA
8. Press the SET button for the volume level setting.
Press the M button to set the volume level of the
voice readout function.
9. Press the START/STOP button to save the settings.
The blood pressure monitor will also automatically
save all settings and switch itself off without any
operations for 3 minutes.
It is important to set the date and time.
Otherwise, you will not be able to save the
measurement results correctly and to access
them again later.
Advice on use
For ideal measurement results, follow the
basic rules below when measuring your
blood pressure.
− If possible, always measure your blood pressure at
the same time of day for comparable results.
− Measurement comparisons should only be made
when the blood pressure monitor is used on the
same arm, in the same position and at the same time
of the day.
− Morning time or any time you feel relaxed and stress-
free is the best for measurements.
− Do not stand during measurements. Sit or lay down
in a relaxed position while keeping your arm level
with your heart.
− Avoid speaking or moving the body parts during the

[e-mail]
AFTER SALES SUPPORT
Advice on use
USA
22
USA 815-342-5850
measurements.
− Relax at least 30 minutes before you perform a
measurement, do not smoke, eat or drink and avoid
physical exertion.
− Give the circulatory system about five minutes to
calm down each time before a measurement is
made.
− If the measurements are not plausible, repeat the
measurement.
− Wait at least five minutes before taking another
measurement for the same person.
− The results of the blood pressure measurements
are for information only and are no substitute for
a medical examination. Do not make any medical
decisions based on your own measurements (e.g.
with respect to taking medication or their dosage).
Consult your physician if you have questions about
the measurements.
− Do not use this blood pressure monitor to perform
any measurements on preeclampsia patients or
newborn babies.
− Consult a physician before using the blood pressure
monitor on pregnant persons.
− Do not use the blood pressure monitor together with
high-frequency surgical devices.
− Only use the blood pressure monitor for persons
with an upper arm circumference between 8.7 and
16.5 inch (22 and 42 cm).
− The function of the affected body part may be

[e-mail]
AFTER SALES SUPPORT
USA 815-342-5850
23
Advice on use USA
impaired when inflating the cuff.
− Do not kink, compress or otherwise restrict the cuff
hose.
− Always measure the blood pressure on the same
arm, ideally, the left arm. Measuring on the left arm
may provide more accurate results as it is closer to
the heart.
− Do not use the cuff on limbs whose arteries or veins
are undergoing medical treatment, e.g. in the form
of intravascular access, intravascular therapy or
arteriovenous (A-V) shunt.
− Do not fit the cuff on persons, who have undergone a
mastectomy.
− Keep in mind that the restriction of circulation
through the inflation of the cuff may temporarily
cause other measurement devices connected to the
same body part to malfunction.
− Avoid performing frequent measurements and
prolonged pressure in the cuff to prevent injury.
− The following illnesses or symptoms may result in
incorrect measurements or affect the measurement
accuracy of the blood pressure monitor:
• Diseases of the cardiovascular system,
• very low blood pressure,
• diabetes,
• circulatory disorder and cardiac arrhythmia,
• shivering,
• shaking.

[e-mail]
AFTER SALES SUPPORT
Performing a measurement
USA
24
USA 815-342-5850
− The following conditions may result in incorrect
measurements or affect the measurement accuracy
of the blood pressure monitor:
• Improper cuff placement,
• Improper body position,
• Feeling anxious or nervous.
Performing a measurement
CAUTION!
Risk of injury!
Improper use of the blood pressure monitor
may result in injury.
− Avoid prolonged exposure to the
pressure exerted by the cuff, e.g. by
kinking the cuff hose and by performing
prolonged or frequent measurements.
− Do not place the cuff over wounds to
prevent further injury.
− Remove the cuff from your arm in the
event of a malfunction.
Fitting the cuff
1. Expose the arm where the blood pressure will be
measured. Use the left arm if possible.

[e-mail]
AFTER SALES SUPPORT
USA 815-342-5850
25
Performing a measurement USA
2. Wrap the cuff 9around the exposed upper arm.
The bottom edge of the cuff must be 0.4–0.8 inch
(1–2 cm) above the elbow and over the artery (see
step 1 in Fig. C). The cuff hose 10 must point towards
the middle of the palm.
3. Place the free end of the cuff around the arm.
The cuff must be fitted tightly enough so that two
fingers can fit under the cuff.
4. Once the cuff has been properly fitted, close the
hook and loop fastener on the cuff.
5. Connect the air plug 11 of the cuff to the air jack 7.
Assuming the correct posture
Perform measurements while sitting or lying down and
observe the following instructions:
− The cuff must be roughly at the height of the heart,
but no higher (see step 2 in Fig. C).
− Rest the arms in a relaxed position. A chair with
armrests or a table are required for measurements
while sitting (see step 3 in Fig. C).
− Do not move and do not speak while performing a
measurement.
When sitting, observe also the following instructions:
− Sit in a relaxed position when measuring the blood
pressure and lean back.
− Place the feet flat on the ground.
− Do not cross the legs.

[e-mail]
AFTER SALES SUPPORT
Performing a measurement
USA
26
USA 815-342-5850
Starting a blood pressure measurement
You can always cancel blood pressure
measurements that are in progress (e.g. when
the pressure in the cuff becomes too extreme)
by pressing the START/STOP button.
1. After the blood pressure monitor is powered, press
the SET button 4.
Do not press the START/STOP button 3at this
moment.
A user icon ( or ) 14 will show on the display 1.
2. Press the M button 2to select either user icon 1 or
user icon 2.
This allows the measurements to be saved into
the memory slots of the selected user after the
measurement is done.
3. Press the START/STOP button to save the setting.
You may skip steps 1–3 if you do not intend to
save the measurement results into memory.
4. Press the START/STOP button to start the
measurement.
5. You will hear a beep tone and then an English
instruction, saying that the measurement will now
begin.
If there is residual air in the cuff 9from the previous
measurement, air will be released from the cuff until
