Gree FP-8XD-E User manual

CASSETTE TYP FAN COIL UNIT

Contens
ⅠPRODUCT................................................................................................. 1
1. MODELS LIST.................................................................................................................2
2. NOMENCLATURE OF THE UNIT...................................................................................4
3. FUNCTION ......................................................................................................................4
4. PRODUCT DATA............................................................................................................5
ⅡCONTROL............................................................................................... 22
1. WIRELESS REMOTE CONTROLLER..........................................................................23
1.1 YB1F2(X-FAN)............................................................................................................................ 23
1.1.1 Guide for operation-general operation .......................................................................................... 26
1.1.2 Guide for operation-optional operation......................................................................................... 26
1.1.3 Introduction for special function .................................................................................................... 26
1.1.4 Changing batteries and notices ...................................................................................................... 27
1.2 YB1FA(X-FAN)........................................................................................................................... 28
1.2.1 Operation of wireless remote control ............................................................................................ 30
1.2.2 Changing batteries and notices. ..................................................................................................... 31
2. WIRED REMOTE CONTROLLER.................................................................................32
2.1 Introduction to Z5K351(optional)............................................................................................ 32
2.2 Introduction to Z4E351B (optional)......................................................................................... 33
2.2.1 Symbols on the LCD ........................................................................................................................ 33
2.2.2 Introduction to the Functions of the Press Keys............................................................................. 34
ⅢUNIT INSTALLATION............................................................................ 36
1. SELECTION THE MOUNTING POSITION....................................................................37
1.1 Ceiling opening and suspension bolt (M l0) pitch flemension............................................ 38
2. DRAINAGE PIPE...........................................................................................................38
3. PRECAUTIONS FOR DRAINAGE RAISING PIPE.......................................................39
3.1 Instruction.................................................................................................................................. 40
4. ELECTRIC WIRING.......................................................................................................41
4.1 Wiring of unit and the controller............................................................................................. 42
4.1.1 Wiring of the unit............................................................................................................................ 42
5. INSTALLATION OF PANEL .........................................................................................43
5.1 Precautions................................................................................................................................ 44
5.2 After fixing be sure no gap left between the ceiling and the panel..................................... 45
ⅣUnit MAINTENANCE............................................................................. 46
1.TROUBLESHOOTING ...................................................................................................47
2.CARE AND MAINTENANCE .........................................................................................47
3. WIRING DIAGRAM .......................................................................................................51
4. DISASSEMBLY AND ASSEMBLY PROCEDURE OF MAIN PARTS ..........................54
5. EXPLODED VIEWS AND SPARE PART LISTS...........................................................60

PRODUCT
1
ⅠPRODUCT

PRODUCT
2
1. MODELS LIST
Model Name
Product Code
Cooling
Capacity
(W)
Air flow
Volume
(m3/h)
Power Supply
(V, Ph, Hz)
Remarks
FP-8XD-E
EM52000051
4600/7500
850
220-240V~ 50Hz
FP-8XD/A-E
EM5200045010
4640/7500
850
220-240V~ 50Hz
FP-10XD-E
EM52000061
5400/9100
1020
220-240V~ 50Hz
FP-10XD/A-E
EM5200046010
5400/9100
1020
220-240V~ 50Hz
FP-12.5XD-E
EM52000031
6700/10500
1270
220-240V~ 50Hz
FP-12.5XD/A-E
EM5200047010
6700/10500
1250
220-240V~ 50Hz
FP-14XD-E
EM52000071
7700/11200
1560
220-240V~ 50Hz
FP-14XD/A-E
EM5200048010
7740/11200
1430
220-240V~ 50Hz
FP-16XD-E
EM52000081
8700/12900
1640
220-240V~ 50Hz
FP-16XD/A-E
EM5200049010
8700/12900
1640
220-240V~ 50Hz
FP-18XD-E
EM52000041
9600/14600
1850
220-240V~ 50Hz
FP-18XD/A-E
EM5200050010
9600/14600
1800
220-240V~ 50Hz
FP-51XD-E
EM52000011
3000/4000
510
220-240V~ 50Hz
FP-68XD-E
EM52000021
3500/5000
680

PRODUCT
3
Model Name
Product Code
Cooling/Heating
Capacity
(W)
Air flow
Volume
(m3/h)
Power Supply
(V, Ph, Hz)
Remarks
FP-51XD/A-K
EM520N1170
2750/3400
510
220-240V~ 50Hz
FP-68XD/A-K
EM520N1160
3600/4200
680
FP-85XD/B-T
EM520N0930
4150/5600
800
220-240V~ 50Hz
EM520N0940
4160/7800
780
208-230V~ 60Hz
FP-102XD/B-T
EM520N0910
500/6500
1020
220-240V~ 50Hz
EM520N0920
540/9000
1020
208-230V~ 60Hz
FP-125XD/B-T
EM520N0890
6000/7800
1180
220-240V~ 50Hz
EM520N0900
6300/10000
1130
208-230V~ 60Hz
FP-140XD/B-T
EM520N0870
8000/9000
1400
220-240V~ 50Hz
EM520N0880
8000/12000
1350
208-230V~ 60Hz
FP-160XD/B-T
EM520N0850
8700/10000
1550
220-240V~ 50Hz
EM520N0860
9000/14000
1550
208-230V~ 60Hz
FP-180XD/B-T
EM520N0830
9500/11000
1800
220-240V~ 50Hz
EM520N0840
10000/16000
1800
208-230V~ 60Hz
FP-200XD/B-T
EM520N0810
13000/14600
2000
220-240V~ 50Hz
EM520N0820
13000/19000
2000
208-230V~ 60Hz
FP-200XD/D-K
EM520N1210
12000/14200
2000
220-240V~ 50Hz
FP-68XDT/B-K
EM520N0990
3500/6000
680
220-240V~ 50Hz
FP-85XDT/B-K
EM520N0960
4100/6800
850
220-240V~ 50Hz
FP-125XDT/B-K
EM520N0970
6000/9500
1250
220-240V~ 50Hz
FP-180XDT/B-K
EM520N0980
8000/13000
1800
220-240V~ 50Hz

PRODUCT
4
2. NOMENCLATURE OF THE UNIT
FP
-
□
□
□
/
□
-
□
1
2
3
4
5
6
NO.
Description
Options
1
Fan coil
Fan coil unit
2
Air flow volume
Number×10 m3/h(FP-51XD-E;FP-68XD-E);Number×100
m3/h(8,10,12.5,14,16,18)
3
Structure type
XD-Cassette Type
4
Pipes type
Default- 2 pipes; T-4 pipes
5
Design Sequence
Arranged by A, B,C…
6
Power code
E-220-240V~ 50Hz;T-220-240V~ 50Hz, 208-230V~ 60Hz; K-220-240V~ 50Hz
3. FUNCTION
(1) Novel pattern: the exposed skin plates of unit looks so elegant and luxurious that they can be
taken as the indoor decorations.
(2) Compact design: A large number of non-metallic materials have been used, so that the body of
the unit is quite light-weight and thin, which makes the unit looks sensuous.
(3) Low noise: Dynamic principles have been adopted for the design of the fan blades so as to make
sure the air volume is enough and running noise is considerably low.
(4) Durable filter screen: The durable filter screen shares a cleaning cycle 20 times longer than that
of the conventional filter screen, needless to clean it frequently.
(5) Microcomputer control: The unit is able to automatically adjust the fan speed in accordance with
the indoor ambient temperature to meet a wide range of users’ requirements.
(6) Small height of the unit, saving much installation space
(7) Large cooling (heating) capacity, low noise, three-speed motor which can adjust the air volume
and meet a wide range of users’ requirements.
(8) Excellent material, stringent process control, which guarantee the hi-quality and long life of the
unit.
(9) Die-formed drain pan, entirely bonded insulating material, carefree about the condensate water.

PRODUCT
5
4. PRODUCT DATA
Model
FP-8XD/A-E
FP-10XD/A-E
FP-12.5XD/A-E
FP-14XD/A-E
Code
EM5200045010
EM5200046010
EM5200047010
EM5200048010
Air flow
volume
High
CFM
500
600
735
841
m3/h
850
1020
1250
1430
Medium
CFM
375
464
606
802
m3/h
637
789
1030
1363
Low
CFM
303
362
538
705
m3/h
515
615
915
1200
Capacity
Cooling
W
4640
5400
6700
7740
Heating
W
7500
9100
10500
11200
Power system
Type
V-Ph-Hz
220-240V~ 50Hz
220-240V~ 50Hz
220-240V~ 50Hz
220-240V~ 50Hz
Input
W
100
100
150
140
Exterior static pressure
Pa
0
0
0
0
Water system
Water flow volume
m3/h
0.829
0.964
1.196
1.382
Pressure drop
kPa
15
25
25
30
Coil
Type
-
Aluminum
fin-copper tube
Aluminum
fin-copper tube
Aluminum
fin-copper tube
Aluminum
fin-copper tube
Operating pressure
MPa
≤1.6MPa
≤1.6MPa
≤1.6MPa
≤1.6MPa
Motor
Type
-
FN35B
FN35B
FN35B
FN50T
Capacitor
µF
2.5
3.5
3.5
2.5
Power output
W
35
35
35
50
Sound pressure level
dB(A)
46
46
47
52
Connection
pipe size
Water inlet &outlet
inch
G3/4"
G3/4"
G3/4"
G3/4"
Condensing water
drain
mm
32
32
32
32
Outline
dimension
(W×D×H)
Body
mm
840×840×240
840×840×240
840×840×240
840×840×320
Panel
mm
960×960×60
960×960×60
960×960×60
960×960×60
Package
dimension
(W×D×H)
Body
mm
960×960×310
960×960×310
960×960×310
960×960×394
Panel
mm
1040×1025×115
1040×1025×115
1040×1025×115
1040×1025×115
Net weight
Body
kg
27
27
27
33
Panel
kg
6.5
6.5
6.5
6.5
Gross weight
Body
kg
35
35
35
42
Panel
kg
10
10
10
10
Loading quantity
20'GP
84
84
84
72
40'GP
168
168
168
120
40'HQ
192
192
192
144
Wired remote controller
Z5K351/Z4E351B
Z5K351/Z4E351B
Z5K351/Z4E351B
Z5K351/Z4E351B
Wireless remote controller
YB1F2(X-FAN)
YB1F2(X-FAN)
YB1F2(X-FAN)
YB1F2(X-FAN)

PRODUCT
6
Model
FP-16XD/A-E
FP-18XD/A-E
Code
EM5200049010
EM5200050010
Air flow volume
High
CFM
965
1060
m3/h
1640
1800
Medium
CFM
853
1035
m3/h
1460
1760
Low
CFM
781
932
m3/h
1327
1584
Capacity
Cooling
W
8700
9600
Heating
W
12900
14600
Power system
Type
V-Ph-Hz
220-240V~ 50Hz
220-240V~ 50Hz
Input
W
150
155
Exterior static pressure
Pa
0
0
Water system
Water flow volume
m3/h
1.554
1.714
Pressure drop
kPa
30
30
Coil
Type
-
Aluminum fin-copper tube
Aluminum fin-copper tube
Operating pressure
MPa
≤1.6MPa
≤1.6MPa
Motor
Type
-
FN50T
FN50T
Capacitor
µF
4.5
4.5
Power output
W
50
50
Sound pressure level
dB(A)
53
54
Connection pipe
size
Water inlet &outlet
inch
G3/4"
G3/4"
Condensing water
drain
mm
32
32
Outline
dimension
(W×D×H)
Body
mm
840×840×320
840×840×320
Panel
mm
960×960×60
960×960×60
Package
dimension
(W×D×H)
Body
mm
960×960×394
960×960×394
Panel
mm
1040×1025×115
1040×1025×115
Net weight
Body
kg
33
33
Panel
kg
6.5
6.5
Gross weight
Body
kg
42
42
Panel
kg
10
10
Loading quantity
20'GP
72
72
40'GP
120
120
40'HQ
144
144
Wired remote controller
Z5K351/Z4E351B
Z5K351/Z4E351B
Wireless remote controller
YB1F2(X-FAN)
YB1F2(X-FAN)

PRODUCT
7
Model
FP-8XD-E
FP-10XD-E
FP-12.5XD-E
FP-14XD-E
Code
EM52000051
EM52000061
EM52000031
EM52000071
Power system
Type
V-Ph-Hz
220-240V~ 50Hz
220-240V~ 50Hz
220-240V~ 50Hz
220-240V~ 50Hz
Input
W
100
100
150
140
Air flow volume
High
CFM
500
600
735
840
m3/h
850
1020
1250
1430
Medium
CFM
375
464
606
802
m3/h
638
789
1030
1363
Low
CFM
303
363
538
705
m3/h
515
617
914
1198
Capacity
Cooling
W
4640
5400
6700
7740
Heating
W
7500
9100
10500
11200
Electric heater rated power
W
1400
1400
1400
1400
Water system
Water flow
volume
m3/h
0.81
0.95
1.18
1.36
Pressure
drop
kPa
15
25
25
25
Sound pressure level
dB(A)
46
46
47
52
Coil
Type
-
Aluminum
fin-copper tube
Aluminum
fin-copper tube
Aluminum
fin-copper tube
Aluminum
fin-copper tube
Operating
pressure
MPa
≤1.6MPa
≤1.6MPa
≤1.6MPa
≤1.6MPa
Motor
Type
-
FN35B
FN35B
FN35B
FN50T
Capacitor
µF
2.5
3.5
3.5
2.5
Connection
pipe size
Water inlet
&outlet
inch
G3/4"
G3/4"
G3/4"
G3/4"
Condensing
water drain
mm
32
32
32
32
Outline
dimension
(W×D×H)
Body
mm
840×840×240
840×840×240
840×840×240
840×840×320
Panel
mm
960×960×60
960×960×60
960×960×60
960×960×60
Package
dimension
(W×D×H)
Body
mm
960×960×310
960×960×310
960×960×310
960×960×394
Panel
mm
1040×1025×115
1040×1025×115
1040×1025×115
1040×1025×115
Net weight
Body
kg
30
30
30
38
Panel
kg
6.5
6.5
6.5
6.5
Gross weight
Body
kg
38
38
38
46
Panel
kg
10
10
10
10
Loading quantity
20'GP
61
61
51
51
40'GP
116
116
116
93
40'HQ
133
133
133
112
Wired remote controller
Z5K351/Z4E351B
Z5K351/Z4E351B
Z5K351/Z4E351B
Z5K351/Z4E351B
Wireless remote controller
YB1F2(X-FAN)
YB1F2(X-FAN)
YB1F2(X-FAN)
YB1F2(X-FAN)

PRODUCT
8
Model
FP-16XD-E
FP-18XD-E
Code
EM52000081
EM52000041
Power system
Type
V-Ph-Hz
220-240V~ 50Hz
220-240V~ 50Hz
Input
W
49
56
Air flow volume
High
CFM
300
371
m3/h
510
680
Medium
CFM
247
318
m3/h
420
540
Low
CFM
206
265
m3/h
350
450
Capacity
Cooling
W
3000
3500
Heating
W
4000
5000
Electric heater rated power
W
1400
-
Water system
Water flow volume
m3/h
0.49
0.616
Pressure drop
kPa
5
9
Sound pressure level
dB(A)
53
43
Coil
Type
-
Aluminum fin-copper tube
Aluminum fin-copper tube
Operating pressure
MPa
≤1.6MPa
≤1.6MPa
Motor
Type
-
FN11T
FN11T
Capacitor
µF
1
2.5
Connection pipe size
Water inlet &outlet
inch
G3/4"
G3/4"
Condensing water drain
mm
25
25
Outline dimension
(W×D×H)
Body
mm
600×600×230
600×600×230
Panel
mm
650×650×50
650×650×50
Package dimension
(W×D×H)
Body
mm
848×678×310
848×678×310
Panel
mm
730×670×102
730×670×102
Net weight
Body
kg
19.3
19.3
Panel
kg
5
5
Gross weight
Body
kg
27
27
Panel
kg
6
6
Loading quantity
20'GP
51
114
40'GP
93
216
40'HQ
112
256
Wired remote controller
Z5K351/Z4E351B
Z5K351/Z4E351B
Wireless remote controller
YB1F2(X-FAN)
YB1F2(X-FAN)

PRODUCT
9
Model
FP-51XD-E
FP-68XD-E
Code
EM52000011
EM52000021
Power system
Type
V-Ph-Hz
220-240V~ 50Hz
220-240V~ 50Hz
Input
W
49
56
Air flow volume
High
CFM
300
371
m3/h
510
680
Medium
CFM
247
318
m3/h
420
540
Low
CFM
206
265
m3/h
350
450
Capacity
Cooling
W
3000
3500
Heating
W
4000
5000
Electric heater rated power
W
-
-
Water system
Water flow volume
m3/h
0.49
0.616
Pressure drop
kPa
5
9
Sound pressure level
dB(A)
43
48
Coil
Type
-
Aluminum fin-copper tube
Aluminum fin-copper tube
Operating pressure
MPa
≤1.6MPa
≤1.6MPa
Motor
Type
-
FN11T
FN11T
Capacitor
µF
1
2.5
Connection pipe size
Water inlet &outlet
inch
G3/4"
G3/4"
Condensing water drain
mm
25
25
Outline dimension
(W×D×H)
Body
mm
600×600×230
600×600×230
Panel
mm
650×650×50
650×650×50
Package dimension
(W×D×H)
Body
mm
848×678×310
848×678×310
Panel
mm
730×670×102
730×670×102
Net weight
Body
kg
19.3
19.3
Panel
kg
5
5
Gross weight
Body
kg
27
27
Panel
kg
6
6
Loading quantity
20'GP
114
114
40'GP
216
216
40'HQ
256
256
Wired remote controller
Z5K351
Z5K351
Wireless remote controller
YB1F2(X-FAN)
YB1F2(X-FAN)

PRODUCT
10
Notes:
(a) The water working temperature is from 7°C(44.6°F) to 60°C(140°F).
(b) The temperature exchange efficiency and enthalpy exchange efficiency are tested under these
testing conditions as below:
Cooling efficiency: air 27°C(80.6°F) DB, 19.5°C(67.1°F) WB, water temperature in
7°C(44.6°F),water out 12°C(53.6°F).
Heating capacity: air 21°C(69.8°F) DB, Water temperature intake 60°C(140°F), the water-flow
volume is same as Cooling capacity.
Model
FP-51XD/A-K
FP-68XD/A-K
Code
EM520N1170
EM520N1160
Power system
Type
V-Ph-Hz
220-240V~ 50Hz
220-240V~ 50Hz
Input
W
73
73
Air flow volume
High
CFM
300
400
m3/h
510
680
Medium
CFM
235
329
m3/h
400
560
Low
CFM
176
270
m3/h
300
460
Capacity
Cooling
W
2750
3600
Heating
W
3400
4200
Electric heater rated power
W
-
-
Water system
Cooling water flow volume
l/s
0.13
0.18
Heating water flow volume
l/s
0.16
0.20
Cooling pressure drop
kPa
15
28
Heating pressure drop
kPa
24
38
Sound pressure level
dB(A)
46
46
Coil
Type
-
Aluminum fin-copper tube
Aluminum fin-copper tube
Operating pressure
MPa
≤1.6MPa
≤1.6MPa
Motor
Type
-
FN30L
FN30L
Capacitor
µF
2
2
Connection pipe
size
Water inlet &outlet
inch
G3/4
G3/4
Condensing water drain
mm
25
25
Outline dimension
Body
mm
664x594x292
664x594x292

PRODUCT
11
(W×D×H)
Panel TC06
mm
670x670x60
670x670x60
Package
dimension
(W×D×H)
Body
mm
775x730x285
775x730x285
Panel TC06
mm
760x760x90
760x760x90
Net weight
Body
kg
20
20
Panel TC06
kg
3.5
3.5
Gross weight
Body
kg
24
24
Panel TB03
kg
5
5
20'GP (with panel TB03)
168
168
40'GP (with panel TB03)
376
376
40'HQ (with panel TB03)
423
423
Wired remote controller
Z4E351B
Z4E351B
Wireless remote controller
YB1FA(MOTO)
YB1FA(MOTO)
Notes:
Testing condition:
The FCU designed for installation indoor. The environmental temperature is from 5°C to 43°C, water
working temperature is from 7°C to 60°C.
The temperature exchange efficiency and enthalpy exchange efficiency are tested under these testing
conditions as below:
(a) Cooling capacity: air 27°C DB , 19°C WB, water temperature intake 7°C, outlet 12°C.
(b) Heating capacity: air 20°C DB , Water temperature intake 45°C, outlet 40°C.
(c) Freeze-up : air 27°C DB, 24°C WB , water temperature 6°C intake , 10°C outlet .
(d) Sound power level according to ISO 5151. Sound pressure level are calculated at the below of
air-outlet 1m and 1m distance. The noise are tested before leaving factory.

PRODUCT
12
Model
FP-85XD/B-T
FP-85XD/B-T
FP-102XD/B-T
FP-102XD/B-T
Code
EM520N0940
EM520N0930
EM520N0920
EM520N0910
Power
system
Type
V-Ph-Hz
208-230V~ 60Hz
220-240V~ 50Hz
208-230V~ 60Hz
220-240V~ 50Hz
Input
W
70
75
130
110
Air flow
volume
High
CFM
459
471
600
600
m3/h
780
800
1020
1020
Medium
CFM
371
382
599
599
m3/h
630
650
950
950
Low
CFM
324
324
529
529
m3/h
550
550
900
900
Capacity
Cooling
W
4600
4500
5400
5000
Heating
W
7800
5600
9000
6500
Electric heater rated power
W
-
-
-
-
Water
system
Cooling water flow
volume
l/s
0.22
0.21
0.26
0.24
Heating water flow
volume
l/s
0.22
0.13
0.26
0.17
Cooling pressure
drop
kPa
27
24
48
36
Heating pressure
drop
kPa
24
8
47
13
Sound pressure level
dB(A)
39
39
49
49
Coil
Type
-
Aluminum
fin-copper tube
Aluminum
fin-copper tube
Aluminum
fin-copper tube
Aluminum
fin-copper tube
Operating pressure
MPa
≤1.6MPa
≤1.6MPa
≤1.6MPa
≤1.6MPa
Motor
Type
-
FN35D-1
FN35D-1
FN35D-1
FN35D-1
Capacitor
µF
2.00
2.00
5.00
5.00
Connectio
n pipe size
Water inlet &outlet
inch
G3/4"
G3/4"
G3/4"
G3/4"
Condensing water
drain
mm
25
25
25
25
Outline
dimension
(W×D×H)
Body
mm
840×840×190
840×840×190
840×840×190
840×840×190
Panel T01
mm
950×950×60
950×950×60
950×950×60
950×950×60
Panel TB03
mm
950×950×85
950×950×85
950×950×85
950×950×85
Package
dimension
Body
mm
963×963×272
963×963×272
963×963×272
963×963×272
Panel T01
mm
1028×1043×130
1028×1043×130
1028×1043×130
1028×1043×130

PRODUCT
13
(W×D×H)
Panel TB03
mm
1033×1038×133
1033×1038×133
1033×1038×133
1033×1038×133
Net weight
Body
kg
25.0
25.0
25.0
25.0
Panel T01
kg
3.0
3.0
3.0
3.0
Panel TB03
kg
7
7
7
7
Gross
weight
Body
kg
33.0
33.0
33.0
33.0
Panel T01
kg
5.0
5.0
5.0
5.0
Panel TB03
kg
11
11
11
11
Loading
quantity
20'GP(with panel T01)
57
57
57
57
40'GP (with panel T01)
133
133
133
133
40'HQ (with panel T01)
149
149
149
149
20'GP (with panel TB03)
56
56
56
56
40'GP (with panel TB03)
131
131
131
131
40'HQ (with panel TB03)
147
147
147
147
Wired remote controller
Z4E351B
Z4E351B
Z4E351B
Z4E351B
Wireless remote controller
YB1FA(X-FAN)
YB1FA(X-FAN)
YB1FA(X-FAN)
YB1FA(X-FAN)
Model
FP-125XD/B-T
FP-125XD/B-T
FP-140XD/B-T
FP-140XD/B-T
Code
EM520N0900
EM520N0890
EM520N0880
EM520N0870
Power
system
Type
V-Ph-Hz
208-230V~ 60Hz
220-240V~ 50Hz
208-230V~ 60Hz
220-240V~ 50Hz
Input
W
130
82
140
120
Air flow
volume
High
CFM
665
694
794
824
m3/h
1130
1180
1350
1400
Medium
CFM
529
588
647
735
m3/h
900
1000
1100
1250
Low
CFM
441
529
588
676
m3/h
750
900
1000
1150
Capacity
Cooling
W
6300
6000
8000
8000
Heating
W
10000
7800
12000
9000
Electric heater rated power
W
-
-
-
-
Water
system
Cooling water flow
volume
l/s
0.3
0.29
0.38
0.38
Heating water flow
volume
l/s
0.3
0.18
0.38
0.21

PRODUCT
14
Cooling pressure
drop
kPa
27
24
33
30
Heating pressure
drop
kPa
28
9
29
10
Sound pressure level
dB(A)
43
43
48
50
Coil
Type
-
Aluminum
fin-copper tube
Aluminum
fin-copper tube
Aluminum
fin-copper tube
Aluminum
fin-copper tube
Operating pressure
MPa
≤1.6MPa
≤1.6MPa
≤1.6MPa
≤1.6MPa
Motor
Type
-
FN35B-1
FN35B-1
FN35C
FN35C
Capacitor
µF
2.00
2.00
4.00
4.00
Connection
pipe size
Water inlet &outlet
inch
G3/4"
G3/4"
G3/4"
G3/4"
Condensing water
drain
mm
25
25
25
25
Outline
dimension
(W×D×H)
Body
mm
840×840×240
840×840×240
840×840×240
840×840×240
Panel T01
mm
950×950×60
950×950×60
950×950×60
950×950×60
Panel TB03
mm
950×950×85
950×950×85
950×950×85
950×950×85
Package
dimension
(W×D×H)
Body
mm
963×963×325
963×963×325
963×963×325
963×963×325
Panel T01
mm
1028×1043×130
1028×1043×130
1028×1043×130
1028×1043×130
Panel TB03
mm
1033×1038×133
1033×1038×133
1033×1038×133
1033×1038×133
Net weight
Body
kg
27.0
27.0
27.0
27.0
Panel T01
kg
3.0
3.0
3.0
3.0
Panel TB03
kg
7
7
7
7
Gross
weight
Body
kg
34.0
34.0
35.0
35.0
Panel T01
kg
5.0
5.0
5.0
5.0
Panel TB03
kg
11
11
11
11
Loading
quantity
20'GP(with panel T01)
50
50
50
50
40'GP (with panel T01)
121
121
121
121
40'HQ (with panel T01)
134
134
134
134
20'GP (with panel TB03)
50
50
50
50
40'GP (with panel TB03)
117
117
117
117
40'HQ (with panel TB03)
133
133
133
133
Wired remote controller
Z4E351B
Z4E351B
Z4E351B
Z4E351B
Wireless remote controller
YB1FA(X-FAN)
YB1FA(X-FAN)
YB1FA(X-FAN)
YB1FA(X-FAN)

PRODUCT
15
Model
FP-160XD/B-T
FP-160XD/B-T
FP-180XD/B-T
FP-180XD/B-T
Code
EM520N0860
EM520N0850
EM520N0840
EM520N0830
Power
system
Type
V-Ph-Hz
208-230V~ 60Hz
220-240V~ 50Hz
208-230V~ 60Hz
220-240V~ 50Hz
Input
W
140
125
160
160
Air flow
volume
High
CFM
912
912
1059
1059
m3/h
1550
1550
1800
1800
Medium
CFM
765
824
824
853
m3/h
1300
1400
1400
1450
Low
CFM
676
765
765
794
m3/h
1150
1300
1300
1350
Capacity
Cooling
W
9000
8700
10000
9500
Heating
W
14000
10000
16000
11000
Electric heater rated power
W
-
-
-
-
Water
system
Cooling water flow
volume
l/s
0.43
0.42
0.48
0.45
Heating water flow
volume
l/s
0.43
0.23
0.48
0.27
Cooling pressure
drop
kPa
34
30
42
34
Heating pressure
drop
kPa
34
11
43
12
Sound pressure level
dB(A)
51
51
50
50
Coil
Type
-
Aluminum
fin-copper tube
Aluminum
fin-copper tube
Aluminum
fin-copper tube
Aluminum
fin-copper tube
Operating pressure
MPa
≤1.6MPa
≤1.6MPa
≤1.6MPa
≤1.6MPa
Motor
Type
-
FN35C
FN35C
FN50K-1
FN50K-1
Capacitor
µF
5.00
5.00
3.50
3.50
Connection
pipe size
Water inlet &outlet
inch
G3/4"
G3/4"
G3/4"
G3/4"
Condensing water
drain
mm
25
25
25
25
Outline
dimension
(W×D×H)
Body
mm
840×840×240
840×840×240
840×840×320
840×840×320
Panel T01
mm
950×950×60
950×950×60
950×950×60
950×950×60
Panel TB03
mm
950×950×85
950×950×85
950×950×85
950×950×85
Package
dimension
Body
mm
963×963×325
963×963×325
963×963×409
963×963×409
Panel T01
mm
1028×1043×130
1028×1043×130
1028×1043×130
1028×1043×130

PRODUCT
16
(W×D×H)
Panel TB03
mm
1033×1038×133
1033×1038×133
1033×1038×133
1033×1038×133
Net weight
Body
kg
27.0
27.0
32.0
32.0
Panel T01
kg
3.0
3.0
3.0
3.0
Panel TB03
kg
7
7
7
7
Gross
weight
Body
kg
35.0
35.0
41.0
41.0
Panel T01
kg
5.0
5.0
5.0
5.0
Panel TB03
kg
11
11
11
11
Loading
quantity
20'GP(with panel T01)
50
50
42
42
40'GP (with panel T01)
121
121
98
98
40'HQ (with panel T01)
134
134
112
112
20'GP (with panel TB03)
50
50
42
42
40'GP (with panel TB03)
117
117
98
98
40'HQ (with panel TB03)
133
133
112
112
Wired remote controller
Z4E351B
Z4E351B
Z4E351B
Z4E351B
Wireless remote controller
YB1FA(X-FAN)
YB1FA(X-FAN)
YB1FA(X-FAN)
YB1FA(X-FAN)
Model
FP-200XD/B-T
FP-200XD/B-T
Code
EM520N0820
EM520N0810
Power
system
Type
V-Ph-Hz
208-230V~ 60Hz
220-240V~ 50Hz
Input
W
230
210
Air flow
volume
High
CFM
1176
1176
m3/h
2000
2000
Medium
CFM
912
1000
m3/h
1550
1700
Low
CFM
735
853
m3/h
1250
1450
Capacity
Cooling
W
13000
13000
Heating
W
19000
14600
Electric heater rated power
W
-
-
Water
system
Cooling water flow volume
l/s
0.62
0.62
Heating water flow volume
l/s
0.62
0.25
Cooling pressure drop
kPa
35
34

PRODUCT
17
Heating pressure drop
kPa
35
30
Sound pressure level
dB(A)
55
55
Coil
Type
-
Aluminum fin-copper tube
Aluminum fin-copper tube
Operating pressure
MPa
≤1.6MPa
≤1.6MPa
Motor
Type
-
FN50K-2
FN50K-2
Capacitor
µF
5.00
5.00
Connection
pipe size
Water inlet &outlet
inch
G3/4"
G3/4"
Condensing water drain
mm
25
25
Outline
dimension
(W×D×H)
Body
mm
840×840×320
840×840×320
Panel T01
mm
950×950×60
950×950×60
Panel TB03
mm
950×950×85
950×950×85
Package
dimension
(W×D×H)
Body
mm
963×963×409
963×963×409
Panel T01
mm
1028×1043×130
1028×1043×130
Panel TB03
mm
1033×1038×133
1033×1038×133
Net weight
Body
kg
33.0
33.0
Panel T01
kg
3.0
3.0
Panel TB03
kg
7
7
Gross
weight
Body
kg
42.0
42.0
Panel T01
kg
5.0
5.0
Panel TB03
kg
11
11
Loading
quantity
20'GP(with panel T01)
42
42
40'GP (with panel T01)
98
98
40'HQ (with panel T01)
112
112
20'GP (with panel TB03)
42
42
40'GP (with panel TB03)
98
98
40'HQ (with panel TB03)
112
112
Wired remote controller
Z4E351B
Z4E351B
Wireless remote controller
YB1FA(X-FAN)
YB1FA(X-FAN)

PRODUCT
18
Model
FP-200XD/D-K
Code
EM520N1210
Power system
Type
V-Ph-Hz
220-240V~ 50Hz
Input
W
140
Air flow volume
High
CFM
1177
m3/h
2000
Medium
CFM
1000
m3/h
1700
Low
CFM
853
m3/h
1450
Capacity
Cooling
W
12000
Heating
W
14200
Electric heater rated power
W
-
Water system
Cooling water flow volume
l/s
0.62
Heating water flow volume
l/s
0.4
Cooling pressure drop
kPa
34
Heating pressure drop
kPa
30
Sound pressure level
dB(A)
55
Coil
Type
-
Aluminum fin-copper tube
Operating pressure
MPa
≤1.6MPa
Motor
Type
-
FN60C-ZL
Capacitor
µF
/
Connection pipe size
Water inlet &outlet
inch
G3/4"
Condensing water drain
mm
25
Outline dimension (W×D×H)
Body
mm
840×840×320
Panel T01
mm
950×950×60
Panel TB03
mm
950×950×85
Package dimension
(W×D×H)
Body
mm
963×963×409
Panel T01
mm
1028×1043×130
Panel TB03
mm
1033×1038×133
Net weight
Body
kg
32.0
Panel TB03
kg
7
Gross weight
Body
kg
41.0
Panel TB03
kg
11
20'GP (with panel TB03)
42
40'GP (with panel TB03)
98
40'HQ (with panel TB03)
112
Wired remote controller
Z4E351B
Wireless remote controller
YB1FA(MOTO)
