Gree Vireo Gen 3 3VIR09HP115V1AH User manual

TWD-1594 Livo+ owners printer. xp_Layout 1 2/21/17 2:10 PM Page 1
Models:
3VIR09HP115V1AH
3VIR12HP115V1AH
3VIR09HP230V1AH
3VIR12HP230V1AH
3VIR18HP230V1AH
3VIR24HP230V1AH
HIGH-WALL DUCTLESS
AIR CONDITIONING & HEATING SYSTE
OWNER’S ANUAL

CONTENTS
Safety precautions ..................................................................................
01-04
..................................................................................................
05
.........................................
06-11
...............................................................................
12
.............................................................
13
....................................................................................
14-15
...........................................................................
16-18
.......................................................................................
19
..................................................................
20
Parts name
Operation and introduction of remote controller
Clean and maintenance
Checked items before maintenance
Installation notice
Installation of indoor unit
Test and operation
Configuration of connection pipe
.......................................................................................
22
...................................................................................................
Back
Energy Saving Tips
Warranty
Explanation of Symbols and Statements.....................................................
II-V
I

Explanation of Symbols
WARNING
CAUTION
NOTICE
1. Damage the product due to improper use or misuse of the product;
2. Altering, changing, maintaining or using the product with other equipment
without following the recommendations in manufacturer's instruction manual;
3. After verification, the product defect is directly caused by corrosive gas;
4. After verification, the defects are due to improper operation or handling during
the transportation of product;
5. Operating, repairing or maintaining the unit without following the instruction
manual or related regulations.
6. After verification, the problem or dispute is caused by the quality or
performance of parts and components produced by other manufacturers;
7. The damage is caused by natural disasters, a hazardous environment or
force majeure.
Exception Clauses
Manufacturer will bear no responsibilities when personal injury or property loss is
caused by the following reasons.
This symbol indicates the possibility of death or serious injury.
This symbol indicates the possibility of injury or damage to
property.
Indicates important but not hazard-related
information, used
to indicate risk of property damage.
If you need to install, move or maintain this air conditioner, please use a licensed
HVAC dealer to avoid serious damage or personal injury or death.
When refrigerant leaks or requires discharging during installation, maintenance,
or disassembly, it should be handled by certified professionals in compliance
with local laws and regulations.
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities or lack of experience and
knowledge unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
II

Fcc Warning
Fcc Statement
Ic Statement
WARNING: Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment.
This device complies with Part 15 of the FCC Rules.Operation is subject to the
following two conditions :
●
●
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
●Connect the equipment into an outlet on a circuit different from that to which the
●Consult the dealer or an experienced radio/TV technician for help.
receiver is connected.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,may cause harmful
interference to radio communications.
(1) this device may not cause harmful interference, and (2) this device must accept
any interference received,including interference that may cause undesired operation.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
This device complies with Industry Canada license exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference
that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de
l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
III

Ic Statement
This equipment complies with FCC’s and IC’s RF radiation exposure limits set forth
for an uncontrolled environment. The antenna(s) used for this transmitter must be
installed and operated to provide a separation distance of at least 20 cm from all
persons and must not be collocated or operating in conjunction with any
other
antenna or transmitter. Installers must ensure that
20cm separation distance will
be maintained between the device (excluding its handset) and users.
Cet appareil est conforme aux limites d’exposition au rayonnement RF stipulées
par la FCC et l’IC pour une utilisation dans un environnement non contrôlé. Les
antennes utilisées pour cet émetteur doivent être installées et doivent fonctionner
à au moins 20 cm de
distance des utilisateurs et ne doivent pas être placées près
d’autres antennes ou émetteurs ou fonctionner avec ceux-ci. Les installateurs
doivent s’assurer qu’une
distance de 20 cm sépare l’appareil (à l’exception du
combiné) des utilisateurs.
V

Safety precautions
Installation
1
WARNING
Installationor maintenance
must be performed by qua-
lified professionals.
The appliance shall be in-
stalled in accordance with
local and national wiring
codes.
All wiring, circuit breakers
and disconnects must be
to code.
All wiring of indoor and
outdoorunitsshould be
connected bylicensed
professionals.
Disconnect the power
supply before proceeding
with any work related to
electricity and safety.
All power and control wiring
must conform to the air
conditioner's specification
and local codes. Unstable
power supply or incorrect
wiring may result in
electrical shock ,fire
hazardor unit
malfunction.
Grounding of units must
comply with the National
Electrical Code and local
codes.
Air Conditioner should be
properly grounded. Inco-
rrect grounding may cause
electrical shock.
Do not connect power
before finishinginstalla-
tion.
To prevent malfunctions,
install aproperly sized
circuit breaker.
An all-pole disconnect
switch having a contact
separation of at least 3mm
in all poles shouldbe
installed in fixed wiring.
Circuit breaker must be
properly sized to the unit
specifications and code to
prevent an electrical over-
load or short-circuit.

Safety precautions
Installation
2
CAUTION
Instructions for installation
and use of this product are
provided by the manufac-
turer.
Select a location which is
out of reach for children
and far away from animals
or plants. If unavoidable,
please install a fence for
safety.
The indoor unit should be
installed close to an
outside wall.
Wire to code (see
submittals).
Power and control wiring
from the outdoor unit to
the indoor unit must be
continuous.
Acircuit breaker must be
installed in the line.
Theyellow-green wire is
the ground wire it cannot
be used for any other
purpose.
This air conditioner is a
first class electric applian-
ce. It must be properly gro-
undedto code. Improper
grounding could cause an
electrical shock.
Therefrigerant circuit
temperature will be hot,
keep theinterconnecting
wire away fromall copper
tubing.

Safety precautions
Operation
and Maintenance
3
WARNING
This appliance can be used
by children aged from 8
years and above and per-
sons with reduced physi-
cal, sensory or mental ca-
pabilities or lack of expe-
rience and knowledge if
they have been given su-
pervision or instruction con-
cerning use of the applian-
ce in a safe way and un-
derstand the hazards in-
volved.
Children shall not play with
the appliance.
Cleaning and user main-
tenance shall not be made
by children without super-
vision.
If the supply wiring is
damaged, it must be
replaced by a licensed
HVAC technician or other
licensed electrical
professional.
Connect air conditioner
to a dedicated circuit
breaker.
Disconnect power supply
when cleaning air condit-
ioner, to avoid an
electrical shock.
To avoid electrical shock,
donot wash the
equipment with water.
To avoid electrical shock
or unit malfunction do not
spray water on indoor unit.
Do not repair air condition-
er by yourself. Doing so
maycause electrical shock
or damage. Contact a
licensed HVAC
contractor.
To avoid injury, do not
touch fins when removing
the filter.
Do not extend fingers or
objects into air inlet or air
outlet. It may cause
personal injury or damage.

Safety precautions
Operation
and Maintenance
4
CAUTION
To avoid damaging the
remote controller, donot
spill water on it.
To avoid damage when
drying the air filter, do not
use a flame or hair dryer.
Do not block air outlet or
air inlet. It may cause the
unit to malfunction.
Do not step on or put heavy
objects on top panel of
outdoor unit . It may
damage the unit or cause
personal injury.
If any of the following
occur, turnoff the air
conditioner and disconnect
power immediatelyand
contact the dealer or a
qualifiedprofessional for
service.
Wiring is overheating or
damaged.
Abnormal sounds
during operation.
Circuit breaker trips off
frequently.
A burning smell coming
from the air conditioner.
Indoor unit is leaking.

Parts name
Indoor Unit
air outlet
■ If remote controller is lost or damaged, please use aux. button to turn on or turn off the air
conditioner. The operation in details is as below: As shown in the figure, open panel and
press aux.button to turn off the air conditioner. When the air conditioner is turned on, it will
operate under auto mode.
Display
Temp. indicator
Power indicator
This is the general introduction and the color of indicator is only for reference. Please refer to the actual
display.
Display content may be different from the actual. Please refer to the actual display.
5
air inlet
filter
panel
NOTE
●
●
upper air guide louver
lower air guide louver
aux. button
panel
