Green Energy 10KVA User manual

Three-Phase UPS
(10kVA-160kVA) Series
User Manual

i
Foreword
Summaries
Thank you for choosing the Three-Phase (10kVA-160kVA) series UPS!
This document gives a description of the Three-Phase (10kVA-160kVA) series UPS, including the
features, performance, appearance, structure, working principles, installation, operation and
maintenance.etc.
Please save the manual after reading, in order to consult in the future.
The figures in this manual are just for reference, for details please see the actual product.
Symbol Conventions
The manual quotes the safety symbols, these symbols used to prompt users to comply with safety
matters during installation, operation and maintenance. Safety symbol meaning as follows.
Symbol
Description
Alerts you to a high risk hazard that could, if not avoided, result in
serious injury or death.
Alerts you to a medium or low risk hazard that could, if not
avoided, result in moderate or minor injury.
Alerts you to a potentially hazardous situation that could, if not
avoided, result in equipment damage, data loss, performance
deterioration, or unanticipated results.
Anti-static prompting.
Be care electric shock prompting.
Provides a tip that may help you solve a problem or save time.

Foreword
Three-Phase UPS (10kVA-160kVA) Series
User Manual
ii
Provides additional information to emphasize or supplement
important points in the main text.
Product standard: Q/ZZKJ 001
Change History
Changes between document issues are cumulative. The latest document issue contains all the changes
made in earlier issues.
Issue 001 (2018-12-07)
First issue.

Three-Phase UPS (10kVA-160kVA) Series
User Manual
Contents
iii
Contents
1 Safety Instructions ........................................................................................................................1
1.1 Safety Announcements.....................................................................................................................................1
1.1.1 Safety Instructions ..................................................................................................................................1
1.1.2 Use Announcements for Battery .............................................................................................................4
1.1.3 Anti-Static Protection..............................................................................................................................4
1.1.4 Grounding Requirements........................................................................................................................5
1.1.5 Safety Warning Label Setting .................................................................................................................5
1.1.6 Measure with Electricity.........................................................................................................................5
1.2 Operation and Maintenance Requirements ......................................................................................................6
1.3 Environment Requirements..............................................................................................................................7
2 Overview.........................................................................................................................................8
2.1 Product Intro.....................................................................................................................................................8
2.1.1 Features...................................................................................................................................................8
2.2 Operating Principle ........................................................................................................................................10
2.2.1 Single-unit.............................................................................................................................................10
2.2.2 Series Hot-standby................................................................................................................................10
2.2.3 Parallel System...................................................................................................................................... 11
2.3 Work Mode..................................................................................................................................................... 11
2.4 Configuration .................................................................................................................................................12
2.5 Appearance and Structure...............................................................................................................................13
2.5.1 Operation Panel.....................................................................................................................................15
2.5.2 Layout (Open Door)..............................................................................................................................16
2.6 Communication Way......................................................................................................................................20
2.6.1 RS485 Communicaiton.........................................................................................................................20

Contents
Three-Phase UPS (10kVA-160kVA) Series
User Manual
iv
2.6.2 Dry Contact Communicaiton(Optional for Single Input Model) ..........................................................22
2.6.3 SNMP Card (Optional) .........................................................................................................................25
2.6.4 RS232 Communicaiton (Optional) .......................................................................................................27
2.7 Other Optional Accessories............................................................................................................................27
2.7.1 Feedback Protection Device..................................................................................................................27
2.7.2 Wiring Cabinet......................................................................................................................................28
2.7.3 Energy Feedback Absorbing Cabinet....................................................................................................28
2.7.4 Battery Cabinet/ Rack...........................................................................................................................29
2.7.5 Battery Switch Box...............................................................................................................................29
2.7.6 Top Waterproof Cover...........................................................................................................................29
3 Installation....................................................................................................................................31
3.1 Installation Annuncements .............................................................................................................................31
3.2 Installation Process.........................................................................................................................................32
3.3 Installation Preparation ..................................................................................................................................32
3.3.1 Tools......................................................................................................................................................32
3.3.2 Installation Environment.......................................................................................................................34
3.3.3 Installation Clearance............................................................................................................................34
3.3.4 Selection of Input and Output Cables ...................................................................................................35
3.3.5 Surge Protection Device........................................................................................................................39
3.4 Transportation and Unpacking .......................................................................................................................39
3.4.1 Transportation.......................................................................................................................................39
3.4.2 Unpacking.............................................................................................................................................40
3.5 Install UPS .....................................................................................................................................................43
3.5.1 Single-unit.............................................................................................................................................43
3.5.2 Rack Installation ...................................................................................................................................49
3.6 Electrical Connection.....................................................................................................................................49
3.6.1 Single-unit.............................................................................................................................................49
3.6.2 Series System........................................................................................................................................55
3.6.3 Parallel System......................................................................................................................................57
4 Touch Screen Operation ............................................................................................................63

Three-Phase UPS (10kVA-160kVA) Series
User Manual
Contents
v
4.1 Menu Hierarchy .............................................................................................................................................63
4.2 System Monitor Page .....................................................................................................................................64
4.2.1 Icon Meaning ........................................................................................................................................64
4.2.2 Working Status......................................................................................................................................65
4.2.3 Bypass Information...............................................................................................................................67
4.2.4 Mains Information Page........................................................................................................................67
4.2.5 Battery Information...............................................................................................................................68
4.2.6 Output information................................................................................................................................69
4.2.7 Warning Information.............................................................................................................................69
4.3 Information Management...............................................................................................................................70
4.3.1 Working Status......................................................................................................................................70
4.3.2 Event Log..............................................................................................................................................71
4.3.3 User Log ...............................................................................................................................................71
4.3.4 Device Information ...............................................................................................................................71
4.4 Setting Management.......................................................................................................................................73
4.4.1 System Manage.....................................................................................................................................74
4.4.2 Battery Manage.....................................................................................................................................75
4.4.3 Log Manage ..........................................................................................................................................77
4.4.4 Screen Set .............................................................................................................................................78
4.4.5 Password Set.........................................................................................................................................78
4.4.6 Communication Set...............................................................................................................................79
5 Operation Guide .........................................................................................................................80
5.1 Checking Before Startup ................................................................................................................................80
5.1.1 Check Electrical Connection.................................................................................................................80
5.1.2 UPS Test................................................................................................................................................81
5.2 UPS Announcements......................................................................................................................................81
5.2.1 Start UPS...............................................................................................................................................81
5.2.2 Start Load..............................................................................................................................................82
5.2.3 Close UPS.............................................................................................................................................82
5.3 Manual Maintenance Opeartion.....................................................................................................................83

Contents
Three-Phase UPS (10kVA-160kVA) Series
User Manual
vi
5.3.1 Transfer From UPS Status to Maintenance Bypass Status....................................................................84
5.3.2 Transfer From Maintenance Bypass Status to UPS Status....................................................................84
5.4 Parallel System Operation..............................................................................................................................85
5.4.1 Start Parallel System.............................................................................................................................85
5.4.2 Close Parallel System............................................................................................................................86
5.4.3 Remove Faulty UPS from Parallel System ...........................................................................................87
5.4.4 Add New UPS into Parallel System......................................................................................................87
5.5 Series System Operation ................................................................................................................................88
5.5.1 Start Series System ...............................................................................................................................88
5.5.2 Close Series System..............................................................................................................................88
6 Routine Maintenance .................................................................................................................89
6.1 UPS Status Checking .....................................................................................................................................89
6.1.1 Safety Precautions.................................................................................................................................89
6.1.2 Preventive Maintenance........................................................................................................................89
6.2 Battery Maintenance ......................................................................................................................................90
6.2.1 Battery Maintenance Announcements...................................................................................................90
6.2.2 Battery Maintenance Method................................................................................................................90
6.2.3 Battery Replacement Announcements ..................................................................................................90
6.3 Fan Maintenance............................................................................................................................................91
7 Troubleshooting..........................................................................................................................92
7.1 Identify UPS Status........................................................................................................................................92
7.2 Deal with Emergency Fault............................................................................................................................94
8 Package, Transportation, Storage.............................................................................................95
8.1 Package ..........................................................................................................................................................95
8.2 Transportation ................................................................................................................................................95
8.3 Storage ...........................................................................................................................................................95
A Technical Specifications ...........................................................................................................96
B Acronyms and Abbreviations ..................................................................................................99

Three-Phase UPS (10kVA-160kVA) Series
User Manual
1 Safety Instructions
1
1 Safety Instructions
This chapter introduces the safety announcements. Please read this user manual carefully prior to
installing the device. It provides important information on safe and efficient installation.
1.1 Safety Announcements
This section introduces the safety announcements that must be complied with and pay special
attention while installing, using, maintenance and other relative operations.
Before operating, please read the announcements and operation instructions in this section carefully
to avoid accident.
The DANGER, WARNING, CAUTION instructions in the manual are not all the safety
announcements that you must abide by, there are just the supplements for the safety announcements
during operating.
Our Company does not undertake the responsibility caused by violating common safety operation
requirements or the safety standard of design, manufacture and use.
1.1.1 Safety Instructions
The input and output of the UPS is dangerous high voltage, once operate improperly, it may endanger
human safety. Please read this manual carefully before installing or operating, and pay attention to
the warning labels. Do not dismantle the cover plate of the UPS unless authorized person.

1 Safety Instructions
Three-Phase UPS (10kVA-160kVA) Series
User Manual
2
It is prohibited to touching any terminal or conductor that connected with grid circuit, or, it may
cause deadly danger.
The damaged device or device fault may cause electric shock or firing!
Before operating, please inspect the device and see if there is any damage or exist other danger.
Check if the external devices or circuit connection is safe.
During a lightning storm, it is strictly prohibited to perform high voltage and AC operation, as well as
in the tower or the mast. The atmosphere will generate a strong electromagnetic field in a lightning
storm. Therefore, in order to avoid equipment struck by lightning, lightning protection and grounding
system should be prepared in time.
If the output load is impact feedback device, please consult the engineer of our company.
Do not reversely connect the grounding wire and neutral wire, live wire and neutral wire to avoid
short circuit.
It should be well grounded and the voltage between grounding wire and neutral wire should be less
than 5V.

Three-Phase UPS (10kVA-160kVA) Series
User Manual
1 Safety Instructions
3
Please do not put finger or tool into rotating fans to avoid endangering the human safety or damaging
the device.
In case of fire, please use dry power fire extinguisher. If using liquid fire extinguisher, it may cause
electric shock.
No liquid or other objects are allowed to enter the UPS.
The UPS is class C3 device. If used in resident living, it may cause wireless interference. User should
take actions to avoid the interference.
Warning label should be affixed away from UPS location!
When UPS is power off, there still exists dangerous voltage. It should affix warning labels away from
UPS location and the warning labels should include: 1. It supplies power for UPS. 2. Please
disconnect UPS before wiring.

1 Safety Instructions
Three-Phase UPS (10kVA-160kVA) Series
User Manual
4
1.1.2 Use Announcements for Battery
Please use specified battery. Non-specified battery will damage the UPS.
The charging voltage of different brands and different model' battery is different. Before using,
ensure that the charging voltage of the UPS matches that of battery. If doubted, please consult the
manufacturer for support.
Battery operation must be done according to instructions, especially battery wiring. Irregular
operation will cause battery damage, even human injury.
It is prohibited to short circuit the anode and cathode of the battery. The battery wiring must be
tightened. It is strictly prohibited to touch any two wiring terminals of battery or the bare
terminals of wires simultaneously, or it may cause battery damage or human injury.
Prevent electrolyte leaking from batteries. The metal objects and circuit board will be corroded
by the overflowing electrolyte and it will result in equipment damage and circuit board short
circuit.
Keep the battery away from fire source and all device that easy cause spark to avoid danger or
unnecessary lose.
1.1.3 Anti-Static Protection
The static generated by human bodies may damage the electrostatic-sensitive components on PCB.
Before touching the sensitive component, please wear anti-static rings and well connect the other end
of the anti-static rings to ground.

Three-Phase UPS (10kVA-160kVA) Series
User Manual
1 Safety Instructions
5
1.1.4 Grounding Requirements
High leakage risk! The device must be grounded before electrical connection. The grounding
terminal must be connected to earth.
When installing, connect the grounding wire first; when dismantling, the grounding wire must be
removed at last.
It is prohibited to damage the grounding conductor.
The UPS must be connected with protection earthing permanently. Before operating, please
check the electric connection and ensure the device has been connected to earth reliably.
1.1.5 Safety Warning Label Setting
To avoid irrelevant person close to or misoperate the UPS, during installation or daily maintenance,
please comply with the related standards.
Set warning labels at the switches of input end and output end to avoid wrongly switch on and
even cause accident.
Set warning label or safety warning area to avoid irrelevant person entering and cause human
injury or device damage.
After maintenance, ensure that pull out the key of the UPS and save it properly.
1.1.6 Measure with Electricity
There is dangerous high voltage, contacting by accident may lead to deadly danger. So, when
measure with electricity, it is necessary to do the protection (such as wear insulated gloves, etc.)
The measure meter must accord with the following requirements.
The range and use condition of the measure meter should conform to the site requirements.
Ensure that connection of the measure meter is proper and normative, which is to avoid the
danger of electric arc, etc.

1 Safety Instructions
Three-Phase UPS (10kVA-160kVA) Series
User Manual
6
1.2 Operation and Maintenance Requirements
There exists high temperature and high voltage inside the UPS. Please comply with the relevant
safety regulations and operation procedures during installation, operation and maintenance to avoid
human injury or device damage. The safety precautions mentioned in the user manual are just as a
supplement to the local safety regulations.
The related operation and wiring for the UPS should be performed by qualified professionals, and
ensure the electric installation accord with the electricity installation standards.
The installation and maintenance man should be trained and know about each safety announcements
and get the right operation method, and then, the installation, operation and maintenance can be done.
Mounting and dismantling power cables is prohibited when power on. Please switch off the power
switches before mounting or dismantling power cables. Before connecting, make sure the cable
connection, cable labels are in accordance with the actual installation.
Touching high voltage directly or through damp objects will lead to lethal risk.
Only authorized professionals are allowed to open the UPS! The input and output of the UPS are
dangerous high voltage. Touching high voltage will lead to lethal risk.
Before maintenance, please disconnect theAC power and battery to isolate the power input. It is
better to measure the input, output and battery terminals by a voltmeter to ensure the input power
is disconnected and in a safe condition.
Even if all external power are disconnected, there still exists residual electric charge on the
capacitance inside the UPS, and the output terminals may exists high voltage which may
endanger human life. It is necessary to set the UPS aside for enough time (≥10 min) to release all
charge before opening the UPS chassis.

Three-Phase UPS (10kVA-160kVA) Series
User Manual
1 Safety Instructions
7
The battery cables are not isolated withAC input. There may exist dangerous voltage between
battery terminal and grounding terminal. Pay attention to the insulation when installing and using
the battery.
Do not wear conductive objects, such as watches, bracelets and rings during operating.
The installing man should have the qualification of high voltage andAC power operation. The
maintenance and repair for the power system only can be done by professional persons.
Leakage risk! Before performing electrical connection, the UPS should be grounded. The
grounding terminal must be connected to the ground.
Drilling holes on the cabinet is prohibited! Inappropriate drilling will damage the components inside
the UPS. Metal debris generated by drilling will lead to circuit board short circuit.
Changing the UPS configuration, structure or assembly will affect the performance of the UPS. If user
needs to do like this, please consult the manufacturer in advance.
1.3 Environment Requirements
The used environment may influence the service life and reliability of the device. So, please avoid
using the device in the following environment for long time.
The place where beyond the specification (normal work temperature: -5℃～40℃, relative
humidity: 0%-95%).
The place where has direct sunshine and rain.
The place where has vibration or easy impacted.
The place where has dust, corrosive material, salty or flammable gas.
The place where without good ventilation or closed.

2 Overview
Three-Phase UPS (10kVA-160kVA) Series
User Manual
8
2 Overview
This chapter introduces the UPS’ model meaning, product features, configuration, appearance and
structure, work principle, etc.
2.1 Product Intro
Three-Phase (10kVA-160kVA) series UPS product is the high performance sine-wave online UPS
which is special for the network computer room and small smart device (such as measure device,
industrial automation device, etc.), precise instrument, etc. of financial, communication, insurance,
railway, medical treatment, enterprise, etc. it is special for the wicked grid environment.
2.1.1 Features
Real double conversion online UPS
Adopts high-efficient IGBT power component, which thoroughly solves the electric system problems,
such as impulse and interference of power grid, and ensure the load works normally.
Precise mains synchronization system
The output and power grid realizes the accurate zero-phase synchronization, which meets the high
requirement for the synchronization of power supply and power grid and enhances the performance
and reliability of bypass switch.
Digitalized DSP control technique and none-principle-subordinate and self-adaptive parallel
technique
The DSP controls the UPS's inverting, phase synchronization, input rectification, logics with high
precision, high speed and perfect whole system performance. The digitalized
none-principle-subordinate and self-adaptive parallel technique make the multi-parallel and the
reliable redundancy come true and ensure the high requirement of the device for power supply.

Three-Phase UPS (10kVA-160kVA) Series
User Manual
2 Overview
9
Full function Chinese/English touch screen
Adopts hommization touch screen display module to show the operating status and parameters. And
also, it can record historical data for easy engineering maintenance. The touch screen supports
Chinese/English display flexibly.
Allow 100% three-phase unbalanced load
The three-phase output is allowed with the 100% unbalanced load.
Flexible network monitoring
This series products not only realize intellectual monitoring between UPS and PC by SNMP, but also
equip with independent remote monitor to manage the power source conveniently. The monitor can
be one-to-one monitor or one-to-multi monitor.
Designed with manual bypass maintenance
This series UPS are designed with bypass maintenance channel to ensure supply power for load when
maintenance.
Reliable EMC performance
The UPS pass the authority institution and professional test on EMC, including conducting
disturbance, radioactive disturbance, conducting anti-disturbance, radioactive anti-disturbance, power
falling, mass impulse, static discharging, surge, etc. The EMC characteristics are excellent and it can
be applied to high frequency communication, broadcasting audio and video system.
Wide voltage input range
The UPS can adapt to different voltage ranges, which make the UPS have a strong adaptability for
grid.
Smart battery charging and testing
The UPS uses professional battery management technologies to control battery charging, discharging
and test the battery performance automatically, which improves battery reliability and extends the
battery lifespan.

2 Overview
Three-Phase UPS (10kVA-160kVA) Series
User Manual
10
Redundancy design for key circuit
The working power of the UPS adopts standby redundancy design, which effectively enhances the
reliability of the system.
Smart fan control
The fan adjusts rotating speed automatically in accordance with the load status to prolong fan life and
reduce noise. It can also alarm when fans fault.
2.2 Operating Principle
2.2.1 Single-unit
This series UPS are made up of input switch, filter, rectifier, inverter, static switch, bypass switch,
output transformer and batteries, etc. when the AC input is normal, the AC power will be converted
into DC power by rectifier to supply power for inverter, and charge the batteries with enough power
to supply pour power for load without transfer time when mains disconnects.
The basic structure is as shown in Figure2-1.
Bypass switch
Mains switch
Rectifier
AC/DC
Inverter
DC/AC
Transfo
rmer
Maintenance switch
Batteries
AC
SOURCE
TO LOAD
Output switch
AC
SOURCE
Filter
Battery
switch
Figure2-1 Operating principle of single-unit
2.2.2 Series Hot-standby
Connect the bypass input of UPS2 to the output of UPS1 instead of mains, it constitutes series
hot-standby working mode.
When UPS2 fault, it will turn to bypass mode automatically. At this time, the UPS1 supply power for
load, the load stay on UPS1 inverting protection status to ensure safety work. If the UPS2 stay on
bypass mode, and the UPS1 fault at the same time, the mains will supply for load directly.

Three-Phase UPS (10kVA-160kVA) Series
User Manual
2 Overview
11
Mains
input
UPS2UPS1
Load
Bypass
switch
Rectifier Inverter
Battery
Bypass
switch
Rectifier Inverter
Battery
Bypass
input
Figure2-2 Operating principle of series hot-standby system
2.2.3 Parallel System
The parallel equalized current of AC power works by quickly adjusting the AC output waveform,
amplitude and phase of parallel single-units and in accordance with each other strictly. Any difference
of amplitude or phase of voltage may generate large loop current, even overload or inverter damage.
The parallel system has strong anti-interference, which is to ensure reliable running of system.
Mains input
UPS2
UPS1
Load
Bypass
switch
Rectifier Inverter
Battery
Bypass
switch
Rectifier Inverter
Battery
Figure2-3 Operating principle of parallel system
2.3 Work Mode
The UPS has 4 working modes: mains mode, battery mode, bypass mode and maintenance bypass
mode.

2 Overview
Three-Phase UPS (10kVA-160kVA) Series
User Manual
12
Mains mode
When mains normal, the rectifier will convert the AC power into DC power to charge battery and
supply power for inverter to provide pure AC for load.
Battery mode
When mains abnormal or rectifier stops working, the batteries connected with DC.BUS will supply
power for inverter and the AC output will not interrupt.
Bypass mode
When the inverter abnormal (such as over-temperature, short circuit, output voltage abnormal or
overload and exceed the range that the inverter can withstand), the inverter will shut down
automatically to avoid damage. If the mains still normal at this moment, bypass power will instead of
mains power to supply power for load by static switch.
Maintenance bypass mode
When the UPS needs to be maintained or the battery needs to be replaced and at the same time, the
power supply for load cannot be interrupted, shut down the UPS firstly, then switch on the
maintenance bypass switch and then switch off the switches of mains, bypass, output and external
battery cabinet. During switching to maintenance bypass manually, AC power supplies power for
load through maintenance bypass switch. Meanwhile, there is no electricity inside UPS (except N),
and maintainer can carry out the maintenance safely.
2.4 Configuration
Model
Nominal rated power
Rated DC voltage
10KVA
10kVA/9kW
348VDC
15KVA
15kVA/13.5kW
348VDC
20KVA
20kVA/18kW
348VDC
0KVA
30kVA/27kW
348VDC
40KVA
40kVA/36kW
348VDC
50KVA
50kVA/45kW
348VDC
60KVA
60kVA/54kW
348VDC
