Green Power GPG4000 User manual

Green-Power America LLC Powers Your World
Green-Power America,LLC
Owner’s Manual of Generator for
GPG4000
GPG4000W
GPG4000EW

Products Service
Green-Power America LLC thanks you for choosing a Green-Power America product.
egister your product within 10 days of purchase to ensure that you receive
service.
egistering your product
1. You have a record of the product purchase,
2. Customer Service can Be serve you on Warranty related issues,
3.
You can register your product in one ways as follow
1: o to the website at www.greenpoweramerica.com/
service and
2: box,
Please note
that postage is required to mail the registraon form back to Green Power America
If you sll have any ques ons regarding the or operaon of your generator er you
have carefully read the manual, or if you have any quality issues during oper please
call our toll-free service number shown below:
For any issues related to LCT Engine, the parts include recoil starter, air filter,spark plug,
and all the other parts fixed to the engine, please go to www.lctusa.com (LCT website) or
call toll free:
800-558-5402
For any issues related to the remaining parts except for the LCT Engine, including
alternator, muffler, AVR, wheel kit, fuel tank, parts on the control panel, please call toll
free:
888-834-4218
1

GREEN-POWER AMERICA，LLC（HEREINAFTER
IN SHORT “GREEN-POWER” OR “GPA” ）
4000W Generator
Topi c Page
3ytnarraWdetimiL
5senilediuGytefaS
6snoituacerPlareneG
Battery 15
Assembly and Installation 16
Inspection，Cleaning,Maintenance and Storage 24
Operation 19
Specifications 30
13gnitsiLstraPlareneG
2

Green-Power
Green-Power Green-Power
Green-Power
please call specified toll free number.
Service
purchaser should contact Green-Power

Green-Power
Green-Pow
4 000W Generator

5
Owner’s Manual
Safety Guidelines - Definitions
This manual contains important information that you need to know and
understand in order to protect YOUR SAFETY and to PREVENT
EQUIPMENTPROBLEMS.Thefollowingsymbolshelpyourecognizethis
information. Please read the manual and pay attention to these sections.
Save These Important Safety Instructions!
Readandunderstandallofthesesafetyinstructions.Be
sure to retain them for future use.
WARNING! WARNINGS INDICATE A CERTAINTY OR STRONG
POSSIBILITYOFPERSONALINJURYORDEATHIF
INSTRUCTIONS ARE NOT FOLLOWED.
CAUTION: CAUTIONS INDICATE A POSSIBILITY OF
EQUIPMENT DAMAGE IF INSTRUCTIONS ARE NOT
FOLLOWED.
NOTE: NOTES GIVE HELPFUL INFORMATION
WARNING! IMPROPER OPERATION OR MAINTENANCE
OFTHISPRODUCTCOULDRESULTINSERIOUSINJURY
AND PROPERTY DAMAGE. READ AND UNDERSTAND ALL
WARNINGS AND OPERATING INSTRUCTIONS BEFORE USING
THIS EQUIPMENT. WHEN USING AIR TOOLS, BASIC SAFETY
PRECAUTIONS SHOULD ALWAYS BE FOLLOWED TO REDUCE
THERISKOFPERSONALINJURY.

6
WARNING! THE EXHAUST CONTAINS POISONOUS CARBON MONOXIDE
GAS THAT CAN CAUSE LOSS OF CONSCIOUSNESS AND MAY LEAD TO
DEATH.
Gasoline and Oil
This product requires oil and fuel. Attempting to start the engine without oil will ruin
the engine and void the warranty. Work in well ventilated area. Keep cigarettes,
flames or sparks away from the work area or where gasoline is stored.
WARNING! GASOLINE IS EXTREMELY FLAMMABLE AND IS EXPLOSIVE
UNDER CERTAIN CONDITIONS. KEEP OUT OF REACH OF CHILDREN.
• Gasoline fuel and fumes are flammable and potentially explosive. Use proper fuel storage and
handling procedures. Always have multiple ABC class fire extinguishers nearby.
General Precautions
WARNING! FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN
SEVERE INJURY OR DEATH.
CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS CAN ALSO
RESULT IN DAMAGE TO THE TOOL AND/OR THE ITEM YOU ARE WORKING
ON. DANGER
CARBON MONOXIDE
Using a generator indoors WILL KILL YOU IN MINUTES.
Generator exhaust contains high levels of carbon monoxide (CO), a poisonous gas you cannot
see or smell. If you can smell the generator exhaust, you are breathing CO. But even If you
cannot smell the exhaust, you could be breathing CO.
· NEVER use a generator inside homes, garages, crawlspaces, or other partly enclosed areas.
Deadly levels of carbon monoxide can build up in these areas. Using a fan or opening windows
and doors does NOT supply enough fresh air.
· ONLY use a generator outdoors and far away from open windows, doors, and vents. These
openings can pull in generator exhaust.
Even when you use a generator correctly, CO may leak into the home. ALWAYS use a battery-
powered or battery-backup CO alarm in the home.
If you start to feel sick, dizzy, or weak after the generator has been running, move to fresh air
RIGHT AWAY. See a doctor. You could have carbon monoxide poisoning.
• Keep the generator and surrounding area clean at all times.
4 000W Generator

Owner’s Manual
7
General Precautions (cont’d)
Gasoline and Oil (cont’d)
• Do not smoke, or allow sparks, flames or other sources of ignition around the engine and fuel
tank. Fuel vapors are explosive.
• Keep grounded conductive objects, such as tools, away from exposed, live electrical parts and
connections to avoid sparking or arcing. These events could ignite fumes or vapors.
• Do not refill the fuel tank while the engine is running or while the engine is still hot. Do not
operate the generator with known leaks in the fuel system
• Excessive buildup of unburned fuel gases in the exhaust system can create a potentially
explosive condition. This buildup can occur after repeated failed start attempts, valve testing, or
hot engine shutdown. If this occurs, open exhaust system drain plugs, if equipped, and allow the
gases to dissipate before attempting to restart the generator.
• Use only engine manufacturer recommended fuel and oil.
Hot Components
WARNING! ENGINE AND EXHAUST SYSTEM PARTS BECOME VERY
HOT AND REMAIN HOT FOR SOME TIME AFTER THE ENGINE IS RUN. WEAR
INSULATED GLOVES OR WAIT UNTIL THE ENGINE AND EXHAUST SYSTEM
HAVE COOLED BEFORE HANDLING THESE PARTS.
Power Output
This generator is not designed to power sensitive electronic equipment (including computers
and medical devices) without the addition of an approved line conditioner, which is sold separately.
CAUTION: ATTEMPTING TO POWER SENSITIVE ELECTRONIC EQUIPMENT
WITHOUT THE USE OF AN APPROVED LINE CONDITIONER MAY CAUSE
DAMAGE TO THE EQUIPMENT. GREEN-POWER LLC IS NOT RESPONSIBLE
FOR ANY DIRECT OR INDIRECT DAMAGE CAUSED BY FAILURE TO USE AN
APPROVED LINE CONDITIONER.
• Fuel or oil spills must be cleaned up immediately. Dispose of fluids and cleaning materials as per
any local, state, or federal codes and regulations. Store oily rags in a covered metal container.
• Never store fuel or other flammable materials near the generator.
Fuel:
Fuel capacity is 6.6 US gallons(25 L). Use regularr
unleaded gasoline with a minium octane rating of 90.
Oil:
Oil capacity is 0.62 qt(0.6 L)

8
General Precautions (cont’d)
Work Area
• Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.
• Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases, or dust. Generators create sparks which may ignite the dust or fumes.
• Keep bystanders, children, and visitors away while operating a generator. Provide barriers or
shields as needed.
Electrical Safety
•Grounded tools must be plugged into an outlet properly installed and
grounded in accordance with all codes and ordinances. Never remove the
grounding prong or modify the plug in any way. Do not use any adapter
plugs.
• Grounding provides a low-resistance path to carry electricity away from the
user in the event of an electrical malfunction.
• Double insulated tools are equipped with a polarized plug where one blade is wider than the
other. This plug fits in a polarized outlet only one way. If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit, contact a qualified electrician to install a polarized outlet.
Do not change the plug in any way. Double insulation eliminates the need for the three-wire
grounded power cord and grounded power supply system.
• Avoid body contact with grounded surfaces such as pipes, radiators, ranges, and refrigerators.
There is an increased risk of electric shock if your body is grounded.
• Do not expose generator to rain or wet conditions. Water entering a generator will increase the
risk of electric shock.
• Do not abuse the power cord. Keep power cords away from heat, oil, sharp edges, or moving
parts. Replace damaged power cords immediately. Damaged power cords increase the risk of
electric shock.
• When operating a power tool outside, use an outdoor extension cord marked “W-A” or “W”.
These extension cords are rated for outdoor use, and reduce the risk of electric shock.
4 000W Generator

9
Owner’s Manual
General Precautions (cont’d)
Electrical Safety (cont’d)
• All connections and conduits from the generator to the load must only be installed by trained and
licensed electricians, and in compliance with allrelevantlocal,state,andfederalelectrical
codes and standards, and other regulations where applicable.
• The generator must be earth-grounded for fixed installations in accordance with all relevant
electricalcodesandstandardsbeforeoperation.
•Donotattempttoconnectordisconnectloadconnectionswhilestandinginwater,oronwetor
soggy ground.
•Donottouchelectricallyenergizedpartsofthegeneratorandinterconnectingcablesor
conductorswithanypartofthebody,orwithanynon-insulatedconductiveobject.
•Connectthegeneratoronlytoaloadorelectricalsystem(120volt)thatiscompatiblewiththe
electrical characteristics and rated capacities of the generator.
• Before servicing equipment powered by the generator, disconnect the equipment from its power
input.
•Keepallelectricalequipmentcleananddry.Replaceanywiringwheretheinsulationiscracked,
cut abraded or otherwise degraded. Replace terminals that are worn, discolored, or corroded.
Keep terminals clean and tight.
• Insulate all connections and disconnected wires.
•Guardagainstelectricshock.Preventbodycontactwithgroundedsurfacessuchaspipes,
radiators, ranges, and refrigerator enclosures.
Personal Safety
•Stayalert.Watchwhatyouaredoing,andusecommonsensewhenoperatingagenerator.Do
notusegeneratorwhiletiredorundertheinfluenceofdrugs,alcohol,ormedication.Amoment
of inattention while operating generators may result in serious personal injury.
•Dressproperly.Donotwearlooseclothingorjewelry.Containlonghair.Keepyourhair,clothing,
andglovesawayfrommovingparts.Looseclothes,jewelry,orlonghaircanbecaughtin
moving parts.

General Precautions (cont’d)
Personal Safety (cont’d)
• Avoid accidental starting. Make sure the power switch is in its “OFF” position, and disconnect
the spark plug wire when not in use.
• Remove adjusting keys or wrenches before turning the generator on. A wrench or a key that is
left attached to a rotating part of the generator may result in personal injury.
• Do not overreach. Keep proper footing and balance at all times.
• Use safety equipment. Always wear eye protection. Wear ANSI approved safety impact eye
goggles. Dust mask, non-skid safety shoes, hard hat, or hearing protection must be used for
appropriate conditions.
• Do not force the generator. Use the correct generator for your application. The correct generator
will do the job better and safer at the rate for which it is designed.
• Do not use the generator if the power switch does not turn it on or off. Any generator that cannot
be controlled with the power switch is dangerous and must be replaced.
Generator Use and Care
Make sure the power switch is in its “OFF” position and disconnect the spark plug wire before
making any adjustment, changing accessories, or storing the generator. Such preventive safety
measures reduce the risk of starting the generator accidentally.
Store idle generators out of reach of children and other untrained persons. Generators are
dangerous in the hands of untrained users.
Maintain generators with care. Do not use damaged generator. Tag damaged generators “Do not
use” until repaired.
Check for misalignment or binding of moving parts, breakage of parts, and any other condition that
may affect the generator’s operation. If damaged, have the generator serviced before using. Many
accidents are caused by poorly maintained generators.
Use only accessories that are recommended by the manufacturer for your model. Accessories that
may be suitable for one generator may become hazardous when used on another generator.
10
4 000W Generator

Owner’s Manual
General Precautions (cont’d)
Servicing
Maintain labels and name plates on the generator and engine. These carry important information.
If unreadable or missing, contact our service center toll free immediately for a replacement.
Generator service must be performed only qualified repair personnel. Service or maintenance
performed by unqualified personnel could result in a risk of injury.
When servicing a generator, use only identical replacement parts. Follow all appropriate
instructions in this manual. Use of unauthorized parts or failure to follow maintenance instructions
may create a risk of electric shock or injury.
Heart Pacemakers
WARNING! PEOPLE WITH PACEMAKERS SHOULD CONSULT THEIR
PHYSICIAN(S) BEFORE USING THIS PRODUCT. ELECTROMAGNETIC
FIELDS IN CLOSE PROXIMITY TO A HEART PACEMAKER COULD CAUSE
INTERFERENCE TO OR FAILURE OF THE PACEMAKER.
Installation
• enIf a transfer switch is installed, sure installation meets all applicable safety, and local and
national electrical codes. Have installation performed by a qualified, licensed electrician and
building contractor.
• All electrical work, including the earth-ground connection, should be completed by a licensed
electrician.
• Any separate fuel storage or generator supply facility must be built or installed in full compliance
with all relevant local, state, and federal regulations.
11

12
4 000W Generator
General Precautions (cont’d)
Installation (cont’d)
• If the generator is installed outdoors, it must be weatherproofed and should be soundproofed. It
should not be run outdoors without protection to the generator and wiring conduit.
• The generator might weigh over 100 lbs Two or more people should assist when moving or lifting
this product. Never lift the generator using the engine or alternator lifting lugs. Connect lifting
equipment to the frame of the generator
• Before lifting the generator, ensure the lift rigging and supporting structure are in good
condition, and are rated to lift such a load.
• Keep all personnel away from the suspended generator during relocating.
• The supporting floor/ground surface should be level and strong enough to safely hold the weight
of the generator. If the floor/grounded surface is not level, strong cross members should be
placed under the full length of the generator frame at its low side.
• For trailer installation, the generator should be mounted on the center point of the trailer, over
the wheels. The trailer must be capable of supporting the weight of the generator and all
contents (tools, etc.)
• Install sound-and weather-proofing only when it is not raining or snowing to avoid trapping
moisture within the generator’s area.
Mechanical
• Always make sure the power switch is in its “OFF” position. Disconnect the spark plug wire, and
allow the engine to completely cool before carrying out maintenance.
• Check for damaged parts. Before using the generator, any part that appears damaged should
be carefully checked to determine that it will operate properly and perform its intended function.
Check for alignment and binding of moving parts, any broken parts or mounting fixtures, and any
other condition that may affect proper operation technician.
• The generator is designed with guards for protection from moving parts. In any case, care must
still be taken to protect personnel and equipment from other mechanical hazards when working
around the generator.

Owner’s Manual
General Precautions (cont’d)
Mechanical (cont’d)
• Do not operate the generator with safety guards removed. While the generator is running, do not
attempttoreacharoundthesafetyguardformaintenanceoranyotherreason.
•Keephands,arms,longhair,looseclothing,andjewelryawayfrommovingparts.Beawarethat
when engine parts are moving fast they cannot be seen clearly.
•Keepaccessdoorsonenclosuresclosedandlockedwhenaccessisnotrequired.
• When working on or around the generator always wear protective clothing including ANSI
approvedsafetygloves,safetyeyegoggles,andsafetyhat.
•Donotalteroradjustanypartofthegeneratorthatisassembledandsuppliedbythe
manufacturer.
• Always follow and complete scheduled engine and generator maintenance.
Chemicals
•Avoidcontactwithhotfuel,oil,exhaustfumes,andhotsolidsurfaces.
•Avoidbodycontactwithfuels,oils,andlubricants used in the generator. If swallowed, seek
medical treatment immediately. Do not induce vomiting if fuel is swallowed. For skin contact,
immediately wash with soap and water. For eye contact, immediately flush eyes with clean water
and seek medical attention.
Noise
• Prolonged exposure to noise levels above 68 DBA is hazardous to hearing. Always wear ANSI
approved ear protection when operating or working around the generator when it is running.
13

General Precautions (cont’d)
Extension Cord
If an extension cord (not included) is used, make sure to use only UL approved cords having the
correct gauge and length according to the following table:
Cord LengthsNameplate Amps (@ full load)
0 - 5 16 16 12 12
5.1 - 8 16 14 10 -
8.1 - 12 14 12 - -
12.1 - 15 12 10 - -
15 - 20 10 10 - -
14
0 ft.- 50 ft. 50 ft.-100 ft. 100 ft.-150 ft. 150 ft.-200 ft.
AWG AWG
AWG
AWG
AWG
AWG
AWG
AWG
AWG
AWG
AWG
AWG
AWG
4 000W Generator

Owner’s Manual
15
During connection, DO NOT touch battery’s positive electrode and negative electrode directly.
Battery
If the generator is equipped with electric start system,you need to install the battery properly,
which may not be provided.the regular battery should be Pb-acid AGM battery with following
specifications:Voltage 12V.lead-acid battery with 17AH,or 12V Li-battery with 1.6AH respectively.
First, install battery onto the frame with provided accessories. Connect the wires to the
electrical motor positive electrode and battery positive electrode, electrical motor negative and
battery negative electrode respectively.
Caution: Connecting or touching the Battery’s positive electrode and neg ative electrode
directly may cause battery burning and cause damage to the equipment or even more
serious accident!

16
Assembly and Installation
Unpacking
1. Remove the generator and loose parts box from the carton.
Loose Parts (Wheel kit and handle)
Check all loose parts against the following list. Contact your dealer toll free at 888.834.4218
if any of the loose parts shown are not included with your generator
Hardware Check:
Your Hardware Kit should include:
1) Two Handles with bolts, nuts.
2) Two axle shaft with nuts
3) Two washers
4)
5)
One generator leg with bolts and nuts
Two wheels
3
2
4
1
5
4000W Generator
2. Compare the Hardware Kit included with the inventory list below.

17
Installation
NOTE: PRIOR TO POWERING TOOLS AND EQUIPMENT MAKE SURE THE
GENERATOR’S RATED VOLTAGE, WATTAGE AND AMPERAGE CAPACITY IS
ADEQUATE TO SUPPLY ALL ELECTRICAL LOADS THAT THE UNIT WILL
POWER. IF POWERING EXCEEDS THE GENERATOR’S CAPACITY, IT MAY BE
NECESSARY TO GROUP ONE OR MORE OF THE TOOLS AND/OR EQUIPMENT
FOR CONNECTION TO A SEPARATE GENERATOR.
Electrical and other permits may be required for the installation of emergency power systems.
Investigate your local building and electrical codes before installing this unit. Installation must be
completed by licensed contractors.
WARNING! THE GENERATOR WEIGHS APPROXIMATELY OVER 100 POUNDS.
USE CARE AND THE PROPER LIFTING OR HOISTING EQUIPMENT WHEN
MOVING IT TO THE INSTALLATION LOCATION. ALWAYS CONNECT HOIST
LINES TO THE FRAME OF THE GENERATOR.
General Location
•Make sure to locate and install the generator outdoors where cooling air is readily available.
• Install the generator so that the air inlets and outlets are not blocked by obstructions such as
bushes, trees, or snow drifts. Locating it in the path of heavy winds or snowdrifts may require
the placement of a barrier for protection. In normal weather conditions, the air vent should face
the prevailing wind direction.
• Install the generator on a concrete slab or other area where rain drainage or flood waters can
not reach it.
• Generator placement should allow four feet of access to all sides for maintenance.
• Place the generator as close as possible to the electrical tools and equipment being powered to
reduce the length of extension cords.
Owner’s Manual

18
Installation (cont’d)
Supporting and Mounting
Mount the generator on a concrete slab capable of supporting the weight of the generator. The
slab must extend on all sides beyond the frame by at least one foot. Contact a cement contractor
for slab specifications if necessary. Attach the frame to the concrete slab using 3/8” diameter
expansion anchor bolts (not supplied).
Grounding
NOTE: IT IS RECOMMENDED THAT ONLY A TRAINED AND LICENSED
ELECTRICIAN PERFORM THIS PROCEDURE
Connect a #6 AWG grounding wire (not included) from the ground connector (8) on the generator
to a grounding rod (not included) that has been driven at least 24 inches deep into the earth. The
grounding rod must be an earth-driven copper or brass rod (electrode) which can adequately
ground the generator.
Handle
Oil plug
Recoil Start
Air filter
Choke lever
Fuel tank
Product Image for Reference only
rotareneGW0004

CAUTION: PRIOR TO FIRST USING THE GENERATOR, THE ENGINE MUST BE
FILLED WITH HIGH QUALITY SAE 10W-30 GRADE ENGINE OIL. TO DO SO,
UNSCREW AND REMOVE THE ENGINE’S OIL DIPSTICK LOCATED AT THE
BOTTOM OF THE ENGINE CRANKCASE. FILL THE ENGINE CRANKCASE UNTIL
THE OIL LEVEL IS LEVEL WITH THE UPPER MARKED LINE ON THE DIPSTICK.
THEN SCREW THE DIPSTICK BACK INTO THE OIL FILL HOLE.
19
Owner’s Manual
Operation
NOTE: THE PARTS LISTED ABOVE ARE HELPFUL FOR LOCATING THE
CONTROLS MENTIONED BELOW.
Before Starting the Generator
1. Check that the engine power switch is in its Fuel tank capacity:25.0L(6.6 gallons)
“OFF” position.
2. Before the first use, remove the fuel
tank cap and fill the fuel tank with unleaded
gasoline. When fueling, be sure that the
fuel strainer is in place. Replace the fuel
tank cap. Thereafter, check the engine’s
fuel gauge for the amount of unleaded
gasoline in the fuel tank. If necessary,
refill the fuel tank with unleaded gasoline;
the generator must be turned off and
cooled down before refilling the fuel tank.
Upper Level
Use gasoline with a pump octane rating of 90 or higher.
We recommend unleaded gasoling because it produces
fewer engine and spark plug deposits and extends
exhaust system life. Never use stale or contaminated
gasoline or oil/gasoline mixture. Avoid getting dirt or
water in the fuel tank.
