Green-Qube Quick-Qube User manual

Quick-Qube Assembly Instructions
1. Drag the frame outwards so it is fully
extended and you hear a ‘click’.
2. Next add the top hanging bars, you will have a
combination of:
 Hanging Bars
 Outer Support Poles
 Cross Support Poles (not applicable for QQ1224 & QQ1530)
See below diagrams for the set up for your Quick-Qube
For each Outer Support Pole insert the crook end into the central
slot. Then match the hole at the other end of the Outer Support
Pole to the hole in the corner of the frame. Use one of the screws
to fix into place.
Slot each of the crooks of each Cross Support Pole into the central
and side slots. Finally Add the hanging bars in position.
QQ1224 & QQ1530 QQ2030 QQ200, QQ240 & QQ30
All manuals and user guides at all-guides.com

3. Unwrap the outer shell and place the roof
over the top of the frame.
4. Then slid the base under the frame.
5. Select one leg and extend it downwards by
pulling the green ring out and pushing the
upper frame leg up. Click onto the 4th
notch for the full 2.2m height.
After one leg is done, select the diagonal
leg. Then continue with the last two legs.
For Quick Qube 200, 240 & 300 extend the
fifth central leg last.
6. Finally wrap the outer shell around the frame,
zipping it together as you go.
All Done!
Visit our website for more info…
