OPERATION MANUAL
52080019 REV 05 © 2022 Greenlee Tools, Inc. 10/22
Serial Number
Read and understand all of the instructions and
safety information in this manual before operating
or servicing this tool.
Register this product at www.greenlee.com
EK1550FLX & EK1550SLX
GATOR®Battery-powered,
15-ton Crimping Tool
Français.............. 17
Español............... 33
EK1550FLX
EK1550SLX

15 Ton Battery-Powered Crimping Tool
252080019 REV 05
© 2022 Greenlee Tools, Inc.
KEEP THIS MANUAL
Table of Contents
Safety Symbols Key ...........................................3
General Safety Warnings*...................................4
Tool Specic Safety Information.........................6
Greenlee Contact Information............................6
Tool Description..................................................7
Specications.....................................................7
Tool Identication ...............................................8
Decals & Locations.............................................8
OLED Screen......................................................9
I-Press App.........................................................9
Training and Qualications ...............................10
Pre-Operation Inspection .................................10
Work Area & Tool Set Up..................................11
Connector & Die Selection.. .............................12
Tool Operation..................................................13
Troubleshooting................................................14
Transportation & Storage .................................15
Service..............................................................15
Maintenance.....................................................15
Disposal............................................................16
Required Statements........................................16

15 Ton Battery-Powered Crimping Tool
3
52080019 REV 05 © 2022 Greenlee Tools, Inc.
IMPORTANT SAFETY INFORMATION
SAFETY
ALERT
SYMBOL
This symbol is used to call your attention to hazards
or unsafe practices which could result in an injury or
property damage. The signal word, dened below,
indicates the severity of the hazard. The message
after the signal word provides information for pre-
venting or avoiding the hazard.
Immediate hazards which, if not avoided, WILL result
in severe injury or death.
Hazards which, if not avoided, COULD result in
severe injury or death.
Hazards or unsafe practices which, if not avoided,
MAY result in injury or property damage.
This symbol means always wear
safety glasses with side shields or
goggles when handling or using
this equipment to reduce the risk of
eye injury.
This symbol means read the
operator’s manual carefully before
using the equipment. The operator’s
manual contains important
information on the safe and proper
operation of the equipment.
This symbol indicates the risk of
electrical shock.
This symbol indicates the risk of
pressurized uid directed at hand or
body parts, causing skin puncture
and injection injuries.
This symbol indicates the risk of re
starting.
Always wear gloves when handling
or using this equipment to reduce
the risk of injury.
This symbol indicates the risk of
striking injuries from ying objects.
This symbol indicates the risk of
striking injuries from ying objects.

15 Ton Battery-Powered Crimping Tool
452080019 REV 05
© 2022 Greenlee Tools, Inc.
Read all safety warnings, instructions,
illustrations and specifications provided with this
power tool. Failure to follow all instructions listed
below may result in electric shock, fire and/or
serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR
FUTURE REFERENCE.
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery operated (cordless) power
tool.
WORK AREA SAFETY
• Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
• Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
• Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
ELECTRICAL SAFETY
• Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodied plugs and matching outlets will
reduce risk of electric shock.
• Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
• Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
• Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords
increase the risk of electric shock.
• When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
• If operating a power tool in a damp location
is unavoidable, use a RESIDUAL CURRENT
DEVICE (RCD) protected supply. Use of an RCD
reduces the risk of electric shock.
General Safety Warnings* PERSONAL SAFETY
• Stay alert, watch what you are doing and
use common sense when operating a power
tool. Do not use a power tool while you are
tired or under the inuence of drugs, alcohol
or medication. A moment of inattention while
operating power tools may result in serious
personal injury.
• Use personal protective equipment (PPE).
Always wear eye protection. Protective
equipment such as dust mask, non-skid safety
shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal
injuries.
• Prevent unintentional starting. Ensure the
switch is in the off-position before connecting to
power source and/or BATTERY pack, picking up
or carrying the tool. Carrying power tools with
your nger on the switch or energizing power
tools that have the switch on invites accidents.
• Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personal injury.
• Do not overreach. Keep proper footing and
balance at all times. This enables better control of
the power tool in unexpected situations.
• Dress properly. Do not wear loose clothing or
jewelry. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewelry or long
hair can be caught in moving parts.
• If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
• Do not let familiarity gained from frequent use
of tools allow you to become complacent and
ignore tool safety principles. A careless action
can cause severe injury within a fraction of a
second.
POWER TOOL USE AND CARE
• Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
• Do not use the power tool if the switch does
not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous
and must be repaired.
• Disconnect the plug from the power
source and/or remove the BATTERY
pack, if detachable, from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.

15 Ton Battery-Powered Crimping Tool
5
52080019 REV 05 © 2022 Greenlee Tools, Inc.
* The text used in the General Power Tool Safety Warnings section of this manual
is required from the applicable EN 62841-1 standard to which this tool is tested.
This section contains general safety practices for many different types of power
tools. Not every precaution applies to every tool, and some may not apply to this
tool.
• Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool.
• Power tools are dangerous in the hands of
untrained users.
• Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation. If
damaged, have the power tool repaired before
use. Many accidents are caused by poorly
maintained power tools.
• Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
• Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions and
the work to be performed. Use of the power tool
for operations different from those intended could
result in a hazardous situation.
• Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles
and grasping surfaces do not allow for safe
handling and control of the tool in unexpected
situations.
BATTERY TOOL USE AND CARE
• Recharge only with the charger specified by
the manufacturer. A charger that is suitable for
one type of BATTERY pack may create a risk of re
when used with another BATTERY pack.
• Use power tool only with specifically
designated BATTERY packs. Use of any other
BATTERY packs may create a risk of injury and
re. When BATTERY pack is not in use, keep it
away from other metal objects, like paper clip,
coins, keys, nails, screws or other small metal
objects, that can make a connection from one
terminal to another. Shorting the BATTERY
terminals together may cause burns or a re.
• Under abusive conditions, liquid may be
ejected from the BATTERY; avoid contact. If
contact accidentally occurs, ush with water. If
liquid contacts eyes, additionally seek medical
help. Liquid ejected from the BATTERY may cause
irritation or burns.
• Do not use a BATTERY pack or tool that is
damaged or modified. Damaged or modied
batteries may exhibit unpredictable behavior
resulting in re, EXPLOSION or risk of injury.
• Do not expose a BATTERY pack or tool to fire
or excessive temperature. Exposure to re or
temperature above 265°F (130°C) may cause
explosion.
• Follow all charging instructions and do not
charge the BATTERY pack or tool outside the
temperature range specified in the instructions.
Charging improperly or at temperatures outside
the specied range may damage the battery and
increase the risk of re.
SERVICE
• Have your power tool serviced by a qualified
repair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.

15 Ton Battery-Powered Crimping Tool
652080019 REV 05
© 2022 Greenlee Tools, Inc.
Use the correct tool and accessories for your applica-
tion. The correct tool will do the job better and safer
at the rate for which it was designed. Use of the tool
for operations different from those intended can result
in a hazardous situation.
Before operating this tool, read and understand:
• This operator's manual
• The instructions for any other equipment or
material used with this tool
• Markings on the tool
• Required work site safety procedures
Failure to follow all instructions and warnings may
result in serious injury or death.
• Use proper die, connector, and cable combi-
nations, improper combinations can result in
an incomplete crimp. An incomplete crimp can
cause a re.
• Do not use any worn or damaged dies with
this tool. A damaged or worn die can break and
strike nearby personnel.
• Keep your fingers and hands away from the
tool head during the operating cycle. Your
ngers or hands can be crushed, fractured, or
amputated if they become caught in the tool head
or between the tool head and other objects.
• One person must control work process and
machine operation. Only the operator should be
in the area when the tool is running.
• Large forces are generated during use that
can break or throw parts and cause injury.
Keep all unnecessary personnel away from work
area and wear appropriate PPE.
• Do not use on live electrical lines, this tool is
not insulated. When using this unit on or near
energized electrical lines, use proper personal
protective equipment.
• Proper set up is essential to minimizing risk
during use. Set up the tool and work area
according to these procedures to reduce the risk
of injury.
• Use this equipment only in accordance with
these instructions, considering the working
conditions and the work to be performed. Use of
this equipment for operations different from those
intended could result in a hazardous situation.
• Do not modify tool. Modifying the tool in any
manner may result in personal injury and voidance
of the tool’s warranty. A head that has been welded,
ground, drilled or modied in any manner can break
during use. To reduce risk of injury, replace and
dispose of the whole damaged head, never indi-
vidual components.
• Do not use hands to check for oil leaks. Oil under
pressure easily punctures skin. If injured, seek
medical attention immediately.
Tool Specific Safety Warnings
Greenlee Contact Information
If you have any questions, need to arrange service or
purchase parts or accessories for this Greenlee/HDE
product: Contact your local Greenlee distributor or
Greenlee’s Customer Service Center.
Additional copies of this manual are available for
download at www.greenlee.com
Greenlee Customer Service
USA: 1-800-435-0786 | Canada: 800-435-0786
International: 1-815-397-7070
[email protected]
Shipping address:
Greenlee Factory Service Center
4411 Boeing Dr., Rockford, IL 61109

15 Ton Battery-Powered Crimping Tool
7
52080019 REV 05 © 2022 Greenlee Tools, Inc.
Maximum Crimping Force ............................................................................................................................15 tons (135 kN)
Maximum Capacity Lugs & Splices ................................................................................................. 8 AWG - 1500 kcmil Cu
8 AWG - 1250 kcmil AL
P-Style Dies.....................................................................................................................................1250 kcmil aluminum
1500 kcmil copper ttings
12-ton U-Style Dies.................................................................................................................. 500 kcmil copper splices
750 kcmil copper terminals
350 kcmil aluminum splices
750 kcmil aluminum terminals
Hydraulic Oil............................................................................................................52057878 biodegradable hydraulic uid
Operating Temperature Range .............................................................................................5 °F to 122 °F (–15 °C to 50 °C)
Battery Charging .........................................................................Read the instructions supplied with the battery charger
Battery Technology..........................................................................MAKITA®LXT®Lithium ion BL1830, BL1840, BL1850
Do not use non-butting dies (crimps controlled by tonnage) in this tool, as damage could occur to connectors and/or conductors.
NOT for use with flex, navy or welding wire
This tool may be used in damp or wet environments; however, air-drying is recommended before use if the tool becomes soaked. Damage may
result when the tool is operated prior to thorough drying when electrical components are soaked.
Specifications
EK1550FLX Flip-Head Configuration
Length ................................................................................................................................................... 19.5 in. (495.3 mm)
Width............................................................................................................................................................ 3.0 in. (76 mm)
Height (with battery)................................................................................................................................... 11 in. ( 280 mm)
Weight (with battery)................................. .....................................................................................................17.5 lb. (7. kg)
EK1550FLX crimping tool is a battery-powered, Flip-head and pistol grip congured tool intended to crimp alumi-
num and copper connectors onto electrical cable.
The EK1550SLX crimping tool is a battery-powered, C-head and pistol grip congured tool intended to crimp alumi-
num and copper connectors onto electrical cable..
Features
• Intelli-CRIMP® Technology
• One Trigger Control
• Accepts U and P die congurations
• LED Work Light
• Display with Real Time PSI reading
EK1550SLX C-Head Configuration
Length ..........................................................................................................................................................18.5 in. (470 mm)
Width............................................................................................................................................................3.125 in. (80 mm)
Height (with battery).....................................................................................................................................13.5 in. (343 mm)
Weight (with battery) ..................................................................................................................................... 18.9 lb. (8.57 kg)
Tool Description
All specifications are nominal and may change as design improvements occur. Greenlee Tools, Inc.
shall not be liable for damages resulting from misapplication or misuse of its products.
GATOR is a registered trademark of Greenlee Tools, Inc.
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Blackburn is a registered trademark of Thomas & Betts.

15 Ton Battery-Powered Crimping Tool
852080019 REV 05
© 2022 Greenlee Tools, Inc.
Tool Identification
2
1
54
7
8
9
3
6
B
C
1. Die Release Buttons
2. Lanyard Ring
3. Housing
4. Retract Button
5. LED Indicator (Red)
6. OLED Screen
7. Battery
8. Trigger
9. LED Work Light (White)
10. Pull Pin
11. Ram
12. Flip-Top Head
13. C-Head
14. Handle Connection
15. Handle
Decals & Locations
A. Crush Hazard
B. Brand Identication
C. Model Information
EK1550FLX
A
B
7
2
11
13
4
8
9
1
3
6
5
C
14
EK1550SLX
10
11
12
15
14

15 Ton Battery-Powered Crimping Tool
9
52080019 REV 05 © 2022 Greenlee Tools, Inc.
i-Press App
This tool has wireless capability that allows it to communicate with the Greenlee
i-press app on your smart device.
1. Install the “i-press Klauke Software Solutions” from the Apple App Store™ or
Google Play™. Open the app on your smart device and select the “Greenlee”
option.
2. Switch on the wireless function on your smart device and activate the tool to
establish a connection.
The app will allow you to create projects, personalize your tool, display tool pressure readings, battery charge, the
last service date, and more. Instructions how to use the app are shown in the i-press app itself; alternately, request a
brochure (G-1024 10/22) from any Greenlee distributor.
i—Press is a registered trademark of Gustav Klauke GmbH
App Store is a registered trademark of Apple Inc.
Google Play is a registered trademark of GOOGLE INC.
OLED Screen
The OLED screen displays information about the tool and is used to set up operating proles and display error codes
in the event of abnormal operation (See Troubleshooting). Turn on the screen by inserting the battery and pressing
the trigger.
Cycle through the various displays using the left and right buttons on either side of the screen.
Display OLED Screen Information Shown
Error Screen
****
ERROR CODE: Error code numbers (See Troubleshooting)
Battery &
Pressure
XXX PSI
XXX PSI
P
P
^
Wireless status, battery charge, current pressure, and max pressure.
Press and hold both buttons to change units, select with right button, and confirm by
jogging the tool.
Tool Software
Information
INFO
123456AB001
FW: 2.0 Firmware version, serial number
Profile Mode
Select
CURRENT USER : 1
SINGLE CLICK
MRS+
User 1: Single Trigger Pull Operation
User 2: Double Trigger Pull Operation.
Press trigger twice within 0.5 sec. to operate
To Change Mode:
1. Press and hold both buttons to change user.
2. Press trigger to lock in mode.
Service
Information #ODS #DAYS Cycles and days until next service.
Tool Operation
Information
TOTAL:
t=
Q=
n=
1.35 h
8.87 Ah
1560
Since Date of Manufacture;
t=Elapsed Operating Hours
q= Ah Used
n= # of Crimping Cycles

15 Ton Battery-Powered Crimping Tool
10 52080019 REV 05
© 2022 Greenlee Tools, Inc.
• Daily before use, inspect the tool and correct
any problems before using to reduce the risk
of injury and prevent product damage. If any
problems are found, do not use this tool until the
problems have been xed, failure to follow these
steps increase the risk of injury.
• Do not use hands to check for oil leaks. Oil
under pressure easily punctures skin. If injured,
seek medical attention immediately.
1. Remove battery before inspecting tool.
2. Clean any oil, grease or dirt from the tool body and
head, including handles and controls. This aids
inspection and helps prevent the machine or control
from slipping from your grip. Clean and maintain per
maintenance instructions.
3. Inspect tool body and head for damage in the form
of chips, wear and pitting. Replace any worn or
damaged parts. A damaged or improperly assembled
tool can break and strike nearby personnel.
4. Inspect the die seat area is free of damage and
debris. Debris in the die seat area can interfere with
the die or adapter's ability to be secured in tool head.
5. Inspect the tool head for damage. Replace any worn
or damaged parts.
6. Inspect dies before use. Do not use if any dies are
worn, corroded, rusted, or cracked. A damaged die
can break and strike nearby personnel.
7. Check the rotation of the head assembly. The head
should rotate no more than one turn (360°). If the
head rotates past this point, send in for service.
Check for proper assembly and completeness, do
not use if there are missing or misaligned parts.
8. Check for the presence and condition of decals.
9. Inspect any other equipment and batteries according
to their instruction manuals.
If any issues are found, do not use this tool until
corrected.
Pre-Operation Inspection
1. Check work area for:
• Adequate lighting
• A clear, level, stable and dry place for all equip-
ment and space for the operator to work
comfortably and according to tool operating
instructions to reduce the risk of injury.
2. Make sure the work site is easily recognizable to
outside observers to prevent people from coming
into the area while the tool is being used. Barriers or
cones around work site are some of the ways to do
this.
3. Strip and prepare cable according to the
manufacturer’s instructions.
Note: Apply an oxide inhibitor, if required. See the
connector manufacturer’s instructions.
4. Select a proper size and type of connector to
correspond with the wire or cable. It is important to
use the proper die and connector for a specic cable
to make sure the crimp is correct (See Connector &
Die Selection).
5. Remove battery before installing adapters or
changing dies.
6. Install the appropriate die set or adapter for your
tool. (See Adapter & Die Set Up) Do not use non-
butting dies (crimps controlled by tonnage) in this
tool, as damage could occur to connectors and/or
conductors. Before installing dies or the adapter into
the EK1550FLX, press in and then turn the pull pin
45o counter-clockwise to open the ip-top head.
7. Install battery and press the trigger for one
complete cycle to check the tool for proper
operation, keep hands clear of tool head.
Work Area & Tool Set Up
Set up the tool and work area according to these
procedures to reduce the risk of injury and tool
damage.
• Use proper die, connector, and cable combi-
nations, improper combinations can result in
an incomplete crimp. An incomplete crimp can
cause a re.
• Do not use any worn or damaged dies with
this tool. A damaged or worn die can break and
strike nearby personnel.
• Remove battery before touching crimping head
and installing dies to reduce the risk of injury.
Training & Qualifications
This product is designed for use by professionals
trained for working in a construction environment or
around high voltage electrical equipment. If you are not
trained in the work methods required for safe operation,
do not use this product.

15 Ton Battery-Powered Crimping Tool
11
52080019 REV 05 © 2022 Greenlee Tools, Inc.
“P” Style Dies—No Adapters Required (Fig.1)
1. Slide top die into tool head while pressing the
die retainer button.
2. Release button and allow die to snap into place.
The dies should not be able to be removed
without pressing the die retainer button,
3. Repeat with other die.
Figure 2
Figure 1
Adapter & Die Set Up
It is important to know the appropriate die set that corresponds to the size, type, and manufacturer of the connector to
be crimped (See Connector & Die Selection). Using the wrong die and connector combination will lead to incomplete
crimps that, if not corrected, risks a re starting from the bad crimp.
The EK1550FLX and Ek1550SLX have the capacity to use several different die sets. Some types of dies require an
adapter to hold the dies. If no adapter is needed, dies t directly into tool.
Determine the dies to be used and if an adapter is required based on the type of die and the model of crimper. See
CJ22 Jaws and KC22/KA22-Type Die Tables for cUL and UL classied die and connector combinations.
12-ton “U” Style Dies - Use UA15T Adapter (Fig. 2)
1. Slide top UA15T adapter into tool head while
pressing the die retainer button.
2. Release button and allow adapter to snap into
place. Repeat with the other adapter.
3. Slide the appropriate die into the adaptor while
pressing the retaining button on the adaptor.
4. Release button and allow die to snap into place.
Neither the dies or the adapters should be able
to be removed without pressing the die retainer
buttons.
Die Retainer
Button
Die Retainer
Button
UA15T
U-Die Pair

15 Ton Battery-Powered Crimping Tool
12 52080019 REV 05
© 2022 Greenlee Tools, Inc.
Connectors by Manufacturer & Type
Tool Range: 8 AWG to 750 kcmil
When used with KC12-type dies, this tool is cUL and UL classied for use with the following connector brands:
When used with KA12-type dies, this tool is cUL and UL classied for use with the following connector brands:
Short
Long
Short
Long
Barrel
Type
8 AWG to
250 kcmil:
1 crimp
300 to
750 kcmil:
2 crimps
Number
of Crimps*
VHSS
VHS
VHCS
VHCL
Anderson
CSP
CU
CTL-2/CTL
CTL-L/LCN
Blackburn®
YS-L
YS
YA-2LN/
YA-L/YA-2L;
YA/YA-L-TC/
YA-L-2TC
YA/YAZ
YA-2N/YA-2TC
YAZ-2N/YAZ-2TC
Burndy
CT
CTL
CSW
CRA/CRB
CRC
CLN, CLW
CRA-L/CRB-L
CRA-2/CRB-2L
CRC-2L
ILSCO
SCSS
SCS
SCL
SCH
LCAS
LCA
LCD
LCAN
LCB
LCC
Panduit
54504 to
54523-TB
54804 to
54823
54104 to
54123-TB;
54204 to
54223
54930BE to
54923BE;
54850BE to
54880BE
T&B
BCU
BBCU
BLU
BBLU
Penn-
Union
Connector
Type
Copper
Splice
Copper
Lugs
8 to
1/0 AWG:
1 crimp
2/0 AWG to
350 kcmil:
2 crimps
400 to
750 kcmil:
3 crimps
Number
of Crimps*
Anderson
VACS
VACL
Blackburn®
ASP
ATL
Burndy
YS-A
YA-A
YA-ATN
ILSCO
AS
ASN
ACL/ACN
2ACL/2ACN
ALNS/ALNN/ALND
Panduit
SA
LAA
LAB
T&B
60501 to
60578
60101 to
60176;
60230 to
60278
Penn-
Union
PIK
BLUA
Connector
Type
Dual-Rated
Aluminum
Splice
Dual-Rated
Aluminum
Lugs
* Use the number of
crimps listed in this
column instead of the
number provided with
the connector.
Connector & Die Selection
Dies for Copper Connectors
Catalog
No. UPC No. Cable Size Color Code No. of Crimps
KC12-8 10996 8 AWG Red 1
KC12-6 10997 6 AWG Blue 1
KC12-4 10998 4 AWG Gray 1
KC12-2 10999 2 AWG Brown 1
KC12-1 11003 1 AWG Green 1
KC12-1/0 11004 1/0 AWG Pink 1
KC12-2/0 11007 2/0 AWG Black 1
KC12-3/0 11010 3/0 AWG Orange 1
KC12-4/0 11011 4/0 AWG Purple 1
KC12-250 11012 250 kcmil Yellow 1
KC12-300 11013 300 kcmil White 2
KC12-350 11014 350 kcmil Red 2
KC12-400 11015 400 kcmil Blue 2
KC12-500 11016 500 kcmil Brown 2
KC12-600 11018 600 kcmil Green 2
KC12-750 11020 750 kcmil Black 2
Dies for Aluminum Connectors
Catalog
No. UPC No. Cable Size Color Code No. of Crimps
KA12-8 22084 8 AWG Blue 1
KA12-6 22085 6 AWG Gray 1
KA12-4 22086 4 AWG Green 1
KA12-2 22087 2 AWG Pink 1
KA12-1 22088 1 AWG Gold 1
KA12-1/0 22089 1/0 AWG Tan 1
KA12-2/0 22090 2/0 AWG Olive 2
KA12-3/0 22121 3/0 AWG Ruby 2
KA12-4/0 22122 4/0 AWG White 2
KA12-250 22123 250 kcmil Red 2
KA12-300 22124 300 kcmil Blue 2
KA12-350 22125 350 kcmil Brown 2
KA12-400 22126 400 kcmil Green 3
KA12-500 22127 500 kcmil Pink 3
KA12-600 22128 600 kcmil Black 3
KA12-750 22129 750 kcmil Yellow 3
Crimps made with this tool and KC12-type or KA12-type dies are cUL and UL classied when used with the appropriate conductor
and connectors listed below. When using KC12-type dies, complete the number of crimps listed on the in Connector
Selection chart in this manual. For other connector, complete the number of crimps specied by the manufacturer.

15 Ton Battery-Powered Crimping Tool
13
52080019 REV 05 © 2022 Greenlee Tools, Inc.
Set up the tool and work area according to these
procedures to reduce the risk of injury and tool
damage.
• Keep your fingers and hands away from the
tool head during the operating cycle. Your
ngers or hands can be crushed, fractured, or
amputated if they become caught in the tool head
or between the tool head and other objects.
• Use proper die, connector, and cable combi-
nations, improper combinations can result in
an incomplete crimp. An incomplete crimp can
cause a re.
• Do not use on live electrical lines, this tool is
not insulated. When using this unit on or near
energized electrical lines, use proper personal
protective equipment.
• Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
Operation
This tool is equipped with a pressure sensor that alerts
the user of an incomplete crimp. If the tool is manually
retracted before completion of a crimp, the red LED and
an audible beep will be active for 2 seconds.
If the tool is unable to reach the required crimp force,
the red LED, work light, and an audible beep will pulse
until after the trigger is released.
In cold weather, allow the power source to run (idle) for
a few minutes to warm the hydraulic uid. Actuating the
tool intermittently will reduce the time required to warm
the uid to an efcient operating temperature.
Crimping
1. Insert the cable fully into the connector. Make sure
the cable is properly prepared per connector manu-
facturer's instructions.
2. If open, close the ip-top head and engage the pull
pin. Make sure the pull pin is fully engaged
3. Insert the connector in the tool head and align
where the crimp will be located with the center line
of the tool.
4. Depress the trigger to advance the ram. Hold until
the ram automatically begins to retract.
If the crimping tool does not automatically retract,
the crimp is incomplete. It is normal for the battery
load display to light at both the beginning and near
the end of the crimping cycle.
5. Repeat the cycle until the recommended number of
crimps is reached. For a UL or cUL classied crimp,
complete the number of crimps specied under
“Connector & Die Selection”.
Pay attention to the direction and spacing of the
crimps for best results (Fig.3).
To stop the ram from returning fully when automatically
retracting, depress the trigger quickly and release. This
activation will close the retraction valve and stop the
retraction motion. Depressing the trigger will cause the
ram to advance from that stopped position. Pushing the
retract button will open the retraction valve and com-
plete retraction of the ram.
After completing the last crimp on an aluminum connec-
tor, wipe off the excess oxide inhibitor.
Figure 3
Crimping Direction
(Evenly Spaced)
Crimping Direction
Side B
(Evenly Spaced)
Crimping Direction
Side A
(Evenly Spaced)
1st Compression
Side B
1st Compression
Side A
1st Compression

15 Ton Battery-Powered Crimping Tool
14 52080019 REV 05
© 2022 Greenlee Tools, Inc.
Table 1: Tool Indicator LED Signals
Signal LED (Red) Meaning Action
Red LED stays lit
for 20 seconds
after trigger is
released.
Battery Charge
Low
Change
or charge
the
battery.
LED will flash
for 20 sec. after
trigger is released.
Motor current
exceeds 20 A
during cycle Let the
tool cool.
Tool is
Overheated
Flashing light for
20 sec. at end of
cycle.
Internal Error
Send
in for
Service.
The red LED located on the side of the tool near the
trigger indicates several states of the tool. (See Table 1)
Troubleshooting
If something goes wrong with the tool OLED screen will
most likely display an error code. (See Table 2) Some
problems can arise where an error code is not shown.
(See Table 3)
Table 2: Error Codes
Error
Code Meaning Action
1Over current fuse Seek Service
2Over current comparator Seek Service
3Overheated circuit board Cool Tool
4Overheated battery Cool Battery
5Battery empty: operation stops Charge Battery
6Faulty cut; complete cycle Seek Service
7Faulty cut; incomplete cycle Seek Service
8Low battery Charge Battery
9Battery empty Charge Battery
10 Real-time clock battery low Seek Service
11 Tool deactivated Seek Service
12 Service necessary Seek Service
13 Real-time clock not found Re-insert Battery
Seek Service
14 Wireless unit is not found Re-insert Battery
Seek Service
15 [Not Used]
16 Pressure sensor not found Seek Service
17 Pressure exceeded Seek Service
18 Battery temperature too low Warm Battery
21 Remote control battery low Replace Battery
Table 3: Other Problems
Problem Possible Cause Solution
Tool does not
activate when
pressing trigger.
Contaminants (dirt, rust
etc.) in Cutting Head.
Remove battery
and clean tool
head thoroughly.
Components Worn or
Damaged Send in for service.
Motor is Not Working
Check battery
charge and
change battery if
necessary.
Check for
broken switch
components
and send in for
service.
Low or Expired Battery Charge or Change
battery.
Broken Components Send in for service.
Motor runs but
tool will not
complete a
cycle.
Low Oil Send in for service.
Air in Hydraulic System
Press trigger and
hold retract button
simultaneously.
Run for
approximately 10
seconds, and then
attempt to cut.
If unsuccessful,
contact Greenlee
customer service
at 800-435-0786
for warranty
service or repair.
Cold Oil
Press trigger and
hold retract button
simultaneously
10-20 seconds
to warm oil.
Press trigger and
complete a cycle.
Repeat until tool
completes a cycle
successfully.
Red LED glows
for 20 seconds. Low Battery Charge or replace battery.
Tool loses oil. Damaged Seal Send in for service.

15 Ton Battery-Powered Crimping Tool
15
52080019 REV 05 © 2022 Greenlee Tools, Inc.
Maintenance
Remove battery before cleaning. Use a damp cloth and
mild detergent to clean the housing. Allow the housing to
dry fully before using.
If necessary, recharge the batteries. Refer to the instruc-
tions supplied with the battery charger.
Do not attempt to open the tool. It contains no user-
serviceable parts.
• Tool service must be performed only by qualified
repair personnel. Service or maintenance
performed by unqualied personnel could result in
a risk of injury.
When servicing a tool, use only identical
replacement parts. Use of unauthorized parts or
failure to follow maintenance instructions may create
a risk of electric shock or injury.
Service
• Do not perform any maintenance other than
as described in this manual. Personal injury or
damage to the tool may result.
• Wear eye protection when operating or servicing
this tool.
• Remove battery before changing dies, adapters,
or jaws.
• Do not modify this tool. Modifying the tool in any
manner may result in personal injury and damage to
the tool.
• Do not use hands to check for oil leaks. Oil under
pressure easily punctures skin. If injured, seek
medical attention immediately. Failure to observe
this warning could result in serious injury, gangrene,
or death.
Disposal
Parts of these tools contain valuable materials and
can be recycled. There are companies that specialize
in recycling that may be found locally. Dispose of
the components in compliance with all applicable
regulations. Contact your local waste management
authority for more information
For EU Countries: Do not dispose of
electrical equipment with household waste!
According to the European Guideline
2012/19/EU for Waste Electrical and
Electronic Equipment and its implementation
into national legislation, electrical
equipment that is no longer usable must be
collected separately and disposed of in an
environmentally correct manner.
At either 3 years or 10,000 cycles, schedule a factory
service maintenance. Factory service includes general
inspections, replacement of tool’s di-electric hydraulic oil
and testing of tool by trained technicians.
When the Factory Service Date is approaching or arrived,
contact Greenlee Customer Service. Expedited shipping
is available.
Transportation & Storage
Before storing fully retract the ram. Place the tool in the
carrying case and store in a cool, dry place. Keep tool,
instructions, and accessories with the tool in the carry
case. Carrying strap is for carrying only, not to be used
to hang tool.
Remove battery before storing for more than 6 months.
Store battery with tool in carrying case or on charging
rack.

15 Ton Battery-Powered Crimping Tool
16 52080019 REV 05
© 2022 Greenlee Tools, Inc.
Model X—FCC ID: RFRMS42; IC ID:
4957A-MS42
USA requirements:
Responsible party: Greenlee Tools, Inc.
Rockford, IL 61109 USA
Note: This equipment has been tested and found to
comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference when the equipment is operated in
a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction
manual, may cause harmful interference to radio com-
munications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case
the user will be required to correct the interference at
his own expense.
This device complies with the RF exposure SAR
test exclusion requirements for portable devices, if a
minimum separation distance is kept. However, the
device shall be used in such a manner that the potential
for human contact during normal operation is minimized.
Canada requirements:
This device complies with Industry Canada’s license-
exempt RSSs. Operation is subject to the following two
conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including
interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux CNR d’Industrie
Canada applicables aux appareils radio exempts de
licence. L’exploitation est autorisée aux deux conditions
suivantes:
1) l’appareil ne doit pas produire de brouillage;
2) l’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est suscep-
tible d’en compromettre le fonctionnement.

MANUEL D’UTILISATION
52080019REV05 © 2022 GreenleeTools,Inc. 10/22
Numéro de série
Lire et comprendre toutes les instructions et les
renseignements de sécurité de ce manuel avant
l’utilisation ou l’entretien de cet outil.
Enregistrer ce produit sur www.greenlee.com
EK1550FLX & EK1550SLX
GATOR®alimentation par batterie,
outil de sertissage 15tonnes
English.................. 1
Español............... 33
EK1550FLX
EK1550SLX

Outil de sertissage à batterie 15tonnes
18 52080019REV05
© 2022 GreenleeTools,Inc.
CONSERVER CE MANUEL
Table des matières
Liste explicative des symboles de sécurité......19
Avertissements généraux*................................20
Renseignements de sécurité propres à l’outil..22
Coordonnées Greenlee ....................................22
Description de l’outil.........................................23
Caractéristiques ...............................................23
Identication de l’outil ......................................24
Décalques et emplacements............................24
Écran DELO......................................................25
Application I-Press ...........................................25
Formation et compétences ..............................26
Inspection avant utilisation...............................26
Préparation de la zone de travail et de l’outil...27
Choix des connecteurs et des matrices...........28
Fonctionnement de l’outil.................................29
Dépannage .......................................................30
Transport et entreposage .................................31
Réparation........................................................31
Entretien ...........................................................31
Mise au rebut....................................................31
Déclarations requises.......................................32

Outil de sertissage à batterie 15tonnes
19
52080019REV05 © 2022 GreenleeTools,Inc.
RENSEIGNEMENTS DE SÉCURITÉ IMPORTANTS
SYMBOLE
D’AVERTISSE-
MENT DE
SÉCURITÉ
Ce symbole met en garde contre les risques ou les
pratiques dangereuses pouvant causer des blessures
ou des dommages matériels. Le mot indicateur, déni
ci-dessous, indique la gravité du danger. Le message
après le mot indicateur fournit des renseignements
qui permettent de prévenir ou d’éviter le danger.
Dangers immédiats qui, s’il ne sont pas évités,
ENTRAÎNERONT des blessures graves, voire mortelles.
Dangers qui, s’ils ne sont pas évités, POURRAIENT
entraîner des blessures graves, voire mortelles.
Dangers ou pratiques dangereuses qui, s’ils ne sont
pas évités, SONT SUSCEPTIBLES d’entraîner des
blessures ou des dommages matériels.
Ce symbole signie qu’il faut
toujoursporter des lunettes de
sécurité à écrans latéraux ou
deslunettes deprotection lors
delamanipulation ou de l’utilisation
decetéquipement an de réduire
lerisque de blessures oculaires.
Ce symbole signie qu’il faut lire
attentivement le manuel d’utilisation
avant d’utiliser l’équipement.
Lemanuel d’utilisation contient
desrenseignements importants sur
la sécurité et le bon fonctionnement
del’équipement.
Ce symbole indique un risque
dedécharge électrique.
Ce symbole indique le risque
queduliquide sous pression
soitdirigé vers les mains ou des
parties du corps, provoquant des
blessures par perforation de la
peauet par injection.
Ce symbole indique le risque
dedéclenchement d’incendie.
Toujours porter des gants lors de
la manipulation ou de l’utilisation
de cet équipement pour réduire
lerisque de blessures.
Ce symbole indique le risque de
blessures dues à des objets volants.
Ce symbole indique le risque de
blessures dues à des objets volants.
DANGER
AVERTISSEMENT
ATTENTION

Outil de sertissage à batterie 15tonnes
20 52080019REV05
© 2022 GreenleeTools,Inc.
Lire tous les avertissements de sécurité, les
instructions, les illustrations et les caractéristiques
fournis avec cet outil électrique. Veiller à respecter
toutes les instructions ci-dessous pour écarter les
risques de décharge électrique, d’incendie et (ou)
de blessure grave.
CONSERVER TOUS LES AVERTISSEMENTS
ET TOUTES LES INSTRUCTIONS POUR
CONSULTATION ULTÉRIEURE.
Dans les avertissements, le terme «outil électrique» fait référence
àunoutil électrique fonctionnant sur le courant secteur (à fil)
ouàunoutil électrique à batterie (sans fil).
SÉCURITÉ DE LA ZONE DE TRAVAIL
• Garder la zone de travail propre et bien éclairée.
Les endroits sombres et encombrés favorisent les
accidents.
• Ne pas utiliser les outils électriques dans des
atmosphères explosives, notamment en présence
de liquides, gaz ou poussières inflammables.
Les outils électriques produisent des étincelles
susceptibles d’enammer les poussières ou
lesvapeurs.
• Tenir les enfants et autres personnes présentes
à l’écart durant l’utilisation d’un outil électrique.
Les distractions peuvent provoquer une perte
decontrôle.
SÉCURITÉ EN MATIÈRE D’ÉLECTRICITÉ
• La fiche de l’outil électrique doit correspondre
au type de prise. Ne jamais modifier la fiche
d’une quelconque manière. Ne pas utiliser de
ched’adaptation sur des outils électriques à che
de terre. L’utilisation de che d’origine et d’une
priseappropriée contribue à réduire le risque
dedécharge électrique.
• Éviter tout contact corporel avec des surfaces
reliées à la masse ou à la terre, notamment les
tuyaux, radiateurs, cuisinières et réfrigérateurs.
La mise à la terre du corps accroît le risque de
décharge électrique.
• Ne pas exposer les outils électriques à la pluie
ou à l’humidité. L’inltration d’eau dans un outil
électrique accroît le risque de décharge électrique.
• Ne pas malmener le cordon. Ne jamais utiliser
le cordon pour porter, tirer ou débrancher l’outil
électrique. Tenir le cordon à l’écart de sources de
chaleur, d’huile, d’arêtes coupantes ou de pièces
mobiles. Un cordon endommagé ou emmêlé accroît
le risque de décharge électrique.
• Lors de l’utilisation d’un outil électrique
àl’extérieur, utiliser un cordon de rallonge
prévupour l’extérieur. L’utilisation d’une
rallongeconçue pour l’extérieur réduit le risque
dedécharge électrique.
Avertissements généraux* • Si un outil électrique doit absolument être utilisé
dans un endroit humide, utiliser une alimentation
électrique protégée par DÉTECTEUR DE FUITE
À LA TERRE (DFT). L’utilisation d’un DFT réduit le
risque de décharge électrique.
SÉCURITÉ INDIVIDUELLE
• Faites preuve de vigilance, de concentration
et de bon sens lors de l’utilisation d’un outil
électrique. Ne pas utiliser un outil électrique
alors qu’on est fatigué ou sous l’inuence de
drogues, d’alcool ou de médicaments. Un instant
d’inattention durant l’utilisation d’un outil électrique
peut entraîner des blessures graves.
• Utiliser un équipement de protection individuelle
(EPI). Toujours porter une protection oculaire.
Les équipements de protection tels qu’un masque
anti-poussière, des chaussures de sécurité
antidérapantes, un casque ou une protection
auditive utilisés dans des conditions appropriées
réduisent les risques de blessure.
• Éviter tout démarrage accidentel. S’assurer
que l’interrupteur est en position d’arrêt avant de
raccorder l’outil à une prise de courant ou à une
BATTERIE, de le saisir ou de le transporter. Le
fait de porter un outil électrique avec le doigt sur
l’interrupteur ou de mettre sous tension un outil
électrique avec l’interrupteur en position de marche
favorise les accidents.
• Veiller à enlever toute clé ou tout outil de réglage
avant de mettre l’outil électrique en marche. Une
clé laissée ou attachée sur une pièce tournante de
l’outil électrique peut entraîner des blessures.
• Ne pas travailler à bout de bras. Maintenir toujours
un bon appui et un bon équilibre. Cela permet un
meilleur contrôle de l’outil électrique en cas d’imprévu.
• Porter une tenue appropriée. Ne pas porter de
vêtements amples ni de bijoux. Tenir les cheveux,
les vêtements et les gants à l’écart des pièces
mobiles. Les vêtements amples, les bijoux ou les
cheveux longs peuvent se prendre dans les pièces
en mouvement.
• Si des mécanismes sont prévus pour le
raccordement à des équipements d’extraction
et de collecte de poussière, s’assurer qu’ils sont
correctement raccordés et utilisés. L’utilisation
d’un dispositif de captation des poussières peut
réduire les dangers liés à la poussière.
• Ne pas laisser la familiarité acquise par une
utilisation fréquente de l’outil entraîner une
baisse de la vigilance ou le non-respect des
principes de sécurité. Un geste imprudent peut
provoquer des blessures graves en une fraction
deseconde.
UTILISATION ET ENTRETIEN DE L’OUTIL
ÉLECTRIQUE
• Ne pas forcer sur l’outil électrique. Utiliser
l’outilélectrique adapté au travail à effectuer.
L’outilélectrique adapté assure un travail plus
correct et plus sûr, au régime pour lequel il a
étéconçu.
AVERTISSEMENT
