Greenlee 658 Guide

999 6439.2 © 1996 Greenlee Textron Inc. IM 800 Rev 6 8/96
658
TRAY TYPE SHEAVE
OPERATION, SERVICE AND PARTS
INSTRUCTION MANUAL
Read and understand this material before operating
or servicing this tool. Failure to understand how to
safely operate this tool could result in an accident
causing serious injury or death. This tool should only
be operated by qualified personnel.

Greenlee Textron Inc. / Subsidiary of Textron Inc. 24455 Boeing Drive, Rockford, IL 61109 815/397-7070
TrayType Sheave
The 658 Tray Type Sheave is designed to help roll and
guide cable during tray pulls.
Installation
1. Position the tray frame where needed.
2. Clamp at least 2 of the of the cable tray rungs
between the tray frame and clamp plate.
3. Fasten with carriage bolts and wing nuts.
Description
• Follow cable tray manufacturer’s and cable
manufacturer’s instructions when pulling cable
in tray.
• Read and understand instruction manual
included with cable puller.
Failure to observe these warnings could result in
severe injury or death.
Tray-type Pulling Setup
WRONG WAY
RIGHT WAY

Greenlee Textron Inc. / Subsidiary of Textron Inc. 34455 Boeing Drive, Rockford, IL 61109 815/397-7070
TrayType Sheave
Key Part Number Description Qty
1 501 5362.5 Sheave ..............................................................................................1
2 905 0302.3 Spring Clip .........................................................................................2
3 501 7323.5 Sheave Pin Unit, 6-1/4" (includes 2 Key #2) .....................................1
4 502 5651.3 Tray Frame ........................................................................................1
5 501 7327.8 Clamp Plate .......................................................................................1
6 501 7324.3 Carriage Bolt 7/16-14 x 3" .................................................................2
7 501 7325.1 Wing Nut, 7/16-14..............................................................................2
658TrayType Sheave
7
5
4
3
2
1
6
